SAXSdb — 1hw7

▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

HEAT SHOCK PROTEIN HSP33

Escherichia coli

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein homooligomer	Homooligomer	Protein 2	SULFATE ION × 8 ZINC ION × 2 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 water × 2	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	HSLO_ECOLI
Isoform	—
PDB entities	1
Chains and sequence ranges	Author chain A； PDBConstruct 1–255； UniProt 1–255

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id	1hw7
Deposition date deposition_date	2001-01-09
Structure title title	HSP33, HEAT SHOCK PROTEIN WITH REDOX-REGULATED CHAPERONE ACTIVITY
Keywords keywords	Hsp33, dimerization, heat shock protein, oxidative stress, CHAPERONE; CHAPERONE
Experimental Method method	X-RAY DIFFRACTION

▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1hw7__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1hw7__assembly_1__model_1 | I(q)

100 plotted points; both axes use logarithmic scales.

1hw7__assembly_1__model_1 | P(r) · Pending

P(r) will be calculated and displayed separately for the same assembly/model.

Rg（Guinier）	25.18 Å
Rg (electron density)	24.00 Å
Total Rg	24.83 Å
Atom count	3644
Residues	458
Excluded volume	64342 Å³
Maximum q	0.500 Å⁻¹

Assembly	Model	Structure unit	Oligomeric description	Status	CRYSOL	Actions
1	1	`1hw7__assembly_1__model_1`	dimeric （2）	Success	4.1.3-1-20251215 (887e7ef)	View Download

▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (5)

Entity 1 Entity 1 polymer

Description description	HEAT SHOCK PROTEIN HSP33
Molecular weight formula_weight	28442.0 kDa
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	A
Atom count atom_count	1972

MIMPQHDQLHRYLFENFAVRGELVTVSETLQQILENHDYPQPVKNVLAELLVATSLLTATLKFDGDITVQLQGDGPMNLAVINGNNNQQMRGVARVQGEIPENADLKTLVGNGYVVITITPSEGERYQGVVGLEGDTLAACLEDYFMRSEQLPTRLFIRTGDVDGKPAAGGMLLQVMPAQNAQQDDFDHLATLTETIKTEELLTLPANEVLWRLYHEEEVTVYDPQDVEFKCTCSRERCADALKTLPDEEVDSIL

Source Source

Source organism organism	Escherichia coli
NCBI taxonomy ID ncbi_taxonomy_id	562
Host organism host_organism	Escherichia coli BL21(DE3)

Entity 2 Entity 2 non-polymer

Description description	SULFATE ION
Molecular weight formula_weight	96.1 kDa
Source method src_method	syn
Copy count entity_count	4

Entity 3 Entity 3 non-polymer

Description description	ZINC ION
Molecular weight formula_weight	65.4 kDa
Source method src_method	syn
Copy count entity_count	1

Entity 4 Entity 4 non-polymer

Description description	2-(N-MORPHOLINO)-ETHANESULFONIC ACID
Molecular weight formula_weight	195.2 kDa
Source method src_method	syn
Copy count entity_count	1

Entity 5 Entity 5 water

Description description	water
Molecular weight formula_weight	18.0 kDa
Source method src_method	nat
Copy count entity_count	144

▼

6. Fold Classification (SCOP + CATH) 3 domains

SCOP 2.08 (1 domains)

Domain ID domain_id	d1hw7a_
Class class	d — Alpha and beta proteins (a+b)
Fold Fold fold	d.193 — Hsp33 domain
Superfamily Superfamily superfamily	d.193.1 — Hsp33 domain
Family Family family	d.193.1.1 — Hsp33 domain

CATH v4.4 (2 domains)

Domain ID domain_id	1hw7A01
Class class	3 — Alpha Beta
Architecture architecture	55 — 3-Layer(bab) Sandwich
Topology topology	30 — Hsp33 domain
Homologous superfamily homologous superfamily	10 — Hsp33 domain

Domain ID domain_id	1hw7A02
Class class	1 — Mainly Alpha
Architecture architecture	10 — Orthogonal Bundle
Topology topology	287 — Helix Hairpins
Homologous superfamily homologous superfamily	480 — helix hairpin bin

▶

Unit-cell length a length_a	77.180 Å
Unit-cell length b length_b	77.180 Å
Unit-cell length c length_c	199.210 Å
Unit-cell angle α angle_alpha	90.00 °
Unit-cell angle β angle_beta	90.00 °
Unit-cell angle γ angle_gamma	120.00 °
Molecules per unit cell Z z_pdb	12

Space group space_group	P 65 2 2
Space-group number int_tables_number	179
Crystal system crystal_system	—

Resolution resolution	2.200 Å
Low-resolution limit resolution_low	30.000 Å
R factor r_factor	—
R_work r_work	0.2295
R_free r_free	0.2567
