Ferritin light chain
OrganismNot specified
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein homooligomer Homooligomer Protein × 24 PDB declaration: 24-meric（24） Consistent with protein copy count | Chain A； UniProt 1–175 Chain B； UniProt 1–175 Chain C； UniProt 1–175 Chain D； UniProt 1–175 Chain E； UniProt 1–175 Chain F； UniProt 1–175 Chain G； UniProt 1–175 Chain H； UniProt 1–175 Chain I； UniProt 1–175 Chain J； UniProt 1–175 Chain K； UniProt 1–175 Chain L； UniProt 1–175 Chain M； UniProt 1–175 Chain N； UniProt 1–175 Chain O； UniProt 1–175 Chain P； UniProt 1–175 Chain Q； UniProt 1–175 Chain R； UniProt 1–175 Chain S； UniProt 1–175 Chain T； UniProt 1–175 Chain V； UniProt 1–175 Chain W； UniProt 1–175 Chain X； UniProt 1–175 Chain Y； UniProt 1–175 | Not recorded | No other associated polymer | ELECTRON MICROSCOPY cryo-EM buffer：pH 7.4 cryo-EM vitrification conditions：Cryogen ETHANE；Chameleon EP2 based on Spotiton | Resolution 2.10 Å |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 6PXM | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 1AEW L-CHAIN HORSE APOFERRITIN Deposited 1997-02-26 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
Fragment：L CHAIN
|
Not recorded | CD CADMIUM ION × 144 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；CRYSTALLIZED BY SITTING DROP: 15 LAMBDA PROTEIN + 1-2 LAMBDA 2% CDSO4, pH 7.0, vapor diffusion - sitting drop
|
Resolution 1.95 Å |
| 1DAT CUBIC CRYSTAL STRUCTURE RECOMBINANT HORSE L APOFERRITIN Deposited 1996-11-14 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Not recorded | CD CADMIUM ION × 72 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.05 Å |
| 1GWG Tri-iodide derivative of apoferritin Deposited 2002-03-15 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
Fragment：L-CHAIN RESIDUES 1-174
|
Not recorded | IOD IODIDE ION × 216 CD CADMIUM ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.3；40MG/ML PROTEIN; 8MM CDSO4, 1M AMMONIUM SULPHATE, 0.01M NAN3., pH 5.30
|
Resolution 2.01 Å R-free 0.208 |
| 1HRS A CRYSTALLOGRAPHIC STUDY OF HAEM BINDING TO FERRITIN Deposited 1993-11-05 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Not recorded | CD CADMIUM ION × 48 PP9 PROTOPORPHYRIN IX × 24 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.60 Å |
| 1IER CUBIC CRYSTAL STRUCTURE OF NATIVE HORSE SPLEEN FERRITIN Deposited 1996-05-28 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
Fragment：L-CHAIN
|
Not recorded | CD CADMIUM ION × 72 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.26 Å |
| 1IES TETRAGONAL CRYSTAL STRUCTURE OF NATIVE HORSE SPLEEN FERRITIN Deposited 1996-05-28 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
Fragment：L-CHAIN
Chain B
1–174（174 aa）
Fragment：L-CHAIN
Chain C
1–174（174 aa）
Fragment：L-CHAIN
Chain D
1–174（174 aa）
Fragment：L-CHAIN
Chain E
1–174（174 aa）
Fragment：L-CHAIN
Chain F
1–174（174 aa）
Fragment：L-CHAIN
|
Not recorded | CD CADMIUM ION × 20 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.60 Å |
| 1XZ1 Complex of halothane with apoferritin Deposited 2004-11-11 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Not recorded | CD CADMIUM ION × 144 HLT 2-BROMO-2-CHLORO-1,1,1-TRIFLUOROETHANE × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；cadmium sulfate, HEPES, sodium acetate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.75 Å R-free 0.212 |
| 1XZ3 Complex of apoferritin with isoflurane Deposited 2004-11-11 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Not recorded | CD CADMIUM ION × 168 ICF 1-CHLORO-2,2,2-TRIFLUOROETHYL DIFLUOROMETHYL ETHER × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；cadmium sulfate, HEPES, sodium acetate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.75 Å R-free 0.210 |
| 2G4H Anomalous substructure of apoferritin Deposited 2006-02-22 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Not recorded | CD CADMIUM ION × 216 CL CHLORIDE ION × 48 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å R-free 0.218 |
| 2V2I Wild type recombinant horse spleen apoferritin cocrystallized with haemin in acidic conditions Deposited 2007-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Not recorded | CD CADMIUM ION × 192 GOL GLYCEROL × 24 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；RESERVOIR: CADMIUM SULFATE 0.13M, AMMONIUM SULFATE 0.8M, SODIUM ACETATE 0.1M PH 5.5, SODIUM AZIDE 0.003M DROP 2 UL PROTEIN AND 2UL RESERVOIR
|
Resolution 2.00 Å R-free 0.217 |
| 2V2J Wild type recombinant horse spleen apoferritin cocrystallized with haemin in basic conditions Deposited 2007-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Not recorded | CD CADMIUM ION × 192 GOL GLYCEROL × 120 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.2；RESERVOIR: CADMIUM SULFATE 0.04M, AMMONIUM SULFATE 0.5M, SODIUM AZIDE 0.003M DROP: 1UL PROTEIN AND 1 UL RESERVOIR, pH 8.2
|
Resolution 2.22 Å R-free 0.250 |
| 2V2L Mutant (E53,56,57,60Q) recombinant horse spleen apoferritin cocrystallized with haemin in acidic conditions Deposited 2007-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Mutation：YES | CD CADMIUM ION × 168 SO4 SULFATE ION × 24 GOL GLYCEROL × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；RESERVOIR: CADMIUM SULFATE 0.13M, AMMONIUM SULFATE 0.8M, SODIUM ACETATE 0.1M PH 5.5, SODIUM AZIDE 0.003M. DROP: 2 UL PROTEIN AND 2 UL RESERVOIR
|
Resolution 1.90 Å R-free 0.216 |
| 2V2M Mutant (E53,56,57,60Q) recombinant horse spleen apoferritin cocrystallized with haemin in basic conditions Deposited 2007-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Mutation：YES | CD CADMIUM ION × 168 SO4 SULFATE ION × 24 GOL GLYCEROL × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8；RESERVOIR: CADMIUM SULFATE 0.044M, AMMONIUM SULFATE 0.5M, SODIUM AZIDE 0.003M. DROP: 1UL PROTEIN AND 1UL RESERVOIR, pH 8.0
|
Resolution 1.65 Å R-free 0.212 |
| 2V2N Mutant R59M recombinant horse spleen apoferritin cocrystallized with haemin in acidic conditions Deposited 2007-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Mutation：YES | CD CADMIUM ION × 192 GOL GLYCEROL × 72 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；RESERVOIR: CADMIUM SULFATE 0.12M, AMMONIUM SULFATE 1.1M, SODIUM ACETATE 0.1M PH 5.6, SODIUM AZIDE 0.003M DROP: 1UL PROTEIN AND 1UL RESERVOIR
|
Resolution 1.55 Å R-free 0.222 |
| 2V2O Mutant R59M recombinant horse spleen apoferritin cocrystallized with haemin in basic conditions Deposited 2007-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Mutation：YES | CD CADMIUM ION × 216 GOL GLYCEROL × 24 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.2；RESERVOIR: CADMIUM SULFATE 0.145M, AMMONIUM SULFATE 0.55M, SODIUM AZIDE 0.003M. DROP: 1UL PROTEIN AND 1UL RESERVOIR, pH 8.2
|
Resolution 1.87 Å R-free 0.236 |
