SAXSdb — 2mxc

▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Sorting nexin-3

Homo sapiens

State in the Current Structure

Assembly	Oligomeric State	Construct	Mutations and Modifications	Ligands, Ions and Associated Components	Method and Experimental Conditions	Structure Quality
1	Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count	Chain A； UniProt 2–162	Not recorded	No other associated polymer	SOLUTION NMR NMR measurement conditions：pH 6.5；298 K；Ionic strength (raw mmCIF value) 0.100；Pressure 1.000 NMR sample composition：0.5 mM [U-100% 13C; U-100% 15N] SNX3FL, 90% H2O/10% D2O \| 90% H2O/10% D2O	Resolution not provided

Other States of the Same Protein in the Database

Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.

Other PDB	Difference from Current Entry 2MXC	Assembly / Oligomeric State	Construct	Mutations and Modifications	Ligands, Ions and Non-polymers	Method and Experimental Conditions	Structure Quality
2YPS Crystal structure of the PX domain of human sorting nexin 3 Deposited 2012-10-31	Different construct Different experimental method Different experimental conditions Different structure-quality metrics	Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric	Chain A 24–155（132 aa） Fragment：PX DOMAIN, RESIDUES 24-155	Not recorded	No recorded non-water small molecule	X-RAY DIFFRACTION X-ray crystallization conditions 3.5M FORMATE	Resolution 2.60 Å R-free 0.255
2YPS Crystal structure of the PX domain of human sorting nexin 3 Deposited 2012-10-31	Different construct Different experimental method Different experimental conditions Different structure-quality metrics	Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric	Chain B 24–155（132 aa） Fragment：PX DOMAIN, RESIDUES 24-155	Not recorded	No recorded non-water small molecule	X-RAY DIFFRACTION X-ray crystallization conditions 3.5M FORMATE	Resolution 2.60 Å R-free 0.255
2YPS Crystal structure of the PX domain of human sorting nexin 3 Deposited 2012-10-31	Different construct Different experimental method Different experimental conditions Different structure-quality metrics	Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric	Chain C 24–155（132 aa） Fragment：PX DOMAIN, RESIDUES 24-155	Not recorded	No recorded non-water small molecule	X-RAY DIFFRACTION X-ray crystallization conditions 3.5M FORMATE	Resolution 2.60 Å R-free 0.255
2YPS Crystal structure of the PX domain of human sorting nexin 3 Deposited 2012-10-31	Different construct Different experimental method Different experimental conditions Different structure-quality metrics	Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric	Chain D 24–155（132 aa） Fragment：PX DOMAIN, RESIDUES 24-155	Not recorded	No recorded non-water small molecule	X-RAY DIFFRACTION X-ray crystallization conditions 3.5M FORMATE	Resolution 2.60 Å R-free 0.255
5F0J Structure of retromer VPS26-VPS35 subunits bound to SNX3 Deposited 2015-11-27	Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics	Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric	Chain C 1–162（162 aa）	Not recorded	SO4 SULFATE ION × 6 GOL GLYCEROL × 5 EDO 1,2-ETHANEDIOL × 24	X-RAY DIFFRACTION X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6；291 K；0.9 M AmSO4, 0.1 M MES pH 6.0	Resolution 2.70 Å R-free 0.246
5F0L Structure of retromer VPS26-VPS35 subunits bound to SNX3 and DMT1 Deposited 2015-11-27	Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics	Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric	Chain C 1–162（162 aa） Fragment：Residues 14-470	Not recorded	SO4 SULFATE ION × 10 GOL GLYCEROL × 6 EDO 1,2-ETHANEDIOL × 18	X-RAY DIFFRACTION X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6；291 K；0.75 M AmSO4, 0.1 M MES pH 6.0, 15% Glycerol	Resolution 3.20 Å R-free 0.259
5F0M Structure of retromer VPS26-VPS35 subunits bound to SNX3 and DMT1 (SeMet labeled) Deposited 2015-11-27	Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics	Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric	Chain C 1–162（162 aa） Fragment：Residues 14-470	Not recorded	SO4 SULFATE ION × 6 GOL GLYCEROL × 5 EDO 1,2-ETHANEDIOL × 12	X-RAY DIFFRACTION X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6；291 K；0.8 M AmSO4, 0.1 M MES pH 6.0, 5% Glycerol	Resolution 3.10 Å R-free 0.254
5F0P Structure of retromer VPS26-VPS35 subunits bound to SNX3 and DMT1(L557M) (SeMet labeled) Deposited 2015-11-27	Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics	Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric	Chain C 1–162（162 aa） Fragment：Residues 1-162	Not recorded	SO4 SULFATE ION × 6 GOL GLYCEROL × 4 EDO 1,2-ETHANEDIOL × 20 ZN ZINC ION × 1	X-RAY DIFFRACTION X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6；291 K；0.8 M AmSO4, 0.1 M MES pH 6.0, 10% Glycerol	Resolution 2.78 Å R-free 0.261

