Ferritin light chain
OrganismNot specified
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein homooligomer Homooligomer Protein × 24 PDB declaration: 24-meric（24） Consistent with protein copy count | Chain A； UniProt 2–175 | Not recorded | SDS DODECYL SULFATE × 24 CD CADMIUM ION × 240 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.05 M cadmium sulfate, 0.1 M HEPES, 1.0 M sodium acetate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K | Resolution 1.90 Å R-free 0.208 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 3U90 | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 1AEW L-CHAIN HORSE APOFERRITIN Deposited 1997-02-26 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
Fragment：L CHAIN
|
Not recorded | CD CADMIUM ION × 144 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；CRYSTALLIZED BY SITTING DROP: 15 LAMBDA PROTEIN + 1-2 LAMBDA 2% CDSO4, pH 7.0, vapor diffusion - sitting drop
|
Resolution 1.95 Å |
| 1DAT CUBIC CRYSTAL STRUCTURE RECOMBINANT HORSE L APOFERRITIN Deposited 1996-11-14 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Not recorded | CD CADMIUM ION × 72 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.05 Å |
| 1GWG Tri-iodide derivative of apoferritin Deposited 2002-03-15 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
Fragment：L-CHAIN RESIDUES 1-174
|
Not recorded | IOD IODIDE ION × 216 CD CADMIUM ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.3；40MG/ML PROTEIN; 8MM CDSO4, 1M AMMONIUM SULPHATE, 0.01M NAN3., pH 5.30
|
Resolution 2.01 Å R-free 0.208 |
| 1HRS A CRYSTALLOGRAPHIC STUDY OF HAEM BINDING TO FERRITIN Deposited 1993-11-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Not recorded | CD CADMIUM ION × 48 PP9 PROTOPORPHYRIN IX × 24 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.60 Å |
| 1IER CUBIC CRYSTAL STRUCTURE OF NATIVE HORSE SPLEEN FERRITIN Deposited 1996-05-28 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
Fragment：L-CHAIN
|
Not recorded | CD CADMIUM ION × 72 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.26 Å |
| 1IES TETRAGONAL CRYSTAL STRUCTURE OF NATIVE HORSE SPLEEN FERRITIN Deposited 1996-05-28 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
Fragment：L-CHAIN
Chain B
1–174（174 aa）
Fragment：L-CHAIN
Chain C
1–174（174 aa）
Fragment：L-CHAIN
Chain D
1–174（174 aa）
Fragment：L-CHAIN
Chain E
1–174（174 aa）
Fragment：L-CHAIN
Chain F
1–174（174 aa）
Fragment：L-CHAIN
|
Not recorded | CD CADMIUM ION × 20 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.60 Å |
| 1XZ1 Complex of halothane with apoferritin Deposited 2004-11-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Not recorded | CD CADMIUM ION × 144 HLT 2-BROMO-2-CHLORO-1,1,1-TRIFLUOROETHANE × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；cadmium sulfate, HEPES, sodium acetate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.75 Å R-free 0.212 |
| 1XZ3 Complex of apoferritin with isoflurane Deposited 2004-11-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Not recorded | CD CADMIUM ION × 168 ICF 1-CHLORO-2,2,2-TRIFLUOROETHYL DIFLUOROMETHYL ETHER × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；cadmium sulfate, HEPES, sodium acetate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.75 Å R-free 0.210 |
| 2G4H Anomalous substructure of apoferritin Deposited 2006-02-22 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Not recorded | CD CADMIUM ION × 216 CL CHLORIDE ION × 48 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å R-free 0.218 |
| 2V2I Wild type recombinant horse spleen apoferritin cocrystallized with haemin in acidic conditions Deposited 2007-06-06 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Not recorded | CD CADMIUM ION × 192 GOL GLYCEROL × 24 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；RESERVOIR: CADMIUM SULFATE 0.13M, AMMONIUM SULFATE 0.8M, SODIUM ACETATE 0.1M PH 5.5, SODIUM AZIDE 0.003M DROP 2 UL PROTEIN AND 2UL RESERVOIR
|
Resolution 2.00 Å R-free 0.217 |
| 2V2J Wild type recombinant horse spleen apoferritin cocrystallized with haemin in basic conditions Deposited 2007-06-06 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Not recorded | CD CADMIUM ION × 192 GOL GLYCEROL × 120 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.2；RESERVOIR: CADMIUM SULFATE 0.04M, AMMONIUM SULFATE 0.5M, SODIUM AZIDE 0.003M DROP: 1UL PROTEIN AND 1 UL RESERVOIR, pH 8.2
|
Resolution 2.22 Å R-free 0.250 |
| 2V2L Mutant (E53,56,57,60Q) recombinant horse spleen apoferritin cocrystallized with haemin in acidic conditions Deposited 2007-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Mutation：YES | CD CADMIUM ION × 168 SO4 SULFATE ION × 24 GOL GLYCEROL × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；RESERVOIR: CADMIUM SULFATE 0.13M, AMMONIUM SULFATE 0.8M, SODIUM ACETATE 0.1M PH 5.5, SODIUM AZIDE 0.003M. DROP: 2 UL PROTEIN AND 2 UL RESERVOIR
|
Resolution 1.90 Å R-free 0.216 |
| 2V2M Mutant (E53,56,57,60Q) recombinant horse spleen apoferritin cocrystallized with haemin in basic conditions Deposited 2007-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Mutation：YES | CD CADMIUM ION × 168 SO4 SULFATE ION × 24 GOL GLYCEROL × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8；RESERVOIR: CADMIUM SULFATE 0.044M, AMMONIUM SULFATE 0.5M, SODIUM AZIDE 0.003M. DROP: 1UL PROTEIN AND 1UL RESERVOIR, pH 8.0
|
Resolution 1.65 Å R-free 0.212 |
| 2V2N Mutant R59M recombinant horse spleen apoferritin cocrystallized with haemin in acidic conditions Deposited 2007-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Mutation：YES | CD CADMIUM ION × 192 GOL GLYCEROL × 72 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；RESERVOIR: CADMIUM SULFATE 0.12M, AMMONIUM SULFATE 1.1M, SODIUM ACETATE 0.1M PH 5.6, SODIUM AZIDE 0.003M DROP: 1UL PROTEIN AND 1UL RESERVOIR
|
Resolution 1.55 Å R-free 0.222 |
| 2V2O Mutant R59M recombinant horse spleen apoferritin cocrystallized with haemin in basic conditions Deposited 2007-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Mutation：YES | CD CADMIUM ION × 216 GOL GLYCEROL × 24 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.2；RESERVOIR: CADMIUM SULFATE 0.145M, AMMONIUM SULFATE 0.55M, SODIUM AZIDE 0.003M. DROP: 1UL PROTEIN AND 1UL RESERVOIR, pH 8.2
|
Resolution 1.87 Å R-free 0.236 |
| 2V2P Mutant (E53,56,57,60Q and R59M) recombinant horse spleen apoferritin cocrystallized with haemin in acidic conditions Deposited 2007-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Mutation：YES | CD CADMIUM ION × 120 GOL GLYCEROL × 48 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；RESERVOIR: CADMIUM SULFATE 0.08M, AMMONIUM SULFATE 0.5M, SODIUM ACETATE 0.1M PH 5.6, SODIUM AZIDE 0.003M. DROP: 1UL PROTEIN AND 1UL RESERVOIR
