1s3s

Crystal structure of AAA ATPase p97/VCP ND1 in complex with p47 C

Method: X-RAY DIFFRACTION

▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

;Transitional endoplasmic reticulum ATPase (TER ATPase) (15S Mg(2+)- ATPase p97 subunit) (Valosin containing protein) (VCP) [Contains: Valosin] ;

Mus musculus

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein heterocomplex	Heteromer	Protein 9	p47 protein × 3 （O35987） ADENOSINE-5'-DIPHOSPHATE × 6 water × 9	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	TERA_MOUSE
Isoform	—
PDB entities	1
Chains and sequence ranges	Author chain A； PDBConstruct 1–458； UniProt 1–457 Author chain B； PDBConstruct 1–458； UniProt 1–457 Author chain C； PDBConstruct 1–458； UniProt 1–457 Author chain D； PDBConstruct 1–458； UniProt 1–457 Author chain E； PDBConstruct 1–458； UniProt 1–457 Author chain F； PDBConstruct 1–458； UniProt 1–457

p47 protein

Rattus norvegicus

UniProt O35987

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein heterocomplex	Heteromer	Protein 9	;Transitional endoplasmic reticulum ATPase (TER ATPase) (15S Mg(2+)- ATPase p97 subunit) (Valosin containing protein) (VCP) [Contains: Valosin] ; × 6 （Q01853） ADENOSINE-5'-DIPHOSPHATE × 6 water × 9	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	NSF1C_RAT
Isoform	—
PDB entities	2
Chains and sequence ranges	Author chain G； PDBConstruct 1–127； UniProt 244–370 Author chain H； PDBConstruct 1–127； UniProt 244–370 Author chain I； PDBConstruct 1–127； UniProt 244–370

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id	1s3s
Deposition date deposition_date	2004-01-14
Structure title title	Crystal structure of AAA ATPase p97/VCP ND1 in complex with p47 C
Keywords keywords	AAA ATPase, p97, p47, protein-protein complex, UBX domain, PROTEIN BINDING; PROTEIN BINDING
Experimental Method method	X-RAY DIFFRACTION

▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1s3s__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1s3s__assembly_1__model_1 | I(q)

100 plotted points; both axes use logarithmic scales.

1s3s__assembly_1__model_1 | P(r) · Pending

P(r) will be calculated and displayed separately for the same assembly/model.

Rg（Guinier）	55.78 Å
Rg (electron density)	55.93 Å
Total Rg	55.89 Å
Atom count	22304
Residues	2871
Excluded volume	396990 Å³
Maximum q	0.500 Å⁻¹

Assembly	Model	Structure unit	Oligomeric description	Status	CRYSOL	Actions
1	1	`1s3s__assembly_1__model_1`	nonameric （9）	Success	4.1.3-1-20251215 (887e7ef)	View Download

▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (4)

Entity 1 Entity 1 polymer

Description description	;Transitional endoplasmic reticulum ATPase (TER ATPase) (15S Mg(2+)- ATPase p97 subunit) (Valosin containing protein) (VCP) [Contains: Valosin] ;
Molecular weight formula_weight	51027.5 kDa
Source method src_method	man
Copy count entity_count	6

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	A,B,C,D,E,F
Atom count atom_count	22367

MASGADSKGDDLSTAILKQKNRPNRLIVDEAINEDNSVVSLSQPKMDELQLFRGDTVLLKGKKRREAVCIVLSDDTCSDEKIRMNRVVRNNLRVRLGDVISIQPCPDVKYGKRIHVLPIDDTVEGITGNLFEVYLKPYFLEAYRPIRKGDIFLVRGGMRAVEFKVVETDPSPYCIVAPDTVIHCEGEPIKREDEEESLNEVGYDDVGGCRKQLAQIKEMVELPLRHPALFKAIGVKPPRGILLYGPPGTGKTLIARAVANETGAFFFLINGPEIMSKLAGESESNLRKAFEEAEKNAPAIIFIDELDAIAPKREKTHGEVERRIVSQLLTLMDGLKQRAHVIVMAATNRPNSIDPALRRFGRFDREVDIGIPDATGRLEILQIHTKNMKLADDVDLEQVANETHGHVGADLAALCSEAALQAIRKKMDLIDLEDETIDAEVMNSLAVTMDDFRWALSQ

Source Source

Source organism organism	Mus musculus
Common name common_name	house mouse
NCBI taxonomy ID ncbi_taxonomy_id	10090
Host organism host_organism	Escherichia coli