| 2V2P Mutant (E53,56,57,60Q and R59M) recombinant horse spleen apoferritin cocrystallized with haemin in acidic conditions Deposited 2007-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Mutation：YES | CD CADMIUM ION × 120 GOL GLYCEROL × 48 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；RESERVOIR: CADMIUM SULFATE 0.08M, AMMONIUM SULFATE 0.5M, SODIUM ACETATE 0.1M PH 5.6, SODIUM AZIDE 0.003M. DROP: 1UL PROTEIN AND 1UL RESERVOIR
|
Resolution 1.15 Å R-free 0.224 |
| 2V2R Mutant (E53,56,57,60Q and R59M) recombinant horse spleen apoferritin cocrystallized with haemin in basic conditions Deposited 2007-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Mutation：YES | CD CADMIUM ION × 144 GOL GLYCEROL × 24 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.2；RESERVOIR: CADMIUM SULFATE 0.16M, AMMONIUM SULFATE 0.5M, SODIUM AZIDE 0.003M. DROP: 1UL PROTEIN AND 1UL RESERVOIR, pH 8.2
|
Resolution 1.90 Å R-free 0.230 |
| 2V2S Mutant R59M recombinant horse spleen apoferritin crystallized in acidic conditions Deposited 2007-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–174（174 aa）
|
Mutation：YES | CD CADMIUM ION × 192 GOL GLYCEROL × 48 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；RESERVOIR: CADMIUM SULFATE 0.12M, AMMONIUM SULFATE 1.1M, SODIUM ACETATE 0.1M PH5.6, SODIUM AZIDE 0.003M. DROP: 1UL PROTEIN AND 1UL RESERVOIR, pH 5.5
|
Resolution 1.37 Å R-free 0.226 |
| 2W0O Horse spleen apoferritin Deposited 2008-08-20 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
Fragment：RESIDUES 2-175
|
Not recorded | SO4 SULFATE ION × 24 CD CADMIUM ION × 168 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.6；RESERVOIR: CADMIUM SULFATE 0.12M, AMMONIUM SULFATE 0.8M, SODIUM ACETATE BUFFER 0.1M PH 5.6, SODIUM AZIDE 0.003M. DROP: 1UL PROTEIN AND 1 UL RESERVOIR
|
Resolution 1.50 Å R-free 0.236 |
| 2Z5P Apo-Fr with low content of Pd ions Deposited 2007-07-16 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | PD PALLADIUM ION × 144 CD CADMIUM ION × 48 SO4 SULFATE ION × 72 GOL GLYCEROL × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulfate, Cadmium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.65 Å R-free 0.188 |
| 2Z5Q Apo-Fr with intermediate content of Pd ion Deposited 2007-07-16 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | PD PALLADIUM ION × 216 CD CADMIUM ION × 24 GOL GLYCEROL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulfate, Cadmium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.10 Å R-free 0.254 |
| 2Z5R Apo-Fr with high content of Pd ions Deposited 2007-07-16 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | PD PALLADIUM ION × 240 CD CADMIUM ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulfate, Cadmium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.50 Å R-free 0.287 |
| 2ZA6 recombinant horse L-chain apoferritin Deposited 2007-10-02 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
1–175（175 aa）
|
Not recorded | CD CADMIUM ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.1M Tris-HCl, 0.13% cadmium chloride, 15% PEG4000, 19 mM calcium chloride, 5% glycerol, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293.0K
|
Resolution 1.75 Å R-free 0.225 |
| 2ZA7 recombinant horse L-chain apoferritin N-terminal deletion mutant (residues 1-4) Deposited 2007-10-02 | Different construct Different mutation/modification Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
5–175（171 aa）
Fragment：residues 5-175
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.1M Tris-HCl, 0.13% cadmium chloride, 15% PEG4000, 190mM calcium chloride, 5% glycerol, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293.0K
|
Resolution 1.40 Å R-free 0.242 |
| 2ZA8 recombinant horse L-chain apoferritin N-terminal deletion mutant (residues 1-8) Deposited 2007-10-02 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
9–175（167 aa）
Fragment：residues 9-175
|
Not recorded | CD CADMIUM ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.8；293 K；0.1M Tris-HCl, 225mM ammonium sulphate, 0.13% cadmium chloride, 25% 2-Metyl-2,4-pentanediol, pH 6.8, VAPOR DIFFUSION, HANGING DROP, temperature 293.0K
|
Resolution 1.40 Å R-free 0.239 |
| 2ZG7 Crystal Structure of Pd(allyl)/apo-Fr Deposited 2008-01-18 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 24 SO4 SULFATE ION × 96 PLL Palladium(II) allyl complex × 96 EDO 1,2-ETHANEDIOL × 192 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium slfate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.70 Å R-free 0.202 |
| 2ZG8 Crystal Structure of Pd(allyl)/apo-H49AFr Deposited 2008-01-18 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：H49A | PD PALLADIUM ION × 24 CD CADMIUM ION × 24 SO4 SULFATE ION × 96 PLL Palladium(II) allyl complex × 72 EDO 1,2-ETHANEDIOL × 168 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.60 Å R-free 0.211 |
| 2ZG9 Crystal Structure of Pd(allyl)/apo-H114AFr Deposited 2008-01-18 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：H114A | CD CADMIUM ION × 24 SO4 SULFATE ION × 96 PLL Palladium(II) allyl complex × 72 EDO 1,2-ETHANEDIOL × 144 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.75 Å R-free 0.211 |
| 2ZUR Crystal Structure of Rh(nbd)/apo-Fr Deposited 2008-10-28 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CD CADMIUM ION × 120 SO4 SULFATE ION × 48 RH Rhodium × 48 EDO 1,2-ETHANEDIOL × 192 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；0.5M ammonium sulfate, 10mM cadmium sulfate, pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.80 Å R-free 0.196 |
| 3AF7 Crystal Structure of 25Pd(allyl)/apo-Fr Deposited 2010-02-24 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 24 SO4 SULFATE ION × 24 PD PALLADIUM ION × 48 PLL Palladium(II) allyl complex × 72 EDO 1,2-ETHANEDIOL × 120 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate, pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.58 Å R-free 0.212 |
| 3AF8 Crystal Structure of Pd(ally)/apo-C126AFr Deposited 2010-02-24 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：C126A | CD CADMIUM ION × 72 SO4 SULFATE ION × 24 PLL Palladium(II) allyl complex × 48 EDO 1,2-ETHANEDIOL × 168 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate, pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.66 Å R-free 0.195 |
| 3AF9 Crystal Structure of Pd(allyl)/apo-C48AFr Deposited 2010-02-24 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：C48A | SO4 SULFATE ION × 24 CD CADMIUM ION × 72 PLL Palladium(II) allyl complex × 24 PD PALLADIUM ION × 24 EDO 1,2-ETHANEDIOL × 168 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate, pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.85 Å R-free 0.203 |
| 3F32 Horse spleen apoferritin Deposited 2008-10-30 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 120 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；Cadmium sulfate, ammonium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.70 Å R-free 0.209 |