|
Resolution 1.15 Å R-free 0.224 |
| 2V2R Mutant (E53,56,57,60Q and R59M) recombinant horse spleen apoferritin cocrystallized with haemin in basic conditions Deposited 2007-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Mutation：YES | CD CADMIUM ION × 144 GOL GLYCEROL × 24 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.2；RESERVOIR: CADMIUM SULFATE 0.16M, AMMONIUM SULFATE 0.5M, SODIUM AZIDE 0.003M. DROP: 1UL PROTEIN AND 1UL RESERVOIR, pH 8.2
|
Resolution 1.90 Å R-free 0.230 |
| 2V2S Mutant R59M recombinant horse spleen apoferritin crystallized in acidic conditions Deposited 2007-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Mutation：YES | CD CADMIUM ION × 192 GOL GLYCEROL × 48 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；RESERVOIR: CADMIUM SULFATE 0.12M, AMMONIUM SULFATE 1.1M, SODIUM ACETATE 0.1M PH5.6, SODIUM AZIDE 0.003M. DROP: 1UL PROTEIN AND 1UL RESERVOIR, pH 5.5
|
Resolution 1.37 Å R-free 0.226 |
| 2W0O Horse spleen apoferritin Deposited 2008-08-20 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
Fragment：RESIDUES 2-175
|
Not recorded | SO4 SULFATE ION × 24 CD CADMIUM ION × 168 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.6；RESERVOIR: CADMIUM SULFATE 0.12M, AMMONIUM SULFATE 0.8M, SODIUM ACETATE BUFFER 0.1M PH 5.6, SODIUM AZIDE 0.003M. DROP: 1UL PROTEIN AND 1 UL RESERVOIR
|
Resolution 1.50 Å R-free 0.236 |
| 2Z5P Apo-Fr with low content of Pd ions Deposited 2007-07-16 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | PD PALLADIUM ION × 144 CD CADMIUM ION × 48 SO4 SULFATE ION × 72 GOL GLYCEROL × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulfate, Cadmium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.65 Å R-free 0.188 |
| 2Z5Q Apo-Fr with intermediate content of Pd ion Deposited 2007-07-16 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | PD PALLADIUM ION × 216 CD CADMIUM ION × 24 GOL GLYCEROL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulfate, Cadmium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.10 Å R-free 0.254 |
| 2Z5R Apo-Fr with high content of Pd ions Deposited 2007-07-16 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | PD PALLADIUM ION × 240 CD CADMIUM ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulfate, Cadmium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.50 Å R-free 0.287 |
| 2ZA6 recombinant horse L-chain apoferritin Deposited 2007-10-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–175（175 aa）
|
Not recorded | CD CADMIUM ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.1M Tris-HCl, 0.13% cadmium chloride, 15% PEG4000, 19 mM calcium chloride, 5% glycerol, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293.0K
|
Resolution 1.75 Å R-free 0.225 |
| 2ZA7 recombinant horse L-chain apoferritin N-terminal deletion mutant (residues 1-4) Deposited 2007-10-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
5–175（171 aa）
Fragment：residues 5-175
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.1M Tris-HCl, 0.13% cadmium chloride, 15% PEG4000, 190mM calcium chloride, 5% glycerol, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293.0K
|
Resolution 1.40 Å R-free 0.242 |
| 2ZA8 recombinant horse L-chain apoferritin N-terminal deletion mutant (residues 1-8) Deposited 2007-10-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
9–175（167 aa）
Fragment：residues 9-175
|
Not recorded | CD CADMIUM ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.8；293 K；0.1M Tris-HCl, 225mM ammonium sulphate, 0.13% cadmium chloride, 25% 2-Metyl-2,4-pentanediol, pH 6.8, VAPOR DIFFUSION, HANGING DROP, temperature 293.0K
|
Resolution 1.40 Å R-free 0.239 |
| 2ZG7 Crystal Structure of Pd(allyl)/apo-Fr Deposited 2008-01-18 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 24 SO4 SULFATE ION × 96 PLL Palladium(II) allyl complex × 96 EDO 1,2-ETHANEDIOL × 192 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium slfate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.70 Å R-free 0.202 |
| 2ZG8 Crystal Structure of Pd(allyl)/apo-H49AFr Deposited 2008-01-18 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：H49A | PD PALLADIUM ION × 24 CD CADMIUM ION × 24 SO4 SULFATE ION × 96 PLL Palladium(II) allyl complex × 72 EDO 1,2-ETHANEDIOL × 168 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.60 Å R-free 0.211 |
| 2ZG9 Crystal Structure of Pd(allyl)/apo-H114AFr Deposited 2008-01-18 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：H114A | CD CADMIUM ION × 24 SO4 SULFATE ION × 96 PLL Palladium(II) allyl complex × 72 EDO 1,2-ETHANEDIOL × 144 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.75 Å R-free 0.211 |
| 2ZUR Crystal Structure of Rh(nbd)/apo-Fr Deposited 2008-10-28 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CD CADMIUM ION × 120 SO4 SULFATE ION × 48 RH Rhodium × 48 EDO 1,2-ETHANEDIOL × 192 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；0.5M ammonium sulfate, 10mM cadmium sulfate, pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.80 Å R-free 0.196 |
| 3AF7 Crystal Structure of 25Pd(allyl)/apo-Fr Deposited 2010-02-24 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 24 SO4 SULFATE ION × 24 PD PALLADIUM ION × 48 PLL Palladium(II) allyl complex × 72 EDO 1,2-ETHANEDIOL × 120 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate, pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.58 Å R-free 0.212 |
| 3AF8 Crystal Structure of Pd(ally)/apo-C126AFr Deposited 2010-02-24 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：C126A | CD CADMIUM ION × 72 SO4 SULFATE ION × 24 PLL Palladium(II) allyl complex × 48 EDO 1,2-ETHANEDIOL × 168 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate, pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.66 Å R-free 0.195 |
| 3AF9 Crystal Structure of Pd(allyl)/apo-C48AFr Deposited 2010-02-24 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：C48A | SO4 SULFATE ION × 24 CD CADMIUM ION × 72 PLL Palladium(II) allyl complex × 24 PD PALLADIUM ION × 24 EDO 1,2-ETHANEDIOL × 168 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate, pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.85 Å R-free 0.203 |
| 3F32 Horse spleen apoferritin Deposited 2008-10-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 120 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；Cadmium sulfate, ammonium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.70 Å R-free 0.209 |