5 other PDB entries and 8 assemblies. Open the comparison page and filter oligomeric states

View Construct and Data Evidence

UniProt name	SNX3_HUMAN
Isoform	—
PDB entities	1
Chains and sequence ranges	Author chain A； PDBConstruct 12–172； UniProt 2–162

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id	2mxc
Deposition date deposition_date	2014-12-20
Structure title title	Solution structure of the full length sorting nexin 3
Keywords keywords	PI3P, SNX3, membrane, endosome, protein transport; PROTEIN TRANSPORT
Experimental Method method	SOLUTION NMR

▼

3. SAXS Parameters (CRYSOL theoretical calculation) 3. SAXS Parameters (CRYSOL)

Radius of gyration Rg (Guinier) rg_guinier	23.21 Å
Radius of gyration Rg (electron density) rg_electron	22.75 Å
Forward intensity I(0) i0	2288310000.00
Molecular weight molecular_weight	398310.0 kDa
Excluded volume excluded_volume	496450 Å³
Envelope volume envelope_volume	188420 Å³
Hydration-shell volume shell_volume	43103 Å³
Envelope diameter envelope_diameter	122.8 Å
Shell Rg shell_rg	41.05 Å
Envelope Rg envelope_rg	40.12 Å
Shape Rg shape_rg	22.77 Å
Total Rg total_rg	23.16 Å
Total atoms total_atoms	56160
Residues n_residues	3440
Spherical-harmonic order n_harmonics	20
q range q_range	— – 0.5000 Å⁻¹
Data points n_points	101
Shell type shell_type	directional
Solvent electron density solvent_density	0.3340 e/Å³
Shell contrast contrast_shell	0.0300 e/Å³
CRYSOL version crysol_version	4.1.3

▼

4. P(r) Distance Distribution (GNOM inversion) 4. P(r) Analysis (GNOM)

Maximum dimension Dmax dmax	63.3 Å
Rg (real space) rg_real	20.79 Å
Rg uncertainty (real space) rg_real_error	0.19 Å
I(0) (real space) i0_real	2.1670e+09
I(0) uncertainty (real space) i0_real_error	2.1420e+07
Rg (reciprocal space) rg_reciprocal	23.90 Å
I(0) (reciprocal space) i0_reciprocal	2288000000.0000
Solution quality estimate total_estimate	0.6502
Solution quality rating solution_quality	REASONABLE a REASONABLE solution
P(r) peaks n_peaks	1
Primary peak position r_peak_primary	19.5 Å
Skewness Skewness skewness	0.574
Kurtosis Kurtosis kurtosis	-0.292
Angular range angular_range	— – 0.3400 Å⁻¹
Current regularization parameter α current_alpha	1.4850
Highest regularization parameter α highest_alpha	1538000.0000
Real-space data points n_real_points	66
GNOM version gnom_version	4.1.3
Quality Criteria quality_criteria	AN1: 0.011; Oscil: 0.869; Stabil: 0.994; Sysdev: 0.000; Positv: 1.000; Valcen: 0.886; Smooth: 0.000

▶

5. Crystallography and Experiment 5. Crystallography & Experiment

▶

6. Entities and Polymers Entities & Polymers (1)

▼

7. Fold Classification (SCOP + CATH) 1 domains

CATH v4.4 (1 domains)

Domain ID domain_id	2mxcA01
Class class	3 — Alpha Beta
Architecture architecture	30 — 2-Layer Sandwich
Topology topology	1520 — PX Domain
Homologous superfamily homologous superfamily	10 — Phox-like domain

▶

8. Citations (1)

▶

Description description	Sorting nexin-3
Molecular weight formula_weight	19947.6 kDa
Source method src_method	man
Copy count entity_count	1

Polymer type type	polypeptide(L)
Chain IDs strand_id	A
Atom count atom_count	56160

来源生物 organism	Homo sapiens
通用名 common_name	human
NCBI Class编号 ncbi_taxonomy_id	9606
宿主生物 host_organism	Escherichia coli

fit	/app/data/saxs_computation/mx/2mxc/2mxc.fit
pddf	/app/data/pr_computation/mx/2mxc/2mxc.pr.out
profile	/app/data/saxs_computation/mx/2mxc/2mxc.dat

Solution structure of the full length sorting nexin 3

1. Protein Identity and Related Structures Protein Identity & Related Structures

Sorting nexin-3

State in the Current Structure

Other States of the Same Protein in the Database

SAXS scattering curve SAXS Profile

P(r) Distance Distribution P(r) Distribution
