Myoglobin
Equus caballus
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain A； UniProt 2–154 | Mutation：H64V, V67R | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 PO4 PHOSPHATE ION × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；ammonium phosphate, EDTA, pH 6.4, VAPOR DIFFUSION, HANGING DROP, temperature 295K | Resolution 1.90 Å R-free 0.233 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 3HEN | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 1AZI MYOGLOBIN (HORSE HEART) RECOMBINANT WILD-TYPE COMPLEXED WITH AZIDE Deposited 1997-10-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 1 AZI AZIDE ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å |
| 1BJE H64T VARIANT OF MYOGLOBIN (HORSE HEART) RECOMBINANT WILD-TYPE COMPLEXED WITH AZIDE Deposited 1997-10-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Mutation：H64T | SO4 SULFATE ION × 1 AZI AZIDE ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.80 Å |
| 1DWR MYOGLOBIN (HORSE HEART) WILD-TYPE COMPLEXED WITH CO Deposited 1999-12-11 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 CMO CARBON MONOXIDE × 1 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；HHMB(SIGMA) WAS CRYSTALLIZED AT ROOM TEMPERATURE BY EQUILIBRATING 10 UL DROPS OF 5 MG/ML PROTEIN IN 1.7-1.8 M AMMONIUM SULFATE, 0.1 M TRIS HCL PH 7.5 USING THE HANGING DROP GEOMETRY
|
Resolution 1.45 Å R-free 0.255 |
| 1DWS PHOTOLYZED CARBONMONOXY MYOGLOBIN (HORSE HEART) Deposited 1999-12-11 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 CMO CARBON MONOXIDE × 1 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；HHMB(SIGMA) WAS CRYSTALLIZED AT ROOM TEMPERATURE BY EQUILIBRATING 10 UL DROPS OF 5 MG/ML PROTEIN IN 1.7-1.8 M AMMONIUM SULFATE, 0.1 M TRIS HCL PH 7.5 USING THE HANGING DROP GEOMETRY
|
Resolution 1.45 Å R-free 0.251 |
| 1DWT Photorelaxed horse heart MYOGLOBIN CO complex Deposited 1999-12-12 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 CMO CARBON MONOXIDE × 1 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；HHMB(SIGMA) WAS CRYSTALLIZED AT ROOM TEMPERATURE BY EQUILIBRATING 10 UL DROPS OF 5 MG/ML PROTEIN IN 1.7-1.8 M AMMONIUM SULFATE, 0.1 M TRIS HCL PH 7.5 USING THE HANGING DROP GEOMETRY
|
Resolution 1.40 Å R-free 0.243 |
| 1HRM THE PROXIMAL LIGAND VARIANT HIS93TYR OF HORSE HEART MYOGLOBIN Deposited 1994-09-21 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.70 Å |
| 1HSY ORIGIN OF THE PH-DEPENDENT SPECTROSCOPIC PROPERTIES OF PENTACOORDINATE METMYOGLOBIN VARIANTS Deposited 1994-12-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.90 Å |
| 1NPF MYOGLOBIN (HORSE HEART) WILD-TYPE COMPLEXED WITH NITRIC OXIDE Deposited 2003-01-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 2 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 NO NITRIC OXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；AMMONIUM SULFATE, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 100K
|
Resolution 1.90 Å R-free 0.247 |
| 1NPG MYOGLOBIN (HORSE HEART) WILD-TYPE COMPLEXED WITH NITROSOETHANE Deposited 2003-01-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 2 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 NOE NITROSOETHANE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；AMMONIUM SULFATE, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 100K
|
Resolution 1.70 Å R-free 0.225 |
| 1NZ2 K45E Variant of Horse Heart Myoglobin Deposited 2003-02-15 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Mutation：K45E | SO4 SULFATE ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.3；298 K；Ammonium Sulfate, pH 7.3, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.90 Å |
| 1NZ3 K45E-K63E Variant of Horse Heart Myoglobin Deposited 2003-02-15 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Mutation：K45E, K63E | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.3；298 K；ammonium sulfate, pH 7.3, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.60 Å |
| 1NZ4 The horse heart myoglobin variant K45E/K63E complexed with Cadmium Deposited 2003-02-15 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Mutation：K45E, K63E | CD CADMIUM ION × 2 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.3；298 K；ammonium sulfate, pH 7.3, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.80 Å |
| 1NZ5 The Horse heart myoglobin variant K45E/K63E complexed with Manganese Deposited 2003-02-15 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Mutation：K45E, K63E | MN MANGANESE (II) ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.70 Å |
| 1RSE MYOGLOBIN (HORSE HEART) MUTANT WITH SER 92 REPLACED BY ASP (S92D) Deposited 1996-06-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Mutation：S92D | SO4 SULFATE ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.70 Å |
| 1WLA MYOGLOBIN (HORSE HEART) RECOMBINANT WILD-TYPE Deposited 1997-09-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.70 Å |
| 1XCH MYOGLOBIN (HORSE HEART) MUTANT WITH LEU 104 REPLACED BY ASN (L104N) Deposited 1997-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Mutation：L104N | SO4 SULFATE ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.4；20 MM TRIS/HCL, 1MM EDTA, PH 8.4, 8 MG/ML PROTEIN 69% AMMONIUM SULFATE
|
Resolution 1.70 Å |
| 1YMA STRUCTURAL CHARACTERIZATION OF HEME LIGATION IN THE HIS64-->TYR VARIANT OF MYOGLOBIN Deposited 1993-09-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å |
| 1YMB HIGH RESOLUTION STUDY OF THE THREE-DIMENSIONAL STRUCTURE OF HORSE HEART METMYOGLOBIN Deposited 1993-09-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.90 Å |
| 1YMC THREE-DIMENSIONAL STRUCTURE OF CYANOMET-SULFMYOGLOBIN C Deposited 1993-09-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 1 CYN CYANIDE ION × 1 CLN SULFUR SUBSTITUTED PROTOPORPHYRIN IX × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å |
| 2FRF Horse Heart Myoglobin, Nitrite Adduct, Crystal Soak Deposited 2006-01-19 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 2 NO2 NITRITE ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；295 K；Ammonium Sulfate/Tris-HCl, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.20 Å R-free 0.211 |
| 2FRI Horse Heart Myoglobin, Nitrite Adduct, Co-crystallized Deposited 2006-01-19 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain X
1–153（153 aa）
|
Not recorded | NO2 NITRITE ION × 1 SO4 SULFATE ION × 2 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；295 K；Ammonium Sulfate, Tris-HCl, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.60 Å R-free 0.206 |
