Entity 1
polymer
| description | ;3',5'-cyclic-AMP phosphodiesterase 4D
; |
| formula_weight | 37706.7 kDa |
| ec_number | 3.1.4.53 |
| src_method | man |
| entity_count | 2 |
Polymer
| type | polypeptide(L) |
| strand_id | A,B |
| atom_count | 5531 |
TEQEDVLAKELEDVNKWGLHVFRIAELSGNRPLTVIMHTIFQERDLLKTFKIPVDTLITYLMTLEDHYHADVAYHNNIHAADVVQSTHVLLSTPALEAVFTDLEILAAIFASAIHDVDHPGVSNQFLINTNSELALMYNDSSVLENHHLAVGFKLLQEENCDIFQNLTKKQRQSLRKMVIDIVLATDMSKHMNLLADLKTMVETKKVTSSGVLLLDNYSDRIQVLQNMVHCADLSNPTKPLQLYRQWTDRIMEEFFRQGDRERERGMEISPMCDKHNASVEKSQVGFIDYIVHPLWETWADLVHPDAQDILDTLEDNREWYQSTIPQ
Source
| organism | Homo sapiens |
| common_name | human |
| ncbi_taxonomy_id | 9606 |
| host_organism | Escherichia coli BL21 |
Entity 2
non-polymer
| description | ZINC ION |
| formula_weight | 65.4 kDa |
| src_method | syn |
| entity_count | 2 |
Entity 3
non-polymer
| description | MAGNESIUM ION |
| formula_weight | 24.3 kDa |
| src_method | syn |
| entity_count | 2 |
Entity 4
non-polymer
| description | (3~{S},3~{a}~{R},6~{S},6~{a}~{R})-3,6-bis(3,4-dimethoxyphenyl)-1,3,3~{a},4,6,6~{a}-hexahydrofuro[3,4-c]furan |
| formula_weight | 386.4 kDa |
| src_method | syn |
| entity_count | 2 |
Entity 5
water
| description | water |
| formula_weight | 18.0 kDa |
| src_method | nat |
| entity_count | 245 |
