SAXSdb — 3tg0

▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Alkaline phosphatase

Escherichia coli

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein homooligomer	Homooligomer	Protein 2	ZINC ION × 4 MAGNESIUM ION × 2 PHOSPHATE ION × 2 water × 2	Consistent with protein count
2	Protein homooligomer	Homooligomer	Protein 2	ZINC ION × 4 MAGNESIUM ION × 2 PHOSPHATE ION × 2 water × 2	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	PPB_ECOLI
Isoform	—
PDB entities	1
Chains and sequence ranges	Author chain A； PDBConstruct 1–449； UniProt 23–471 Author chain B； PDBConstruct 1–449； UniProt 23–471 Author chain C； PDBConstruct 1–449； UniProt 23–471 Author chain D； PDBConstruct 1–449； UniProt 23–471

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id	3tg0
Deposition date deposition_date	2011-08-16
Structure title title	E. coli alkaline phosphatase with bound inorganic phosphate
Keywords keywords	hydrolase; HYDROLASE
Experimental Method method	X-RAY DIFFRACTION

▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

3tg0__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

3tg0__assembly_1__model_1 | I(q)

100 plotted points; both axes use logarithmic scales.

3tg0__assembly_1__model_1 | P(r) · Pending

P(r) will be calculated and displayed separately for the same assembly/model.

Rg（Guinier）	28.42 Å
Rg (electron density)	27.91 Å
Total Rg	28.51 Å
Atom count	6480
Residues	880
Excluded volume	113940 Å³
Maximum q	0.500 Å⁻¹

Assembly	Model	Structure unit	Oligomeric description	Status	CRYSOL	Actions
1	1	`3tg0__assembly_1__model_1`	dimeric （2）	Success	4.1.3-1-20251215 (887e7ef)	View Download
2	1	`3tg0__assembly_2__model_1`	dimeric （2）	Success	4.1.3-1-20251215 (887e7ef)	View Download

▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (5)

Entity 1 Entity 1 polymer

Description description	Alkaline phosphatase
Molecular weight formula_weight	47094.4 kDa
EC 编号 ec_number	3.1.3.1
Source method src_method	man
Copy count entity_count	4

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	A,B,C,D
Atom count atom_count	15183

TPEMPVLENRAAQGDITAPGGARRLTGDQTAALRDSLSDKPAKNIILLIGDGMGDSEITAARNYAEGAGGFFKGIDALPLTGQYTHYALNKKTGKPDYVTDSAASATAWSTGVKTYNGALGVDIHEKDHPTILEMAKAAGLATGNVSTAELQDATPAALVAHVTSRKCYGPSATSEKCPGNALEKGGKGSITEQLLNARADVTLGGGAKTFAETATAGEWQGKTLREQAQARGYQLVSDAASLNSVTEANQQKPLLGLFADGNMPVRWLGPKATYHGNIDKPAVTCTPNPQRNDSVPTLAQMTDKAIELLSKNEKGFFLQVEGASIDKQDHAANPCGQIGETVDLDEAVQRALEFAKKEGNTLVIVTADHAHASQIVAPDTKAPGLTQALNTKDGAVMVMSYGNSEEDSQEHTGSQLRIAAYGPHAANVVGLTDQTDLFYTMKAALGLK

Source Source

Source organism organism	Escherichia coli
NCBI taxonomy ID ncbi_taxonomy_id	83333
Host organism host_organism	Escherichia coli

Entity 2 Entity 2 non-polymer

Description description	ZINC ION
Molecular weight formula_weight	65.4 kDa
Source method src_method	syn
Copy count entity_count	8

Entity 3 Entity 3 non-polymer

Description description	MAGNESIUM ION
Molecular weight formula_weight	24.3 kDa
Source method src_method	syn
Copy count entity_count	4

Entity 4 Entity 4 non-polymer

Description description	PHOSPHATE ION
Molecular weight formula_weight	95.0 kDa
Source method src_method	syn
Copy count entity_count	4

Entity 5 Entity 5 water

Description description	water
Molecular weight formula_weight	18.0 kDa
Source method src_method	nat
Copy count entity_count	1878

▼

6. Fold Classification (SCOP + CATH) 8 domains

SCOP 2.08 (4 domains)

Domain ID domain_id	d3tg0a_
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.76 — Alkaline phosphatase-like
Superfamily Superfamily superfamily	c.76.1 — Alkaline phosphatase-like
Family Family family	c.76.1.1 — Alkaline phosphatase

Domain ID domain_id	d3tg0b_
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.76 — Alkaline phosphatase-like
Superfamily Superfamily superfamily	c.76.1 — Alkaline phosphatase-like
Family Family family	c.76.1.1 — Alkaline phosphatase

Domain ID domain_id	d3tg0c_
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.76 — Alkaline phosphatase-like
Superfamily Superfamily superfamily	c.76.1 — Alkaline phosphatase-like
Family Family family	c.76.1.1 — Alkaline phosphatase

Domain ID domain_id	d3tg0d_
Class class	c — Alpha and beta proteins (a/b)
Fold Fold fold	c.76 — Alkaline phosphatase-like
Superfamily Superfamily superfamily	c.76.1 — Alkaline phosphatase-like
Family Family family	c.76.1.1 — Alkaline phosphatase

CATH v4.4 (4 domains)

Domain ID domain_id	3tg0A00
Class class	3 — Alpha Beta
Architecture architecture	40 — 3-Layer(aba) Sandwich
Topology topology	720 — Alkaline Phosphatase, subunit A
Homologous superfamily homologous superfamily	10 — Alkaline Phosphatase, subunit A

Domain ID domain_id	3tg0B00
Class class	3 — Alpha Beta
Architecture architecture	40 — 3-Layer(aba) Sandwich
Topology topology	720 — Alkaline Phosphatase, subunit A
Homologous superfamily homologous superfamily	10 — Alkaline Phosphatase, subunit A

Domain ID domain_id	3tg0C00
Class class	3 — Alpha Beta
Architecture architecture	40 — 3-Layer(aba) Sandwich
Topology topology	720 — Alkaline Phosphatase, subunit A
Homologous superfamily homologous superfamily	10 — Alkaline Phosphatase, subunit A

Domain ID domain_id	3tg0D00
Class class	3 — Alpha Beta
Architecture architecture	40 — 3-Layer(aba) Sandwich
Topology topology	720 — Alkaline Phosphatase, subunit A
Homologous superfamily homologous superfamily	10 — Alkaline Phosphatase, subunit A

▶

Unit-cell length a length_a	65.963 Å
Unit-cell length b length_b	98.457 Å
Unit-cell length c length_c	152.146 Å
Unit-cell angle α angle_alpha	90.00 °
Unit-cell angle β angle_beta	94.61 °
Unit-cell angle γ angle_gamma	90.00 °
Molecules per unit cell Z z_pdb	8

Space group space_group	P 1 21 1
Space-group number int_tables_number	4
Crystal system crystal_system	—

Resolution resolution	1.200 Å
Low-resolution limit resolution_low	50.000 Å
R factor r_factor	0.1495
R_work r_work	0.1485
R_free r_free	0.1687
