Coagulation factor VII
Homo sapiens
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein heterocomplex Heteromer Protein × 3 PDB declaration: trimeric（3） Consistent with protein copy count | Chain H； UniProt 213–466 Chain L； UniProt 61–212 | Fragment：Factor VII light chain Non-standard monomer：Yes (specific site not provided by mmCIF) Fragment：Factor VII heavy chain | Tissue factor × 1 （P13726） BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 CA CALCIUM ION × 9 P5B N-(ETHYLSULFONYL)TRYPTOPHYL-N~1~-{4-[AMINO(IMINO)METHYL]BENZYL}GLUTAMAMIDE × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, HANGING DROP；pH 5；298 K；PEG 5000, sodium chloride, cacodylate, calcium chloride, VAPOR DIFFUSION, HANGING DROP, temperature 298K | Resolution 2.40 Å R-free 0.264 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 1WUN | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 1BF9 N-TERMINAL EGF-LIKE DOMAIN FROM HUMAN FACTOR VII, NMR, 23 STRUCTURES Deposited 1998-05-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
105–145（41 aa）
Fragment：N-TERMINAL EGF-LIKE DOMAIN
|
Not recorded | No recorded non-water small molecule |
SOLUTION NMR
NMR measurement conditions
pH 5.6；298 K；Ionic strength (raw mmCIF value) NO SALT ADDED；Pressure 1
NMR sample composition
H2O AND D2O
|
Resolution not provided |
| 1CVW Crystal structure of active site-inhibited human coagulation factor VIIA (DES-GLA) Deposited 1999-08-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Chain L
150–204（55 aa）
|
Not recorded | 0GE N-{[5-(dimethylamino)naphthalen-1-yl]sulfonyl}-L-alpha-glutamyl-N-[(2S,3S)-6-carbamimidamido-1-chloro-2-hydroxyhexan-3-yl]glycinamide × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；SOLUTION 30, HAMPTON SCREEN II, SEE REFERENCE 1, pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.28 Å R-free 0.239 |
| 1DAN Complex of active site inhibited human blood coagulation factor VIIA with human recombinant soluble tissue factor Deposited 1997-03-05 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain H
213–466（254 aa）
Chain L
61–212（152 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 CA CALCIUM ION × 9 0Z6 D-phenylalanyl-N-[(2S,3S)-6-{[amino(iminio)methyl]amino}-1-chloro-2-hydroxyhexan-3-yl]-L-phenylalaninamide × 1 CAC CACODYLATE ION × 1 CL CHLORIDE ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å R-free 0.218 |
| 1DVA Crystal Structure of the Complex Between the Peptide Exosite Inhibitor E-76 and Coagulation Factor VIIA Deposited 2000-01-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Chain L
102–202（101 aa）
|
Not recorded | 0Z6 D-phenylalanyl-N-[(2S,3S)-6-{[amino(iminio)methyl]amino}-1-chloro-2-hydroxyhexan-3-yl]-L-phenylalaninamide × 1 CA CALCIUM ION × 2 CAC CACODYLATE ION × 1 FUC alpha-L-fucopyranose × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；292 K；PEG4000, t-butanol, sodium cacodylate, pH 5.5, VAPOR DIFFUSION, SITTING DROP, temperature 292K
|
Resolution 3.00 Å R-free 0.295 |
| 1DVA Crystal Structure of the Complex Between the Peptide Exosite Inhibitor E-76 and Coagulation Factor VIIA Deposited 2000-01-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain I
213–466（254 aa）
Chain M
102–202（101 aa）
|
Not recorded | 0Z6 D-phenylalanyl-N-[(2S,3S)-6-{[amino(iminio)methyl]amino}-1-chloro-2-hydroxyhexan-3-yl]-L-phenylalaninamide × 1 CA CALCIUM ION × 2 CAC CACODYLATE ION × 1 GLC alpha-D-glucopyranose × 1 FUL beta-L-fucopyranose × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；292 K；PEG4000, t-butanol, sodium cacodylate, pH 5.5, VAPOR DIFFUSION, SITTING DROP, temperature 292K
|
Resolution 3.00 Å R-free 0.295 |
| 1F7E THE FIRST EGF-LIKE DOMAIN FROM HUMAN BLOOD COAGULATION FVII, NMR, 20 STRUCTURES Deposited 1999-02-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
83–125（43 aa）
Fragment：FIRST EGF-LIKE DOMAIN (RESIDUES 45-87)
|
Not recorded | No recorded non-water small molecule |
SOLUTION NMR
NMR measurement conditions
pH 5.5；298 K；Ionic strength (raw mmCIF value) 400mM；Pressure 1
|
Resolution not provided |
| 1F7M THE FIRST EGF-LIKE DOMAIN FROM HUMAN BLOOD COAGULATION FVII, NMR, MINIMIZED AVERAGE STRUCTURE Deposited 1999-02-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
83–125（43 aa）
Fragment：FIRST EGF-LIKE DOMAIN
|
Not recorded | No recorded non-water small molecule |
SOLUTION NMR
NMR measurement conditions
pH 5.5；298 K；Ionic strength (raw mmCIF value) 400mM；Pressure 1
|
Resolution not provided |
| 1FAK HUMAN TISSUE FACTOR COMPLEXED WITH COAGULATION FACTOR VIIA INHIBITED WITH A BPTI-MUTANT Deposited 1998-12-28 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain H
213–466（254 aa）
Fragment：HEAVY CHAIN
Chain L
61–212（152 aa）
Fragment：LIGHT CHAIN
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | GLC alpha-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.6；pH 5.6
|
Resolution 2.10 Å |
| 1FF7 THE FIRST EGF-LIKE DOMAIN FROM HUMAN BLOOD COAGULATION FVII (FUCOSYLATED AT SER-60), NMR, 20 STRUCTURES Deposited 1999-02-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
83–125（43 aa）
Fragment：FIRST EGF-LIKE DOMAIN (FUCOSYLATED AT SER-60)
|
Not recorded | FUC alpha-L-fucopyranose × 1 |
SOLUTION NMR
NMR measurement conditions
pH 5.5；298 K；Ionic strength (raw mmCIF value) 400mM；Pressure 1
|
Resolution not provided |
| 1FFM THE FIRST EGF-LIKE DOMAIN FROM HUMAN BLOOD COAGULATION FVII (FUCOSYLATED AT SER-60), NMR, MINIMIZED AVERAGE STRUCTURE Deposited 1999-02-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
83–125（43 aa）
Fragment：FIRST EGF-LIKE DOMAIN (RESIDUES 45-87; FUCOSYLATED AT SER-60)
|
Not recorded | FUC alpha-L-fucopyranose × 1 |
SOLUTION NMR
NMR measurement conditions
pH 5.5；298 K；Ionic strength (raw mmCIF value) 400mM；Pressure 1
|
Resolution not provided |
| 1J9C Crystal Structure of tissue factor-factor VIIa complex Deposited 2001-05-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Chain L
108–202（95 aa）
|
Not recorded | GLC alpha-D-glucopyranose × 1 FUL beta-L-fucopyranose × 1 0Z6 D-phenylalanyl-N-[(2S,3S)-6-{[amino(iminio)methyl]amino}-1-chloro-2-hydroxyhexan-3-yl]-L-phenylalaninamide × 1 NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；2% PEG 400, 2% 2-propanol, 2% PEG 4000, 12.5mM Calcium chloride, 2.0M ammonium sulfate, 0.1M HEPES, pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.90 Å R-free 0.299 |
| 1JBU Coagulation Factor VII Zymogen (EGF2/Protease) in Complex with Inhibitory Exosite Peptide A-183 Deposited 2001-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：Heavy chain
Chain L
150–212（63 aa）
Fragment：Light chain
|
Not recorded | SO4 SULFATE ION × 1 BEN BENZAMIDINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；HEPES, ammonium sulfate, glycerol, PEG 400, benzamidine, calcium chloride, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.227 |
| 1JBU Coagulation Factor VII Zymogen (EGF2/Protease) in Complex with Inhibitory Exosite Peptide A-183 Deposited 2001-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：Heavy chain
Chain L
150–212（63 aa）
Fragment：Light chain
|
Not recorded | SO4 SULFATE ION × 1 BEN BENZAMIDINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；HEPES, ammonium sulfate, glycerol, PEG 400, benzamidine, calcium chloride, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.227 |
| 1KLI Cofactor-and substrate-assisted activation of factor VIIa Deposited 2001-12-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：heavy chain
Chain L
144–212（69 aa）
Fragment：light chain
|
Not recorded | SO4 SULFATE ION × 4 CA CALCIUM ION × 1 BEN BENZAMIDINE × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；275 K；Ammonium sulphate, glycerol, PEG 400, BICINE, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 275K
|
Resolution 1.69 Å R-free 0.225 |
| 1KLI Cofactor-and substrate-assisted activation of factor VIIa Deposited 2001-12-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain H
213–466（254 aa）
Fragment：heavy chain
Chain L
144–212（69 aa）
Fragment：light chain
|
Not recorded | SO4 SULFATE ION × 8 CA CALCIUM ION × 2 BEN BENZAMIDINE × 2 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；275 K；Ammonium sulphate, glycerol, PEG 400, BICINE, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 275K
|
Resolution 1.69 Å R-free 0.225 |
| 1KLJ Crystal structure of uninhibited factor VIIa Deposited 2001-12-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：heavy chain
Chain L
144–212（69 aa）
Fragment：light chain
|
Not recorded | CA CALCIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；275 K；Ammonium sulphate, glycerol, PEG 400, BICINE, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 275K
|
Resolution 2.44 Å R-free 0.286 |
| 1O5D Dissecting and Designing Inhibitor Selectivity Determinants at the S1 site Using an Artificial Ala190 Protease (Ala190 uPA) Deposited 2003-09-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：heavy chain (catalytic domain)
Chain L
61–212（152 aa）