| 2FRJ Nitrosyl Horse Heart Myoglobin, Nitrite/Dithionite Method Deposited 2006-01-19 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain X
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 2 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 NO NITRIC OXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；295 K；Ammonium Sulfate, Tris-HCl, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.30 Å R-free 0.220 |
| 2FRK Nitrosyl Horse Heart Myoglobin, Nitric Oxide Gas Method Deposited 2006-01-19 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain X
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 NO NITRIC OXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；295 K；Ammonium Sulfate, Tris-HCl, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.30 Å R-free 0.205 |
| 2IN4 Crystal Structure of Myoglobin with Charge Neutralized Heme, ZnDMb-dme Deposited 2006-10-05 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 1 HE5 ZINC(II)-DEUTEROPORPHYRIN DIMETHYLESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；12-17 mg/ml protein solution, 3.3 M ammonium sulfate, 0.1 M sodium acetate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.15 Å R-free 0.232 |
| 2NSR Nitromethane Modified Horse Heart Myoglobin Deposited 2006-11-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 2 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 NSM NITROSOMETHANE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；295 K；Ammonium Sulfate, Tris-HCl, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.90 Å R-free 0.231 |
| 2NSS Nitrobenzene Modified Horse Heart Myoglobin Deposited 2006-11-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 2 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 NBE NITROSOBENZENE × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；295 K；Ammonium sulfate, Tris-HCL, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 2.00 Å R-free 0.266 |
| 2O58 Horse heart met manganese myoglobin Deposited 2006-12-05 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain X
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 2 MNR PROTOPORPHYRIN IX CONTAINING MN × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；296 K；Ammonium sulfate, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 296K
|
Resolution 1.65 Å R-free 0.223 |
| 2O5B Manganese horse heart myoglobin, reduced Deposited 2006-12-05 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain X
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 3 MNH MANGANESE PROTOPORPHYRIN IX × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；296 K；Ammonium sulfate, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 296K
|
Resolution 2.00 Å R-free 0.239 |
| 2O5L Manganese horse heart myoglobin, methanol modified Deposited 2006-12-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain X
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 2 MNR PROTOPORPHYRIN IX CONTAINING MN × 1 MOH METHANOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；296 K；Ammonium sulfate, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 296K
|
Resolution 1.70 Å R-free 0.230 |
| 2O5M Manganese horse heart myoglobin, azide modified Deposited 2006-12-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain X
1–153（153 aa）
|
Not recorded | AZI AZIDE ION × 1 SO4 SULFATE ION × 2 MNR PROTOPORPHYRIN IX CONTAINING MN × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；296 K；Ammonium sulfate, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 296K
|
Resolution 1.65 Å R-free 0.221 |
| 2O5O Manganese horse heart myoglobin, nitrite modified Deposited 2006-12-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain X
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 2 NO2 NITRITE ION × 1 MNR PROTOPORPHYRIN IX CONTAINING MN × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；296 K；Ammonium sulfate, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 296K
|
Resolution 1.60 Å R-free 0.224 |
| 2O5Q Manganese horse heart myoglobin, nitric oxide modified Deposited 2006-12-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain X
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 2 MNH MANGANESE PROTOPORPHYRIN IX × 1 NO NITRIC OXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；296 K；Ammonium sulfate, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 296K
|
Resolution 1.90 Å R-free 0.235 |
| 2O5S Cobalt horse heart myoglobin, nitrite modified Deposited 2006-12-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain X
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 2 NO2 NITRITE ION × 1 COH PROTOPORPHYRIN IX CONTAINING CO × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；296 K；Ammonium sulfate, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 296K
|
Resolution 1.60 Å R-free 0.215 |
| 2O5T Cobalt horse heart myoglobin, oxidized Deposited 2006-12-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain X
1–153（153 aa）
|
Not recorded | SO4 SULFATE ION × 2 COH PROTOPORPHYRIN IX CONTAINING CO × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；296 K；Ammonium sulfate, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 296K
|
Resolution 1.60 Å R-free 0.248 |
| 2V1E Crystal structure of radiation-induced myoglobin compound II - intermediate H at pH 6.8 Deposited 2007-05-23 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 OH HYDROXIDE ION × 1 SO4 SULFATE ION × 2 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.8；BATCH METHOD: 6-12 MG/ML MYOGLOBIN, 80-85% OF THE CRYSTALLIZATION STOCK-SOLUTION (3.9 M AMMONIUM SULPHATE, 0.1 M MOPS AND 5-10% OF GLYCEROL), pH 6.80
|
Resolution 1.30 Å R-free 0.176 |
| 2V1F Crystal structure of radiation-induced myoglobin compound II - intermediate H at pH 8.7 Deposited 2007-05-24 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 OH HYDROXIDE ION × 1 SO4 SULFATE ION × 2 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.7；BATCH METHOD: 6-12 MG/ML MYOGLOBIN, 80-85% OF THE CRYSTALLIZATION STOCK-SOLUTION (3.9 M AMMONIUM SULPHATE, 0.1 M TAPS AND 5-10% OF GLYCEROL PH 8.7)
|
Resolution 1.20 Å R-free 0.163 |
| 2V1G Crystal structure of radiation-induced myoglobin compound II - intermediate H at pH 5.2 Deposited 2007-05-24 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 OH HYDROXIDE ION × 1 SO4 SULFATE ION × 2 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.2；6-10 MG/ML PROTEIN, 3.0 M AMMONIUM SULPHATE, 10.8% GLYCEROL PH 5.2, RT.
