2a68

Crystal structure of the T. thermophilus RNA polymerase holoenzyme in complex with antibiotic rifabutin

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

DNA-directed RNA polymerase alpha chain

OrganismNot specified

UniProt Q9Z9H6

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 6 DNA-directed RNA polymerase beta chain × 1 （Q8RQE9） ;DNA-directed RNA polymerase beta' chain ; × 1 （Q8RQE8） RNA polymerase omega chain × 1 RNA polymerase sigma factor rpoD × 1 MAGNESIUM ION × 313 RIFABUTIN × 1 ZINC ION × 2 water × 6 Consistent with protein count
2 Protein heterocomplex Heteromer Protein 6 DNA-directed RNA polymerase beta chain × 1 （Q8RQE9） ;DNA-directed RNA polymerase beta' chain ; × 1 （Q8RQE8） RNA polymerase omega chain × 1 RNA polymerase sigma factor rpoD × 1 MAGNESIUM ION × 249 RIFABUTIN × 1 ZINC ION × 2 water × 6 Consistent with protein count

Other States of the Same Protein in the Database

Monomer
1doq

1 assemblies

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
1iw7 1iw7 1smy 1smy 2a68 2a68 2a69 2a69 2be5 2be5 2ppb 2ppb

38 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name RPOA_THETH
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 1–315； UniProt 1–315 Author chain B； PDBConstruct 1–315； UniProt 1–315 Author chain K； PDBConstruct 1–315； UniProt 1–315 Author chain L； PDBConstruct 1–315； UniProt 1–315

DNA-directed RNA polymerase beta chain

OrganismNot specified

UniProt Q8RQE9

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 6 DNA-directed RNA polymerase alpha chain × 2 （Q9Z9H6） ;DNA-directed RNA polymerase beta' chain ; × 1 （Q8RQE8） RNA polymerase omega chain × 1 RNA polymerase sigma factor rpoD × 1 MAGNESIUM ION × 313 RIFABUTIN × 1 ZINC ION × 2 water × 6 Consistent with protein count
2 Protein heterocomplex Heteromer Protein 6 DNA-directed RNA polymerase alpha chain × 2 （Q9Z9H6） ;DNA-directed RNA polymerase beta' chain ; × 1 （Q8RQE8） RNA polymerase omega chain × 1 RNA polymerase sigma factor rpoD × 1 MAGNESIUM ION × 249 RIFABUTIN × 1 ZINC ION × 2 water × 6 Consistent with protein count

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
1smy 1smy 1zyr 1zyr 2a68 2a68 2a69 2a69 2a6e 2a6e 2a6h 2a6h

147 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name RPOB_THET8
Isoform —
PDB entities 2
Chains and sequence ranges Author chain C； PDBConstruct 1–1119； UniProt 1–1119 Author chain M； PDBConstruct 1–1119； UniProt 1–1119

;DNA-directed RNA polymerase beta' chain ;

OrganismNot specified

UniProt Q8RQE8

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 6 DNA-directed RNA polymerase alpha chain × 2 （Q9Z9H6） DNA-directed RNA polymerase beta chain × 1 （Q8RQE9） RNA polymerase omega chain × 1 RNA polymerase sigma factor rpoD × 1 MAGNESIUM ION × 313 RIFABUTIN × 1 ZINC ION × 2 water × 6 Consistent with protein count
2 Protein heterocomplex Heteromer Protein 6 DNA-directed RNA polymerase alpha chain × 2 （Q9Z9H6） DNA-directed RNA polymerase beta chain × 1 （Q8RQE9） RNA polymerase omega chain × 1 RNA polymerase sigma factor rpoD × 1 MAGNESIUM ION × 249 RIFABUTIN × 1 ZINC ION × 2 water × 6 Consistent with protein count

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
1smy 1smy 1zyr 1zyr 2a68 2a68 2a69 2a69 2a6e 2a6e 2a6h 2a6h

133 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name RPOC_THET8
Isoform —
PDB entities 3
Chains and sequence ranges Author chain D； PDBConstruct 1–1524； UniProt 1–1524 Author chain N； PDBConstruct 1–1524； UniProt 1–1524

