5i8g

CBP in complex with Cpd637 ((R)-4-methyl-6-(1-methyl-3-(1-methyl-1H-pyrazol-4-yl)-1H-indazol-5-yl)-1,3,4,5-tetrahydro-2H-benzo[b][1,4]diazepin-2-one)

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

CREB-binding protein

Homo sapiens

UniProt Q92793

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein monomer Monomer Protein 1 ZINC ION × 3 (4R)-4-methyl-6-[1-methyl-3-(1-methyl-1H-pyrazol-4-yl)-1H-indazol-5-yl]-1,3,4,5-tetrahydro-2H-1,5-benzodiazepin-2-one × 1 2-[3-(2-HYDROXY-1,1-DIHYDROXYMETHYL-ETHYLAMINO)-PROPYLAMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 1,2-ETHANEDIOL × 5 SODIUM ION × 1 DI(HYDROXYETHYL)ETHER × 2 water × 1 Consistent with protein count

Other States of the Same Protein in the Database

Monomer
1liq 1wo3 1wo4 1wo5 1wo6 1wo7 2d82 2l84 2l85 3dwy 3dwy 3p1c

194 assemblies; showing the first 12

Homodimer
7xne 7xng

2 assemblies

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
1jsp 1zoq 1zoq 2kje 2kwf 2lxs 2lxt 2n1a 2rny 4n3w 4n4f 5gh9

29 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name CBP_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 33–264； UniProt 1081–1312

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id5i8g
Deposition date deposition_date2016-02-18
Structure title titleCBP in complex with Cpd637 ((R)-4-methyl-6-(1-methyl-3-(1-methyl-1H-pyrazol-4-yl)-1H-indazol-5-yl)-1,3,4,5-tetrahydro-2H-benzo[b][1,4]diazepin-2-one)
Keywords keywordsCREBBP, bromodomain, epigenetics, structure-based drug design, Transcription-Protein Binding complex; Transcription/Protein Binding
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

5i8g__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

5i8g__assembly_1__model_1 | I(q)

10-2 10-1 105 106 107 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

5i8g__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）22.40 Å
Rg (electron density)21.54 Å
Total Rg22.47 Å
Atom count1958
Residues226
Excluded volume35047 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 5i8g__assembly_1__model_1 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (8)

▼

6. Fold Classification (SCOP + CATH) 3 domains

CATH v4.4 (3 domains)

Domain ID domain_id5i8gA01
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology920 — Histone Acetyltransferase; Chain A
Homologous superfamily homologous superfamily10 — Bromodomain-like
Domain ID domain_id5i8gA02
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology40 — Herpes Virus-1
Homologous superfamily homologous superfamily10 — Zinc/RING finger domain, C3HC4 (zinc finger)
Domain ID domain_id5i8gA03
Class class2 — Mainly Beta
Architecture architecture10 — Ribbon
Topology topology110 — Cysteine Rich Protein
Homologous superfamily homologous superfamily40 — CREB-binding protein/p300 RING domain
▶

7. Citations (1)
