1ztq

Crystal structure of the catalytic domain of MMP-13 complexed with WAY-033

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Collagenase 3

Homo sapiens

UniProt P45452

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein monomer Monomer Protein 1 ZINC ION × 2 CALCIUM ION × 3 N-({4'-[(1-BENZOFURAN-2-YLCARBONYL)AMINO]-1,1'-BIPHENYL-4-YL}SULFONYL)-L-VALINE × 1 water × 1 Consistent with protein count
2 Protein monomer Monomer Protein 1 ZINC ION × 2 CALCIUM ION × 3 N-({4'-[(1-BENZOFURAN-2-YLCARBONYL)AMINO]-1,1'-BIPHENYL-4-YL}SULFONYL)-L-VALINE × 1 water × 1 Consistent with protein count
3 Protein monomer Monomer Protein 1 ZINC ION × 2 CALCIUM ION × 3 N-({4'-[(1-BENZOFURAN-2-YLCARBONYL)AMINO]-1,1'-BIPHENYL-4-YL}SULFONYL)-L-VALINE × 1 water × 1 Consistent with protein count
4 Protein monomer Monomer Protein 1 ZINC ION × 2 CALCIUM ION × 3 N-({4'-[(1-BENZOFURAN-2-YLCARBONYL)AMINO]-1,1'-BIPHENYL-4-YL}SULFONYL)-L-VALINE × 1 water × 1 Consistent with protein count

Other States of the Same Protein in the Database

Monomer
1eub 1fls 1fm1 1pex 1xuc 1xuc 1xud 1xud 1you 1you 1ztq 1ztq

66 assemblies; showing the first 12

Homodimer
1xur 2yig 3elm 3i7g 3i7i 3o2x 3o2x 3wv1 3wv2 3wv3 3zxh 456c

26 assemblies; showing the first 12

Homotetramer
1xur 1you 2ow9 3elm 3i7g 3i7i 3kry 3o2x 3zxh 4a7b 4l19

11 assemblies

Other homooligomers
2ozr

1 assemblies

Heteromeric or nucleic-acid complex
2e2d 5uwm 5uwm

3 assemblies

View Construct and Data Evidence
UniProt name MMP13_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 1–165； UniProt 104–268 Author chain B； PDBConstruct 1–165； UniProt 104–268 Author chain C； PDBConstruct 1–165； UniProt 104–268 Author chain D； PDBConstruct 1–165； UniProt 104–268

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id1ztq
Deposition date deposition_date2005-05-27
Structure title titleCrystal structure of the catalytic domain of MMP-13 complexed with WAY-033
Keywords keywords;MMPs, METALLOPROTEASE, HYDROLASE, MMP-13, COLLAGENASE, ZINC CHELATOR, hydroxamate, hydrophobic S1', P1' group ;; HYDROLASE
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1ztq__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1ztq__assembly_1__model_1 | I(q)

10-2 10-1 105 106 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

1ztq__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）15.86 Å
Rg (electron density)14.68 Å
Total Rg15.92 Å
Atom count1333
Residues162
Excluded volume23604 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 1ztq__assembly_1__model_1 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
2 1 1ztq__assembly_2__model_1 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
3 1 1ztq__assembly_3__model_1 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
4 1 1ztq__assembly_4__model_1 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (5)

▼

6. Fold Classification (SCOP + CATH) 8 domains

SCOP 2.08 (4 domains)

Domain ID domain_idd1ztqa_
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.92 — Zincin-like
Superfamily Superfamily superfamilyd.92.1 — Metalloproteases ('zincins'), catalytic domain
Family Family familyd.92.1.11 — Matrix metalloproteases, catalytic domain
Domain ID domain_idd1ztqb_
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.92 — Zincin-like
Superfamily Superfamily superfamilyd.92.1 — Metalloproteases ('zincins'), catalytic domain
Family Family familyd.92.1.11 — Matrix metalloproteases, catalytic domain
Domain ID domain_idd1ztqc_
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.92 — Zincin-like
Superfamily Superfamily superfamilyd.92.1 — Metalloproteases ('zincins'), catalytic domain
Family Family familyd.92.1.11 — Matrix metalloproteases, catalytic domain
Domain ID domain_idd1ztqd_
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.92 — Zincin-like
Superfamily Superfamily superfamilyd.92.1 — Metalloproteases ('zincins'), catalytic domain
Family Family familyd.92.1.11 — Matrix metalloproteases, catalytic domain

CATH v4.4 (4 domains)

Domain ID domain_id1ztqA00
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology390 — Collagenase (Catalytic Domain)
Homologous superfamily homologous superfamily10 — Collagenase (Catalytic Domain)
Domain ID domain_id1ztqB00
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology390 — Collagenase (Catalytic Domain)
Homologous superfamily homologous superfamily10 — Collagenase (Catalytic Domain)
Domain ID domain_id1ztqC00
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology390 — Collagenase (Catalytic Domain)
Homologous superfamily homologous superfamily10 — Collagenase (Catalytic Domain)
Domain ID domain_id1ztqD00
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology390 — Collagenase (Catalytic Domain)
Homologous superfamily homologous superfamily10 — Collagenase (Catalytic Domain)
▶

7. Citations (1)
