1jy7

THE STRUCTURE OF HUMAN METHEMOGLOBIN. THE VARIATION OF A THEME

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Hemoglobin alpha chain

OrganismNot specified

UniProt P69905

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 4 Hemoglobin beta chain × 2 （P68871） PROTOPORPHYRIN IX CONTAINING FE × 4 Consistent with protein count
2 Protein heterocomplex Heteromer Protein 4 Hemoglobin beta chain × 2 （P68871） PROTOPORPHYRIN IX CONTAINING FE × 4 Consistent with protein count
3 Protein heterocomplex Heteromer Protein 4 Hemoglobin beta chain × 2 （P68871） PROTOPORPHYRIN IX CONTAINING FE × 4 Consistent with protein count

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
1a00 1a01 1a0u 1a0z 1a3n 1a3o 1a9w 1abw 1aby 1aj9 1b86 1bab

413 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name HBA_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 1–141； UniProt 1–141 Author chain C； PDBConstruct 1–141； UniProt 1–141 Author chain P； PDBConstruct 1–141； UniProt 1–141 Author chain R； PDBConstruct 1–141； UniProt 1–141 Author chain U； PDBConstruct 1–141； UniProt 1–141 Author chain W； PDBConstruct 1–141； UniProt 1–141

Hemoglobin beta chain

OrganismNot specified

UniProt P68871

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 4 Hemoglobin alpha chain × 2 （P69905） PROTOPORPHYRIN IX CONTAINING FE × 4 Consistent with protein count
2 Protein heterocomplex Heteromer Protein 4 Hemoglobin alpha chain × 2 （P69905） PROTOPORPHYRIN IX CONTAINING FE × 4 Consistent with protein count
3 Protein heterocomplex Heteromer Protein 4 Hemoglobin alpha chain × 2 （P69905） PROTOPORPHYRIN IX CONTAINING FE × 4 Consistent with protein count

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer
1cbl 1cbm 6fqf 9ww1

4 assemblies

Other homooligomers

None

Heteromeric or nucleic-acid complex
1a00 1a01 1a0u 1a0z 1a3n 1a3o 1abw 1aby 1aj9 1b86 1bab 1bbb

396 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name HBB_HUMAN
Isoform —
PDB entities 2
Chains and sequence ranges Author chain B； PDBConstruct 1–146； UniProt 1–146 Author chain D； PDBConstruct 1–146； UniProt 1–146 Author chain Q； PDBConstruct 1–146； UniProt 1–146 Author chain S； PDBConstruct 1–146； UniProt 1–146 Author chain V； PDBConstruct 1–146； UniProt 1–146 Author chain X； PDBConstruct 1–146； UniProt 1–146

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id1jy7
Deposition date deposition_date2001-09-11
Structure title titleTHE STRUCTURE OF HUMAN METHEMOGLOBIN. THE VARIATION OF A THEME
Keywords keywordsHUMAN METHEMOGLOBIN, OXYGEN TRANSPORT, OXYGEN STORAGE-TRANSPORT COMPLEX; OXYGEN STORAGE/TRANSPORT
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1jy7__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1jy7__assembly_1__model_1 | I(q)

10-2 10-1 106 107 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

1jy7__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）25.24 Å
Rg (electron density)24.01 Å
Total Rg24.95 Å
Atom count4556
Residues574
Excluded volume81558 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 1jy7__assembly_1__model_1 tetrameric （4） Success 4.1.3-1-20251215 (887e7ef) View Download
2 1 1jy7__assembly_2__model_1 tetrameric （4） Success 4.1.3-1-20251215 (887e7ef) View Download
3 1 1jy7__assembly_3__model_1 tetrameric （4） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (3)

▼

6. Fold Classification (SCOP + CATH) 24 domains

SCOP 2.08 (12 domains)

