Non-receptor tyrosine-protein kinase TYK2
Homo sapiens
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain A； UniProt 566–870 | Not recorded | ZOI N-[(3M)-3-{6-[(3R)-3-methoxyoxolan-3-yl]pyridin-2-yl}-1-methyl-1H-pyrrolo[2,3-c]pyridin-5-yl]urea × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；30% w/v PEG4,000, 200mM Sodium Acetate, 100mM Tris-HCl pH8.5 | Resolution 1.96 Å R-free 0.236 |
| 2 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain B； UniProt 566–870 | Not recorded | ZOI N-[(3M)-3-{6-[(3R)-3-methoxyoxolan-3-yl]pyridin-2-yl}-1-methyl-1H-pyrrolo[2,3-c]pyridin-5-yl]urea × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；30% w/v PEG4,000, 200mM Sodium Acetate, 100mM Tris-HCl pH8.5 | Resolution 1.96 Å R-free 0.236 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 8TB6 | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 3LXN Structural and Thermodynamic Characterization of the TYK2 and JAK3 Kinase Domains in Complex with CP-690550 and CMP-6 Deposited 2010-02-25 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
888–1182（295 aa）
Fragment：Kinase Domain
|
Mutation：C936A, Q969A, E971A, K972A, C1142A Non-standard monomer：Yes (specific site not provided by mmCIF) | MI1 3-{(3R,4R)-4-methyl-3-[methyl(7H-pyrrolo[2,3-d]pyrimidin-4-yl)amino]piperidin-1-yl}-3-oxopropanenitrile × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；10% Ethanol, 0.1 M Tris, 0.3 M magnesium chloride, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.50 Å R-free 0.286 |
| 3LXP Structural and Thermodynamic Characterization of the TYK2 and JAK3 Kinase Domains in Complex with CP-690550 and CMP-6 Deposited 2010-02-25 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
888–1182（295 aa）
Fragment：Kinase Domain
|
Mutation：C936A, Q969A, E971A, K972A, C1142A Non-standard monomer：Yes (specific site not provided by mmCIF) | IZA 2-TERT-BUTYL-9-FLUORO-3,6-DIHYDRO-7H-BENZ[H]-IMIDAZ[4,5-F]ISOQUINOLINE-7-ONE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；10% Ethanol, 0.1 M Tris, and 0.3 M magnesium chloride, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.65 Å R-free 0.229 |
| 3NYX Non-phosphorylated TYK2 JH1 domain with Quinoline-Thiadiazole-Thiophene Inhibitor Deposited 2010-07-15 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
885–1176（292 aa）
Fragment：kinase domain JH1
|
Mutation：Asp1023Asn | TZ1 N-{5-[(7-chloroquinolin-4-yl)sulfanyl]-1,3,4-thiadiazol-2-yl}thiophene-2-carboxamide × 1 DTT 2,3-DIHYDROXY-1,4-DITHIOBUTANE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 0；293 K；PEG3350, sodium acetate, pH 0.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.50 Å R-free 0.275 |
| 3NZ0 Non-phosphorylated TYK2 kinase with CMP6 Deposited 2010-07-15 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
885–1176（292 aa）
Fragment：Kinase domain JH1
|
Mutation：Asp1023Asn | IZA 2-TERT-BUTYL-9-FLUORO-3,6-DIHYDRO-7H-BENZ[H]-IMIDAZ[4,5-F]ISOQUINOLINE-7-ONE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 0；293 K；KSCN, PEG3350, hexafluoro-2-propanol, pH 0.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.253 |
| 3ZON Human TYK2 pseudokinase domain bound to a kinase inhibitor Deposited 2013-02-22 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
541–873（333 aa）
Fragment：PSEUDOKINASE DOMAIN, RESIDUES 541-873
|
Not recorded | IK1 5-PHENYL-2-UREIDOTHIOPHENE-3-CARBOXAMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；0.1M MES PH 6.5, 12%(W/V) PEG 20000
|
Resolution 2.15 Å R-free 0.268 |
| 4GFO TYK2 kinase (JH1 domain) with 2,6-DICHLORO-N-(2-OXO-2,5-DIHYDROPYRIDIN-4-YL)BENZAMIDE Deposited 2012-08-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
884–1176（293 aa）
Fragment：JH1 domain, UNP residues 884-1176
|
Mutation：D1023N | SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 2 GOL GLYCEROL × 1 0X2 2,6-dichloro-N-(2-oxo-2,5-dihydropyridin-4-yl)benzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5；300 K；2 M ammonium sulfate, pH 5, VAPOR DIFFUSION, SITTING DROP, temperature 300K
|
Resolution 2.30 Å R-free 0.287 |
| 4GIH Tyk2 (JH1) in complex with 2,6-DICHLORO-N-{2-[(CYCLOPROPYLCARBONYL)AMINO]PYRIDIN-4-YL}BENZAMIDE Deposited 2012-08-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
885–1176（292 aa）
Fragment：Kinase domain, UNP residues 885-1176
|
Mutation：C936A, Q969A, E971A, K972A, D1023N, C1142A | 0X5 2,6-dichloro-N-{2-[(cyclopropylcarbonyl)amino]pyridin-4-yl}benzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；20-25%(w/v) PEG3350 and 0.2M Mg sulfate, 0.1M MES pH6.5, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.00 Å R-free 0.217 |
| 4GII Tyk2 (JH1) in complex with 2,6-dichloro-4-cyano-N-{2-[(cyclopropylcarbonyl)amino]pyridin-4-yl}benzamide Deposited 2012-08-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
885–1176（292 aa）
Fragment：Kinase domain, UNP residues 885-1176
|
Mutation：C936A,Q969A,E971A,K972A,D1023N,C1142A | 0X6 2,6-dichloro-4-cyano-N-{2-[(cyclopropylcarbonyl)amino]pyridin-4-yl}benzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；20-25%(w/v) PEG3350 and 0.2M Mg sulfate, 0.1M MES pH6.5, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.31 Å R-free 0.252 |
| 4GJ2 Tyk2 (JH1) in complex with 2,6-dichloro-N-[2-({[(1R,2R)-2-fluorocyclopropyl]carbonyl}amino)pyridin-4-yl]benzamide Deposited 2012-08-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
885–1176（292 aa）
Fragment：Kinase domain, UNP residues 696-1022
|