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id2a68
Deposition date deposition_date2005-07-01
Structure title titleCrystal structure of the T. thermophilus RNA polymerase holoenzyme in complex with antibiotic rifabutin
Keywords keywords;RNA POLYMERASE HOLOENZYME, RIFABUTIN, ANTIBIOTIC, TRANSCRIPTION REGULATION, RIKEN Structural Genomics/Proteomics Initiative, RSGI, Structural Genomics, TRANSFERASE ;; TRANSFERASE
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

2a68__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

2a68__assembly_1__model_1 | I(q)

10-2 10-1 106 107 108 109 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

2a68__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）50.55 Å
Rg (electron density)50.18 Å
Total Rg50.44 Å
Atom count27154
Residues3409
Excluded volume486120 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 2a68__assembly_1__model_1 hexameric （6） Success 4.1.3-1-20251215 (887e7ef) View Download
2 1 2a68__assembly_2__model_1 hexameric （6） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (9)

▼

6. Fold Classification (SCOP + CATH) 60 domains

SCOP 2.08 (20 domains)

Domain ID domain_idd2a68a1
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.74 — DCoH-like
Superfamily Superfamily superfamilyd.74.3 — RBP11-like subunits of RNA polymerase
Family Family familyd.74.3.1 — RNA polymerase alpha subunit dimerisation domain
Domain ID domain_idd2a68a2
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.181 — Insert subdomain of RNA polymerase alpha subunit
Superfamily Superfamily superfamilyd.181.1 — Insert subdomain of RNA polymerase alpha subunit
Family Family familyd.181.1.1 — Insert subdomain of RNA polymerase alpha subunit
Domain ID domain_idd2a68b1
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.74 — DCoH-like
Superfamily Superfamily superfamilyd.74.3 — RBP11-like subunits of RNA polymerase
Family Family familyd.74.3.1 — RNA polymerase alpha subunit dimerisation domain
Domain ID domain_idd2a68b2
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.181 — Insert subdomain of RNA polymerase alpha subunit
Superfamily Superfamily superfamilyd.181.1 — Insert subdomain of RNA polymerase alpha subunit
Family Family familyd.181.1.1 — Insert subdomain of RNA polymerase alpha subunit
Domain ID domain_idd2a68c_
Class classe — Multi-domain proteins (alpha and beta)
Fold Fold folde.29 — beta and beta-prime subunits of DNA dependent RNA-polymerase
Superfamily Superfamily superfamilye.29.1 — beta and beta-prime subunits of DNA dependent RNA-polymerase
Family Family familye.29.1.1 — RNA-polymerase beta
Domain ID domain_idd2a68d_
Class classe — Multi-domain proteins (alpha and beta)
Fold Fold folde.29 — beta and beta-prime subunits of DNA dependent RNA-polymerase
Superfamily Superfamily superfamilye.29.1 — beta and beta-prime subunits of DNA dependent RNA-polymerase
Family Family familye.29.1.2 — RNA-polymerase beta-prime
Domain ID domain_idd2a68e_
Class classa — All alpha proteins
Fold Fold folda.143 — RPB6/omega subunit-like
Superfamily Superfamily superfamilya.143.1 — RPB6/omega subunit-like
Family Family familya.143.1.1 — RNA polymerase omega subunit
Domain ID domain_idd2a68f1
Class classa — All alpha proteins
Fold Fold folda.4 — DNA/RNA-binding 3-helical bundle
Superfamily Superfamily superfamilya.4.13 — Sigma3 and sigma4 domains of RNA polymerase sigma factors
Family Family familya.4.13.1 — Sigma3 domain
