3tag

5-fluorocytosine paired with dAMP in RB69 gp43

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

DNA-directed DNA polymerase

Escherichia phage RB69

UniProt Q38087

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein–DNA Monomer Protein 1 DNA 2 ;DNA (5'-D(*CP*CP*(C37)P*GP*GP*TP*AP*TP*GP*AP*CP*AP*GP*CP*CP*GP*CP*G)-3') ; × 1 ;DNA (5'-D(*GP*CP*GP*GP*CP*TP*GP*TP*CP*AP*TP*AP*CP*CP*A)-3') ; × 1 SULFATE ION × 1 water × 3 Consistent with all polymers
2 Protein–DNA Monomer Protein 1 DNA 2 ;DNA (5'-D(*CP*CP*(C37)P*GP*GP*TP*AP*TP*GP*AP*CP*AP*GP*CP*CP*GP*CP*G)-3') ; × 1 ;DNA (5'-D(*GP*CP*GP*GP*CP*TP*GP*TP*CP*AP*TP*AP*CP*CP*A)-3') ; × 1 water × 3 Consistent with all polymers
3 Protein–DNA Monomer Protein 1 DNA 2 ;DNA (5'-D(*CP*CP*(C37)P*GP*GP*TP*AP*TP*GP*AP*CP*AP*GP*CP*CP*GP*CP*G)-3') ; × 1 ;DNA (5'-D(*GP*CP*GP*GP*CP*TP*GP*TP*CP*AP*TP*AP*CP*CP*A)-3') ; × 1 water × 3 Consistent with all polymers
4 Protein–DNA Monomer Protein 1 DNA 2 ;DNA (5'-D(*CP*CP*(C37)P*GP*GP*TP*AP*TP*GP*AP*CP*AP*GP*CP*CP*GP*CP*G)-3') ; × 1 ;DNA (5'-D(*GP*CP*GP*GP*CP*TP*GP*TP*CP*AP*TP*AP*CP*CP*A)-3') ; × 1 water × 1 Consistent with all polymers

Other States of the Same Protein in the Database

Monomer
1ih7 1waf 1waf 1waj 3cfo 4i9l

6 assemblies

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
1b8h 1clq 1ig9 1q9x 1q9x 1q9x 1q9x 1q9y 2atq 2dtu 2dtu 2dtu

161 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name DPOL_BPR69
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 1–903； UniProt 1–903 Author chain B； PDBConstruct 1–903； UniProt 1–903 Author chain C； PDBConstruct 1–903； UniProt 1–903 Author chain D； PDBConstruct 1–903； UniProt 1–903

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id3tag
Deposition date deposition_date2011-08-04
Structure title title5-fluorocytosine paired with dAMP in RB69 gp43
Keywords keywordsTransferase-DNA complex; Transferase/DNA
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

3tag__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

3tag__assembly_1__model_1 | I(q)

10-2 10-1 106 107 108 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

3tag__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）33.06 Å
Rg (electron density)32.03 Å
Total Rg32.69 Å
Atom count8061
Residues938
Excluded volume141640 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 3tag__assembly_1__model_1 trimeric （3） Success 4.1.3-1-20251215 (887e7ef) View Download
2 1 3tag__assembly_2__model_1 trimeric （3） Success 4.1.3-1-20251215 (887e7ef) View Download
3 1 3tag__assembly_3__model_1 trimeric （3） Success 4.1.3-1-20251215 (887e7ef) View Download
4 1 3tag__assembly_4__model_1 trimeric （3） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (5)

▼

6. Fold Classification (SCOP + CATH) 33 domains

SCOP 2.08 (9 domains)

Domain ID domain_idd3taga1
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.55 — Ribonuclease H-like motif
Superfamily Superfamily superfamilyc.55.3 — Ribonuclease H-like
Family Family familyc.55.3.5 — DnaQ-like 3'-5' exonuclease
Domain ID domain_idd3taga2
Class classe — Multi-domain proteins (alpha and beta)
Fold Fold folde.8 — DNA/RNA polymerases
Superfamily Superfamily superfamilye.8.1 — DNA/RNA polymerases
Family Family familye.8.1.1 — DNA polymerase I
Domain ID domain_idd3taga3
Class classl — Artifacts
Fold Fold foldl.1 — Tags
Superfamily Superfamily superfamilyl.1.1 — Tags
Family Family familyl.1.1.1 — Tags
Domain ID domain_idd3tagb1
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.55 — Ribonuclease H-like motif
Superfamily Superfamily superfamilyc.55.3 — Ribonuclease H-like
Family Family familyc.55.3.5 — DnaQ-like 3'-5' exonuclease
Domain ID domain_idd3tagb2
Class classe — Multi-domain proteins (alpha and beta)
Fold Fold folde.8 — DNA/RNA polymerases
Superfamily Superfamily superfamilye.8.1 — DNA/RNA polymerases
Family Family familye.8.1.1 — DNA polymerase I
Domain ID domain_idd3tagc1
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.55 — Ribonuclease H-like motif
Superfamily Superfamily superfamilyc.55.3 — Ribonuclease H-like
Family Family familyc.55.3.5 — DnaQ-like 3'-5' exonuclease
Domain ID domain_idd3tagc2
Class classe — Multi-domain proteins (alpha and beta)
Fold Fold folde.8 — DNA/RNA polymerases
Superfamily Superfamily superfamilye.8.1 — DNA/RNA polymerases
Family Family familye.8.1.1 — DNA polymerase I
Domain ID domain_idd3tagd1
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.55 — Ribonuclease H-like motif
Superfamily Superfamily superfamilyc.55.3 — Ribonuclease H-like
Family Family familyc.55.3.5 — DnaQ-like 3'-5' exonuclease
Domain ID domain_idd3tagd2
Class classe — Multi-domain proteins (alpha and beta)
Fold Fold folde.8 — DNA/RNA polymerases
Superfamily Superfamily superfamilye.8.1 — DNA/RNA polymerases
Family Family familye.8.1.1 — DNA polymerase I

