3ca2

CRYSTALLOGRAPHIC STUDIES OF INHIBITOR BINDING SITES IN HUMAN CARBONIC ANHYDRASE II. A PENTACOORDINATED BINDING OF THE SCN-ION TO THE ZINC AT HIGH P*H

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

CARBONIC ANHYDRASE II

Homo sapiens

UniProt P00918

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein monomer Monomer Protein 1 MERCURY (II) ION × 2 ZINC ION × 1 3-MERCURI-4-AMINOBENZENESULFONAMIDE × 1 water × 1 Consistent with protein count

Other States of the Same Protein in the Database

Monomer
12ca 1a42 1am6 1avn 1bcd 1bic 1bn1 1bn3 1bn4 1bnm 1bnn 1bnq

1245 assemblies; showing the first 12

Homodimer
3l14 4lp6

2 assemblies

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
3hkn 3hkt 4ywp 5l3o 5l6k 5l6t 5l70 5l9e 5l9e 5l9e 5l9e 5lvs

26 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name CAH2_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 1–259； UniProt 1–259

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id3ca2
Deposition date deposition_date1989-10-02
Structure title titleCRYSTALLOGRAPHIC STUDIES OF INHIBITOR BINDING SITES IN HUMAN CARBONIC ANHYDRASE II. A PENTACOORDINATED BINDING OF THE SCN-ION TO THE ZINC AT HIGH P*H
Keywords keywordsLYASE(OXO-ACID); LYASE(OXO-ACID)
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

3ca2__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

3ca2__assembly_1__model_1 | I(q)

10-2 10-1 105 106 107 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

3ca2__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）18.40 Å
Rg (electron density)17.28 Å
Total Rg18.20 Å
Atom count2054
Residues256
Excluded volume36509 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 3ca2__assembly_1__model_1 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (5)

▼

6. Fold Classification (SCOP + CATH) 2 domains

SCOP 2.08 (1 domains)

Domain ID domain_idd3ca2a_
Class classb — All beta proteins
Fold Fold foldb.74 — Carbonic anhydrase
Superfamily Superfamily superfamilyb.74.1 — Carbonic anhydrase
Family Family familyb.74.1.1 — Carbonic anhydrase

CATH v4.4 (1 domains)

Domain ID domain_id3ca2A00
Class class3 — Alpha Beta
Architecture architecture10 — Roll
Topology topology200 — Carbonic Anhydrase II
Homologous superfamily homologous superfamily10 — Alpha carbonic anhydrase
▶

7. Citations (5)
