GLYCOGEN SYNTHASE KINASE-3 BETA
HOMO SAPIENS
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein homooligomer Homooligomer Protein × 2 PDB declaration: dimeric（2） Consistent with protein copy count | Chain A； UniProt 35–386 Chain B； UniProt 35–386 | Not recorded | EPE 4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID × 2 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, HANGING DROP；pH 7.5；CRYSTAL WERE GROWN BY THE HANGING DROP METHOD. 1UL OF PROTEIN SOLUTION (4MG/ML IN 20MM HEPES-NAOH, 500MM NACL, 2MM MGCL2, 1MM DTT, PH 7.2) WAS MIXED WITH 1UL PRECIPITANT (6% PEG8000, 100MM TRIS-HCL, PH 7.5) | Resolution 2.80 Å R-free 0.256 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 1H8F | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 1GNG Glycogen synthase kinase-3 beta (GSK3) complex with FRATtide peptide Deposited 2001-10-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
27–393（367 aa）
Fragment：RESIDUES 27-393
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；1.6M AMMONIUM SULPHATE, 0.1M TRIS PH7.5, pH 7.50
|
Resolution 2.60 Å R-free 0.262 |
| 1GNG Glycogen synthase kinase-3 beta (GSK3) complex with FRATtide peptide Deposited 2001-10-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
27–393（367 aa）
Fragment：RESIDUES 27-393
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 2 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；1.6M AMMONIUM SULPHATE, 0.1M TRIS PH7.5, pH 7.50
|
Resolution 2.60 Å R-free 0.262 |
| 1I09 STRUCTURE OF GLYCOGEN SYNTHASE KINASE-3 (GSK3B) Deposited 2001-01-29 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Not recorded | PO4 PHOSPHATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.1；277 K；PEG 3350 Na/K Phosphate DTT, pH 4.1, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.70 Å R-free 0.274 |
| 1I09 STRUCTURE OF GLYCOGEN SYNTHASE KINASE-3 (GSK3B) Deposited 2001-01-29 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Not recorded | PO4 PHOSPHATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.1；277 K；PEG 3350 Na/K Phosphate DTT, pH 4.1, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.70 Å R-free 0.274 |
| 1J1B Binary complex structure of human tau protein kinase I with AMPPNP Deposited 2002-12-03 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
Chain B
1–420（420 aa）
|
Not recorded | ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；278 K；PEG6000, sodium chloride, magnesium chloride, glycerol, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 278K
|
Resolution 1.80 Å R-free 0.242 |
| 1J1C Binary complex structure of human tau protein kinase I with ADP Deposited 2002-12-03 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
Chain B
1–420（420 aa）
|
Not recorded | MG MAGNESIUM ION × 2 ADP ADENOSINE-5'-DIPHOSPHATE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；278 K；PEG6000, sodium chloride, magnesium chloride, glycerol, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 278K
|
Resolution 2.10 Å R-free 0.242 |
| 1O6K Structure of activated form of PKB kinase domain S474D with GSK3 peptide and AMP-PNP Deposited 2002-10-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
3–12（10 aa）
Fragment：PEPTIDE, RESIDUES 3-12
|
Not recorded | ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 MN MANGANESE (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；10 MG/ML PROTEIN 20 PEG 4K, 10% ISOPROPONAL, 5 MM DTT, pH 7.50
|
Resolution 1.70 Å R-free 0.234 |
| 1O6L Crystal structure of an activated Akt/protein kinase B (PKB-PIF chimera) ternary complex with AMP-PNP and GSK3 peptide Deposited 2002-10-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
3–12（10 aa）
Fragment：PEPTIDE, RESIDUES 3-12
|
Not recorded | ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 MN MANGANESE (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；10 MG/ML PROTEIN, 20% (W/V) POLYETHYLENE, GLYCOL 4000, 10% (V/V) ISOPROPANOL, 0.1 M HEPES (PH 7.5), 5 MM DTT
|
Resolution 1.60 Å R-free 0.227 |
| 1O9U GLYCOGEN SYNTHASE KINASE 3 BETA COMPLEXED WITH AXIN PEPTIDE Deposited 2002-12-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
35–384（350 aa）
Fragment：RESIDUES 35-384
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | ADZ 9-METHYL-9H-PURIN-6-AMINE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；CRYSTAL WERE GROWN BY THE HANGING DROP METHOD. 1UL OF PROTEIN SOLUTION (6MG/ML GSK3B AND 0.37MG/ML AXIN PEPTIDE) IN 25MM HEPES-NAOH, 250MM NACL, 1MM DTT, PH 7.0) WAS MIXED WITH 1UL PRECIPITANT (18% PEG4000, 150MM MGCL2, 100MM TRIS- HCL, PH 7.5)
|
Resolution 2.40 Å R-free 0.260 |
| 1PYX GSK-3 Beta complexed with AMP-PNP Deposited 2003-07-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
Chain B
1–420（420 aa）
|
Not recorded | MG MAGNESIUM ION × 4 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7；298 K；PEG 3350 monodisperse, Glycerol, Magnesium Chloride, Hepes, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K, pH 7.00
|
Resolution 2.40 Å R-free 0.233 |
| 1Q3D GSK-3 Beta complexed with Staurosporine Deposited 2003-07-29 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–420（419 aa）
Chain B
2–420（419 aa）
|
Not recorded | STU STAUROSPORINE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；PEG 3350 MONODISPERSE, GLYCEROL, MAGNESIUM CHLORIDE, HEPES, pH 7.00, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.20 Å R-free 0.252 |
| 1Q3W GSK-3 Beta complexed with Alsterpaullone Deposited 2003-08-01 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–420（419 aa）
Chain B
2–420（419 aa）
|
Not recorded | ATU 9-NITRO-5,12-DIHYDRO-7H-BENZO[2,3]AZEPINO[4,5-B]INDOL-6-ONE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；PEG 3350 MONODISPERSE, GLYCEROL, MAGNESIUM CHLORIDE, HEPES, pH 7.00, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.30 Å R-free 0.248 |
| 1Q41 GSK-3 Beta complexed with Indirubin-3'-monoxime Deposited 2003-08-01 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–420（419 aa）
Chain B
2–420（419 aa）
|
Not recorded | IXM (Z)-1H,1'H-[2,3']BIINDOLYLIDENE-3,2'-DIONE-3-OXIME × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；PEG 3350 MONODISPERSE, GLYCEROL, MAGNESIUM CHLORIDE, HEPES, pH 7.00, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.10 Å R-free 0.245 |
| 1Q4L GSK-3 Beta complexed with Inhibitor I-5 Deposited 2003-08-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–420（419 aa）
Chain B
2–420（419 aa）
|
Not recorded | 679 2-CHLORO-5-[4-(3-CHLORO-PHENYL)-2,5-DIOXO-2,5-DIHYDRO-1H-PYRROL-3-YLAMINO]-BENZOIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；PEG 3350 MONODISPERSE, GLYCEROL, MAGNESIUM CHLORIDE, HEPES, pH 7.00, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.77 Å R-free 0.251 |
| 1Q5K crystal structure of Glycogen synthase kinase 3 in complexed with inhibitor Deposited 2003-08-08 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
7–420（414 aa）
Chain B
7–420（414 aa）
|
Not recorded | TMU N-(4-METHOXYBENZYL)-N'-(5-NITRO-1,3-THIAZOL-2-YL)UREA × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.94 Å R-free 0.242 |
| 1R0E Glycogen synthase kinase-3 beta in complex with 3-indolyl-4-arylmaleimide inhibitor Deposited 2003-09-20 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
35–420（386 aa）
Chain B
35–420（386 aa）
|
Not recorded | FLC CITRATE ANION × 2 DFN 3-[3-(2,3-DIHYDROXY-PROPYLAMINO)-PHENYL]-4-(5-FLUORO-1-METHYL-1H-INDOL-3-YL)-PYRROLE-2,5-DIONE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.4；277 K；PEG3350, ammonium fluoride, pH 7.4, VAPOR DIFFUSION, temperature 277K
|
Resolution 2.25 Å R-free 0.252 |
| 1UV5 GLYCOGEN SYNTHASE KINASE 3 BETA COMPLEXED WITH 6-BROMOINDIRUBIN-3'-OXIME Deposited 2004-01-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
35–384（350 aa）
|
Not recorded | BRW 6-BROMOINDIRUBIN-3'-OXIME × 2 PO4 PHOSPHATE ION × 4 CL CHLORIDE ION × 2 CO COBALT (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；pH 7.50
|
Resolution 2.80 Å R-free 0.226 |
| 2JDO STRUCTURE OF PKB-BETA (AKT2) COMPLEXED WITH ISOQUINOLINE-5-SULFONIC ACID (2-(2-(4-CHLOROBENZYLOXY) ETHYLAMINO)ETHYL)AMIDE Deposited 2007-01-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
3–12（10 aa）
Fragment：RESIDUES 3-12
|
Not recorded | I5S ISOQUINOLINE-5-SULFONIC ACID (2-(2-(4-CHLOROBENZYLOXY)ETHYLAMINO)ETHYL)AMIDE × 1 EDO 1,2-ETHANEDIOL × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.80 Å R-free 0.210 |
| 2JDR STRUCTURE OF PKB-BETA (AKT2) COMPLEXED WITH THE INHIBITOR A-443654 Deposited 2007-01-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
3–12（10 aa）
Fragment：RESIDUES 3-12
|
Not recorded | L20 (2S)-1-(1H-INDOL-3-YL)-3-{[5-(3-METHYL-1H-INDAZOL-5-YL)PYRIDIN-3-YL]OXY}PROPAN-2-AMINE × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å R-free 0.252 |
| 2JLD Extremely Tight Binding of Ruthenium Complex to Glycogen Synthase Kinase 3 Deposited 2008-09-08 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–420（420 aa）
Chain B
1–420（420 aa）
|
Not recorded | AG1 RUTHENIUM PYRIDOCARBAZOLE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.2；100MM TRIS PH 7.4, 500MM NACL, 12.5% PEG 8000, 1MM MGCL2, 1MM DTT
|
Resolution 2.35 Å R-free 0.227 |
| 2JLD Extremely Tight Binding of Ruthenium Complex to Glycogen Synthase Kinase 3 Deposited 2008-09-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Not recorded | AG1 RUTHENIUM PYRIDOCARBAZOLE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.2；100MM TRIS PH 7.4, 500MM NACL, 12.5% PEG 8000, 1MM MGCL2, 1MM DTT
|
Resolution 2.35 Å R-free 0.227 |
| 2JLD Extremely Tight Binding of Ruthenium Complex to Glycogen Synthase Kinase 3 Deposited 2008-09-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
|
Not recorded | AG1 RUTHENIUM PYRIDOCARBAZOLE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.2；100MM TRIS PH 7.4, 500MM NACL, 12.5% PEG 8000, 1MM MGCL2, 1MM DTT
|
Resolution 2.35 Å R-free 0.227 |
| 2O5K Crystal Structure of GSK3beta in complex with a benzoimidazol inhibitor Deposited 2006-12-06 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
29–393（365 aa）
Fragment：residues 22-393
|
Not recorded | HBM 2-(2,4-DICHLORO-PHENYL)-7-HYDROXY-1H-BENZOIMIDAZOLE-4-CARBOXYLIC ACID [2-(4-METHANESULFONYLAMINO-PHENYL)-ETHYL]-AMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；277 K；0.1M HEPES Na, 0.1M Proline, 20% PEG3350, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 3.20 Å R-free 0.309 |
| 2OW3 Glycogen synthase kinase-3 beta in complex with bis-(indole)maleimide pyridinophane inhibitor Deposited 2007-02-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
35–386（352 aa）
Fragment：residues 35-386