CATH v4.4 (24 domains)

Domain ID domain_id3tagA01
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology342 — DNA Polymerase; Chain A, domain 1
Homologous superfamily homologous superfamily10 — DNA Polymerase, chain B, domain 1
Domain ID domain_id3tagA02
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology420 — Nucleotidyltransferase; domain 5
Homologous superfamily homologous superfamily10 — Ribonuclease H-like superfamily/Ribonuclease H
Domain ID domain_id3tagA03
Class class3 — Alpha Beta
Architecture architecture90 — Alpha-Beta Complex
Topology topology1600 — Palm domain of DNA polymerase
Homologous superfamily homologous superfamily10 — B family DNA polymerase, palm domain
Domain ID domain_id3tagA04
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology287 — Helix Hairpins
Homologous superfamily homologous superfamily690 — B family DNA polymerase, finger domain
Domain ID domain_id3tagA05
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology1280 — Monooxygenase
Homologous superfamily homologous superfamily300 —
Domain ID domain_id3tagA06
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology1820 — Ribonuclease H-like motif
Homologous superfamily homologous superfamily10 — DnaQ-like 3'-5' exonuclease
Domain ID domain_id3tagB01
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology342 — DNA Polymerase; Chain A, domain 1
Homologous superfamily homologous superfamily10 — DNA Polymerase, chain B, domain 1
Domain ID domain_id3tagB02
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology420 — Nucleotidyltransferase; domain 5
Homologous superfamily homologous superfamily10 — Ribonuclease H-like superfamily/Ribonuclease H
Domain ID domain_id3tagB03
Class class3 — Alpha Beta
Architecture architecture90 — Alpha-Beta Complex
Topology topology1600 — Palm domain of DNA polymerase
Homologous superfamily homologous superfamily10 — B family DNA polymerase, palm domain
Domain ID domain_id3tagB04
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology287 — Helix Hairpins
Homologous superfamily homologous superfamily690 — B family DNA polymerase, finger domain
Domain ID domain_id3tagB05
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology1280 — Monooxygenase
Homologous superfamily homologous superfamily300 —
Domain ID domain_id3tagB06
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology1820 — Ribonuclease H-like motif
Homologous superfamily homologous superfamily10 — DnaQ-like 3'-5' exonuclease
Domain ID domain_id3tagC01
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology342 — DNA Polymerase; Chain A, domain 1
Homologous superfamily homologous superfamily10 — DNA Polymerase, chain B, domain 1
Domain ID domain_id3tagC02
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology420 — Nucleotidyltransferase; domain 5
Homologous superfamily homologous superfamily10 — Ribonuclease H-like superfamily/Ribonuclease H
Domain ID domain_id3tagC03
Class class3 — Alpha Beta
Architecture architecture90 — Alpha-Beta Complex
Topology topology1600 — Palm domain of DNA polymerase
Homologous superfamily homologous superfamily10 — B family DNA polymerase, palm domain
Domain ID domain_id3tagC04
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology287 — Helix Hairpins
Homologous superfamily homologous superfamily690 — B family DNA polymerase, finger domain
Domain ID domain_id3tagC05
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology1280 — Monooxygenase
Homologous superfamily homologous superfamily300 —
Domain ID domain_id3tagC06
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology1820 — Ribonuclease H-like motif
Homologous superfamily homologous superfamily10 — DnaQ-like 3'-5' exonuclease
Domain ID domain_id3tagD01
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology342 — DNA Polymerase; Chain A, domain 1
Homologous superfamily homologous superfamily10 — DNA Polymerase, chain B, domain 1
Domain ID domain_id3tagD02
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology420 — Nucleotidyltransferase; domain 5
Homologous superfamily homologous superfamily10 — Ribonuclease H-like superfamily/Ribonuclease H
Domain ID domain_id3tagD03
Class class3 — Alpha Beta
Architecture architecture90 — Alpha-Beta Complex
Topology topology1600 — Palm domain of DNA polymerase
Homologous superfamily homologous superfamily10 — B family DNA polymerase, palm domain
Domain ID domain_id3tagD04
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology287 — Helix Hairpins
Homologous superfamily homologous superfamily690 — B family DNA polymerase, finger domain
Domain ID domain_id3tagD05
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology1280 — Monooxygenase
Homologous superfamily homologous superfamily300 —
Domain ID domain_id3tagD06
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology1820 — Ribonuclease H-like motif
Homologous superfamily homologous superfamily10 — DnaQ-like 3'-5' exonuclease
▶

7. Citations (1)