Mutation：C936A,Q969A,E971A,K972A,D1023N,C1142A | 0XH 2,6-dichloro-N-[2-({[(1R,2R)-2-fluorocyclopropyl]carbonyl}amino)pyridin-4-yl]benzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；20-25%(w/v) PEG3350 and 0.2M Mg sulfate, 0.1M MES pH6.5, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.40 Å R-free 0.237 |
| 4GJ3 Tyk2 (JH1) in complex with 2,6-dichloro-4-cyano-N-[2-({[(1R,2R)-2-fluorocyclopropyl]carbonyl}amino)pyridin-4-yl]benzamide Deposited 2012-08-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
885–1176（292 aa）
Fragment：Kinase domain, UNP residues 885-1176
|
Mutation：C936A,Q969A,E971A,K972A,D1023N,C1142A | 0XP 2,6-dichloro-4-cyano-N-[2-({[(1R,2R)-2-fluorocyclopropyl]carbonyl}amino)pyridin-4-yl]benzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；20-25%(w/v) PEG3350 and 0.2M Mg sulfate, 0.1M MES pH6.5, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.50 Å R-free 0.260 |
| 4GVJ Tyk2 (JH1) in complex with adenosine di-phosphate Deposited 2012-08-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
885–1176（292 aa）
Fragment：Kinase domain, UNP residues 885-1176
|
Mutation：C936A, Q969A, E971A, K972A, C1142A | ADP ADENOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；291 K；20-30% w/v PEG 3350, 0.2M Mg sulfate, 0.1M MES , pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.03 Å R-free 0.231 |
| 4OLI The pseudokinase/kinase protein from JAK-family member TYK2 Deposited 2014-01-23 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
566–1187（622 aa）
|
Mutation：D1023N | 2TT 2-chloro-N-{2-[(cyclopropylcarbonyl)amino]pyridin-4-yl}benzamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.4；291 K；15% PEG monomethylether 2000, HEPES pH 7.4 0.1 M, 1mM TCEP, VAPOR DIFFUSION, SITTING DROP, temperature 291K
|
Resolution 2.80 Å R-free 0.257 |
| 4PO6 Crystal structure of the human TYK2 FERM and SH2 domains with an IFNAR1 intracellular peptide Deposited 2014-02-25 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
23–583（561 aa）
Fragment：unp residues 23-583
|
Not recorded | GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7；293 K；0.1 M Tris HCl pH 7.0, 0.2 M MgCl2, and 8-12% PEG 8000, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.99 Å R-free 0.234 |
| 4PY1 Crystal structure of Tyk2 in complex with compound 15, 6-((2,5-dimethoxyphenyl)thio)-3-(1-methyl-1H-pyrazol-4-yl)-[1,2,4]triazolo[4,3-b]pyridazine Deposited 2014-03-25 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
888–1182（295 aa）
|
Mutation：C936A, Q969A, E971A, K972A, C1142A Non-standard monomer：Yes (specific site not provided by mmCIF) | 2YK 6-[(2,5-dimethoxyphenyl)sulfanyl]-3-(1-methyl-1H-pyrazol-4-yl)[1,2,4]triazolo[4,3-b]pyridazine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.5；298 K；0.1 M Bis-tris pH 5.5, 250 mM NaCl, 10 mM TCEP, 33-40% PEG-3350, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.16 Å R-free 0.236 |
| 4WOV CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH BMS-066 AKA 2-METHOXY-N-({6-[3-METHYL-7-(METHYLAMINO)-3,5,8,10-TETRAAZATRICYCLO[7.3.0.0, 6]DODECA-1(9),2(6),4,7,11-PENTAEN-11-YL]PYRIDIN-2-YL}METHY L)ACETAMIDE Deposited 2014-10-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
575–869（295 aa）
Fragment：PSEUDO KINASE DOMAIN (UNP residues 575-869)
|
Not recorded | 3SM 2-methoxy-N-({6-[1-methyl-4-(methylamino)-1,6-dihydroimidazo[4,5-d]pyrrolo[2,3-b]pyridin-7-yl]pyridin-2-yl}methyl)acetamide × 1 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；30% PEG5000 (methyl ether), 200 mM ammonium sulfate and 100 mM sodium cacodylate buffer, pH 6.5
|
Resolution 1.80 Å R-free 0.214 |
| 4WOV CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH BMS-066 AKA 2-METHOXY-N-({6-[3-METHYL-7-(METHYLAMINO)-3,5,8,10-TETRAAZATRICYCLO[7.3.0.0, 6]DODECA-1(9),2(6),4,7,11-PENTAEN-11-YL]PYRIDIN-2-YL}METHY L)ACETAMIDE Deposited 2014-10-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
575–869（295 aa）
Fragment：PSEUDO KINASE DOMAIN (UNP residues 575-869)
|
Not recorded | 3SM 2-methoxy-N-({6-[1-methyl-4-(methylamino)-1,6-dihydroimidazo[4,5-d]pyrrolo[2,3-b]pyridin-7-yl]pyridin-2-yl}methyl)acetamide × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；30% PEG5000 (methyl ether), 200 mM ammonium sulfate and 100 mM sodium cacodylate buffer, pH 6.5
|
Resolution 1.80 Å R-free 0.214 |
| 4WOV CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH BMS-066 AKA 2-METHOXY-N-({6-[3-METHYL-7-(METHYLAMINO)-3,5,8,10-TETRAAZATRICYCLO[7.3.0.0, 6]DODECA-1(9),2(6),4,7,11-PENTAEN-11-YL]PYRIDIN-2-YL}METHY L)ACETAMIDE Deposited 2014-10-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
575–869（295 aa）
Fragment：PSEUDO KINASE DOMAIN (UNP residues 575-869)
Chain B
575–869（295 aa）
Fragment：PSEUDO KINASE DOMAIN (UNP residues 575-869)
|
Not recorded | 3SM 2-methoxy-N-({6-[1-methyl-4-(methylamino)-1,6-dihydroimidazo[4,5-d]pyrrolo[2,3-b]pyridin-7-yl]pyridin-2-yl}methyl)acetamide × 2 SO4 SULFATE ION × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；30% PEG5000 (methyl ether), 200 mM ammonium sulfate and 100 mM sodium cacodylate buffer, pH 6.5
|
Resolution 1.80 Å R-free 0.214 |
| 5C01 Crystal Structure of kinase Deposited 2015-06-12 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
556–871（316 aa）
Fragment：pseudokinase domain
|
Not recorded | UNL UNKNOWN LIGAND × 1 EDO 1,2-ETHANEDIOL × 2 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；18-22% PEG 4000, 0.1 M Tris, pH 8.5, 200 mM CaCl2
|
Resolution 2.15 Å R-free 0.240 |
| 5C01 Crystal Structure of kinase Deposited 2015-06-12 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
556–871（316 aa）
