8zeu

CryoEM structure of GR2002-F(ab')2: TSLP complex

Method: ELECTRON MICROSCOPY
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Thymic stromal lymphopoietin

Homo sapiens

UniProt Q969D9

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 10 Fab-H1A10 fragment, heavy chain × 2 Fab fragment, light chain × 4 Fab-H3B10 fragment, heavy chain × 2 Consistent with protein count

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
5j11 5j12 5j13 8qfz 8zeu

5 assemblies

View Construct and Data Evidence
UniProt name TSLP_HUMAN
Isoform —
PDB entities 3
Chains and sequence ranges Author chain C； PDBConstruct 1–127； UniProt 29–155 Author chain G； PDBConstruct 1–127； UniProt 29–155

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id8zeu
Deposition date deposition_date2024-05-07
Structure title titleCryoEM structure of GR2002-F(ab')2: TSLP complex
Keywords keywords;Cryo-EM, TSLP-F(ab')2 complex, bispecific antibody, IMMUNE SYSTEM ;; IMMUNE SYSTEM
Experimental Method methodELECTRON MICROSCOPY
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

8zeu__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

8zeu__assembly_1__model_1 | I(q)

10-2 10-1 106 107 108 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

8zeu__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）52.41 Å
Rg (electron density)51.95 Å
Total Rg52.32 Å
Atom count14534
Residues1906
Excluded volume257580 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 8zeu__assembly_1__model_1 decameric （10） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (4)

▶

7. Citations (1)