|
Resolution 1.35 Å R-free 0.174 |
| 2V1H Crystal structure of radiation-induced metmyoglobin - aqua ferrous myoglobin at pH 5.2 Deposited 2007-05-24 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.2；BATCH METHOD: 6-12 MG/ML MYOGLOBIN, 80-85% OF THE CRYSTALLIZATION STOCK-SOLUTION (3.9 M AMMONIUM SULPHATE, 5-10% OF GLYCEROL PH 5.2)
|
Resolution 1.30 Å R-free 0.165 |
| 2V1I Crystal structure of radiation-induced metmyoglobin - aqua ferrous myoglobin at pH 6.8 Deposited 2007-05-24 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.8；BATCH METHOD: 6-12 MG/ML MYOGLOBIN, 80-85% OF THE CRYSTALLIZATION STOCK-SOLUTION (3.9 M AMMONIUM SULPHATE, 0.1 M MOPS AND 5-10% OF GLYCEROL PH 6.8)
|
Resolution 1.20 Å R-free 0.168 |
| 2V1J Crystal structure of radiation-induced metmyoglobin - aqua ferrous myoglobin at pH 8.7 Deposited 2007-05-24 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.7；BATCH METHOD: 6-12 MG/ML MYOGLOBIN, 80-85% OF THE CRYSTALLIZATION STOCK-SOLUTION (3.9 M AMMONIUM SULPHATE, 0.1 M TAPS AND 5-10% OF GLYCEROL PH 8.7)
|
Resolution 1.40 Å R-free 0.166 |
| 2V1K Crystal structure of ferrous deoxymyoglobin at pH 6.8 Deposited 2007-05-24 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.8；BATCH METHOD: 6-12 MG/ML MYOGLOBIN, 80-85% OF THE CRYSTALLIZATION STOCK-SOLUTION (3.9 M AMMONIUM SULPHATE, 0.1 M MOPS AND 5-10% OF GLYCEROL PH 6.8)
|
Resolution 1.25 Å R-free 0.164 |
| 2VLX Crystal structure of peroxymyoglobin generated by cryoradiolytic reduction of myoglobin compound III Deposited 2008-01-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
Fragment：RESIDUES 2-154
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 PER PEROXIDE ION × 1 SO4 SULFATE ION × 2 GOL GLYCEROL × 2 PEO HYDROGEN PEROXIDE × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.8；BATCH METHOD: 6-12 MG/ML MYOGLOBIN, 80-85% OF THE CRYSTALLIZATION STOCK-SOLUTION (3.9 M AMMONIUM SULPHATE, 0.1 M MOPS, 5-10% OF GLYCEROL PH 6.8)
|
Resolution 1.30 Å R-free 0.175 |
| 2VLY Crystal structure of myoglobin compound III (radiation-induced) Deposited 2008-01-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
Fragment：RESIDUES 2-154
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 OXY OXYGEN MOLECULE × 1 SO4 SULFATE ION × 2 GOL GLYCEROL × 2 PEO HYDROGEN PEROXIDE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.8；CRYSTALLIZATION CONDITIONS: BATCH METHOD: 6-12 MG/ML MYOGLOBIN, 80-85% OF THE CRYSTALLIZATION STOCK-SOLUTION (3.9 M AMMONIUM SULPHATE, 0.1 M MOPS, 5-10% OF GLYCEROL PH 6.8)
|
Resolution 1.60 Å R-free 0.209 |
| 2VLZ Crystal structure of peroxymyoglobin generated by cryoradiolytic reduction of myoglobin compound III Deposited 2008-01-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
Fragment：RESIDUES 2-154
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 PER PEROXIDE ION × 1 SO4 SULFATE ION × 2 GOL GLYCEROL × 1 PEO HYDROGEN PEROXIDE × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.8；BATCH METHOD: 6-12 MG/ML MYOGLOBIN, 80-85% OF THE CRYSTALLIZATION STOCK-SOLUTION (3.9 M AMMONIUM SULPHATE, 0.1 M MOPS, 5-10% OF GLYCEROL PH 5.2)
|
Resolution 1.50 Å R-free 0.190 |
| 2VM0 Crystal structure of radiation-induced myoglobin compound II generated after annealing of peroxymyoglobin Deposited 2008-01-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
Fragment：RESIDUES 2-154
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 OH HYDROXIDE ION × 1 SO4 SULFATE ION × 2 GOL GLYCEROL × 1 PEO HYDROGEN PEROXIDE × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.8；BATCH METHOD: 6-12 MG/ML MYOGLOBIN, 80-85% OF THE CRYSTALLIZATION STOCK-SOLUTION (3.9 M AMMONIUM SULPHATE, 0.1 M MOPS, 5-10% OF GLYCEROL PH 6.8)
|
Resolution 1.60 Å R-free 0.190 |
| 3BA2 Cyanide bound Chlorin substituted Myoglobin Deposited 2007-11-07 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | SO4 SULFATE ION × 3 CYN CYANIDE ION × 1 HKL Fe(III) pyropheophorbide-a methyl ester × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；295 K；3.1M ammonium sulfate, 100mM Tris HCl, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.80 Å R-free 0.231 |
| 3HC9 Ferric Horse Heart Myoglobin; H64V mutant Deposited 2009-05-05 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Mutation：H64V | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 PO4 PHOSPHATE ION × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；ammonium phosphate, EDTA, horse heart myoglobin H64V mutant, pH 6.4, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 2.00 Å R-free 0.237 |
| 3HEO Ferric Horse Heart Myoglobin; H64V/V67R mutant, Nitrite Modified Deposited 2009-05-09 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Mutation：H64V, V67R | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 NO2 NITRITE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.8；295 K；ammonium phosphate, EDTA, crystal soaking with sodium nitrite, pH 6.8, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 2.00 Å R-free 0.258 |
| 3HEP Ferric Horse Heart Myoglobin; H64V Mutant, Nitrite Modified Deposited 2009-05-09 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Mutation：H64V | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 NO2 NITRITE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；ammonium phosphate, EDTA, crystal soaking with sodium nitrite, pH 6.4, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.95 Å R-free 0.250 |
| 3LR7 Ferric horse heart myoglobin, nitrite adduct Deposited 2010-02-10 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 NO2 NITRITE ION × 3 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
seeding；pH 7.4；295 K；2.76M ammonium sulfate, 100 mM TrisHCl, 1 mM EDTA, pH 7.4, seeding, temperature 295K
|
Resolution 1.60 Å R-free 0.247 |