| 3F33 Apoferritin: complex with propofol Deposited 2008-10-30 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 144 PFL 2,6-BIS(1-METHYLETHYL)PHENOL × 24 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；Cadmium sulfate, ammonium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.70 Å R-free 0.220 |
| 3F34 Apoferritin: complex with 2,6-diethylphenol Deposited 2008-10-30 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 120 DIE 2,6-diethylphenol × 24 SO4 SULFATE ION × 72 ACT ACETATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；Cadmium sulfate, ammonium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.68 Å R-free 0.247 |
| 3F35 Apoferritin: complex with 2,6-diethylphenol Deposited 2008-10-30 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 168 DIE 2,6-diethylphenol × 24 SO4 SULFATE ION × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；cadmium sulfate, ammonium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.92 Å R-free 0.236 |
| 3F36 Apoferritin: complex with 2-isopropylphenol Deposited 2008-10-30 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 192 IP0 2-(1-methylethyl)phenol × 24 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；Cadmium sulfate, ammonium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.70 Å R-free 0.210 |
| 3F37 Apoferritin: complex with 2,6-dimethylphenol Deposited 2008-10-30 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 168 2MY 2,6-dimethylphenol × 24 SO4 SULFATE ION × 72 ACT ACETATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；Cadmium sulfate, ammonium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.54 Å R-free 0.198 |
| 3F38 Apoferritin: complex with 2,6-dimethylphenol Deposited 2008-10-30 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 144 2MY 2,6-dimethylphenol × 24 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；Cadmium sulfate, ammonium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.75 Å R-free 0.222 |
| 3F39 Apoferritin: complex with phenol Deposited 2008-10-30 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 192 IPH PHENOL × 24 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；Cadmium sulfate, ammonium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.85 Å R-free 0.216 |
| 3FI6 apo-H49AFr with high content of Pd ions Deposited 2008-12-11 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：H49A, L93P | PD PALLADIUM ION × 192 CD CADMIUM ION × 24 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulfate, Cadmium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.80 Å R-free 0.225 |
| 3H7G Apo-FR with AU ions Deposited 2009-04-27 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | AU3 GOLD 3+ ION × 144 CD CADMIUM ION × 72 SO4 SULFATE ION × 72 GOL GLYCEROL × 96 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；AMMONIUM SULFATE, CADMIUM SULFATE, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.65 Å R-free 0.236 |
| 3NOZ Crystal Structure of Pd(allyl)/apo-E45C/R52H-rHLFr Deposited 2010-06-27 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：E45C, R52H | SO4 SULFATE ION × 24 CD CADMIUM ION × 24 PLL Palladium(II) allyl complex × 144 EDO 1,2-ETHANEDIOL × 216 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate, pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.52 Å R-free 0.209 |
| 3NP0 Crystal Structure of Pd(allyl)/apo-E45C/H49A/R52H-rHLFr Deposited 2010-06-27 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：E45C, H49A, R52H | SO4 SULFATE ION × 48 PLL Palladium(II) allyl complex × 144 CD CADMIUM ION × 24 EDO 1,2-ETHANEDIOL × 192 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate, pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.48 Å R-free 0.210 |
| 3NP2 Crystal Structure of Pd(allyl)/apo-E45C/C48A-rHLFr Deposited 2010-06-27 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：E45C, C48A | SO4 SULFATE ION × 24 PLL Palladium(II) allyl complex × 48 PD PALLADIUM ION × 48 CD CADMIUM ION × 48 EDO 1,2-ETHANEDIOL × 192 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate , pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.86 Å R-free 0.229 |
| 3O7R Crystal structure of Ru(p-cymene)/apo-H49AFr Deposited 2010-07-31 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：H49A, L93P | CD CADMIUM ION × 72 RU RUTHENIUM ION × 48 SO4 SULFATE ION × 48 EDO 1,2-ETHANEDIOL × 144 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；AMMONIUM SULFATE, CADMIUM SLFATE, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.90 Å R-free 0.237 |
| 3O7S Crystal structure of Ru(p-cymene)/apo-Fr Deposited 2010-07-31 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 72 RU RUTHENIUM ION × 72 MML 1-methyl-4-(1-methylethyl)benzene × 24 SO4 SULFATE ION × 24 EDO 1,2-ETHANEDIOL × 120 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；AMMONIUM SULFATE, CADMIUM SLFATE, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.73 Å R-free 0.217 |
| 3RAV Horse spleen apo-ferritin with bound Pentobarbital Deposited 2011-03-28 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 144 SO4 SULFATE ION × 48 RAV 5-ethyl-5-[(2S)-pentan-2-yl]pyrimidine-2,4,6(1H,3H,5H)-trione × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；291 K；0.2-1.6 M (NH4)2SO4 and 0.1-0.275 M CdSO4, 0.5 mM thiopental were mixed with equal volumes of apoferritin solution and equilibrated over 0.7-1 mL, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.90 Å R-free 0.208 |
| 3RD0 Horse spleen apo-ferritin with bound thiopental Deposited 2011-03-31 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | EDP 5-ethyl-5-[(2R)-pentan-2-yl]-2-thioxodihydropyrimidine-4,6(1H,5H)-dione × 24 CD CADMIUM ION × 120 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；291 K；0.2-1.6 M (NH4)2SO4 and 0.1-0.275 M CdSO4, 0.5 mM thiopental were mixed with equal volumes of apoferritin solution and equilibrated over 0.7-1 ml, vapor diffusion, hanging drop, temperature 291K
|
Resolution 2.00 Å R-free 0.205 |
| 3U90 apoferritin: complex with SDS Deposited 2011-10-17 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | SDS DODECYL SULFATE × 24 CD CADMIUM ION × 240 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.05 M cadmium sulfate, 0.1 M HEPES, 1.0 M sodium acetate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.90 Å R-free 0.208 |
| 3WVU Crystal Structure of RuCO/apo-R52CFr Deposited 2014-06-09 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52C | CD CADMIUM ION × 72 SO4 SULFATE ION × 24 EDO 1,2-ETHANEDIOL × 192 RU RUTHENIUM ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；1M ammonium sulfate, 20mM cadmium sulfate, pH 8, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.92 Å R-free 0.193 |
