6ern

HIV Hexamer with ligand

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Gag polyprotein

Human immunodeficiency virus 1

UniProt B6DRA0

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein homooligomer Homooligomer Protein 6 ADENOSINE-5'-TRIPHOSPHATE × 6 water × 6 Consistent with protein count

Other States of the Same Protein in the Database

Monomer
7urt 7urt 8eep 8eep 8eet 8eet

6 assemblies

Homodimer

None

Homotetramer

None

Other homooligomers
5mcx 5mcy 5up4 5w4o 5w4p 5w4q 6axr 6axs 6axt 6axv 6axw 6axx

88 assemblies; showing the first 12

Heteromeric or nucleic-acid complex
6ay9 6obh 6pu1 7n9u 7n9v 7n9x 8cky 8cl0 8cl1 8cl3

10 assemblies

View Construct and Data Evidence
UniProt name B6DRA0_9HIV1
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 4–216； UniProt 139–351

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id6ern
Deposition date deposition_date2017-10-18
Structure title titleHIV Hexamer with ligand
Keywords keywordsHIV, VIRAL PROTEIN; VIRAL PROTEIN
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

6ern__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

6ern__assembly_1__model_1 | I(q)

10-2 10-1 106 107 108 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

6ern__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）34.95 Å
Rg (electron density)34.52 Å
Total Rg34.87 Å
Atom count9513
Residues1212
Excluded volume168820 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 6ern__assembly_1__model_1 hexameric （6） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (3)

▼

6. Fold Classification (SCOP + CATH) 5 domains

SCOP 2.08 (3 domains)

Domain ID domain_idd6erna1
Class classa — All alpha proteins
Fold Fold folda.73 — Retrovirus capsid protein, N-terminal core domain
Superfamily Superfamily superfamilya.73.1 — Retrovirus capsid protein, N-terminal core domain
Family Family familya.73.1.1 — Retrovirus capsid protein, N-terminal core domain
Domain ID domain_idd6erna2
Class classa — All alpha proteins
Fold Fold folda.28 — Acyl carrier protein-like
Superfamily Superfamily superfamilya.28.3 — Retrovirus capsid dimerization domain-like
Family Family familya.28.3.0 — automated matches
Domain ID domain_idd6erna3
Class classl — Artifacts
Fold Fold foldl.1 — Tags
Superfamily Superfamily superfamilyl.1.1 — Tags
Family Family familyl.1.1.1 — Tags

CATH v4.4 (2 domains)

Domain ID domain_id6ernA01
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology375 — Human Immunodeficiency Virus Type 1 Capsid Protein
Homologous superfamily homologous superfamily10 — Human Immunodeficiency Virus Type 1 Capsid Protein
Domain ID domain_id6ernA02
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology1200 — Non-ribosomal Peptide Synthetase Peptidyl Carrier Protein; Chain A
Homologous superfamily homologous superfamily30 — Retrovirus capsid C-terminal domain
▶

7. Citations (1)
