9pv6

SARS-CoV-2 Papain-like Protease (PLpro) in complex with Fragment 37

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Papain-like protease nsp3

Severe acute respiratory syndrome coronavirus 2

UniProt P0DTD1

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein monomer Monomer Protein 1 ZINC ION × 1 1,2-ETHANEDIOL × 2 (7M)-8-methyl-7-(2-methylpyridin-4-yl)-1'-[(pyridin-2-yl)methyl]spiro[[1]benzopyran-2,4'-piperidin]-4(3H)-one × 1 SODIUM ION × 1 water × 1 Consistent with protein count

Other States of the Same Protein in the Database

Monomer
13mi 13mj 13mk 13ml 13mm 13mn 13mo 13mp 13mq 13mr 13ms 13mt

2357 assemblies; showing the first 12

Homodimer
11ro 12af 23lw 23lx 23lz 23lz 23ma 23mc 23md 23me 23mf 23mg

1611 assemblies; showing the first 12

Homotetramer
6m71 6wiq 6wqd 6wtc 6xip 7btf 7bv1 7bw4 7cjd 7d4f 7dvp 7dvw

29 assemblies; showing the first 12

Other homooligomers
5s6x 5s6y 5s6z 5s70 5s71 5s72 5sa4 5sa5 5sa6 5sa7 5sa8 5sa9

59 assemblies; showing the first 12

Heteromeric or nucleic-acid complex
10dv 24ew 28wf 6lu7 6wuu 6wuu 6wuu 6wuu 6wx4 6x1b 6xa4 6xa9

269 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name R1AB_SARS2
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 2–318； UniProt 1563–1879

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id9pv6
Deposition date deposition_date2025-08-01
Structure title titleSARS-CoV-2 Papain-like Protease (PLpro) in complex with Fragment 37
Keywords keywordsViral protease, Inhibitor complex, VIRAL PROTEIN; VIRAL PROTEIN
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

9pv6__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

9pv6__assembly_1__model_1 | I(q)

10-2 10-1 105 106 107 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

9pv6__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）23.60 Å
Rg (electron density)22.83 Å
Total Rg23.78 Å
Atom count2420
Residues312
Excluded volume42756 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 9pv6__assembly_1__model_1 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
▶
