2f3m

Structure of human GLUTATHIONE S-TRANSFERASE M1A-1A complexed with 1-(S-(GLUTATHIONYL)-2,4,6-TRINITROCYCLOHEXADIENATE ANION

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Glutathione S-transferase Mu 1

Homo sapiens

UniProt P09488

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein homooligomer Homooligomer Protein 2 1-(S-GLUTATHIONYL)-2,4,6-TRINITROCYCLOHEXA-2,5-DIENE × 2 water × 2 Consistent with protein count
2 Protein homooligomer Homooligomer Protein 2 1-(S-GLUTATHIONYL)-2,4,6-TRINITROCYCLOHEXA-2,5-DIENE × 2 water × 2 Consistent with protein count
3 Protein homooligomer Homooligomer Protein 2 1-(S-GLUTATHIONYL)-2,4,6-TRINITROCYCLOHEXA-2,5-DIENE × 2 water × 2 Consistent with protein count

Other States of the Same Protein in the Database

Monomer

None

Homodimer
1gtu 1gtu 1xw6 1xw6 1xwk 1xwk 1yj6 1yj6 2f3m 2f3m 2f3m 7beu

15 assemblies; showing the first 12

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex

None

View Construct and Data Evidence
UniProt name GSTM1_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 1–218； UniProt 1–217 Author chain B； PDBConstruct 1–218； UniProt 1–217 Author chain C； PDBConstruct 1–218； UniProt 1–217 Author chain D； PDBConstruct 1–218； UniProt 1–217 Author chain E； PDBConstruct 1–218； UniProt 1–217 Author chain F； PDBConstruct 1–218； UniProt 1–217

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id2f3m
Deposition date deposition_date2005-11-21
Structure title titleStructure of human GLUTATHIONE S-TRANSFERASE M1A-1A complexed with 1-(S-(GLUTATHIONYL)-2,4,6-TRINITROCYCLOHEXADIENATE ANION
Keywords keywordsTRANSFERASE, GLUTATHIONE, CONJUGATION, DETOXIFICATION, CYTOSOLIC, DIMER, ACTIVE SITE, TRANSITION STATE ANALOGUE; TRANSFERASE
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

2f3m__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

2f3m__assembly_1__model_1 | I(q)

10-2 10-1 105 106 107 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

2f3m__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）22.48 Å
Rg (electron density)21.46 Å
Total Rg22.38 Å
Atom count3694
Residues436
Excluded volume66286 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 2f3m__assembly_1__model_1 dimeric （2） Success 4.1.3-1-20251215 (887e7ef) View Download
2 1 2f3m__assembly_2__model_1 dimeric （2） Success 4.1.3-1-20251215 (887e7ef) View Download
3 1 2f3m__assembly_3__model_1 dimeric （2） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (3)

▼

6. Fold Classification (SCOP + CATH) 24 domains

SCOP 2.08 (12 domains)

