SAXSdb — 2sod

▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

COPPER,ZINC SUPEROXIDE DISMUTASE

Bos taurus

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein homooligomer	Homooligomer	Protein 2	COPPER (II) ION × 2 ZINC ION × 2 water × 2	Consistent with protein count
2	Protein homooligomer	Homooligomer	Protein 2	COPPER (II) ION × 2 ZINC ION × 2 water × 2	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	SODC_BOVIN
Isoform	—
PDB entities	1
Chains and sequence ranges	Author chain B； PDBConstruct 2–152； UniProt 1–151 Author chain G； PDBConstruct 2–152； UniProt 1–151 Author chain O； PDBConstruct 2–152； UniProt 1–151 Author chain Y； PDBConstruct 2–152； UniProt 1–151

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id	2sod
Deposition date deposition_date	1980-03-25
Structure title title	DETERMINATION AND ANALYSIS OF THE 2 ANGSTROM STRUCTURE OF COPPER, ZINC SUPEROXIDE DISMUTASE
Keywords keywords	OXIDOREDUCTASE (SUPEROXIDE ACCEPTOR); OXIDOREDUCTASE (SUPEROXIDE ACCEPTOR)
Experimental Method method	X-RAY DIFFRACTION

▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

2sod__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

2sod__assembly_1__model_1 | I(q)

100 plotted points; both axes use logarithmic scales.

2sod__assembly_1__model_1 | P(r) · Pending

P(r) will be calculated and displayed separately for the same assembly/model.

Rg（Guinier）	20.92 Å
Rg (electron density)	20.01 Å
Total Rg	20.74 Å
Atom count	2194
Residues	302
Excluded volume	38476 Å³
Maximum q	0.500 Å⁻¹

Assembly	Model	Structure unit	Oligomeric description	Status	CRYSOL	Actions
1	1	`2sod__assembly_1__model_1`	dimeric （2）	Success	4.1.3-1-20251215 (887e7ef)	View Download
2	1	`2sod__assembly_2__model_1`	dimeric （2）	Success	4.1.3-1-20251215 (887e7ef)	View Download

▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (4)

Entity 1 Entity 1 polymer

Description description	COPPER,ZINC SUPEROXIDE DISMUTASE
Molecular weight formula_weight	15599.4 kDa
EC 编号 ec_number	1.15.1.1
Source method src_method	man
Copy count entity_count	4

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	O,Y,B,G
Atom count atom_count	4392

XATKAVCVLKGDGPVQGTIHFEAKGDTVVVTGSITGLTEGDHGFHVHQFGDNTQGCTSAGPHFNPLSKKHGGPKDEERHVGDLGNVTADKNGVAIVDIVDPLISLSGEYSIIGRTMVVHEKPDDLGRGGNEESTKTGNAGSRLACGVIGIAK

Source Source

Source organism organism	Bos taurus
Common name common_name	cattle
NCBI taxonomy ID ncbi_taxonomy_id	9913

Entity 2 Entity 2 non-polymer

Description description	COPPER (II) ION
Molecular weight formula_weight	63.5 kDa
Source method src_method	syn
Copy count entity_count	4

Entity 3 Entity 3 non-polymer

Description description	ZINC ION
Molecular weight formula_weight	65.4 kDa
Source method src_method	syn
Copy count entity_count	4

Entity 4 Entity 4 water

Description description	water
Molecular weight formula_weight	18.0 kDa
Source method src_method	nat
Copy count entity_count	4

▼

6. Fold Classification (SCOP + CATH) 8 domains

SCOP 2.08 (4 domains)

Domain ID domain_id	d2sodb_
Class class	b — All beta proteins
Fold Fold fold	b.1 — Immunoglobulin-like beta-sandwich
Superfamily Superfamily superfamily	b.1.8 — Cu,Zn superoxide dismutase-like
Family Family family	b.1.8.1 — Cu,Zn superoxide dismutase-like

