SAXSdb — 1b66

▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

6-PYRUVOYL TETRAHYDROPTERIN SYNTHASE

Rattus rattus

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein homooligomer	Homooligomer	Protein 6	ZINC ION × 6 BIOPTERIN × 6 water × 6	Consistent with protein count
2	Protein homooligomer	Homooligomer	Protein 3	ZINC ION × 3 BIOPTERIN × 3 water × 3	Consistent with protein count
3	Protein homooligomer	Homooligomer	Protein 3	ZINC ION × 3 BIOPTERIN × 3 water × 3	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	PTPS_RAT
Isoform	—
PDB entities	1
Chains and sequence ranges	Author chain A； PDBConstruct 1–140； UniProt 5–144 Author chain B； PDBConstruct 1–140； UniProt 5–144

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id	1b66
Deposition date deposition_date	1999-01-20
Structure title title	6-PYRUVOYL TETRAHYDROPTERIN SYNTHASE
Keywords keywords	TETRAHYDROBIOPTERIN BIOSYNTHESIS, PHOSPHATE ELIMINATION, PTERINE SYNTHESIS; TETRAHYDROBIOPTERIN BIOSYNTHESIS
Experimental Method method	X-RAY DIFFRACTION

▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1b66__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1b66__assembly_1__model_1 | I(q)

100 plotted points; both axes use logarithmic scales.

1b66__assembly_1__model_1 | P(r) · Pending

P(r) will be calculated and displayed separately for the same assembly/model.

Rg（Guinier）	28.05 Å
Rg (electron density)	26.70 Å
Total Rg	27.49 Å
Atom count	6714
Residues	828
Excluded volume	119260 Å³
Maximum q	0.500 Å⁻¹

Assembly	Model	Structure unit	Oligomeric description	Status	CRYSOL	Actions
1	1	`1b66__assembly_1__model_1`	hexameric （6）	Success	4.1.3-1-20251215 (887e7ef)	View Download
2	1	`1b66__assembly_2__model_1`	trimeric （3）	Success	4.1.3-1-20251215 (887e7ef)	View Download
3	1	`1b66__assembly_3__model_1`	trimeric （3）	Success	4.1.3-1-20251215 (887e7ef)	View Download

▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (4)

Entity 1 Entity 1 polymer

Description description	6-PYRUVOYL TETRAHYDROPTERIN SYNTHASE
Molecular weight formula_weight	15875.2 kDa
EC 编号 ec_number	4.6.1.10
Source method src_method	man
Copy count entity_count	2

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	A,B
Atom count atom_count	2497

VGLRRRARLSRLVSFSASHRLHSPSLSAEENLKVFGKCNNPNGHGHNYKVVVTIHGEIDPVTGMVMNLTDLKEYMEEAIMKPLDHKNLDLDVPYFADVVSTTENVAVYIWENLQRLLPVGALYKVKVYETDNNIVVYKGE

Source Source

Source organism organism	Rattus rattus
Common name common_name	black rat
NCBI taxonomy ID ncbi_taxonomy_id	10117
Host organism host_organism	Escherichia coli

Entity 2 Entity 2 non-polymer

Description description	ZINC ION
Molecular weight formula_weight	65.4 kDa
Source method src_method	syn
Copy count entity_count	2

Entity 3 Entity 3 non-polymer

Description description	BIOPTERIN
Molecular weight formula_weight	237.2 kDa
Source method src_method	syn
Copy count entity_count	2

Entity 4 Entity 4 water

Description description	water
Molecular weight formula_weight	18.0 kDa
Source method src_method	nat
Copy count entity_count	259

▼

6. Fold Classification (SCOP + CATH) 4 domains

SCOP 2.08 (2 domains)

Domain ID domain_id	d1b66a_
Class class	d — Alpha and beta proteins (a+b)
Fold Fold fold	d.96 — T-fold
Superfamily Superfamily superfamily	d.96.1 — Tetrahydrobiopterin biosynthesis enzymes-like
Family Family family	d.96.1.2 — 6-pyruvoyl tetrahydropterin synthase

Domain ID domain_id	d1b66b_
Class class	d — Alpha and beta proteins (a+b)
Fold Fold fold	d.96 — T-fold
Superfamily Superfamily superfamily	d.96.1 — Tetrahydrobiopterin biosynthesis enzymes-like
Family Family family	d.96.1.2 — 6-pyruvoyl tetrahydropterin synthase

CATH v4.4 (2 domains)

Domain ID domain_id	1b66A00
Class class	3 — Alpha Beta
Architecture architecture	30 — 2-Layer Sandwich
Topology topology	479 — Tetrahydropterin Synthase; Chain A
Homologous superfamily homologous superfamily	10 — 6-pyruvoyl tetrahydropterin synthase/QueD

Domain ID domain_id	1b66B00
Class class	3 — Alpha Beta
Architecture architecture	30 — 2-Layer Sandwich
Topology topology	479 — Tetrahydropterin Synthase; Chain A
Homologous superfamily homologous superfamily	10 — 6-pyruvoyl tetrahydropterin synthase/QueD

▶

Unit-cell length a length_a	120.270 Å
Unit-cell length b length_b	120.270 Å
Unit-cell length c length_c	61.250 Å
Unit-cell angle α angle_alpha	90.00 °
Unit-cell angle β angle_beta	90.00 °
Unit-cell angle γ angle_gamma	120.00 °
Molecules per unit cell Z z_pdb	12

Space group space_group	P 3 2 1
Space-group number int_tables_number	150
Crystal system crystal_system	—

Resolution resolution	1.900 Å
Low-resolution limit resolution_low	20.000 Å
R factor r_factor	0.2270
R_work r_work	0.2270
R_free r_free	0.2580