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | BIM BIS-(INDOLE)MALEIMIDE PYRIDINOPHANE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 9；PEG2000, BICINE pH9.0
|
Resolution 2.80 Å R-free 0.295 |
| 2OW3 Glycogen synthase kinase-3 beta in complex with bis-(indole)maleimide pyridinophane inhibitor Deposited 2007-02-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
35–386（352 aa）
Fragment：residues 35-386
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | BIM BIS-(INDOLE)MALEIMIDE PYRIDINOPHANE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 9；PEG2000, BICINE pH9.0
|
Resolution 2.80 Å R-free 0.295 |
| 2UW9 STRUCTURE OF PKB-BETA (AKT2) COMPLEXED WITH 4-(4-chloro-phenyl)-4-(4-(1H-pyrazol-4-yl)-phenyl)-piperidine Deposited 2007-03-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
3–12（10 aa）
Fragment：RESIDUES 3-12
|
Not recorded | GVP 4-(4-CHLOROPHENYL)-4-[4-(1H-PYRAZOL-4-YL)PHENYL]PIPERIDINE × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.10 Å R-free 0.305 |
| 2X39 Structure of 4-Amino-N-(4-chlorobenzyl)-1-(7H-pyrrolo(2,3-d)pyrimidin- 4-yl)piperidine-4-carboxamide bound to PKB Deposited 2010-01-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
3–12（10 aa）
Fragment：RESIDUES 3-12
|
Not recorded | X39 4-AMINO-N-(4-CHLOROBENZYL)-1-(7H-PYRROLO[2,3-D]PYRIMIDIN-4-YL)PIPERIDINE-4-CARBOXAMIDE × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.93 Å R-free 0.226 |
| 2XH5 Structure of 4-(4-tert-Butylbenzyl)-1-(7H-pyrrolo(2,3-d)pyrimidin-4- yl)piperidin-4-amine bound to PKB Deposited 2010-06-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
3–12（10 aa）
Fragment：RESIDUES 3-12
|
Not recorded | X37 4-(4-tert-butylbenzyl)-1-(7H-pyrrolo[2,3-d]pyrimidin-4-yl)piperidin-4-aminium × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.72 Å R-free 0.305 |
| 3CQU Crystal Structure of Akt-1 complexed with substrate peptide and inhibitor Deposited 2008-04-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
3–12（10 aa）
Fragment：residues 3-12
|
Not recorded | CQU N-[2-(5-methyl-4H-1,2,4-triazol-3-yl)phenyl]-7H-pyrrolo[2,3-d]pyrimidin-4-amine × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.20 Å R-free 0.283 |
| 3CQW Crystal Structure of Akt-1 complexed with substrate peptide and inhibitor Deposited 2008-04-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
3–12（10 aa）
Fragment：residues 3-12
|
Not recorded | MN MANGANESE (II) ION × 1 CQW 5-(5-chloro-7H-pyrrolo[2,3-d]pyrimidin-4-yl)-4,5,6,7-tetrahydro-1H-imidazo[4,5-c]pyridine × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å R-free 0.257 |
| 3DU8 Crystal structure of GSK-3 beta in complex with NMS-869553A Deposited 2008-07-17 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Not recorded | 553 (7S)-2-(2-aminopyrimidin-4-yl)-7-(2-fluoroethyl)-1,5,6,7-tetrahydro-4H-pyrrolo[3,2-c]pyridin-4-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；20% w/v PEG 3350, 100 mM Hepes pH 8.0, 20 mM MgCl2, 10% v/v Glycerol, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.20 Å R-free 0.246 |
| 3DU8 Crystal structure of GSK-3 beta in complex with NMS-869553A Deposited 2008-07-17 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Not recorded | 553 (7S)-2-(2-aminopyrimidin-4-yl)-7-(2-fluoroethyl)-1,5,6,7-tetrahydro-4H-pyrrolo[3,2-c]pyridin-4-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；20% w/v PEG 3350, 100 mM Hepes pH 8.0, 20 mM MgCl2, 10% v/v Glycerol, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.20 Å R-free 0.246 |
| 3E87 Crystal structures of the kinase domain of AKT2 in complex with ATP-competitive inhibitors Deposited 2008-08-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
3–12（10 aa）
|
Not recorded | G95 N-[(1S)-2-amino-1-phenylethyl]-5-(1H-pyrrolo[2,3-b]pyridin-4-yl)thiophene-2-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 8；298 K；14% PEG 2KMME, 100 mM Tris pH 8.0 and 10% ethanol diffused in. Seeded., vapor diffusion, temperature 298K
|
Resolution 2.30 Å R-free 0.246 |
| 3E87 Crystal structures of the kinase domain of AKT2 in complex with ATP-competitive inhibitors Deposited 2008-08-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain D
3–12（10 aa）
|
Not recorded | G95 N-[(1S)-2-amino-1-phenylethyl]-5-(1H-pyrrolo[2,3-b]pyridin-4-yl)thiophene-2-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 8；298 K；14% PEG 2KMME, 100 mM Tris pH 8.0 and 10% ethanol diffused in. Seeded., vapor diffusion, temperature 298K
|
Resolution 2.30 Å R-free 0.246 |
| 3E88 Crystal structures of the kinase domain of AKT2 in complex with ATP-competitive inhibitors Deposited 2008-08-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
3–12（10 aa）
|
Not recorded | G96 4-[2-(4-amino-1,2,5-oxadiazol-3-yl)-6-{[(2R)-2-amino-3-phenylpropyl]oxy}-1-ethyl-1H-imidazo[4,5-c]pyridin-4-yl]-2-methylbut-3-yn-2-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 8；298 K；14% PEG 2KMME, 100 mM Tris pH 8.0 and 10% ethanol diffused in. Seeded., vapor diffusion, temperature 298K
|
Resolution 2.50 Å R-free 0.273 |
| 3E88 Crystal structures of the kinase domain of AKT2 in complex with ATP-competitive inhibitors Deposited 2008-08-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain D
3–12（10 aa）
|
Not recorded | G96 4-[2-(4-amino-1,2,5-oxadiazol-3-yl)-6-{[(2R)-2-amino-3-phenylpropyl]oxy}-1-ethyl-1H-imidazo[4,5-c]pyridin-4-yl]-2-methylbut-3-yn-2-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 8；298 K；14% PEG 2KMME, 100 mM Tris pH 8.0 and 10% ethanol diffused in. Seeded., vapor diffusion, temperature 298K
|
Resolution 2.50 Å R-free 0.273 |
| 3E8D Crystal structures of the kinase domain of AKT2 in complex with ATP-competitive inhibitors Deposited 2008-08-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
3–12（10 aa）
|
Not recorded | G98 4-[2-(4-amino-2,5-dihydro-1,2,5-oxadiazol-3-yl)-6-{[(1S)-3-amino-1-phenylpropyl]oxy}-1-ethyl-1H-imidazo[4,5-c]pyridin-4-yl]-2-methylbut-3-yn-2-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 8；298 K；14% PEG 2KMME, 100 mM Tris pH 8.0 and 10% ethanol diffused in. Seeded., vapor diffusion, temperature 298K
|
Resolution 2.70 Å R-free 0.268 |
| 3E8D Crystal structures of the kinase domain of AKT2 in complex with ATP-competitive inhibitors Deposited 2008-08-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain D
3–12（10 aa）
|
Not recorded | G98 4-[2-(4-amino-2,5-dihydro-1,2,5-oxadiazol-3-yl)-6-{[(1S)-3-amino-1-phenylpropyl]oxy}-1-ethyl-1H-imidazo[4,5-c]pyridin-4-yl]-2-methylbut-3-yn-2-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 8；298 K；14% PEG 2KMME, 100 mM Tris pH 8.0 and 10% ethanol diffused in. Seeded., vapor diffusion, temperature 298K
|
Resolution 2.70 Å R-free 0.268 |
| 3F7Z X-ray Co-Crystal Structure of Glycogen Synthase Kinase 3beta in Complex with an Inhibitor Deposited 2008-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
35–383（349 aa）
Fragment：UNP residues 35-383, Protein kinase domain
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 34O 2-(1,3-benzodioxol-5-yl)-5-[(3-fluoro-4-methoxybenzyl)sulfanyl]-1,3,4-oxadiazole × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；105 PEG 3350, 0.2M proline, pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.40 Å R-free 0.253 |
| 3F7Z X-ray Co-Crystal Structure of Glycogen Synthase Kinase 3beta in Complex with an Inhibitor Deposited 2008-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
35–383（349 aa）
Fragment：UNP residues 35-383, Protein kinase domain
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 34O 2-(1,3-benzodioxol-5-yl)-5-[(3-fluoro-4-methoxybenzyl)sulfanyl]-1,3,4-oxadiazole × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；105 PEG 3350, 0.2M proline, pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.40 Å R-free 0.253 |
| 3F88 glycogen synthase Kinase 3beta inhibitor complex Deposited 2008-11-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
35–383（349 aa）
Fragment：UNP residues 35-383, Protein kinase domain
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 3HT 5-[1-(4-methoxyphenyl)-1H-benzimidazol-6-yl]-1,3,4-oxadiazole-2(3H)-thione × 1 2HT 3-methylbenzonitrile × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10% PEG 3350, 0.2M proline, 0.1M HEPES, pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.60 Å R-free 0.281 |
| 3F88 glycogen synthase Kinase 3beta inhibitor complex Deposited 2008-11-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
35–383（349 aa）
Fragment：UNP residues 35-383, Protein kinase domain
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 3HT 5-[1-(4-methoxyphenyl)-1H-benzimidazol-6-yl]-1,3,4-oxadiazole-2(3H)-thione × 1 2HT 3-methylbenzonitrile × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10% PEG 3350, 0.2M proline, 0.1M HEPES, pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.60 Å R-free 0.281 |
| 3GB2 GSK3beta inhibitor complex Deposited 2009-02-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
34–383（350 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | G3B 2-methyl-5-(3-{4-[(S)-methylsulfinyl]phenyl}-1-benzofuran-5-yl)-1,3,4-oxadiazole × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；298 K；10% PEG MME 550, 0.1M HEPES, pH 7.0, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 2.40 Å R-free 0.289 |
| 3I4B Crystal structure of GSK3b in complex with a pyrimidylpyrrole inhibitor Deposited 2009-07-01 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
7–420（414 aa）
Chain B
7–420（414 aa）
|
Not recorded | Z48 N-[(1S)-2-hydroxy-1-phenylethyl]-4-[5-methyl-2-(phenylamino)pyrimidin-4-yl]-1H-pyrrole-2-carboxamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；20% PEG 3350, 0.2M Potassium fluoride, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
|
Resolution 2.30 Å R-free 0.222 |
| 3L1S 3-Aryl-4-(arylhydrazono)-1H-pyrazol-5-ones: Highly ligand efficient and potent inhibitors of GSK3 Deposited 2009-12-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
7–420（414 aa）
|
Not recorded | Z92 (4E)-4-[(4-chlorophenyl)hydrazono]-5-(3,4-dimethoxyphenyl)-2,4-dihydro-3H-pyrazol-3-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；20% PEG3350, 0.2M KF, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
|
Resolution 2.90 Å R-free 0.232 |
| 3L1S 3-Aryl-4-(arylhydrazono)-1H-pyrazol-5-ones: Highly ligand efficient and potent inhibitors of GSK3 Deposited 2009-12-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
7–420（414 aa）
|
Not recorded | Z92 (4E)-4-[(4-chlorophenyl)hydrazono]-5-(3,4-dimethoxyphenyl)-2,4-dihydro-3H-pyrazol-3-one × 1 PO4 PHOSPHATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；20% PEG3350, 0.2M KF, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