| 3F33 Apoferritin: complex with propofol Deposited 2008-10-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 144 PFL 2,6-BIS(1-METHYLETHYL)PHENOL × 24 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；Cadmium sulfate, ammonium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.70 Å R-free 0.220 |
| 3F34 Apoferritin: complex with 2,6-diethylphenol Deposited 2008-10-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 120 DIE 2,6-diethylphenol × 24 SO4 SULFATE ION × 72 ACT ACETATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；Cadmium sulfate, ammonium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.68 Å R-free 0.247 |
| 3F35 Apoferritin: complex with 2,6-diethylphenol Deposited 2008-10-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 168 DIE 2,6-diethylphenol × 24 SO4 SULFATE ION × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；cadmium sulfate, ammonium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.92 Å R-free 0.236 |
| 3F36 Apoferritin: complex with 2-isopropylphenol Deposited 2008-10-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 192 IP0 2-(1-methylethyl)phenol × 24 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；Cadmium sulfate, ammonium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.70 Å R-free 0.210 |
| 3F37 Apoferritin: complex with 2,6-dimethylphenol Deposited 2008-10-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 168 2MY 2,6-dimethylphenol × 24 SO4 SULFATE ION × 72 ACT ACETATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；Cadmium sulfate, ammonium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.54 Å R-free 0.198 |
| 3F38 Apoferritin: complex with 2,6-dimethylphenol Deposited 2008-10-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 144 2MY 2,6-dimethylphenol × 24 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；Cadmium sulfate, ammonium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.75 Å R-free 0.222 |
| 3F39 Apoferritin: complex with phenol Deposited 2008-10-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 192 IPH PHENOL × 24 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；Cadmium sulfate, ammonium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.85 Å R-free 0.216 |
| 3FI6 apo-H49AFr with high content of Pd ions Deposited 2008-12-11 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：H49A, L93P | PD PALLADIUM ION × 192 CD CADMIUM ION × 24 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulfate, Cadmium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.80 Å R-free 0.225 |
| 3H7G Apo-FR with AU ions Deposited 2009-04-27 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | AU3 GOLD 3+ ION × 144 CD CADMIUM ION × 72 SO4 SULFATE ION × 72 GOL GLYCEROL × 96 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；AMMONIUM SULFATE, CADMIUM SULFATE, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.65 Å R-free 0.236 |
| 3NOZ Crystal Structure of Pd(allyl)/apo-E45C/R52H-rHLFr Deposited 2010-06-27 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：E45C, R52H | SO4 SULFATE ION × 24 CD CADMIUM ION × 24 PLL Palladium(II) allyl complex × 144 EDO 1,2-ETHANEDIOL × 216 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate, pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.52 Å R-free 0.209 |
| 3NP0 Crystal Structure of Pd(allyl)/apo-E45C/H49A/R52H-rHLFr Deposited 2010-06-27 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：E45C, H49A, R52H | SO4 SULFATE ION × 48 PLL Palladium(II) allyl complex × 144 CD CADMIUM ION × 24 EDO 1,2-ETHANEDIOL × 192 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate, pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.48 Å R-free 0.210 |
| 3NP2 Crystal Structure of Pd(allyl)/apo-E45C/C48A-rHLFr Deposited 2010-06-27 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：E45C, C48A | SO4 SULFATE ION × 24 PLL Palladium(II) allyl complex × 48 PD PALLADIUM ION × 48 CD CADMIUM ION × 48 EDO 1,2-ETHANEDIOL × 192 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate , pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.86 Å R-free 0.229 |
| 3O7R Crystal structure of Ru(p-cymene)/apo-H49AFr Deposited 2010-07-31 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：H49A, L93P | CD CADMIUM ION × 72 RU RUTHENIUM ION × 48 SO4 SULFATE ION × 48 EDO 1,2-ETHANEDIOL × 144 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；AMMONIUM SULFATE, CADMIUM SLFATE, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.90 Å R-free 0.237 |
| 3O7S Crystal structure of Ru(p-cymene)/apo-Fr Deposited 2010-07-31 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 72 RU RUTHENIUM ION × 72 MML 1-methyl-4-(1-methylethyl)benzene × 24 SO4 SULFATE ION × 24 EDO 1,2-ETHANEDIOL × 120 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；AMMONIUM SULFATE, CADMIUM SLFATE, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.73 Å R-free 0.217 |
| 3RAV Horse spleen apo-ferritin with bound Pentobarbital Deposited 2011-03-28 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 144 SO4 SULFATE ION × 48 RAV 5-ethyl-5-[(2S)-pentan-2-yl]pyrimidine-2,4,6(1H,3H,5H)-trione × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；291 K；0.2-1.6 M (NH4)2SO4 and 0.1-0.275 M CdSO4, 0.5 mM thiopental were mixed with equal volumes of apoferritin solution and equilibrated over 0.7-1 mL, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.90 Å R-free 0.208 |
| 3RD0 Horse spleen apo-ferritin with bound thiopental Deposited 2011-03-31 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | EDP 5-ethyl-5-[(2R)-pentan-2-yl]-2-thioxodihydropyrimidine-4,6(1H,5H)-dione × 24 CD CADMIUM ION × 120 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；291 K；0.2-1.6 M (NH4)2SO4 and 0.1-0.275 M CdSO4, 0.5 mM thiopental were mixed with equal volumes of apoferritin solution and equilibrated over 0.7-1 ml, vapor diffusion, hanging drop, temperature 291K
|
Resolution 2.00 Å R-free 0.205 |
| 3WVU Crystal Structure of RuCO/apo-R52CFr Deposited 2014-06-09 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52C | CD CADMIUM ION × 72 SO4 SULFATE ION × 24 EDO 1,2-ETHANEDIOL × 192 RU RUTHENIUM ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；1M ammonium sulfate, 20mM cadmium sulfate, pH 8, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.92 Å R-free 0.193 |
| 3WVV Crystal Structure of RuCO/apo-E45C_C48AFr Deposited 2014-06-09 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E45C, C48A | CD CADMIUM ION × 96 SO4 SULFATE ION × 24 EDO 1,2-ETHANEDIOL × 168 RU RUTHENIUM ION × 96 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；1M ammonium sulfate, 20mM cadmium sulfate, pH 8, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.82 Å R-free 0.191 |
