2ezv

Crystal structure of tetrameric restriction endonuclease SfiI bound to cognate DNA.

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Type II restriction enzyme SfiI

OrganismNot specified

UniProt O52512

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein–DNA Homooligomer Protein 4 DNA 4 5'-D(*TP*GP*GP*CP*CP*AP*AP*CP*AP*AP*GP*GP*CP*CP*T)-3' × 2 5'-D(*AP*GP*GP*CP*CP*TP*TP*GP*TP*TP*GP*GP*CP*CP*A)-3' × 2 CALCIUM ION × 4 water × 8 Consistent with all polymers

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
2ezv 2f03

2 assemblies

View Construct and Data Evidence
UniProt name T2S1_STRFI
Isoform —
PDB entities 3
Chains and sequence ranges Author chain A； PDBConstruct 1–269； UniProt 1–269 Author chain B； PDBConstruct 1–269； UniProt 1–269

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id2ezv
Deposition date deposition_date2005-11-10
Structure title titleCrystal structure of tetrameric restriction endonuclease SfiI bound to cognate DNA.
Keywords keywordsType IIF restriction endonuclease, protein-DNA complex, HYDROLASE-DNA COMPLEX; HYDROLASE/DNA
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

2ezv__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

2ezv__assembly_1__model_1 | I(q)

10-2 10-1 106 107 108 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

2ezv__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）33.90 Å
Rg (electron density)31.95 Å
Total Rg32.70 Å
Atom count9700
Residues1132
Excluded volume167860 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 2ezv__assembly_1__model_1 octameric （8） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (5)

▼

6. Fold Classification (SCOP + CATH) 4 domains

CATH v4.4 (4 domains)

Domain ID domain_id2ezvA01
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology600 — ECO RV Endonuclease; Chain A
Homologous superfamily homologous superfamily40 — Type II restriction enzyme SfiI, multifunctional domain
Domain ID domain_id2ezvA02
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology50 — OB fold (Dihydrolipoamide Acetyltransferase, E2P)
Homologous superfamily homologous superfamily610 — Type II restriction enzyme SfiI, DNA-recognition domain
Domain ID domain_id2ezvB01
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology600 — ECO RV Endonuclease; Chain A
Homologous superfamily homologous superfamily40 — Type II restriction enzyme SfiI, multifunctional domain
Domain ID domain_id2ezvB02
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology50 — OB fold (Dihydrolipoamide Acetyltransferase, E2P)
Homologous superfamily homologous superfamily610 — Type II restriction enzyme SfiI, DNA-recognition domain
▶

7. Citations (2)
