2fox

CLOSTRIDIUM BEIJERINCKII FLAVODOXIN: SEMIQUINONE

Method: X-RAY DIFFRACTION

1. Protein Identity and Related Structures Protein Identity & Related Structures

FLAVODOXIN

OrganismNot specified

UniProt P00322

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein monomer Monomer Protein 1 FLAVIN MONONUCLEOTIDE × 1 water × 1 Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name FLAV_CLOBE
Isoform
PDB entities 1
Chains and sequence ranges Author chain A; PDBConstruct 1–138; UniProt 1–138

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

2. Structure Basics 2. Structure Basics

Entry ID entry_id2fox
Deposition date deposition_date1997-01-08
Structure title titleCLOSTRIDIUM BEIJERINCKII FLAVODOXIN: SEMIQUINONE
Keywords keywordsELECTRON TRANSPORT, FLAVOPROTEIN, FMN; ELECTRON TRANSPORT
Experimental Method methodX-RAY DIFFRACTION

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

2fox__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

2fox__assembly_1__model_1 | I(q)

10-2 10-1 105 106 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

2fox__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg(Guinier)15.43 Å
Rg (electron density)13.86 Å
Total Rg15.02 Å
Atom count1104
Residues138
Excluded volume19604 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 2fox__assembly_1__model_1 monomeric (1) Success 4.1.3-1-20251215 (887e7ef) View Download

4. Crystallography and Experiment 4. Crystallography & Experiment

5. Entities and Polymers Entities & Polymers (3)

6. Fold Classification (SCOP + CATH) 2 domains

SCOP 2.08 (1 domains)

Domain ID domain_idd2foxa_
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.23 — Flavodoxin-like
Superfamily Superfamily superfamilyc.23.5 — Flavoproteins
Family Family familyc.23.5.1 — Flavodoxin-related

CATH v4.4 (1 domains)

Domain ID domain_id2foxA00
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily360 — Flavodoxin domain

7. Citations (10)