Entity 2 Entity 2 polymer

Description description	p47 protein
Molecular weight formula_weight	13775.6 kDa
Source method src_method	man
Copy count entity_count	3

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	G,H,I

VKPKGAFKAFTGEGQKLGSTAPQVLNTSSPAQQAENEAKASSSILINEAEPTTNIQIRLADGGRLVQKFNHSHRISDIRLFIVDARPAMAATSFVLMTTFPNKELADENQTLKEANLLNAVIVQRLT

Source Source

Source organism organism	Rattus norvegicus
Common name common_name	Norway rat
NCBI taxonomy ID ncbi_taxonomy_id	10116
Host organism host_organism	Escherichia coli

Entity 3 Entity 3 non-polymer

Description description	ADENOSINE-5'-DIPHOSPHATE
Molecular weight formula_weight	427.2 kDa
Source method src_method	syn
Copy count entity_count	6

Entity 4 Entity 4 water

Description description	water
Molecular weight formula_weight	18.0 kDa
Source method src_method	nat
Copy count entity_count	63

▼

6. Fold Classification (SCOP + CATH) 47 domains

SCOP 2.08 (21 domains)

Domain ID domain_id	d1s3sa1
Class class	b — All beta proteins
Fold Fold fold	b.52 — Double psi beta-barrel
Superfamily Superfamily superfamily	b.52.2 — ADC-like
Family Family family	b.52.2.3 — Cdc48 N-terminal domain-like

Domain ID domain_id	d1s3sa2
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.37 — P-loop containing nucleoside triphosphate hydrolases
Superfamily Superfamily superfamily	c.37.1 — P-loop containing nucleoside triphosphate hydrolases
Family Family family	c.37.1.20 — Extended AAA-ATPase domain

Domain ID domain_id	d1s3sa3
Class class	d — Alpha and beta proteins (a+b)
Fold Fold fold	d.31 — Cdc48 domain 2-like
Superfamily Superfamily superfamily	d.31.1 — Cdc48 domain 2-like
Family Family family	d.31.1.1 — Cdc48 domain 2-like

Domain ID domain_id	d1s3sb1
Class class	b — All beta proteins
Fold Fold fold	b.52 — Double psi beta-barrel
Superfamily Superfamily superfamily	b.52.2 — ADC-like
Family Family family	b.52.2.3 — Cdc48 N-terminal domain-like

Domain ID domain_id	d1s3sb2
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.37 — P-loop containing nucleoside triphosphate hydrolases
Superfamily Superfamily superfamily	c.37.1 — P-loop containing nucleoside triphosphate hydrolases
Family Family family	c.37.1.20 — Extended AAA-ATPase domain

Domain ID domain_id	d1s3sb3
Class class	d — Alpha and beta proteins (a+b)
Fold Fold fold	d.31 — Cdc48 domain 2-like
Superfamily Superfamily superfamily	d.31.1 — Cdc48 domain 2-like
Family Family family	d.31.1.1 — Cdc48 domain 2-like

Domain ID domain_id	d1s3sc1
Class class	b — All beta proteins
Fold Fold fold	b.52 — Double psi beta-barrel
Superfamily Superfamily superfamily	b.52.2 — ADC-like
Family Family family	b.52.2.3 — Cdc48 N-terminal domain-like

Domain ID domain_id	d1s3sc2
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.37 — P-loop containing nucleoside triphosphate hydrolases
Superfamily Superfamily superfamily	c.37.1 — P-loop containing nucleoside triphosphate hydrolases
Family Family family	c.37.1.20 — Extended AAA-ATPase domain

Domain ID domain_id	d1s3sc3
Class class	d — Alpha and beta proteins (a+b)
Fold Fold fold	d.31 — Cdc48 domain 2-like
Superfamily Superfamily superfamily	d.31.1 — Cdc48 domain 2-like
Family Family family	d.31.1.1 — Cdc48 domain 2-like

Domain ID domain_id	d1s3sd1
Class class	b — All beta proteins
Fold Fold fold	b.52 — Double psi beta-barrel
Superfamily Superfamily superfamily	b.52.2 — ADC-like
Family Family family	b.52.2.3 — Cdc48 N-terminal domain-like

Domain ID domain_id	d1s3sd2
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.37 — P-loop containing nucleoside triphosphate hydrolases
Superfamily Superfamily superfamily	c.37.1 — P-loop containing nucleoside triphosphate hydrolases
Family Family family	c.37.1.20 — Extended AAA-ATPase domain