Fragment：pseudokinase domain
|
Not recorded | UNL UNKNOWN LIGAND × 1 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；18-22% PEG 4000, 0.1 M Tris, pH 8.5, 200 mM CaCl2
|
Resolution 2.15 Å R-free 0.240 |
| 5C03 Crystal Structure of kinase Deposited 2015-06-12 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
556–871（316 aa）
|
Not recorded | AGS PHOSPHOTHIOPHOSPHORIC ACID-ADENYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 EDO 1,2-ETHANEDIOL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；18-22% PEG 4000, 0.1 M Tris, pH 8.5, 200 mM CaCl2
|
Resolution 1.90 Å R-free 0.218 |
| 5C03 Crystal Structure of kinase Deposited 2015-06-12 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
556–871（316 aa）
|
Not recorded | AGS PHOSPHOTHIOPHOSPHORIC ACID-ADENYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 2 EDO 1,2-ETHANEDIOL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；18-22% PEG 4000, 0.1 M Tris, pH 8.5, 200 mM CaCl2
|
Resolution 1.90 Å R-free 0.218 |
| 5F1Z Structure of TYK2 with inhibitor 16: 3-azanyl-5-[(2~{S})-3-methylbutan-2-yl]-7-[1-methyl-5-(2-oxidanylpropan-2-yl)pyrazol-3-yl]-1~{H}-pyrazolo[4,3-c]pyridin-4-one Deposited 2015-12-01 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
884–1176（293 aa）
|
Not recorded | 5U3 3-azanyl-5-[(2~{S})-3-methylbutan-2-yl]-7-[1-methyl-5-(2-oxidanylpropan-2-yl)pyrazol-3-yl]-1~{H}-pyrazolo[4,3-c]pyridin-4-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；293 K；15% PEG 5000 MME, and 100 mM Sodium Citrate (pH 6.0)
|
Resolution 2.65 Å R-free 0.310 |
| 5F20 Structure of TYK2 with inhibitor 4: 3-azanyl-5-(2-methylphenyl)-7-(1-methylpyrazol-3-yl)-1~{H}-pyrazolo[4,3-c]pyridin-4-one Deposited 2015-12-01 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
884–1176（293 aa）
|
Not recorded | 5U4 3-azanyl-5-(2-methylphenyl)-7-(1-methylpyrazol-3-yl)-1~{H}-pyrazolo[4,3-c]pyridin-4-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；293 K；15% PEG 5000 MME, and 100 mM Sodium Citrate (pH 6.0)
|
Resolution 2.91 Å R-free 0.288 |
| 5TKD CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH 6-[(3,5-DIMETHYLPHE NYL)AMINO]-8- (METHYLAMINO)IMIDAZO[1,2-B]PYRIDAZINE-3-CARBO XAMIDE Deposited 2016-10-06 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
575–869（295 aa）
Fragment：pseudo kinase domain (UNP residues 575-869)
|
Not recorded | 7GL 6-[(3,5-dimethylphenyl)amino]-8-(methylamino)imidazo[1,2-b]pyridazine-3-carboxamide × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.5；298 K
|
Resolution 1.92 Å R-free 0.215 |
| 5TKD CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH 6-[(3,5-DIMETHYLPHE NYL)AMINO]-8- (METHYLAMINO)IMIDAZO[1,2-B]PYRIDAZINE-3-CARBO XAMIDE Deposited 2016-10-06 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
575–869（295 aa）
Fragment：pseudo kinase domain (UNP residues 575-869)
|
Not recorded | 7GL 6-[(3,5-dimethylphenyl)amino]-8-(methylamino)imidazo[1,2-b]pyridazine-3-carboxamide × 1 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.5；298 K
|
Resolution 1.92 Å R-free 0.215 |
| 5TKD CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH 6-[(3,5-DIMETHYLPHE NYL)AMINO]-8- (METHYLAMINO)IMIDAZO[1,2-B]PYRIDAZINE-3-CARBO XAMIDE Deposited 2016-10-06 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
575–869（295 aa）
Fragment：pseudo kinase domain (UNP residues 575-869)
Chain B
575–869（295 aa）
Fragment：pseudo kinase domain (UNP residues 575-869)
|
Not recorded | 7GL 6-[(3,5-dimethylphenyl)amino]-8-(methylamino)imidazo[1,2-b]pyridazine-3-carboxamide × 2 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.5；298 K
|
Resolution 1.92 Å R-free 0.215 |
| 5WAL Identification of an imidazopyridine scaffold to generate potent and selective TYK2 inhibitors that demonstrate activity in an in vivo psoriasis model Deposited 2017-06-26 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
884–1176（293 aa）
|
Mutation：C936A, Q969A, E971A, K972A, S1016A, C1142A, D1023N | 9ZS N-[2-(2,6-dichlorophenyl)-1H-imidazo[4,5-c]pyridin-4-yl]cyclopropanecarboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；20-25%(w/v) PEG3350 and 0.2M Mg sulfate, 0.1M MES pH6.5
|
Resolution 2.45 Å R-free 0.243 |
| 6AAM Crystal structure of TYK2 in complex with peficitinib Deposited 2018-07-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
888–1182（295 aa）
|
Mutation：D1023N, I1114L,K972A,E971A,Q969A,C936A,C1142A | 9T6 4-[[(1S,3R)-5-oxidanyl-2-adamantyl]amino]-1H-pyrrolo[2,3-b]pyridine-5-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；277 K；0.1M Bis-Tris pH7.5, 0.2M sodium acetate, 10% glycerol, 20% PEG3350
|
Resolution 1.98 Å R-free 0.238 |
| 6DBK Tyk2 with compound 8 Deposited 2018-05-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
888–1182（295 aa）
Fragment：kinase domain
|
Mutation：C936A, C1142A, Q969A, E971A, K972A Non-standard monomer：Yes (specific site not provided by mmCIF) | G5D 4-({4-[(1S,4S)-5-(cyanoacetyl)-2,5-diazabicyclo[2.2.1]heptan-2-yl]pyrimidin-2-yl}amino)-N-ethylbenzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；298 K；0.1 M bis-tris pH 5.5, 0.25 M NaCl, 10 mM TCEP, 27-33% PEG-3350
|
Resolution 2.00 Å R-free 0.249 |
| 6DBM Tyk2 with compound 23 Deposited 2018-05-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
888–1182（295 aa）
Fragment：kinase domain
|
Mutation：C936A, C1142A, Q969A, E971A, K972A Non-standard monomer：Yes (specific site not provided by mmCIF) | G4J [(1S)-2,2-difluorocyclopropyl][(1R,5S)-3-{2-[(1-methyl-1H-pyrazol-4-yl)amino]pyrimidin-4-yl}-3,8-diazabicyclo[3.2.1]octan-8-yl]methanone × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；298 K；0.1 M bis-tris pH 5.5, 0.25 M NaCl, 10 mM TCEP, 27-33% PEG-3350