| 3LR9 X-ray photogenerated ferrous horse heart myoglobin, nitrite adduct Deposited 2010-02-10 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 NO2 NITRITE ION × 4 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
seeding；pH 7.4；295 K；2.74 M ammonium sulfate, 100 mM TrisHCl, 1 mM EDTA, pH 7.4, seeding, temperature 295K
|
Resolution 1.55 Å R-free 0.212 |
| 3RJ6 Crystal Structure of Horse heart ferric myoglobin; K45E/K63E/K96E mutant Deposited 2011-04-15 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Mutation：K45E, K63E, K96E | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.3；293 K；3.3 M ammonium sulfate, 0.02 M tris, 0.001 M EDTA, , pH 8.3, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.23 Å R-free 0.197 |
| 3RJ6 Crystal Structure of Horse heart ferric myoglobin; K45E/K63E/K96E mutant Deposited 2011-04-15 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
2–154（153 aa）
|
Mutation：K45E, K63E, K96E | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.3；293 K；3.3 M ammonium sulfate, 0.02 M tris, 0.001 M EDTA, , pH 8.3, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.23 Å R-free 0.197 |
| 3RJN Horse heart myoglobin: D44K/D60K mutant with zinc (II) -deuteroporphyrin dimethyl ester Deposited 2011-04-15 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
2–154（153 aa）
|
Mutation：D44K, D60K | SO4 SULFATE ION × 2 HE5 ZINC(II)-DEUTEROPORPHYRIN DIMETHYLESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；3.3 M ammonium sulfate, 0.1 M TRIS, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.228 |
| 3V2V Nitrite Bound Chlorin Substituted Myoglobin- Method 1 Deposited 2011-12-12 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | HKL Fe(III) pyropheophorbide-a methyl ester × 1 NO2 NITRITE ION × 3 SO4 SULFATE ION × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；295 K；ammonium sulfate, 100mM TrisHCl, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.65 Å R-free 0.218 |
| 3V2Z Nitrite Bound Chlorin Substituted Myoglobin- Method 2 Deposited 2011-12-12 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | HKL Fe(III) pyropheophorbide-a methyl ester × 1 NO2 NITRITE ION × 2 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；295 K；ammonium sulfate, 100mM TrisHCl, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.65 Å R-free 0.232 |
| 3VAU Myoglobin nitrite structure: nitriheme modified Deposited 2011-12-29 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | NTE [3,3'-{7-ethenyl-3,8,13,17-tetramethyl-12-[(E)-2-nitroethenyl]porphyrin-2,18-diyl-kappa~4~N~21~,N~22~,N~23~,N~24~}dipro panoato(2-)]iron × 1 NO2 NITRITE ION × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；295 K；ammonium sulfate, 100mM TrisHCl, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.70 Å R-free 0.237 |
| 3VM9 Dimeric horse myoglobin Deposited 2011-12-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–154（153 aa）
Chain B
2–154（153 aa）
|
Not recorded | O OXYGEN ATOM × 2 HEM PROTOPORPHYRIN IX CONTAINING FE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；10% PEG 6000, 200mM CH3COONa, 0.1M Tris-HCl buffer, pH 7.0, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.05 Å R-free 0.168 |
| 3WFT Crystal structure of horse heart myoglobin reconstituted with cobalt(II) tetradehydrocorrin Deposited 2013-07-23 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | J1R (1R,19R) cobalt tetradehydrocorrin × 1 J1S (1S,19S) cobalt tetradehydrocorrin × 1 SO4 SULFATE ION × 2 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；298 K；0.1M Tris-HCl, 3.4M ammonium sulfate, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.30 Å R-free 0.183 |
| 3WFU Crystal structure of horse heart myoglobin reconstituted with cobalt(I) tetradehydrocorrin Deposited 2013-07-23 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | J1R (1R,19R) cobalt tetradehydrocorrin × 1 J1S (1S,19S) cobalt tetradehydrocorrin × 1 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；298 K；0.1M Tris-HCl, 3.4M ammonium sulfate, 10% treharose, pH 7.4, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.35 Å R-free 0.197 |
| 3WI8 Crystal structure of horse heart myoglobin reconstituted with manganese porphycene Deposited 2013-09-09 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | HNN PORPHYCENE CONTAINING MN × 1 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；3.2M ammonium sulfate, 0.1M imidazole, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.20 Å R-free 0.253 |
| 3WYO Heterodimeric myoglobin formed by domain swapping Deposited 2014-09-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–154（153 aa）
Chain B
2–154（153 aa）
|
Mutation：H64V/V68H/E85K/D141K Mutation：K78E/K79D | HEM PROTOPORPHYRIN IX CONTAINING FE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；25% (w/v) PEG 1000, 100mM MES-NaOH buffer, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.00 Å R-free 0.266 |
| 3WYO Heterodimeric myoglobin formed by domain swapping Deposited 2014-09-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain C
2–154（153 aa）
Chain D
2–154（153 aa）
|
Mutation：H64V/V68H/E85K/D141K Mutation：K78E/K79D | HEM PROTOPORPHYRIN IX CONTAINING FE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；25% (w/v) PEG 1000, 100mM MES-NaOH buffer, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.00 Å R-free 0.266 |
| 4DC7 Crystal Structure of Myoglobin Exposed to Excessive SONICC Imaging Laser Dose. Deposited 2012-01-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；Protein Solution (20 mg/ml myoglobin, 60% saturated ammonium sulfate, 20 mM Tris, pH 7.5, 5 mM sodium azide, 1 mM EDTA); Well Solution (65% saturated ammonium sulfate, 20 mM Tris, pH 7.5, 1 mM EDTA); Cryoprotectant (68% ammonium sulfate, 20 mM Tris, pH 7.5, 5 mM EDTA, 20% glycerol), VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.50 Å R-free 0.212 |