Domain ID domain_idd2a68f2
Class classa — All alpha proteins
Fold Fold folda.4 — DNA/RNA-binding 3-helical bundle
Superfamily Superfamily superfamilya.4.13 — Sigma3 and sigma4 domains of RNA polymerase sigma factors
Family Family familya.4.13.2 — Sigma4 domain
Domain ID domain_idd2a68f3
Class classa — All alpha proteins
Fold Fold folda.177 — Sigma2 domain of RNA polymerase sigma factors
Superfamily Superfamily superfamilya.177.1 — Sigma2 domain of RNA polymerase sigma factors
Family Family familya.177.1.1 — Sigma2 domain of RNA polymerase sigma factors
Domain ID domain_idd2a68k1
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.74 — DCoH-like
Superfamily Superfamily superfamilyd.74.3 — RBP11-like subunits of RNA polymerase
Family Family familyd.74.3.1 — RNA polymerase alpha subunit dimerisation domain
Domain ID domain_idd2a68k2
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.181 — Insert subdomain of RNA polymerase alpha subunit
Superfamily Superfamily superfamilyd.181.1 — Insert subdomain of RNA polymerase alpha subunit
Family Family familyd.181.1.1 — Insert subdomain of RNA polymerase alpha subunit
Domain ID domain_idd2a68l1
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.74 — DCoH-like
Superfamily Superfamily superfamilyd.74.3 — RBP11-like subunits of RNA polymerase
Family Family familyd.74.3.1 — RNA polymerase alpha subunit dimerisation domain
Domain ID domain_idd2a68l2
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.181 — Insert subdomain of RNA polymerase alpha subunit
Superfamily Superfamily superfamilyd.181.1 — Insert subdomain of RNA polymerase alpha subunit
Family Family familyd.181.1.1 — Insert subdomain of RNA polymerase alpha subunit
Domain ID domain_idd2a68m_
Class classe — Multi-domain proteins (alpha and beta)
Fold Fold folde.29 — beta and beta-prime subunits of DNA dependent RNA-polymerase
Superfamily Superfamily superfamilye.29.1 — beta and beta-prime subunits of DNA dependent RNA-polymerase
Family Family familye.29.1.1 — RNA-polymerase beta
Domain ID domain_idd2a68n_
Class classe — Multi-domain proteins (alpha and beta)
Fold Fold folde.29 — beta and beta-prime subunits of DNA dependent RNA-polymerase
Superfamily Superfamily superfamilye.29.1 — beta and beta-prime subunits of DNA dependent RNA-polymerase
Family Family familye.29.1.2 — RNA-polymerase beta-prime
Domain ID domain_idd2a68o_
Class classa — All alpha proteins
Fold Fold folda.143 — RPB6/omega subunit-like
Superfamily Superfamily superfamilya.143.1 — RPB6/omega subunit-like
Family Family familya.143.1.1 — RNA polymerase omega subunit
Domain ID domain_idd2a68p1
Class classa — All alpha proteins
Fold Fold folda.4 — DNA/RNA-binding 3-helical bundle
Superfamily Superfamily superfamilya.4.13 — Sigma3 and sigma4 domains of RNA polymerase sigma factors
Family Family familya.4.13.1 — Sigma3 domain
Domain ID domain_idd2a68p2
Class classa — All alpha proteins
Fold Fold folda.4 — DNA/RNA-binding 3-helical bundle
Superfamily Superfamily superfamilya.4.13 — Sigma3 and sigma4 domains of RNA polymerase sigma factors
Family Family familya.4.13.2 — Sigma4 domain
Domain ID domain_idd2a68p3
Class classa — All alpha proteins
Fold Fold folda.177 — Sigma2 domain of RNA polymerase sigma factors
Superfamily Superfamily superfamilya.177.1 — Sigma2 domain of RNA polymerase sigma factors
Family Family familya.177.1.1 — Sigma2 domain of RNA polymerase sigma factors