|
Resolution 2.90 Å R-free 0.232 |
| 3M1S Structure of Ruthenium Half-Sandwich Complex Bound to Glycogen Synthase Kinase 3 Deposited 2010-03-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
Chain B
1–420（420 aa）
|
Not recorded | DW1 Ruthenium pyridocarbazole × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 7.2；298 K；100 mM Tris, 10 % PEG 8000, Seeding process, pH 7.2, EVAPORATION, temperature 298K
|
Resolution 3.13 Å R-free 0.228 |
| 3PUP Structure of Glycogen Synthase Kinase 3 beta (GSK3B) in complex with a ruthenium octasporine ligand (OS1) Deposited 2010-12-06 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Not recorded | OS1 Ruthenium octasporine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；277 K；100 mM Tris pH 7.4
20 % PEG 6000, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.99 Å R-free 0.249 |
| 3PUP Structure of Glycogen Synthase Kinase 3 beta (GSK3B) in complex with a ruthenium octasporine ligand (OS1) Deposited 2010-12-06 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Not recorded | OS1 Ruthenium octasporine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；277 K；100 mM Tris pH 7.4
20 % PEG 6000, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.99 Å R-free 0.249 |
| 3PUP Structure of Glycogen Synthase Kinase 3 beta (GSK3B) in complex with a ruthenium octasporine ligand (OS1) Deposited 2010-12-06 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
Chain B
1–420（420 aa）
|
Not recorded | OS1 Ruthenium octasporine × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；277 K；100 mM Tris pH 7.4
20 % PEG 6000, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.99 Å R-free 0.249 |
| 3Q3B 6-Amino-4-(pyrimidin-4-yl)pyridones: Novel Glycogen Synthase Kinase-3 Inhibitors Deposited 2010-12-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–420（419 aa）
|
Not recorded | 55E 4-(4-hydroxy-3-methylphenyl)-6-phenylpyrimidin-2(5H)-one × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.70 Å R-free 0.259 |
| 3Q3B 6-Amino-4-(pyrimidin-4-yl)pyridones: Novel Glycogen Synthase Kinase-3 Inhibitors Deposited 2010-12-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
2–420（419 aa）
|
Not recorded | 55E 4-(4-hydroxy-3-methylphenyl)-6-phenylpyrimidin-2(5H)-one × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.70 Å R-free 0.259 |
| 3QKK Spirochromane Akt Inhibitors Deposited 2011-02-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
3–12（10 aa）
|
Not recorded | SMH N-(2-ethoxyethyl)-N-{(2S)-2-hydroxy-3-[(2R)-6-hydroxy-4-oxo-3,4-dihydro-1'H-spiro[chromene-2,3'-piperidin]-1'-yl]propyl}-2,6-dimethylbenzenesulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
Under oil；pH 7.8；293 K；8.1mg/ml protein, 0.6mM GSK-3 beta peptide, 5mM Mg-AMPPNP, 10mM DTT, 20% PEG 4K, 10% Isopropanol, 0.1M Hepes, pH 7.8, Under oil, temperature 293K
|
Resolution 2.30 Å R-free 0.250 |
| 3QKL Spirochromane Akt Inhibitors Deposited 2011-02-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
3–12（10 aa）
|
Not recorded | SMR N-{(2S)-3-[(3S)-8',9'-dihydro-1H,3'H-spiro[piperidine-3,7'-pyrano[3,2-e]indazol]-1-yl]-2-hydroxypropyl}-N-(2-ethoxyethyl)-2,6-dimethylbenzenesulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
Under oil；pH 7.8；293 K；9.7mg/ml protein, 0.6mM GSK-3 beta peptide, 1mM Mg-AMPPNP, 10mM DTT, 22% PEG 4K, 10% Isopropanol, 0.1M Hepes, pH 7.8, Under oil, temperature 293K
|
Resolution 1.90 Å R-free 0.243 |
| 3SAY Crystal structure of human glycogen synthase kinase 3 beta (GSK3b) in complex with inhibitor 142 Deposited 2011-06-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | OFT (3Z)-N,N-diethyl-3-[(3E)-3-(hydroxyimino)-1,3-dihydro-2H-indol-2-ylidene]-2-oxo-2,3-dihydro-1H-indole-5-sulfonamide × 1 MLA MALONIC ACID × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；296 K；20% PEG3350, 0.1M sodium Hepes pH 7.0, 2% (v/v) Tacsimate pH 7.0, VAPOR DIFFUSION, SITTING DROP, temperature 296K
|
Resolution 2.23 Å R-free 0.230 |
| 3SAY Crystal structure of human glycogen synthase kinase 3 beta (GSK3b) in complex with inhibitor 142 Deposited 2011-06-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | OFT (3Z)-N,N-diethyl-3-[(3E)-3-(hydroxyimino)-1,3-dihydro-2H-indol-2-ylidene]-2-oxo-2,3-dihydro-1H-indole-5-sulfonamide × 1 MLA MALONIC ACID × 1 MPD (4S)-2-METHYL-2,4-PENTANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；296 K；20% PEG3350, 0.1M sodium Hepes pH 7.0, 2% (v/v) Tacsimate pH 7.0, VAPOR DIFFUSION, SITTING DROP, temperature 296K
|
Resolution 2.23 Å R-free 0.230 |
| 3SD0 Identification of a Glycogen Synthase Kinase-3b Inhibitor that Attenuates Hyperactivity in CLOCK Mutant Mice Deposited 2011-06-08 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
35–384（350 aa）
Fragment：UNP residues 35-384
Chain B
35–384（350 aa）
Fragment：UNP residues 35-384
|
Not recorded | TSK 3-(5-fluoro-6-iodo-1-methyl-1H-indol-3-yl)-4-(7-methoxy-1-benzofuran-3-yl)-1H-pyrrole-2,5-dione × 2 EPE 4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.70 Å R-free 0.254 |
| 3SD0 Identification of a Glycogen Synthase Kinase-3b Inhibitor that Attenuates Hyperactivity in CLOCK Mutant Mice Deposited 2011-06-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
35–384（350 aa）
Fragment：UNP residues 35-384
|
Not recorded | TSK 3-(5-fluoro-6-iodo-1-methyl-1H-indol-3-yl)-4-(7-methoxy-1-benzofuran-3-yl)-1H-pyrrole-2,5-dione × 1 EPE 4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.70 Å R-free 0.254 |
| 3SD0 Identification of a Glycogen Synthase Kinase-3b Inhibitor that Attenuates Hyperactivity in CLOCK Mutant Mice Deposited 2011-06-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
35–384（350 aa）
Fragment：UNP residues 35-384
|
Not recorded | TSK 3-(5-fluoro-6-iodo-1-methyl-1H-indol-3-yl)-4-(7-methoxy-1-benzofuran-3-yl)-1H-pyrrole-2,5-dione × 1 EPE 4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.70 Å R-free 0.254 |
| 3ZDI Glycogen Synthase Kinase 3 Beta complexed with Axin Peptide and Inhibitor 7d Deposited 2012-11-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
35–384（350 aa）
Fragment：RESIDUES 35-384
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | PO4 PHOSPHATE ION × 1 UGJ 3,6-Diamino-4-(2-chlorophenyl)thieno[2,3-b]pyridine-2,5-dicarbonitrile × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
0.1 M 2-(N-MORPHOLINO)ETHANESULFONIC ACID (MES), PH 6.5, 12% (W/V) PEG 20000
|
Resolution 2.65 Å R-free 0.242 |
| 3ZRK Identification of 2-(4-pyridyl)thienopyridinones as GSK-3beta inhibitors Deposited 2011-06-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
23–393（371 aa）
Fragment：RESIDUES 23-393
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 2 GOL GLYCEROL × 2 ZRK 2-(4-PYRIDINYL)FURO[3,2-C]PYRIDIN-4(5H)-ONE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
0.2M AMMONIUM SULFATE, 0.1M BISTRIS PH6.5, 30% PEG 3350, 10% GLYCEROL
|
Resolution 2.37 Å R-free 0.243 |
| 3ZRK Identification of 2-(4-pyridyl)thienopyridinones as GSK-3beta inhibitors Deposited 2011-06-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
23–393（371 aa）
Fragment：RESIDUES 23-393
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 4 GOL GLYCEROL × 1 ZRK 2-(4-PYRIDINYL)FURO[3,2-C]PYRIDIN-4(5H)-ONE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
0.2M AMMONIUM SULFATE, 0.1M BISTRIS PH6.5, 30% PEG 3350, 10% GLYCEROL
|
Resolution 2.37 Å R-free 0.243 |
| 3ZRL Identification of 2-(4-pyridyl)thienopyridinones as GSK-3beta inhibitors Deposited 2011-06-17 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
23–393（371 aa）
Fragment：RESIDUES 23-393
Chain B
23–393（371 aa）
Fragment：RESIDUES 23-393
|
Non-standard monomer：Yes (specific site not provided by mmCIF) Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 6 GOL GLYCEROL × 3 ZRL 7-BROMO-2-PYRIDIN-4-YL-5H-THIENO[3,2-C]PYRIDIN-4-ONE × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.48 Å R-free 0.249 |
| 3ZRM Identification of 2-(4-pyridyl)thienopyridinones as GSK-3beta inhibitors Deposited 2011-06-17 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
23–393（371 aa）
Fragment：RESIDUES 23-393
Chain B
23–393（371 aa）
Fragment：RESIDUES 23-393
|
Non-standard monomer：Yes (specific site not provided by mmCIF) Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 6 GOL GLYCEROL × 2 ZRM 7-(4-HYDROXYPHENYL)-2-PYRIDIN-4-YL-5H-THIENO[3,2-C]PYRIDIN-4-ONE × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.49 Å R-free 0.247 |
| 4ACC GSK3b in complex with inhibitor Deposited 2011-12-14 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
Chain B
1–420（420 aa）
|
Not recorded | DMS DIMETHYL SULFOXIDE × 3 7YG 3-AMINO-6-(4-{[2-(DIMETHYLAMINO)ETHYL]SULFAMOYL}PHENYL)-N-PYRIDIN-3-YLPYRAZINE-2-CARBOXAMIDE × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.21 Å R-free 0.219 |
| 4ACD GSK3b in complex with inhibitor Deposited 2011-12-15 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
Chain B
1–420（420 aa）
|
Not recorded | GR9 3-AMINO-6-{4-[(4-METHYLPIPERAZIN-1-YL)SULFONYL]PHENYL}-N-PYRIDIN-3-YLPYRAZINE-2-CARBOXAMIDE × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.60 Å R-free 0.226 |
| 4ACG GSK3b in complex with inhibitor Deposited 2011-12-15 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
Chain B
1–420（420 aa）
|
Not recorded | 6LQ 2-AMINO-5-{4-[(4-METHYLPIPERAZIN-1-YL)SULFONYL]PHENYL}-N-[4-(PYRROLIDIN-1-YLMETHYL)PYRIDIN-3-YL]PYRIDINE-3-CARBOXAMIDE × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.60 Å R-free 0.225 |
| 4ACH GSK3b in complex with inhibitor Deposited 2011-12-15 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
Chain B
1–420（420 aa）
|
Not recorded | KDI 3-AMINO-N-(3-METHOXYPROPYL)-6-{4-[(4-METHYLPIPERAZIN-1-YL)SULFONYL]PHENYL}PYRAZINE-2-CARBOXAMIDE × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.60 Å R-free 0.252 |
| 4AFJ 5-aryl-4-carboxamide-1,3-oxazoles: potent and selective GSK-3 inhibitors Deposited 2012-01-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
27–393（367 aa）
Fragment：RESIDUES 27-393
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 3 GOL GLYCEROL × 3 SJJ 5-(4-METHOXYPHENYL)-N-(PYRIDIN-4-YLMETHYL)-1,3-OXAZOLE-4-CARBOXAMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；20 DEGREES CELSIUS USING THE SITTING DRO METHOD 80 UL OF WELL SOLUTION AND 120 OR 100 NL OF PROTEIN AND 60 O 100 NL OF WELL SOLUTION (2 + 1 AND 1 + 1 PROTEIN:WELL RATIO) 30% PEG 3350, 10% GLYCEROL, 0.1 M BISTRIS PH6.5 AND 0.2 M AMMONIUM SULPHATE, CONTAINING 0.1 M COMPOUND (AND 1% DMSO).