| 4DC8 Crystal Structure of Myoglobin Unexposed to Excessive SONICC Imaging Laser Dose. Deposited 2012-01-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；Protein Solution (20 mg/ml myoglobin, 60% saturated ammonium sulfate, 20 mM Tris, pH 7.5, 5 mM sodium azide, 1 mM EDTA); Well Solution (65% saturated ammonium sulfate, 20 mM Tris, pH 7.5, 1 mM EDTA); Cryoprotectant (68% ammonium sulfate, 20 mM Tris, pH 7.5, 5 mM EDTA, 20% glycerol), VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.50 Å R-free 0.218 |
| 4NS2 Crystal structure of Horse heart ferric myoglobin; D44K/D60K/E85K mutant Deposited 2013-11-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–154（154 aa）
|
Mutation：D44K, D60K, E85K | SO4 SULFATE ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；3.3 M ammonium sulfate, 0.1 M Tris pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.18 Å R-free 0.194 |
| 4TWU Horse heart myoglobin mutant (D44K/D60K/E85K) with Zn-deuteroporphyrin IX Deposited 2014-07-02 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–154（154 aa）
|
Mutation：D44K, D60K, E85K | ZND Zinc (II) Deuteroporphyrin IX × 1 SO4 SULFATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；0.1 M Tris/HCl, 3.2 M ammonium sulfate
|
Resolution 1.08 Å R-free 0.185 |
| 4TWV Horse heart myoglobin mutant (K45E/K63E/K96E) with Zn-deuteroporphyrin IX Deposited 2014-07-02 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–154（154 aa）
|
Mutation：K45E, K63E, K96E | ZND Zinc (II) Deuteroporphyrin IX × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；0.1 M Tris/HCl, 2.8 M ammonium sulfate
|
Resolution 1.06 Å R-free 0.165 |
| 5AZQ Crystal structure of cyano-cobalt(III) tetradehydrocorrin in the heme pocket of horse heart myoglobin Deposited 2015-10-21 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | J1R (1R,19R) cobalt tetradehydrocorrin × 1 J1S (1S,19S) cobalt tetradehydrocorrin × 1 CYN CYANIDE ION × 1 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；298 K；ammonium sulfate, Tris-HCl, trehalose
|
Resolution 1.40 Å R-free 0.189 |
| 5AZR Crystal structure of aqua-cobalt(III) tetradehydrocorrin in the heme pocket of horse heart myoglobin Deposited 2015-10-21 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | J1R (1R,19R) cobalt tetradehydrocorrin × 1 J1S (1S,19S) cobalt tetradehydrocorrin × 1 SO4 SULFATE ION × 2 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；298 K；ammonium sulfate, Tris-HCl, trehalose
|
Resolution 1.20 Å R-free 0.168 |
| 5CMV Ultrafast dynamics in myoglobin: dark-state, CO-ligated structure Deposited 2015-07-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.80 Å R-free 0.204 |
| 5CN4 Ultrafast dynamics in myoglobin: -0.1 ps time delay Deposited 2015-07-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.80 Å R-free 0.231 |
| 5CN5 Ultrafast dynamics in myoglobin: 0 ps time delay Deposited 2015-07-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.80 Å R-free 0.231 |
| 5CN6 Ultrafast dynamics in myoglobin: 0.1 ps time delay Deposited 2015-07-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.80 Å R-free 0.238 |
| 5CN7 Ultrafast dynamics in myoglobin: 0.2 ps time delay Deposited 2015-07-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.80 Å R-free 0.224 |
| 5CN8 Ultrafast dynamics in myoglobin: 0.3 ps time delay Deposited 2015-07-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.80 Å R-free 0.215 |
| 5CN9 Ultrafast dynamics in myoglobin: 0.4 ps time delay Deposited 2015-07-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.80 Å R-free 0.220 |
| 5CNB Ultrafast dynamics in myoglobin: 0.5 ps time delay Deposited 2015-07-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.80 Å R-free 0.218 |
| 5CNC Ultrafast dynamics in myoglobin: 0.6 ps time delay Deposited 2015-07-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.80 Å R-free 0.220 |
| 5CND Ultrafast dynamics in myoglobin: 3 ps time delay Deposited 2015-07-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.80 Å R-free 0.213 |
| 5CNE Ultrafast dynamics in myoglobin: 10 ps time delay Deposited 2015-07-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.80 Å R-free 0.215 |
| 5CNF Ultrafast dynamics in myoglobin: 50 ps time delay Deposited 2015-07-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.80 Å R-free 0.218 |
| 5CNG ultrafast dynamics in myoglobin: 150 ps time delay Deposited 2015-07-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.80 Å R-free 0.228 |
| 5D5R Horse-heart myoglobin - deoxy state Deposited 2015-08-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；3.5 M ammonium sulphate, 0.1 M Tris-HCl pH 7.4
|
Resolution 1.60 Å R-free 0.205 |
| 5YL3 Crystal structure of horse heart myoglobin reconstituted with manganese porphycene in resting state at pH 8.5 Deposited 2017-10-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–154（154 aa）
|
Not recorded | HNN PORPHYCENE CONTAINING MN × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；298 K；Hanging drop containing 1.5 M ammonium sulfate, 5 mg/mL of protein, 50 mM Tris-HCl and 5 mM potassium phosphate at pH 8.5 was equilibrated with the reserver solution containing 3.0 M ammonium sulfate and 100 mM Tris-HCl buffer at pH 8.5
|
Resolution 1.50 Å R-free 0.208 |
| 5Z7E Horse Heart Myoglobin Mutant - H93M Deposited 2018-01-28 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Mutation：H93M | NO2 NITRITE ION × 1 SO4 SULFATE ION × 2 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；2.5-3.0M ammonium sulfate, 0.1M Tris
|
Resolution 1.80 Å R-free 0.197 |
| 5Z7F Horse Heart Myoglobin Mutant -V68A/I107Y-Sulfide Derivative Deposited 2018-01-28 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Mutation：V68A,I107Y | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 H2S HYDROSULFURIC ACID × 1 NO2 NITRITE ION × 1 SO4 SULFATE ION × 2 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；2.5-3.0M ammonium sulfate, 0.1M Tris
