Bromodomain-containing protein 1
Homo sapiens
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain A； UniProt 555–688 | Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350 | Resolution 1.61 Å R-free 0.213 |
| 2 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain B； UniProt 555–688 | Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350 | Resolution 1.61 Å R-free 0.213 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 5PPC | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 2KU3 Solution structure of BRD1 PHD1 finger Deposited 2010-02-12 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
208–269（62 aa）
Fragment：PHD Zinc finger domain, residues 208-269
|
Mutation：C218S, C225S | ZN ZINC ION × 2 |
SOLUTION NMR
NMR measurement conditions
pH 6.7；293 K；Ionic strength (raw mmCIF value) 0.15；Pressure ambient
NMR measurement conditions
293 K；Ionic strength (raw mmCIF value) 0.15
NMR sample composition
2mM ZINC ION; 1mM [U-100% 13C; U-100% 15N] protein; 150mM sodium chloride; 20mM Bis-Tris; 90% H2O/10% D2O | 90% H2O/10% D2O
NMR sample composition
2mM ZINC ION; 1mM [U-100% 13C; U-100% 15N] protein; 20mM Bis-Tris; 150mM sodium chloride; 100% D2O | 100% D2O
|
Resolution not provided |
| 2L43 Structural basis for histone code recognition by BRPF2-PHD1 finger Deposited 2010-10-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
208–269（62 aa）
|
Mutation：C29S, C36S | ZN ZINC ION × 2 |
SOLUTION NMR
NMR measurement conditions
pH 6.7；293 K；Ionic strength (raw mmCIF value) 0.15；Pressure ambient
NMR sample composition
0.8mM [U-100% 13C; U-100% 15N] protein-1, 1.6mM ZINC ION-2, 20mM Bis-Tris-3, 150mM sodium chloride-4, 90% H2O/10% D2O | 90% H2O/10% D2O
NMR sample composition
0.8mM [U-100% 13C; U-100% 15N] protein-5, 1.6mM ZINC ION-6, 20mM Bis-Tris-7, 150mM sodium chloride-8, 100% D2O | 100% D2O
|
Resolution not provided |
| 2LQ6 Solution structure of BRD1 PHD2 finger Deposited 2012-02-25 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
317–394（78 aa）
Fragment：UNP residues 317-394
|
Mutation：C338S, C393S | ZN ZINC ION × 2 |
SOLUTION NMR
NMR measurement conditions
pH 6.5；293 K；Ionic strength (raw mmCIF value) 150；Pressure ambient
NMR sample composition
0.3 mM [U-15N] protein-1, 90% H2O/10% D2O | 90% H2O/10% D2O
NMR sample composition
0.4 mM [U-13C; U-15N] protein-2, 90% H2O/10% D2O | 90% H2O/10% D2O
NMR sample composition
0.4 mM [U-13C; U-15N] protein-3, 100% D2O | 100% D2O
|
Resolution not provided |
| 3LYI PWWP Domain of Human Bromodomain-Containing Protein 1 Deposited 2010-02-26 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
925–1049（125 aa）
Fragment：PWWP Domain, residues 925-1049
|
Not recorded | OCS CYSTEINESULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；293 K；30% PEG2000-MME, 0.15M KBr, pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.10 Å R-free 0.276 |
| 3LYI PWWP Domain of Human Bromodomain-Containing Protein 1 Deposited 2010-02-26 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
925–1049（125 aa）
Fragment：PWWP Domain, residues 925-1049
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；293 K；30% PEG2000-MME, 0.15M KBr, pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.10 Å R-free 0.276 |
| 3RCW Crystal Structure of the bromodomain of human BRD1 Deposited 2011-03-31 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
556–688（133 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 4.8；277 K；32.5% PEG3350, 5% EtGly, 0.1M Acetate, pH 4.8, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.21 Å R-free 0.275 |
| 3RCW Crystal Structure of the bromodomain of human BRD1 Deposited 2011-03-31 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
556–688（133 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 4.8；277 K；32.5% PEG3350, 5% EtGly, 0.1M Acetate, pH 4.8, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.21 Å R-free 0.275 |
| 3RCW Crystal Structure of the bromodomain of human BRD1 Deposited 2011-03-31 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
556–688（133 aa）
|
Not recorded | MB3 1-methylpyrrolidin-2-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 4.8；277 K；32.5% PEG3350, 5% EtGly, 0.1M Acetate, pH 4.8, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.21 Å R-free 0.275 |
| 3RCW Crystal Structure of the bromodomain of human BRD1 Deposited 2011-03-31 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
556–688（133 aa）
|
Not recorded | ACT ACETATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 4.8；277 K；32.5% PEG3350, 5% EtGly, 0.1M Acetate, pH 4.8, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.21 Å R-free 0.275 |
| 3RCW Crystal Structure of the bromodomain of human BRD1 Deposited 2011-03-31 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 5 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain E
556–688（133 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 4.8；277 K；32.5% PEG3350, 5% EtGly, 0.1M Acetate, pH 4.8, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.21 Å R-free 0.275 |
| 3RCW Crystal Structure of the bromodomain of human BRD1 Deposited 2011-03-31 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 6 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain F
556–688（133 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 4.8；277 K；32.5% PEG3350, 5% EtGly, 0.1M Acetate, pH 4.8, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.21 Å R-free 0.275 |
| 3RCW Crystal Structure of the bromodomain of human BRD1 Deposited 2011-03-31 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 7 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain G
556–688（133 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 4.8；277 K；32.5% PEG3350, 5% EtGly, 0.1M Acetate, pH 4.8, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.21 Å R-free 0.275 |
| 3RCW Crystal Structure of the bromodomain of human BRD1 Deposited 2011-03-31 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 8 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain H
556–688（133 aa）
|
Not recorded | ACT ACETATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 4.8；277 K；32.5% PEG3350, 5% EtGly, 0.1M Acetate, pH 4.8, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.21 Å R-free 0.275 |
| 4Z02 Crystal structure of BRD1 in complex with Isoquinoline-3-carboxylic acid Deposited 2015-03-25 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
925–1049（125 aa）
Fragment：UNP residues 925-1049
|
Not recorded | 4K8 isoquinoline-3-carboxylic acid × 1 EDO 1,2-ETHANEDIOL × 1 UNX UNKNOWN LIGAND × 7 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；293 K；28% PEG 2K MME, 0.1 M Bis-Tris pH6.5
|
Resolution 1.87 Å R-free 0.257 |
| 4Z02 Crystal structure of BRD1 in complex with Isoquinoline-3-carboxylic acid Deposited 2015-03-25 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
925–1049（125 aa）
Fragment：UNP residues 925-1049
|
Not recorded | 4K8 isoquinoline-3-carboxylic acid × 1 UNX UNKNOWN LIGAND × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；293 K；28% PEG 2K MME, 0.1 M Bis-Tris pH6.5
|
Resolution 1.87 Å R-free 0.257 |
| 5AME Crystal structure of the bromodomain of human surface epitope engineered BRD1A in complex with 3D Consortium fragment 4-acetyl- piperazin-2-one (SGC - Diamond I04-1 fragment screening) Deposited 2015-03-10 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
556–688（133 aa）
Fragment：BROMODOMAIN AND PHD FINGER, RESIDUES 556-688
|
Mutation：YES | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.2；293 K；0.1M BIS-TRIS PH 6.2 , 31% PEG3350, 293 K, 12 HOURS
|
Resolution 1.58 Å R-free 0.204 |
| 5AME Crystal structure of the bromodomain of human surface epitope engineered BRD1A in complex with 3D Consortium fragment 4-acetyl- piperazin-2-one (SGC - Diamond I04-1 fragment screening) Deposited 2015-03-10 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
556–688（133 aa）
Fragment：BROMODOMAIN AND PHD FINGER, RESIDUES 556-688
|
Mutation：YES | PW3 4-acetyl-piperazin-2-one × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.2；293 K；0.1M BIS-TRIS PH 6.2 , 31% PEG3350, 293 K, 12 HOURS
|
Resolution 1.58 Å R-free 0.204 |
| 5AMF Crystal structure of the bromodomain of human surface epitope engineered BRD1A in complex with 3D Consortium fragment Ethyl 4,5,6,7- tetrahydro-1H-indazole-5-carboxylate (SGC - Diamond I04-1 fragment screening) Deposited 2015-03-10 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
556–688（133 aa）
Fragment：BROMODOMAIN AND PHD FINGER, RESIDUES 556-688
|
Mutation：YES | TWL ETHYL (5R)-4,5,6,7-TETRAHYDRO-1H-INDAZOLE-5-CARBOXYLATE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.2；293 K；0.1M BIS-TRIS PH 7.0 , 30% PEG3350, 293 K, 12 HOURS
|
Resolution 1.75 Å R-free 0.213 |
| 5AMF Crystal structure of the bromodomain of human surface epitope engineered BRD1A in complex with 3D Consortium fragment Ethyl 4,5,6,7- tetrahydro-1H-indazole-5-carboxylate (SGC - Diamond I04-1 fragment screening) Deposited 2015-03-10 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
556–688（133 aa）
Fragment：BROMODOMAIN AND PHD FINGER, RESIDUES 556-688
|
Mutation：YES | NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.2；293 K；0.1M BIS-TRIS PH 7.0 , 30% PEG3350, 293 K, 12 HOURS
|
Resolution 1.75 Å R-free 0.213 |
| 5FG6 Crystal structure of the bromodomain of human BRD1 (BRPF2) in complex with OF-1 chemical probe Deposited 2015-12-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
563–688（126 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 4 5XE 4-bromanyl-~{N}-(6-methoxy-1,3-dimethyl-2-oxidanylidene-benzimidazol-5-yl)-2-methyl-benzenesulfonamide × 1 NI NICKEL (II) ION × 1 PO4 PHOSPHATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；277.15 K；0.1 M tri-sodium citrate dihydrate pH 5.6, 1 M ammoinum dihydrogen phosphate
|
Resolution 1.10 Å R-free 0.197 |
| 5N49 BRPF2 in complex with Compound 7 Deposited 2017-02-10 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Not recorded | 8LW 2-(1,3,6-trimethyl-2-oxidanylidene-benzimidazol-5-yl)benzo[de]isoquinoline-1,3-dione × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；295 K；100 mM bis-tris pH 6.5, 30% (w/v) PEG 3350
|
Resolution 1.94 Å R-free 0.229 |
| 5N49 BRPF2 in complex with Compound 7 Deposited 2017-02-10 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；295 K；100 mM bis-tris pH 6.5, 30% (w/v) PEG 3350
|
Resolution 1.94 Å R-free 0.229 |
| 5PNX PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10128a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 M3I 5-methyl-1,2-oxazol-3-amine × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.47 Å R-free 0.212 |
| 5PNX PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10128a Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.47 Å R-free 0.212 |
| 5PNY PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10174a Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.48 Å R-free 0.209 |
| 5PNY PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10174a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 8S1 5-amino-1-(2-chlorophenyl)-1H-pyrazole-4-carbonitrile × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.48 Å R-free 0.209 |
| 5PNZ PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10162a Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.213 |
| 5PNZ PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10162a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 3 NA SODIUM ION × 1 8S4 1-[(4-methoxyphenyl)methyl]-1H-tetrazole × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.213 |
| 5PO0 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10146a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 3 8S7 N-(3-methyl-1,2-oxazol-5-yl)cyclopropanecarboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.46 Å R-free 0.211 |
| 5PO0 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10146a Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.46 Å R-free 0.211 |
| 5PO1 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10152a Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.210 |
| 5PO1 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10152a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 8SA 5-methyl-N-[(thiophen-2-yl)methyl]-1,2-oxazol-3-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.210 |
| 5PO2 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10132a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8SD 5-hydroxy-1,3-dihydro-2H-indol-2-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.67 Å R-free 0.209 |
| 5PO2 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10132a Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.67 Å R-free 0.209 |