CATH v4.4 (40 domains)

Domain ID domain_id2a68A01
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology1360 — Gyrase A; domain 2
Homologous superfamily homologous superfamily10 — RNA polymerase, RBP11-like subunit
Domain ID domain_id2a68A02
Class class2 — Mainly Beta
Architecture architecture170 — Beta Complex
Topology topology120 — RNA Polymerase Alpha Subunit; Chain A, domain 2
Homologous superfamily homologous superfamily12 — DNA-directed RNA polymerase, insert domain
Domain ID domain_id2a68B01
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology1360 — Gyrase A; domain 2
Homologous superfamily homologous superfamily10 — RNA polymerase, RBP11-like subunit
Domain ID domain_id2a68B02
Class class2 — Mainly Beta
Architecture architecture170 — Beta Complex
Topology topology120 — RNA Polymerase Alpha Subunit; Chain A, domain 2
Homologous superfamily homologous superfamily12 — DNA-directed RNA polymerase, insert domain
Domain ID domain_id2a68C01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology270 — Dna-directed Rna Polymerase Ii 140kd Polypeptide; Chain: B; Domain 6
Homologous superfamily homologous superfamily10 — DNA-directed RNA polymerase, subunit 2, domain 6
Domain ID domain_id2a68C02
Class class3 — Alpha Beta
Architecture architecture90 — Alpha-Beta Complex
Topology topology1100 — Rna Polymerase Beta Subunit; Chain: C,domain 2
Homologous superfamily homologous superfamily10 —
Domain ID domain_id2a68C03
Class class3 — Alpha Beta
Architecture architecture90 — Alpha-Beta Complex
Topology topology1110 — Dna-directed Rna Polymerase Ii 140kd Polypeptide; Chain: B; domain 3
Homologous superfamily homologous superfamily10 — RNA polymerase Rpb2, domain 2
Domain ID domain_id2a68C04
Class class2 — Mainly Beta
Architecture architecture30 — Roll
Topology topology150 — Rna Polymerase Beta Subunit; Chain: C, domain 4
Homologous superfamily homologous superfamily10 — DNA-directed RNA polymerase, beta subunit, external 1 domain
Domain ID domain_id2a68C05
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology50 — OB fold (Dihydrolipoamide Acetyltransferase, E2P)
Homologous superfamily homologous superfamily100 — RNA polymerase II/Efflux pump adaptor protein, barrel-sandwich hybrid domain
Domain ID domain_id2a68C06
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology50 — OB fold (Dihydrolipoamide Acetyltransferase, E2P)
Homologous superfamily homologous superfamily150 — RNA polymerase II, Rpb2 subunit, wall domain
Domain ID domain_id2a68D03
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology50 — OB fold (Dihydrolipoamide Acetyltransferase, E2P)
Homologous superfamily homologous superfamily100 — RNA polymerase II/Efflux pump adaptor protein, barrel-sandwich hybrid domain
Domain ID domain_id2a68D04
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology40 — Barwin-like endoglucanases
Homologous superfamily homologous superfamily20 —
Domain ID domain_id2a68D05
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology274 — Enzyme I; Chain A, domain 2
Homologous superfamily homologous superfamily100 — RNA polymerase Rpb1, domain 3
Domain ID domain_id2a68D06
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology132 — Topoisomerase I; Chain A, domain 4
Homologous superfamily homologous superfamily30 — RNA polymerase Rpb1 funnel domain
Domain ID domain_id2a68D08
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology50 — OB fold (Dihydrolipoamide Acetyltransferase, E2P)
Homologous superfamily homologous superfamily100 — RNA polymerase II/Efflux pump adaptor protein, barrel-sandwich hybrid domain
Domain ID domain_id2a68D09
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology60 — Wheat Germ Agglutinin (Isolectin 2); domain 1
Homologous superfamily homologous superfamily280 —
Domain ID domain_id2a68E00
Class class3 — Alpha Beta
Architecture architecture90 — Alpha-Beta Complex
Topology topology940 — Eukaryotic RPB6 RNA polymerase subunit
Homologous superfamily homologous superfamily10 — RNA polymerase subunit, RPB6/omega
Domain ID domain_id2a68F01
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology120 — Four Helix Bundle (Hemerythrin (Met), subunit A)
Homologous superfamily homologous superfamily1810 —
Domain ID domain_id2a68F02
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology10 — Arc Repressor Mutant, subunit A
Homologous superfamily homologous superfamily10 — Winged helix-like DNA-binding domain superfamily/Winged helix DNA-binding domain
Domain ID domain_id2a68F03
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology10 — Arc Repressor Mutant, subunit A
Homologous superfamily homologous superfamily10 — Winged helix-like DNA-binding domain superfamily/Winged helix DNA-binding domain
