9v4f

Soy storage protein fibril (glycinin A) PM2

Method: ELECTRON MICROSCOPY
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Glycinin G4

Glycine max

UniProt P02858

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein homooligomer Homooligomer Protein 10 No other associated polymer Consistent with protein count

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers
9v45 9v4f

2 assemblies

Heteromeric or nucleic-acid complex

None

View Construct and Data Evidence
UniProt name GLYG4_SOYBN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 1–563； UniProt 1–563 Author chain B； PDBConstruct 1–563； UniProt 1–563 Author chain C； PDBConstruct 1–563； UniProt 1–563 Author chain D； PDBConstruct 1–563； UniProt 1–563 Author chain E； PDBConstruct 1–563； UniProt 1–563 Author chain F； PDBConstruct 1–563； UniProt 1–563 Author chain G； PDBConstruct 1–563； UniProt 1–563 Author chain H； PDBConstruct 1–563； UniProt 1–563 Author chain I； PDBConstruct 1–563； UniProt 1–563 Author chain J； PDBConstruct 1–563； UniProt 1–563

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id9v4f
Deposition date deposition_date2025-05-23
Structure title titleSoy storage protein fibril (glycinin A) PM2
Keywords keywordsSoy storage protein fibril, PROTEIN FIBRIL; PROTEIN FIBRIL
Experimental Method methodELECTRON MICROSCOPY
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

9v4f__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

9v4f__assembly_1__model_1 | I(q)

10-2 10-1 105 106 107 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

9v4f__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）18.17 Å
Rg (electron density)18.03 Å
Total Rg19.57 Å
Atom count1990
Residues260
Excluded volume36690 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 9v4f__assembly_1__model_1 decameric （10） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (1)

▶

7. Citations (1)