|
Resolution 2.37 Å R-free 0.264 |
| 6NSL CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH Compound-6c AKA 6-((1-(4-CYANOPHENY L)-2-OXO-1,2-DIHYDRO-3-PYRIDINYL)AMINO)-N-CYCLOPROPYL-8-(M ETHYLAMINO)IMIDAZO[1,2-B]PYRIDAZINE-3-CARBOXAMIDE Deposited 2019-01-25 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
575–869（295 aa）
Fragment：residues 575-869
|
Not recorded | KZJ 6-{[1-(4-cyanophenyl)-2-oxo-1,2-dihydropyridin-3-yl]amino}-N-cyclopropyl-8-(methylamino)imidazo[1,2-b]pyridazine-3-carboxamide × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；200 mM ammonium sulfate, and 100 mM sodium cacodylate buffer, pH 6.5, 30%(W/V) PEG 5000 (Methyl Ether)
|
Resolution 2.15 Å R-free 0.213 |
| 6NSL CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH Compound-6c AKA 6-((1-(4-CYANOPHENY L)-2-OXO-1,2-DIHYDRO-3-PYRIDINYL)AMINO)-N-CYCLOPROPYL-8-(M ETHYLAMINO)IMIDAZO[1,2-B]PYRIDAZINE-3-CARBOXAMIDE Deposited 2019-01-25 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
575–869（295 aa）
Fragment：residues 575-869
|
Not recorded | KZJ 6-{[1-(4-cyanophenyl)-2-oxo-1,2-dihydropyridin-3-yl]amino}-N-cyclopropyl-8-(methylamino)imidazo[1,2-b]pyridazine-3-carboxamide × 1 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；200 mM ammonium sulfate, and 100 mM sodium cacodylate buffer, pH 6.5, 30%(W/V) PEG 5000 (Methyl Ether)
|
Resolution 2.15 Å R-free 0.213 |
| 6NZE CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH Compound_5 AKA 4-[(2-CARBAMOYLPHEN YL)AMINO]-6-[(5-FLUOROPYRIDIN-2-YL)AMINO]-N-METHYLPYRIDINE -3-CARBOXAMIDE Deposited 2019-02-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
575–869（295 aa）
Fragment：Pseudo kinase domain, residues 575-869
Chain B
575–869（295 aa）
Fragment：Pseudo kinase domain, residues 575-869
|
Not recorded | L8Y 4-[(2-carbamoylphenyl)amino]-6-[(5-fluoropyridin-2-yl)amino]-N-methylpyridine-3-carboxamide × 2 SO4 SULFATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；200 mM ammonium sulfate, and 100 mM HEPES buffer, pH 7.5, 30%(W/V) PEG 5000 (Methyl Ether)
|
Resolution 1.96 Å R-free 0.227 |
| 6NZF CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH Compound_5 AKA 4-[(2-CARBAMOYLPHEN YL)AMINO]-6-[(5-FLUOROPYRIDIN-2-YL)AMINO]-N-METHYLPYRIDINE -3-CARBOXAMIDE Deposited 2019-02-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
575–869（295 aa）
Fragment：Pseudo kinase domain, residues 575-869
Chain B
575–869（295 aa）
Fragment：Pseudo kinase domain, residues 575-869
|
Not recorded | L91 6-[(5-fluoropyridin-2-yl)amino]-N-methyl-4-{[2-(methylsulfonyl)phenyl]amino}pyridine-3-carboxamide × 2 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；200 mM ammonium sulfate, and 100 mM HEPES buffer, pH 7.5, 30%(W/V) PEG 5000 (Methyl Ether)
|
Resolution 2.39 Å R-free 0.231 |
| 6NZH CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH Compound_40 AKA 6-cyclopropaneamido-4-[(2-methanesulfonylphenyl)amino]-N-methylpyridine-3-carboxamide Deposited 2019-02-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
575–869（295 aa）
Chain B
575–869（295 aa）
|
Not recorded | L9A 6-[(cyclopropanecarbonyl)amino]-N-methyl-4-{[2-(methylsulfonyl)phenyl]amino}pyridine-3-carboxamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；200 mM ammonium sulfate, and 100 mM HEPES buffer, pH 7.5, 30%(W/V) PEG 5000 (Methyl Ether)
|
Resolution 2.73 Å R-free 0.215 |
| 6NZP CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH COMPOUND-11 AKA 6-CYCLOPROPANEAMIDO-4-{[2-METHOXY-3-(1-METHYL-1H-1,2,4-TRI AZOL-3-YL)PHENYL]AMINO}-N-(?H?)METHYLPYRIDAZINE-3-CARBOXAMIDE Deposited 2019-02-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
575–869（295 aa）
Fragment：Pseudo kinase domain, residues 575-869
Chain B
575–869（295 aa）
Fragment：Pseudo kinase domain, residues 575-869
|
Not recorded | LB7 6-[(cyclopropanecarbonyl)amino]-4-{[2-methoxy-3-(1-methyl-1H-1,2,4-triazol-3-yl)phenyl]amino}-N-methylpyridazine-3-carboxamide × 2 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；200 mM ammonium sulfate, and 100 mM Cacodylate buffer, pH 7.5, 30%(W/V) PEG 5000 (Methyl Ether)
|
Resolution 2.35 Å R-free 0.238 |
| 6NZP CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH COMPOUND-11 AKA 6-CYCLOPROPANEAMIDO-4-{[2-METHOXY-3-(1-METHYL-1H-1,2,4-TRI AZOL-3-YL)PHENYL]AMINO}-N-(?H?)METHYLPYRIDAZINE-3-CARBOXAMIDE Deposited 2019-02-14 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
575–869（295 aa）
Fragment：Pseudo kinase domain, residues 575-869
|
Not recorded | LB7 6-[(cyclopropanecarbonyl)amino]-4-{[2-methoxy-3-(1-methyl-1H-1,2,4-triazol-3-yl)phenyl]amino}-N-methylpyridazine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；200 mM ammonium sulfate, and 100 mM Cacodylate buffer, pH 7.5, 30%(W/V) PEG 5000 (Methyl Ether)
|
Resolution 2.35 Å R-free 0.238 |
| 6NZP CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH COMPOUND-11 AKA 6-CYCLOPROPANEAMIDO-4-{[2-METHOXY-3-(1-METHYL-1H-1,2,4-TRI AZOL-3-YL)PHENYL]AMINO}-N-(?H?)METHYLPYRIDAZINE-3-CARBOXAMIDE Deposited 2019-02-14 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
575–869（295 aa）
Fragment：Pseudo kinase domain, residues 575-869
|
Not recorded | LB7 6-[(cyclopropanecarbonyl)amino]-4-{[2-methoxy-3-(1-methyl-1H-1,2,4-triazol-3-yl)phenyl]amino}-N-methylpyridazine-3-carboxamide × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；200 mM ammonium sulfate, and 100 mM Cacodylate buffer, pH 7.5, 30%(W/V) PEG 5000 (Methyl Ether)
