SUBTILISIN CARLSBERG
Bacillus subtilis
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain A； UniProt 106–379 | Not recorded | CA CALCIUM ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed experimental conditions | Resolution 2.50 Å |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 1SBC | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 1AF4 CRYSTAL STRUCTURE OF SUBTILISIN CARLSBERG IN ANHYDROUS DIOXANE Deposited 1997-03-21 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
|
Not recorded | CA CALCIUM ION × 1 DIO 1,4-DIETHYLENE DIOXIDE × 7 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.6；PROTEIN WAS CRYSTALLIZED FROM 13% SODIUM SULFATE, 30 MM CACODYLATE, PH 5.6; THEN CROSS-LINKED WITH 10% GLUTARALDEHYDE IN 13% SODIUM SULFATE, 30 MM CACODYLATE, PH 7.5, WASHED WITH DISTILLED WATER, AND TRANSFERRED TO ANHYDROUS DIOXANE.
|
Resolution 2.60 Å R-free 0.248 |
| 1AV7 SUBTILISIN CARLSBERG L-NAPHTHYL-1-ACETAMIDO BORONIC ACID INHIBITOR COMPLEX Deposited 1997-09-29 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | NA SODIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7；AS GIVEN IN REFERENCE 4, pH 7.0
|
Resolution 2.60 Å R-free 0.273 |
| 1AVT SUBTILISIN CARLSBERG D-PARA-CHLOROPHENYL-1-ACETAMIDO BORONIC ACID INHIBITOR COMPLEX Deposited 1997-09-19 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
Fragment：FULL PROTEIN
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | NA SODIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7；AS GIVEN IN REFERENCE 4, pH 7.0
|
Resolution 2.00 Å R-free 0.226 |
| 1BE6 TRANS-CINNAMOYL-SUBTILISIN IN ANHYDROUS ACETONITRILE Deposited 1998-05-20 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
|
Not recorded | CA CALCIUM ION × 1 TCA PHENYLETHYLENECARBOXYLIC ACID × 1 CCN ACETONITRILE × 12 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；PROTEIN WAS CRYSTALLIZED FROM 13% SODIUM SULFATE, 30 MM CACODYLATE, PH 5.6; THEN CROSS-LINKED WITH 10% GLUTARALDEHYDE IN 13% SODIUM SULFATE, 30 MM CACODYLATE, PH 7.5, WASHED WITH DISTILLED WATER, AND TRANSFERRED TO ANHYDROUS ACETONITRILE N-TRANS-CINNAMOYL IMIDAZOLE WAS THEN ADDED
|
Resolution 2.15 Å R-free 0.234 |
| 1BE8 TRANS-CINNAMOYL-SUBTILISIN IN WATER Deposited 1998-05-20 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
|
Not recorded | CA CALCIUM ION × 1 TCA PHENYLETHYLENECARBOXYLIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 3；PROTEIN WAS CRYSTALLIZED FROM 13% SODIUM SULFATE, 30 MM CACODYLATE, PH 5.6; THEN CROSS-LINKED WITH 10% GLUTARALDEHYDE IN 13% SODIUM SULFATE, 30 MM CACODYLATE, PH 7.5, WASHED WITH DISTILLED WATER, AND TRANSFERRED TO WATER AND N-TRANS-CINNAMOYL IMIDAZOLE WAS ADDED., pH 3.0
|
Resolution 2.20 Å R-free 0.223 |
| 1BFK CRYSTAL STRUCTURE OF SUBTILISIN CARLSBERG IN 40% ACETONITRILE Deposited 1998-05-21 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
|
Not recorded | CA CALCIUM ION × 1 CCN ACETONITRILE × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.6；PROTEIN WAS CRYSTALLIZED FROM 13% SODIUM SULFATE, 30 MM CACODYLATE, PH 5.6; THEN CROSS-LINKED WITH 10% GLUTARALDEHYDE IN 13% SODIUM SULFATE, 30 MM CACODYLATE, PH 7.5, WASHED WITH DISTILLED WATER, AND TRANSFERRED TO AN AQUEOUS SYSTEM CONTAINING 40% ACETONITRILE.
|
Resolution 2.30 Å R-free 0.247 |
| 1BFU SUBTILISIN CARLSBERG IN 20% DIOXANE Deposited 1998-05-22 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
|
Not recorded | CA CALCIUM ION × 1 DIO 1,4-DIETHYLENE DIOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.6；PROTEIN WAS CRYSTALLIZED FROM 13% SODIUM SULFATE, 30 MM CACODYLATE, PH 5.6; THEN CROSS-LINKED WITH 10% GLUTARALDEHYDE IN 13% SODIUM SULFATE, 30 MM CACODYLATE, PH 7.5, WASHED WITH DISTILLED WATER, AND TRANSFERRED TO 20% DIOXANE.