Domain ID domain_id	d1s3sd3
Class class	d — Alpha and beta proteins (a+b)
Fold Fold fold	d.31 — Cdc48 domain 2-like
Superfamily Superfamily superfamily	d.31.1 — Cdc48 domain 2-like
Family Family family	d.31.1.1 — Cdc48 domain 2-like

Domain ID domain_id	d1s3se1
Class class	b — All beta proteins
Fold Fold fold	b.52 — Double psi beta-barrel
Superfamily Superfamily superfamily	b.52.2 — ADC-like
Family Family family	b.52.2.3 — Cdc48 N-terminal domain-like

Domain ID domain_id	d1s3se2
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.37 — P-loop containing nucleoside triphosphate hydrolases
Superfamily Superfamily superfamily	c.37.1 — P-loop containing nucleoside triphosphate hydrolases
Family Family family	c.37.1.20 — Extended AAA-ATPase domain

Domain ID domain_id	d1s3se3
Class class	d — Alpha and beta proteins (a+b)
Fold Fold fold	d.31 — Cdc48 domain 2-like
Superfamily Superfamily superfamily	d.31.1 — Cdc48 domain 2-like
Family Family family	d.31.1.1 — Cdc48 domain 2-like

Domain ID domain_id	d1s3sf1
Class class	b — All beta proteins
Fold Fold fold	b.52 — Double psi beta-barrel
Superfamily Superfamily superfamily	b.52.2 — ADC-like
Family Family family	b.52.2.3 — Cdc48 N-terminal domain-like

Domain ID domain_id	d1s3sf2
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.37 — P-loop containing nucleoside triphosphate hydrolases
Superfamily Superfamily superfamily	c.37.1 — P-loop containing nucleoside triphosphate hydrolases
Family Family family	c.37.1.20 — Extended AAA-ATPase domain

Domain ID domain_id	d1s3sf3
Class class	d — Alpha and beta proteins (a+b)
Fold Fold fold	d.31 — Cdc48 domain 2-like
Superfamily Superfamily superfamily	d.31.1 — Cdc48 domain 2-like
Family Family family	d.31.1.1 — Cdc48 domain 2-like

Domain ID domain_id	d1s3sg_
Class class	d — Alpha and beta proteins (a+b)
Fold Fold fold	d.15 — beta-Grasp (ubiquitin-like)
Superfamily Superfamily superfamily	d.15.1 — Ubiquitin-like
Family Family family	d.15.1.2 — UBX domain

Domain ID domain_id	d1s3sh_
Class class	d — Alpha and beta proteins (a+b)
Fold Fold fold	d.15 — beta-Grasp (ubiquitin-like)
Superfamily Superfamily superfamily	d.15.1 — Ubiquitin-like
Family Family family	d.15.1.2 — UBX domain

Domain ID domain_id	d1s3si_
Class class	d — Alpha and beta proteins (a+b)
Fold Fold fold	d.15 — beta-Grasp (ubiquitin-like)
Superfamily Superfamily superfamily	d.15.1 — Ubiquitin-like
Family Family family	d.15.1.2 — UBX domain

CATH v4.4 (26 domains)

Domain ID domain_id	1s3sA01
Class class	2 — Mainly Beta
Architecture architecture	40 — Beta Barrel
Topology topology	40 — Barwin-like endoglucanases
Homologous superfamily homologous superfamily	20 —

Domain ID domain_id	1s3sA02
Class class	3 — Alpha Beta
Architecture architecture	40 — 3-Layer(aba) Sandwich
Topology topology	50 — Rossmann fold
Homologous superfamily homologous superfamily	300 — P-loop containing nucleotide triphosphate hydrolases

Domain ID domain_id	1s3sA03
Class class	3 — Alpha Beta
Architecture architecture	10 — Roll
Topology topology	330 — Vcp-like ATPase; Chain A, domain 2
Homologous superfamily homologous superfamily	10 —

Domain ID domain_id	1s3sA04
Class class	1 — Mainly Alpha
Architecture architecture	10 — Orthogonal Bundle
Topology topology	8 — Helicase, Ruva Protein; domain 3
Homologous superfamily homologous superfamily	60 —

Domain ID domain_id	1s3sB01
Class class	2 — Mainly Beta
Architecture architecture	40 — Beta Barrel
Topology topology	40 — Barwin-like endoglucanases
Homologous superfamily homologous superfamily	20 —