| 5PO3 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10164a Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.70 Å R-free 0.212 |
| 5PO3 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10164a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 8SG N-(3-methyl-1,2-oxazol-5-yl)furan-2-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.70 Å R-free 0.212 |
| 5PO4 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10170a Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.49 Å R-free 0.197 |
| 5PO4 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10170a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 8SJ (4-nitrophenyl)methyl carbamimidothioate × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.49 Å R-free 0.197 |
| 5PO5 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10192a Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.44 Å R-free 0.200 |
| 5PO5 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10192a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 8SM 2-[1-methyl-3-(1H-pyrrol-1-yl)-1H-pyrazol-4-yl]pyridine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.44 Å R-free 0.200 |
| 5PO6 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10157a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8SS 4-(4-bromophenyl)-1H-pyrazol-3-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.61 Å R-free 0.211 |
| 5PO6 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10157a Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.61 Å R-free 0.211 |
| 5PO7 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11083a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8SV 1,3-dimethyl-5-(methylamino)-6-nitro-1,3-dihydro-2H-benzimidazol-2-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.50 Å R-free 0.216 |
| 5PO7 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11083a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8SV 1,3-dimethyl-5-(methylamino)-6-nitro-1,3-dihydro-2H-benzimidazol-2-one × 1 NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.50 Å R-free 0.216 |
| 5PO8 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N07808b Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8SY 6-amino-1-methyl-3,4-dihydroquinolin-2(1H)-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.50 Å R-free 0.209 |
| 5PO8 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N07808b Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8SY 6-amino-1-methyl-3,4-dihydroquinolin-2(1H)-one × 2 NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.50 Å R-free 0.209 |
| 5PO9 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N07950b Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8T7 1-methyl-4-phenyl-3-(trifluoromethyl)-1H-pyrazol-5-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.12 Å R-free 0.253 |
| 5PO9 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N07950b Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8T7 1-methyl-4-phenyl-3-(trifluoromethyl)-1H-pyrazol-5-amine × 1 NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.12 Å R-free 0.253 |
| 5POA PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10186a Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.209 |
| 5POA PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10186a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 8TA 2-[5-(1H-pyrrol-1-yl)-1H-pyrazol-4-yl]pyridine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.209 |
| 5POB PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with E13683b Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8TD 5-amino-1,3-dimethyl-1,3-dihydro-2H-benzimidazol-2-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.78 Å R-free 0.212 |
| 5POB PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with E13683b Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8TD 5-amino-1,3-dimethyl-1,3-dihydro-2H-benzimidazol-2-one × 1 NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.78 Å R-free 0.212 |
| 5POC PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11081a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8TG 7-bromo-1-methyl-6-nitroquinolin-2(1H)-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.48 Å R-free 0.208 |
| 5POC PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11081a Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.48 Å R-free 0.208 |
| 5POD PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N07807b Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8T1 6-amino-1-methylquinolin-2(1H)-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.210 |
| 5POD PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N07807b Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8T1 6-amino-1-methylquinolin-2(1H)-one × 1 NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.210 |
| 5POE PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10188a and N07807b Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8T1 6-amino-1-methylquinolin-2(1H)-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.207 |
| 5POE PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10188a and N07807b Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8T1 6-amino-1-methylquinolin-2(1H)-one × 1 NA SODIUM ION × 1 8T4 1-methyl-4-phenyl-5-(1H-pyrrol-1-yl)-1H-pyrazole × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.207 |
| 5POF PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10941a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 8RV N-(1-benzylpiperidin-4-yl)acetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.27 Å R-free 0.249 |
| 5POF PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10941a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8RV N-(1-benzylpiperidin-4-yl)acetamide × 1 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.27 Å R-free 0.249 |
| 5POG PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11063a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8TJ N-methylthieno[2,3-b]pyridine-2-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.77 Å R-free 0.246 |
| 5POG PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11063a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8TJ N-methylthieno[2,3-b]pyridine-2-carboxamide × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.77 Å R-free 0.246 |
| 5POH PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11029a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8TP N-[2-(phenylamino)ethyl]acetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.61 Å R-free 0.225 |
| 5POH PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11029a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8TP N-[2-(phenylamino)ethyl]acetamide × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.61 Å R-free 0.225 |
| 5POI PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11016a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8RY N-methylpyrimidine-2-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.37 Å R-free 0.228 |
| 5POI PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11016a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8RY N-methylpyrimidine-2-carboxamide × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.37 Å R-free 0.228 |
| 5POJ PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10941a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8RV N-(1-benzylpiperidin-4-yl)acetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.236 |
| 5POJ PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10941a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 1 8RV N-(1-benzylpiperidin-4-yl)acetamide × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.236 |
| 5POK PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10908a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8RS 1-(4-phenylpiperazin-1-yl)ethan-1-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.228 |
| 5POK PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10908a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8RS 1-(4-phenylpiperazin-1-yl)ethan-1-one × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.228 |
| 5POL PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10971a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8RP 1-(6,7-dimethoxy-3,4-dihydroisoquinolin-2(1H)-yl)ethan-1-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.225 |
| 5POL PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10971a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8RP 1-(6,7-dimethoxy-3,4-dihydroisoquinolin-2(1H)-yl)ethan-1-one × 1 NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.225 |
| 5POM PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10958a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 8RM N-methylquinoline-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.54 Å R-free 0.239 |
| 5POM PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10958a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8RM N-methylquinoline-3-carboxamide × 1 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.54 Å R-free 0.239 |
| 5PON PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10980a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8RA 1-[4-(pyridin-2-yl)piperazin-1-yl]ethan-1-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.218 |
| 5PON PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10980a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8RA 1-[4-(pyridin-2-yl)piperazin-1-yl]ethan-1-one × 1 NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.218 |
| 5POO PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10966a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 8TS 6-(4-acetylpiperazin-1-yl)pyridine-3-carbonitrile × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.50 Å R-free 0.230 |
| 5POO PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10966a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8TS 6-(4-acetylpiperazin-1-yl)pyridine-3-carbonitrile × 1 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.50 Å R-free 0.230 |
| 5POP PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10987a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8TV 1-[4-(pyridin-4-yl)piperazin-1-yl]ethan-1-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.242 |
| 5POP PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10987a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 1 8TV 1-[4-(pyridin-4-yl)piperazin-1-yl]ethan-1-one × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.242 |
| 5POQ PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10974a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8TY 1-[4-(methylsulfonyl)piperazin-1-yl]ethan-1-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.97 Å R-free 0.280 |
| 5POQ PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10974a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8TY 1-[4-(methylsulfonyl)piperazin-1-yl]ethan-1-one × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.97 Å R-free 0.280 |
| 5POR PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10982a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 PW3 4-acetyl-piperazin-2-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.227 |
| 5POR PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10982a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 PW3 4-acetyl-piperazin-2-one × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.227 |
| 5POS PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10919a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 3 8U1 N-[(4-methoxyphenyl)methyl]acetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.75 Å R-free 0.222 |
| 5POS PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10919a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8U1 N-[(4-methoxyphenyl)methyl]acetamide × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.75 Å R-free 0.222 |
| 5POT PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10931a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8U4 N-[(3-chlorophenyl)methyl]acetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.217 |
| 5POT PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10931a Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.217 |
| 5POU PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10954a Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.43 Å R-free 0.213 |
| 5POU PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10954a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 1 NA SODIUM ION × 1 8U7 N-(1-benzylpiperidin-4-yl)-N'-methylurea × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.43 Å R-free 0.213 |