|
Resolution 1.90 Å R-free 0.227 |
| 5ZZE Crystal structure of horse myoglobin crystallized by ammonium sulfate Deposited 2018-06-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
Fragment：UNP residues 2-153
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；3.2M ammonium sulfate
|
Resolution 1.42 Å R-free 0.248 |
| 6LS8 The monomeric structure of G80A/H81A/H82A myoglobin Deposited 2020-01-17 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Mutation：G80A/H81A/H82A | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1M Tris-HCl buffer, 15% (w/v) PEG 6000
|
Resolution 2.30 Å R-free 0.274 |
| 6LS8 The monomeric structure of G80A/H81A/H82A myoglobin Deposited 2020-01-17 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
2–154（153 aa）
|
Mutation：G80A/H81A/H82A | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1M Tris-HCl buffer, 15% (w/v) PEG 6000
|
Resolution 2.30 Å R-free 0.274 |
| 6LS8 The monomeric structure of G80A/H81A/H82A myoglobin Deposited 2020-01-17 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain E
2–154（153 aa）
|
Mutation：G80A/H81A/H82A | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1M Tris-HCl buffer, 15% (w/v) PEG 6000
|
Resolution 2.30 Å R-free 0.274 |
| 6LS8 The monomeric structure of G80A/H81A/H82A myoglobin Deposited 2020-01-17 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain G
2–154（153 aa）
|
Mutation：G80A/H81A/H82A | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1M Tris-HCl buffer, 15% (w/v) PEG 6000
|
Resolution 2.30 Å R-free 0.274 |
| 6LS8 The monomeric structure of G80A/H81A/H82A myoglobin Deposited 2020-01-17 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 5 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain I
2–154（153 aa）
|
Mutation：G80A/H81A/H82A | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1M Tris-HCl buffer, 15% (w/v) PEG 6000
|
Resolution 2.30 Å R-free 0.274 |
| 6LS8 The monomeric structure of G80A/H81A/H82A myoglobin Deposited 2020-01-17 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 6 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain K
2–154（153 aa）
|
Mutation：G80A/H81A/H82A | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1M Tris-HCl buffer, 15% (w/v) PEG 6000
|
Resolution 2.30 Å R-free 0.274 |
| 6LTL The dimeric structure of G80A myoglobin Deposited 2020-01-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–154（153 aa）
Chain B
2–154（153 aa）
|
Mutation：G80A Mutation：G80A | HEM PROTOPORPHYRIN IX CONTAINING FE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1M Tris-HCl buffer, 0.1M sodium acetate, 10% (w/v) PEG 6000
|
Resolution 1.25 Å R-free 0.245 |
| 6LTM The dimeric structure of G80A/H81A/H82A myoglobin Deposited 2020-01-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–154（153 aa）
Chain B
2–154（153 aa）
|
Mutation：G80A/H81A/H82A Mutation：G80A/H81A/H82A | HEM PROTOPORPHYRIN IX CONTAINING FE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1M Tris-HCl buffer, 0.1M sodium acetate, 12.5% (w/v) PEG 6000
|
Resolution 1.65 Å R-free 0.231 |
| 7DGJ The dimeric structure of K78H/G80A/H82A myoglobin Deposited 2020-11-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–154（153 aa）
Chain B
2–154（153 aa）
|
Mutation：K78H, G80A, H82A Mutation：K78H, G80A, H82A | HEM PROTOPORPHYRIN IX CONTAINING FE × 2 O OXYGEN ATOM × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1 M Sodium acetate, 0.1 M Tris-HCl, 25% (w/v) PEG 6,000
|
Resolution 1.60 Å R-free 0.245 |
| 7DGK The Co-bound dimeric structure of K78H/G80A/H82A myoglobin Deposited 2020-11-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–154（153 aa）
Chain B
2–154（153 aa）
|
Mutation：K78H, G80A, H82A Mutation：K78H, G80A, H82A | HEM PROTOPORPHYRIN IX CONTAINING FE × 2 O OXYGEN ATOM × 2 CO COBALT (II) ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1 M Sodium acetate, 0.1 M Tris-HCl, 25% (w/v) PEG 6,000
|
Resolution 1.75 Å R-free 0.251 |
| 7DGL The Ni-bound dimeric structure of K78H/G80A/H82A myoglobin Deposited 2020-11-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–154（153 aa）
Chain B
2–154（153 aa）
|
Mutation：K78H, G80A, H82A Mutation：K78H, G80A, H82A | HEM PROTOPORPHYRIN IX CONTAINING FE × 2 O OXYGEN ATOM × 2 NI NICKEL (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1 M Sodium acetate, 0.1 M Tris-HCl, 25% (w/v) PEG 6,000
|
Resolution 1.91 Å R-free 0.262 |
| 7DGM The dimeric structure of K79H/G80A/H81A myoglobin Deposited 2020-11-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–154（153 aa）
Chain B
2–154（153 aa）
|
Mutation：K79H, G80A, H81A Mutation：K79H, G80A, H81A | HEM PROTOPORPHYRIN IX CONTAINING FE × 2 O OXYGEN ATOM × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1 M Sodium acetate, 0.1 M Tris-HCl, 25% (w/v) PEG 6,000
|
Resolution 1.62 Å R-free 0.223 |
| 7DGN The Co-bound dimeric structure of K79H/G80A/H81A myoglobin Deposited 2020-11-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–154（153 aa）
Chain B
2–154（153 aa）
|
Mutation：K79H, G80A, H81A Mutation：K79H, G80A, H81A | HEM PROTOPORPHYRIN IX CONTAINING FE × 2 O OXYGEN ATOM × 2 CO COBALT (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1 M Sodium acetate, 0.1 M Tris-HCl, 25% (w/v) PEG 6,000
|
Resolution 2.35 Å R-free 0.269 |
| 7DGO The Zn-bound dimeric structure of K79H/G80A/H81A myoglobin Deposited 2020-11-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–154（153 aa）
Chain B
2–154（153 aa）
|
Mutation：K79H, G80A, H81A Mutation：K79H, G80A, H81A | HEM PROTOPORPHYRIN IX CONTAINING FE × 2 O OXYGEN ATOM × 2 ZN ZINC ION × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1 M Sodium acetate, 0.1 M Tris-HCl, 25% (w/v) PEG 6,000