| 3WVW Crystal structure of RuCO/apo-WTFr Deposited 2014-06-09 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 72 SO4 SULFATE ION × 24 EDO 1,2-ETHANEDIOL × 192 RU RUTHENIUM ION × 48 RU1 bis(oxidaniumylidynemethyl)ruthenium(2+) × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；1M ammonium sulfate, 20 mM cadmium sulfate, pH 8, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.199 |
| 4DE6 Horse spleen apo-ferritin complex with arachidonic acid Deposited 2012-01-19 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | ACD ARACHIDONIC ACID × 24 CD CADMIUM ION × 240 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；(NH4)2SO4 and CDSO4, ,0.2 mM arachidonate was mixed in the reservoir, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.18 Å R-free 0.224 |
| 4V1W 3D structure of horse spleen apoferritin determined by electron cryomicroscopy Deposited 2014-10-02 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
Chain B
2–175（174 aa）
Chain C
2–175（174 aa）
Chain D
2–175（174 aa）
Chain E
2–175（174 aa）
Chain F
2–175（174 aa）
Chain G
2–175（174 aa）
Chain H
2–175（174 aa）
Chain I
2–175（174 aa）
Chain J
2–175（174 aa）
Chain K
2–175（174 aa）
Chain L
2–175（174 aa）
Chain M
2–175（174 aa）
Chain N
2–175（174 aa）
Chain O
2–175（174 aa）
Chain P
2–175（174 aa）
Chain Q
2–175（174 aa）
Chain R
2–175（174 aa）
Chain S
2–175（174 aa）
Chain T
2–175（174 aa）
Chain U
2–175（174 aa）
Chain V
2–175（174 aa）
Chain W
2–175（174 aa）
Chain X
2–175（174 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
PBS；pH 7.4；PBS
cryo-EM vitrification conditions
Cryogen ETHANE；LIQUID ETHANE
|
Resolution 4.70 Å |
| 4Z3B Crystal structure of MnCO/apo-R52CFr Deposited 2015-03-31 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
Fragment：UNP residues 2-175
|
Not recorded | CD CADMIUM ION × 72 GOL GLYCEROL × 24 MN MANGANESE (II) ION × 48 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；1M ammonium sulfate, 20mM cadmium sulfite
|
Resolution 1.42 Å R-free 0.176 |
| 5AXS Crystal structure of CdCat-Fn Deposited 2015-08-01 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：A119C, C126A | 4LF N-[2-[2,5-bis(oxidanylidene)pyrrol-1-yl]ethyl]-2,3-bis(oxidanyl)benzamide × 24 CD CADMIUM ION × 120 SO4 SULFATE ION × 24 GOL GLYCEROL × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate
|
Resolution 1.67 Å R-free 0.188 |
| 5CZU Crystal structure of FeCat-Fn Deposited 2015-08-01 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：A119C, C126A | 4LF N-[2-[2,5-bis(oxidanylidene)pyrrol-1-yl]ethyl]-2,3-bis(oxidanyl)benzamide × 24 SO4 SULFATE ION × 24 CD CADMIUM ION × 96 FE FE (III) ION × 24 GOL GLYCEROL × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate
|
Resolution 1.60 Å R-free 0.208 |
| 5E1U Crystal structure of IrCp*-apo-Fr Deposited 2015-09-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | IR3 IRIDIUM (III) ION × 144 CD CADMIUM ION × 24 SO4 SULFATE ION × 48 RIR [(1,2,3,4,5-Eta)-1,2,3,4,5-Pentamethylcyclopentadienyl]iridium(III) × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；Ammonium sulphate, Cadmium Sulphate
|
Resolution 1.56 Å R-free 0.188 |
| 5E2D Crystal structure of IrCp*/Pd(allyl)-apo-Fr Deposited 2015-10-01 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | IR3 IRIDIUM (III) ION × 120 IR IRIDIUM ION × 24 SO4 SULFATE ION × 48 PLL Palladium(II) allyl complex × 48 PD PALLADIUM ION × 24 CD CADMIUM ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.87 Å R-free 0.201 |
| 5ERJ X-ray structure of cisplatin-encapsulated horse spleen apoferritin Deposited 2015-11-14 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CL CHLORIDE ION × 96 CD CADMIUM ION × 312 CPT Cisplatin × 24 GOL GLYCEROL × 24 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；0.6-0.8 M (NH4)2SO4, 0.1 M Tris pH 7.4-7.7, 50-60 mM CdSO4
|
Resolution 1.45 Å R-free 0.173 |
| 5ERK X-ray structure of horse spleen apoferritin (control) Deposited 2015-11-14 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 312 CL CHLORIDE ION × 72 SO4 SULFATE ION × 24 GOL GLYCEROL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；0.6-0.8 M (NH4)2SO4, 0.1 M Tris pH 7.4-7.7, 50-60 mM CdSO4.
|
Resolution 2.00 Å R-free 0.181 |
| 5GU0 Crystal structure of Au.CL-apo-E45C/R52C-rHLFr Deposited 2016-08-24 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：E45C,R52C | AU GOLD ION × 192 CD CADMIUM ION × 72 SO4 SULFATE ION × 48 EDO 1,2-ETHANEDIOL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.95 Å R-free 0.205 |
| 5GU1 Crystal structure of Au(L).CL-apo-E45C/R52C-rHLFr Deposited 2016-08-24 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：E45C,R52C | AU GOLD ION × 216 CD CADMIUM ION × 144 SO4 SULFATE ION × 48 EDO 1,2-ETHANEDIOL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium Sulphate, Cadmium Sulphate
|
Resolution 2.05 Å R-free 0.223 |
| 5GU2 Crystal structure of Au(M).CL-apo-E45C/R52C-rHLFr Deposited 2016-08-24 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：E45C,R52C | AU GOLD ION × 240 CD CADMIUM ION × 144 SO4 SULFATE ION × 48 EDO 1,2-ETHANEDIOL × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium Sulphate, Cadmium Sulphate
|
Resolution 2.12 Å R-free 0.229 |
| 5GU3 Crystal structure of Au(E).CL-apo-E45C/R52C-rHLFr Deposited 2016-08-24 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：E45C,R52C | SO4 SULFATE ION × 48 AU GOLD ION × 144 CD CADMIUM ION × 120 EDO 1,2-ETHANEDIOL × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 2.03 Å R-free 0.244 |
| 5HQO Crystal structure of IrCp*/I-Pd(allyl)-apo-rHLFr Deposited 2016-01-21 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | PD PALLADIUM ION × 48 PLL Palladium(II) allyl complex × 24 IR IRIDIUM ION × 144 CD CADMIUM ION × 24 SO4 SULFATE ION × 24 EDO 1,2-ETHANEDIOL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.81 Å R-free 0.221 |
| 5IX6 X-ray structure of Auoxo3-encapsulated horse spleen apoferritin Deposited 2016-03-23 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | AU GOLD ION × 168 CD CADMIUM ION × 216 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；Crystals of Auoxo3-encapsulated AFt with diamond-like morphology, suitable for X-ray diffraction data collection, were grown by hanging-drop vapor diffusion technique at 293 K mixing the protein (5-10 mg x mL-1) with equal volumes of a reservoir solution consisting of 0.6-0.8 M (NH4)2SO4, 0.1 M Tris pH 7.4-7.7, 50-60 mM CdSO4.