| 3WVV Crystal Structure of RuCO/apo-E45C_C48AFr Deposited 2014-06-09 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E45C, C48A | CD CADMIUM ION × 96 SO4 SULFATE ION × 24 EDO 1,2-ETHANEDIOL × 168 RU RUTHENIUM ION × 96 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；1M ammonium sulfate, 20mM cadmium sulfate, pH 8, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.82 Å R-free 0.191 |
| 3WVW Crystal structure of RuCO/apo-WTFr Deposited 2014-06-09 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 72 SO4 SULFATE ION × 24 EDO 1,2-ETHANEDIOL × 192 RU RUTHENIUM ION × 48 RU1 bis(oxidaniumylidynemethyl)ruthenium(2+) × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；1M ammonium sulfate, 20 mM cadmium sulfate, pH 8, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.199 |
| 4DE6 Horse spleen apo-ferritin complex with arachidonic acid Deposited 2012-01-19 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | ACD ARACHIDONIC ACID × 24 CD CADMIUM ION × 240 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；(NH4)2SO4 and CDSO4, ,0.2 mM arachidonate was mixed in the reservoir, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.18 Å R-free 0.224 |
| 4V1W 3D structure of horse spleen apoferritin determined by electron cryomicroscopy Deposited 2014-10-02 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
Chain B
2–175（174 aa）
Chain C
2–175（174 aa）
Chain D
2–175（174 aa）
Chain E
2–175（174 aa）
Chain F
2–175（174 aa）
Chain G
2–175（174 aa）
Chain H
2–175（174 aa）
Chain I
2–175（174 aa）
Chain J
2–175（174 aa）
Chain K
2–175（174 aa）
Chain L
2–175（174 aa）
Chain M
2–175（174 aa）
Chain N
2–175（174 aa）
Chain O
2–175（174 aa）
Chain P
2–175（174 aa）
Chain Q
2–175（174 aa）
Chain R
2–175（174 aa）
Chain S
2–175（174 aa）
Chain T
2–175（174 aa）
Chain U
2–175（174 aa）
Chain V
2–175（174 aa）
Chain W
2–175（174 aa）
Chain X
2–175（174 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
PBS；pH 7.4；PBS
cryo-EM vitrification conditions
Cryogen ETHANE；LIQUID ETHANE
|
Resolution 4.70 Å |
| 4Z3B Crystal structure of MnCO/apo-R52CFr Deposited 2015-03-31 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
Fragment：UNP residues 2-175
|
Not recorded | CD CADMIUM ION × 72 GOL GLYCEROL × 24 MN MANGANESE (II) ION × 48 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；1M ammonium sulfate, 20mM cadmium sulfite
|
Resolution 1.42 Å R-free 0.176 |
| 5AXS Crystal structure of CdCat-Fn Deposited 2015-08-01 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：A119C, C126A | 4LF N-[2-[2,5-bis(oxidanylidene)pyrrol-1-yl]ethyl]-2,3-bis(oxidanyl)benzamide × 24 CD CADMIUM ION × 120 SO4 SULFATE ION × 24 GOL GLYCEROL × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate
|
Resolution 1.67 Å R-free 0.188 |
| 5CZU Crystal structure of FeCat-Fn Deposited 2015-08-01 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：A119C, C126A | 4LF N-[2-[2,5-bis(oxidanylidene)pyrrol-1-yl]ethyl]-2,3-bis(oxidanyl)benzamide × 24 SO4 SULFATE ION × 24 CD CADMIUM ION × 96 FE FE (III) ION × 24 GOL GLYCEROL × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；ammonium sulfate, cadmium sulfate
|
Resolution 1.60 Å R-free 0.208 |
| 5E1U Crystal structure of IrCp*-apo-Fr Deposited 2015-09-30 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | IR3 IRIDIUM (III) ION × 144 CD CADMIUM ION × 24 SO4 SULFATE ION × 48 RIR [(1,2,3,4,5-Eta)-1,2,3,4,5-Pentamethylcyclopentadienyl]iridium(III) × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；Ammonium sulphate, Cadmium Sulphate
|
Resolution 1.56 Å R-free 0.188 |
| 5E2D Crystal structure of IrCp*/Pd(allyl)-apo-Fr Deposited 2015-10-01 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | IR3 IRIDIUM (III) ION × 120 IR IRIDIUM ION × 24 SO4 SULFATE ION × 48 PLL Palladium(II) allyl complex × 48 PD PALLADIUM ION × 24 CD CADMIUM ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.87 Å R-free 0.201 |
| 5ERJ X-ray structure of cisplatin-encapsulated horse spleen apoferritin Deposited 2015-11-14 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CL CHLORIDE ION × 96 CD CADMIUM ION × 312 CPT Cisplatin × 24 GOL GLYCEROL × 24 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；0.6-0.8 M (NH4)2SO4, 0.1 M Tris pH 7.4-7.7, 50-60 mM CdSO4
|
Resolution 1.45 Å R-free 0.173 |
| 5ERK X-ray structure of horse spleen apoferritin (control) Deposited 2015-11-14 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 312 CL CHLORIDE ION × 72 SO4 SULFATE ION × 24 GOL GLYCEROL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；0.6-0.8 M (NH4)2SO4, 0.1 M Tris pH 7.4-7.7, 50-60 mM CdSO4.
|
Resolution 2.00 Å R-free 0.181 |
| 5GU0 Crystal structure of Au.CL-apo-E45C/R52C-rHLFr Deposited 2016-08-24 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：E45C,R52C | AU GOLD ION × 192 CD CADMIUM ION × 72 SO4 SULFATE ION × 48 EDO 1,2-ETHANEDIOL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.95 Å R-free 0.205 |
| 5GU1 Crystal structure of Au(L).CL-apo-E45C/R52C-rHLFr Deposited 2016-08-24 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：E45C,R52C | AU GOLD ION × 216 CD CADMIUM ION × 144 SO4 SULFATE ION × 48 EDO 1,2-ETHANEDIOL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium Sulphate, Cadmium Sulphate
|
Resolution 2.05 Å R-free 0.223 |
| 5GU2 Crystal structure of Au(M).CL-apo-E45C/R52C-rHLFr Deposited 2016-08-24 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：E45C,R52C | AU GOLD ION × 240 CD CADMIUM ION × 144 SO4 SULFATE ION × 48 EDO 1,2-ETHANEDIOL × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium Sulphate, Cadmium Sulphate
|
Resolution 2.12 Å R-free 0.229 |
| 5GU3 Crystal structure of Au(E).CL-apo-E45C/R52C-rHLFr Deposited 2016-08-24 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：E45C,R52C | SO4 SULFATE ION × 48 AU GOLD ION × 144 CD CADMIUM ION × 120 EDO 1,2-ETHANEDIOL × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 2.03 Å R-free 0.244 |
| 5HQO Crystal structure of IrCp*/I-Pd(allyl)-apo-rHLFr Deposited 2016-01-21 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | PD PALLADIUM ION × 48 PLL Palladium(II) allyl complex × 24 IR IRIDIUM ION × 144 CD CADMIUM ION × 24 SO4 SULFATE ION × 24 EDO 1,2-ETHANEDIOL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.81 Å R-free 0.221 |
| 5IX6 X-ray structure of Auoxo3-encapsulated horse spleen apoferritin Deposited 2016-03-23 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | AU GOLD ION × 168 CD CADMIUM ION × 216 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；Crystals of Auoxo3-encapsulated AFt with diamond-like morphology, suitable for X-ray diffraction data collection, were grown by hanging-drop vapor diffusion technique at 293 K mixing the protein (5-10 mg x mL-1) with equal volumes of a reservoir solution consisting of 0.6-0.8 M (NH4)2SO4, 0.1 M Tris pH 7.4-7.7, 50-60 mM CdSO4.
