1kkd

Solution structure of the calmodulin binding domain (CaMBD) of small conductance Ca2+-activated potassium channels (SK2)

Method: SOLUTION NMR
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Small conductance calcium-activated potassium channel protein 2

Rattus norvegicus

UniProt P70604

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein monomer Monomer Protein 1 No other associated polymer Consistent with protein count

Other States of the Same Protein in the Database

Monomer
1kkd

1 assemblies

Homodimer

None

Homotetramer

None

Other homooligomers
2pnv 2pnv 2pnv

3 assemblies

Heteromeric or nucleic-acid complex
1g4y 1qx7 3sjq 4g27 4g28 4j9y 4j9z 4qnh 4qnh 6czq 8v2g 8v2h

17 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name KCNN2_RAT
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 3–94； UniProt 396–487

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id1kkd
Deposition date deposition_date2001-12-07
Structure title titleSolution structure of the calmodulin binding domain (CaMBD) of small conductance Ca2+-activated potassium channels (SK2)
Keywords keywordsSMALL-CONDUCTANCE CALCIUM-ACTIVATED POTASSIUM CHANNEL, CALMODULIN BINDING DOMAIN (CAMBD), CHANNEL GATING, SIGNALING PROTEIN; SIGNALING PROTEIN
Experimental Method methodSOLUTION NMR
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1kkd__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1kkd__assembly_1__model_1 | I(q)

10-2 10-1 105 106 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

1kkd__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）22.31 Å
Rg (electron density)21.64 Å
Total Rg22.64 Å
Atom count1583
Residues92
Excluded volume13855 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 1kkd__assembly_1__model_1 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 2 1kkd__assembly_1__model_2 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 3 1kkd__assembly_1__model_3 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 4 1kkd__assembly_1__model_4 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 5 1kkd__assembly_1__model_5 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 6 1kkd__assembly_1__model_6 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 7 1kkd__assembly_1__model_7 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 8 1kkd__assembly_1__model_8 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 9 1kkd__assembly_1__model_9 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 10 1kkd__assembly_1__model_10 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 11 1kkd__assembly_1__model_11 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 12 1kkd__assembly_1__model_12 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 13 1kkd__assembly_1__model_13 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 14 1kkd__assembly_1__model_14 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 15 1kkd__assembly_1__model_15 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 16 1kkd__assembly_1__model_16 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 17 1kkd__assembly_1__model_17 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 18 1kkd__assembly_1__model_18 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 19 1kkd__assembly_1__model_19 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 20 1kkd__assembly_1__model_20 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 21 1kkd__assembly_1__model_21 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 22 1kkd__assembly_1__model_22 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
1 23 1kkd__assembly_1__model_23 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (1)

▼

6. Fold Classification (SCOP + CATH) 2 domains

SCOP 2.08 (1 domains)

Domain ID domain_idd1kkda_
Class classf — Membrane and cell surface proteins and peptides
Fold Fold foldf.15 — Small-conductance potassium channel
Superfamily Superfamily superfamilyf.15.1 — Small-conductance potassium channel
Family Family familyf.15.1.1 — Small-conductance potassium channel

CATH v4.4 (1 domains)

Domain ID domain_id1kkdA00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology287 — Helix Hairpins
Homologous superfamily homologous superfamily70 —
▶