|
Resolution 1.98 Å R-free 0.216 |
| 4AFJ 5-aryl-4-carboxamide-1,3-oxazoles: potent and selective GSK-3 inhibitors Deposited 2012-01-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
27–393（367 aa）
Fragment：RESIDUES 27-393
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 3 GOL GLYCEROL × 4 SJJ 5-(4-METHOXYPHENYL)-N-(PYRIDIN-4-YLMETHYL)-1,3-OXAZOLE-4-CARBOXAMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；20 DEGREES CELSIUS USING THE SITTING DRO METHOD 80 UL OF WELL SOLUTION AND 120 OR 100 NL OF PROTEIN AND 60 O 100 NL OF WELL SOLUTION (2 + 1 AND 1 + 1 PROTEIN:WELL RATIO) 30% PEG 3350, 10% GLYCEROL, 0.1 M BISTRIS PH6.5 AND 0.2 M AMMONIUM SULPHATE, CONTAINING 0.1 M COMPOUND (AND 1% DMSO).
|
Resolution 1.98 Å R-free 0.216 |
| 4B7T Glycogen Synthase Kinase 3 Beta complexed with Axin Peptide and Leucettine L4 Deposited 2012-08-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
35–384（350 aa）
Fragment：RESIDUES 35-384
|
Not recorded | CWT (5Z)-5-(1,3-benzodioxol-5-ylmethylidene)-3-methyl-2-(propan-2-ylamino)imidazol-4-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
0.1 M TRIS-HCL, PH 8.0, 0.15 M MGCL2, 15% (W/V) PEG 4000
|
Resolution 2.77 Å R-free 0.235 |
| 4DIT Crystal Structure of GSK3beta in complex with a Imidazopyridine inhibitor Deposited 2012-01-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
27–393（367 aa）
Fragment：protein kinase domain, UNP residues 27-393
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 0KD N-(pyridin-3-yl)-2-(thiophen-3-yl)-3H-imidazo[4,5-b]pyridine-7-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；295 K；0.1M Tris pH 8.0, 15% PEG 6000, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 2.60 Å R-free 0.304 |
| 4EKK Akt1 with AMP-PNP Deposited 2012-04-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
3–12（10 aa）
Fragment：UNP residues 3-12
|
Not recorded | ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 MN MANGANESE (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；293 K；20% PEG4K, 100mM Tris-pH7.5, Under Oil, temperature 293K
|
Resolution 2.80 Å R-free 0.280 |
| 4EKK Akt1 with AMP-PNP Deposited 2012-04-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain D
3–12（10 aa）
Fragment：UNP residues 3-12
|
Not recorded | ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 MN MANGANESE (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；293 K；20% PEG4K, 100mM Tris-pH7.5, Under Oil, temperature 293K
|
Resolution 2.80 Å R-free 0.280 |
| 4IQ6 Gsk-3beta with inhibitor 6-chloro-N-cyclohexyl-4-(1H-pyrrolo[2,3-b]pyridin-3-yl)pyridin-2-amine Deposited 2013-01-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Not recorded | IQ6 6-chloro-N-cyclohexyl-4-(1H-pyrrolo[2,3-b]pyridin-3-yl)pyridin-2-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277.15 K；15% Peg 3350, 0.1 M Hepes pH 7.0, 5% glycerol, VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
|
Resolution 3.12 Å R-free 0.227 |
| 4IQ6 Gsk-3beta with inhibitor 6-chloro-N-cyclohexyl-4-(1H-pyrrolo[2,3-b]pyridin-3-yl)pyridin-2-amine Deposited 2013-01-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Not recorded | IQ6 6-chloro-N-cyclohexyl-4-(1H-pyrrolo[2,3-b]pyridin-3-yl)pyridin-2-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277.15 K；15% Peg 3350, 0.1 M Hepes pH 7.0, 5% glycerol, VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
|
Resolution 3.12 Å R-free 0.227 |
| 4J1R Crystal Structure of GSK3b in complex with inhibitor 15R Deposited 2013-02-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | PO4 PHOSPHATE ION × 1 I5R (2R)-2-(1H-indol-3-ylmethyl)-1,4-dihydropyrido[2,3-b]pyrazin-3(2H)-one × 1 K POTASSIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 9.2；290 K；20% PEG-3350, 0.2M dipotassium phosphate, pH 9.2, VAPOR DIFFUSION, SITTING DROP, temperature 290.0K
|
Resolution 2.70 Å R-free 0.193 |
| 4J1R Crystal Structure of GSK3b in complex with inhibitor 15R Deposited 2013-02-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | PO4 PHOSPHATE ION × 1 I5R (2R)-2-(1H-indol-3-ylmethyl)-1,4-dihydropyrido[2,3-b]pyrazin-3(2H)-one × 1 K POTASSIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 9.2；290 K；20% PEG-3350, 0.2M dipotassium phosphate, pH 9.2, VAPOR DIFFUSION, SITTING DROP, temperature 290.0K
|
Resolution 2.70 Å R-free 0.193 |
| 4J1R Crystal Structure of GSK3b in complex with inhibitor 15R Deposited 2013-02-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | PO4 PHOSPHATE ION × 1 I5R (2R)-2-(1H-indol-3-ylmethyl)-1,4-dihydropyrido[2,3-b]pyrazin-3(2H)-one × 1 K POTASSIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 9.2；290 K；20% PEG-3350, 0.2M dipotassium phosphate, pH 9.2, VAPOR DIFFUSION, SITTING DROP, temperature 290.0K
|
Resolution 2.70 Å R-free 0.193 |
| 4J1R Crystal Structure of GSK3b in complex with inhibitor 15R Deposited 2013-02-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | PO4 PHOSPHATE ION × 1 I5R (2R)-2-(1H-indol-3-ylmethyl)-1,4-dihydropyrido[2,3-b]pyrazin-3(2H)-one × 1 K POTASSIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 9.2；290 K；20% PEG-3350, 0.2M dipotassium phosphate, pH 9.2, VAPOR DIFFUSION, SITTING DROP, temperature 290.0K
|
Resolution 2.70 Å R-free 0.193 |
| 4J1R Crystal Structure of GSK3b in complex with inhibitor 15R Deposited 2013-02-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 5 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
Chain B
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) Non-standard monomer：Yes (specific site not provided by mmCIF) | PO4 PHOSPHATE ION × 2 I5R (2R)-2-(1H-indol-3-ylmethyl)-1,4-dihydropyrido[2,3-b]pyrazin-3(2H)-one × 2 K POTASSIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 9.2；290 K；20% PEG-3350, 0.2M dipotassium phosphate, pH 9.2, VAPOR DIFFUSION, SITTING DROP, temperature 290.0K
|
Resolution 2.70 Å R-free 0.193 |
| 4J1R Crystal Structure of GSK3b in complex with inhibitor 15R Deposited 2013-02-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 6 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain C
1–420（420 aa）
Chain D
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) Non-standard monomer：Yes (specific site not provided by mmCIF) | PO4 PHOSPHATE ION × 2 I5R (2R)-2-(1H-indol-3-ylmethyl)-1,4-dihydropyrido[2,3-b]pyrazin-3(2H)-one × 2 K POTASSIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 9.2；290 K；20% PEG-3350, 0.2M dipotassium phosphate, pH 9.2, VAPOR DIFFUSION, SITTING DROP, temperature 290.0K
|
Resolution 2.70 Å R-free 0.193 |
| 4J71 Crystal Structure of GSK3b in complex with inhibitor 1R Deposited 2013-02-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 1JX (2R)-2-methyl-1,4-dihydropyrido[2,3-b]pyrazin-3(2H)-one × 1 SO4 SULFATE ION × 2 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.2；290 K；20% PEG-3350, 0.2M Na Formate, pH 7.2, VAPOR DIFFUSION, SITTING DROP, temperature 290.0K
|
Resolution 2.31 Å R-free 0.234 |
| 4J71 Crystal Structure of GSK3b in complex with inhibitor 1R Deposited 2013-02-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 1JX (2R)-2-methyl-1,4-dihydropyrido[2,3-b]pyrazin-3(2H)-one × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.2；290 K；20% PEG-3350, 0.2M Na Formate, pH 7.2, VAPOR DIFFUSION, SITTING DROP, temperature 290.0K
|
Resolution 2.31 Å R-free 0.234 |
| 4NM0 Crystal structure of peptide inhibitor-free GSK-3/Axin complex Deposited 2013-11-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–383（383 aa）
Fragment：Residues 1-383
|
Not recorded | GOL GLYCEROL × 5 MG MAGNESIUM ION × 2 ADP ADENOSINE-5'-DIPHOSPHATE × 1 DTT 2,3-DIHYDROXY-1,4-DITHIOBUTANE × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
MICRODIALYSIS；pH 7.5；277 K；10% PEG 35,000, 20mM Tris 7.5, 300mM NaCl, 5% glycerol, 20mM MgCl2, 400uM ATP, and 5mM DTT, MICRODIALYSIS, temperature 277K
|
Resolution 2.50 Å R-free 0.239 |
| 4NM3 Crystal structure of GSK-3/Axin complex bound to phosphorylated N-terminal auto-inhibitory pS9 peptide Deposited 2013-11-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–383（383 aa）
Fragment：Residues 1-383 with phosphoylated Ser9
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | GOL GLYCEROL × 4 MG MAGNESIUM ION × 2 CL CHLORIDE ION × 1 DTT 2,3-DIHYDROXY-1,4-DITHIOBUTANE × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
MICRODIALYSIS；pH 7.5；277 K；10% PEG 35,000, 20mM Tris 7.5, 300mM NaCl, 5% glycerol, 10mM MgCl2, 200uM ATP, and 5mM DTT, MICRODIALYSIS, temperature 277K
|
Resolution 2.10 Å R-free 0.242 |
| 4PTC Structure of a carboxamide compound (3) (2-{2-[(CYCLOPROPYLCARBONYL)AMINO]PYRIDIN-4-YL}-4-OXO-4H-1LAMBDA~4~,3-THIAZOLE-5-CARBOXAMIDE) to GSK3b Deposited 2014-03-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
Chain B
1–420（420 aa）
|
Not recorded | 2WE 2-[2-(cyclopropylcarbonylamino)pyridin-4-yl]-4-methoxy-1,3-thiazole-5-carboxamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 4；293 K；GSK-3 was mixed with a 10-fold molar excess of 3 (1 mM final concentration). Crystals were grown at 20 C by vapor diffusion in the presence of 25% PEG 1500 and 0.1M MMT pH 4.0. Crystals would nucleate within 1-3 days and continued to grow for an addition 5-10 days before harvesting, VAPOR DIFFUSION, temperature 293K
|
Resolution 2.71 Å R-free 0.281 |
| 4PTE Structure of a carvoxamide compound (15) (N-[4-(ISOQUINOLIN-7-YL)PYRIDIN-2-YL]CYCLOPROPANECARBOXAMIDE) to GSK3b Deposited 2014-03-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
Chain B
1–420（420 aa）
|
Not recorded | 2WF N-[4-(isoquinolin-7-yl)pyridin-2-yl]cyclopropanecarboxamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.5；293 K；GSK-3 was mixed with a 10-fold molar excess of 18 (1 mM final concentration). Crystals grown at 20 C by vapor diffusion in the presence of 20% PEG 3350, 0.20M sodium malonate and 0.1M bis-tris pH 6.5. Crystals would nucleate within 1-3 days and continued to grow for an addition 5-10 days before harvesting, VAPOR DIFFUSION, temperature 293K
|
Resolution 2.03 Å R-free 0.195 |