Domain ID domain_id	1s3sB02
Class class	3 — Alpha Beta
Architecture architecture	40 — 3-Layer(aba) Sandwich
Topology topology	50 — Rossmann fold
Homologous superfamily homologous superfamily	300 — P-loop containing nucleotide triphosphate hydrolases

Domain ID domain_id	1s3sB03
Class class	3 — Alpha Beta
Architecture architecture	10 — Roll
Topology topology	330 — Vcp-like ATPase; Chain A, domain 2
Homologous superfamily homologous superfamily	10 —

Domain ID domain_id	1s3sB04
Class class	1 — Mainly Alpha
Architecture architecture	10 — Orthogonal Bundle
Topology topology	8 — Helicase, Ruva Protein; domain 3
Homologous superfamily homologous superfamily	60 —

Domain ID domain_id	1s3sC01
Class class	2 — Mainly Beta
Architecture architecture	40 — Beta Barrel
Topology topology	40 — Barwin-like endoglucanases
Homologous superfamily homologous superfamily	20 —

Domain ID domain_id	1s3sC02
Class class	3 — Alpha Beta
Architecture architecture	40 — 3-Layer(aba) Sandwich
Topology topology	50 — Rossmann fold
Homologous superfamily homologous superfamily	300 — P-loop containing nucleotide triphosphate hydrolases

Domain ID domain_id	1s3sC03
Class class	3 — Alpha Beta
Architecture architecture	10 — Roll
Topology topology	330 — Vcp-like ATPase; Chain A, domain 2
Homologous superfamily homologous superfamily	10 —

Domain ID domain_id	1s3sC04
Class class	1 — Mainly Alpha
Architecture architecture	10 — Orthogonal Bundle
Topology topology	8 — Helicase, Ruva Protein; domain 3
Homologous superfamily homologous superfamily	60 —

Domain ID domain_id	1s3sD01
Class class	2 — Mainly Beta
Architecture architecture	40 — Beta Barrel
Topology topology	40 — Barwin-like endoglucanases
Homologous superfamily homologous superfamily	20 —

Domain ID domain_id	1s3sD02
Class class	3 — Alpha Beta
Architecture architecture	40 — 3-Layer(aba) Sandwich
Topology topology	50 — Rossmann fold
Homologous superfamily homologous superfamily	300 — P-loop containing nucleotide triphosphate hydrolases

Domain ID domain_id	1s3sD03
Class class	3 — Alpha Beta
Architecture architecture	10 — Roll
Topology topology	330 — Vcp-like ATPase; Chain A, domain 2
Homologous superfamily homologous superfamily	10 —

Domain ID domain_id	1s3sD04
Class class	1 — Mainly Alpha
Architecture architecture	10 — Orthogonal Bundle
Topology topology	8 — Helicase, Ruva Protein; domain 3
Homologous superfamily homologous superfamily	60 —

Domain ID domain_id	1s3sE01
Class class	2 — Mainly Beta
Architecture architecture	40 — Beta Barrel
Topology topology	40 — Barwin-like endoglucanases
Homologous superfamily homologous superfamily	20 —

Domain ID domain_id	1s3sE02
Class class	3 — Alpha Beta
Architecture architecture	40 — 3-Layer(aba) Sandwich
Topology topology	50 — Rossmann fold
Homologous superfamily homologous superfamily	300 — P-loop containing nucleotide triphosphate hydrolases

Domain ID domain_id	1s3sE03
Class class	3 — Alpha Beta
Architecture architecture	10 — Roll
Topology topology	330 — Vcp-like ATPase; Chain A, domain 2
Homologous superfamily homologous superfamily	10 —

Domain ID domain_id	1s3sE04
Class class	1 — Mainly Alpha
Architecture architecture	10 — Orthogonal Bundle
Topology topology	8 — Helicase, Ruva Protein; domain 3
Homologous superfamily homologous superfamily	60 —

Domain ID domain_id	1s3sF01
Class class	2 — Mainly Beta
Architecture architecture	40 — Beta Barrel
Topology topology	40 — Barwin-like endoglucanases
Homologous superfamily homologous superfamily	20 —

Domain ID domain_id	1s3sF02
Class class	3 — Alpha Beta
Architecture architecture	40 — 3-Layer(aba) Sandwich
Topology topology	50 — Rossmann fold
Homologous superfamily homologous superfamily	300 — P-loop containing nucleotide triphosphate hydrolases

Domain ID domain_id	1s3sF03
Class class	3 — Alpha Beta
Architecture architecture	10 — Roll
Topology topology	330 — Vcp-like ATPase; Chain A, domain 2
Homologous superfamily homologous superfamily	10 —