Domain ID domain_idd2f3ma1
Class classa — All alpha proteins
Fold Fold folda.45 — GST C-terminal domain-like
Superfamily Superfamily superfamilya.45.1 — GST C-terminal domain-like
Family Family familya.45.1.1 — Glutathione S-transferase (GST), C-terminal domain
Domain ID domain_idd2f3ma2
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.47 — Thioredoxin fold
Superfamily Superfamily superfamilyc.47.1 — Thioredoxin-like
Family Family familyc.47.1.5 — Glutathione S-transferase (GST), N-terminal domain
Domain ID domain_idd2f3mb1
Class classa — All alpha proteins
Fold Fold folda.45 — GST C-terminal domain-like
Superfamily Superfamily superfamilya.45.1 — GST C-terminal domain-like
Family Family familya.45.1.1 — Glutathione S-transferase (GST), C-terminal domain
Domain ID domain_idd2f3mb2
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.47 — Thioredoxin fold
Superfamily Superfamily superfamilyc.47.1 — Thioredoxin-like
Family Family familyc.47.1.5 — Glutathione S-transferase (GST), N-terminal domain
Domain ID domain_idd2f3mc1
Class classa — All alpha proteins
Fold Fold folda.45 — GST C-terminal domain-like
Superfamily Superfamily superfamilya.45.1 — GST C-terminal domain-like
Family Family familya.45.1.1 — Glutathione S-transferase (GST), C-terminal domain
Domain ID domain_idd2f3mc2
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.47 — Thioredoxin fold
Superfamily Superfamily superfamilyc.47.1 — Thioredoxin-like
Family Family familyc.47.1.5 — Glutathione S-transferase (GST), N-terminal domain
Domain ID domain_idd2f3md1
Class classa — All alpha proteins
Fold Fold folda.45 — GST C-terminal domain-like
Superfamily Superfamily superfamilya.45.1 — GST C-terminal domain-like
Family Family familya.45.1.1 — Glutathione S-transferase (GST), C-terminal domain
Domain ID domain_idd2f3md2
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.47 — Thioredoxin fold
Superfamily Superfamily superfamilyc.47.1 — Thioredoxin-like
Family Family familyc.47.1.5 — Glutathione S-transferase (GST), N-terminal domain
Domain ID domain_idd2f3me1
Class classa — All alpha proteins
Fold Fold folda.45 — GST C-terminal domain-like
Superfamily Superfamily superfamilya.45.1 — GST C-terminal domain-like
Family Family familya.45.1.1 — Glutathione S-transferase (GST), C-terminal domain
Domain ID domain_idd2f3me2
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.47 — Thioredoxin fold
Superfamily Superfamily superfamilyc.47.1 — Thioredoxin-like
Family Family familyc.47.1.5 — Glutathione S-transferase (GST), N-terminal domain
Domain ID domain_idd2f3mf1
Class classa — All alpha proteins
Fold Fold folda.45 — GST C-terminal domain-like
Superfamily Superfamily superfamilya.45.1 — GST C-terminal domain-like
Family Family familya.45.1.1 — Glutathione S-transferase (GST), C-terminal domain
Domain ID domain_idd2f3mf2
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.47 — Thioredoxin fold
Superfamily Superfamily superfamilyc.47.1 — Thioredoxin-like
Family Family familyc.47.1.5 — Glutathione S-transferase (GST), N-terminal domain

CATH v4.4 (12 domains)

Domain ID domain_id2f3mA01
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology30 — Glutaredoxin
Homologous superfamily homologous superfamily10 — Glutaredoxin
Domain ID domain_id2f3mA02
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology1050 — Glutathione S-transferase Yfyf (Class Pi); Chain A, domain 2
Homologous superfamily homologous superfamily10 —
Domain ID domain_id2f3mB01
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology30 — Glutaredoxin
Homologous superfamily homologous superfamily10 — Glutaredoxin
Domain ID domain_id2f3mB02
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology1050 — Glutathione S-transferase Yfyf (Class Pi); Chain A, domain 2
Homologous superfamily homologous superfamily10 —
Domain ID domain_id2f3mC01
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology30 — Glutaredoxin
Homologous superfamily homologous superfamily10 — Glutaredoxin
Domain ID domain_id2f3mC02
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology1050 — Glutathione S-transferase Yfyf (Class Pi); Chain A, domain 2
Homologous superfamily homologous superfamily10 —
Domain ID domain_id2f3mD01
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology30 — Glutaredoxin
Homologous superfamily homologous superfamily10 — Glutaredoxin
Domain ID domain_id2f3mD02
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology1050 — Glutathione S-transferase Yfyf (Class Pi); Chain A, domain 2
Homologous superfamily homologous superfamily10 —
Domain ID domain_id2f3mE01
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology30 — Glutaredoxin
Homologous superfamily homologous superfamily10 — Glutaredoxin
Domain ID domain_id2f3mE02
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology1050 — Glutathione S-transferase Yfyf (Class Pi); Chain A, domain 2
Homologous superfamily homologous superfamily10 —
Domain ID domain_id2f3mF01
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology30 — Glutaredoxin
Homologous superfamily homologous superfamily10 — Glutaredoxin
Domain ID domain_id2f3mF02
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology1050 — Glutathione S-transferase Yfyf (Class Pi); Chain A, domain 2
Homologous superfamily homologous superfamily10 —
▶

7. Citations (2)