| 4PTG Structure of a carboxamine compound (26) (2-{2-[(CYCLOPROPYLCARBONYL)AMINO]PYRIDIN-4-YL}-4-METHOXYPYRIMIDINE-5-CARBOXAMIDE) to GSK3b Deposited 2014-03-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Not recorded | 2WG 2-{2-[(cyclopropylcarbonyl)amino]pyridin-4-yl}-4-methoxypyrimidine-5-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；GSK-3 was mixed with a 10-fold molar excess of compound (1 mM final concentration). Crystals were grown at 20 C by vapor diffusion in the presence of 22% PEG 3350 and 3.0% w/v methanol. Crystals would nucleate within 1-3 days and continued to grow for an addition 5-10 days before harvesting., VAPOR DIFFUSION, temperature 293K
|
Resolution 2.36 Å R-free 0.211 |
| 4PTG Structure of a carboxamine compound (26) (2-{2-[(CYCLOPROPYLCARBONYL)AMINO]PYRIDIN-4-YL}-4-METHOXYPYRIMIDINE-5-CARBOXAMIDE) to GSK3b Deposited 2014-03-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Not recorded | 2WG 2-{2-[(cyclopropylcarbonyl)amino]pyridin-4-yl}-4-methoxypyrimidine-5-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；GSK-3 was mixed with a 10-fold molar excess of compound (1 mM final concentration). Crystals were grown at 20 C by vapor diffusion in the presence of 22% PEG 3350 and 3.0% w/v methanol. Crystals would nucleate within 1-3 days and continued to grow for an addition 5-10 days before harvesting., VAPOR DIFFUSION, temperature 293K
|
Resolution 2.36 Å R-free 0.211 |
| 5F94 Crystal structure of GSK3b in complex with Compound 15: 2-[(cyclopropylcarbonyl)amino]-N-(4-methoxypyridin-3-yl)pyridine-4-carboxamide Deposited 2015-12-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
36–385（350 aa）
|
Not recorded | 3UO 2-[(cyclopropylcarbonyl)amino]-N-(4-methoxypyridin-3-yl)pyridine-4-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；298 K；Crystals grown in the presence of 25% PEG 1500 and 0.1 M MMT pH 4.0
|
Resolution 2.51 Å R-free 0.226 |
| 5F94 Crystal structure of GSK3b in complex with Compound 15: 2-[(cyclopropylcarbonyl)amino]-N-(4-methoxypyridin-3-yl)pyridine-4-carboxamide Deposited 2015-12-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
36–385（350 aa）
|
Not recorded | 3UO 2-[(cyclopropylcarbonyl)amino]-N-(4-methoxypyridin-3-yl)pyridine-4-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；298 K；Crystals grown in the presence of 25% PEG 1500 and 0.1 M MMT pH 4.0
|
Resolution 2.51 Å R-free 0.226 |
| 5F95 Crystal structure of GSK3b in complex with Compound 18: 2-[(cyclopropylcarbonyl)amino]-N-(4-phenylpyridin-3-yl)pyridine-4-carboxamide Deposited 2015-12-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
36–385（350 aa）
|
Not recorded | 3UP 2-[(cyclopropylcarbonyl)amino]-N-(4-phenylpyridin-3-yl)pyridine-4-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；298 K；Crystals grown in the presence of 25% PEG 1500 and 0.1 M MMT pH 4.0
|
Resolution 2.52 Å R-free 0.242 |
| 5F95 Crystal structure of GSK3b in complex with Compound 18: 2-[(cyclopropylcarbonyl)amino]-N-(4-phenylpyridin-3-yl)pyridine-4-carboxamide Deposited 2015-12-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
36–385（350 aa）
|
Not recorded | 3UP 2-[(cyclopropylcarbonyl)amino]-N-(4-phenylpyridin-3-yl)pyridine-4-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；298 K；Crystals grown in the presence of 25% PEG 1500 and 0.1 M MMT pH 4.0
|
Resolution 2.52 Å R-free 0.242 |
| 5HLN X-RAY CRYSTAL STRUCTURE OF GSK3B IN COMPLEX WITH CHIR99021 Deposited 2016-01-15 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
Chain B
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) Non-standard monomer：Yes (specific site not provided by mmCIF) | 65C CHIR99021 × 2 MG MAGNESIUM ION × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；298 K；14% (W/V) PEG 8000, 100 mM MES, pH 6.0 and 100 mM magnesium acetate
|
Resolution 3.10 Å R-free 0.236 |
| 5HLP X-RAY CRYSTAL STRUCTURE OF GSK3B IN COMPLEX WITH BRD3937 Deposited 2016-01-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 65A 4-(2-methoxyphenyl)-3,7,7-trimethyl-1,6,7,8-tetrahydro-5H-pyrazolo[3,4-b]quinolin-5-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；298 K；10% (W/V) PEG 5000 MME, 50 mM citric acid and 50 mM bis-tris propane, pH 5.0, 5 mM TCEP
|
Resolution 2.45 Å R-free 0.240 |
| 5HLP X-RAY CRYSTAL STRUCTURE OF GSK3B IN COMPLEX WITH BRD3937 Deposited 2016-01-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 65A 4-(2-methoxyphenyl)-3,7,7-trimethyl-1,6,7,8-tetrahydro-5H-pyrazolo[3,4-b]quinolin-5-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；298 K；10% (W/V) PEG 5000 MME, 50 mM citric acid and 50 mM bis-tris propane, pH 5.0, 5 mM TCEP
|
Resolution 2.45 Å R-free 0.240 |
| 5K5N Crystal structure of GSK-3beta complexed with PF-04802367, a highly selective brain-penetrant kinase inhibitor Deposited 2016-05-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
28–384（357 aa）
Fragment：residues 28-382
|
Mutation：V28G Non-standard monomer：Yes (specific site not provided by mmCIF) | 6QH 5-(3-chloranyl-4-methoxy-phenyl)-~{N}-[3-(1,2,4-triazol-1-yl)propyl]-1,3-oxazole-4-carboxamide × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；Protein storage conditions: 20 mM Tris pH 7.8, 5% (v/v) glycerol, 200 mM NaCl, 1 mM TCEP, 0.5 mM EDTA, 0.5% DMSO, and 0.2 mM PF-4802367, Well solution: 18-23% (w/v) PEG MME 5000, 100-150 mM ammonium sulfate, and 100 mM MES pH 6.5, Crystallization set-up: 0.5 + 0.5 uL drops over a well-solution of 200 uL
|
Resolution 2.20 Å R-free 0.229 |
| 5K5N Crystal structure of GSK-3beta complexed with PF-04802367, a highly selective brain-penetrant kinase inhibitor Deposited 2016-05-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
28–384（357 aa）
Fragment：residues 28-382
|
Mutation：V28G Non-standard monomer：Yes (specific site not provided by mmCIF) | 6QH 5-(3-chloranyl-4-methoxy-phenyl)-~{N}-[3-(1,2,4-triazol-1-yl)propyl]-1,3-oxazole-4-carboxamide × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；Protein storage conditions: 20 mM Tris pH 7.8, 5% (v/v) glycerol, 200 mM NaCl, 1 mM TCEP, 0.5 mM EDTA, 0.5% DMSO, and 0.2 mM PF-4802367, Well solution: 18-23% (w/v) PEG MME 5000, 100-150 mM ammonium sulfate, and 100 mM MES pH 6.5, Crystallization set-up: 0.5 + 0.5 uL drops over a well-solution of 200 uL
|
Resolution 2.20 Å R-free 0.229 |
| 5KPK Glycogen Synthase Kinase 3 beta Complexed with BRD0209 Deposited 2016-07-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 6VK (4~{S})-3-cyclopropyl-4,7,7-trimethyl-4-phenyl-2,6,8,9-tetrahydropyrazolo[3,4-b]quinolin-5-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；298 K；Reservoir: 0.15 M DL-malic acid, pH 7.0, 20% w/v PEG3350
|
Resolution 2.40 Å R-free 0.224 |
| 5KPK Glycogen Synthase Kinase 3 beta Complexed with BRD0209 Deposited 2016-07-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 6VK (4~{S})-3-cyclopropyl-4,7,7-trimethyl-4-phenyl-2,6,8,9-tetrahydropyrazolo[3,4-b]quinolin-5-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；298 K；Reservoir: 0.15 M DL-malic acid, pH 7.0, 20% w/v PEG3350
|
Resolution 2.40 Å R-free 0.224 |
| 5KPL Glycogen Synthase Kinase 3 beta Complexed with BRD0705 Deposited 2016-07-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 6VL (4~{S})-4-ethyl-7,7-dimethyl-4-phenyl-2,6,8,9-tetrahydropyrazolo[3,4-b]quinolin-5-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；298 K；Reservoir: 0.1 M Bis-Tris, pH 6.5, 25% w/v PEG3350
|
Resolution 2.60 Å R-free 0.244 |
| 5KPL Glycogen Synthase Kinase 3 beta Complexed with BRD0705 Deposited 2016-07-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 6VL (4~{S})-4-ethyl-7,7-dimethyl-4-phenyl-2,6,8,9-tetrahydropyrazolo[3,4-b]quinolin-5-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；298 K；Reservoir: 0.1 M Bis-Tris, pH 6.5, 25% w/v PEG3350
|
Resolution 2.60 Å R-free 0.244 |
| 5KPM Glycogen Synthase Kinase 3 beta Complexed with BRD3731 Deposited 2016-07-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 6VM (4~{S})-3-(2,2-dimethylpropyl)-4,7,7-trimethyl-4-phenyl-2,6,8,9-tetrahydropyrazolo[3,4-b]quinolin-5-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；298 K；Reservoir: 0.2 M sodium acetate, pH 7.0, 20% w/v PEG3350
|
Resolution 2.69 Å R-free 0.240 |
| 5KPM Glycogen Synthase Kinase 3 beta Complexed with BRD3731 Deposited 2016-07-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 6VM (4~{S})-3-(2,2-dimethylpropyl)-4,7,7-trimethyl-4-phenyl-2,6,8,9-tetrahydropyrazolo[3,4-b]quinolin-5-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；298 K；Reservoir: 0.2 M sodium acetate, pH 7.0, 20% w/v PEG3350
|
Resolution 2.69 Å R-free 0.240 |
| 5OY4 GSK3beta complex with N-(6-(3,4-dihydroxyphenyl)-1H-pyrazolo[3,4-b]pyridin-3-yl)acetamide Deposited 2017-09-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 3 B4K ~{N}-[6-[3,4-bis(oxidanyl)phenyl]-1~{H}-pyrazolo[3,4-b]pyridin-3-yl]ethanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；1.6M AMMONIUM SULPHATE, 0.1M TRIS PH7.5, pH 7.50
|
Resolution 3.20 Å R-free 0.229 |
| 5OY4 GSK3beta complex with N-(6-(3,4-dihydroxyphenyl)-1H-pyrazolo[3,4-b]pyridin-3-yl)acetamide Deposited 2017-09-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 1 B4K ~{N}-[6-[3,4-bis(oxidanyl)phenyl]-1~{H}-pyrazolo[3,4-b]pyridin-3-yl]ethanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；1.6M AMMONIUM SULPHATE, 0.1M TRIS PH7.5, pH 7.50
|
Resolution 3.20 Å R-free 0.229 |
| 5T31 Exploiting an Asp-Glu switch in Glycogen Synthase Kinase 3 to design paralog selective inhibitors for use in acute myeloid leukemia Deposited 2016-08-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Mutation：D133E Non-standard monomer：Yes (specific site not provided by mmCIF) | 6VL (4~{S})-4-ethyl-7,7-dimethyl-4-phenyl-2,6,8,9-tetrahydropyrazolo[3,4-b]quinolin-5-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；293 K；20% PEG MME 5,000 and 0.1 M Bis-Tris pH 6.5
|
Resolution 2.85 Å R-free 0.268 |
| 5T31 Exploiting an Asp-Glu switch in Glycogen Synthase Kinase 3 to design paralog selective inhibitors for use in acute myeloid leukemia Deposited 2016-08-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Mutation：D133E Non-standard monomer：Yes (specific site not provided by mmCIF) | 6VL (4~{S})-4-ethyl-7,7-dimethyl-4-phenyl-2,6,8,9-tetrahydropyrazolo[3,4-b]quinolin-5-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；293 K；20% PEG MME 5,000 and 0.1 M Bis-Tris pH 6.5