Domain ID domain_id2a68K01
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology1360 — Gyrase A; domain 2
Homologous superfamily homologous superfamily10 — RNA polymerase, RBP11-like subunit
Domain ID domain_id2a68K02
Class class2 — Mainly Beta
Architecture architecture170 — Beta Complex
Topology topology120 — RNA Polymerase Alpha Subunit; Chain A, domain 2
Homologous superfamily homologous superfamily12 — DNA-directed RNA polymerase, insert domain
Domain ID domain_id2a68L01
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology1360 — Gyrase A; domain 2
Homologous superfamily homologous superfamily10 — RNA polymerase, RBP11-like subunit
Domain ID domain_id2a68L02
Class class2 — Mainly Beta
Architecture architecture170 — Beta Complex
Topology topology120 — RNA Polymerase Alpha Subunit; Chain A, domain 2
Homologous superfamily homologous superfamily12 — DNA-directed RNA polymerase, insert domain
Domain ID domain_id2a68M01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology270 — Dna-directed Rna Polymerase Ii 140kd Polypeptide; Chain: B; Domain 6
Homologous superfamily homologous superfamily10 — DNA-directed RNA polymerase, subunit 2, domain 6
Domain ID domain_id2a68M02
Class class3 — Alpha Beta
Architecture architecture90 — Alpha-Beta Complex
Topology topology1100 — Rna Polymerase Beta Subunit; Chain: C,domain 2
Homologous superfamily homologous superfamily10 —
Domain ID domain_id2a68M03
Class class3 — Alpha Beta
Architecture architecture90 — Alpha-Beta Complex
Topology topology1110 — Dna-directed Rna Polymerase Ii 140kd Polypeptide; Chain: B; domain 3
Homologous superfamily homologous superfamily10 — RNA polymerase Rpb2, domain 2
Domain ID domain_id2a68M04
Class class2 — Mainly Beta
Architecture architecture30 — Roll
Topology topology150 — Rna Polymerase Beta Subunit; Chain: C, domain 4
Homologous superfamily homologous superfamily10 — DNA-directed RNA polymerase, beta subunit, external 1 domain
Domain ID domain_id2a68M05
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology50 — OB fold (Dihydrolipoamide Acetyltransferase, E2P)
Homologous superfamily homologous superfamily100 — RNA polymerase II/Efflux pump adaptor protein, barrel-sandwich hybrid domain
Domain ID domain_id2a68M06
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology50 — OB fold (Dihydrolipoamide Acetyltransferase, E2P)
Homologous superfamily homologous superfamily150 — RNA polymerase II, Rpb2 subunit, wall domain
Domain ID domain_id2a68N03
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology50 — OB fold (Dihydrolipoamide Acetyltransferase, E2P)
Homologous superfamily homologous superfamily100 — RNA polymerase II/Efflux pump adaptor protein, barrel-sandwich hybrid domain
Domain ID domain_id2a68N04
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology40 — Barwin-like endoglucanases
Homologous superfamily homologous superfamily20 —
Domain ID domain_id2a68N05
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology274 — Enzyme I; Chain A, domain 2
Homologous superfamily homologous superfamily100 — RNA polymerase Rpb1, domain 3
Domain ID domain_id2a68N06
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology132 — Topoisomerase I; Chain A, domain 4
Homologous superfamily homologous superfamily30 — RNA polymerase Rpb1 funnel domain
Domain ID domain_id2a68N08
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology50 — OB fold (Dihydrolipoamide Acetyltransferase, E2P)
Homologous superfamily homologous superfamily100 — RNA polymerase II/Efflux pump adaptor protein, barrel-sandwich hybrid domain
Domain ID domain_id2a68N09
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology60 — Wheat Germ Agglutinin (Isolectin 2); domain 1
Homologous superfamily homologous superfamily280 —
Domain ID domain_id2a68O00
Class class3 — Alpha Beta
Architecture architecture90 — Alpha-Beta Complex
Topology topology940 — Eukaryotic RPB6 RNA polymerase subunit
Homologous superfamily homologous superfamily10 — RNA polymerase subunit, RPB6/omega
Domain ID domain_id2a68P01
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology120 — Four Helix Bundle (Hemerythrin (Met), subunit A)
Homologous superfamily homologous superfamily1810 —
Domain ID domain_id2a68P02
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology10 — Arc Repressor Mutant, subunit A
Homologous superfamily homologous superfamily10 — Winged helix-like DNA-binding domain superfamily/Winged helix DNA-binding domain
Domain ID domain_id2a68P03
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology10 — Arc Repressor Mutant, subunit A
Homologous superfamily homologous superfamily10 — Winged helix-like DNA-binding domain superfamily/Winged helix DNA-binding domain
▶

7. Citations (1)