|
Resolution 2.35 Å R-free 0.238 |
| 6NZQ CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH Compound_29 AKA 6-[(5-FLUORO-4-METH YLPYRIDIN-2-YL)AMINO]-4-({2-METHOXY-3-[(PYRIDIN-2-YLMETHYL )CARBAMOYL]PHENYL}AMINO)-N-METHYLPYRIDINE-3-CARBOXAMIDE Deposited 2019-02-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
575–869（295 aa）
Fragment：Pseudo kinase domain, residues 575-869
Chain B
575–869（295 aa）
Fragment：Pseudo kinase domain, residues 575-869
|
Not recorded | LB4 6-[(5-fluoro-4-methylpyridin-2-yl)amino]-4-[(2-methoxy-3-{[(pyridin-2-yl)methyl]carbamoyl}phenyl)amino]-N-methylpyridine-3-carboxamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；200 mM ammonium sulfate, and 100 mM Sodium Cacodylate, pH 6.5, 30%(W/V) PEG 5000 (Methyl Ether)
|
Resolution 2.11 Å R-free 0.237 |
| 6NZQ CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH Compound_29 AKA 6-[(5-FLUORO-4-METH YLPYRIDIN-2-YL)AMINO]-4-({2-METHOXY-3-[(PYRIDIN-2-YLMETHYL )CARBAMOYL]PHENYL}AMINO)-N-METHYLPYRIDINE-3-CARBOXAMIDE Deposited 2019-02-14 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
575–869（295 aa）
Fragment：Pseudo kinase domain, residues 575-869
|
Not recorded | LB4 6-[(5-fluoro-4-methylpyridin-2-yl)amino]-4-[(2-methoxy-3-{[(pyridin-2-yl)methyl]carbamoyl}phenyl)amino]-N-methylpyridine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；200 mM ammonium sulfate, and 100 mM Sodium Cacodylate, pH 6.5, 30%(W/V) PEG 5000 (Methyl Ether)
|
Resolution 2.11 Å R-free 0.237 |
| 6NZQ CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH Compound_29 AKA 6-[(5-FLUORO-4-METH YLPYRIDIN-2-YL)AMINO]-4-({2-METHOXY-3-[(PYRIDIN-2-YLMETHYL )CARBAMOYL]PHENYL}AMINO)-N-METHYLPYRIDINE-3-CARBOXAMIDE Deposited 2019-02-14 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
575–869（295 aa）
Fragment：Pseudo kinase domain, residues 575-869
|
Not recorded | LB4 6-[(5-fluoro-4-methylpyridin-2-yl)amino]-4-[(2-methoxy-3-{[(pyridin-2-yl)methyl]carbamoyl}phenyl)amino]-N-methylpyridine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；200 mM ammonium sulfate, and 100 mM Sodium Cacodylate, pH 6.5, 30%(W/V) PEG 5000 (Methyl Ether)
|
Resolution 2.11 Å R-free 0.237 |
| 6NZR CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH Compound_12 AKA 4-[(2-methanesulfonylphenyl)amino]-N-(H3)methyl-6-[(pyridin-2- yl)amino]pyridazine-3-carboxamide Deposited 2019-02-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
575–869（295 aa）
Fragment：PSEUDO KINASE DOMAIN, residues 575-869
Chain B
575–869（295 aa）
Fragment：PSEUDO KINASE DOMAIN, residues 575-869
|
Not recorded | LAJ N-methyl-4-{[2-(methylsulfonyl)phenyl]amino}-6-[(pyridin-2-yl)amino]pyridazine-3-carboxamide × 2 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；200 mM ammonium sulfate, and 100 mM Sodium Cacodylate, pH 6.5, 30%(W/V) PEG 5000 (Methyl Ether)
|
Resolution 2.56 Å R-free 0.229 |
| 6OVA Crystal Structure of TYK2 with novel pyrrolidinone inhibitor Deposited 2019-05-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
884–1176（293 aa）
Fragment：residues 884-1176
|
Not recorded | N9G 6-({4-[(3S)-3-cyano-3-cyclopropyl-2-oxopyrrolidin-1-yl]pyridin-2-yl}amino)-N,N-dimethylpyridine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；293 K；15% PEG 5000 MME, and 100 mM Sodium Citrate (pH 6.0)
|
Resolution 2.50 Å R-free 0.251 |
| 6VNS Crystal structure of TYK2 kinase with compound 13 Deposited 2020-01-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
888–1182（295 aa）
Fragment：kinase domain
|
Mutation：C936A, C1142A, Q969A, E971A, K972A Non-standard monomer：Yes (specific site not provided by mmCIF) | R5D (1R,2R)-2-cyano-N-[(1S,5R)-3-(5-fluoro-2-{[1-(2-hydroxyethyl)-1H-pyrazol-4-yl]amino}pyrimidin-4-yl)-3-azabicyclo[3.1.0]hexan-1-yl]cyclopropane-1-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 8；298 K；0.1 M bis-tris pH 5.5, 0.25 M NaCl, 10 mM TCEP, 27-33% PEG-3350
|
Resolution 2.09 Å R-free 0.231 |
| 6VNV Crystal structure of TYK2 kinase with compound 14 Deposited 2020-01-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
888–1182（295 aa）
Fragment：kinase domain
|
Mutation：C936A, C1142A, Q969A, E971A, K972A Non-standard monomer：Yes (specific site not provided by mmCIF) | R4Y (1S,2S)-2-cyano-N-[(1S,5R)-3-(5-fluoro-2-{[1-(2-hydroxyethyl)-1H-pyrazol-4-yl]amino}pyrimidin-4-yl)-3-azabicyclo[3.1.0]hexan-1-yl]cyclopropane-1-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 8；298 K；0.1 M bis-tris pH 5.5, 0.25 M NaCl, 10 mM TCEP, 27-33% PEG-3350
|
Resolution 2.15 Å R-free 0.238 |
| 6VNX Crystal structure of TYK2 kinase with compound 19 Deposited 2020-01-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
888–1182（295 aa）
Fragment：kinase domain
|
Mutation：C936A, C1142A, Q969A, E971A, K972A Non-standard monomer：Yes (specific site not provided by mmCIF) | R4V (1S)-2,2-difluoro-N-[(1S,5R,6R)-3-{5-fluoro-2-[(1-methyl-1H-pyrazol-4-yl)amino]pyrimidin-4-yl}-6-methyl-3-azabicyclo[3.1.0]hexan-1-yl]cyclopropane-1-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 8；298 K；0.1 M bis-tris pH 5.5, 0.25 M NaCl, 10 mM TCEP, 27-33% PEG-3350
|
Resolution 2.18 Å R-free 0.238 |
| 6VNY Crystal structure of TYK2 kinase with compound 10 Deposited 2020-01-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
888–1182（295 aa）
Fragment：kinase domain
|