|
Resolution 1.85 Å R-free 0.226 |
| 5LG2 Horse L type ferritin iron loaded for 60 minutes Deposited 2016-07-05 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
3–173（171 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CD CADMIUM ION × 72 FE FE (III) ION × 96 CL CHLORIDE ION × 24 OXY OXYGEN MOLECULE × 24 PER PEROXIDE ION × 48 GOL GLYCEROL × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；297 K；80 mM Cd(NO3)2, 80 mM ammonium sulfate, and 200 mM sodium acetate pH 5
|
Resolution 2.22 Å R-free 0.224 |
| 5MIJ X-ray structure of carboplatin-encapsulated horse spleen apoferritin Deposited 2016-11-28 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 264 CL CHLORIDE ION × 96 SO4 SULFATE ION × 24 PT PLATINUM (II) ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.7；298 K；0.8 M (NH4)2SO4, 0.1 M Tris pH 7.7, 60 mM CdSO4.
|
Resolution 1.49 Å R-free 0.181 |
| 5MIK X-ray structure of carboplatin-encapsulated horse spleen apoferritin (rotating anode data) Deposited 2016-11-28 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 264 CL CHLORIDE ION × 72 SO4 SULFATE ION × 24 GOL GLYCEROL × 48 PT PLATINUM (II) ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.7；298 K；0.8 M (NH4)2SO4,
0.1 M Tris pH 7.7,
60 mM CdSO4.
|
Resolution 1.96 Å R-free 0.192 |
| 6ENV X-ray structure of Au2phen-encapsulated horse spleen apoferritin Deposited 2017-10-06 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 240 CL CHLORIDE ION × 24 SO4 SULFATE ION × 24 AU GOLD ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；0.6-0.8 M (NH4)2SO4, 0.1 M Tris pH 7.4-7.7, 50-60 mM CdSO4
|
Resolution 1.82 Å R-free 0.175 |
| 6ENW X-ray structure of Auoxo4-encapsulated horse spleen apoferritin Deposited 2017-10-06 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 240 CL CHLORIDE ION × 24 GOL GLYCEROL × 48 AU GOLD ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；0.6-0.8 M (NH4)2SO4, 0.1 M Tris pH 7.4-7.7, 50-60 mM CdSO4
|
Resolution 2.60 Å R-free 0.236 |
| 6FX8 The X-ray structure of the ferritin nanocage containing Au and Pt, obtained upon encapsulation of a single heterobimetallic compound within the protein cage (rotating anode data) Deposited 2018-03-08 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 312 CL CHLORIDE ION × 72 SO4 SULFATE ION × 24 AU GOLD ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；298 K；0.6 M ammonium sulfate
0.1 M Tris HCl pH 7.4
60 mM cadmium sulfate
|
Resolution 1.80 Å R-free 0.197 |
| 6FX9 The X-ray structure of the ferritin nanocage containing Au and Pt, obtained upon encapsulation of a single heterobimetallic compound within the protein cage (synchrtron data) Deposited 2018-03-08 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 288 CL CHLORIDE ION × 72 SO4 SULFATE ION × 24 GOL GLYCEROL × 24 AU GOLD ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；298 K；0.6 M ammonium sulfate
0.1 M Tris HCl pH 7.4
60 mM cadmium sulfate
|
Resolution 1.50 Å R-free 0.183 |
| 6GXJ X-ray structure of DiRu-1-encapsulated Apoferritin Deposited 2018-06-27 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 240 CL CHLORIDE ION × 48 SO4 SULFATE ION × 24 GOL GLYCEROL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；0.6-0.8 M (NH4)2SO4, 0.1 M Tris HCl pH 7.7, 50 mM CDSO4
|
Resolution 1.43 Å R-free 0.191 |
| 6HJT The X-ray structure of the horse spleen ferritin nanocage containing Pt, obtained upon encapsulation of a Pt(II) terpyridine compound within the protein cage Deposited 2018-09-04 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 168 CL CHLORIDE ION × 72 PT PLATINUM (II) ION × 120 SO4 SULFATE ION × 24 GOL GLYCEROL × 24 DMS DIMETHYL SULFOXIDE × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；298 K；0.6 M (NH4)2SO4, 0.1 M Tris HCl pH 7.4, 60 mM CdSO4
|
Resolution 1.33 Å R-free 0.157 |
| 6HJU The X-ray structure of the horse spleen ferritin nanocage containing Pt, obtained upon encapsulation of a Pt(II) terpyridine compound within the protein cage Deposited 2018-09-04 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 168 CL CHLORIDE ION × 72 PT PLATINUM (II) ION × 120 SO4 SULFATE ION × 24 GOL GLYCEROL × 24 DMS DIMETHYL SULFOXIDE × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；298 K；0.6 M (NH4)2SO4, 0.1 M Tris HCl pH 7.4, 60 mM CdSO4
|
Resolution 1.58 Å R-free 0.182 |
| 6JEE Crystal structure of apo-L161C/L165C-Fr Deposited 2019-02-05 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 120 SO4 SULFATE ION × 48 EDO 1,2-ETHANEDIOL × 48 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.30 Å R-free 0.170 |
| 6JEF Crystal structure of apo-R168C/L169C-Fr Deposited 2019-02-05 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | SO4 SULFATE ION × 24 CD CADMIUM ION × 120 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.58 Å R-free 0.182 |
| 6MSX Iron containing ferritin at 1.43A Deposited 2018-10-18 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
Fragment：residue 2-175
|
Not recorded | SO4 SULFATE ION × 24 EDO 1,2-ETHANEDIOL × 24 CD CADMIUM ION × 96 NA SODIUM ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；A 20 uL pellet of 50 mM cadmium sulfate in 2% agar was deposited on a cover slip. Adjacent to this was positioned ferritin (10 ul of 50 mg/ml ferritin, Sigma F4503) and precipitant (10 ul of 3.5M Ammonium Sulfate and 100 mM Tris pH 7.4). The cover slip was equilibrated over 3.5 M Ammonium Sulfate
|
Resolution 1.43 Å R-free 0.172 |
| 6RA8 Horse spleen apoferritin under 2 kBar of argon Deposited 2019-04-05 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–174（173 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CD CADMIUM ION × 168 AR ARGON × 24 SO4 SULFATE ION × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；Ammonium sulfate 0.6 M + cadmium sulfate 0.1 M
|
Resolution 2.00 Å R-free 0.221 |
| 6RJH 3D structure of horse spleen apoferritin determined using multifunctional graphene supports for electron cryomicroscopy Deposited 2019-04-26 | Different construct Different experimental conditions | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
3–173（171 aa）
Chain B
3–173（171 aa）
Chain C
3–173（171 aa）
Chain D
3–173（171 aa）
Chain E
3–173（171 aa）
Chain F
3–173（171 aa）
Chain G
3–173（171 aa）
Chain H
3–173（171 aa）
Chain I
3–173（171 aa）
Chain J
3–173（171 aa）
Chain K
3–173（171 aa）
Chain L
3–173（171 aa）
Chain M
3–173（171 aa）
Chain N
3–173（171 aa）
Chain O
3–173（171 aa）
Chain P
3–173（171 aa）
Chain Q
3–173（171 aa）
Chain R
3–173（171 aa）
Chain S
3–173（171 aa）
Chain T
3–173（171 aa）
Chain U
3–173（171 aa）
Chain V
3–173（171 aa）
Chain W
3–173（171 aa）
Chain X
3–173（171 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.10 Å |
| 6TRZ Crystal structure of horse L ferritin (HoLf) Fe(III)-loaded for 15 minutes Deposited 2019-12-19 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain AAA