| 5POV PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11063a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8TJ N-methylthieno[2,3-b]pyridine-2-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.57 Å R-free 0.220 |
| 5POV PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11063a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | 8TJ N-methylthieno[2,3-b]pyridine-2-carboxamide × 1 NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.57 Å R-free 0.220 |
| 5POW PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10894b Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 3 8UA N-[(pyridin-2-yl)methyl]acetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.77 Å R-free 0.217 |
| 5POW PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N10894b Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8UA N-[(pyridin-2-yl)methyl]acetamide × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.77 Å R-free 0.217 |
| 5POX PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11075a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8UG ethyl (5S)-4,5,6,7-tetrahydro-2H-indazole-5-carboxylate × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.75 Å R-free 0.216 |
| 5POX PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11075a Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.75 Å R-free 0.216 |
| 5POY PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11029a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8TP N-[2-(phenylamino)ethyl]acetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.76 Å R-free 0.274 |
| 5POY PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11029a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8TP N-[2-(phenylamino)ethyl]acetamide × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.76 Å R-free 0.274 |
| 5POZ PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11039a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 8UJ N-{[(3R)-1-cyclopentyl-5-oxopyrrolidin-3-yl]methyl}methanesulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.50 Å R-free 0.225 |
| 5POZ PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11039a Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.50 Å R-free 0.225 |
| 5PP0 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11009a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.61 Å R-free 0.242 |
| 5PP0 PanDDA analysis group deposition -- Crystal Structure of BRD1 in complex with N11009a Deposited 2017-02-07 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 8UD 2-amino-N-methylpyridine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.61 Å R-free 0.242 |
| 5PP1 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 1) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.35 Å R-free 0.266 |
| 5PP1 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 1) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.35 Å R-free 0.266 |
| 5PP2 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 2) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.61 Å R-free 0.215 |
| 5PP2 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 2) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.61 Å R-free 0.215 |
| 5PP3 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 3) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.58 Å R-free 0.301 |
| 5PP3 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 3) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.58 Å R-free 0.301 |
| 5PP4 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 4) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.92 Å R-free 0.220 |
| 5PP4 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 4) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.92 Å R-free 0.220 |
| 5PP5 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 5) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.87 Å R-free 0.211 |
| 5PP5 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 5) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.87 Å R-free 0.211 |
| 5PP6 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 6) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.204 |
| 5PP6 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 6) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.204 |
| 5PP7 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 7) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.241 |
| 5PP7 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 7) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.241 |
| 5PP8 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 8) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.74 Å R-free 0.219 |
| 5PP8 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 8) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.74 Å R-free 0.219 |
| 5PP9 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 9) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.231 |
| 5PP9 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 9) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.231 |
| 5PPA PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 10) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.91 Å R-free 0.223 |
| 5PPA PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 10) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.91 Å R-free 0.223 |
| 5PPB PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 11) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.48 Å R-free 0.201 |
| 5PPB PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 11) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.48 Å R-free 0.201 |
| 5PPD PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 13) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.67 Å R-free 0.210 |
| 5PPD PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 13) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.67 Å R-free 0.210 |
| 5PPE PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 14) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.46 Å R-free 0.206 |
| 5PPE PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 14) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.46 Å R-free 0.206 |
| 5PPF PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 16) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.64 Å R-free 0.230 |
| 5PPF PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 16) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.64 Å R-free 0.230 |
| 5PPG PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 17) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.221 |
| 5PPG PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 17) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.221 |
| 5PPH PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 18) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.89 Å R-free 0.231 |
| 5PPH PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 18) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.89 Å R-free 0.231 |
| 5PPI PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 19) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.215 |
| 5PPI PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 19) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.215 |
| 5PPJ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 20) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.61 Å R-free 0.215 |
| 5PPJ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 20) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.61 Å R-free 0.215 |
| 5PPK PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 21) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.87 Å R-free 0.231 |
| 5PPK PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 21) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.87 Å R-free 0.231 |
| 5PPL PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 22) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.223 |
| 5PPL PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 22) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.223 |
| 5PPM PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 23) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.87 Å R-free 0.232 |
| 5PPM PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 23) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.87 Å R-free 0.232 |
| 5PPN PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 24) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.80 Å R-free 0.232 |
| 5PPN PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 24) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.80 Å R-free 0.232 |
| 5PPO PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 25) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.84 Å R-free 0.233 |
| 5PPO PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 25) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.84 Å R-free 0.233 |
| 5PPP PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 26) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.68 Å R-free 0.208 |
| 5PPP PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 26) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.68 Å R-free 0.208 |
| 5PPQ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 27) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.70 Å R-free 0.208 |
| 5PPQ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 27) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.70 Å R-free 0.208 |
| 5PPR PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 28) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.69 Å R-free 0.470 |
| 5PPR PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 28) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.69 Å R-free 0.470 |
| 5PPS PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 29) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.212 |
| 5PPS PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 29) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.212 |
| 5PPT PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 30) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.61 Å R-free 0.207 |
| 5PPT PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 30) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.61 Å R-free 0.207 |
| 5PPU PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 31) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.216 |
| 5PPU PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 31) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.216 |
| 5PPV PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 32) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.70 Å R-free 0.206 |
| 5PPV PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 32) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.70 Å R-free 0.206 |
| 5PPW PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 33) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.45 Å R-free 0.203 |
| 5PPW PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 33) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.45 Å R-free 0.203 |
| 5PPX PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 34) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.44 Å R-free 0.202 |
| 5PPX PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 34) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.44 Å R-free 0.202 |
| 5PPY PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 35) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.45 Å R-free 0.197 |
| 5PPY PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 35) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.45 Å R-free 0.197 |
| 5PPZ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 36) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.209 |
| 5PPZ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 36) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.209 |
| 5PQ0 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 37) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.81 Å R-free 0.233 |
| 5PQ0 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 37) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.81 Å R-free 0.233 |
| 5PQ1 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 38) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.203 |
| 5PQ1 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 38) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.203 |
| 5PQ2 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 39) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.47 Å R-free 0.211 |
| 5PQ2 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 39) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.47 Å R-free 0.211 |