Fragment：light chain
|
Not recorded | CR9 2-{5-[AMINO(IMINIO)METHYL]-6-FLUORO-1H-BENZIMIDAZOL-2-YL}-6-[(2-METHYLCYCLOHEXYL)OXY]BENZENOLATE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.2；290 K；0.1 M citrate, 16-18% PEG 5K MME, pH 7.2, vapor diffusion at 290 K
|
Resolution 2.05 Å R-free 0.262 |
| 1QFK STRUCTURE OF HUMAN FACTOR VIIA AND ITS IMPLICATIONS FOR THE TRIGGERING OF BLOOD COAGULATION Deposited 1999-04-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：UNP residues 213-466
Chain L
109–212（104 aa）
Fragment：UNP residues 109-212
|
Not recorded | GLC alpha-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 0Z6 D-phenylalanyl-N-[(2S,3S)-6-{[amino(iminio)methyl]amino}-1-chloro-2-hydroxyhexan-3-yl]-L-phenylalaninamide × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；50MM NACL, 10MM CACL2, 3.5-3.7M SODIUM FORMATE IN 100MM TRIS PH 8.5, pH 8.50
|
Resolution 2.80 Å R-free 0.267 |
| 1W0Y tf7a_3771 complex Deposited 2004-05-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：FACTOR VII HEAVY CHAIN, RESIDUES 213-466
Chain L
61–202（142 aa）
Fragment：FACTOR VII HEAVY CHAIN, RESIDUES 61-202
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 771 4-(4-BENZYLOXY-2-METHANESULFONYLAMINO-5-METHOXY-BENZYLAMINO)-BENZAMIDINE × 1 CA CALCIUM ION × 9 CAC CACODYLATE ION × 1 FUC alpha-L-fucopyranose × 1 BGC beta-D-glucopyranose × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；pH 5.50
|
Resolution 2.50 Å R-free 0.258 |
| 1W2K tf7a_4380 complex Deposited 2004-07-06 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：FACTOR VII HEAVY CHAIN, RESIDUES 213-466
Chain L
61–202（142 aa）
Fragment：FACTOR VII HEAVY CHAIN, RESIDUES 61-202
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 380 (2R)-2-({4-[AMINO(IMINO)METHYL]PHENYL}AMINO)-N-BENZYL-2-(3,4-DIMETHOXYPHENYL)ACETAMIDE × 1 CA CALCIUM ION × 9 CAC CACODYLATE ION × 1 FUC alpha-L-fucopyranose × 1 BGC beta-D-glucopyranose × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；pH 5.50
|
Resolution 3.00 Å R-free 0.257 |
| 1W7X Factor7 - 413 complex Deposited 2004-09-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：FACTOR VII HEAVY CHAIN, RESIDUES 213-466
Chain L
150–204（55 aa）
Fragment：FACTOR VII LIGHT CHAIN, RESIDUES 151-204
|
Not recorded | GOL GLYCEROL × 2 CA CALCIUM ION × 1 413 (S)-[(R)-2-(4-BENZYLOXY-3-METHOXY-PHENYL)-2-(4-CARBAMIMIDOYL-PHENYLAMINO)-ACETYLAMINO]-PHENYL-ACETIC ACID × 1 SO4 SULFATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；35%AS, 2%PEG400, 100MM BICINE PH8.5, 15% GLYCEROL, pH 8.50
|
Resolution 1.80 Å R-free 0.195 |
| 1W8B Factor7 - 413 complex Deposited 2004-09-17 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：FACTOR VII HEAVY CHAIN, RESIDUES 213-466
Chain L
148–204（57 aa）
Fragment：FACTOR VII LIGHT CHAIN, RESIDUES 148-204
|
Not recorded | CA CALCIUM ION × 1 413 (S)-[(R)-2-(4-BENZYLOXY-3-METHOXY-PHENYL)-2-(4-CARBAMIMIDOYL-PHENYLAMINO)-ACETYLAMINO]-PHENYL-ACETIC ACID × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 3.00 Å R-free 0.272 |
| 1WQV Human Factor Viia-Tissue Factor Complexed with propylsulfonamide-D-Thr-Met-p-aminobenzamidine Deposited 2004-10-02 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：Factor VII heavy chain
Chain L
61–212（152 aa）
Fragment：Factor VII light chain
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 CA CALCIUM ION × 9 PSM N-[DIHYDROXY(PROPYL)-LAMBDA~4~-SULFANYL]THREONYL-N~1~-{4-[AMINO(IMINO)METHYL]BENZYL}METHIONINAMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；298 K；PEG 5000, sodium chloride, cacodylate, calcium chloride, pH 5.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.50 Å R-free 0.272 |
| 1WSS Human Factor Viia-Tissue Factor in Complex with peptide-mimetic inhibitor that has two charged groups in P2 and P4 Deposited 2004-11-10 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：Factor VII heavy chain
Chain L
61–212（152 aa）
Fragment：Factor VII light chain
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 CA CALCIUM ION × 9 3CB N-[(3-CARBOXYBENZYL)SULFONYL]ISOLEUCYL-N~1~-{4-[AMINO(IMINO)METHYL]BENZYL}-5-IMINOORNITHINAMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；298 K；PEG 5000, sodium chloride, cacodylate, calcium chloride, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.60 Å R-free 0.282 |
| 1WTG Human Factor Viia-Tissue Factor Complexed with ethylsulfonamide-D-biphenylalanine-Gln-p-aminobenzamidine Deposited 2004-11-23 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：Factor VII heavy chain
Chain L
61–212（152 aa）
Fragment：Factor VII light chain
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 CA CALCIUM ION × 9 3BP 2-(3-BIPHENYL-4-YL-2-ETHANESULFONYLAMINO-PROPIONYLAMINO)-PENTANEDIOIC ACID 5-AMIDE 1-(4-CARBAMIMIDOYL-BENZYLAMIDE) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；298 K；PEG 5000, sodium chloride, cacodylate, calcium chloride, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.20 Å R-free 0.251 |
| 1WV7 Human Factor Viia-Tissue Factor Complexed with ethylsulfonamide-D-5-propoxy-Trp-Gln-p-aminobenzamidine Deposited 2004-12-11 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：Factor VII heavy chain
Chain L
61–212（152 aa）
Fragment：Factor VII light chain
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 CA CALCIUM ION × 9 5PI N-(ETHYLSULFONYL)-5-PROPOXY-L-TRYPTOPHYL-N~1~-{4-[AMINO(IMINO)METHYL]BENZYL}-L-GLUTAMAMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；298 K；PEG 5000, sodium chloride, cacodylate, calcium chloride, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.70 Å R-free 0.273 |
| 1YGC Short Factor VIIa with a small molecule inhibitor Deposited 2005-01-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：heavy chain (residues 213-466)
Chain L
150–212（63 aa）
Fragment：light chain, del 1-149 from full length (residues 150-212)
|
Not recorded | CA CALCIUM ION × 2 SO4 SULFATE ION × 7 905 (R)-4-[2-(3-AMINO-BENZENESULFONYLAMINO)-1-(3,5-DIETHOXY-2-FLUOROPHENYL)-2-OXO-ETHYLAMINO]-2-HYDROXY-BENZAMIDINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；292 K；ammonium sulfate, glycerol, PEG 400, Calcium ion, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 292K
|
Resolution 2.00 Å R-free 0.205 |
| 1YGC Short Factor VIIa with a small molecule inhibitor Deposited 2005-01-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain H
213–466（254 aa）
Fragment：heavy chain (residues 213-466)
Chain L
150–212（63 aa）
Fragment：light chain, del 1-149 from full length (residues 150-212)
|
Not recorded | CA CALCIUM ION × 4 SO4 SULFATE ION × 14 905 (R)-4-[2-(3-AMINO-BENZENESULFONYLAMINO)-1-(3,5-DIETHOXY-2-FLUOROPHENYL)-2-OXO-ETHYLAMINO]-2-HYDROXY-BENZAMIDINE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；292 K；ammonium sulfate, glycerol, PEG 400, Calcium ion, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 292K
|
Resolution 2.00 Å R-free 0.205 |
| 1Z6J Crystal Structure of a ternary complex of Factor VIIa/Tissue Factor/Pyrazinone Inhibitor Deposited 2005-03-22 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：Heavy Chain
Chain L
61–202（142 aa）
Fragment：Light Chain
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CA CALCIUM ION × 2 MG MAGNESIUM ION × 1 PY3 5-[AMINO(IMINO)METHYL]-2-[({[6-[3-AMINO-5-({[(1R)-1-METHYLPROPYL]AMINO}CARBONYL)PHENYL]-3-(ISOPROPYLAMINO)-2-OXOPYRAZIN-1(2H)-YL]ACETYL}AMINO)METHYL]-N-PYRIDIN-4-YLBENZAMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.5；298 K；50 mM citrate, 16-24% PEG 4K, 150 mM MgCl2, pH 7.5, VAPOR DIFFUSION, temperature 298K
|
Resolution 2.00 Å R-free 0.258 |
| 2A2Q Complex of Active-site Inhibited Human Coagulation Factor VIIa with Human Soluble Tissue Factor in the Presence of Ca2+, Mg2+, Na+, and Zn2+ Deposited 2005-06-22 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：Heavy chain, residues 213-466
Chain L
61–212（152 aa）
Fragment：Light chain, residues 61-212
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | GLC alpha-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 MG MAGNESIUM ION × 3 CA CALCIUM ION × 6 NA SODIUM ION × 1 ZN ZINC ION × 2 CL CHLORIDE ION × 3 PBZ P-AMINO BENZAMIDINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7；298 K；PEG 4000, magnesium chloride, sodium chloride, calcium chloride, zinc chloride, Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 298K, pH 7.00
|
Resolution 1.80 Å R-free 0.259 |
| 2AEI Crystal structure of a ternary complex of factor VIIa/tissue factor and 2-[[6-[3-(aminoiminomethyl)phenoxy]-3,5-difluro-4-[(1-methyl-3-phenylpropyl)amino]-2-pyridinyl]oxy]-benzoic acid Deposited 2005-07-22 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：HEAVY CHAIN
Chain L
61–212（152 aa）
Fragment：LIGHT CHAIN
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CA CALCIUM ION × 8 CAC CACODYLATE ION × 1 03R 2-({6-{3-[AMINO(IMINO)METHYL]PHENOXY}-3,5-DIFLUORO-4-[(1-METHYL-3-PHENYLPROPYL)AMINO]-2-PYRIDINYL}OXY)BENZOIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；298 K；PEG 8000,CACODYLATE, GLYCEROL, pH 5.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.52 Å R-free 0.297 |
