1fry

THE SOLUTION STRUCTURE OF SHEEP MYELOID ANTIMICROBIAL PEPTIDE, RESIDUES 1-29 (SMAP29)

Method: SOLUTION NMR
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

MYELOID ANTIMICROBIAL PEPTIDE

OrganismNot specified

UniProt P49928

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein monomer Monomer Protein 1 No other associated polymer Consistent with protein count

Other States of the Same Protein in the Database

Monomer
1fry

1 assemblies

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex

None

View Construct and Data Evidence
UniProt name SC51_SHEEP
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 1–29； UniProt 132–160

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id1fry
Deposition date deposition_date2000-09-07
Structure title titleTHE SOLUTION STRUCTURE OF SHEEP MYELOID ANTIMICROBIAL PEPTIDE, RESIDUES 1-29 (SMAP29)
Keywords keywordsrandom-ordered coil-loop, ANTIMICROBIAL PROTEIN; ANTIMICROBIAL PROTEIN
Experimental Method methodSOLUTION NMR
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1fry__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1fry__assembly_1__model_1 | I(q)

10-2 10-1 104 105 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

1fry__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）10.22 Å
Rg (electron density)8.84 Å
Total Rg10.68 Å
Atom count454
Residues29
Excluded volume4193 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 1fry__assembly_1__model_1 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 2 1fry__assembly_1__model_2 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 3 1fry__assembly_1__model_3 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 4 1fry__assembly_1__model_4 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 5 1fry__assembly_1__model_5 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 6 1fry__assembly_1__model_6 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 7 1fry__assembly_1__model_7 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 8 1fry__assembly_1__model_8 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 9 1fry__assembly_1__model_9 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 10 1fry__assembly_1__model_10 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 11 1fry__assembly_1__model_11 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 12 1fry__assembly_1__model_12 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 13 1fry__assembly_1__model_13 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 14 1fry__assembly_1__model_14 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 15 1fry__assembly_1__model_15 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 16 1fry__assembly_1__model_16 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 17 1fry__assembly_1__model_17 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 18 1fry__assembly_1__model_18 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 19 1fry__assembly_1__model_19 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 20 1fry__assembly_1__model_20 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 21 1fry__assembly_1__model_21 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 22 1fry__assembly_1__model_22 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 23 1fry__assembly_1__model_23 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 24 1fry__assembly_1__model_24 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 25 1fry__assembly_1__model_25 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 26 1fry__assembly_1__model_26 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 27 1fry__assembly_1__model_27 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 28 1fry__assembly_1__model_28 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 29 1fry__assembly_1__model_29 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 30 1fry__assembly_1__model_30 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 31 1fry__assembly_1__model_31 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 32 1fry__assembly_1__model_32 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 33 1fry__assembly_1__model_33 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 34 1fry__assembly_1__model_34 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 35 1fry__assembly_1__model_35 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 36 1fry__assembly_1__model_36 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 37 1fry__assembly_1__model_37 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 38 1fry__assembly_1__model_38 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 39 1fry__assembly_1__model_39 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 40 1fry__assembly_1__model_40 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (1)

▼

6. Fold Classification (SCOP + CATH) 1 domains

SCOP 2.08 (1 domains)

Domain ID domain_idd1frya_
Class classj — Peptides
Fold Fold foldj.93 — Sheep myeloid antimicrobial peptide SMAP29 based peptides
Superfamily Superfamily superfamilyj.93.1 — Sheep myeloid antimicrobial peptide SMAP29 based peptides
Family Family familyj.93.1.1 — Sheep myeloid antimicrobial peptide SMAP29 based peptides
▶

7. Citations (1)