| 5PQ3 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 40) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.72 Å R-free 0.222 |
| 5PQ3 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 40) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.72 Å R-free 0.222 |
| 5PQ4 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 41) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.224 |
| 5PQ4 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 41) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.224 |
| 5PQ5 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 42) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.60 Å R-free 0.223 |
| 5PQ5 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 42) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.60 Å R-free 0.223 |
| 5PQ6 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 43) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.64 Å R-free 0.201 |
| 5PQ6 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 43) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.64 Å R-free 0.201 |
| 5PQ7 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 44) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.211 |
| 5PQ7 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 44) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.211 |
| 5PQ8 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 45) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.65 Å R-free 0.219 |
| 5PQ8 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 45) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.65 Å R-free 0.219 |
| 5PQ9 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 46) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.60 Å R-free 0.211 |
| 5PQ9 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 46) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.60 Å R-free 0.211 |
| 5PQA PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 47) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.78 Å R-free 0.206 |
| 5PQA PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 47) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.78 Å R-free 0.206 |
| 5PQB PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 48) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.215 |
| 5PQB PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 48) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.215 |
| 5PQC PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 49) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.45 Å R-free 0.206 |
| 5PQC PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 49) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.45 Å R-free 0.206 |
| 5PQD PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 50) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.65 Å R-free 0.218 |
| 5PQD PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 50) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.65 Å R-free 0.218 |
| 5PQE PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 51) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.213 |
| 5PQE PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 51) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.213 |
| 5PQF PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 52) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.65 Å R-free 0.225 |
| 5PQF PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 52) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.65 Å R-free 0.225 |
| 5PQG PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 53) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.207 |
| 5PQG PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 53) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.207 |
| 5PQH PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 54) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.197 |
| 5PQH PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 54) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.197 |
| 5PQI PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 55) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.33 Å R-free 0.202 |
| 5PQI PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 55) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.33 Å R-free 0.202 |
| 5PQJ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 56) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.59 Å R-free 0.210 |
| 5PQJ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 56) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.59 Å R-free 0.210 |
| 5PQK PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 57) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.206 |
| 5PQK PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 57) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.206 |
| 5PQL PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 58) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.207 |
| 5PQL PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 58) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.207 |
| 5PQM PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 59) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.56 Å R-free 0.238 |
| 5PQM PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 59) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.56 Å R-free 0.238 |
| 5PQN PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 60) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.00 Å R-free 0.229 |
| 5PQN PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 60) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.00 Å R-free 0.229 |
| 5PQO PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 61) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.75 Å R-free 0.215 |
| 5PQO PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 61) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.75 Å R-free 0.215 |
| 5PQP PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 62) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.97 Å R-free 0.240 |
| 5PQP PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 62) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.97 Å R-free 0.240 |
| 5PQQ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 63) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.30 Å R-free 0.236 |
| 5PQQ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 63) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.30 Å R-free 0.236 |
| 5PQR PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 64) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.43 Å R-free 0.233 |
| 5PQR PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 64) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.43 Å R-free 0.233 |
| 5PQS PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 65) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.217 |
| 5PQS PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 65) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.217 |
| 5PQT PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 66) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.89 Å R-free 0.218 |
| 5PQT PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 66) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.89 Å R-free 0.218 |
| 5PQU PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 67) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.00 Å R-free 0.260 |
| 5PQU PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 67) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.00 Å R-free 0.260 |
| 5PQV PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 68) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.97 Å R-free 0.231 |
| 5PQV PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 68) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.97 Å R-free 0.231 |
| 5PQW PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 69) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.00 Å R-free 0.228 |
| 5PQW PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 69) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.00 Å R-free 0.228 |
| 5PQX PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 70) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.95 Å R-free 0.226 |
| 5PQX PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 70) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.95 Å R-free 0.226 |
| 5PQY PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 71) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.89 Å R-free 0.214 |
| 5PQY PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 71) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.89 Å R-free 0.214 |
| 5PQZ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 72) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.58 Å R-free 0.242 |
| 5PQZ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 72) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.58 Å R-free 0.242 |
| 5PR0 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 73) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.23 Å R-free 0.258 |
| 5PR0 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 73) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.23 Å R-free 0.258 |
| 5PR1 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 74) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.10 Å R-free 0.224 |
| 5PR1 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 74) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.10 Å R-free 0.224 |
| 5PR2 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 75) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.10 Å R-free 0.240 |
| 5PR2 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 75) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.10 Å R-free 0.240 |
| 5PR4 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 77) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.234 |
| 5PR4 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 77) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.234 |
| 5PR5 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 78) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.95 Å R-free 0.217 |
| 5PR5 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 78) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.95 Å R-free 0.217 |
| 5PR6 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 79) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.80 Å R-free 0.213 |
| 5PR6 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 79) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.80 Å R-free 0.213 |
| 5PR7 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 80) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.80 Å R-free 0.214 |
| 5PR7 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 80) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.80 Å R-free 0.214 |
| 5PR8 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 81) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.92 Å R-free 0.219 |
| 5PR8 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 81) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.92 Å R-free 0.219 |
| 5PR9 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 82) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.216 |
| 5PR9 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 82) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.216 |
| 5PRA PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 83) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.87 Å R-free 0.215 |
| 5PRA PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 83) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.87 Å R-free 0.215 |
| 5PRB PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 84) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.23 Å R-free 0.237 |
| 5PRB PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 84) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.23 Å R-free 0.237 |
| 5PRD PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 85) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.90 Å R-free 0.215 |
| 5PRD PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 85) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.90 Å R-free 0.215 |
| 5PRE PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 86) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.73 Å R-free 0.217 |
| 5PRE PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 86) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.73 Å R-free 0.217 |
| 5PRF PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 87) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.218 |