| 2AER Crystal Structure of Benzamidine-Factor VIIa/Soluble Tissue Factor complex. Deposited 2005-07-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：Factor VII heavy chain
Chain L
61–202（142 aa）
Fragment：Factor VII light chain
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | GLC alpha-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 MG MAGNESIUM ION × 3 CA CALCIUM ION × 6 NA SODIUM ION × 1 ZN ZINC ION × 2 CL CHLORIDE ION × 3 BEN BENZAMIDINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.2；298 K；Tris, Sodium Chloride, Calcium Chloride, PEG 4000, ADA, Magnesium Chloride, pH 6.2, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.87 Å R-free 0.256 |
| 2B7D Factor VIIa Inhibitors: Chemical Optimization, Preclinical Pharmacokinetics, Pharmacodynamics, and Efficacy in a Baboon Thrombosis Model Deposited 2005-10-04 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：heavy chain
Chain L
61–212（152 aa）
Fragment：light chain
|
Not recorded | C1B (2R)-2-[5-(5-CARBAMIMIDOYL-1H-BENZOIMIDAZOL-2-YL)-6,2'-DIHYDROXY-5'-UREIDOMETHYL-BIPHENYL-3-YL]-SUCCINIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.2；290 K；0.1 M citrate, 16-18 % PEG 5K MME, pH 7.2, VAPOR DIFFUSION, HANGING DROP, temperature 290.0K
|
Resolution 2.24 Å R-free 0.289 |
| 2B8O Crystal Structure of Glu-Gly-Arg-Chloromethyl Ketone-Factor VIIa/Soluble Tissue Factor Complex Deposited 2005-10-08 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Chain L
61–202（142 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | GLC alpha-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 CA CALCIUM ION × 6 MG MAGNESIUM ION × 2 0GJ L-alpha-glutamyl-N-{(1S)-4-{[amino(iminio)methyl]amino}-1-[(1S)-2-chloro-1-hydroxyethyl]butyl}glycinamide × 1 NA SODIUM ION × 1 ZN ZINC ION × 2 CL CHLORIDE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.2；298 K；Tris, sodium chloride, calcium chloride, PEG 4000, ADA, magnesium chloride, pH 6.2, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.80 Å R-free 0.285 |
| 2BZ6 Orally available Factor7a inhibitor Deposited 2005-08-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：FACTOR VII HEAVY CHAIN, RESIDUES 213-466
Chain L
150–202（53 aa）
Fragment：FACTOR VII LIGHT CHAIN, RESIDUES 150-202
|
Not recorded | 346 (R)-(4-CARBAMIMIDOYL-PHENYLAMINO)-[5-ETHOXY-2-FLUORO-3-[(R)-TETRAHYDRO-FURAN-3-YLOXY]-PHENYL]-ACETIC ACID × 1 SO4 SULFATE ION × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；35%AS, 2%PEG400, 100MM BICINE PH8.5, 15% GLYCEROL, pH 8.50
|
Resolution 1.60 Å R-free 0.193 |
| 2C4F crystal structure of factor VII.stf complexed with pd0297121 Deposited 2005-10-18 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain H
213–466（254 aa）
Fragment：FACTOR VII HEAVY CHAIN, RESIDUES 213-466
Chain L
61–202（142 aa）
Fragment：FACTOR VII LIGHT CHAIN, RESIDUES 61-202
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CA CALCIUM ION × 5 GIL 2-{[6-{3-[AMINO(IMINO)METHYL]PHENOXY}-4-(DIISOPROPYLAMINO)-3,5-DIFLUOROPYRIDIN-2-YL]OXY}-5-[(ISOBUTYLAMINO)CARBONYL]BEN ZOIC ACID × 1 GLC alpha-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.72 Å |
| 2EC9 Crystal structure analysis of human Factor VIIa , Souluble tissue factor complexed with BCX-3607 Deposited 2007-02-13 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain H
213–466（254 aa）
Fragment：residues 16-257
Chain L
61–202（142 aa）
Fragment：residues 1-142
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | ASO 1,5-anhydro-D-glucitol × 1 FUC alpha-L-fucopyranose × 1 CA CALCIUM ION × 9 24X 2'-((5-CARBAMIMIDOYLPYRIDIN-2-YLAMINO)METHYL)-4-(ISOBUTYLCARBAMOYL)-4'-VINYLBIPHENYL-2-CARBOXYLIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；14% (w/v)PEG 4K, 0.1M MgCl2, 0.1M ADA buffer, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.282 |
| 2F9B Discovery of Novel Heterocyclic Factor VIIa Inhibitors Deposited 2005-12-05 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：heavy chain, residues 213-466
Chain L
61–212（152 aa）
Fragment：light chain, residues 61-212
|
Not recorded | N1H {5-(5-AMINO-1H-PYRROLO[3,2-B]PYRIDIN-2-YL)-6-HYDROXY-3'-NITRO-BIPHENYL-3-YL]-ACETIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.2；290 K；0.1 M CITRATE, 16-18% PEG5000 MME, pH 7.2, VAPOR DIFFUSION, HANGING DROP, temperature 290K
|
Resolution 2.54 Å R-free 0.286 |
| 2FIR Crystal structure of DFPR-VIIa/sTF Deposited 2005-12-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Chain L
61–202（142 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | GLC alpha-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 MG MAGNESIUM ION × 3 CA CALCIUM ION × 6 0G7 D-phenylalanyl-N-[(3S)-6-carbamimidamido-1-chloro-2-oxohexan-3-yl]-L-prolinamide × 1 NA SODIUM ION × 1 ZN ZINC ION × 2 CL CHLORIDE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；293 K；20% PEG 4000, 100 mM magnesium chloride, 200 mM sodium chloride, 10 mM calcium chloride, 20 uM zinc chloride , pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.281 |
| 2FLB Discovery of a Novel Hydroxy Pyrazole Based Factor IXa Inhibitor Deposited 2006-01-05 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：heavy chain, residues 213-466
Chain L
61–212（152 aa）
Fragment：light chain, residues 61-212
|
Not recorded | 6NH 2-(4-HYDROXY-5-PHENYL-1H-PYRAZOL-3-YL)-1H-BENZOIMIDAZOLE-5-CARBOXAMIDINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.2；290 K；0.1 M CITRATE, 16-18% PEG5000 MME, pH 7.2, VAPOR DIFFUSION, HANGING DROP, temperature 290.0K
|
Resolution 1.95 Å R-free 0.280 |
| 2FLR Novel 5-Azaindole Factor VIIa Inhibitors Deposited 2006-01-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：heavy chain, residues 213-466
Chain L
61–212（152 aa）
Fragment：light chain, residues 61-212
|
Not recorded | 7NH [2'-HYDROXY-3'-(1H-PYRROLO[3,2-C]PYRIDIN-2-YL)-BIPHENYL-3-YLMETHYL]-UREA × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.2；290 K；0.1 M CITRATE, 16-18% PEG5000 MME, pH 7.2, VAPOR DIFFUSION, HANGING DROP, temperature 290K
|
Resolution 2.35 Å R-free 0.259 |
| 2PUQ Crystal structure of active site inhibited coagulation factor VIIA in complex with soluble tissue factor Deposited 2007-05-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain H
213–466（254 aa）
Fragment：HEAVY CHAIN
Chain L
109–202（94 aa）
Fragment：LIGHT CHAIN
|
Not recorded | BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；298 K；0.1 M sodium citrate, pH 5.6, 16.0 % (w/v) PEG 4000, 12 % (v/v) 1-propanol, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.05 Å R-free 0.273 |
| 2ZP0 Human factor viia-tissue factor complexed with benzylsulfonamide-D-ile-gln-P-aminobenzamidine Deposited 2008-06-20 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Chain L
61–212（152 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 CA CALCIUM ION × 9 PI0 (2S)-N-[(4-carbamimidoylphenyl)methyl]-2-[[(2R,3R)-3-methyl-2-(phenylmethylsulfonylamino)pentanoyl]amino]pentanediamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；298 K；8 % PEG 5000, 0.1M sodium chloride, 0.005M calcium chloride, 0.1M cacodylate, pH 5.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.70 Å R-free 0.306 |
| 2ZWL Human factor viia-tissue factor complexed with highly selective peptide inhibitor Deposited 2008-12-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：UNP residues 213-466
Chain L
61–212（152 aa）
Fragment：UNP residues 61-212
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 CA CALCIUM ION × 9 567 2-[[(2R)-1-[[(2S)-5-amino-1-[(4-carbamimidoylphenyl)methylamino]-1,5-dioxo-pentan-2-yl]amino]-3-(1H-indol-3-yl)-1-oxo-propan-2-yl]sulfamoyl]ethanoic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；298 K；8% PEG 5000, 0.1M sodium chloride, 0.005M calcium chloride, 0.1M cacodylate, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.20 Å R-free 0.267 |
| 2ZZU Human Factor VIIA-Tissue Factor Complexed with ethylsulfonamide-D-5-(3-carboxybenzyloxy)-Trp-Gln-p-aminobenzamidine Deposited 2009-02-25 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：UNP RESIDUES 213-466
Chain L
61–212（152 aa）
Fragment：UNP RESIDUES 61-212
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 CA CALCIUM ION × 9 359 3-[[3-[(2R)-3-[[(2S)-5-amino-1-[(4-carbamimidoylphenyl)methylamino]-1,5-dioxo-pentan-2-yl]amino]-2-(ethylsulfonylamino)-3-oxo-propyl]-1H-indol-5-yl]oxymethyl]benzoic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；298 K；8% PEG5000, 0.1M sodium chloride, 0.005M calcium chloride, 0.1M cacodylate, VAPOR DIFFUSION, HANGING DROP, TEMPERATURE 298K
|
Resolution 2.50 Å R-free 0.273 |
| 3ELA Crystal structure of active site inhibited coagulation factor VIIA mutant in complex with soluble tissue factor Deposited 2008-09-21 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：UNP residues 213-466
Chain L
61–212（152 aa）
Fragment：UNP residues 61-212
|
