1wmg

Crystal structure of the UNC5H2 death domain

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

netrin receptor Unc5h2

Mus musculus

UniProt Q8K1S3

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein homooligomer Homooligomer Protein 6 SULFITE ION × 7 SULFATE ION × 3 water × 6 Consistent with protein count

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers
1wmg

1 assemblies

Heteromeric or nucleic-acid complex
6ool

1 assemblies

View Construct and Data Evidence
UniProt name UNC5B_MOUSE
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 8–97； UniProt 854–943 Author chain B； PDBConstruct 8–97； UniProt 854–943 Author chain C； PDBConstruct 8–97； UniProt 854–943 Author chain D； PDBConstruct 8–97； UniProt 854–943 Author chain E； PDBConstruct 8–97； UniProt 854–943 Author chain F； PDBConstruct 8–97； UniProt 854–943

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id1wmg
Deposition date deposition_date2004-07-09
Structure title titleCrystal structure of the UNC5H2 death domain
Keywords keywords;six helix bundle, death domain, apoptosis, Structural Genomics, NPPSFA, National Project on Protein Structural and Functional Analyses, RIKEN Structural Genomics/Proteomics Initiative, RSGI ;; APOPTOSIS
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1wmg__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1wmg__assembly_1__model_1 | I(q)

10-2 10-1 105 106 107 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

1wmg__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）43.98 Å
Rg (electron density)45.33 Å
Total Rg45.00 Å
Atom count4113
Residues498
Excluded volume73445 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 1wmg__assembly_1__model_1 hexameric （6） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (4)

▼

6. Fold Classification (SCOP + CATH) 12 domains

SCOP 2.08 (6 domains)

Domain ID domain_idd1wmga_
Class classa — All alpha proteins
Fold Fold folda.77 — DEATH domain
Superfamily Superfamily superfamilya.77.1 — DEATH domain
Family Family familya.77.1.2 — DEATH domain, DD
Domain ID domain_idd1wmgb_
Class classa — All alpha proteins
Fold Fold folda.77 — DEATH domain
Superfamily Superfamily superfamilya.77.1 — DEATH domain
Family Family familya.77.1.2 — DEATH domain, DD
Domain ID domain_idd1wmgc_
Class classa — All alpha proteins
Fold Fold folda.77 — DEATH domain
Superfamily Superfamily superfamilya.77.1 — DEATH domain
Family Family familya.77.1.2 — DEATH domain, DD
Domain ID domain_idd1wmgd_
Class classa — All alpha proteins
Fold Fold folda.77 — DEATH domain
Superfamily Superfamily superfamilya.77.1 — DEATH domain
Family Family familya.77.1.2 — DEATH domain, DD
Domain ID domain_idd1wmge_
Class classa — All alpha proteins
Fold Fold folda.77 — DEATH domain
Superfamily Superfamily superfamilya.77.1 — DEATH domain
Family Family familya.77.1.2 — DEATH domain, DD
Domain ID domain_idd1wmgf_
Class classa — All alpha proteins
Fold Fold folda.77 — DEATH domain
Superfamily Superfamily superfamilya.77.1 — DEATH domain
Family Family familya.77.1.2 — DEATH domain, DD

CATH v4.4 (6 domains)

Domain ID domain_id1wmgA00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology533 — Death Domain, Fas
Homologous superfamily homologous superfamily10 — Death Domain, Fas
Domain ID domain_id1wmgB00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology533 — Death Domain, Fas
Homologous superfamily homologous superfamily10 — Death Domain, Fas
Domain ID domain_id1wmgC00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology533 — Death Domain, Fas
Homologous superfamily homologous superfamily10 — Death Domain, Fas
Domain ID domain_id1wmgD00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology533 — Death Domain, Fas
Homologous superfamily homologous superfamily10 — Death Domain, Fas
Domain ID domain_id1wmgE00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology533 — Death Domain, Fas
Homologous superfamily homologous superfamily10 — Death Domain, Fas
Domain ID domain_id1wmgF00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology533 — Death Domain, Fas
Homologous superfamily homologous superfamily10 — Death Domain, Fas
▶

7. Citations (1)