| 5PRF PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 87) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.218 |
| 5PRG PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 88) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.68 Å R-free 0.273 |
| 5PRG PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 88) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.68 Å R-free 0.273 |
| 5PRH PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 89) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.95 Å R-free 0.212 |
| 5PRH PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 89) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.95 Å R-free 0.212 |
| 5PRI PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 90) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.90 Å R-free 0.211 |
| 5PRI PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 90) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.90 Å R-free 0.211 |
| 5PRJ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 91) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.17 Å R-free 0.242 |
| 5PRJ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 91) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.17 Å R-free 0.242 |
| 5PRK PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 92) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.23 Å R-free 0.362 |
| 5PRK PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 92) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.23 Å R-free 0.362 |
| 5PRL PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 93) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.75 Å R-free 0.511 |
| 5PRL PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 93) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.75 Å R-free 0.511 |
| 5PRM PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 94) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 3.58 Å R-free 0.341 |
| 5PRM PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 94) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 3.58 Å R-free 0.341 |
| 5PRO PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 95) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.204 |
| 5PRO PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 95) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.204 |
| 5PRP PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 96) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.45 Å R-free 0.199 |
| 5PRP PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 96) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.45 Å R-free 0.199 |
| 5PRQ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 97) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.68 Å R-free 0.216 |
| 5PRQ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 97) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.68 Å R-free 0.216 |
| 5PRR PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 98) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.233 |
| 5PRR PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 98) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.233 |
| 5PRS PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 99) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.72 Å R-free 0.219 |
| 5PRS PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 99) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.72 Å R-free 0.219 |
| 5PRT PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 100) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.89 Å R-free 0.235 |
| 5PRT PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 100) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.89 Å R-free 0.235 |
| 5PRU PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 101) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.217 |
| 5PRU PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 101) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.217 |
| 5PRV PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 102) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.223 |
| 5PRV PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 102) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.223 |
| 5PRW PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 103) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.65 Å R-free 0.221 |
| 5PRW PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 103) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.65 Å R-free 0.221 |
| 5PRX PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 104) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.87 Å R-free 0.233 |
| 5PRX PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 104) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.87 Å R-free 0.233 |
| 5PRY PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 105) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.80 Å R-free 0.249 |
| 5PRY PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 105) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.80 Å R-free 0.249 |
| 5PRZ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 106) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.216 |
| 5PRZ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 106) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.216 |
| 5PS0 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 107) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.68 Å R-free 0.217 |
| 5PS0 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 107) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.68 Å R-free 0.217 |
| 5PS1 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 108) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.71 Å R-free 0.230 |
| 5PS1 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 108) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.71 Å R-free 0.230 |
| 5PS2 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 109) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.228 |
| 5PS2 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 109) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.228 |
| 5PS3 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 110) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.93 Å R-free 0.233 |
| 5PS3 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 110) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.93 Å R-free 0.233 |
| 5PS4 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 111) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.70 Å R-free 0.223 |
| 5PS4 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 111) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.70 Å R-free 0.223 |
| 5PS5 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 113) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.15 Å R-free 0.232 |
| 5PS5 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 113) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.15 Å R-free 0.232 |
| 5PS6 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 114) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.221 |
| 5PS6 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 114) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.221 |
| 5PS7 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 115) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.21 Å R-free 0.282 |
| 5PS7 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 115) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.21 Å R-free 0.282 |
| 5PS8 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 116) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.93 Å R-free 0.238 |
| 5PS8 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 116) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.93 Å R-free 0.238 |
| 5PS9 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 117) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.71 Å R-free 0.268 |
| 5PS9 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 117) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.71 Å R-free 0.268 |
| 5PSA PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 118) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.64 Å R-free 0.220 |
| 5PSA PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 118) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.64 Å R-free 0.220 |
| 5PSB PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 119) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.213 |
| 5PSB PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 119) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.213 |
| 5PSC PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 120) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.68 Å R-free 0.217 |
| 5PSC PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 120) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.68 Å R-free 0.217 |
| 5PSD PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 121) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.245 |
| 5PSD PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 121) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.245 |
| 5PSE PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 122) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.19 Å R-free 0.296 |
| 5PSE PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 122) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.19 Å R-free 0.296 |
| 5PSF PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 123) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.31 Å R-free 0.252 |
| 5PSF PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 123) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.31 Å R-free 0.252 |
| 5PSG PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 124) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.247 |
| 5PSG PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 124) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.247 |
| 5PSH PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 125) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 3.43 Å R-free 0.499 |
| 5PSH PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 125) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 3.43 Å R-free 0.499 |
| 5PSI PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 126) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.218 |
| 5PSI PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 126) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.218 |
| 5PSJ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 127) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.38 Å R-free 0.214 |
| 5PSJ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 127) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.38 Å R-free 0.214 |
| 5PSK PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 128) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.38 Å R-free 0.213 |
| 5PSK PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 128) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.38 Å R-free 0.213 |
| 5PSL PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 129) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.39 Å R-free 0.209 |
| 5PSL PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 129) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.39 Å R-free 0.209 |
| 5PSM PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 130) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.213 |
| 5PSM PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 130) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.213 |
| 5PSN PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 131) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.48 Å R-free 0.212 |
| 5PSN PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 131) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.48 Å R-free 0.212 |
| 5PSO PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 132) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.212 |
| 5PSO PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 132) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.212 |
| 5PSP PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 133) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.215 |
| 5PSP PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 133) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.215 |
| 5PSQ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 134) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.43 Å R-free 0.213 |
| 5PSQ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 134) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.43 Å R-free 0.213 |
