1hdg

THE CRYSTAL STRUCTURE OF HOLO-GLYCERALDEHYDE-3-PHOSPHATE DEHYDROGENASE FROM THE HYPERTHERMOPHILIC BACTERIUM THERMOTOGA MARITIMA AT 2.5 ANGSTROMS RESOLUTION

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

HOLO-D-GLYCERALDEHYDE-3-PHOSPHATE DEHYDROGENASE

Thermotoga maritima

UniProt P17721

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein homooligomer Homooligomer Protein 4 SULFATE ION × 8 NICOTINAMIDE-ADENINE-DINUCLEOTIDE × 4 water × 4 Consistent with protein count

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer
1hdg

1 assemblies

Other homooligomers

None

Heteromeric or nucleic-acid complex

None

View Construct and Data Evidence
UniProt name G3P_THEMA
Isoform —
PDB entities 1
Chains and sequence ranges Author chain O； PDBConstruct 1–332； UniProt 1–332 Author chain Q； PDBConstruct 1–332； UniProt 1–332

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id1hdg
Deposition date deposition_date1995-01-17
Structure title titleTHE CRYSTAL STRUCTURE OF HOLO-GLYCERALDEHYDE-3-PHOSPHATE DEHYDROGENASE FROM THE HYPERTHERMOPHILIC BACTERIUM THERMOTOGA MARITIMA AT 2.5 ANGSTROMS RESOLUTION
Keywords keywordsOXIDOREDUCTASE (ALDEHY(D)-NAD(A)); OXIDOREDUCTASE (ALDEHY(D)-NAD(A))
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1hdg__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1hdg__assembly_1__model_1 | I(q)

10-2 10-1 106 107 108 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

1hdg__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）32.43 Å
Rg (electron density)31.80 Å
Total Rg32.52 Å
Atom count10432
Residues1328
Excluded volume187030 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 1hdg__assembly_1__model_1 tetrameric （4） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (4)

▼

6. Fold Classification (SCOP + CATH) 8 domains

SCOP 2.08 (4 domains)

Domain ID domain_idd1hdgo1
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.2 — NAD(P)-binding Rossmann-fold domains
Superfamily Superfamily superfamilyc.2.1 — NAD(P)-binding Rossmann-fold domains
Family Family familyc.2.1.3 — Glyceraldehyde-3-phosphate dehydrogenase-like, N-terminal domain
Domain ID domain_idd1hdgo2
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.81 — FwdE/GAPDH domain-like
Superfamily Superfamily superfamilyd.81.1 — Glyceraldehyde-3-phosphate dehydrogenase-like, C-terminal domain
Family Family familyd.81.1.1 — GAPDH-like
Domain ID domain_idd1hdgq1
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.2 — NAD(P)-binding Rossmann-fold domains
Superfamily Superfamily superfamilyc.2.1 — NAD(P)-binding Rossmann-fold domains
Family Family familyc.2.1.3 — Glyceraldehyde-3-phosphate dehydrogenase-like, N-terminal domain
Domain ID domain_idd1hdgq2
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.81 — FwdE/GAPDH domain-like
Superfamily Superfamily superfamilyd.81.1 — Glyceraldehyde-3-phosphate dehydrogenase-like, C-terminal domain
Family Family familyd.81.1.1 — GAPDH-like

CATH v4.4 (4 domains)

Domain ID domain_id1hdgO01
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily720 — NAD(P)-binding Rossmann-like Domain
Domain ID domain_id1hdgO02
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology360 — Dihydrodipicolinate Reductase; domain 2
Homologous superfamily homologous superfamily10 — Dihydrodipicolinate Reductase; domain 2
Domain ID domain_id1hdgQ01
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily720 — NAD(P)-binding Rossmann-like Domain
Domain ID domain_id1hdgQ02
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology360 — Dihydrodipicolinate Reductase; domain 2
Homologous superfamily homologous superfamily10 — Dihydrodipicolinate Reductase; domain 2
▶

7. Citations (1)