1–175（175 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | O OXYGEN ATOM × 24 FE FE (III) ION × 144 CD CADMIUM ION × 24 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；293 K；30 mM cadmium nitrate, 1 M ammonium sulfate, and 200 mM sodium acetate, pH 5.5
|
Resolution 2.02 Å R-free 0.188 |
| 6TSS Crystal structure of horse L ferritin (HoLf) Fe(III)-loaded for 60 minutes Deposited 2019-12-21 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain AAA
1–175（175 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | O OXYGEN ATOM × 96 CD CADMIUM ION × 24 FE FE (III) ION × 360 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；293 K；30 mM cadmium nitrate, 1 M ammonium sulfate, 200 mM sodium acetate, pH 5.5
|
Resolution 2.18 Å R-free 0.257 |
| 6TSX Crystal structure of horse L ferritin (HoLf) Fe(III)-loaded for 30 minutes Deposited 2019-12-21 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain AAA
1–175（175 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | O OXYGEN ATOM × 96 FE FE (III) ION × 360 CD CADMIUM ION × 24 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；293 K；30 mM cadmium nitrate, 1 M ammonium sulfate, 200 mM sodium acetate, pH 5.5
|
Resolution 2.02 Å R-free 0.221 |
| 7BD7 X-ray structure of Arsenoplatin-1-encapsulated horse spleen ferritin Deposited 2020-12-21 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–173（172 aa）
|
Not recorded | NA SODIUM ION × 72 CD CADMIUM ION × 360 GOL GLYCEROL × 48 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 A6R arsenoplatin-1 × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.2；293 K；0.6 M ammomium sulphate
0.1 M Tris HCl buffer pH 7.2
60 mM cadmium sulphate
|
Resolution 1.50 Å R-free 0.185 |
| 7BOM Crystal structure of recombinant horse spleen apo-R52C/E56C/R59C/E63C-Fr immobilized with gold ions. Deposited 2020-03-19 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：R53C,E57C,R60C,E64C | AU GOLD ION × 288 CD CADMIUM ION × 120 SO4 SULFATE ION × 24 EDO 1,2-ETHANEDIOL × 24 CL CHLORIDE ION × 24 NA SODIUM ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.93 Å R-free 0.196 |
| 7BON Crystal structure of recombinant horse spleen apo-R52C/E56C/R59C/E63C-Fr Deposited 2020-03-19 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R53C,E57C,R60C,E64C | SO4 SULFATE ION × 24 CD CADMIUM ION × 384 EDO 1,2-ETHANEDIOL × 48 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.48 Å R-free 0.189 |
| 7EML Structure of IrCp* immobilized apo-D38H-rHLFr Deposited 2021-04-14 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：D38H | RIR [(1,2,3,4,5-Eta)-1,2,3,4,5-Pentamethylcyclopentadienyl]iridium(III) × 24 EDO 1,2-ETHANEDIOL × 48 SO4 SULFATE ION × 48 CD CADMIUM ION × 120 CL CHLORIDE ION × 24 IR IRIDIUM ION × 96 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.25 Å R-free 0.183 |
| 7EMM Crystal structure of IrCp* immobilized apo-R52H-rHLFr Deposited 2021-04-14 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52H | EDO 1,2-ETHANEDIOL × 24 SO4 SULFATE ION × 48 CD CADMIUM ION × 144 IR IRIDIUM ION × 144 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.25 Å R-free 0.185 |
| 7RYW Crystal structure of Ferritin grown by the microbatch method in the presence of Agarose Deposited 2021-08-26 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
Fragment：residues 3-172
|
Not recorded | CD CADMIUM ION × 312 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
MICROBATCH；290 K；CdSO4, NH4SO4, Tris pH 7.4
|
Resolution 2.09 Å R-free 0.196 |
| 7RZN Crystal Structure of Ferritin grown by microbatch method in presence of agarose and electric field 2.1KV Deposited 2021-08-27 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
Fragment：residue 3-172
|
Not recorded | CD CADMIUM ION × 312 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
MICROBATCH；290 K；CdSO4, NH4SO4, Tris ph 7.4
|
Resolution 1.97 Å R-free 0.264 |
| 7RZX Crystal Structure of Ferritin grown by microbatch method in presence of agarose and electric field 4.3KV Deposited 2021-08-27 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
Fragment：residue 3-172
|
Not recorded | CD CADMIUM ION × 312 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
MICROBATCH；290 K；CdSO4,NH4SO4,Tris pH7.4
|
Resolution 2.44 Å R-free 0.222 |
| 7VIO Crystal structure of recombinant horse spleen apo-R168H/L169C-Fr Deposited 2021-09-27 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R168H/L169C | GOL GLYCEROL × 24 CD CADMIUM ION × 72 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293.15 K；Ammonium Sulfate, Cadmium Sulfate
|
Resolution 1.50 Å R-free 0.193 |
| 7VIP Crystal structure of Au(10EQ)-apo-R168H/L169C-rHLFr Deposited 2021-09-27 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：168H/L169C | GOL GLYCEROL × 48 CD CADMIUM ION × 72 AU GOLD ION × 48 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293.15 K；Ammonium Sulfate, Cadmium Sulfate
|
Resolution 1.90 Å R-free 0.212 |
| 7VIQ Crystal structure of Au(50EQ)-apo-R168H/L169C-rHLFr Deposited 2021-09-27 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R168H/L169C | EDO 1,2-ETHANEDIOL × 48 AU GOLD ION × 192 CD CADMIUM ION × 96 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293.15 K；Ammonium Sulfate, Cadmium Sulfate
|
Resolution 1.90 Å R-free 0.195 |
| 7VIR Crystal structure of Au(100EQ)-apo-R168H/L169C-rHLFr Deposited 2021-09-27 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R168H/L169C | CD CADMIUM ION × 96 SO4 SULFATE ION × 72 AU GOLD ION × 192 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293.15 K；Ammonium Sulfate, Cadmium Sulfate
|
Resolution 1.90 Å R-free 0.208 |
| 7VIS Crystal structure of Au(200EQ)-apo-R168H/L169C-rHLFr Deposited 2021-09-27 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R168H/L169C | EDO 1,2-ETHANEDIOL × 24 AU GOLD ION × 168 CD CADMIUM ION × 72 SO4 SULFATE ION × 24 CL CHLORIDE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293.15 K；Ammonium Sulfate, Cadmium Sulfate
|
Resolution 1.85 Å R-free 0.198 |
| 7VIT Crystal structure of Au(400EQ)-apo-R168H/L169C-rHLFr Deposited 2021-09-27 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R168H/L169C | CD CADMIUM ION × 72 AU GOLD ION × 192 SO4 SULFATE ION × 48 CL CHLORIDE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293.15 K；Ammonium Sulfate, Cadmium Sulfate
|
Resolution 1.90 Å R-free 0.217 |
| 7VIU Crystal structure of Au(200EQ)-apo-R168C/L169C-rHLFr Deposited 2021-09-27 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R168C/L169C | AU GOLD ION × 192 CL CHLORIDE ION × 72 CD CADMIUM ION × 72 SO4 SULFATE ION × 48 GOL GLYCEROL × 96 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293.15 K；Ammonium Sulfate, Cadmium Sulfate
|
Resolution 1.50 Å R-free 0.167 |