|
Resolution 1.85 Å R-free 0.226 |
| 5LG2 Horse L type ferritin iron loaded for 60 minutes Deposited 2016-07-05 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
3–173（171 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CD CADMIUM ION × 72 FE FE (III) ION × 96 CL CHLORIDE ION × 24 OXY OXYGEN MOLECULE × 24 PER PEROXIDE ION × 48 GOL GLYCEROL × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；297 K；80 mM Cd(NO3)2, 80 mM ammonium sulfate, and 200 mM sodium acetate pH 5
|
Resolution 2.22 Å R-free 0.224 |
| 5MIJ X-ray structure of carboplatin-encapsulated horse spleen apoferritin Deposited 2016-11-28 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 264 CL CHLORIDE ION × 96 SO4 SULFATE ION × 24 PT PLATINUM (II) ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.7；298 K；0.8 M (NH4)2SO4, 0.1 M Tris pH 7.7, 60 mM CdSO4.
|
Resolution 1.49 Å R-free 0.181 |
| 5MIK X-ray structure of carboplatin-encapsulated horse spleen apoferritin (rotating anode data) Deposited 2016-11-28 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 264 CL CHLORIDE ION × 72 SO4 SULFATE ION × 24 GOL GLYCEROL × 48 PT PLATINUM (II) ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.7；298 K；0.8 M (NH4)2SO4,
0.1 M Tris pH 7.7,
60 mM CdSO4.
|
Resolution 1.96 Å R-free 0.192 |
| 6ENV X-ray structure of Au2phen-encapsulated horse spleen apoferritin Deposited 2017-10-06 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 240 CL CHLORIDE ION × 24 SO4 SULFATE ION × 24 AU GOLD ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；0.6-0.8 M (NH4)2SO4, 0.1 M Tris pH 7.4-7.7, 50-60 mM CdSO4
|
Resolution 1.82 Å R-free 0.175 |
| 6ENW X-ray structure of Auoxo4-encapsulated horse spleen apoferritin Deposited 2017-10-06 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 240 CL CHLORIDE ION × 24 GOL GLYCEROL × 48 AU GOLD ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；0.6-0.8 M (NH4)2SO4, 0.1 M Tris pH 7.4-7.7, 50-60 mM CdSO4
|
Resolution 2.60 Å R-free 0.236 |
| 6FX8 The X-ray structure of the ferritin nanocage containing Au and Pt, obtained upon encapsulation of a single heterobimetallic compound within the protein cage (rotating anode data) Deposited 2018-03-08 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 312 CL CHLORIDE ION × 72 SO4 SULFATE ION × 24 AU GOLD ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；298 K；0.6 M ammonium sulfate
0.1 M Tris HCl pH 7.4
60 mM cadmium sulfate
|
Resolution 1.80 Å R-free 0.197 |
| 6FX9 The X-ray structure of the ferritin nanocage containing Au and Pt, obtained upon encapsulation of a single heterobimetallic compound within the protein cage (synchrtron data) Deposited 2018-03-08 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 288 CL CHLORIDE ION × 72 SO4 SULFATE ION × 24 GOL GLYCEROL × 24 AU GOLD ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；298 K；0.6 M ammonium sulfate
0.1 M Tris HCl pH 7.4
60 mM cadmium sulfate
|
Resolution 1.50 Å R-free 0.183 |
| 6GXJ X-ray structure of DiRu-1-encapsulated Apoferritin Deposited 2018-06-27 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 240 CL CHLORIDE ION × 48 SO4 SULFATE ION × 24 GOL GLYCEROL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；0.6-0.8 M (NH4)2SO4, 0.1 M Tris HCl pH 7.7, 50 mM CDSO4
|
Resolution 1.43 Å R-free 0.191 |
| 6HJT The X-ray structure of the horse spleen ferritin nanocage containing Pt, obtained upon encapsulation of a Pt(II) terpyridine compound within the protein cage Deposited 2018-09-04 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 168 CL CHLORIDE ION × 72 PT PLATINUM (II) ION × 120 SO4 SULFATE ION × 24 GOL GLYCEROL × 24 DMS DIMETHYL SULFOXIDE × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；298 K；0.6 M (NH4)2SO4, 0.1 M Tris HCl pH 7.4, 60 mM CdSO4
|
Resolution 1.33 Å R-free 0.157 |
| 6HJU The X-ray structure of the horse spleen ferritin nanocage containing Pt, obtained upon encapsulation of a Pt(II) terpyridine compound within the protein cage Deposited 2018-09-04 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 168 CL CHLORIDE ION × 72 PT PLATINUM (II) ION × 120 SO4 SULFATE ION × 24 GOL GLYCEROL × 24 DMS DIMETHYL SULFOXIDE × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；298 K；0.6 M (NH4)2SO4, 0.1 M Tris HCl pH 7.4, 60 mM CdSO4
|
Resolution 1.58 Å R-free 0.182 |
| 6JEE Crystal structure of apo-L161C/L165C-Fr Deposited 2019-02-05 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 120 SO4 SULFATE ION × 48 EDO 1,2-ETHANEDIOL × 48 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.30 Å R-free 0.170 |
| 6JEF Crystal structure of apo-R168C/L169C-Fr Deposited 2019-02-05 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | SO4 SULFATE ION × 24 CD CADMIUM ION × 120 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.58 Å R-free 0.182 |
| 6MSX Iron containing ferritin at 1.43A Deposited 2018-10-18 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
Fragment：residue 2-175
|
Not recorded | SO4 SULFATE ION × 24 EDO 1,2-ETHANEDIOL × 24 CD CADMIUM ION × 96 NA SODIUM ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；A 20 uL pellet of 50 mM cadmium sulfate in 2% agar was deposited on a cover slip. Adjacent to this was positioned ferritin (10 ul of 50 mg/ml ferritin, Sigma F4503) and precipitant (10 ul of 3.5M Ammonium Sulfate and 100 mM Tris pH 7.4). The cover slip was equilibrated over 3.5 M Ammonium Sulfate
|
Resolution 1.43 Å R-free 0.172 |
| 6PXM Horse spleen apoferritin light chain Deposited 2019-07-26 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–175（175 aa）
Chain B
1–175（175 aa）
Chain C
1–175（175 aa）
Chain D
1–175（175 aa）
Chain E
1–175（175 aa）
Chain F
1–175（175 aa）
Chain G
1–175（175 aa）
Chain H
1–175（175 aa）
Chain I
1–175（175 aa）
Chain J
1–175（175 aa）
Chain K
1–175（175 aa）
Chain L
1–175（175 aa）
Chain M
1–175（175 aa）
Chain N
1–175（175 aa）
Chain O
1–175（175 aa）
Chain P
1–175（175 aa）
Chain Q
1–175（175 aa）
Chain R
1–175（175 aa）
Chain S
1–175（175 aa）
Chain T
1–175（175 aa）
Chain V
1–175（175 aa）
Chain W
1–175（175 aa）
Chain X
1–175（175 aa）
Chain Y
1–175（175 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE；Chameleon EP2 based on Spotiton
|
Resolution 2.10 Å |
| 6RA8 Horse spleen apoferritin under 2 kBar of argon Deposited 2019-04-05 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–174（173 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CD CADMIUM ION × 168 AR ARGON × 24 SO4 SULFATE ION × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；Ammonium sulfate 0.6 M + cadmium sulfate 0.1 M
|
Resolution 2.00 Å R-free 0.221 |