Mutation：V158D,E296V,M298Q | GLC alpha-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 CA CALCIUM ION × 1 0Z6 D-phenylalanyl-N-[(2S,3S)-6-{[amino(iminio)methyl]amino}-1-chloro-2-hydroxyhexan-3-yl]-L-phenylalaninamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；298 K；100mM NaCitrate, 16%(w/v) PEG4000, 12%(v/v) 1-propanol, pH 5.6, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.20 Å R-free 0.294 |
| 3TH2 Mg2+ Is Required for Optimal Folding of the Gamma-Carboxyglutamic Acid (Gla) Domains of Vitamin K-Dependent Clotting Factors At Physiological Ca2+ Deposited 2011-08-18 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Chain L
61–202（142 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 MG MAGNESIUM ION × 3 CA CALCIUM ION × 6 BEN BENZAMIDINE × 1 NA SODIUM ION × 1 CL CHLORIDE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7；298 K；20% PEG 4000, 50 mM Tris-HCL, 50 mM N-(2-Acetamido)iminodiacetic acid, 150 mM NaCl, 5 mM Calcium Chloride, 2.5 mM Magnesium Chloride, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
|
Resolution 1.72 Å R-free 0.233 |
| 3TH3 Mg2+ Is Required for Optimal Folding of the Gamma-Carboxyglutamic Acid (Gla) Domains of Vitamin K-Dependent Clotting Factors At Physiological Ca2+ Deposited 2011-08-18 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Chain L
61–202（142 aa）
Fragment：Coagulation Factor VII
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | FUC alpha-L-fucopyranose × 1 CA CALCIUM ION × 2 BGC beta-D-glucopyranose × 1 0GE N-{[5-(dimethylamino)naphthalen-1-yl]sulfonyl}-L-alpha-glutamyl-N-[(2S,3S)-6-carbamimidamido-1-chloro-2-hydroxyhexan-3-yl]glycinamide × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7；298 K；20% PEG 4000, 50 mM Tris-HCL, 50 mM N-(2-Acetamido)iminodiacetic acid, 150 mM NaCl, 2.5 mM Calcium Chloride, 1.25 mM Magnesium Chloride, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
|
Resolution 2.70 Å R-free 0.298 |
| 3TH4 Mg2+ Is Required for Optimal Folding of the Gamma-Carboxyglutamic Acid (Gla) Domains of Vitamin K-Dependent Clotting Factors At Physiological Ca2+ Deposited 2011-08-18 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Chain L
61–202（142 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 MG MAGNESIUM ION × 2 CA CALCIUM ION × 7 0GE N-{[5-(dimethylamino)naphthalen-1-yl]sulfonyl}-L-alpha-glutamyl-N-[(2S,3S)-6-carbamimidamido-1-chloro-2-hydroxyhexan-3-yl]glycinamide × 1 CL CHLORIDE ION × 3 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7；298 K；20% PEG 4000, 50 mM Tris-HCL, 50 mM N-(2-Acetamido)iminodiacetic acid, 150 mM NaCl, 45 mM Calcium Chloride, 5 mM Magnesium Chloride, pH 7.0, VAPOR DIFFUSION, temperature 298K
|
Resolution 1.80 Å R-free 0.235 |
| 4IBL Rubidium Sites in Blood Coagulation Factor VIIa Deposited 2012-12-08 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：Heavy Chain
Chain L
61–212（152 aa）
Fragment：Light Chain
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 MG MAGNESIUM ION × 3 CA CALCIUM ION × 4 RB RUBIDIUM ION × 6 BEN BENZAMIDINE × 1 CL CHLORIDE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；20 mM Tris-HCL, 200mM RbCl, 5 mM Calcium Chloride, 45 mM Magnesium Chloride
, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.215 |
| 4ISH Structure of FACTOR VIIA in complex with the inhibitor BMS-593214 also known as 2'-[(6R,6AR,11BR)-2-CARBAMIMIDOYL-6,6A,7,11B-TETRAHYDRO-5H-INDENO[2,1-C]QUINOLIN-6-YL]-5'-HYDROXY-4'-METHOXYBIPHENYL-4-CARBOXYLIC ACID Deposited 2013-01-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Chain L
150–204（55 aa）
Fragment：UNP residues 150-204
|
Not recorded | 1GE 2'-[(6R,6aR,11bR)-2-carbamimidoyl-6,6a,7,11b-tetrahydro-5H-indeno[2,1-c]quinolin-6-yl]-5'-hydroxy-4'-methoxybiphenyl-4-carboxylic acid × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000, vapor diffusion, hanging drop, temperature 277K
|
Resolution 1.82 Å R-free 0.213 |
| 4ISI Structure of FACTOR VIIA in complex with the inhibitor (6S)-N-(4-CARBAMIMIDOYLBENZYL)-1-CHLORO-3-(CYCLOBUTYLAMINO)-8,8-DIETHYL-4-OXO-4,6,7,8-TETRAHYDROPYRROLO[1,2-A]PYRAZINE-6-CARBOXAMIDE Deposited 2013-01-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Chain L
150–204（55 aa）
Fragment：UNP residues 150-204
|
Not recorded | 1GG (6S)-N-(4-carbamimidoylbenzyl)-1-chloro-3-(cyclobutylamino)-8,8-diethyl-4-oxo-4,6,7,8-tetrahydropyrrolo[1,2-a]pyrazine-6-carboxamide × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000, vapor diffusion, hanging drop, temperature 277K
|
Resolution 1.94 Å R-free 0.229 |
| 4JYU Structure of factor VIIA in complex with the inhibitor (2R)-2-[(1-AMINOISOQUINOLIN-6-YL)AMINO]-2-[3-ETHOXY-4-(PROPAN-2-YLOXY)PHENYL]-N-(PHENYLSULFONYL)ETHANAMIDE Deposited 2013-04-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Chain L
150–204（55 aa）
|
Not recorded | 1OK (2R)-2-[(1-aminoisoquinolin-6-yl)amino]-2-[3-ethoxy-4-(propan-2-yloxy)phenyl]-N-(phenylsulfonyl)ethanamide × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 4 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000, vapor diffusion, hanging drop, temperature 277K
|
Resolution 1.80 Å R-free 0.192 |
| 4JYV Structure of factor VIIA in complex with the inhibitor (2R)-2-[3-ETHOXY-4-(PROPAN-2-YLOXY)PHENYL]-2-(ISOQUINOLIN-6-YLAMINO)-N-[(3-SULFAMOYLPHENYL)SULFONYL]ETHANAMIDE Deposited 2013-04-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Chain L
150–204（55 aa）
|
Not recorded | 1OJ (2R)-2-[3-ethoxy-4-(propan-2-yloxy)phenyl]-2-(isoquinolin-6-ylamino)-N-[(3-sulfamoylphenyl)sulfonyl]ethanamide × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 4 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000, vapor diffusion, hanging drop, temperature 277K
|
Resolution 2.19 Å R-free 0.215 |
| 4JZD Structure of factor VIIA in complex with the inhibitor 2-{2-[(4-carbamimidoylphenyl)carbamoyl]-6-methoxypyridin-3-yl}-5-{[(2S)-1-hydroxy-3,3-dimethylbutan-2-yl]carbamoyl}benzoic acid Deposited 2013-04-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：UNP residues 213-466
Chain L
150–204（55 aa）
Fragment：UNP residues 150-204
|
Not recorded | 1NJ 2-{2-[(4-carbamimidoylphenyl)carbamoyl]-6-methoxypyridin-3-yl}-5-{[(2S)-1-hydroxy-3,3-dimethylbutan-2-yl]carbamoyl}benzoic acid × 2 CA CALCIUM ION × 1 SO4 SULFATE ION × 6 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；277 K；100 mM bicine, pH 9.0, 1.4-1.9 M lithium sulfate, 5% v/v MPD, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.20 Å R-free 0.197 |
| 4JZE Structure of factor VIIA in complex with the inhibitor 2-{2-[(1-aminoisoquinolin-6-yl)carbamoyl]-6-methoxypyridin-3-yl}-5-{[(2S)-1-hydroxy-3,3-dimethylbutan-2-yl]carbamoyl}benzoic acid Deposited 2013-04-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：UNP residues 213-466
Chain L
150–204（55 aa）
Fragment：UNP residues 150-204
|
Not recorded | 1NK 2-{2-[(1-aminoisoquinolin-6-yl)carbamoyl]-6-methoxypyridin-3-yl}-5-{[(2S)-1-hydroxy-3,3-dimethylbutan-2-yl]carbamoyl}benzoic acid × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 4 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM calcium chloride, 17.5% w/v PEG6000, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 1.52 Å R-free 0.210 |
| 4JZF Structure of factor VIIA in complex with the inhibitor 2-{2-[(3-carbamoylphenyl)carbamoyl]-6-methoxypyridin-3-yl}-5-{[(2S)-1-hydroxy-3,3-dimethylbutan-2-yl]carbamoyl}benzoic acid Deposited 2013-04-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：UNP residues 213-466
Chain L
150–204（55 aa）
Fragment：UNP residues 150-204
|
Not recorded | 1NL 2-{2-[(3-carbamoylphenyl)carbamoyl]-6-methoxypyridin-3-yl}-5-{[(2S)-1-hydroxy-3,3-dimethylbutan-2-yl]carbamoyl}benzoic acid × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 4 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM calcium chloride, 17.5% w/v PEG6000, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 1.84 Å R-free 0.199 |
| 4NA9 Factor VIIa in complex with the inhibitor 3'-amino-5'-[(2s,4r)-6-carbamimidoyl-4-phenyl-1,2,3,4-tetrahydroquinolin-2-yl]biphenyl-2-carboxylic acid Deposited 2013-10-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Chain L
150–204（55 aa）
|
Not recorded | 1T7 3'-amino-5'-[(2S,4R)-6-carbamimidoyl-4-phenyl-1,2,3,4-tetrahydroquinolin-2-yl]biphenyl-2-carboxylic acid × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000, vapor diffusion, hanging drop, temperature 277K
|
Resolution 2.24 Å R-free 0.245 |
| 4NG9 Factor viia in complex with the inhibitor (2R)-2-[(1-aminoisoquinolin-6-yl)amino]-2-[3-ethoxy-4-(propan-2-yloxy)phenyl]-n-(3-sulfamoylbenzyl)ethanamide Deposited 2013-11-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：UNP residues 213-466
Chain L
150–204（55 aa）
Fragment：UKNP residues 150-204
|
Not recorded | 2KE (2R)-2-[(1-aminoisoquinolin-6-yl)amino]-2-[3-ethoxy-4-(propan-2-yloxy)phenyl]-N-(3-sulfamoylbenzyl)ethanamide × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 5 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000, vapor diffusion, hanging drop, temperature 277K