| 7W7J Crystal structure of IrCp* immobilized apo-R52H-rHLFr (25 equiv) Deposited 2021-12-05 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52H | EDO 1,2-ETHANEDIOL × 24 IR IRIDIUM ION × 24 CD CADMIUM ION × 120 CL CHLORIDE ION × 24 SO4 SULFATE ION × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.50 Å R-free 0.210 |
| 8B7L X-ray structure of Auranofin-horse spleen ferritin Deposited 2022-09-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 3 PDB declaration: trimeric |
Chain AAA
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 27 SO4 SULFATE ION × 3 AU GOLD ION × 3 CL CHLORIDE ION × 9 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.2；293 K；0.8 M ammonium sulphate
0.1 M TrisHCl pH 7.4
60 mM cadmium sulphate
|
Resolution 1.24 Å R-free 0.180 |
| 8H8L Crystal structure of apo-R52F/E56F/R59F/E63F-rHLFr Deposited 2022-10-23 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52F,E56F,R59F,E63F | EDO 1,2-ETHANEDIOL × 24 CD CADMIUM ION × 240 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.50 Å R-free 0.171 |
| 8H8M Crystal structure of apo-E53F/E57F/E60F/E64F-rHLFr Deposited 2022-10-23 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53F,E57F,E60F,E64F | EDO 1,2-ETHANEDIOL × 48 CD CADMIUM ION × 192 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.50 Å R-free 0.176 |
| 8H8N Crystal structure of apo-R52Y/E56Y/R59Y/E63Y-rHLFr Deposited 2022-10-23 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52Y,E56Y,R59Y,E63Y | EDO 1,2-ETHANEDIOL × 48 CD CADMIUM ION × 192 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.50 Å R-free 0.178 |
| 8H8O Crystal structure of apo-R52W/E56W/R59W/E63W-rHLFr Deposited 2022-10-23 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52W,E56W,R59W,E63W | EDO 1,2-ETHANEDIOL × 48 CD CADMIUM ION × 168 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Ammonium sulphate, Cadmium sulphate
|
Resolution 1.50 Å R-free 0.179 |
| 8I6L Crystal structure of horse spleen L-ferritin at -180deg Celsius. Deposited 2023-01-28 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 96 CD CADMIUM ION × 216 SO4 SULFATE ION × 96 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 8；293 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.50 Å R-free 0.174 |
| 8I77 Crystal structure of horse spleen L-ferritin A115V mutant at -180deg Celsius. Deposited 2023-01-31 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：A115V | CD CADMIUM ION × 120 SO4 SULFATE ION × 96 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.50 Å R-free 0.177 |
| 8I81 Crystal structure of horse spleen L-ferritin A115G mutant at -180deg Celsius. Deposited 2023-02-02 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：A115G | CD CADMIUM ION × 168 SO4 SULFATE ION × 72 EDO 1,2-ETHANEDIOL × 96 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.50 Å R-free 0.168 |
| 8I8Q Crystal structure of horse spleen L-ferritin H114A mutant at -180deg Celsius. Deposited 2023-02-05 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：H114A | CD CADMIUM ION × 192 SO4 SULFATE ION × 72 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.50 Å R-free 0.174 |
| 8I8U Crystal structure of horse spleen L-ferritin S118A mutant at -180deg Celsius. Deposited 2023-02-05 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Mutation：S118A | EDO 1,2-ETHANEDIOL × 72 SO4 SULFATE ION × 72 CD CADMIUM ION × 96 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.203 |
| 8J0U Crystal structure of horse spleen L-ferritin A115T mutant at -180deg Celsius. Deposited 2023-04-12 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：A115T | EDO 1,2-ETHANEDIOL × 72 CD CADMIUM ION × 216 SO4 SULFATE ION × 72 CL CHLORIDE ION × 24 NA SODIUM ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.50 Å R-free 0.181 |
| 8J0V Crystal structure of horse spleen L-ferritin at -100deg Celsius. Deposited 2023-04-12 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 96 CD CADMIUM ION × 72 SO4 SULFATE ION × 96 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.191 |
| 8J0W Crystal structure of horse spleen L-ferritin at -40deg Celsius. Deposited 2023-04-12 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | SO4 SULFATE ION × 72 CD CADMIUM ION × 72 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.175 |
| 8J0X Crystal structure of horse spleen L-ferritin at -20deg Celsius. Deposited 2023-04-12 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 96 CL CHLORIDE ION × 24 SO4 SULFATE ION × 48 EDO 1,2-ETHANEDIOL × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.169 |
| 8J0Y Crystal structure of horse spleen L-ferritin at 20deg Celsius. Deposited 2023-04-12 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | SO4 SULFATE ION × 48 CD CADMIUM ION × 72 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.190 |
| 8J0Z Crystal structure of horse spleen L-ferritin at -180deg Celsius cooled from -40deg Celsius. Deposited 2023-04-12 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | SO4 SULFATE ION × 96 CD CADMIUM ION × 96 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.202 |
| 8J10 Crystal structure of horse spleen L-ferritin at -180deg Celsius cooled from -20deg Celsius. Deposited 2023-04-12 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 72 CL CHLORIDE ION × 24 SO4 SULFATE ION × 96 EDO 1,2-ETHANEDIOL × 96 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.206 |
| 8J11 Crystal structure of horse spleen L-ferritin at 0deg Celsius. Deposited 2023-04-12 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 24 SO4 SULFATE ION × 48 CD CADMIUM ION × 96 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.186 |
| 8J16 Crystal structure of horse spleen L-ferritin at -80deg Celsius. Deposited 2023-04-12 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain X
2–175（174 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 48 SO4 SULFATE ION × 96 CD CADMIUM ION × 72 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate(12-20mM)
|
Resolution 1.60 Å R-free 0.209 |
| 8KH2 Crystal structure of horse-spleen L-ferritin fused with amyloid beta peptide (1-42). Deposited 2023-08-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Not recorded | CD CADMIUM ION × 216 SO4 SULFATE ION × 72 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293.15 K；Ammonium sulfate (0.5-1.0M), Cadmium sulfate (12-20 mM)
|
Resolution 2.00 Å R-free 0.258 |
| 9E6X Crystal structure of ferritin Deposited 2024-10-31 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
3–172（170 aa）
|
Not recorded | CD CADMIUM ION × 144 FE FE (III) ION × 24 GOL GLYCEROL × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.6M (NH4)2SO4, 50mM CdSO4, 0.1M Hepes, pH7.5
|
Resolution 2.50 Å R-free 0.256 |
| 9KF5 Crystal structure of Ferritin mutant(E53H/E57H) Deposited 2024-11-05 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53H/E57H | EDO 1,2-ETHANEDIOL × 48 CD CADMIUM ION × 144 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Precipitant: (NH4)2SO4 (0.5-1.0M); CdSO4(12-20mM)
