1rus

CRYSTAL STRUCTURE OF THE BINARY COMPLEX OF RIBULOSE-1,5-BISPHOSPHATE CARBOXYLASE AND ITS PRODUCT, 3-PHOSPHO-D-GLYCERATE

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

RUBISCO (RIBULOSE-1,5-BISPHOSPHATE CARBOXYLASE(SLASH)OXYGENASE)

Rhodospirillum rubrum

UniProt P04718

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein homooligomer Homooligomer Protein 2 3-PHOSPHOGLYCERIC ACID × 2 Consistent with protein count

Other States of the Same Protein in the Database

Monomer

None

Homodimer
1rba 1rus 2rus 5rub 9rub

5 assemblies

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
5hqm

1 assemblies

View Construct and Data Evidence
UniProt name RBL2_RHORU
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 25–490； UniProt 1–466 Author chain B； PDBConstruct 25–490； UniProt 1–466

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id1rus
Deposition date deposition_date1991-10-10
Structure title titleCRYSTAL STRUCTURE OF THE BINARY COMPLEX OF RIBULOSE-1,5-BISPHOSPHATE CARBOXYLASE AND ITS PRODUCT, 3-PHOSPHO-D-GLYCERATE
Keywords keywordsLYASE(CARBON-CARBON); LYASE(CARBON-CARBON)
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1rus__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1rus__assembly_1__model_1 | I(q)

10-2 10-1 106 107 108 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

1rus__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）29.50 Å
Rg (electron density)28.83 Å
Total Rg29.34 Å
Atom count6677
Residues872
Excluded volume117940 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 1rus__assembly_1__model_1 dimeric （2） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (2)

▼

6. Fold Classification (SCOP + CATH) 8 domains

SCOP 2.08 (4 domains)

Domain ID domain_idd1rusa1
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.1 — TIM beta/alpha-barrel
Superfamily Superfamily superfamilyc.1.14 — RuBisCo, C-terminal domain
Family Family familyc.1.14.1 — RuBisCo, large subunit, C-terminal domain
Domain ID domain_idd1rusa2
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.58 — Ferredoxin-like
Superfamily Superfamily superfamilyd.58.9 — RuBisCO, large subunit, small (N-terminal) domain
Family Family familyd.58.9.1 — Ribulose 1,5-bisphosphate carboxylase-oxygenase
Domain ID domain_idd1rusb1
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.1 — TIM beta/alpha-barrel
Superfamily Superfamily superfamilyc.1.14 — RuBisCo, C-terminal domain
Family Family familyc.1.14.1 — RuBisCo, large subunit, C-terminal domain
Domain ID domain_idd1rusb2
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.58 — Ferredoxin-like
Superfamily Superfamily superfamilyd.58.9 — RuBisCO, large subunit, small (N-terminal) domain
Family Family familyd.58.9.1 — Ribulose 1,5-bisphosphate carboxylase-oxygenase

CATH v4.4 (4 domains)

Domain ID domain_id1rusA01
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology70 — Alpha-Beta Plaits
Homologous superfamily homologous superfamily150 — RuBisCO large subunit, N-terminal domain
Domain ID domain_id1rusA02
Class class3 — Alpha Beta
Architecture architecture20 — Alpha-Beta Barrel
Topology topology20 — TIM Barrel
Homologous superfamily homologous superfamily110 — Ribulose bisphosphate carboxylase, large subunit, C-terminal domain
Domain ID domain_id1rusB01
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology70 — Alpha-Beta Plaits
Homologous superfamily homologous superfamily150 — RuBisCO large subunit, N-terminal domain
Domain ID domain_id1rusB02
Class class3 — Alpha Beta
Architecture architecture20 — Alpha-Beta Barrel
Topology topology20 — TIM Barrel
Homologous superfamily homologous superfamily110 — Ribulose bisphosphate carboxylase, large subunit, C-terminal domain
▶

7. Citations (6)