|
Resolution 2.20 Å R-free 0.222 |
| 4NGA Factor viia in complex with the inhibitor (2R)-2-[(1-aminoisoquinolin-6-yl)amino]-2-[3-ethoxy-4-(propan-2-yloxy)phenyl]-N-[2-(propan-2-ylsulfonyl)benzyl]ethanamide Deposited 2013-11-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：UNP residues 213-466
Chain L
150–204（55 aa）
Fragment：UNP residues 150-204
|
Not recorded | 2KF (2R)-2-[(1-aminoisoquinolin-6-yl)amino]-2-[3-ethoxy-4-(propan-2-yloxy)phenyl]-N-[2-(propan-2-ylsulfonyl)benzyl]ethanamide × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 4 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000, vapor diffusion, hanging drop, temperature 277K
|
Resolution 2.15 Å R-free 0.228 |
| 4X8S FACTOR VIIA IN COMPLEX WITH THE INHIBITOR 4-BROMO-2-METHOXYPHENOL Deposited 2014-12-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：unp RESIDUES 213-466
Chain L
150–204（55 aa）
Fragment：unp RESIDUES 150-204
|
Not recorded | 3Z7 4-bromo-2-methoxyphenol × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 4 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000
|
Resolution 2.10 Å R-free 0.199 |
| 4X8T FACTOR VIIA IN COMPLEX WITH THE INHIBITOR 7-chloro-3,4-dihydroisoquinolin-1(2H)-one Deposited 2014-12-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：unp RESIDUES 213-466
Chain L
150–204（55 aa）
Fragment：unp RESIDUES 150-204
|
Not recorded | 3Z8 7-chloro-3,4-dihydroisoquinolin-1(2H)-one × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 3 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000
|
Resolution 2.20 Å R-free 0.221 |
| 4X8U FACTOR VIIA IN COMPLEX WITH THE INHIBITOR 5-CHLORO-1H-INDOLE-2-CARBOXYLIC ACID Deposited 2014-12-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：unp residues 213-466
Chain L
150–204（55 aa）
Fragment：unp residues 150-204
|
Not recorded | 3ZB 5-chloro-1H-indole-2-carboxylic acid × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 4 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000
|
Resolution 2.10 Å R-free 0.201 |
| 4X8V FACTOR VIIA IN COMPLEX WITH THE INHIBITOR (methyl {3-[(2R)-1-{(2R)-2-(3,4-dimethoxyphenyl)-2-[(1-oxo-1,2,3,4-tetrahydroisoquinolin-7-yl)amino]acetyl}pyrrolidin-2-yl]-4-(propan-2-ylsulfonyl)phenyl}carbamate) Deposited 2014-12-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：UNP RESIDUES 213-466
Chain L
150–204（55 aa）
Fragment：UNP RESIDUES 150-204
|
Not recorded | 3Z9 methyl {3-[(2R)-1-{(2R)-2-(3,4-dimethoxyphenyl)-2-[(1-oxo-1,2,3,4-tetrahydroisoquinolin-7-yl)amino]acetyl}pyrrolidin-2-yl]-4-(propan-2-ylsulfonyl)phenyl}carbamate × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 3 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000
|
Resolution 2.50 Å R-free 0.230 |
| 4YLQ Crystal Structure of a FVIIa-Trypsin Chimera (FT) in Complex with Soluble Tissue Factor Deposited 2015-03-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：UNP residues 213-466
Chain L
61–212（152 aa）
Fragment：BLOOD COAGULATION FACTOR VIIA LIGHT CHAIN, UNP residues 61-212
|
Mutation：[169-175] LQQSRKVGDSPN - EASFPGK Non-standard monomer：Yes (specific site not provided by mmCIF) | CA CALCIUM ION × 9 FUC alpha-L-fucopyranose × 1 TMA TETRAMETHYLAMMONIUM ION × 22 0Z7 N-acetyl-D-phenylalanyl-N-[(2S,3S)-6-carbamimidamido-1-chloro-2-hydroxyhexan-3-yl]-L-phenylalaninamide × 1 POL N-PROPANOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；295 K；0.1M NaCitrate, 16.6% PEG 3350, 12.5% 1-Propanol, with seeding
|
Resolution 1.40 Å R-free 0.174 |
| 4YT6 Factor VIIa in complex with the inhibitor 4-{[(R)-[5-ethoxy-2-fluoro-3-(propan-2-yloxy)phenyl](4-phenyl-1H-imidazol-2-yl)methyl]amino}benzenecarboximidamide Deposited 2015-03-17 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：UNP residues 213-466
Chain L
148–204（57 aa）
Fragment：UNP residues 148-204
|
Not recorded | 4JY 4-[[(R)-(5-ethoxy-2-fluoranyl-3-propan-2-yloxy-phenyl)-(4-phenyl-1H-imidazol-2-yl)methyl]amino]benzenecarboximidamide × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 4 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM calcium chloride, 17.5% w/v PEG6000
|
Resolution 2.07 Å R-free 0.202 |
| 4YT7 Factor VIIa in complex with the inhibitor 2-(2-{(R)-[(4-carbamimidoylphenyl)amino][5-ethoxy-2-fluoro-3-(propan-2-yloxy)phenyl]methyl}-1H-imidazol-4-yl)benzamide Deposited 2015-03-17 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：UNP residues 213-466
Chain L
148–204（57 aa）
Fragment：UNP residues 148-204
|
Not recorded | 4K1 2-[2-[(R)-[(4-carbamimidoylphenyl)amino]-(5-ethoxy-2-fluoranyl-3-propan-2-yloxy-phenyl)methyl]-1H-imidazol-4-yl]benzamide × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 4 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM calcium chloride, 17.5% w/v PEG6000
|
Resolution 2.30 Å R-free 0.198 |
| 4Z6A Crystal Structure of a FVIIa-Trypsin Chimera (YT) in Complex with Soluble Tissue Factor Deposited 2015-04-04 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：unp residues 213-465
Chain L
108–203（96 aa）
Fragment：UNP residues 108-203
|
Mutation：[169-175] LQQSRKVGDSPN - EASYPGK | BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 0Z6 D-phenylalanyl-N-[(2S,3S)-6-{[amino(iminio)methyl]amino}-1-chloro-2-hydroxyhexan-3-yl]-L-phenylalaninamide × 1 CA CALCIUM ION × 1 CIT CITRIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；295 K；0.1M NaCitrate, 16.6% PEG 3350, 12.5% 1-Propanol, with seeding
|
Resolution 2.25 Å R-free 0.240 |
| 4ZMA Crystal Structure of a FVIIa-Trypsin Chimera (ST) in Complex with Soluble Tissue Factor Deposited 2015-05-02 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Fragment：UNP residues 213-466
Chain L
61–212（152 aa）
|
Mutation：169-175 LQQSRKVGDSPN -> EASSPGK Non-standard monomer：Yes (specific site not provided by mmCIF) | CA CALCIUM ION × 8 BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 0Z6 D-phenylalanyl-N-[(2S,3S)-6-{[amino(iminio)methyl]amino}-1-chloro-2-hydroxyhexan-3-yl]-L-phenylalaninamide × 1 CAC CACODYLATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.1；295 K；0.1M Cacodylate,11% PEG 8000 , with seeding
|
Resolution 2.30 Å R-free 0.295 |
| 4ZXX FACTOR VIIA IN COMPLEX WITH THE INHIBITOR N-{3-[(2R)-1-{(2R)-2-[(1-aminoisoquinolin-6-yl)amino]-2-phenylacetyl}pyrrolidin-2-yl]-4-(propan-2-ylsulfonyl)phenyl}acetamide Deposited 2015-05-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：UNP residues 213-466
Chain L
150–204（55 aa）
Fragment：UNP residues 150-204
|
Not recorded | 4T0 N-{3-[(2R)-1-{(2R)-2-[(1-aminoisoquinolin-6-yl)amino]-2-phenylacetyl}pyrrolidin-2-yl]-4-(propan-2-ylsulfonyl)phenyl}acetamide × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000
|
Resolution 2.60 Å R-free 0.248 |
| 4ZXY FACTOR VIIA IN COMPLEX WITH THE INHIBITOR (2R)-2-[(1-aminoisoquinolin-6-yl)amino]-4,11-diazatricyclo[14.2.2.1~6,10~]henicosa-1(18),6(21),7,9,16,19-hexaene-3,12-dione Deposited 2015-05-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Fragment：UNP residues 213-466
Chain L
150–204（55 aa）
Fragment：UNP residues 150-204
|
Not recorded | 4T1 (2R)-2-[(1-aminoisoquinolin-6-yl)amino]-4,11-diazatricyclo[14.2.2.1~6,10~]henicosa-1(18),6(21),7,9,16,19-hexaene-3,12-dione × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 3 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000
|
Resolution 2.06 Å R-free 0.211 |
| 5I46 Factor VIIA in complex with the inhibitor (2R,15R)-2-[(1-aminoisoquinolin-6-yl)amino]-8-fluoro-7-hydroxy-4,15,17-trimethyl-13-oxa-4,11-diazatricyclo[14.2.2.1~6,10~]henicosa-1(18),6(21),7,9,16,19-hexaene-3,12-dione Deposited 2016-02-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Chain L
150–204（55 aa）
|
Not recorded | 67O (2R,15R)-2-[(1-aminoisoquinolin-6-yl)amino]-8-fluoro-7-hydroxy-4,15,17-trimethyl-13-oxa-4,11-diazatricyclo[14.2.2.1~6,10~]henicosa-1(18),6(21),7,9,16,19-hexaene-3,12-dione × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 3 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000
|
Resolution 2.06 Å R-free 0.239 |
| 5L0S human POGLUT1 in complex with Factor VII EGF1 and UDP Deposited 2016-07-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
105–145（41 aa）
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 3 UDP URIDINE-5'-DIPHOSPHATE × 1 CL CHLORIDE ION × 1 GOL GLYCEROL × 2 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；20% PEG5000 MME, 50 mM MES pH 6.5, 2mM CaCl2, 250mM NaCl, 5% glycerol
|
Resolution 1.45 Å R-free 0.159 |
| 5L2Y Factor VIIa in complex with the inhibitor 1-[(2R,15R)-2-[(1-amino-4-fluoroisoquinolin-6-yl)amino]-4,15,20-trimethyl-3,12-dioxo-13-oxa-4,11-diazatricyclo[14.2.2.1~6,10~]henicosa-1(18),6,8,10(21),16,19-hexaen-7-yl] cyclobutane-1-carboxylic acid Deposited 2016-08-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Chain L
150–204（55 aa）
|