| 5PSR PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 135) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.59 Å R-free 0.212 |
| 5PSR PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 135) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.59 Å R-free 0.212 |
| 5PSS PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 136) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.59 Å R-free 0.215 |
| 5PSS PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 136) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.59 Å R-free 0.215 |
| 5PST PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 137) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.39 Å R-free 0.210 |
| 5PST PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 137) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.39 Å R-free 0.210 |
| 5PSU PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 138) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.218 |
| 5PSU PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 138) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.218 |
| 5PSV PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 139) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.218 |
| 5PSV PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 139) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.218 |
| 5PSW PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 140) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.215 |
| 5PSW PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 140) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.215 |
| 5PSX PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 141) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.59 Å R-free 0.213 |
| 5PSX PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 141) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.59 Å R-free 0.213 |
| 5PSY PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 142) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.223 |
| 5PSY PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 142) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.223 |
| 5PSZ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 143) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.212 |
| 5PSZ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 143) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.212 |
| 5PT0 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 144) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.43 Å R-free 0.215 |
| 5PT0 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 144) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.43 Å R-free 0.215 |
| 5PT1 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 145) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.54 Å R-free 0.218 |
| 5PT1 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 145) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.54 Å R-free 0.218 |
| 5PT2 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 146) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.221 |
| 5PT2 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 146) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.221 |
| 5PT3 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 147) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.70 Å R-free 0.219 |
| 5PT3 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 147) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.70 Å R-free 0.219 |
| 5PT4 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 148) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.54 Å R-free 0.214 |
| 5PT4 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 148) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.54 Å R-free 0.214 |
| 5PT5 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 149) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.76 Å R-free 0.225 |
| 5PT5 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 149) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.76 Å R-free 0.225 |
| 5PT6 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 150) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.214 |
| 5PT6 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 150) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.214 |
| 5PT7 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 151) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.214 |
| 5PT7 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 151) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.214 |
| 5PT8 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 152) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.66 Å R-free 0.221 |
| 5PT8 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 152) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.66 Å R-free 0.221 |
| 5PT9 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 153) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.47 Å R-free 0.219 |
| 5PT9 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 153) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.47 Å R-free 0.219 |
| 5PTA PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 154) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.19 Å R-free 0.243 |
| 5PTA PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 154) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.19 Å R-free 0.243 |
| 5PTB PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 155) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.88 Å R-free 0.241 |
| 5PTB PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 155) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.88 Å R-free 0.241 |
| 5PTC PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 156) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.78 Å R-free 0.221 |
| 5PTC PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 156) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.78 Å R-free 0.221 |
| 5PTE PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 157) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.220 |
| 5PTE PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 157) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.220 |
| 5PTF PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 158) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.49 Å R-free 0.220 |
| 5PTF PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 158) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.49 Å R-free 0.220 |
| 5PTG PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 159) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.46 Å R-free 0.218 |
| 5PTG PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 159) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.46 Å R-free 0.218 |
| 5PTH PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 160) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.223 |
| 5PTH PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 160) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.223 |
| 5PTJ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 161) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.69 Å R-free 0.224 |
| 5PTJ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 161) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.69 Å R-free 0.224 |
| 5PTK PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 162) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.48 Å R-free 0.216 |
| 5PTK PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 162) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.48 Å R-free 0.216 |
| 5PTL PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 163) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.209 |
| 5PTL PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 163) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.209 |
| 5PTM PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 164) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.41 Å R-free 0.218 |
| 5PTM PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 164) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.41 Å R-free 0.218 |
| 5PTN PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 165) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.47 Å R-free 0.216 |
| 5PTN PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 165) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.47 Å R-free 0.216 |
| 5PTO PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 167) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.67 Å R-free 0.216 |
| 5PTO PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 167) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.67 Å R-free 0.216 |
| 5PTQ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 168) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.49 Å R-free 0.222 |
| 5PTQ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 168) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.49 Å R-free 0.222 |
| 5PTR PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 169) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.219 |
| 5PTR PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 169) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.52 Å R-free 0.219 |
| 5PTS PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 170) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.45 Å R-free 0.220 |
| 5PTS PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 170) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.45 Å R-free 0.220 |
| 5PTT PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 171) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.47 Å R-free 0.216 |
| 5PTT PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 171) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.47 Å R-free 0.216 |
| 5PTU PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 172) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.69 Å R-free 0.228 |
| 5PTU PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 172) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.69 Å R-free 0.228 |
| 5PTV PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 173) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.70 Å R-free 0.219 |
| 5PTV PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 173) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.70 Å R-free 0.219 |
| 5PTW PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 174) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.214 |
| 5PTW PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 174) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.214 |
| 5PTX PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 175) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.60 Å R-free 0.228 |
| 5PTX PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 175) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.60 Å R-free 0.228 |
| 5PTY PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 176) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.10 Å R-free 0.230 |
| 5PTY PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 176) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.10 Å R-free 0.230 |
| 5PTZ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 177) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.51 Å R-free 0.216 |
| 5PTZ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 177) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.51 Å R-free 0.216 |
| 5PU0 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 178) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.89 Å R-free 0.237 |
| 5PU0 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 178) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.89 Å R-free 0.237 |
| 5PU1 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 179) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.73 Å R-free 0.219 |
| 5PU1 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 179) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.73 Å R-free 0.219 |
| 5PU2 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 180) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.59 Å R-free 0.220 |
| 5PU2 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 180) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.59 Å R-free 0.220 |
| 5PU3 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 181) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.37 Å R-free 0.287 |
| 5PU3 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 181) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.37 Å R-free 0.287 |
