SAXSdb — 1fdj

▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

FRUCTOSE 1,6-BISPHOSPHATE ALDOLASE

OrganismNot specified

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein homooligomer	Homooligomer	Protein 4	SULFATE ION × 4 1,6-FRUCTOSE DIPHOSPHATE (LINEAR FORM) × 4 1,3-DIHYDROXYACETONEPHOSPHATE × 2 SN-GLYCEROL-3-PHOSPHATE × 2 water × 4	Consistent with protein count
2	Protein homooligomer	Homooligomer	Protein 4	SULFATE ION × 4 1,3-DIHYDROXYACETONEPHOSPHATE × 6 water × 4	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	ALDOB_RABIT
Isoform	—
PDB entities	1
Chains and sequence ranges	Author chain A； PDBConstruct 1–363； UniProt 1–363 Author chain B； PDBConstruct 1–363； UniProt 1–363 Author chain C； PDBConstruct 1–363； UniProt 1–363 Author chain D； PDBConstruct 1–363； UniProt 1–363

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id	1fdj
Deposition date deposition_date	2000-07-20
Structure title title	FRUCTOSE 1,6-BISPHOSPHATE ALDOLASE FROM RABBIT LIVER
Keywords keywords	ALDOLASE, LYASE (ALDEHYDE), SCHIFF BASE, GLYCOLYSIS, LYASE; LYASE
Experimental Method method	X-RAY DIFFRACTION

▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1fdj__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1fdj__assembly_1__model_1 | I(q)

100 plotted points; both axes use logarithmic scales.

1fdj__assembly_1__model_1 | P(r) · Pending

P(r) will be calculated and displayed separately for the same assembly/model.

Rg（Guinier）	36.54 Å
Rg (electron density)	35.91 Å
Total Rg	36.31 Å
Atom count	11232
Residues	1452
Excluded volume	199080 Å³
Maximum q	0.500 Å⁻¹

Assembly	Model	Structure unit	Oligomeric description	Status	CRYSOL	Actions
1	1	`1fdj__assembly_1__model_1`	tetrameric （4）	Success	4.1.3-1-20251215 (887e7ef)	View Download
2	1	`1fdj__assembly_2__model_1`	tetrameric （4）	Success	4.1.3-1-20251215 (887e7ef)	View Download

▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (6)

Entity 1 Entity 1 polymer

Description description	FRUCTOSE 1,6-BISPHOSPHATE ALDOLASE
Molecular weight formula_weight	39508.9 kDa
EC 编号 ec_number	4.1.2.13
Source method src_method	nat
Copy count entity_count	4

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	A,B,C,D
Atom count atom_count	15089

AHRFPALTPEQKKELSDIAQRIVANGKGILAADESVGTMGNRLQRIKVENSEENRRQFREILFTVDNSINQSIGGVILFHETLYQKDSQGKLFRNILKEKGIVVGIKLDQGGAPLAGTNKETTIQGLDGLSERCAQYKKDGVDFGKWRAVLRIADQCPSSLAIQENANTLARYASICQQNGLVPIVEPEVIPDGDHDLEHCQYVTEKVLAAVYKALNDHHVYLEGTLLKPNMVTAGHACTKKYTPEQVAMATVTALHRTVPAAVPGICFLSGGMSEEDATLNLNAINLCPLPKPWKLSFSYGRALQASALAAWGGKAENKKATQEAFMKRAVVNCQAAKGQYVHTGSSGAASTQSLFTASYTY

Entity 2 Entity 2 non-polymer

Description description	SULFATE ION
Molecular weight formula_weight	96.1 kDa
Source method src_method	syn
Copy count entity_count	4

Entity 3 Entity 3 non-polymer

Description description	1,6-FRUCTOSE DIPHOSPHATE (LINEAR FORM)
Molecular weight formula_weight	340.1 kDa
Source method src_method	syn
Copy count entity_count	2

Entity 4 Entity 4 non-polymer

Description description	1,3-DIHYDROXYACETONEPHOSPHATE
Molecular weight formula_weight	170.1 kDa
Source method src_method	syn
Copy count entity_count	4

Entity 5 Entity 5 non-polymer

Description description	SN-GLYCEROL-3-PHOSPHATE
Molecular weight formula_weight	172.1 kDa
Source method src_method	syn
Copy count entity_count	1

Entity 6 Entity 6 water

Description description	water
Molecular weight formula_weight	18.0 kDa
Source method src_method	nat
Copy count entity_count	3477

▼

6. Fold Classification (SCOP + CATH) 8 domains

SCOP 2.08 (4 domains)

Domain ID domain_id	d1fdja_
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.1 — TIM beta/alpha-barrel
Superfamily Superfamily superfamily	c.1.10 — Aldolase
Family Family family	c.1.10.1 — Class I aldolase

Domain ID domain_id	d1fdjb_
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.1 — TIM beta/alpha-barrel
Superfamily Superfamily superfamily	c.1.10 — Aldolase
Family Family family	c.1.10.1 — Class I aldolase

Domain ID domain_id	d1fdjc_
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.1 — TIM beta/alpha-barrel
Superfamily Superfamily superfamily	c.1.10 — Aldolase
Family Family family	c.1.10.1 — Class I aldolase

Domain ID domain_id	d1fdjd_
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.1 — TIM beta/alpha-barrel
Superfamily Superfamily superfamily	c.1.10 — Aldolase
Family Family family	c.1.10.1 — Class I aldolase

CATH v4.4 (4 domains)

Domain ID domain_id	1fdjA00
Class class	3 — Alpha Beta
Architecture architecture	20 — Alpha-Beta Barrel
Topology topology	20 — TIM Barrel
Homologous superfamily homologous superfamily	70 — Aldolase class I

Domain ID domain_id	1fdjB00
Class class	3 — Alpha Beta
Architecture architecture	20 — Alpha-Beta Barrel
Topology topology	20 — TIM Barrel
Homologous superfamily homologous superfamily	70 — Aldolase class I

Domain ID domain_id	1fdjC00
Class class	3 — Alpha Beta
Architecture architecture	20 — Alpha-Beta Barrel
Topology topology	20 — TIM Barrel
Homologous superfamily homologous superfamily	70 — Aldolase class I

Domain ID domain_id	1fdjD00
Class class	3 — Alpha Beta
Architecture architecture	20 — Alpha-Beta Barrel
Topology topology	20 — TIM Barrel
Homologous superfamily homologous superfamily	70 — Aldolase class I

▶

Unit-cell length a length_a	377.250 Å
Unit-cell length b length_b	130.540 Å
Unit-cell length c length_c	80.030 Å
Unit-cell angle α angle_alpha	90.00 °
Unit-cell angle β angle_beta	90.00 °
Unit-cell angle γ angle_gamma	90.00 °
Molecules per unit cell Z z_pdb	32

Space group space_group	C 2 2 21
Space-group number int_tables_number	20
Crystal system crystal_system	—

Resolution resolution	2.100 Å
Low-resolution limit resolution_low	12.000 Å
R factor r_factor	0.1740
R_work r_work	0.1710
R_free r_free	0.2140

FRUCTOSE 1,6-BISPHOSPHATE ALDOLASE FROM RABBIT LIVER