Mutation：C936A, C1142A, Q969A, E971A, K972A Non-standard monomer：Yes (specific site not provided by mmCIF) | R4S N-[(1S,5R)-3-(5-fluoro-2-{[1-(2-hydroxyethyl)-1H-pyrazol-4-yl]amino}pyrimidin-4-yl)-3-azabicyclo[3.1.0]hexan-1-yl]cyclopropanecarboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 8；298 K；0.1 M bis-tris pH 5.5, 0.25 M NaCl, 10 mM TCEP, 27-33% PEG-3350
|
Resolution 2.30 Å R-free 0.229 |
| 6X8F Crystal structure of TYK2 with Compound 11 Deposited 2020-06-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
888–1182（295 aa）
Fragment：kinase domain
|
Mutation：C936A, C1142A, Q969A, E971A, K972A Non-standard monomer：Yes (specific site not provided by mmCIF) | UWP [3-{4-[6-(1-methyl-1H-pyrazol-4-yl)pyrazolo[1,5-a]pyrazin-4-yl]-1H-pyrazol-1-yl}-1-(2,2,2-trifluoroethyl)azetidin-3-yl]acetonitrile × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 8；298 K；0.1 M bis-tris pH 5.5, 0.25 M NaCl, 10 mM TCEP, 27-33% PEG-3350
|
Resolution 2.15 Å R-free 0.255 |
| 6X8F Crystal structure of TYK2 with Compound 11 Deposited 2020-06-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
888–1182（295 aa）
Fragment：kinase domain
|
Mutation：C936A, C1142A, Q969A, E971A, K972A Non-standard monomer：Yes (specific site not provided by mmCIF) | UWP [3-{4-[6-(1-methyl-1H-pyrazol-4-yl)pyrazolo[1,5-a]pyrazin-4-yl]-1H-pyrazol-1-yl}-1-(2,2,2-trifluoroethyl)azetidin-3-yl]acetonitrile × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 8；298 K；0.1 M bis-tris pH 5.5, 0.25 M NaCl, 10 mM TCEP, 27-33% PEG-3350
|
Resolution 2.15 Å R-free 0.255 |
| 6X8G Crystal structure of TYK2 with Compound 22 Deposited 2020-06-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
888–1182（295 aa）
Fragment：kinase domain
|
Mutation：C936A, C1142A, Q969A, E971A, K972A Non-standard monomer：Yes (specific site not provided by mmCIF) | UWM trans-3-(cyanomethyl)-3-{4-[6-(1-methyl-1H-pyrazol-4-yl)pyrazolo[1,5-a]pyrazin-4-yl]-1H-pyrazol-1-yl}cyclobutane-1-carbonitrile × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 8；298 K；0.1 M bis-tris pH 5.5, 0.25 M NaCl, 10 mM TCEP, 27-33% PEG-3350
|
Resolution 2.21 Å R-free 0.244 |
| 7AX4 Human TYK2 pseudokinase domain (575-869) in complex with 5-(4-Fluoro-phenyl)-2-ureido-thiophene-3-carboxylic acid amide. Deposited 2020-11-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
575–869（295 aa）
|
Not recorded | NM7 2-(carbamoylamino)-5-(4-fluorophenyl)thiophene-3-carboxamide × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；25.5% w/v PEG 4000, 0.21 M calcium chloride, 0.10 M Tris pH 8.5
|
Resolution 2.12 Å R-free 0.229 |
| 7AX4 Human TYK2 pseudokinase domain (575-869) in complex with 5-(4-Fluoro-phenyl)-2-ureido-thiophene-3-carboxylic acid amide. Deposited 2020-11-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
575–869（295 aa）
|
Not recorded | NM7 2-(carbamoylamino)-5-(4-fluorophenyl)thiophene-3-carboxamide × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；25.5% w/v PEG 4000, 0.21 M calcium chloride, 0.10 M Tris pH 8.5
|
Resolution 2.12 Å R-free 0.229 |
| 7K7O CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH COMPOUND-12 AKA:6-[(cyclopropanecarbonyl)amino]-4-{[2-methoxy-3-(pyrimidin-2-yl)phenyl]amino}-N-methylpyridazine-3-carboxamide Deposited 2020-09-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
575–869（295 aa）
Fragment：TYK2-JH2 DOMAIN
Chain B
575–869（295 aa）
Fragment：TYK2-JH2 DOMAIN
|
Not recorded | VZJ 6-[(cyclopropanecarbonyl)amino]-4-{[2-methoxy-3-(pyrimidin-2-yl)phenyl]amino}-N-methylpyridazine-3-carboxamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；200 mM ammonium sulfate, and 100 mM Cacodylate buffer, pH 7.5, 30%(W/V) PEG 5000 (Methyl Ether)
|
Resolution 2.82 Å R-free 0.252 |
| 7K7Q CRYSTAL STRUCTURE OF TYROSINE KINASE 2 JH2 (PSEUDO KINASE DOMAIN) COMPLEXED WITH COMPOUND-12 AKA:6-[(cyclopropanecarbonyl)amino]-4-({3-[6-(dimethylcarbamoyl)pyridazin-3-yl]-2-methoxyphenyl}amino)-N-methylpyridazine-3-carboxamide Deposited 2020-09-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
575–869（295 aa）
Fragment：TYK2-JH2 DOMAIN
Chain B
575–869（295 aa）
Fragment：TYK2-JH2 DOMAIN
|
Not recorded | VZG 6-[(cyclopropanecarbonyl)amino]-4-({3-[6-(dimethylcarbamoyl)pyridazin-3-yl]-2-methoxyphenyl}amino)-N-methylpyridazine-3-carboxamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；200 mM ammonium sulfate, and 100 mM Cacodylate buffer, pH 7.5, 30%(W/V) PEG 5000 (Methyl Ether)
|
Resolution 2.27 Å R-free 0.215 |
| 7UYR Crystal structure of TYK2 kinase domain in complex with compound 12 Deposited 2022-05-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
889–1177（289 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | OVI 2-(4-{[2-(2,6-difluorophenyl)-5-oxo-5H-pyrrolo[3,4-d]pyrimidin-4-yl]amino}phenyl)-N-ethylacetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；291 K；Crystals of human TYK2 in complex with the ligand were prepared according to established protocols
|
Resolution 2.15 Å R-free 0.259 |
| 7UYS Crystal structure of TYK2 kinase domain in complex with compound 16 Deposited 2022-05-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
889–1177（289 aa）
Fragment：KINASE DOMAIN
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | OVC 2-(2,6-difluorophenyl)-4-(4-methoxyanilino)-5H-pyrrolo[3,4-d]pyrimidin-5-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；291 K；Crystals of human TYK2 in complex with the ligand were prepared according to established protocols
|
Resolution 2.15 Å R-free 0.272 |
| 7UYT Crystal structure of TYK2 kinase domain in complex with compound 25 Deposited 2022-05-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
889–1177（289 aa）
Fragment：KINASE DOMAIN
