2laj

Third WW domain of human Nedd4L in complex with doubly phosphorylated human smad3 derived peptide

Method: SOLUTION NMR
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

E3 ubiquitin-protein ligase NEDD4-like

Homo sapiens

UniProt Q96PU5

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 2 Mothers against decapentaplegic homolog 3 × 1 (P84022) Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name NED4L_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A; PDBConstruct 5–44; UniProt 496–535

Mothers against decapentaplegic homolog 3

OrganismNot specified

UniProt P84022

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 2 E3 ubiquitin-protein ligase NEDD4-like × 1 (Q96PU5) Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name SMAD3_HUMAN
Isoform —
PDB entities 2
Chains and sequence ranges Author chain B; PDBConstruct 1–10; UniProt 202–211

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id2laj
Deposition date deposition_date2011-03-16
Structure title titleThird WW domain of human Nedd4L in complex with doubly phosphorylated human smad3 derived peptide
Keywords keywordsCDK, signal transduction, LIGASE-TRANSCRIPTION REGULATOR complex; LIGASE/TRANSCRIPTION REGULATOR
Experimental Method methodSOLUTION NMR
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

2laj__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

2laj__assembly_1__model_1 | I(q)

10-2 10-1 105 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

2laj__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg(Guinier)11.96 Å
Rg (electron density)10.54 Å
Total Rg12.03 Å
Atom count803
Residues48
Excluded volume7288 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 2laj__assembly_1__model_1 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
1 2 2laj__assembly_1__model_2 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
1 3 2laj__assembly_1__model_3 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
1 4 2laj__assembly_1__model_4 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
1 5 2laj__assembly_1__model_5 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
1 6 2laj__assembly_1__model_6 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
1 7 2laj__assembly_1__model_7 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
1 8 2laj__assembly_1__model_8 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
1 9 2laj__assembly_1__model_9 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
1 10 2laj__assembly_1__model_10 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
1 11 2laj__assembly_1__model_11 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
1 12 2laj__assembly_1__model_12 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
1 13 2laj__assembly_1__model_13 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
1 14 2laj__assembly_1__model_14 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
1 15 2laj__assembly_1__model_15 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (2)

▼

6. Fold Classification (SCOP + CATH) 1 domains

CATH v4.4 (1 domains)

Domain ID domain_id2lajA01
Class class2 — Mainly Beta
Architecture architecture20 — Single Sheet
Topology topology70 — Ubiquitin Ligase Nedd4; Chain: W;
Homologous superfamily homologous superfamily10 —
▶

7. Citations (1)