Not recorded | 70D 1-[(2R,15R)-2-[(1-amino-4-fluoroisoquinolin-6-yl)amino]-4,15,17-trimethyl-3,12-dioxo-13-oxa-4,11-diazatricyclo[14.2.2.1~6,10~]henicosa-1(18),6(21),7,9,16,19-hexaen-7-yl]cyclobutane-1-carboxylic acid × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 4 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000
|
Resolution 1.82 Å R-free 0.189 |
| 5L2Z Factor VIIa in complex with the inhibitor 1-[(2R,15R)-2-[(1-amino-4-fluoroisoquinolin-6-yl)amino]-4,15,17-trimethyl-3,12-dioxo-13-oxa-4,11-diazatricyclo[14.2.2.1~6,10~]henicosa-1(18),6(21),7,9,16,19-hexaen-7-yl]cyclohexane-1-carboxylic acid Deposited 2016-08-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Chain L
147–204（58 aa）
|
Not recorded | 70C 1-[(2R,15R)-2-[(1-amino-4-fluoroisoquinolin-6-yl)amino]-4,15,17-trimethyl-3,12-dioxo-13-oxa-4,11-diazatricyclo[14.2.2.1~6,10~]henicosa-1(18),6(21),7,9,16,19-hexaen-7-yl]cyclohexane-1-carboxylic acid × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 3 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000
|
Resolution 1.79 Å R-free 0.203 |
| 5L30 Factor VIIa in complex with the inhibitor (2R,15R)-2-[(1-aminoisoquinolin-6-yl)amino]-4,15,17-trimethyl-7-[1-(1H-tetrazol-5-yl)cyclopropyl]-13-oxa-4,11-diazatricyclo[14.2.2.1~6,10~]henicosa-1(18),6(21),7,9,16,19-hexaene-3,12-dione Deposited 2016-08-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Chain L
147–204（58 aa）
|
Not recorded | 70A (2R,15R)-2-[(1-aminoisoquinolin-6-yl)amino]-4,15,17-trimethyl-7-[1-(1H-tetrazol-5-yl)cyclopropyl]-13-oxa-4,11-diazatricyclo[14.2.2.1~6,10~]henicosa-1(18),6(21),7,9,16,19-hexaene-3,12-dione × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 4 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000
|
Resolution 1.73 Å R-free 0.194 |
| 5PA8 Crystal Structure of Factor VIIa in complex with cyclohexanamine Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain C
213–466（254 aa）
|
Not recorded | GOL GLYCEROL × 2 CA CALCIUM ION × 1 CL CHLORIDE ION × 2 SO4 SULFATE ION × 3 HAI CYCLOHEXYLAMMONIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.98 Å R-free 0.204 |
| 5PA9 Crystal Structure of Factor VIIa in complex with phenylmethanamine;hydrochloride Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain C
213–466（254 aa）
|
Not recorded | GOL GLYCEROL × 2 CA CALCIUM ION × 1 CL CHLORIDE ION × 2 SO4 SULFATE ION × 2 ABN BENZYLAMINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.55 Å R-free 0.196 |
| 5PAA Crystal Structure of Factor VIIa in complex with cyclohexylmethanamine Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain C
213–466（254 aa）
|
Not recorded | GOL GLYCEROL × 2 CA CALCIUM ION × 1 CL CHLORIDE ION × 4 AMC AMINOMETHYLCYCLOHEXANE × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.98 Å R-free 0.214 |
| 5PAB Crystal Structure of Factor VIIa in complex with 1-[[3-[2-hydroxy-3-(1H-pyrrolo[3,2-c]pyridin-2-yl)phenyl]phenyl]methyl]-3-phenylurea Deposited 2016-11-10 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Chain L
149–212（64 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | 7XD 1-[[3-[2-oxidanyl-3-(1~{H}-pyrrolo[3,2-c]pyridin-2-yl)phenyl]phenyl]methyl]-3-phenyl-urea × 1 CL CHLORIDE ION × 3 GOL GLYCEROL × 4 CA CALCIUM ION × 1 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.99 Å R-free 0.220 |
| 5PAC human factor VIIa in complex with 5-hydroxy-N-(4-oxo-3H-quinazolin-6-yl)-1-[3-[(phenylcarbamoylamino)methyl]phenyl]pyrazole-4-carboxamide at 1.50A Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain B
213–466（254 aa）
|
Not recorded | GOL GLYCEROL × 2 7Y7 5-hydroxy-N-(4-oxo-3H-quinazolin-6-yl)-1-[3-[(phenylcarbamoylamino)methyl]phenyl]pyrazole-4-carboxamide × 1 CA CALCIUM ION × 1 CL CHLORIDE ION × 1 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.50 Å R-free 0.211 |
| 5PAE Crystal Structure of Factor VIIa in complex with (2S)-2-hydroxy-N-[[3-[5-hydroxy-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)pyrazol-1-yl]phenyl]methyl]propanamide Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain B
213–466（254 aa）
|
Not recorded | SO4 SULFATE ION × 5 GOL GLYCEROL × 2 7YA (2S)-2-hydroxy-N-[[3-[5-hydroxy-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)pyrazol-1-yl]phenyl]methyl]propanamide × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.45 Å R-free 0.188 |
| 5PAF Crystal Structure of Factor VIIa in complex with N-(2-amino-1H-benzimidazol-5-yl)-2-[3-[(2-amino-2-oxoethyl)-methylsulfonylamino]-5-chlorophenyl]acetamide;2,2,2-trifluoroacetic acid Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain B
213–466（254 aa）
|
Not recorded | GOL GLYCEROL × 4 CA CALCIUM ION × 1 CL CHLORIDE ION × 1 SO4 SULFATE ION × 3 7LR N-(2-amino-1H-benzimidazol-5-yl)-2-[3-[(2-amino-2-oxoethyl)-methylsulfonylamino]-5-chlorophenyl]acetamide × 1 TFA trifluoroacetic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.50 Å R-free 0.185 |
| 5PAG Crystal Structure of Factor VIIa in complex with (2R)-2-hydroxy-N-[[3-[5-hydroxy-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)pyrazol-1-yl]phenyl]methyl]-3-methylbutanamide;hydrobromide Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Fragment：FACTOR VII HEAVY CHAIN, RESIDUES 149-466
Chain B
213–466（254 aa）
Fragment：FACTOR VII HEAVY CHAIN, RESIDUES 149-466
|
Not recorded | GOL GLYCEROL × 2 7YJ (2R)-2-hydroxy-N-[[3-[5-hydroxy-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)pyrazol-1-yl]phenyl]methyl]-3-methylbutanamide × 1 CA CALCIUM ION × 1 CL CHLORIDE ION × 2 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.36 Å R-free 0.194 |
| 5PAI human factor VIIa in complex with N-(2-amino-1H-benzimidazol-5-yl)-1-[3-[[(3,5-dimethyl-1,2-oxazol-4-yl)carbamoylamino]methyl]phenyl]-5-hydroxypyrazole-4-carboxamide at 1.73A Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain B
213–466（254 aa）
|
Not recorded | GOL GLYCEROL × 1 CA CALCIUM ION × 1 CL CHLORIDE ION × 1 SO4 SULFATE ION × 2 7YM N-(2-amino-1H-benzimidazol-5-yl)-1-[3-[[(3,5-dimethyl-1,2-oxazol-4-yl)carbamoylamino]methyl]phenyl]-5-hydroxypyrazole-4-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.73 Å R-free 0.181 |
| 5PAJ Crystal Structure of Factor VIIa in complex with 1-(1-aminoisoquinolin-6-yl)-3-benzylurea Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain B
213–466（254 aa）
|
Not recorded | CL CHLORIDE ION × 2 7XJ 1-(1-azanylisoquinolin-6-yl)-3-(phenylmethyl)urea × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.70 Å R-free 0.224 |
| 5PAK Crystal Structure of Factor VIIa in complex with N-[[4-(aminomethyl)-2-(2-amino-2-oxoethoxy)phenyl]methyl]-2-(4-hydroxyphenyl)-2-methoxyacetamide;hydrochloride Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain C
213–466（254 aa）
|
Not recorded | CA CALCIUM ION × 1 SO4 SULFATE ION × 2 7YP (2~{S})-~{N}-[[4-(aminomethyl)-2-(2-azanyl-2-oxidanylidene-ethoxy)phenyl]methyl]-2-(4-hydroxyphenyl)-2-methoxy-ethanami de × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.56 Å R-free 0.203 |
| 5PAM Crystal Structure of Factor VIIa in complex with 2-[(1-aminoisoquinolin-6-yl)amino]-2-(5-ethoxy-2-fluorophenyl)-1-(2-phenylpyrrolidin-1-yl)ethanone Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain B
213–466（254 aa）
|
Not recorded | CL CHLORIDE ION × 3 GOL GLYCEROL × 2 CA CALCIUM ION × 1 SO4 SULFATE ION × 1 7Z1 (2~{R})-2-[(1-azanylisoquinolin-6-yl)amino]-2-(5-ethoxy-2-fluoranyl-phenyl)-1-[(2~{R})-2-phenylpyrrolidin-1-yl]ethanone × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.60 Å R-free 0.190 |
| 5PAN Crystal Structure of Factor VIIa in complex with 5-hydroxy-N-(3-oxo-1,2-dihydroisoindol-5-yl)-1-[3-[(phenylcarbamoylamino)methyl]phenyl]pyrazole-4-carboxamide Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain B
213–466（254 aa）
|
Not recorded | SO4 SULFATE ION × 3 GOL GLYCEROL × 2 CA CALCIUM ION × 1 CL CHLORIDE ION × 1 7Z4 5-hydroxy-N-(1-oxo-1H-isoindol-6-yl)-1-(3-{[(phenylcarbamoyl)amino]methyl}phenyl)-1H-pyrazole-4-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.62 Å R-free 0.179 |
| 5PAO Crystal Structure of Factor VIIa in complex with (2S)-2,3-dihydroxy-N-[[3-[5-hydroxy-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)pyrazol-1-yl]phenyl]methyl]propanamide;hydrobromide Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain C
213–466（254 aa）
|
Not recorded | SO4 SULFATE ION × 5 GOL GLYCEROL × 2 CA CALCIUM ION × 1 7Z7 (2S)-2,3-dihydroxy-N-[[3-[5-hydroxy-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)pyrazol-1-yl]phenyl]methyl]propanamide × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.40 Å R-free 0.188 |
| 5PAQ Crystal Structure of Factor VIIa in complex with 2-[(1-aminoisoquinolin-6-yl)amino]-2-(3-ethoxy-4-propan-2-yloxyphenyl)-1-(2-phenylpyrrolidin-1-yl)ethanone Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain B
213–466（254 aa）
|
Not recorded | CL CHLORIDE ION × 3 GOL GLYCEROL × 2 CA CALCIUM ION × 1 SO4 SULFATE ION × 1 7ZA 2-[(1-aminoisoquinolin-6-yl)amino]-2-(3-ethoxy-4-propan-2-yloxyphenyl)-1-(2-phenylpyrrolidin-1-yl)ethanone × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.59 Å R-free 0.194 |