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | OV5 6-{[(2M)-2-(2-chloro-6-fluorophenyl)-5-oxo-5H-pyrrolo[3,4-b]pyridin-4-yl]amino}-N-ethylpyridine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；291 K；Crystals of human TYK2 in complex with the ligand were prepared according to established protocols
|
Resolution 2.14 Å R-free 0.293 |
| 7UYU Crystal structure of TYK2 kinase domain in complex with compound 30 Deposited 2022-05-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
889–1177（289 aa）
Fragment：KINASE DOMAIN
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | OV0 2-(2,6-difluorophenyl)-4-[4-(pyrrolidine-1-carbonyl)anilino]-5H-pyrrolo[3,4-b]pyridin-5-one × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；291 K；Crystals of human TYK2 in complex with the ligand were prepared according to established protocols
|
Resolution 2.05 Å R-free 0.257 |
| 8EXN Crystal structure of PTP1B D181A/Q262A phosphatase domain with TYK2 activation loop phosphopeptide Deposited 2022-10-25 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain D
1048–1062（15 aa）
Fragment：residues 1048-1062 of TYK2
|
Not recorded | PO4 PHOSPHATE ION × 1 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281.15 K；0.2 M Calcium Acetate, 12.5% PEG 4K, 0.05 M MES (pH 6.5)
|
Resolution 2.15 Å R-free 0.241 |
| 8EYC Crystal structure of PTP1B D181A/Q262A/C215A phosphatase domain with TYK2 activation loop phosphopeptide Deposited 2022-10-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1048–1062（15 aa）
Fragment：residues 1048-1062 of TYK2
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281.15 K；14% PEG 8K, 0.20 M Magnesium Acetate, 0.1 M MES (pH 6.5)
|
Resolution 2.99 Å R-free 0.254 |
| 8S98 Crystal structure of the TYK2 pseudokinase domain in complex with compound 8 Deposited 2023-03-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
575–869（295 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | ZRU (8S)-N-cyclopropyl-5-[(2-methoxypyridin-3-yl)amino]-7-(methylamino)pyrazolo[1,5-a]pyrimidine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；The purified protein was used in crystallization trials employing both, a standard screen with approximately 1200 different conditions, as well as crystallization conditions identified using literature data. Conditions initially obtained have been optimised using standard strategies, systematically varying parameters critically influencing crystallization, such as temperature, protein concentration, drop ratio, and others. These conditions were also refined by systematically varying pH or precipitant concentrations.
|
Resolution 1.87 Å R-free 0.274 |
| 8S98 Crystal structure of the TYK2 pseudokinase domain in complex with compound 8 Deposited 2023-03-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
575–869（295 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | ZRU (8S)-N-cyclopropyl-5-[(2-methoxypyridin-3-yl)amino]-7-(methylamino)pyrazolo[1,5-a]pyrimidine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；The purified protein was used in crystallization trials employing both, a standard screen with approximately 1200 different conditions, as well as crystallization conditions identified using literature data. Conditions initially obtained have been optimised using standard strategies, systematically varying parameters critically influencing crystallization, such as temperature, protein concentration, drop ratio, and others. These conditions were also refined by systematically varying pH or precipitant concentrations.
|
Resolution 1.87 Å R-free 0.274 |
| 8S98 Crystal structure of the TYK2 pseudokinase domain in complex with compound 8 Deposited 2023-03-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
575–869（295 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | ZRU (8S)-N-cyclopropyl-5-[(2-methoxypyridin-3-yl)amino]-7-(methylamino)pyrazolo[1,5-a]pyrimidine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；The purified protein was used in crystallization trials employing both, a standard screen with approximately 1200 different conditions, as well as crystallization conditions identified using literature data. Conditions initially obtained have been optimised using standard strategies, systematically varying parameters critically influencing crystallization, such as temperature, protein concentration, drop ratio, and others. These conditions were also refined by systematically varying pH or precipitant concentrations.
|
Resolution 1.87 Å R-free 0.274 |
| 8S99 Crystal structure of the TYK2 pseudokinase domain in complex with compound 11 Deposited 2023-03-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
575–869（295 aa）
|
Not recorded | ZS3 (8S)-N-[(1R,2S)-2-fluorocyclopropyl]-5-{[(1M,2'M)-3'-fluoro-2-oxo-2H-[1,2'-bipyridin]-3-yl]amino}-7-(methylamino)pyrazolo[1,5-a]pyrimidine-3-carboxamide × 1 EDO 1,2-ETHANEDIOL × 2 ACT ACETATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；298 K；The purified protein was used in crystallization trials employing both, a standard screen with approximately 1200 different conditions, as well as crystallization conditions identified using literature data. Conditions initially obtained have been optimized using standard strategies, systematically varying parameters critically influencing crystallization, such as temperature, protein concentration, drop ratio, and others. These conditions were also refined by systematically varying pH or precipitant concentrations.