|
Resolution 2.85 Å R-free 0.268 |
| 6B8J Co-structure of human glycogen synthase kinase beta with a selective (5-imidazol-2-yl-4-phenylpyrimidin-2-yl)[2-(2-pyridylamino)ethyl]amine inhibitor Deposited 2017-10-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | GOL GLYCEROL × 1 65C CHIR99021 × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；290 K；7-12% (w:v) PEG 6000 and 5-8% MPD (v:v)
|
Resolution 2.60 Å R-free 0.247 |
| 6GJO Crystal Structure of Glycogen Synthase Kinase-3 beta in Complex with BI-91BS Deposited 2018-05-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
7–420（414 aa）
|
Not recorded | F1B (3~{Z})-5-ethanoyl-3-[[(1-methylpiperidin-4-yl)amino]-phenyl-methylidene]-1~{H}-indol-2-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 8.1；277 K；100 mM Tris Acetate pH 8.1, 125 mM NaCl, 15-20% PEG8K
|
Resolution 2.91 Å R-free 0.237 |
| 6GJO Crystal Structure of Glycogen Synthase Kinase-3 beta in Complex with BI-91BS Deposited 2018-05-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
7–420（414 aa）
|
Not recorded | F1B (3~{Z})-5-ethanoyl-3-[[(1-methylpiperidin-4-yl)amino]-phenyl-methylidene]-1~{H}-indol-2-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 8.1；277 K；100 mM Tris Acetate pH 8.1, 125 mM NaCl, 15-20% PEG8K
|
Resolution 2.91 Å R-free 0.237 |
| 6GN1 Crystal Structure of Glycogen synthase kinase-3 beta (GSK3B) in Complex with PIK-75 Deposited 2018-05-29 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
27–393（367 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CL CHLORIDE ION × 1 F4N ~{N}-[(~{E})-(6-bromanylimidazo[1,2-a]pyridin-3-yl)methylideneamino]-~{N},2-dimethyl-5-nitro-benzenesulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；reservoir 0,1 M HEPES pH 7.0, 22% v/v PEG 8000, 8% ethylenglycol, 5mg/ml GSK3B (in 25 mM TRIS, 250 mM NaCl, 10 % Glycerol, pH 8), 1ul reservoir + 1ul protein solution
|
Resolution 2.60 Å R-free 0.259 |
| 6GN1 Crystal Structure of Glycogen synthase kinase-3 beta (GSK3B) in Complex with PIK-75 Deposited 2018-05-29 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
27–393（367 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CL CHLORIDE ION × 1 F4N ~{N}-[(~{E})-(6-bromanylimidazo[1,2-a]pyridin-3-yl)methylideneamino]-~{N},2-dimethyl-5-nitro-benzenesulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；reservoir 0,1 M HEPES pH 7.0, 22% v/v PEG 8000, 8% ethylenglycol, 5mg/ml GSK3B (in 25 mM TRIS, 250 mM NaCl, 10 % Glycerol, pH 8), 1ul reservoir + 1ul protein solution
|
Resolution 2.60 Å R-free 0.259 |
| 6H0U Glycogen synthase kinase-3 beta (GSK3) complex with a covalent [1,2,4]triazolo[1,5-a][1,3,5]triazine inhibitor Deposited 2018-07-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
1–420（420 aa）
Chain B
1–420（420 aa）
|
Not recorded | FKB (2~{R})-3-[7-azanyl-5-(cyclohexylamino)-[1,2,4]triazolo[1,5-a][1,3,5]triazin-2-yl]-2-cyano-propanamide × 2 MLI MALONATE ION × 1 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；GSK3beta(35-386) aliquots were concentrated to 4.4 mg/ml and used for crystallization trials. GSK3b-inhibitor co-crystals were grown using the sitting drop vapor diffusion technique in 0.2M DL-Malic acid pH 7.0, 20% PEG 3350 as reservoir solution. The protein was previously incubated with 3x molar excess of compound for 3h at 4C. Crystallization drops were prepared from 0.5ul of protein solution and 0.5ul of reservoir, and incubated for 10 days at 20C. Crystals were cryoprotected in 30% Glycerol and frozen in liquid nitrogen prior to data collection.
|
Resolution 2.30 Å R-free 0.240 |
| 6HK3 Crystal structure of GSK-3B in complex with pyrazine inhibitor C44 Deposited 2018-09-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
35–384（350 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | G8B 3-azanyl-~{N}-(2-methoxyphenyl)-6-[4-(4-methylpiperazin-1-yl)sulfonylphenyl]pyrazine-2-carboxamide × 1 MLI MALONATE ION × 1 GOL GLYCEROL × 3 CL CHLORIDE ION × 1 DMS DIMETHYL SULFOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.4；293 K；0.2M potassium fluoride
22% PEG 3350
|
Resolution 2.35 Å R-free 0.234 |
| 6HK3 Crystal structure of GSK-3B in complex with pyrazine inhibitor C44 Deposited 2018-09-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
35–384（350 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | G8B 3-azanyl-~{N}-(2-methoxyphenyl)-6-[4-(4-methylpiperazin-1-yl)sulfonylphenyl]pyrazine-2-carboxamide × 1 MLI MALONATE ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 1 DMS DIMETHYL SULFOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.4；293 K；0.2M potassium fluoride
22% PEG 3350
|
Resolution 2.35 Å R-free 0.234 |
| 6HK4 Crystal structure of GSK-3B in complex with pyrazine inhibitor C22 Deposited 2018-09-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
35–384（350 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | MLI MALONATE ION × 1 GOL GLYCEROL × 3 DMS DIMETHYL SULFOXIDE × 3 G8E 3-azanyl-6-(4-morpholin-4-ylsulfonylphenyl)-~{N}-pyridin-3-yl-pyrazine-2-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.2M potassium fluoride
22% PEG 3350
|
Resolution 2.50 Å R-free 0.249 |
| 6HK4 Crystal structure of GSK-3B in complex with pyrazine inhibitor C22 Deposited 2018-09-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
35–384（350 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | MLI MALONATE ION × 1 GOL GLYCEROL × 4 DMS DIMETHYL SULFOXIDE × 3 G8E 3-azanyl-6-(4-morpholin-4-ylsulfonylphenyl)-~{N}-pyridin-3-yl-pyrazine-2-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.2M potassium fluoride
22% PEG 3350
|
Resolution 2.50 Å R-free 0.249 |
| 6HK7 Crystal structure of GSK-3B in complex with pyrazine inhibitor C50 Deposited 2018-09-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
36–382（347 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | GOL GLYCEROL × 1 DMS DIMETHYL SULFOXIDE × 1 G8N 3-azanyl-~{N}-(2-methoxyethyl)-6-[4-(4-methylpiperazin-1-yl)sulfonylphenyl]pyrazine-2-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.4；293 K；0.2M potassium fluoride
22% PEG 3350
|
Resolution 3.20 Å R-free 0.286 |
| 6TCU Glycogen synthase kinase-3 beta (GSK3b) in complex with ligand 1 Deposited 2019-11-06 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
35–386（352 aa）
Fragment：KINASE DOMAIN
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | N1Q 5-[2,3-bis(fluoranyl)phenyl]-~{N}-[[1-(2-methoxyethyl)piperidin-4-yl]methyl]-1~{H}-indazole-3-carboxamide × 1 ACT ACETATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；277 K；18% (w/v) PEG8000
0.13 M NaCl
0.1 M Tris Acetate pH 8.0
|
Resolution 2.14 Å R-free 0.240 |
| 6V6L Co-structure of human glycogen synthase kinase beta with 1-(6-((2-((6-amino-5-nitropyridin-2-yl)amino)ethyl)amino)-2-(2,4-dichlorophenyl)pyridin-3-yl)-4-methylpiperazin-2-one Deposited 2019-12-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | QQA 1-(6-((2-((6-amino-5-nitropyridin-2-yl)amino)ethyl)amino)-2-(2,4-dichlorophenyl)pyridin-3-yl)-4-methylpiperazin-2-one × 1 PO4 PHOSPHATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；290 K；7-12% (w:v) PEG 6000 and 5-8% MPD (v:v)
|
Resolution 2.19 Å R-free 0.234 |
| 6Y9R Crystal structure of GSK-3b in complex with the 1H-indazole-3-carboxamide inhibitor 2 Deposited 2020-03-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
35–384（350 aa）
Fragment：KINASE DOMAIN
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | OH8 ~{N}-[[1-(2-methoxyethyl)piperidin-4-yl]methyl]-5-(5-propan-2-yloxypyridin-3-yl)-1~{H}-indazole-3-carboxamide × 1 ACT ACETATE ION × 1 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；277 K；18 % PEG8000
0.13 M NaCl
0.10 M Tris_Acetat_7.5
5 mM TCEP
|
Resolution 2.08 Å R-free 0.226 |
| 6Y9S Crystal structure of GSK-3b in complex with the imidazo[1,5-a]pyridine-3-carboxamide inhibitor 16 Deposited 2020-03-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
35–384（350 aa）
Fragment：KINASE DOMAIN
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | OHK ~{N}-(oxan-4-ylmethyl)-6-(5-propan-2-yloxypyridin-3-yl)imidazo[1,5-a]pyridine-3-carboxamide × 1 ACT ACETATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；277 K；0.10 M TrisAc pH8.25
26 % PEG 8K
0.13 M NaCl
|
Resolution 2.03 Å R-free 0.249 |
| 6Y9S Crystal structure of GSK-3b in complex with the imidazo[1,5-a]pyridine-3-carboxamide inhibitor 16 Deposited 2020-03-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
35–384（350 aa）
Fragment：KINASE DOMAIN
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | OHK ~{N}-(oxan-4-ylmethyl)-6-(5-propan-2-yloxypyridin-3-yl)imidazo[1,5-a]pyridine-3-carboxamide × 1 ACT ACETATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；277 K；0.10 M TrisAc pH8.25
26 % PEG 8K
0.13 M NaCl
|
Resolution 2.03 Å R-free 0.249 |
| 7B6F GSK3-beta in complex with compound (S)-5c Deposited 2020-12-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
26–383（358 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SZW 3-[(3~{S})-3-[(7-chloranyl-9~{H}-pyrimido[4,5-b]indol-4-yl)-methyl-amino]piperidin-1-yl]propanenitrile × 1 EDO 1,2-ETHANEDIOL × 2 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；protein solution: 10 mg/ml in buffer 25mM HEPES, pH 7.5, 200mM NaCl, 5% glycerol, 0.5mM TCEP
reservoir:12% PEG 8000, 1 mM MgCl2, 0.5M NaCl and 0.1M Tris pH 8.0
|
Resolution 2.05 Å R-free 0.209 |
| 7OY5 Crystal structure of GSK3Beta in complex with ARN25068 Deposited 2021-06-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
35–385（351 aa）
Chain B
35–385（351 aa）
|
Not recorded | 39I ~{N}4-(3-cyclopropyl-1~{H}-pyrazol-5-yl)-~{N}2-(phenylmethyl)thieno[3,2-d]pyrimidine-2,4-diamine × 2 CL CHLORIDE ION × 6 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；15-20%PEG 3350, 50 mM Magnesium chloride, 20 mM Hepes 7.4
|
Resolution 2.57 Å R-free 0.260 |
| 7SXH BIO-8546 bound GSK3beta-axin complex Deposited 2021-11-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
37–383（347 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | D1E (4S,5R,8R)-4-ethyl-8-fluoro-4-[3-(3-fluoro-5-methoxypyridin-4-yl)phenyl]-7,7-dimethyl-4,5,6,7,8,9-hexahydro-2H-pyrazolo[3,4-b]quinolin-5-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；289 K；0.2M calcium acetate, 0.1M BisTRIS pH 7.0, 5% Glycerol and 17% PEG3350