|
Resolution 2.00 Å R-free 0.265 |
| 7V5P The dimeric structure of G80A/H81A myoglobin Deposited 2021-08-17 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–154（153 aa）
Chain B
2–154（153 aa）
|
Mutation：G80A, H81A Mutation：G80A, H81A | HEM PROTOPORPHYRIN IX CONTAINING FE × 2 O OXYGEN ATOM × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1 M Sodium acetate, 0.1 M Tris-HCl, 10% (w/v) PEG 6,000
|
Resolution 1.16 Å R-free 0.206 |
| 7V5Q The dimeric structure of G80A/H81A/L137E myoglobin Deposited 2021-08-17 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–154（153 aa）
Chain B
2–154（153 aa）
|
Mutation：G80A, H81A, L137E Mutation：G80A, H81A, L137E | HEM PROTOPORPHYRIN IX CONTAINING FE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1 M Sodium acetate, 0.1 M Tris-HCl, 10% (w/v) PEG 6,000, and 5 % (w/v) PEG 8,000
|
Resolution 1.38 Å R-free 0.205 |
| 7V5R The dimeric structure of G80A/H81A/L137D myoglobin Deposited 2021-08-17 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–154（153 aa）
Chain B
2–154（153 aa）
|
Mutation：G80A, H81A, L137D Mutation：G80A, H81A, L137D | HEM PROTOPORPHYRIN IX CONTAINING FE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1 M Sodium acetate, 0.1 M Tris-HCl, 10 % (w/v) PEG 6000, and 5 % (w/v) PEG 200
|
Resolution 1.39 Å R-free 0.234 |
| 8BKH Carboxymyoglobin dark state for comparison with power titration and 23 / 101 mJ/cm2 time series Deposited 2022-11-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.35 Å R-free 0.227 |
| 8BKN Carboxymyoglobin dark state for comparison with 5 mJ/cm2 time series Deposited 2022-11-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.29 Å R-free 0.210 |
| 8R8F Ensemble-refined carboxymyoglobin photolysis power titration, 6 mJ/cm2 Deposited 2023-11-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.217 |
| 8R8G Ensemble-refined carboxymyoglobin photolysis power titration, 18 mJ/cm2 Deposited 2023-11-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.215 |
| 8R8H Ensemble-refined carboxymyoglobin photolysis power titration, 31 mJ/cm2 Deposited 2023-11-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.213 |
| 8R8I Ensemble-refined carboxymyoglobin photolysis power titration, 56 mJ/cm2 Deposited 2023-11-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.230 |
| 8R8J Ensemble-refined carboxymyoglobin photolysis power titration, 101 mJ/cm2 Deposited 2023-11-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.217 |
| 8R8W Multicopy-refined carboxymyoglobin photolysis time series at 5 mJ/cm2 laser fluence, 254 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.207 |
| 8R8X Multicopy-refined carboxymyoglobin photolysis time series at 5 mJ/cm2 laser fluence, 327 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.218 |
| 8R8Y Multicopy-refined carboxymyoglobin photolysis time series at 5 mJ/cm2 laser fluence, 402 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.205 |
| 8R8Z Multicopy-refined carboxymyoglobin photolysis time series at 5 mJ/cm2 laser fluence, 471 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.217 |
| 8R90 Multicopy-refined carboxymyoglobin photolysis time series at 5 mJ/cm2 laser fluence, 604 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.206 |
| 8R91 Multicopy-refined carboxymyoglobin photolysis time series at 5 mJ/cm2 laser fluence, 627 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.225 |
| 8R92 Multicopy-refined carboxymyoglobin photolysis time series at 5 mJ/cm2 laser fluence, 702 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.205 |
| 8R93 Multicopy-refined carboxymyoglobin photolysis time series at 5 mJ/cm2 laser fluence, 847 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.200 |
| 8R94 Multicopy-refined carboxymyoglobin photolysis time series at 5 mJ/cm2 laser fluence, 1001 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.208 |
| 8R95 Multicopy-refined carboxymyoglobin photolysis time series at 5 mJ/cm2 laser fluence, 1401 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.207 |
| 8R9C Multicopy-refined carboxymyoglobin photolysis time series at 23 mJ/cm2 laser fluence, 320 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；ammonium sulfate
|
Resolution 1.40 Å R-free 0.220 |
| 8R9D Multicopy-refined carboxymyoglobin photolysis time series at 23 mJ/cm2 laser fluence, 399 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.218 |
| 8R9E Multicopy-refined carboxymyoglobin photolysis time series at 23 mJ/cm2 laser fluence, 469 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.220 |
| 8R9F Multicopy-refined carboxymyoglobin photolysis time series at 23 mJ/cm2 laser fluence, 537 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.220 |
| 8R9G Multicopy-refined carboxymyoglobin photolysis time series at 23 mJ/cm2 laser fluence, 600 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.222 |
| 8R9H Multicopy-refined carboxymyoglobin photolysis time series at 23 mJ/cm2 laser fluence, 661 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.222 |
| 8R9I Multicopy-refined carboxymyoglobin photolysis time series at 23 mJ/cm2 laser fluence, 733 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.225 |
| 8R9J Multicopy-refined carboxymyoglobin photolysis time series at 23 mJ/cm2 laser fluence, 822 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.226 |
| 8R9K Multicopy-refined carboxymyoglobin photolysis time series at 23 mJ/cm2 laser fluence, 922 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.224 |
| 8R9L Multicopy-refined carboxymyoglobin photolysis time series at 23 mJ/cm2 laser fluence, 1036 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.222 |
| 8R9M Multicopy-refined carboxymyoglobin photolysis time series at 23 mJ/cm2 laser fluence, 1143 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.224 |