|
Resolution 2.20 Å R-free 0.245 |
| 1C3L SUBTILISIN-CARLSBERG COMPLEXED WITH XENON (8 BAR) Deposited 1999-07-28 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
|
Not recorded | CA CALCIUM ION × 2 XE XENON × 1 FMT FORMIC ACID × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
MICRODIALYSIS；pH 5.5；298 K；protein: 15mg/ml in acetate buffer (0.05M) plus
sodium azide (10-5M). Sodium formate as the
crystallizing agent(4M). Crystals as elongated needles
in two weeks., pH 5.50, MICRODIALYSIS, temperature 298K
|
Resolution 2.16 Å R-free 0.198 |
| 1CSE THE HIGH-RESOLUTION X-RAY CRYSTAL STRUCTURE OF THE COMPLEX FORMED BETWEEN SUBTILISIN CARLSBERG AND EGLIN C, AN ELASTASE INHIBITOR FROM THE LEECH HIRUDO MEDICINALIS. STRUCTURAL ANALYSIS, SUBTILISIN STRUCTURE AND INTERFACE GEOMETRY Deposited 1988-06-03 | Different oligomeric state Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain E
106–379（274 aa）
|
Not recorded | CA CALCIUM ION × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.20 Å |
| 1OYV Crystal structure of tomato inhibitor-II in a ternary complex with subtilisin Carlsberg Deposited 2003-04-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
106–379（274 aa）
Chain B
106–379（274 aa）
|
Not recorded | CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；298 K；PEG 8000, sodium malonate, sodium citrate, ethylene glycol, ethanol, pH 6.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.50 Å R-free 0.270 |
| 1R0R 1.1 Angstrom Resolution Structure of the Complex Between the Protein Inhibitor, OMTKY3, and the Serine Protease, Subtilisin Carlsberg Deposited 2003-09-22 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain E
2–275（274 aa）
|
Not recorded | CA CALCIUM ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；293 K；0.2 M ammonium dihydrogen phosphate, 0.1 M Tris, and 50%(v/v) 2-methyl-2,4-pentanediol (MPD), pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.10 Å R-free 0.184 |
| 1SCA ENZYME CRYSTAL STRUCTURE IN A NEAT ORGANIC SOLVENT Deposited 1993-07-19 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
|
Not recorded | CA CALCIUM ION × 2 NA SODIUM ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å |
| 1SCB ENZYME CRYSTAL STRUCTURE IN A NEAT ORGANIC SOLVENT Deposited 1993-07-13 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
|
Not recorded | CA CALCIUM ION × 1 CCN ACETONITRILE × 12 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1SCD X-RAY CRYSTAL STRUCTURE OF CROSS-LINKED SUBTILISM CARLSBERG IN WATER VS. ACETONITRILE Deposited 1993-08-23 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
|
Not recorded | CA CALCIUM ION × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1SCN INACTIVATION OF SUBTILISIN CARLSBERG BY N-(TERT-BUTOXYCARBONYL-ALANYL-PROLYL-PHENYLALANYL)-O-BENZOL HYDROXYLAMINE: FORMATION OF COVALENT ENZYME-INHIBITOR LINKAGE IN THE FORM OF A CARBAMATE DERIVATIVE Deposited 1994-03-02 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain E
106–379（274 aa）
|
Not recorded | 0EF N-(tert-butoxycarbonyl)-L-alanyl-N-[(1R)-1-(carboxyamino)-2-phenylethyl]-L-prolinamide × 1 CA CALCIUM ION × 2 NA SODIUM ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.90 Å |
| 1SEL CRYSTAL STRUCTURE OF SELENOSUBTILISIN AT 2.0-ANGSTROMS RESOLUTION Deposited 1993-01-17 | Different mutation/modification Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CA CALCIUM ION × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å |
| 1SEL CRYSTAL STRUCTURE OF SELENOSUBTILISIN AT 2.0-ANGSTROMS RESOLUTION Deposited 1993-01-17 | Different mutation/modification Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
106–379（274 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CA CALCIUM ION × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å |
| 1VSB SUBTILISIN CARLSBERG L-PARA-CHLOROPHENYL-1-ACETAMIDO BORONIC ACID INHIBITOR COMPLEX Deposited 1997-09-17 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7；AS GIVEN IN REFERENCE 4, pH 7.0
|
Resolution 2.10 Å R-free 0.242 |
| 1YU6 Crystal Structure of the Subtilisin Carlsberg:OMTKY3 Complex Deposited 2005-02-11 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–275（275 aa）
|
Not recorded | CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.1；298 K；10% ethylene glycol, 480 mM sodium malate, 75 mM sodium citrate, pH 6.1, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.55 Å R-free 0.205 |
| 1YU6 Crystal Structure of the Subtilisin Carlsberg:OMTKY3 Complex Deposited 2005-02-11 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
