1. Protein Identity and Related Structures Protein Identity & Related Structures

UREASE

Klebsiella aerogenes

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein heterocomplex	Heteromer	Protein 9	UREASE × 3 （P18315） UREASE × 3 （P18314） NICKEL (II) ION × 6 ACETOHYDROXAMIC ACID × 3 water × 9	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	URE3_KLEAE
Isoform	—
PDB entities	1
Chains and sequence ranges	Author chain A； PDBConstruct 1–100； UniProt 1–100

UREASE

Klebsiella aerogenes

UniProt P18315

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein heterocomplex	Heteromer	Protein 9	UREASE × 3 （P18316） UREASE × 3 （P18314） NICKEL (II) ION × 6 ACETOHYDROXAMIC ACID × 3 water × 9	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	URE2_KLEAE
Isoform	—
PDB entities	2
Chains and sequence ranges	Author chain B； PDBConstruct 1–106； UniProt 1–106

UREASE

Klebsiella aerogenes

UniProt P18314

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein heterocomplex	Heteromer	Protein 9	UREASE × 3 （P18316） UREASE × 3 （P18315） NICKEL (II) ION × 6 ACETOHYDROXAMIC ACID × 3 water × 9	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	URE1_KLEAE
Isoform	—
PDB entities	3
Chains and sequence ranges	Author chain C； PDBConstruct 1–567； UniProt 1–567

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id	1fwe
Deposition date deposition_date	1997-04-23
Structure title title	KLEBSIELLA AEROGENES UREASE, C319A VARIANT WITH ACETOHYDROXAMIC ACID (AHA) BOUND
Keywords keywords	HYDROLASE(UREA AMIDO), MUTANT, INHIBITOR-BOUND, NICKEL METALLOENZYME, HYDROLASE; HYDROLASE
Experimental Method method	X-RAY DIFFRACTION

▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1fwe__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1fwe__assembly_1__model_1 | I(q)

100 plotted points; both axes use logarithmic scales.

1fwe__assembly_1__model_1 | P(r) · Pending

P(r) will be calculated and displayed separately for the same assembly/model.

Rg（Guinier）	38.75 Å
Rg (electron density)	37.86 Å
Total Rg	38.16 Å
Atom count	17070
Residues	2256
Excluded volume	303240 Å³
Maximum q	0.500 Å⁻¹

Assembly	Model	Structure unit	Oligomeric description	Status	CRYSOL	Actions
1	1	`1fwe__assembly_1__model_1`	nonameric （9）	Success	4.1.3-1-20251215 (887e7ef)	View Download

▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (6)

Entity 1 Entity 1 polymer

Description description	UREASE
Molecular weight formula_weight	11100.9 kDa
EC 编号 ec_number	3.5.1.5
Mutation mutation	C(C 319)A
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	A
Atom count atom_count	5967

MELTPREKDKLLLFTAALVAERRLARGLKLNYPESVALISAFIMEGARDGKSVASLMEEGRHVLTREQVMEGVPEMIPDIQVEATFPDGSKLVTVHNPII

Source Source

Source organism organism	Klebsiella aerogenes
NCBI taxonomy ID ncbi_taxonomy_id	28451
Host organism host_organism	Escherichia coli

Entity 2 Entity 2 polymer

Description description	UREASE
Molecular weight formula_weight	11712.2 kDa
EC 编号 ec_number	3.5.1.5
Mutation mutation	C(C 319)A
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	B

MIPGEYHVKPGQIALNTGRATCRVVVENHGDRPIQVGSHYHFAEVNPALKFDRQQAAGYRLNIPAGTAVRFEPGQKREVELVAFAGHRAVFGFRGEVMGPLEVNDE

Source Source

Source organism organism	Klebsiella aerogenes
NCBI taxonomy ID ncbi_taxonomy_id	28451
Host organism host_organism	Escherichia coli

Entity 3 Entity 3 polymer

Description description	UREASE
Molecular weight formula_weight	60377.3 kDa
EC 编号 ec_number	3.5.1.5
Mutation mutation	C(C 319)A
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	C