| 6RJH 3D structure of horse spleen apoferritin determined using multifunctional graphene supports for electron cryomicroscopy Deposited 2019-04-26 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
3–173（171 aa）
Chain B
3–173（171 aa）
Chain C
3–173（171 aa）
Chain D
3–173（171 aa）
Chain E
3–173（171 aa）
Chain F
3–173（171 aa）
Chain G
3–173（171 aa）
Chain H
3–173（171 aa）
Chain I
3–173（171 aa）
Chain J
3–173（171 aa）
Chain K
3–173（171 aa）
Chain L
3–173（171 aa）
Chain M
3–173（171 aa）
Chain N
3–173（171 aa）
Chain O
3–173（171 aa）
Chain P
3–173（171 aa）
Chain Q
3–173（171 aa）
Chain R
3–173（171 aa）
Chain S
3–173（171 aa）
Chain T
3–173（171 aa）
Chain U
3–173（171 aa）
Chain V
3–173（171 aa）
Chain W
3–173（171 aa）
Chain X
3–173（171 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.10 Å |
| 6TRZ Crystal structure of horse L ferritin (HoLf) Fe(III)-loaded for 15 minutes Deposited 2019-12-19 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain AAA
1–175（175 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | O OXYGEN ATOM × 24 FE FE (III) ION × 144 CD CADMIUM ION × 24 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；293 K；30 mM cadmium nitrate, 1 M ammonium sulfate, and 200 mM sodium acetate, pH 5.5
|
Resolution 2.02 Å R-free 0.188 |
| 6TSS Crystal structure of horse L ferritin (HoLf) Fe(III)-loaded for 60 minutes Deposited 2019-12-21 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain AAA
1–175（175 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | O OXYGEN ATOM × 96 CD CADMIUM ION × 24 FE FE (III) ION × 360 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；293 K；30 mM cadmium nitrate, 1 M ammonium sulfate, 200 mM sodium acetate, pH 5.5
|
Resolution 2.18 Å R-free 0.257 |
| 6TSX Crystal structure of horse L ferritin (HoLf) Fe(III)-loaded for 30 minutes Deposited 2019-12-21 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain AAA
1–175（175 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | O OXYGEN ATOM × 96 FE FE (III) ION × 360 CD CADMIUM ION × 24 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；293 K；30 mM cadmium nitrate, 1 M ammonium sulfate, 200 mM sodium acetate, pH 5.5
|
Resolution 2.02 Å R-free 0.221 |
| 7BD7 X-ray structure of Arsenoplatin-1-encapsulated horse spleen ferritin Deposited 2020-12-21 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–173（172 aa）
|
Not recorded | NA SODIUM ION × 72 CD CADMIUM ION × 360 GOL GLYCEROL × 48 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 A6R arsenoplatin-1 × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.2；293 K；0.6 M ammomium sulphate
0.1 M Tris HCl buffer pH 7.2
60 mM cadmium sulphate
|
Resolution 1.50 Å R-free 0.185 |
| 7BOM Crystal structure of recombinant horse spleen apo-R52C/E56C/R59C/E63C-Fr immobilized with gold ions. Deposited 2020-03-19 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：R53C,E57C,R60C,E64C | AU GOLD ION × 288 CD CADMIUM ION × 120 SO4 SULFATE ION × 24 EDO 1,2-ETHANEDIOL × 24 CL CHLORIDE ION × 24 NA SODIUM ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.93 Å R-free 0.196 |
| 7BON Crystal structure of recombinant horse spleen apo-R52C/E56C/R59C/E63C-Fr Deposited 2020-03-19 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R53C,E57C,R60C,E64C | SO4 SULFATE ION × 24 CD CADMIUM ION × 384 EDO 1,2-ETHANEDIOL × 48 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.48 Å R-free 0.189 |
| 7EML Structure of IrCp* immobilized apo-D38H-rHLFr Deposited 2021-04-14 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：D38H | RIR [(1,2,3,4,5-Eta)-1,2,3,4,5-Pentamethylcyclopentadienyl]iridium(III) × 24 EDO 1,2-ETHANEDIOL × 48 SO4 SULFATE ION × 48 CD CADMIUM ION × 120 CL CHLORIDE ION × 24 IR IRIDIUM ION × 96 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.25 Å R-free 0.183 |
| 7EMM Crystal structure of IrCp* immobilized apo-R52H-rHLFr Deposited 2021-04-14 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52H | EDO 1,2-ETHANEDIOL × 24 SO4 SULFATE ION × 48 CD CADMIUM ION × 144 IR IRIDIUM ION × 144 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.25 Å R-free 0.185 |
| 7RYW Crystal structure of Ferritin grown by the microbatch method in the presence of Agarose Deposited 2021-08-26 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
Fragment：residues 3-172
|
Not recorded | CD CADMIUM ION × 312 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
MICROBATCH；290 K；CdSO4, NH4SO4, Tris pH 7.4
|
Resolution 2.09 Å R-free 0.196 |
| 7RZN Crystal Structure of Ferritin grown by microbatch method in presence of agarose and electric field 2.1KV Deposited 2021-08-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
Fragment：residue 3-172
|
Not recorded | CD CADMIUM ION × 312 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
MICROBATCH；290 K；CdSO4, NH4SO4, Tris ph 7.4
|
Resolution 1.97 Å R-free 0.264 |
| 7RZX Crystal Structure of Ferritin grown by microbatch method in presence of agarose and electric field 4.3KV Deposited 2021-08-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
Fragment：residue 3-172
|
Not recorded | CD CADMIUM ION × 312 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
MICROBATCH；290 K；CdSO4,NH4SO4,Tris pH7.4
|
Resolution 2.44 Å R-free 0.222 |
| 7VIO Crystal structure of recombinant horse spleen apo-R168H/L169C-Fr Deposited 2021-09-27 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R168H/L169C | GOL GLYCEROL × 24 CD CADMIUM ION × 72 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293.15 K；Ammonium Sulfate, Cadmium Sulfate
|
Resolution 1.50 Å R-free 0.193 |
| 7VIP Crystal structure of Au(10EQ)-apo-R168H/L169C-rHLFr Deposited 2021-09-27 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：168H/L169C | GOL GLYCEROL × 48 CD CADMIUM ION × 72 AU GOLD ION × 48 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293.15 K；Ammonium Sulfate, Cadmium Sulfate
|
Resolution 1.90 Å R-free 0.212 |
| 7VIQ Crystal structure of Au(50EQ)-apo-R168H/L169C-rHLFr Deposited 2021-09-27 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R168H/L169C | EDO 1,2-ETHANEDIOL × 48 AU GOLD ION × 192 CD CADMIUM ION × 96 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293.15 K；Ammonium Sulfate, Cadmium Sulfate
|
Resolution 1.90 Å R-free 0.195 |
| 7VIR Crystal structure of Au(100EQ)-apo-R168H/L169C-rHLFr Deposited 2021-09-27 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R168H/L169C | CD CADMIUM ION × 96 SO4 SULFATE ION × 72 AU GOLD ION × 192 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293.15 K；Ammonium Sulfate, Cadmium Sulfate
|
Resolution 1.90 Å R-free 0.208 |
