1wva

Crystal structure of human arginase I from twinned crystal

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Arginase 1

Homo sapiens

UniProt P05089

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein homooligomer Homooligomer Protein 3 MANGANESE (II) ION × 6 S-2-(BORONOETHYL)-L-CYSTEINE × 3 water × 3 Consistent with protein count
2 Protein homooligomer Homooligomer Protein 3 MANGANESE (II) ION × 6 S-2-(BORONOETHYL)-L-CYSTEINE × 3 water × 3 Consistent with protein count

Other States of the Same Protein in the Database

Monomer
2pha 2pho 2pll 3e6k 3e6k

5 assemblies

Homodimer

None

Homotetramer

None

Other homooligomers
1wva 1wva 1wvb 1wvb 2aeb 2aeb 2pha 2pha 2pho 2pho 2pll 2pll

106 assemblies; showing the first 12

Heteromeric or nucleic-acid complex
7lex 7ley 7lez 7lf0 7lf1 7lf2

6 assemblies

View Construct and Data Evidence
UniProt name ARGI1_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 1–322； UniProt 1–322 Author chain B； PDBConstruct 1–322； UniProt 1–322

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id1wva
Deposition date deposition_date2004-12-14
Structure title titleCrystal structure of human arginase I from twinned crystal
Keywords keywordsHydrolase, twinned crystal, BEC inhibitor; HYDROLASE
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1wva__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1wva__assembly_1__model_1 | I(q)

10-2 10-1 106 107 108 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

1wva__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）30.59 Å
Rg (electron density)29.86 Å
Total Rg30.45 Å
Atom count7077
Residues927
Excluded volume127110 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 1wva__assembly_1__model_1 trimeric （3） Success 4.1.3-1-20251215 (887e7ef) View Download
2 1 1wva__assembly_2__model_1 trimeric （3） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (4)

▼

6. Fold Classification (SCOP + CATH) 4 domains

SCOP 2.08 (2 domains)

Domain ID domain_idd1wvaa1
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.42 — Arginase/deacetylase
Superfamily Superfamily superfamilyc.42.1 — Arginase/deacetylase
Family Family familyc.42.1.1 — Arginase-like amidino hydrolases
Domain ID domain_idd1wvab_
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.42 — Arginase/deacetylase
Superfamily Superfamily superfamilyc.42.1 — Arginase/deacetylase
Family Family familyc.42.1.1 — Arginase-like amidino hydrolases

CATH v4.4 (2 domains)

Domain ID domain_id1wvaA00
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology800 — Arginase; Chain A
Homologous superfamily homologous superfamily10 — Ureohydrolase domain
Domain ID domain_id1wvaB00
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology800 — Arginase; Chain A
Homologous superfamily homologous superfamily10 — Ureohydrolase domain
▶

7. Citations (2)