MSNISRQAYADMFGPTVGDKVRLADTELWIEVEDDLTTYGEEVKFGGGKVIRDGMGQGQMLAADCVDLVLTNALIVDHWGIVKADIGVKDGRIFAIGKAGNPDIQPNVTIPIGAATEVIAAEGKIVTAGGIDTHIHWICPQQAEEALVSGVTTMVGGGTGPAAGTHATTCTPGPWYISRMLQAADSLPVNIGLLGKGNVSQPDALREQVAAGVIGLKIHEDWGATPAAIDCALTVADEMDIQVALHSDTLNESGFVEDTLAAIGGRTIHTFHTEGAGGGHAPDIITACAHPNILPSSTNPTLPYTLNTIDEHLDMLMVAHHLDPDIAEDVAFAESRIRRETIAAEDVLHDLGAFSLTSSDSQAMGRVGEVILRTWQVAHRMKVQRGALAEETGDNDNFRVKRYIAKYTINPALTHGIAHEVGSIEVGKLADLVVWSPAFFGVKPATVIKGGMIAIAPMGDINASIPTPQPVHYRPMFGALGSARHHCRLTFLSQAAAANGVAERLNLRSAIAVVKGCRTVQKADMVHNSLQPNITVDAQTYEVRVDGELITSEPADVLPMAQRYFLF

Source Source

Source organism organism	Klebsiella aerogenes
NCBI taxonomy ID ncbi_taxonomy_id	28451
Host organism host_organism	Escherichia coli

Entity 4 Entity 4 non-polymer

Description description	NICKEL (II) ION
Molecular weight formula_weight	58.7 kDa
Source method src_method	syn
Copy count entity_count	2

Entity 5 Entity 5 non-polymer

Description description	ACETOHYDROXAMIC ACID
Molecular weight formula_weight	75.1 kDa
Source method src_method	syn
Copy count entity_count	1

Entity 6 Entity 6 water

Description description	water
Molecular weight formula_weight	18.0 kDa
Source method src_method	nat
Copy count entity_count	277

▼

6. Fold Classification (SCOP + CATH) 8 domains

SCOP 2.08 (4 domains)

Domain ID domain_id	d1fwea_
Class class	d — Alpha and beta proteins (a+b)
Fold Fold fold	d.8 — Urease, gamma-subunit
Superfamily Superfamily superfamily	d.8.1 — Urease, gamma-subunit
Family Family family	d.8.1.1 — Urease, gamma-subunit

Domain ID domain_id	d1fweb_
Class class	b — All beta proteins
Fold Fold fold	b.85 — beta-clip
Superfamily Superfamily superfamily	b.85.3 — Urease, beta-subunit
Family Family family	b.85.3.1 — Urease, beta-subunit

Domain ID domain_id	d1fwec1
Class class	b — All beta proteins
Fold Fold fold	b.92 — Composite domain of metallo-dependent hydrolases
Superfamily Superfamily superfamily	b.92.1 — Composite domain of metallo-dependent hydrolases
Family Family family	b.92.1.1 — alpha-Subunit of urease

Domain ID domain_id	d1fwec2
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.1 — TIM beta/alpha-barrel
Superfamily Superfamily superfamily	c.1.9 — Metallo-dependent hydrolases
Family Family family	c.1.9.2 — alpha-subunit of urease, catalytic domain

CATH v4.4 (4 domains)

Domain ID domain_id	1fweA00
Class class	3 — Alpha Beta
Architecture architecture	30 — 2-Layer Sandwich
Topology topology	280 — Urease; subunit A
Homologous superfamily homologous superfamily	10 — Urease, gamma-like subunit

Domain ID domain_id	1fweB00
Class class	2 — Mainly Beta
Architecture architecture	10 — Ribbon
Topology topology	150 — Urease, subunit B
Homologous superfamily homologous superfamily	10 — Urease, beta subunit

Domain ID domain_id	1fweC01
Class class	2 — Mainly Beta
Architecture architecture	30 — Roll
Topology topology	40 — Urease, subunit C; domain 1
Homologous superfamily homologous superfamily	10 — Urease, subunit C, domain 1

Domain ID domain_id	1fweC02
Class class	3 — Alpha Beta
Architecture architecture	20 — Alpha-Beta Barrel
Topology topology	20 — TIM Barrel
Homologous superfamily homologous superfamily	140 — Metal-dependent hydrolases

▶

Unit-cell length a length_a	170.800 Å
Unit-cell length b length_b	170.800 Å
Unit-cell length c length_c	170.800 Å
Unit-cell angle α angle_alpha	90.00 °
Unit-cell angle β angle_beta	90.00 °
Unit-cell angle γ angle_gamma	90.00 °
Molecules per unit cell Z z_pdb	24

Space group space_group	I 21 3
Space-group number int_tables_number	199
Crystal system crystal_system	—

Resolution resolution	2.000 Å
Low-resolution limit resolution_low	10.000 Å
R factor r_factor	0.2040
R_work r_work	0.2040
R_free r_free	—

KLEBSIELLA AEROGENES UREASE, C319A VARIANT WITH ACETOHYDROXAMIC ACID (AHA) BOUND