| 7VIS Crystal structure of Au(200EQ)-apo-R168H/L169C-rHLFr Deposited 2021-09-27 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R168H/L169C | EDO 1,2-ETHANEDIOL × 24 AU GOLD ION × 168 CD CADMIUM ION × 72 SO4 SULFATE ION × 24 CL CHLORIDE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293.15 K；Ammonium Sulfate, Cadmium Sulfate
|
Resolution 1.85 Å R-free 0.198 |
| 7VIT Crystal structure of Au(400EQ)-apo-R168H/L169C-rHLFr Deposited 2021-09-27 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R168H/L169C | CD CADMIUM ION × 72 AU GOLD ION × 192 SO4 SULFATE ION × 48 CL CHLORIDE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293.15 K；Ammonium Sulfate, Cadmium Sulfate
|
Resolution 1.90 Å R-free 0.217 |
| 7VIU Crystal structure of Au(200EQ)-apo-R168C/L169C-rHLFr Deposited 2021-09-27 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R168C/L169C | AU GOLD ION × 192 CL CHLORIDE ION × 72 CD CADMIUM ION × 72 SO4 SULFATE ION × 48 GOL GLYCEROL × 96 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293.15 K；Ammonium Sulfate, Cadmium Sulfate
|
Resolution 1.50 Å R-free 0.167 |
| 7W7J Crystal structure of IrCp* immobilized apo-R52H-rHLFr (25 equiv) Deposited 2021-12-05 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52H | EDO 1,2-ETHANEDIOL × 24 IR IRIDIUM ION × 24 CD CADMIUM ION × 120 CL CHLORIDE ION × 24 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.50 Å R-free 0.210 |
| 8B7L X-ray structure of Auranofin-horse spleen ferritin Deposited 2022-09-30 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 3 PDB declaration: trimeric |
Chain AAA
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 27 SO4 SULFATE ION × 3 AU GOLD ION × 3 CL CHLORIDE ION × 9 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.2；293 K；0.8 M ammonium sulphate
0.1 M TrisHCl pH 7.4
60 mM cadmium sulphate
|
Resolution 1.24 Å R-free 0.180 |
| 8H8L Crystal structure of apo-R52F/E56F/R59F/E63F-rHLFr Deposited 2022-10-23 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52F,E56F,R59F,E63F | EDO 1,2-ETHANEDIOL × 24 CD CADMIUM ION × 240 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.50 Å R-free 0.171 |
| 8H8M Crystal structure of apo-E53F/E57F/E60F/E64F-rHLFr Deposited 2022-10-23 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53F,E57F,E60F,E64F | EDO 1,2-ETHANEDIOL × 48 CD CADMIUM ION × 192 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.50 Å R-free 0.176 |
| 8H8N Crystal structure of apo-R52Y/E56Y/R59Y/E63Y-rHLFr Deposited 2022-10-23 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52Y,E56Y,R59Y,E63Y | EDO 1,2-ETHANEDIOL × 48 CD CADMIUM ION × 192 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.50 Å R-free 0.178 |
| 8H8O Crystal structure of apo-R52W/E56W/R59W/E63W-rHLFr Deposited 2022-10-23 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52W,E56W,R59W,E63W | EDO 1,2-ETHANEDIOL × 48 CD CADMIUM ION × 168 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.50 Å R-free 0.179 |
| 8I6L Crystal structure of horse spleen L-ferritin at -180deg Celsius. Deposited 2023-01-28 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 96 CD CADMIUM ION × 216 SO4 SULFATE ION × 96 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 8；293 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.50 Å R-free 0.174 |
| 8I77 Crystal structure of horse spleen L-ferritin A115V mutant at -180deg Celsius. Deposited 2023-01-31 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：A115V | CD CADMIUM ION × 120 SO4 SULFATE ION × 96 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.50 Å R-free 0.177 |
| 8I81 Crystal structure of horse spleen L-ferritin A115G mutant at -180deg Celsius. Deposited 2023-02-02 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：A115G | CD CADMIUM ION × 168 SO4 SULFATE ION × 72 EDO 1,2-ETHANEDIOL × 96 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.50 Å R-free 0.168 |
| 8I8Q Crystal structure of horse spleen L-ferritin H114A mutant at -180deg Celsius. Deposited 2023-02-05 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：H114A | CD CADMIUM ION × 192 SO4 SULFATE ION × 72 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.50 Å R-free 0.174 |
| 8I8U Crystal structure of horse spleen L-ferritin S118A mutant at -180deg Celsius. Deposited 2023-02-05 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：S118A | EDO 1,2-ETHANEDIOL × 72 SO4 SULFATE ION × 72 CD CADMIUM ION × 96 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.203 |
| 8J0U Crystal structure of horse spleen L-ferritin A115T mutant at -180deg Celsius. Deposited 2023-04-12 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：A115T | EDO 1,2-ETHANEDIOL × 72 CD CADMIUM ION × 216 SO4 SULFATE ION × 72 CL CHLORIDE ION × 24 NA SODIUM ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.50 Å R-free 0.181 |
| 8J0V Crystal structure of horse spleen L-ferritin at -100deg Celsius. Deposited 2023-04-12 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 96 CD CADMIUM ION × 72 SO4 SULFATE ION × 96 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.191 |
| 8J0W Crystal structure of horse spleen L-ferritin at -40deg Celsius. Deposited 2023-04-12 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | SO4 SULFATE ION × 72 CD CADMIUM ION × 72 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.175 |
| 8J0X Crystal structure of horse spleen L-ferritin at -20deg Celsius. Deposited 2023-04-12 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 96 CL CHLORIDE ION × 24 SO4 SULFATE ION × 48 EDO 1,2-ETHANEDIOL × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.169 |
| 8J0Y Crystal structure of horse spleen L-ferritin at 20deg Celsius. Deposited 2023-04-12 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | SO4 SULFATE ION × 48 CD CADMIUM ION × 72 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.190 |
| 8J0Z Crystal structure of horse spleen L-ferritin at -180deg Celsius cooled from -40deg Celsius. Deposited 2023-04-12 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | SO4 SULFATE ION × 96 CD CADMIUM ION × 96 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.202 |
| 8J10 Crystal structure of horse spleen L-ferritin at -180deg Celsius cooled from -20deg Celsius. Deposited 2023-04-12 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 72 CL CHLORIDE ION × 24 SO4 SULFATE ION × 96 EDO 1,2-ETHANEDIOL × 96 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.206 |
| 8J11 Crystal structure of horse spleen L-ferritin at 0deg Celsius. Deposited 2023-04-12 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 24 SO4 SULFATE ION × 48 CD CADMIUM ION × 96 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.186 |