| 5PAR Crystal Structure of Factor VIIa in complex with 1H-benzimidazol-2-amine Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain C
213–466（254 aa）
|
Not recorded | AX7 1H-benzimidazol-2-amine × 4 GOL GLYCEROL × 2 CA CALCIUM ION × 1 CL CHLORIDE ION × 2 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 2.10 Å R-free 0.220 |
| 5PAS Crystal Structure of Factor VIIa in complex with (2S)-2-hydroxy-N-[[3-[5-hydroxy-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)pyrazol-1-yl]phenyl]methyl]-3-phenylpropanamide Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain C
213–466（254 aa）
|
Not recorded | GOL GLYCEROL × 2 7ZD (2S)-2-hydroxy-N-[[3-[5-hydroxy-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)pyrazol-1-yl]phenyl]methyl]-3-phenylpropanamide × 1 CA CALCIUM ION × 1 CL CHLORIDE ION × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.48 Å R-free 0.206 |
| 5PAT Crystal Structure of Factor VIIa in complex with N-(2-amino-1H-benzimidazol-5-yl)-2-(3-chlorophenyl)acetamide Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain B
213–466（254 aa）
|
Not recorded | 7ZG N-(2-amino-1H-benzimidazol-5-yl)-2-(3-chlorophenyl)acetamide × 1 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.60 Å R-free 0.217 |
| 5PAU Crystal Structure of Factor VIIa in complex with N-(2-amino-1H-benzimidazol-5-yl)-2-[3-[(2-amino-2-oxoethyl)-methylsulfonylamino]phenyl]acetamide;2,2,2-trifluoroacetic acid Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain C
213–466（254 aa）
|
Not recorded | GOL GLYCEROL × 3 CA CALCIUM ION × 1 CL CHLORIDE ION × 2 SO4 SULFATE ION × 2 7ZJ N-(2-amino-1H-benzimidazol-5-yl)-2-[3-[(2-amino-2-oxoethyl)-methylsulfonylamino]phenyl]acetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.55 Å R-free 0.204 |
| 5PAV Crystal Structure of Factor VIIa in complex with N-(6-aminopyridin-3-yl)-5-hydroxy-1-phenylpyrazole-4-carboxamide Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain C
213–466（254 aa）
|
Not recorded | SO4 SULFATE ION × 2 GOL GLYCEROL × 5 CA CALCIUM ION × 1 CL CHLORIDE ION × 3 7ZM N-(6-aminopyridin-3-yl)-5-hydroxy-1-phenylpyrazole-4-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.40 Å R-free 0.197 |
| 5PAW Crystal Structure of Factor VIIa in complex with isoquinoline-1,6-diamine Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain B
213–466（254 aa）
|
Not recorded | CL CHLORIDE ION × 3 CA CALCIUM ION × 1 SO4 SULFATE ION × 2 7XM isoquinoline-1,6-diamine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 2.20 Å R-free 0.220 |
| 5PAX Crystal Structure of Factor VIIa in complex with 1-(2,6-difluorophenyl)-3-[[3-[5-hydroxy-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)pyrazol-1-yl]phenyl]methyl]urea Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain C
213–466（254 aa）
|
Not recorded | GOL GLYCEROL × 2 CA CALCIUM ION × 1 CL CHLORIDE ION × 1 SO4 SULFATE ION × 2 7ZP 1-(2,6-difluorophenyl)-3-[[3-[5-hydroxy-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)pyrazol-1-yl]phenyl]methyl]urea × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.36 Å R-free 0.192 |
| 5PAY Crystal Structure of Factor VIIa in complex with 1-[[3-[5-hydroxy-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)pyrazol-1-yl]phenyl]methyl]-3-phenylurea Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain C
213–466（254 aa）
|
Not recorded | SO4 SULFATE ION × 2 GOL GLYCEROL × 3 CA CALCIUM ION × 1 CL CHLORIDE ION × 2 7ZY 1-[[3-[5-hydroxy-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)pyrazol-1-yl]phenyl]methyl]-3-phenylurea × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.66 Å R-free 0.194 |
| 5PB0 Crystal Structure of Factor VIIa in complex with 2-(4-ethoxy-3-methoxyphenyl)-2-(isoquinolin-6-ylamino)acetic acid Deposited 2016-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Fragment：FACTOR VII RESIDUES 148-466
Chain B
213–466（254 aa）
Fragment：FACTOR VII RESIDUES 148-466
|
Not recorded | CL CHLORIDE ION × 3 SO4 SULFATE ION × 5 GOL GLYCEROL × 1 7LX (2~{R})-2-(4-ethoxy-3-methoxy-phenyl)-2-(isoquinolin-6-ylamino)ethanoic acid × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.98 Å R-free 0.193 |
| 5PB1 Crystal Structure of Factor VIIa in complex with benzenecarboximidamide Deposited 2016-11-10 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain D
213–466（254 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 6 GOL GLYCEROL × 4 CA CALCIUM ION × 1 BEN BENZAMIDINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.90 Å R-free 0.210 |
| 5PB2 Crystal Structure of Factor VIIa in complex with 2-phenyl-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)pyrazol-3-ol Deposited 2016-11-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain C
213–466（254 aa）
|
Not recorded | GOL GLYCEROL × 2 CA CALCIUM ION × 1 CL CHLORIDE ION × 2 SO4 SULFATE ION × 1 9RP 1-phenyl-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)-1H-pyrazol-5-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.45 Å R-free 0.204 |
| 5PB3 Crystal Structure of Factor VIIa in complex with 1-[[3-[4-(5-amino-1H-pyrrolo[3,2-b]pyridin-2-yl)-5-hydroxypyrazol-1-yl]phenyl]methyl]-3-phenylurea Deposited 2016-11-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain C
213–466（254 aa）
|
Not recorded | SO4 SULFATE ION × 2 GOL GLYCEROL × 3 9S1 N-({3-[4-(5-amino-1H-pyrrolo[3,2-b]pyridin-2-yl)-5-hydroxy-1H-pyrazol-1-yl]phenyl}methyl)-N'-phenylurea × 1 CA CALCIUM ION × 1 CL CHLORIDE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.90 Å R-free 0.211 |
| 5PB4 human factor VIIa in complex with 1-[[3-[5-hydroxy-3-methyl-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)pyrazol-1-yl]phenyl]methyl]-3-phenylurea at 2.43A Deposited 2016-11-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain C
213–466（254 aa）
|
Not recorded | GOL GLYCEROL × 2 9RS N-({3-[5-hydroxy-3-methyl-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)-1H-pyrazol-1-yl]phenyl}methyl)-N'-phenylurea × 1 CA CALCIUM ION × 1 CL CHLORIDE ION × 2 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 2.43 Å R-free 0.230 |
| 5PB5 human factor VIIa in complex with 1-[[3-[5-hydroxy-4-(7H-pyrrolo[2,3-d]pyrimidin-6-yl)pyrazol-1-yl]phenyl]methyl]-3-phenylurea at 1.84A Deposited 2016-11-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain B
213–466（254 aa）
|
Not recorded | GOL GLYCEROL × 1 9RY N-({3-[5-hydroxy-4-(7H-pyrrolo[2,3-d]pyrimidin-6-yl)-1H-pyrazol-1-yl]phenyl}methyl)-N'-phenylurea × 1 CA CALCIUM ION × 1 CL CHLORIDE ION × 1 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.84 Å R-free 0.200 |
| 5PB6 Crystal Structure of Factor VIIa in complex with N-[[3-[5-hydroxy-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)pyrazol-1-yl]phenyl]methyl]pentanamide Deposited 2016-11-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
149–212（64 aa）
Chain C
213–466（254 aa）
|
Not recorded | SO4 SULFATE ION × 2 GOL GLYCEROL × 3 CA CALCIUM ION × 1 CL CHLORIDE ION × 3 9RV N-({3-[5-hydroxy-4-(1H-pyrrolo[3,2-c]pyridin-2-yl)-1H-pyrazol-1-yl]phenyl}methyl)pentanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；16 mg/ml protein in 20mM Tris/HCl pH 8.4, 5 mM benzamidine, 0.1 M NaCl, 50 mM CaCl2 mixed 1+1 with 32-35% AMMONIUM SULPHATE, 2% PEG 4000, 0.1 M Bicine-NaOH pH 8.5, 15% glycerol
|
Resolution 1.90 Å R-free 0.210 |
| 5TQE Factor VIIa in complex with the inhibitor (5R)-5-[(1-aminoisoquinolin-6-yl)amino]-19-(cyclopropylsulfonyl)-3-methyl-13-oxa-3,15-diazatricyclo[14.3.1.1~6,10~]henicosa-1(20),6(21),7,9,16,18-hexaene-4,14-dione Deposited 2016-10-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Chain L
150–204（55 aa）
|
Not recorded | 7KQ (5R)-5-[(1-aminoisoquinolin-6-yl)amino]-19-(cyclopropylsulfonyl)-3-methyl-13-oxa-3,15-diazatricyclo[14.3.1.1~6,10~]henicosa-1(20),6(21),7,9,16,18-hexaene-4,14-dione × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 4 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000
|
Resolution 1.90 Å R-free 0.209 |
| 5TQF Factor VIIa in complex with the inhibitor (11R)-11-[(1-aminoisoquinolin-6-yl)amino]-16-(cyclopropylsulfonyl)-13-methyl-2,13-diazatricyclo[13.3.1.1~6,10~]icosa-1(19),6(20),7,9,15,17-hexaene-3,12-dione Deposited 2016-10-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Chain L
150–204（55 aa）
|
Not recorded | 7KR (11R)-11-[(1-aminoisoquinolin-6-yl)amino]-16-(cyclopropylsulfonyl)-13-methyl-2,13-diazatricyclo[13.3.1.1~6,10~]icosa-1(19),6(20),7,9,15,17-hexaene-3,12-dione × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 4 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000
|
Resolution 1.85 Å R-free 0.208 |
| 5TQG Factor VIIa in complex with the inhibitor (5R,11R)-11-[(1-amino-4-fluoroisoquinolin-6-yl)amino]-16-(cyclopropylsulfonyl)-7-(2,2-difluoroethoxy)-5,13-dimethyl-2,13-diazatricyclo[13.3.1.1~6,10~]icosa-1(19),6(20),7,9,15,17-hexaene-3,12-dione Deposited 2016-10-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Chain L
150–204（55 aa）
|