| 8R9N Multicopy-refined carboxymyoglobin photolysis time series at 23 mJ/cm2 laser fluence, 1224 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.225 |
| 8R9P Multicopy-refined carboxymyoglobin photolysis time series at 23 mJ/cm2 laser fluence, 1297 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.227 |
| 8R9Q Multicopy-refined carboxymyoglobin photolysis time series at 23 mJ/cm2 laser fluence, 1373 fs time delay Deposited 2023-11-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.224 |
| 8RA1 Multicopy-refined carboxymyoglobin photolysis time series at 101 mJ/cm2 laser fluence, 312 fs time delay Deposited 2023-12-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.222 |
| 8RA2 Multicopy-refined carboxymyoglobin photolysis time series at 101 mJ/cm2 laser fluence, 392 fs time delay Deposited 2023-12-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.221 |
| 8RA3 Multicopy-refined carboxymyoglobin photolysis time series at 101 mJ/cm2 laser fluence, 462 fs time delay Deposited 2023-12-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.217 |
| 8RA4 Multicopy-refined carboxymyoglobin photolysis time series at 101 mJ/cm2 laser fluence, 527 fs time delay Deposited 2023-12-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.218 |
| 8RA5 Multicopy-refined carboxymyoglobin photolysis time series at 101 mJ/cm2 laser fluence, 590 fs time delay Deposited 2023-12-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.219 |
| 8RA6 Multicopy-refined carboxymyoglobin photolysis time series at 101 mJ/cm2 laser fluence, 655 fs time delay Deposited 2023-12-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.218 |
| 8RA7 Multicopy-refined carboxymyoglobin photolysis time series at 101 mJ/cm2 laser fluence, 722 fs time delay Deposited 2023-12-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.223 |
| 8RA8 Multicopy-refined carboxymyoglobin photolysis time series at 101 mJ/cm2 laser fluence, 802 fs time delay Deposited 2023-12-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.225 |
| 8RA9 Multicopy-refined carboxymyoglobin photolysis time series at 101 mJ/cm2 laser fluence, 907 fs time delay Deposited 2023-12-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.217 |
| 8RAA Multicopy-refined carboxymyoglobin photolysis time series at 101 mJ/cm2 laser fluence, 1023 fs time delay Deposited 2023-12-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.215 |
| 8RAB Multicopy-refined carboxymyoglobin photolysis time series at 101 mJ/cm2 laser fluence, 1112 fs time delay Deposited 2023-12-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.216 |
| 8RAC Multicopy-refined carboxymyoglobin photolysis time series at 101 mJ/cm2 laser fluence, 1174 fs time delay Deposited 2023-12-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.219 |
| 8RAD Multicopy-refined carboxymyoglobin photolysis time series at 101 mJ/cm2 laser fluence, 1235 fs time delay Deposited 2023-12-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.220 |
| 8RAE Multicopy-refined carboxymyoglobin photolysis time series at 101 mJ/cm2 laser fluence, 1303 fs time delay Deposited 2023-12-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–153（152 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 SO4 SULFATE ION × 2 CMO CARBON MONOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；293 K；3.1 M ammonium sulfate
|
Resolution 1.40 Å R-free 0.225 |
| 8WF5 Horse heart myoglobin reconstituted with an iron complex of porphyrin bearing two CF3 groups (rMb(FePor(CF3)2)) Deposited 2023-09-19 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–154（153 aa）
|
Not recorded | WC5 PROTOPORPHYRIN(CF3)2 CONTAINING FE × 1 SO4 SULFATE ION × 3 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；2.8 M ammonium sulfate, 100 mM Tis-HCl buffer (pH 7.0)
|
Resolution 1.72 Å R-free 0.215 |
| 9T6V Low-dose (32.5 kGy) structure of horse-heart myoglobin at room temperature Deposited 2025-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–154（154 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；3.5 M ammonium sulphate, 0.1 M Tris-HCl pH 7.4
|
Resolution 1.24 Å R-free 0.166 |
| 9T6W Higher-dose (260.0 kGy) structure of horse-heart myoglobin at room temperature Deposited 2025-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–154（154 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.4；293 K；3.5 M ammonium sulphate, 0.1 M Tris-HCl pH 7.4
|
Resolution 1.71 Å R-free 0.196 |
| 9T6X Higher-dose (676.8 kGy) structure of horse-heart myoglobin at cryogenic temperature Deposited 2025-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–154（154 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 MLA MALONIC ACID × 3 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；3.5 M ammonium sulphate, 0.1 M Tris-HCl pH 7.4
|
Resolution 1.10 Å R-free 0.201 |
| 9T6Y Low-dose (14.4 kGy) structure of horse-heart myoglobin at cryogenic temperature Deposited 2025-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–154（154 aa）
|
Not recorded | HEM PROTOPORPHYRIN IX CONTAINING FE × 1 MLI MALONATE ION × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；3.5 M ammonium sulphate, 0.1 M Tris-HCl pH 7.4
|
Resolution 1.03 Å R-free 0.214 |
| 9X07 Serial Femtosecond Crystallography Structure of Myoglobin from equine skeletal muscle Deposited 2025-09-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–152（151 aa）
|
Not recorded | SO4 SULFATE ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
SMALL TUBES；298 K；ammonium sulfate
|
Resolution 2.30 Å R-free 0.317 |
149 other PDB entries and 156 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | MYG_HORSE |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 1–153； UniProt 2–154 |