1–275（275 aa）
|
Not recorded | CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.1；298 K；10% ethylene glycol, 480 mM sodium malate, 75 mM sodium citrate, pH 6.1, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.55 Å R-free 0.205 |
| 2SEC STRUCTURAL COMPARISON OF TWO SERINE PROTEINASE-PROTEIN INHIBITOR COMPLEXES. EGLIN-C-SUBTILISIN CARLSBERG AND CI-2-SUBTILISIN NOVO Deposited 1988-09-05 | Different oligomeric state Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain E
106–379（274 aa）
|
Not recorded | CA CALCIUM ION × 3 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.80 Å |
| 2WUV Crystallographic analysis of counter-ion effects on subtilisin enzymatic action in acetonitrile Deposited 2009-10-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–160（55 aa）
Fragment：RESIDUES 106-379
Chain A
161–379（219 aa）
Fragment：RESIDUES 106-379
|
Not recorded | CL CHLORIDE ION × 8 CS CESIUM ION × 11 CA CALCIUM ION × 1 NA SODIUM ION × 1 CCN ACETONITRILE × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
SUBTILISIN WAS CRYSTALLIZED BY THE BATCH METHOD FROM BUFFER SOLUTION SATURATED WITH NA2SO4 ABOUT 13% (W/V) AS PRECIPITANT (32 PETSKO AND TSERNOGLOU 1976)
|
Resolution 2.24 Å R-free 0.231 |
| 2WUW Crystallographic analysis of counter-ion effects on subtilisin enzymatic action in acetonitrile (native data) Deposited 2009-10-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain E
106–160（55 aa）
Fragment：RESIDUES 106-379
Chain E
161–379（219 aa）
Fragment：RESIDUES 106-379
|
Not recorded | SO4 SULFATE ION × 1 NA SODIUM ION × 2 CA CALCIUM ION × 1 CCN ACETONITRILE × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
SUBTILISIN WAS CRYSTALLIZED BY THE BATCH METHOD FROM BUFFER SOLUTION SATURATED WITH NA2SO4 ABOUT 13% (W/V) AS PRECIPITANT (PETSKO AND TSERNOGLOU 1976).
|
Resolution 2.23 Å R-free 0.249 |
| 3UNX Bond length analysis of asp, glu and his residues in subtilisin Carlsberg at 1.26A resolution Deposited 2011-11-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
Fragment：mature form (UNP residues 106-379)
|
Not recorded | GOL GLYCEROL × 4 CA CALCIUM ION × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH；pH 7.5；298 K；13% w/v sodium sulfate, pH 7.5, BATCH, temperature 298K
|
Resolution 1.26 Å R-free 0.139 |
| 3VSB SUBTILISIN CARLSBERG D-NAPHTHYL-1-ACETAMIDO BORONIC ACID INHIBITOR COMPLEX Deposited 1997-09-25 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
Fragment：FULL PROTEIN
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | NA SODIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7；AS GIVEN IN REFERENCE 4, pH 7.0
|
Resolution 2.60 Å R-free 0.299 |
| 4C3U Extensive counter-ion interactions with subtilisin in aqueous medium, Cs derivative Deposited 2013-08-27 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
|
Not recorded | CL CHLORIDE ION × 6 CS CESIUM ION × 10 CA CALCIUM ION × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
SUBTILISIN CARLSBERG WAS PURCHASED FROM SIGMA (PRODUCT CODE: P5380) AND USED FOR CRYSTALLIZATION WITHOUT FURTHER PURIFICATION. THE PROTEIN POWDER WAS DISSOLVED IN 330 MM NA CACODYLATE BUFFER AT PH 5.6 TO A CONCENTRATION OF 10 MG/ML. SUBTILISIN WAS CRYSTALLIZED BY THE BATCH METHOD FROM BUFFER SOLUTION SATURATED WITH NA2SO4 13% (W/V) AS PRECIPITANT1. LONG NEEDLE-LIKE CRYSTALS GREW OVER A PERIOD OF TWO WEEKS TO TYPICAL DIMENSIONS 50 X 50 X 400 UM X UM X UM
|
Resolution 2.29 Å R-free 0.234 |
| 4C3V Extensive counter-ion interactions with subtilisin in aqueous medium, no Cs soak Deposited 2013-08-27 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
106–379（274 aa）
|
Not recorded | SO4 SULFATE ION × 3 NA SODIUM ION × 3 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
SUBTILISIN CARLSBERG WAS PURCHASED FROM SIGMA (PRODUCT CODE: P5380) AND USED FOR CRYSTALLIZATION WITHOUT FURTHER PURIFICATION. THE PROTEIN POWDER WAS DISSOLVED IN 330 MM NA CACODYLATE BUFFER AT PH 5.6 TO A CONCENTRATION OF 10 MG/ML. SUBTILISIN WAS CRYSTALLIZED BY THE BATCH METHOD FROM BUFFER SOLUTION SATURATED WITH NA2SO4 13% (W/V) AS PRECIPITANT1. LONG NEEDLE-LIKE CRYSTALS GREW OVER A PERIOD OF TWO WEEKS TO TYPICAL DIMENSIONS 50 X 50 X 400 UM X UM X UM.
|
Resolution 2.26 Å R-free 0.226 |
25 other PDB entries and 27 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | SUBT_BACLI |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 1–274； UniProt 106–379 |