| 5PU4 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 182) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.237 |
| 5PU4 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 182) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.237 |
| 5PU5 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 183) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.228 |
| 5PU5 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 183) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.228 |
| 5PU6 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 184) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.74 Å R-free 0.219 |
| 5PU6 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 184) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.74 Å R-free 0.219 |
| 5PU7 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 185) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.220 |
| 5PU7 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 185) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.220 |
| 5PU8 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 186) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.224 |
| 5PU8 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 186) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.224 |
| 5PU9 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 187) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.225 |
| 5PU9 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 187) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.225 |
| 5PUA PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 188) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.218 |
| 5PUA PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 188) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.218 |
| 5PUB PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 189) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.23 Å R-free 0.247 |
| 5PUB PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 189) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.23 Å R-free 0.247 |
| 5PUC PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 190) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.64 Å R-free 0.212 |
| 5PUC PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 190) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.64 Å R-free 0.212 |
| 5PUD PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 191) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.01 Å R-free 0.213 |
| 5PUD PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 191) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.01 Å R-free 0.213 |
| 5PUE PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 192) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.70 Å R-free 0.223 |
| 5PUE PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 192) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.70 Å R-free 0.223 |
| 5PUF PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 193) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.235 |
| 5PUF PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 193) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.235 |
| 5PUG PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 194) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.00 Å R-free 0.219 |
| 5PUG PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 194) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.00 Å R-free 0.219 |
| 5PUH PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 195) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.92 Å R-free 0.224 |
| 5PUH PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 195) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.92 Å R-free 0.224 |
| 5PUI PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 196) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.51 Å R-free 0.216 |
| 5PUI PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 196) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.51 Å R-free 0.216 |
| 5PUJ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 197) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.90 Å R-free 0.215 |
| 5PUJ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 197) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.90 Å R-free 0.215 |
| 5PUK PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 198) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.64 Å R-free 0.251 |
| 5PUK PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 198) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.64 Å R-free 0.251 |
| 5PUL PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 199) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.95 Å R-free 0.231 |
| 5PUL PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 199) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.95 Å R-free 0.231 |
| 5PUM PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 200) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.15 Å R-free 0.253 |
| 5PUM PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 200) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.15 Å R-free 0.253 |
| 5PUN PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 201) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.84 Å R-free 0.244 |
| 5PUN PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 201) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.84 Å R-free 0.244 |
| 5PUO PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 202) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.06 Å R-free 0.241 |
| 5PUO PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 202) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.06 Å R-free 0.241 |
| 5PUP PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 203) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.60 Å R-free 0.243 |
| 5PUP PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 203) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.60 Å R-free 0.243 |
| 5PUQ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 204) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.70 Å R-free 0.230 |
| 5PUQ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 204) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.70 Å R-free 0.230 |
| 5PUR PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 205) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.73 Å R-free 0.211 |
| 5PUR PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 205) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.73 Å R-free 0.211 |
| 5PUS PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 206) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.67 Å R-free 0.227 |
| 5PUS PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 206) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.67 Å R-free 0.227 |
| 5PUT PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 207) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.32 Å R-free 0.258 |
| 5PUT PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 207) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.32 Å R-free 0.258 |
| 5PUU PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 208) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.69 Å R-free 0.256 |
| 5PUU PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 208) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.69 Å R-free 0.256 |
| 5PUV PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 209) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.69 Å R-free 0.229 |
| 5PUV PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 209) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.69 Å R-free 0.229 |
| 5PUW PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 210) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.228 |
| 5PUW PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 210) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.82 Å R-free 0.228 |
| 5PUX PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 211) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.51 Å R-free 0.225 |
| 5PUX PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 211) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.51 Å R-free 0.225 |
| 5PUY PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 212) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.01 Å R-free 0.233 |
| 5PUY PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 212) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.01 Å R-free 0.233 |
| 5PUZ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 213) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.49 Å R-free 0.221 |
| 5PUZ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 213) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.49 Å R-free 0.221 |
| 5PV0 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 214) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.76 Å R-free 0.255 |
| 5PV0 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 214) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.76 Å R-free 0.255 |
| 5PV1 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 215) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.73 Å R-free 0.221 |
| 5PV1 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 215) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.73 Å R-free 0.221 |
| 5PV2 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 216) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.240 |
| 5PV2 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 216) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.240 |
| 5PV3 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 217) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.48 Å R-free 0.228 |
| 5PV3 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 217) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.48 Å R-free 0.228 |
| 5PV4 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 218) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.237 |
| 5PV4 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 218) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.237 |
| 5PV5 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 219) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.68 Å R-free 0.242 |
| 5PV5 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 219) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.68 Å R-free 0.242 |
| 5PV6 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 220) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.276 |
| 5PV6 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 220) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.62 Å R-free 0.276 |
| 5PV7 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 221) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.247 |
| 5PV7 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 221) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.247 |
| 5PV8 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 222) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.49 Å R-free 0.233 |
| 5PV8 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 222) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.49 Å R-free 0.233 |
| 5PV9 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 223) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.67 Å R-free 0.237 |
| 5PV9 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 223) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.67 Å R-free 0.237 |
| 5PVA PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 224) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.98 Å R-free 0.227 |
| 5PVA PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 224) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.98 Å R-free 0.227 |
| 5PVB PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 225) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.224 |
| 5PVB PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 225) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.224 |
| 5PVC PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 226) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.238 |
| 5PVC PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 226) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.56 Å R-free 0.238 |
| 5PVD PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 227) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.241 |
| 5PVD PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 227) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.241 |
| 5PVE PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 228) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.29 Å R-free 0.255 |