Domain ID domain_id	d2sodg_
Class class	b — All beta proteins
Fold Fold fold	b.1 — Immunoglobulin-like beta-sandwich
Superfamily Superfamily superfamily	b.1.8 — Cu,Zn superoxide dismutase-like
Family Family family	b.1.8.1 — Cu,Zn superoxide dismutase-like

Domain ID domain_id	d2sodo_
Class class	b — All beta proteins
Fold Fold fold	b.1 — Immunoglobulin-like beta-sandwich
Superfamily Superfamily superfamily	b.1.8 — Cu,Zn superoxide dismutase-like
Family Family family	b.1.8.1 — Cu,Zn superoxide dismutase-like

Domain ID domain_id	d2sody_
Class class	b — All beta proteins
Fold Fold fold	b.1 — Immunoglobulin-like beta-sandwich
Superfamily Superfamily superfamily	b.1.8 — Cu,Zn superoxide dismutase-like
Family Family family	b.1.8.1 — Cu,Zn superoxide dismutase-like

CATH v4.4 (4 domains)

Domain ID domain_id	2sodB00
Class class	2 — Mainly Beta
Architecture architecture	60 — Sandwich
Topology topology	40 — Immunoglobulin-like
Homologous superfamily homologous superfamily	200 — Superoxide dismutase, copper/zinc binding domain

Domain ID domain_id	2sodG00
Class class	2 — Mainly Beta
Architecture architecture	60 — Sandwich
Topology topology	40 — Immunoglobulin-like
Homologous superfamily homologous superfamily	200 — Superoxide dismutase, copper/zinc binding domain

Domain ID domain_id	2sodO00
Class class	2 — Mainly Beta
Architecture architecture	60 — Sandwich
Topology topology	40 — Immunoglobulin-like
Homologous superfamily homologous superfamily	200 — Superoxide dismutase, copper/zinc binding domain

Domain ID domain_id	2sodY00
Class class	2 — Mainly Beta
Architecture architecture	60 — Sandwich
Topology topology	40 — Immunoglobulin-like
Homologous superfamily homologous superfamily	200 — Superoxide dismutase, copper/zinc binding domain

▶

7. Citations (9)

Determination and analysis of the 2 A-structure of copper, zinc superoxide dismutase.

J.Mol.Biol. (1982)

PMID: 7175933 · DOI: 10.1016/0022-2836(82)90174-7 PRIMARY

Structure and Mechanism of Copper, Zinc Superoxide Dismutase

Nature (1983)

Electrostatic Recognition between Superoxide and Copper, Zinc Superoxide Dismutase

Nature (1983)

Metal Sites of Copper-Zinc Superoxide Dismutase

Biochemistry (1977)

Similarity of Three-Dimensional Structure between the Immunoglobulin Domain and the Copper,Zinc Superoxide Dismutase Subunit

J.Mol.Biol. (1976)

Alpha-Carbon Coordinates for Bovine Cu,Zn Superoxide Dismutase

Biochem.Biophys.Res.Commun. (1975)

Crystal Structure of Bovine Cu,Zn Superoxide Dismutase at 3 Angstroms Resolution,Chain Tracing and Metal Ligands

Proc.Natl.Acad.Sci.USA (1975)

The Crystal Structure of Bovine Cu2+,Zn2+ Superoxide Dismutase at 5.5 Angstroms Resolution

J.Biol.Chem. (1974)

Two Crystal Forms of Bovine Superoxide Dismutase

J.Biol.Chem. (1972)

Unit-cell length a length_a	93.650 Å
Unit-cell length b length_b	90.330 Å
Unit-cell length c length_c	71.650 Å
Unit-cell angle α angle_alpha	90.00 °
Unit-cell angle β angle_beta	95.10 °
Unit-cell angle γ angle_gamma	90.00 °
Molecules per unit cell Z z_pdb	16

Space group space_group	C 1 2 1
Space-group number int_tables_number	5
Crystal system crystal_system	—

Resolution resolution	2.000 Å
Low-resolution limit resolution_low	— Å
R factor r_factor	—
R_work r_work	0.2560
R_free r_free	—