Domain ID domain_idd1jy7a_
Class classa — All alpha proteins
Fold Fold folda.1 — Globin-like
Superfamily Superfamily superfamilya.1.1 — Globin-like
Family Family familya.1.1.2 — Globins
Domain ID domain_idd1jy7b_
Class classa — All alpha proteins
Fold Fold folda.1 — Globin-like
Superfamily Superfamily superfamilya.1.1 — Globin-like
Family Family familya.1.1.2 — Globins
Domain ID domain_idd1jy7c_
Class classa — All alpha proteins
Fold Fold folda.1 — Globin-like
Superfamily Superfamily superfamilya.1.1 — Globin-like
Family Family familya.1.1.2 — Globins
Domain ID domain_idd1jy7d_
Class classa — All alpha proteins
Fold Fold folda.1 — Globin-like
Superfamily Superfamily superfamilya.1.1 — Globin-like
Family Family familya.1.1.2 — Globins
Domain ID domain_idd1jy7p_
Class classa — All alpha proteins
Fold Fold folda.1 — Globin-like
Superfamily Superfamily superfamilya.1.1 — Globin-like
Family Family familya.1.1.2 — Globins
Domain ID domain_idd1jy7q_
Class classa — All alpha proteins
Fold Fold folda.1 — Globin-like
Superfamily Superfamily superfamilya.1.1 — Globin-like
Family Family familya.1.1.2 — Globins
Domain ID domain_idd1jy7r_
Class classa — All alpha proteins
Fold Fold folda.1 — Globin-like
Superfamily Superfamily superfamilya.1.1 — Globin-like
Family Family familya.1.1.2 — Globins
Domain ID domain_idd1jy7s_
Class classa — All alpha proteins
Fold Fold folda.1 — Globin-like
Superfamily Superfamily superfamilya.1.1 — Globin-like
Family Family familya.1.1.2 — Globins
Domain ID domain_idd1jy7u_
Class classa — All alpha proteins
Fold Fold folda.1 — Globin-like
Superfamily Superfamily superfamilya.1.1 — Globin-like
Family Family familya.1.1.2 — Globins
Domain ID domain_idd1jy7v_
Class classa — All alpha proteins
Fold Fold folda.1 — Globin-like
Superfamily Superfamily superfamilya.1.1 — Globin-like
Family Family familya.1.1.2 — Globins
Domain ID domain_idd1jy7w_
Class classa — All alpha proteins
Fold Fold folda.1 — Globin-like
Superfamily Superfamily superfamilya.1.1 — Globin-like
Family Family familya.1.1.2 — Globins
Domain ID domain_idd1jy7x_
Class classa — All alpha proteins
Fold Fold folda.1 — Globin-like
Superfamily Superfamily superfamilya.1.1 — Globin-like
Family Family familya.1.1.2 — Globins

CATH v4.4 (12 domains)

Domain ID domain_id1jy7A00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology490 — Globin-like
Homologous superfamily homologous superfamily10 — Globins
Domain ID domain_id1jy7B00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology490 — Globin-like
Homologous superfamily homologous superfamily10 — Globins
Domain ID domain_id1jy7C00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology490 — Globin-like
Homologous superfamily homologous superfamily10 — Globins
Domain ID domain_id1jy7D00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology490 — Globin-like
Homologous superfamily homologous superfamily10 — Globins
Domain ID domain_id1jy7P00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology490 — Globin-like
Homologous superfamily homologous superfamily10 — Globins
Domain ID domain_id1jy7Q00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology490 — Globin-like
Homologous superfamily homologous superfamily10 — Globins
Domain ID domain_id1jy7R00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology490 — Globin-like
Homologous superfamily homologous superfamily10 — Globins
Domain ID domain_id1jy7S00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology490 — Globin-like
Homologous superfamily homologous superfamily10 — Globins
Domain ID domain_id1jy7U00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology490 — Globin-like
Homologous superfamily homologous superfamily10 — Globins
Domain ID domain_id1jy7V00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology490 — Globin-like
Homologous superfamily homologous superfamily10 — Globins
Domain ID domain_id1jy7W00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology490 — Globin-like
Homologous superfamily homologous superfamily10 — Globins
Domain ID domain_id1jy7X00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology490 — Globin-like
Homologous superfamily homologous superfamily10 — Globins
▶

7. Citations (5)