| 5PVE PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 228) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.29 Å R-free 0.255 |
| 5PVF PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 229) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.71 Å R-free 0.282 |
| 5PVF PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 229) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.71 Å R-free 0.282 |
| 5PVG PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 230) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.69 Å R-free 0.239 |
| 5PVG PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 230) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.69 Å R-free 0.239 |
| 5PVH PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 232) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.69 Å R-free 0.280 |
| 5PVH PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 232) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.69 Å R-free 0.280 |
| 5PVI PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 233) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.19 Å R-free 0.256 |
| 5PVI PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 233) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.19 Å R-free 0.256 |
| 5PVJ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 234) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.57 Å R-free 0.232 |
| 5PVJ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 234) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.57 Å R-free 0.232 |
| 5PVK PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 235) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.218 |
| 5PVK PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 235) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.58 Å R-free 0.218 |
| 5PVL PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 236) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.228 |
| 5PVL PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 236) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.53 Å R-free 0.228 |
| 5PVM PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 237) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.65 Å R-free 0.238 |
| 5PVM PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 237) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.65 Å R-free 0.238 |
| 5PVN PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 238) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.228 |
| 5PVN PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 238) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.63 Å R-free 0.228 |
| 5PVO PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 239) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.96 Å R-free 0.217 |
| 5PVO PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 239) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.96 Å R-free 0.217 |
| 5PVP PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 240) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.69 Å R-free 0.236 |
| 5PVP PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 240) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.69 Å R-free 0.236 |
| 5PVQ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 241) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.61 Å R-free 0.255 |
| 5PVQ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 241) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.61 Å R-free 0.255 |
| 5PVR PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 242) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.57 Å R-free 0.235 |
| 5PVR PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 242) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.57 Å R-free 0.235 |
| 5PVS PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 243) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.226 |
| 5PVS PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 243) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.55 Å R-free 0.226 |
| 5PVT PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 244) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.48 Å R-free 0.215 |
| 5PVT PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 244) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.48 Å R-free 0.215 |
| 5PVU PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 245) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 3.01 Å R-free 0.270 |
| 5PVU PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 245) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 3.01 Å R-free 0.270 |
| 5PVV PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 246) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.80 Å R-free 0.218 |
| 5PVV PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 246) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.80 Å R-free 0.218 |
| 5PVW PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 247) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.18 Å R-free 0.267 |
| 5PVW PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 247) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.18 Å R-free 0.267 |
| 5PVX PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 248) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.74 Å R-free 0.253 |
| 5PVX PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 248) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.74 Å R-free 0.253 |
| 5PVY PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 249) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.49 Å R-free 0.246 |
| 5PVY PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 249) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.49 Å R-free 0.246 |
| 5PVZ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 250) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.64 Å R-free 0.246 |
| 5PVZ PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 250) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.64 Å R-free 0.246 |
| 5PW0 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 251) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.13 Å R-free 0.277 |
| 5PW0 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 251) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.13 Å R-free 0.277 |
| 5PW1 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 252) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.57 Å R-free 0.248 |
| 5PW1 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 252) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.57 Å R-free 0.248 |
| 5PW2 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 253) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.32 Å R-free 0.274 |
| 5PW2 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 253) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.32 Å R-free 0.274 |
| 5PW3 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 254) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.21 Å R-free 0.299 |
| 5PW3 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 254) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.21 Å R-free 0.299 |
| 5PW4 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 255) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.91 Å R-free 0.237 |
| 5PW4 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 255) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.91 Å R-free 0.237 |
| 5PW5 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 256) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.09 Å R-free 0.336 |
| 5PW5 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 256) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.09 Å R-free 0.336 |
| 5PW6 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 257) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.75 Å R-free 0.420 |
| 5PW6 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 257) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.75 Å R-free 0.420 |
| 5PW7 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 258) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.85 Å R-free 0.262 |
| 5PW7 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 258) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.85 Å R-free 0.262 |
| 5PW8 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 259) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.08 Å R-free 0.321 |
| 5PW8 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 259) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.08 Å R-free 0.321 |
| 5PW9 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 260) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 3.44 Å R-free 0.301 |
| 5PW9 PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 260) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 3.44 Å R-free 0.301 |
| 5PWA PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 261) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.86 Å R-free 0.314 |
| 5PWA PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 261) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 1.86 Å R-free 0.314 |
| 5PWB PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 262) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.09 Å R-free 0.317 |
| 5PWB PanDDA analysis group deposition -- Crystal Structure of BRD1 after initial refinement with no ligand modelled (structure 262) Deposited 2017-02-07 | Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
555–688（134 aa）
|
Mutation：V23M,P34E,V37R | EDO 1,2-ETHANEDIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M bis-tris pH 7.0 -- 30% PEG3350
|
Resolution 2.09 Å R-free 0.317 |
| 6IN2 Crystal structure of BRD1 in complex with 18-Crown-6 Deposited 2018-10-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
563–680（118 aa）
|
Not recorded | ACT ACETATE ION × 1 O4B 1,4,7,10,13,16-HEXAOXACYCLOOCTADECANE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；17% PEG4000, 0.1 M sodium acetate pH 4.4, 0.2 M ammonium acetate
|
Resolution 1.75 Å R-free 0.248 |
| 7LH9 Crystal structure of BRPF2 PWWP domain in complex with DNA Deposited 2021-01-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Monomer；Protein × 1 PDB declaration: Chain A interacts with the DNA at the junction of one dsDNA (comprising chains E and F) and a symmetry-related dsDNA |
Chain A
925–1049（125 aa）
Fragment：PWWP domain
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；20% PEG 3350, 0.2M Magnesium Acetate
|
Resolution 2.60 Å R-free 0.278 |
| 7LH9 Crystal structure of BRPF2 PWWP domain in complex with DNA Deposited 2021-01-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein–DNA Monomer；Protein × 1 PDB declaration: trimeric |
Chain B
925–1049（125 aa）
Fragment：PWWP domain
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；20% PEG 3350, 0.2M Magnesium Acetate
|
Resolution 2.60 Å R-free 0.278 |
| 7LH9 Crystal structure of BRPF2 PWWP domain in complex with DNA Deposited 2021-01-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein–DNA Monomer；Protein × 1 PDB declaration: trimeric |
Chain C
925–1049（125 aa）
Fragment：PWWP domain
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；20% PEG 3350, 0.2M Magnesium Acetate
|
Resolution 2.60 Å R-free 0.278 |
| 7LH9 Crystal structure of BRPF2 PWWP domain in complex with DNA Deposited 2021-01-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein–DNA Monomer；Protein × 1 PDB declaration: Chain D interacts with the DNA at the junction of one dsDNA (comprising chains E and F) and a symmetry-related dsDNA |
Chain D
925–1049（125 aa）
Fragment：PWWP domain
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；20% PEG 3350, 0.2M Magnesium Acetate
|
Resolution 2.60 Å R-free 0.278 |
| 9T2E Bromodomain containing protein 1 with crystal epitope mutations P566E:V569R Deposited 2025-10-22 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
556–688（133 aa）
|
Mutation：P566E, V569R | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；293.15 K；25% PEG3350
0.1M bis-tris pH 6.5
|
Resolution 1.71 Å R-free 0.236 |
| 9T2E Bromodomain containing protein 1 with crystal epitope mutations P566E:V569R Deposited 2025-10-22 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
556–688（133 aa）
|
Mutation：P566E, V569R | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；293.15 K；25% PEG3350
0.1M bis-tris pH 6.5
|
Resolution 1.71 Å R-free 0.236 |
309 other PDB entries and 621 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | BRD1_HUMAN |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 23–156； UniProt 555–688 Author chain B； PDBConstruct 23–156； UniProt 555–688 |