| 8J16 Crystal structure of horse spleen L-ferritin at -80deg Celsius. Deposited 2023-04-12 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 48 SO4 SULFATE ION × 96 CD CADMIUM ION × 72 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.209 |
| 8KH2 Crystal structure of horse-spleen L-ferritin fused with amyloid beta peptide (1-42). Deposited 2023-08-21 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 216 SO4 SULFATE ION × 72 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate (12-20 mM)
|
Resolution 2.00 Å R-free 0.258 |
| 9E6X Crystal structure of ferritin Deposited 2024-10-31 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
3–172（170 aa）
|
Not recorded | CD CADMIUM ION × 144 FE FE (III) ION × 24 GOL GLYCEROL × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.6M (NH4)2SO4, 50mM CdSO4, 0.1M Hepes, pH7.5
|
Resolution 2.50 Å R-free 0.256 |
| 9KF5 Crystal structure of Ferritin mutant(E53H/E57H) Deposited 2024-11-05 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53H/E57H | EDO 1,2-ETHANEDIOL × 48 CD CADMIUM ION × 144 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Precipitant: (NH4)2SO4 (0.5-1.0M); CdSO4(12-20mM)
Protein: 15-20mg/ml
Crystallization drop: 1:1
|
Resolution 1.50 Å R-free 0.241 |
| 9KF7 Crystal structure of ferritin mutant (R52H/E56H/R59H/E63H) Deposited 2024-11-05 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52H/E56H/R59H/E63H | EDO 1,2-ETHANEDIOL × 48 CD CADMIUM ION × 144 SO4 SULFATE ION × 72 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Precipitant: (NH4)2SO4 (0.5-1.0M), CdSO4(12-20mM)
Protein: 15-20mg/ml
Crystallization drop: 1:1
|
Resolution 1.50 Å R-free 0.187 |
| 9KF8 Crystal structure of ferritin mutant (E53H/E57H/E60H/R64H) Deposited 2024-11-05 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53H/E57H/E60H/R64H | EDO 1,2-ETHANEDIOL × 72 CD CADMIUM ION × 240 SO4 SULFATE ION × 120 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Precipitant: (NH4)2SO4 (0.5-1.0M), CdSO4(12-20mM)
Protein: 15-20mg/ml
Crystallization drop: 1:1
|
Resolution 1.50 Å R-free 0.171 |
| 9KF9 Crystal structure of ferritin mutant(E53H/E56H/E57H/R59H/E60H/E63H) Deposited 2024-11-05 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53H/E56H/E57H/R59H/E60H/E63H | EDO 1,2-ETHANEDIOL × 24 CD CADMIUM ION × 48 SO4 SULFATE ION × 120 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Precipitant: (NH4)2SO4 (0.5-1.0M), CdSO4(12-20mM)
Protein: 15-20mg/ml
Crystallization drop: 1:1
|
Resolution 1.50 Å R-free 0.225 |
| 9KFA Crystal structure of ferritin mutantFr-H8 (R52H/E53H/E56H/E57H/R59H/E60H/E63H/R64H) Deposited 2024-11-05 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52H/E53H/E56H/E57H/R59H/E60H/E63H/R64H | CD CADMIUM ION × 192 EDO 1,2-ETHANEDIOL × 24 SO4 SULFATE ION × 48 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Precipitant: (NH4)2SO4 (0.5-1.0M), CdSO4(12-20mM)
Protein: 15-20mg/ml
Crystallization drop: 1:1
|
Resolution 1.50 Å R-free 0.242 |
| 9KKP Crystal structure of Horse spleen L-ferritin mutant (E53F/E56F/E57F/R59F/E60F/E63F) with Nile Red Deposited 2024-11-14 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53F/E56F/E57F/R59F/E60F/E63F | CD CADMIUM ION × 144 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 72 A1L52 Nile Red × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.60 Å R-free 0.186 |
| 9KKR Crystal structure of Horse spleen L-ferritin mutant (E53F/E56F/E57F/R59F/E60F/E63F) Deposited 2024-11-14 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53F/E56F/E57F/R59F/E60F/E63F | CD CADMIUM ION × 168 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.50 Å R-free 0.203 |
| 9KLE Crystal structure of Horse spleen L-ferritin mutant (R52F/E56F/R59F/E63F) with Nile Red Deposited 2024-11-14 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52F/E56F/R59F/E63F | CD CADMIUM ION × 96 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 24 A1L52 Nile Red × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.65 Å R-free 0.209 |
| 9KN7 Crystal structure of Horse spleen L-ferritin mutant (Fr-E53F/E56F/E57F/R59L/E60F/E63F) Deposited 2024-11-18 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53F/E56F/E57F/R59L/E60F/E63F | CD CADMIUM ION × 192 SO4 SULFATE ION × 48 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 96 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.50 Å R-free 0.178 |
| 9KN8 Crystal structure of Horse spleen L-ferritin mutant (E53F/E56F/E57F/R59F/E60F/E63F) with Coumarin 153 Deposited 2024-11-18 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53F/E56F/E57F/R59F/E60F/E63F | CD CADMIUM ION × 120 SO4 SULFATE ION × 24 A1L54 Coumarin 153 × 24 EDO 1,2-ETHANEDIOL × 72 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.64 Å R-free 0.208 |
| 9KP2 Crystal structure of Horse spleen L-ferritin mutant (E56F/R59F) with Nile Red Deposited 2024-11-22 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E56F/R59F | CD CADMIUM ION × 216 CL CHLORIDE ION × 24 SO4 SULFATE ION × 48 EDO 1,2-ETHANEDIOL × 96 A1L52 Nile Red × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.50 Å R-free 0.190 |
| 9KP5 Crystal structure of Horse spleen L-ferritin mutant (E56F/R59F) Deposited 2024-11-22 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E56F/R59F | CD CADMIUM ION × 168 SO4 SULFATE ION × 48 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.50 Å R-free 0.188 |
| 9KP7 Crystal structure of Horse spleen L-ferritin mutant (R59F) with Nile Red Deposited 2024-11-22 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R59F | CD CADMIUM ION × 144 CL CHLORIDE ION × 24 SO4 SULFATE ION × 48 EDO 1,2-ETHANEDIOL × 96 A1L52 Nile Red × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.50 Å R-free 0.196 |
| 9KPA Crystal structure of Horse spleen L-ferritin mutant (R59F) Deposited 2024-11-22 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R59F | CD CADMIUM ION × 144 SO4 SULFATE ION × 48 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.50 Å R-free 0.194 |
| 9KRS Crystal structure of Horse spleen L-ferritin mutant (Fr-E53F/E56F/E57F/R59A/E60F/E63F) Deposited 2024-11-28 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53F/E56F/E57F/R59A/E60F/E63F | CD CADMIUM ION × 144 SO4 SULFATE ION × 48 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 96 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.53 Å R-free 0.212 |
138 other PDB entries and 138 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | FRIL_HORSE |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 1–174； UniProt 2–175 |