|
Resolution 2.09 Å R-free 0.255 |
| 7SXJ BIO-2895 (BRD0705) bound GSK3beta-axin complex Deposited 2021-11-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
34–383（350 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 6VL (4~{S})-4-ethyl-7,7-dimethyl-4-phenyl-2,6,8,9-tetrahydropyrazolo[3,4-b]quinolin-5-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2M calcium acetate, 0.1M BisTRIS pH 7.0, 5% Glycerol and 17% PEG3350
|
Resolution 1.85 Å R-free 0.203 |
| 7U2Z Crystal structure of human GSK3B in complex with G12 Deposited 2022-02-25 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
35–382（348 aa）
|
Not recorded | L7C (3R)-1-[3-(2-fluorophenyl)propanoyl]-N-(pyridin-2-yl)pyrrolidine-3-carboxamide × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.21 Å R-free 0.266 |
| 7U2Z Crystal structure of human GSK3B in complex with G12 Deposited 2022-02-25 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
35–382（348 aa）
|
Not recorded | L7C (3R)-1-[3-(2-fluorophenyl)propanoyl]-N-(pyridin-2-yl)pyrrolidine-3-carboxamide × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.21 Å R-free 0.266 |
| 7U31 Crystal structure of human GSK3B in complex with G5 Deposited 2022-02-25 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
36–385（350 aa）
|
Not recorded | CL CHLORIDE ION × 1 L7I 5-(4-fluorophenyl)-4-[1-(methanesulfonyl)azetidin-3-yl]pyrimidin-2-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.38 Å R-free 0.276 |
| 7U31 Crystal structure of human GSK3B in complex with G5 Deposited 2022-02-25 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
36–385（350 aa）
|
Not recorded | CL CHLORIDE ION × 1 L7I 5-(4-fluorophenyl)-4-[1-(methanesulfonyl)azetidin-3-yl]pyrimidin-2-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.38 Å R-free 0.276 |
| 7U33 Crystal structure of human GSK3B in complex with ARN9133 Deposited 2022-02-25 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
35–385（351 aa）
|
Not recorded | CL CHLORIDE ION × 1 L7R 3-[2-amino-5-(4-fluorophenyl)pyrimidin-4-yl]-N,N-dimethylazetidine-1-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.60 Å R-free 0.264 |
| 7U33 Crystal structure of human GSK3B in complex with ARN9133 Deposited 2022-02-25 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
35–385（351 aa）
|
Not recorded | CL CHLORIDE ION × 1 L7R 3-[2-amino-5-(4-fluorophenyl)pyrimidin-4-yl]-N,N-dimethylazetidine-1-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.60 Å R-free 0.264 |
| 7U36 Crystal structure of human GSK3B in complex with ARN1484 Deposited 2022-02-25 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
35–385（351 aa）
|
Not recorded | CL CHLORIDE ION × 1 L7W (3S)-1-[(2-fluorophenoxy)acetyl]-N-(pyridin-2-yl)pyrrolidine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.75 Å R-free 0.275 |
| 7U36 Crystal structure of human GSK3B in complex with ARN1484 Deposited 2022-02-25 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
35–385（351 aa）
|
Not recorded | CL CHLORIDE ION × 1 L7W (3S)-1-[(2-fluorophenoxy)acetyl]-N-(pyridin-2-yl)pyrrolidine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.75 Å R-free 0.275 |
| 7Z1F Crystal structure of GSK3b in complex with CX-4945 Deposited 2022-02-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
26–383（358 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 3NG 5-[(3-chlorophenyl)amino]benzo[c][2,6]naphthyridine-8-carboxylic acid × 1 IMD IMIDAZOLE × 1 YT3 YTTRIUM (III) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293.15 K；1.0 M Sodium acetate trihydrate 0.1 M Imidazole pH 6.5, 10 mM Yttrium (III) chloride
|
Resolution 3.00 Å R-free 0.249 |
| 7Z1F Crystal structure of GSK3b in complex with CX-4945 Deposited 2022-02-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
26–383（358 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 3NG 5-[(3-chlorophenyl)amino]benzo[c][2,6]naphthyridine-8-carboxylic acid × 1 YT3 YTTRIUM (III) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293.15 K；1.0 M Sodium acetate trihydrate 0.1 M Imidazole pH 6.5, 10 mM Yttrium (III) chloride
|
Resolution 3.00 Å R-free 0.249 |
| 7Z1G Crystal structure of nonphosphorylated (Tyr216) GSK3b in complex with CX-4945 Deposited 2022-02-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
26–383（358 aa）
|
Not recorded | 3NG 5-[(3-chlorophenyl)amino]benzo[c][2,6]naphthyridine-8-carboxylic acid × 1 MLI MALONATE ION × 5 IMD IMIDAZOLE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293.15 K；1.0 M Sodium acetate trihydrate 0.1 M Imidazole pH 6.5, 0.2 M di-Sodium malonate
|
Resolution 2.85 Å R-free 0.228 |
| 8AUZ Crystal structure of GSK3 beta (GSK3b) in complex with FL291. Deposited 2022-08-26 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
26–383（358 aa）
Chain B
26–383（358 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 2 O9C 8-morpholin-4-yl-2-pyridin-3-yl-[1,3]oxazolo[5,4-f]quinoxaline × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；277.15 K；14% PEG 3350, 0.1 M ammonium sulfate and 0.1 M bis-tris pH 6.0
|
Resolution 2.66 Å R-free 0.229 |
| 8AV1 Crystal structure of GSK3 beta (GSK3b) in complex with CD7. Deposited 2022-08-26 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
26–383（358 aa）
Chain B
26–383（358 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 7 O9L 2-pyridin-3-yl-8-thiomorpholin-4-yl-[1,3]oxazolo[5,4-f]quinoxaline × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；277.15 K；14% PEG 3350, 0.1 M ammonium sulfate and 0.1 M bis-tris pH 6.0
|
Resolution 2.15 Å R-free 0.210 |
| 8DJC CRYSTAL STRUCTURE OF GLYCOGEN SYNTHASE KINASE 3 BETA COMPLEXED WITH (4S)-N-{4-[(2S)-2-methylmorpholin-4-yl] pyridin-3-yl}-2-phenylimidazo[1,2-b]pyridazine-8-carboxamide Deposited 2022-06-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Not recorded | UAU (4S)-N-{4-[(2S)-2-methylmorpholin-4-yl]pyridin-3-yl}-2-phenylimidazo[1,2-b]pyridazine-8-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.1 M MES pH 6.0, 20.0 %w/v PEG6K, 0.2 M NH4Cl
|
Resolution 2.46 Å R-free 0.242 |
| 8DJC CRYSTAL STRUCTURE OF GLYCOGEN SYNTHASE KINASE 3 BETA COMPLEXED WITH (4S)-N-{4-[(2S)-2-methylmorpholin-4-yl] pyridin-3-yl}-2-phenylimidazo[1,2-b]pyridazine-8-carboxamide Deposited 2022-06-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Not recorded | UAU (4S)-N-{4-[(2S)-2-methylmorpholin-4-yl]pyridin-3-yl}-2-phenylimidazo[1,2-b]pyridazine-8-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.1 M MES pH 6.0, 20.0 %w/v PEG6K, 0.2 M NH4Cl
|
Resolution 2.46 Å R-free 0.242 |
| 8DJD CRYSTAL STRUCTURE OF GLYCOGEN SYNTHASE KINASE 3 BETA COMPLEXED WITH 3-[(CYCLOPROPYLMETHYL)AMINO] -N-(4-PHENYLPYRIDIN-3-YL)IMIDAZO[1,2-B]PYRIDAZINE-8-CARBOX AMIDE Deposited 2022-06-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Not recorded | U3E 2-[(cyclopropanecarbonyl)amino]-N-(5-phenylpyridin-3-yl)pyridine-4-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；295 K；0.1 M HEPES pH 7.0, 20.0 %w/v PEG6K, 0.2 M LiCl
|
Resolution 2.21 Å R-free 0.222 |
| 8DJD CRYSTAL STRUCTURE OF GLYCOGEN SYNTHASE KINASE 3 BETA COMPLEXED WITH 3-[(CYCLOPROPYLMETHYL)AMINO] -N-(4-PHENYLPYRIDIN-3-YL)IMIDAZO[1,2-B]PYRIDAZINE-8-CARBOX AMIDE Deposited 2022-06-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Not recorded | U3E 2-[(cyclopropanecarbonyl)amino]-N-(5-phenylpyridin-3-yl)pyridine-4-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；295 K；0.1 M HEPES pH 7.0, 20.0 %w/v PEG6K, 0.2 M LiCl
|
Resolution 2.21 Å R-free 0.222 |
| 8DJE CRYSTAL STRUCTURE OF GLYCOGEN SYNTHASE KINASE 3 BETA COMPLEXED WITH 3-[(CYCLOPROPYLMETHYL)AMINO] -N-(4-PHENYLPYRIDIN-3-YL)IMIDAZO[1,2-B]PYRIDAZINE-8-CARBOX AMIDE Deposited 2022-06-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Not recorded | U6S (4S)-3-[(cyclopropylmethyl)amino]-N-(4-phenylpyridin-3-yl)imidazo[1,2-b]pyridazine-8-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；293 K；0.1 M MES pH 6.0, 20.0 %w/v PEG6K, 0.2 M NH4Cl
|
Resolution 2.37 Å R-free 0.227 |
| 8DJE CRYSTAL STRUCTURE OF GLYCOGEN SYNTHASE KINASE 3 BETA COMPLEXED WITH 3-[(CYCLOPROPYLMETHYL)AMINO] -N-(4-PHENYLPYRIDIN-3-YL)IMIDAZO[1,2-B]PYRIDAZINE-8-CARBOX AMIDE Deposited 2022-06-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Not recorded | U6S (4S)-3-[(cyclopropylmethyl)amino]-N-(4-phenylpyridin-3-yl)imidazo[1,2-b]pyridazine-8-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；293 K；0.1 M MES pH 6.0, 20.0 %w/v PEG6K, 0.2 M NH4Cl
|
Resolution 2.37 Å R-free 0.227 |
| 8FF8 CRYSTAL STRUCTURE OF GLYCOGEN SYNTHASE KINASE 3 BETA COMPLEXED WITH 2-[(4-CYANOPHENYL)AMINO]-N-(4-PHENYLPYRIDIN-3-YL)PYRIMIDINE-4-CARBOXAMIDE Deposited 2022-12-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–420（420 aa）
|
Not recorded | XV0 2-(4-cyanoanilino)-N-(4-phenylpyridin-3-yl)pyrimidine-4-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；293 K；0.1 M MES pH 6.0, 20.0 %w/v PEG6K, 0.2 M NH4Cl, 293K
|
Resolution 2.33 Å R-free 0.217 |
| 8FF8 CRYSTAL STRUCTURE OF GLYCOGEN SYNTHASE KINASE 3 BETA COMPLEXED WITH 2-[(4-CYANOPHENYL)AMINO]-N-(4-PHENYLPYRIDIN-3-YL)PYRIMIDINE-4-CARBOXAMIDE Deposited 2022-12-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–420（420 aa）
|
Not recorded | XV0 2-(4-cyanoanilino)-N-(4-phenylpyridin-3-yl)pyrimidine-4-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；293 K；0.1 M MES pH 6.0, 20.0 %w/v PEG6K, 0.2 M NH4Cl, 293K
|
Resolution 2.33 Å R-free 0.217 |
| 8QJI Crystal structure of GSK3b in complex with N-(4-(5-(1,2,4-oxadiazol-3-yl)thiophen-2-yl)pyridin-2-yl)cyclopropanecarboxamide inhibitor (TW362) Deposited 2023-09-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
26–383（358 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | VNG N-[4-[5-(1,2,4-oxadiazol-3-yl)thiophen-2-yl]pyridin-2-yl]cyclopropanecarboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；293 K；0.1M MES, pH 6.5, 12%w/v PEG 20000
|
Resolution 3.02 Å R-free 0.289 |
| 9FR5 Crystal structure of human GSK3B in complex with ARN25697 Deposited 2024-06-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–420（419 aa）
