SAXSdb — 1pnv

▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

GLYCOSYLTRANSFERASE GTFA

AMYCOLATOPSIS ORIENTALIS

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Other combination	Heteromer	Protein 3 其他Polymer 1	VANCOMYCIN × 1 vancosamine-(1-2)-beta-D-glucopyranose × 1 THYMIDINE-5'-DIPHOSPHATE × 1 water × 3	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	P96558_AMYOR
Isoform	—
PDB entities	1
Chains and sequence ranges	Author chain A； PDBConstruct 1–396； UniProt 1–396 Author chain B； PDBConstruct 1–396； UniProt 1–396

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id	1pnv
Deposition date deposition_date	2003-06-13
Structure title title	Crystal Structure of TDP-epi-Vancosaminyltransferase GtfA in complexes with TDP and Vancomycin
Keywords keywords	GT-B GLYCOSYLTRANSFERASE, ROSSMANN FOLD, GLYCOPEPTIDE, ANTIBIOTIC, TRANSFERASE-ANTIBIOTIC COMPLEX; TRANSFERASE/ANTIBIOTIC
Experimental Method method	X-RAY DIFFRACTION

▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1pnv__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1pnv__assembly_1__model_1 | I(q)

100 plotted points; both axes use logarithmic scales.

1pnv__assembly_1__model_1 | P(r) · Pending

P(r) will be calculated and displayed separately for the same assembly/model.

Rg（Guinier）	29.76 Å
Rg (electron density)	28.90 Å
Total Rg	29.56 Å
Atom count	5697
Residues	767
Excluded volume	101130 Å³
Maximum q	0.500 Å⁻¹

Assembly	Model	Structure unit	Oligomeric description	Status	CRYSOL	Actions
1	1	`1pnv__assembly_1__model_1`	trimeric （3）	Success	4.1.3-1-20251215 (887e7ef)	View Download

▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (5)

Entity 1 Entity 1 polymer

Description description	GLYCOSYLTRANSFERASE GTFA
Molecular weight formula_weight	42773.4 kDa
Source method src_method	man
Copy count entity_count	2

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	A,B
Atom count atom_count	5783

MRVLITGCGSRGDTEPLVALAARLRELGADARMCLPPDYVERCAEVGVPMVPVGRAVRAGAREPGELPPGAAEVVTEVVAEWFDKVPAAIEGCDAVVTTGLLPAAVAVRSMAEKLGIPYRYTVLSPDHLPSEQSQAERDMYNQGADRLFGDAVNSHRASIGLPPVEHLYDYGYTDQPWLAADPVLSPLRPTDLGTVQTGAWILPDERPLSAELEAFLAAGSTPVYVGFGSSSRPATADAAKMAIKAVRASGRRIVLSRGWADLVLPDDGADCFVVGEVNLQELFGRVAAAIHHDSAGTTLLAMRAGIPQIVVRRVVDNVVEQAYHADRVAELGVGVAVDGPVPTIDSLSAALDTALAPEIRARATTVADTIRADGTTVAAQLLFDAVSLEKPTVPALEHHHHHH

Source Source

Source organism organism	AMYCOLATOPSIS ORIENTALIS
NCBI taxonomy ID ncbi_taxonomy_id	31958
Host organism host_organism	ESCHERICHIA COLI BL21(DE3)

Entity 2 Entity 2 polymer

Description description	VANCOMYCIN
Molecular weight formula_weight	1150.0 kDa
Source method src_method	nat
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	C

XXNGGYX

Entity 3 Entity 3 branched

Description description	vancosamine-(1-2)-beta-D-glucopyranose
Molecular weight formula_weight	323.3 kDa
Source method src_method	man
Copy count entity_count	1

Entity 4 Entity 4 non-polymer

Description description	THYMIDINE-5'-DIPHOSPHATE
Molecular weight formula_weight	402.2 kDa
Source method src_method	syn
Copy count entity_count	1

Entity 5 Entity 5 water

Description description	water
Molecular weight formula_weight	18.0 kDa
Source method src_method	nat
Copy count entity_count	86

▼

6. Fold Classification (SCOP + CATH) 6 domains

SCOP 2.08 (2 domains)

Domain ID domain_id	d1pnva_
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.87 — UDP-Glycosyltransferase/glycogen phosphorylase
Superfamily Superfamily superfamily	c.87.1 — UDP-Glycosyltransferase/glycogen phosphorylase
Family Family family	c.87.1.5 — Gtf glycosyltransferase

Domain ID domain_id	d1pnvb_
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.87 — UDP-Glycosyltransferase/glycogen phosphorylase
Superfamily Superfamily superfamily	c.87.1 — UDP-Glycosyltransferase/glycogen phosphorylase
Family Family family	c.87.1.5 — Gtf glycosyltransferase

CATH v4.4 (4 domains)

Domain ID domain_id	1pnvA01
Class class	3 — Alpha Beta
Architecture architecture	40 — 3-Layer(aba) Sandwich
Topology topology	50 — Rossmann fold
Homologous superfamily homologous superfamily	2000 — Glycogen Phosphorylase B;

Domain ID domain_id	1pnvA02
Class class	3 — Alpha Beta
Architecture architecture	40 — 3-Layer(aba) Sandwich
Topology topology	50 — Rossmann fold
Homologous superfamily homologous superfamily	2000 — Glycogen Phosphorylase B;

Domain ID domain_id	1pnvB01
Class class	3 — Alpha Beta
Architecture architecture	40 — 3-Layer(aba) Sandwich
Topology topology	50 — Rossmann fold
Homologous superfamily homologous superfamily	2000 — Glycogen Phosphorylase B;

Domain ID domain_id	1pnvB02
Class class	3 — Alpha Beta
Architecture architecture	40 — 3-Layer(aba) Sandwich
Topology topology	50 — Rossmann fold
Homologous superfamily homologous superfamily	2000 — Glycogen Phosphorylase B;

▶

Unit-cell length a length_a	153.170 Å
Unit-cell length b length_b	153.170 Å
Unit-cell length c length_c	100.640 Å
Unit-cell angle α angle_alpha	90.00 °
Unit-cell angle β angle_beta	90.00 °
Unit-cell angle γ angle_gamma	120.00 °
Molecules per unit cell Z z_pdb	12

Space group space_group	P 32 2 1
Space-group number int_tables_number	154
Crystal system crystal_system	—

Resolution resolution	2.800 Å
Low-resolution limit resolution_low	30.000 Å
R factor r_factor	0.2210
R_work r_work	0.2210
R_free r_free	0.2690

Crystal Structure of TDP-epi-Vancosaminyltransferase GtfA in complexes with TDP and Vancomycin