Domain ID domain_id	1s3sF04
Class class	1 — Mainly Alpha
Architecture architecture	10 — Orthogonal Bundle
Topology topology	8 — Helicase, Ruva Protein; domain 3
Homologous superfamily homologous superfamily	60 —

Domain ID domain_id	1s3sG00
Class class	3 — Alpha Beta
Architecture architecture	10 — Roll
Topology topology	20 — Ubiquitin-like (UB roll)
Homologous superfamily homologous superfamily	90 — Phosphatidylinositol 3-kinase Catalytic Subunit; Chain A, domain 1

Domain ID domain_id	1s3sH00
Class class	3 — Alpha Beta
Architecture architecture	10 — Roll
Topology topology	20 — Ubiquitin-like (UB roll)
Homologous superfamily homologous superfamily	90 — Phosphatidylinositol 3-kinase Catalytic Subunit; Chain A, domain 1

▶

Unit-cell length a length_a	157.719 Å
Unit-cell length b length_b	157.719 Å
Unit-cell length c length_c	243.195 Å
Unit-cell angle α angle_alpha	90.00 °
Unit-cell angle β angle_beta	90.00 °
Unit-cell angle γ angle_gamma	120.00 °
Molecules per unit cell Z z_pdb	36

Space group space_group	P 65
Space-group number int_tables_number	170
Crystal system crystal_system	—

Resolution resolution	2.900 Å
Low-resolution limit resolution_low	39.700 Å
R factor r_factor	—
R_work r_work	0.2480
R_free r_free	0.2940

Crystal structure of AAA ATPase p97/VCP ND1 in complex with p47 C

1. Protein Identity and Related Structures Protein Identity & Related Structures

;Transitional endoplasmic reticulum ATPase (TER ATPase) (15S Mg(2+)- ATPase p97 subunit) (Valosin containing protein) (VCP) [Contains: Valosin] ;

State in the Current Structure

Other States of the Same Protein in the Database

p47 protein

State in the Current Structure

Other States of the Same Protein in the Database

2. Structure Basics 2. Structure Basics

3. Official assembly/model SAXS Official SAXS Profiles

1s3s__assembly_1__model_1

1s3s__assembly_1__model_1 | I(q)

1s3s__assembly_1__model_1 | P(r) · Pending

4. Crystallography and Experiment 4. Crystallography & Experiment

Unit cell Unit Cell

Symmetry Symmetry

Refinement Refinement

Diffraction experiment Diffraction

5. Entities and Polymers Entities & Polymers (4)

Entity 1 Entity 1 polymer

Polymer Polymer

Source Source

Entity 2 Entity 2 polymer

Polymer Polymer

Source Source

Entity 3 Entity 3 non-polymer

Entity 4 Entity 4 water

6. Fold Classification (SCOP + CATH) 47 domains

SCOP 2.08 (21 domains)

CATH v4.4 (26 domains)

7. Citations (1)

Crystal structure of AAA ATPase p97/VCP ND1 in complex with p47 C

1. Protein Identity and Related Structures Protein Identity & Related Structures

;Transitional endoplasmic reticulum ATPase (TER ATPase) (15S Mg(2+)- ATPase p97 subunit) (Valosin containing protein) (VCP) [Contains: Valosin] ;

State in the Current Structure

Other States of the Same Protein in the Database

Monomer

Homodimer

Homotetramer

Other homooligomers

Heteromeric or nucleic-acid complex

p47 protein

State in the Current Structure

Other States of the Same Protein in the Database

Monomer

Homodimer

Homotetramer

Other homooligomers

Heteromeric or nucleic-acid complex

2. Structure Basics 2. Structure Basics

3. Official assembly/model SAXS Official SAXS Profiles

1s3s__assembly_1__model_1

1s3s__assembly_1__model_1 | I(q)

1s3s__assembly_1__model_1 | P(r) · Pending

4. Crystallography and Experiment 4. Crystallography & Experiment

Unit cell Unit Cell

Symmetry Symmetry

Refinement Refinement

Diffraction experiment Diffraction

5. Entities and Polymers Entities & Polymers (4)

Entity 1 Entity 1 polymer

Polymer Polymer

Source Source

Entity 2 Entity 2 polymer

Polymer Polymer

Source Source

Entity 3 Entity 3 non-polymer

Entity 4 Entity 4 water

6. Fold Classification (SCOP + CATH) 47 domains

SCOP 2.08 (21 domains)

CATH v4.4 (26 domains)

7. Citations (1)