|
Not recorded | A1IE8 ~{N}4-(3-cyclobutyl-1~{H}-pyrazol-5-yl)-~{N}2-(pyridin-3-ylmethyl)furo[3,2-d]pyrimidine-2,4-diamine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.30 Å R-free 0.235 |
| 9FR5 Crystal structure of human GSK3B in complex with ARN25697 Deposited 2024-06-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
2–420（419 aa）
|
Not recorded | A1IE8 ~{N}4-(3-cyclobutyl-1~{H}-pyrazol-5-yl)-~{N}2-(pyridin-3-ylmethyl)furo[3,2-d]pyrimidine-2,4-diamine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.30 Å R-free 0.235 |
| 9FR6 Crystal structure of human GSK3B in complex with ARN25641 Deposited 2024-06-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–420（419 aa）
|
Not recorded | A1IFO 3-[[[4-[(3-cyclopropyl-1~{H}-pyrazol-5-yl)amino]thieno[3,2-d]pyrimidin-2-yl]amino]methyl]benzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.30 Å R-free 0.232 |
| 9FR6 Crystal structure of human GSK3B in complex with ARN25641 Deposited 2024-06-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
2–420（419 aa）
|
Not recorded | A1IFO 3-[[[4-[(3-cyclopropyl-1~{H}-pyrazol-5-yl)amino]thieno[3,2-d]pyrimidin-2-yl]amino]methyl]benzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.30 Å R-free 0.232 |
| 9FR7 Crystal structure of human GSK3B in complex with ARN25507 Deposited 2024-06-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–420（419 aa）
|
Not recorded | A1IFJ ~{N}4-(5-cyclopropyl-1~{H}-pyrazol-3-yl)-~{N}2-(phenylmethyl)furo[3,2-d]pyrimidine-2,4-diamine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.30 Å R-free 0.229 |
| 9FR7 Crystal structure of human GSK3B in complex with ARN25507 Deposited 2024-06-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
2–420（419 aa）
|
Not recorded | A1IFJ ~{N}4-(5-cyclopropyl-1~{H}-pyrazol-3-yl)-~{N}2-(phenylmethyl)furo[3,2-d]pyrimidine-2,4-diamine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.30 Å R-free 0.229 |
| 9FR8 Crystal structure of human GSK3B in complex with ARN25565 Deposited 2024-06-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–420（419 aa）
|
Not recorded | A1IE7 ~{N}4-(3-cyclobutyl-1~{H}-pyrazol-5-yl)-~{N}2-(pyridin-3-ylmethyl)thieno[3,2-d]pyrimidine-2,4-diamine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.30 Å R-free 0.221 |
| 9FR8 Crystal structure of human GSK3B in complex with ARN25565 Deposited 2024-06-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
2–420（419 aa）
|
Not recorded | A1IE7 ~{N}4-(3-cyclobutyl-1~{H}-pyrazol-5-yl)-~{N}2-(pyridin-3-ylmethyl)thieno[3,2-d]pyrimidine-2,4-diamine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.30 Å R-free 0.221 |
| 9FR9 Crystal structure of human GSK3B in complex with ARN25699 Deposited 2024-06-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–420（419 aa）
|
Not recorded | A1IE6 3-[[[4-[(3-cyclobutyl-1~{H}-pyrazol-5-yl)amino]furo[3,2-d]pyrimidin-2-yl]amino]methyl]benzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.55 Å R-free 0.234 |
| 9FR9 Crystal structure of human GSK3B in complex with ARN25699 Deposited 2024-06-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
2–420（419 aa）
|
Not recorded | A1IE6 3-[[[4-[(3-cyclobutyl-1~{H}-pyrazol-5-yl)amino]furo[3,2-d]pyrimidin-2-yl]amino]methyl]benzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.55 Å R-free 0.234 |
| 9HUK Crystal structure of human GSK3b in complex with ARN24161 Deposited 2024-12-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–420（419 aa）
Chain B
2–420（419 aa）
|
Not recorded | A1IXL ~{N}-[4-[4-[2,3-bis(chloranyl)phenyl]piperazin-1-yl]butyl]-2-oxidanylidene-6-pyridin-3-yl-3~{H}-benzimidazole-1-carboxamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.4；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 3.50 Å R-free 0.250 |
| 9HUL Crystal structure of human GSK3b in complex with ARN25423 Deposited 2024-12-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–420（419 aa）
Chain B
2–420（419 aa）
|
Not recorded | A1IXM ~{N}-[3-[4-[2,3-bis(chloranyl)phenyl]piperazin-1-yl]propyl]-2-oxidanylidene-6-pyridin-3-yl-3~{H}-benzimidazole-1-carboxamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.90 Å R-free 0.244 |
| 9HV3 Crystal structure of human GSK3b in complex with ARN25657 Deposited 2024-12-24 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
2–420（419 aa）
Chain B
2–420（419 aa）
|
Not recorded | A1IXN 2-oxidanylidene-~{N}-[3-(4-phenylpiperazin-1-yl)propyl]-6-pyridin-3-yl-3~{H}-benzimidazole-1-carboxamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；PEG3350, Sodium Chloride, Hepes
|
Resolution 2.90 Å R-free 0.238 |
| 9PE9 GSK3beta in complex with compound 6 Deposited 2025-07-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
29–385（357 aa）
Fragment：residues 29-385
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | A1CIF (3R,4R)-4-({(4M)-5-fluoro-4-[4-fluoro-2-methyl-1-(propan-2-yl)-1H-1,3-benzimidazol-6-yl]pyrimidin-2-yl}amino)-1-(methanesulfonyl)piperidin-3-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；294.15 K；Well volume: 100.0 uL
Well Ingredients:
Buffer: 0.1 M (10.0 uL of stock 1.0 M) bicine (pH 9.00)
Precipitant: 14.0 %w/v (35.0 uL of stock 40.0 %w/v) PEG 10000
Plate setup temperature: 21 C
Plate incubation temperature: 21 C
Drop volume from well: 1.0 uL
Drop protein volume: 1.0 uL
Protein Formulation Composition:
Protein: GSK3B (4.85 mg/mL) (0.12 mM)
Compound: PF-6825089 (0.50 mM)
|
Resolution 2.11 Å R-free 0.247 |
| 9PE9 GSK3beta in complex with compound 6 Deposited 2025-07-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
29–385（357 aa）
Fragment：residues 29-385
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | A1CIF (3R,4R)-4-({(4M)-5-fluoro-4-[4-fluoro-2-methyl-1-(propan-2-yl)-1H-1,3-benzimidazol-6-yl]pyrimidin-2-yl}amino)-1-(methanesulfonyl)piperidin-3-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；294.15 K；Well volume: 100.0 uL
Well Ingredients:
Buffer: 0.1 M (10.0 uL of stock 1.0 M) bicine (pH 9.00)
Precipitant: 14.0 %w/v (35.0 uL of stock 40.0 %w/v) PEG 10000
Plate setup temperature: 21 C
Plate incubation temperature: 21 C
Drop volume from well: 1.0 uL
Drop protein volume: 1.0 uL
Protein Formulation Composition:
Protein: GSK3B (4.85 mg/mL) (0.12 mM)
Compound: PF-6825089 (0.50 mM)
|
Resolution 2.11 Å R-free 0.247 |
| 9X2Q GSK3beta complexed with BiS-1 Deposited 2025-10-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
27–383（357 aa）
|
Not recorded | CL CHLORIDE ION × 1 PRO PROLINE × 1 PEG DI(HYDROXYETHYL)ETHER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；283 K；0.2M L-proline, 0.1M HEPES-Na pH 7.5, 10% PEG 3350
|
Resolution 1.68 Å R-free 0.202 |
| 9X2Q GSK3beta complexed with BiS-1 Deposited 2025-10-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
27–383（357 aa）
|
Not recorded | CL CHLORIDE ION × 1 PRO PROLINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；283 K；0.2M L-proline, 0.1M HEPES-Na pH 7.5, 10% PEG 3350
|
Resolution 1.68 Å R-free 0.202 |
| 9X2U GSK3beta complexed with BiS-2 Deposited 2025-10-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
27–383（357 aa）
|
Not recorded | CL CHLORIDE ION × 1 MLI MALONATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；283 K；0.2M sodium malonate pH 7.0, 20% PEG 3350
|
Resolution 2.07 Å R-free 0.233 |
| 9X2U GSK3beta complexed with BiS-2 Deposited 2025-10-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
27–383（357 aa）
|
Not recorded | CL CHLORIDE ION × 1 MLI MALONATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；283 K；0.2M sodium malonate pH 7.0, 20% PEG 3350
|
Resolution 2.07 Å R-free 0.233 |
| 9X2V GSK3beta complexed with BiS-3 Deposited 2025-10-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
27–383（357 aa）
|
Not recorded | CL CHLORIDE ION × 1 PG6 1-(2-METHOXY-ETHOXY)-2-{2-[2-(2-METHOXY-ETHOXY]-ETHOXY}-ETHANE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；0.2M sodium malonate pH 7.0, 20% PEG 3350
|
Resolution 1.39 Å R-free 0.195 |
| 9X2W GSK3beta complexed with BiS-4 Deposited 2025-10-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
27–383（357 aa）
|
Not recorded | CL CHLORIDE ION × 1 MLI MALONATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；283 K；5% Tacsimate pH 7.0, 0.1M MES-Na pH 5.3, 15% PEG Smear Broad (Molecular Dimensions), 10% ethylene glycol
|
Resolution 1.92 Å R-free 0.209 |
| 9X2W GSK3beta complexed with BiS-4 Deposited 2025-10-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
27–383（357 aa）
|
Not recorded | CL CHLORIDE ION × 1 MLI MALONATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；283 K；5% Tacsimate pH 7.0, 0.1M MES-Na pH 5.3, 15% PEG Smear Broad (Molecular Dimensions), 10% ethylene glycol
|
Resolution 1.92 Å R-free 0.209 |
| 9X2X GSK3beta complexed with BiS-5 Deposited 2025-10-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
27–383（357 aa）
|
Not recorded | CL CHLORIDE ION × 1 MLI MALONATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；283 K；0.15M DL-malic acid, 20% PEG 3350
|
Resolution 1.79 Å R-free 0.207 |
| 9X2X GSK3beta complexed with BiS-5 Deposited 2025-10-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
27–383（357 aa）
|
Not recorded | CL CHLORIDE ION × 1 MLI MALONATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；283 K；0.15M DL-malic acid, 20% PEG 3350
|
Resolution 1.79 Å R-free 0.207 |
| 9X2Y GSK3beta complexed with BiS-8 Deposited 2025-10-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
27–383（357 aa）
|
Not recorded | CL CHLORIDE ION × 1 MLI MALONATE ION × 1 PG4 TETRAETHYLENE GLYCOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；0.2M sodium malonate pH 7.0, 20% PEG 3350
|
Resolution 1.96 Å R-free 0.205 |
| 9X2Y GSK3beta complexed with BiS-8 Deposited 2025-10-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
27–383（357 aa）
|
Not recorded | CL CHLORIDE ION × 1 MLI MALONATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；0.2M sodium malonate pH 7.0, 20% PEG 3350
|
Resolution 1.96 Å R-free 0.205 |
114 other PDB entries and 177 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | KG3B_HUMAN |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 1–352； UniProt 35–386 Author chain B； PDBConstruct 1–352； UniProt 35–386 |