|
Resolution 1.71 Å R-free 0.225 |
| 8S99 Crystal structure of the TYK2 pseudokinase domain in complex with compound 11 Deposited 2023-03-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
575–869（295 aa）
|
Not recorded | ZS3 (8S)-N-[(1R,2S)-2-fluorocyclopropyl]-5-{[(1M,2'M)-3'-fluoro-2-oxo-2H-[1,2'-bipyridin]-3-yl]amino}-7-(methylamino)pyrazolo[1,5-a]pyrimidine-3-carboxamide × 1 EDO 1,2-ETHANEDIOL × 2 ACT ACETATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；298 K；The purified protein was used in crystallization trials employing both, a standard screen with approximately 1200 different conditions, as well as crystallization conditions identified using literature data. Conditions initially obtained have been optimized using standard strategies, systematically varying parameters critically influencing crystallization, such as temperature, protein concentration, drop ratio, and others. These conditions were also refined by systematically varying pH or precipitant concentrations.
|
Resolution 1.71 Å R-free 0.225 |
| 8S99 Crystal structure of the TYK2 pseudokinase domain in complex with compound 11 Deposited 2023-03-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
575–869（295 aa）
|
Not recorded | ZS3 (8S)-N-[(1R,2S)-2-fluorocyclopropyl]-5-{[(1M,2'M)-3'-fluoro-2-oxo-2H-[1,2'-bipyridin]-3-yl]amino}-7-(methylamino)pyrazolo[1,5-a]pyrimidine-3-carboxamide × 1 EDO 1,2-ETHANEDIOL × 2 ACT ACETATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；298 K；The purified protein was used in crystallization trials employing both, a standard screen with approximately 1200 different conditions, as well as crystallization conditions identified using literature data. Conditions initially obtained have been optimized using standard strategies, systematically varying parameters critically influencing crystallization, such as temperature, protein concentration, drop ratio, and others. These conditions were also refined by systematically varying pH or precipitant concentrations.
|
Resolution 1.71 Å R-free 0.225 |
| 8S9A Crystal structure of the TYK2 pseudokinase domain in complex with TAK-279 Deposited 2023-03-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
575–869（295 aa）
|
Not recorded | ZSB (8S)-N-[(1R,2R)-2-methoxycyclobutyl]-7-(methylamino)-5-{[(1P,2'P)-2-oxo-2H-[1,2'-bipyridin]-3-yl]amino}pyrazolo[1,5-a]pyrimidine-3-carboxamide × 1 ACT ACETATE ION × 3 EDO 1,2-ETHANEDIOL × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；298 K；The purified protein was used in crystallization trials employing both, a standard screen with approximately 1200 different conditions, as well as crystallization conditions identified using literature data. Conditions initially obtained have been optimized using standard strategies, systematically varying parameters critically influencing crystallization, such as temperature, protein concentration, drop ratio, and others. These conditions were also refined by systematically varying pH or precipitant concentrations
|
Resolution 1.83 Å R-free 0.224 |
| 8S9A Crystal structure of the TYK2 pseudokinase domain in complex with TAK-279 Deposited 2023-03-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
575–869（295 aa）
|
Not recorded | ZSB (8S)-N-[(1R,2R)-2-methoxycyclobutyl]-7-(methylamino)-5-{[(1P,2'P)-2-oxo-2H-[1,2'-bipyridin]-3-yl]amino}pyrazolo[1,5-a]pyrimidine-3-carboxamide × 1 ACT ACETATE ION × 2 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；298 K；The purified protein was used in crystallization trials employing both, a standard screen with approximately 1200 different conditions, as well as crystallization conditions identified using literature data. Conditions initially obtained have been optimized using standard strategies, systematically varying parameters critically influencing crystallization, such as temperature, protein concentration, drop ratio, and others. These conditions were also refined by systematically varying pH or precipitant concentrations
|
Resolution 1.83 Å R-free 0.224 |
| 8S9A Crystal structure of the TYK2 pseudokinase domain in complex with TAK-279 Deposited 2023-03-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
575–869（295 aa）
|
Not recorded | ZSB (8S)-N-[(1R,2R)-2-methoxycyclobutyl]-7-(methylamino)-5-{[(1P,2'P)-2-oxo-2H-[1,2'-bipyridin]-3-yl]amino}pyrazolo[1,5-a]pyrimidine-3-carboxamide × 1 ACT ACETATE ION × 3 EDO 1,2-ETHANEDIOL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；298 K；The purified protein was used in crystallization trials employing both, a standard screen with approximately 1200 different conditions, as well as crystallization conditions identified using literature data. Conditions initially obtained have been optimized using standard strategies, systematically varying parameters critically influencing crystallization, such as temperature, protein concentration, drop ratio, and others. These conditions were also refined by systematically varying pH or precipitant concentrations
|
Resolution 1.83 Å R-free 0.224 |
| 8TB5 TYK2 JH2 bound to Compound7 Deposited 2023-06-28 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
566–870（305 aa）
|
Not recorded | ACT ACETATE ION × 1 ZOQ N-{(3P)-3-[3-(dimethylsulfamoyl)phenyl]-1H-pyrrolo[2,3-c]pyridin-5-yl}cyclopropanecarboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；293 K；30% w/v PEG4,000, 200mM Sodium Acetate, 100mM Tris-HCl pH8.5
|
Resolution 2.32 Å R-free 0.243 |
| 8TB5 TYK2 JH2 bound to Compound7 Deposited 2023-06-28 | Different ligand/ion Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
566–870（305 aa）
|
Not recorded | ACT ACETATE ION × 1 ZOQ N-{(3P)-3-[3-(dimethylsulfamoyl)phenyl]-1H-pyrrolo[2,3-c]pyridin-5-yl}cyclopropanecarboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；293 K；30% w/v PEG4,000, 200mM Sodium Acetate, 100mM Tris-HCl pH8.5
|
Resolution 2.32 Å R-free 0.243 |
51 other PDB entries and 71 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | TYK2_HUMAN |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 22–326； UniProt 566–870 Author chain B； PDBConstruct 22–326； UniProt 566–870 |