Protein: 15-20mg/ml
Crystallization drop: 1:1
|
Resolution 1.50 Å R-free 0.241 |
| 9KF7 Crystal structure of ferritin mutant (R52H/E56H/R59H/E63H) Deposited 2024-11-05 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52H/E56H/R59H/E63H | EDO 1,2-ETHANEDIOL × 48 CD CADMIUM ION × 144 SO4 SULFATE ION × 72 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Precipitant: (NH4)2SO4 (0.5-1.0M), CdSO4(12-20mM)
Protein: 15-20mg/ml
Crystallization drop: 1:1
|
Resolution 1.50 Å R-free 0.187 |
| 9KF8 Crystal structure of ferritin mutant (E53H/E57H/E60H/R64H) Deposited 2024-11-05 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53H/E57H/E60H/R64H | EDO 1,2-ETHANEDIOL × 72 CD CADMIUM ION × 240 SO4 SULFATE ION × 120 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Precipitant: (NH4)2SO4 (0.5-1.0M), CdSO4(12-20mM)
Protein: 15-20mg/ml
Crystallization drop: 1:1
|
Resolution 1.50 Å R-free 0.171 |
| 9KF9 Crystal structure of ferritin mutant(E53H/E56H/E57H/R59H/E60H/E63H) Deposited 2024-11-05 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53H/E56H/E57H/R59H/E60H/E63H | EDO 1,2-ETHANEDIOL × 24 CD CADMIUM ION × 48 SO4 SULFATE ION × 120 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Precipitant: (NH4)2SO4 (0.5-1.0M), CdSO4(12-20mM)
Protein: 15-20mg/ml
Crystallization drop: 1:1
|
Resolution 1.50 Å R-free 0.225 |
| 9KFA Crystal structure of ferritin mutantFr-H8 (R52H/E53H/E56H/E57H/R59H/E60H/E63H/R64H) Deposited 2024-11-05 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52H/E53H/E56H/E57H/R59H/E60H/E63H/R64H | CD CADMIUM ION × 192 EDO 1,2-ETHANEDIOL × 24 SO4 SULFATE ION × 48 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Precipitant: (NH4)2SO4 (0.5-1.0M), CdSO4(12-20mM)
Protein: 15-20mg/ml
Crystallization drop: 1:1
|
Resolution 1.50 Å R-free 0.242 |
| 9KKP Crystal structure of Horse spleen L-ferritin mutant (E53F/E56F/E57F/R59F/E60F/E63F) with Nile Red Deposited 2024-11-14 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53F/E56F/E57F/R59F/E60F/E63F | CD CADMIUM ION × 144 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 72 A1L52 Nile Red × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.60 Å R-free 0.186 |
| 9KKR Crystal structure of Horse spleen L-ferritin mutant (E53F/E56F/E57F/R59F/E60F/E63F) Deposited 2024-11-14 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53F/E56F/E57F/R59F/E60F/E63F | CD CADMIUM ION × 168 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.50 Å R-free 0.203 |
| 9KLE Crystal structure of Horse spleen L-ferritin mutant (R52F/E56F/R59F/E63F) with Nile Red Deposited 2024-11-14 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R52F/E56F/R59F/E63F | CD CADMIUM ION × 96 SO4 SULFATE ION × 24 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 24 A1L52 Nile Red × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.65 Å R-free 0.209 |
| 9KN7 Crystal structure of Horse spleen L-ferritin mutant (Fr-E53F/E56F/E57F/R59L/E60F/E63F) Deposited 2024-11-18 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53F/E56F/E57F/R59L/E60F/E63F | CD CADMIUM ION × 192 SO4 SULFATE ION × 48 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 96 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.50 Å R-free 0.178 |
| 9KN8 Crystal structure of Horse spleen L-ferritin mutant (E53F/E56F/E57F/R59F/E60F/E63F) with Coumarin 153 Deposited 2024-11-18 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53F/E56F/E57F/R59F/E60F/E63F | CD CADMIUM ION × 120 SO4 SULFATE ION × 24 A1L54 Coumarin 153 × 24 EDO 1,2-ETHANEDIOL × 72 CL CHLORIDE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.64 Å R-free 0.208 |
| 9KP2 Crystal structure of Horse spleen L-ferritin mutant (E56F/R59F) with Nile Red Deposited 2024-11-22 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E56F/R59F | CD CADMIUM ION × 216 CL CHLORIDE ION × 24 SO4 SULFATE ION × 48 EDO 1,2-ETHANEDIOL × 96 A1L52 Nile Red × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.50 Å R-free 0.190 |
| 9KP5 Crystal structure of Horse spleen L-ferritin mutant (E56F/R59F) Deposited 2024-11-22 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E56F/R59F | CD CADMIUM ION × 168 SO4 SULFATE ION × 48 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 72 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.50 Å R-free 0.188 |
| 9KP7 Crystal structure of Horse spleen L-ferritin mutant (R59F) with Nile Red Deposited 2024-11-22 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R59F | CD CADMIUM ION × 144 CL CHLORIDE ION × 24 SO4 SULFATE ION × 48 EDO 1,2-ETHANEDIOL × 96 A1L52 Nile Red × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.50 Å R-free 0.196 |
| 9KPA Crystal structure of Horse spleen L-ferritin mutant (R59F) Deposited 2024-11-22 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：R59F | CD CADMIUM ION × 144 SO4 SULFATE ION × 48 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 48 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.50 Å R-free 0.194 |
| 9KRS Crystal structure of Horse spleen L-ferritin mutant (Fr-E53F/E56F/E57F/R59A/E60F/E63F) Deposited 2024-11-28 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 24 PDB declaration: 24-meric |
Chain A
2–175（174 aa）
|
Mutation：E53F/E56F/E57F/R59A/E60F/E63F | CD CADMIUM ION × 144 SO4 SULFATE ION × 48 CL CHLORIDE ION × 24 EDO 1,2-ETHANEDIOL × 96 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；Ammonium sulfate, Cadmium sulfate
|
Resolution 1.53 Å R-free 0.212 |
138 other PDB entries and 138 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | FRIL_HORSE |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 1–175； UniProt 1–175 Author chain B； PDBConstruct 1–175； UniProt 1–175 Author chain C； PDBConstruct 1–175； UniProt 1–175 Author chain D； PDBConstruct 1–175； UniProt 1–175 Author chain E； PDBConstruct 1–175； UniProt 1–175 Author chain F； PDBConstruct 1–175； UniProt 1–175 Author chain G； PDBConstruct 1–175； UniProt 1–175 Author chain H； PDBConstruct 1–175； UniProt 1–175 Author chain I； PDBConstruct 1–175； UniProt 1–175 Author chain J； PDBConstruct 1–175； UniProt 1–175 Author chain K； PDBConstruct 1–175； UniProt 1–175 Author chain L； PDBConstruct 1–175； UniProt 1–175 Author chain M； PDBConstruct 1–175； UniProt 1–175 Author chain N； PDBConstruct 1–175； UniProt 1–175 Author chain O； PDBConstruct 1–175； UniProt 1–175 Author chain P； PDBConstruct 1–175； UniProt 1–175 Author chain Q； PDBConstruct 1–175； UniProt 1–175 Author chain R； PDBConstruct 1–175； UniProt 1–175 Author chain S； PDBConstruct 1–175； UniProt 1–175 Author chain T； PDBConstruct 1–175； UniProt 1–175 Author chain V； PDBConstruct 1–175； UniProt 1–175 Author chain W； PDBConstruct 1–175； UniProt 1–175 Author chain X； PDBConstruct 1–175； UniProt 1–175 Author chain Y； PDBConstruct 1–175； UniProt 1–175 |
