Yop effector YopM
Yersinia enterocolitica subsp. enterocolitica WA-314
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein homooligomer Homooligomer Protein × 2 PDB declaration: dimeric（2） Consistent with protein copy count | Chain A； UniProt 34–481 Chain C； UniProt 34–481 | Fragment：UNP residues 34-481 | No other associated polymer | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；293 K；BisTris Propane, sodium citrate, PEG 3350 | Resolution 3.20 Å R-free 0.201 |
| 2 | Protein homooligomer Homooligomer Protein × 2 PDB declaration: dimeric（2） Consistent with protein copy count | Chain B； UniProt 34–481 Chain D； UniProt 34–481 | Fragment：UNP residues 34-481 | No other associated polymer | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；293 K；BisTris Propane, sodium citrate, PEG 3350 | Resolution 3.20 Å R-free 0.201 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
No other PDB entry for the same UniProt protein was found.
View Construct and Data Evidence
| UniProt name | K1AZR9_YEREN |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 1–448； UniProt 34–481 Author chain B； PDBConstruct 1–448； UniProt 34–481 Author chain C； PDBConstruct 1–448； UniProt 34–481 Author chain D； PDBConstruct 1–448； UniProt 34–481 |