Not recorded | 7KS (5R,11R)-11-[(1-amino-4-fluoroisoquinolin-6-yl)amino]-16-(cyclopropylsulfonyl)-7-(2,2-difluoroethoxy)-5,13-dimethyl-2,13-diazatricyclo[13.3.1.1~6,10~]icosa-1(19),6(20),7,9,15,17-hexaene-3,12-dione × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 4 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000
|
Resolution 1.90 Å R-free 0.204 |
| 5U6J Factor VIIa in complex with the inhibitor 3-{[(2R)-17-ethyl-4-methyl-3,12-dioxo-7-[(propan-2-yl)sulfonyl]-13-oxa-4,11-diazatricyclo[14.2.2.1~6,10~]henicosa-1(18),6(21),7,9,16,19-hexaen-2-yl]amino}benzamide Deposited 2016-12-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain H
213–466（254 aa）
Chain L
150–204（55 aa）
|
Not recorded | 82J 3-{[(2R)-17-ethyl-4-methyl-3,12-dioxo-7-[(propan-2-yl)sulfonyl]-13-oxa-4,11-diazatricyclo[14.2.2.1~6,10~]henicosa-1(18),6(21),7,9,16,19-hexaen-2-yl]amino}benzamide × 1 CA CALCIUM ION × 1 SO4 SULFATE ION × 4 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；100 mM MES, pH 6.0, 20 mM CACL2, 17.5%(W/V) PEG 6000
|
Resolution 2.30 Å R-free 0.220 |
| 6R2W Crystal structure of the super-active FVIIa variant VYT in complex with tissue factor Deposited 2019-03-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
213–466（254 aa）
Chain L
61–203（143 aa）
|
Mutation：L350V,371-375del,K376E,V377A,G378S,D379Y,S380P,P381G,N382K Non-standard monomer：Yes (specific site not provided by mmCIF) | CA CALCIUM ION × 9 FUC alpha-L-fucopyranose × 1 TMA TETRAMETHYLAMMONIUM ION × 10 0Z7 N-acetyl-D-phenylalanyl-N-[(2S,3S)-6-carbamimidamido-1-chloro-2-hydroxyhexan-3-yl]-L-phenylalaninamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；295 K；0.1 M sodium citrate, pH 5.6, 15.6 % (w/v) PEG 3350, 12 % (v/v) 1-Propanol
|
Resolution 1.25 Å R-free 0.194 |
| 8CN9 Factor VII binding Fab of the bispecific antibody HMB-001 in complex with Factor VII Deposited 2023-02-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain C
213–466（254 aa）
Chain D
106–212（107 aa）
|
Not recorded | CA CALCIUM ION × 2 BGC beta-D-glucopyranose × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.3；293 K；0.15 M Cesium chloride
15% w/v Polyethylene glycol 3,350
|
Resolution 3.40 Å R-free 0.356 |
| 8CN9 Factor VII binding Fab of the bispecific antibody HMB-001 in complex with Factor VII Deposited 2023-02-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain H
213–466（254 aa）
Chain I
106–212（107 aa）
|
Not recorded | CA CALCIUM ION × 3 BGC beta-D-glucopyranose × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.3；293 K；0.15 M Cesium chloride
15% w/v Polyethylene glycol 3,350
|
Resolution 3.40 Å R-free 0.356 |
| 8CN9 Factor VII binding Fab of the bispecific antibody HMB-001 in complex with Factor VII Deposited 2023-02-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain M
213–466（254 aa）
Chain N
106–212（107 aa）
|
Not recorded | CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.3；293 K；0.15 M Cesium chloride
15% w/v Polyethylene glycol 3,350
|
Resolution 3.40 Å R-free 0.356 |
| 8CN9 Factor VII binding Fab of the bispecific antibody HMB-001 in complex with Factor VII Deposited 2023-02-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain R
213–466（254 aa）
Chain S
106–212（107 aa）
|
Not recorded | CA CALCIUM ION × 2 BGC beta-D-glucopyranose × 1 CS CESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.3；293 K；0.15 M Cesium chloride
15% w/v Polyethylene glycol 3,350
|
Resolution 3.40 Å R-free 0.356 |
| 8QOD CRYSTAL STRUCTURE OF FVIIA IN COMPLEX WITH A BENZAMIDINE-BASED INHIBITOR Deposited 2023-09-28 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
63–203（141 aa）
Chain B
213–466（254 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CA CALCIUM ION × 4 MG MAGNESIUM ION × 1 GLC alpha-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 WIZ 3-[2-bromanyl-4-[(1~{S})-1-[[3-[(4-carbamimidoylphenyl)amino]-3-oxidanylidene-propanoyl]amino]ethyl]phenoxy]benzoic acid × 1 CL CHLORIDE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；The VIIa/sTF complex was crystallized using the sitting drop or the hanging drop vapor diffusion method. Specifically, the protein drop contained 4 mg/ml VIIa/sTF complex, 20 mm Tris-HCl, pH 7.5, 200 mm NaCl, 10 mm CaCl2, and 10 mm pAB or 10 mm benzamidine, whereas the reservoir solution contained 16-22% PEG 4000, 100 mm MgCl2, and 20 mm BisTris, pH 6.5. Drops were prepared by mixing 2 ul of protein solution with 2 ul of reservoir solution at 20 C. Crystals appeared within 7 days and were allowed to grow up to 14-20 days before being flash-frozen without additional cryoprotectant.
|
Resolution 1.57 Å R-free 0.214 |
| 8QQ6 CRYSTAL STRUCTURE OF FVIIA IN COMPLEX WITH A BENZAMIDINE-BASED INHIBITOR Deposited 2023-10-03 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
63–203（141 aa）
Chain B
213–466（254 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CA CALCIUM ION × 2 MG MAGNESIUM ION × 1 GLC alpha-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 CL CHLORIDE ION × 2 WSV 2-azanyl-~{N}-[[2-[2-[[3-methoxy-4-(1,3-oxazol-5-yl)phenyl]amino]-1,3-oxazol-5-yl]phenyl]methyl]-~{N}-methyl-ethanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；The VIIa/sTF complex was crystallized using the sitting drop or the hanging drop vapor diffusion method. Specifically, the protein drop contained 4 mg/ml VIIa/sTF complex, 20 mm Tris-HCl, pH 7.5, 200 mm NaCl, 10 mm CaCl2, and 10 mm pAB or 10 mm benzamidine, whereas the reservoir solution contained 16-22% PEG 4000, 100 mm MgCl2, and 20 mm BisTris, pH 6.5. Drops were prepared by mixing 2 ul of protein solution with 2 ul of reservoir solution at 20 C. Crystals appeared within 7 days and were allowed to grow up to 14-20 days before being flash-frozen without additional cryoprotectant.
|
Resolution 1.87 Å R-free 0.259 |
| 8UUD BCX2627 complexed with human FVIIa and soluble Tissue Factor. Deposited 2023-11-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain H
213–466（254 aa）
Chain L
61–202（142 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 CA CALCIUM ION × 9 XGX (1P)-2'-[(4-carbamimidoylphenyl)carbamoyl]-4'-ethenyl-4-[(2-methylpropyl)carbamoyl][1,1'-biphenyl]-2-carboxylic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；14% (w/v)PEG 4K, 0.1M MgCl2, 0.1M ADA buffer, pH 6.5, VAPOR DIFFUSION,
|
Resolution 2.40 Å R-free 0.265 |
| 9P0X Nanodisc-embedded human TF/FVIIa/XK1 in complex with 10H10 Fab (nanodisc-subtracted) Deposited 2025-06-07 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 7 PDB declaration: heptameric |
Chain S
213–466（254 aa）
Chain V
61–202（142 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | MG MAGNESIUM ION × 4 CA CALCIUM ION × 12 BGC beta-D-glucopyranose × 1 FUC alpha-L-fucopyranose × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.70 Å |
| 9TJX Structure of factor VII Gla domain bound to EPCR Deposited 2025-12-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 2 PDB declaration: dimeric |
Chain E
61–92（32 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 2 PTY PHOSPHATIDYLETHANOLAMINE × 1 CA CALCIUM ION × 5 MG MAGNESIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；295 K；0.2 M Ammonium sulfate, 0.1 M Tris PH 8.5, 12 % w/v PEG 8000
|
Resolution 3.00 Å R-free 0.295 |
| 9TJX Structure of factor VII Gla domain bound to EPCR Deposited 2025-12-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Heteromer；Protein × 2 PDB declaration: dimeric |
Chain L
61–92（32 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 2 PTY PHOSPHATIDYLETHANOLAMINE × 1 CA CALCIUM ION × 5 MG MAGNESIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；295 K；0.2 M Ammonium sulfate, 0.1 M Tris PH 8.5, 12 % w/v PEG 8000
|
Resolution 3.00 Å R-free 0.295 |
| 9TJX Structure of factor VII Gla domain bound to EPCR Deposited 2025-12-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain R
61–92（32 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | PTY PHOSPHATIDYLETHANOLAMINE × 1 NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 5 MG MAGNESIUM ION × 2 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；295 K；0.2 M Ammonium sulfate, 0.1 M Tris PH 8.5, 12 % w/v PEG 8000
|
Resolution 3.00 Å R-free 0.295 |
| 9TJX Structure of factor VII Gla domain bound to EPCR Deposited 2025-12-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Other combination Heteromer；Protein × 2 PDB declaration: dimeric |
Chain F
61–92（32 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 1 PTY PHOSPHATIDYLETHANOLAMINE × 1 CA CALCIUM ION × 5 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；295 K；0.2 M Ammonium sulfate, 0.1 M Tris PH 8.5, 12 % w/v PEG 8000
|
Resolution 3.00 Å R-free 0.295 |
113 other PDB entries and 123 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | FA7_HUMAN |
| Isoform | — |
| PDB entities | 1, 2 |
| Chains and sequence ranges | Author chain L； PDBConstruct 1–152； UniProt 61–212 Author chain H； PDBConstruct 1–254； UniProt 213–466 |
