Exportin-1
Saccharomyces cerevisiae
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein heterocomplex Heteromer Protein × 3 PDB declaration: trimeric（3） Consistent with protein copy count | Chain C； UniProt 1–376 Chain C； UniProt 414–1058 | Fragment：SEE REMARK 999 Mutation：T539C,K579A,Y1022C | GTP-binding nuclear protein Ran × 1 （P62826） Ran-specific GTPase-activating protein 1 × 1 （P41920） RJA Ratjadone A, bound form × 1 GOL GLYCEROL × 3 EDO 1,2-ETHANEDIOL × 3 CL CHLORIDE ION × 3 GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K | Resolution 2.28 Å R-free 0.216 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 4HAX | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 3M1I Crystal structure of yeast CRM1 (Xpo1p) in complex with yeast RanBP1 (Yrb1p) and yeast RanGTP (Gsp1pGTP) Deposited 2010-03-05 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1084（1084 aa）
|
Mutation：A deletion mutant (residues 377-413 deleted) | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.6；293 K；0.1M Bis-Tris, 0.2M ammonium nitrate, 18% PEG3350, pH 6.6, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.220 |
| 3VYC Crystal structure of unliganded Saccharomyces cerevisiae CRM1 (Xpo1p) Deposited 2012-09-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–1084（1084 aa）
|
Mutation：a deletion mutant in which residues 377-413 and 971-984 are deleted | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.6；293 K；0.2M KF, 16% PEG3350, pH 7.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.10 Å R-free 0.217 |
| 3WYF Crystal structure of Xpo1p-Yrb2p-Gsp1p-GTP complex Deposited 2014-08-26 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1084（1084 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.7；0.1M CITRATE, 17% PEG6000, PH 5.7, VAPOR DIFFUSION, HANGING DROP, TEMPERATURE 293K
|
Resolution 2.22 Å R-free 0.214 |
| 3WYF Crystal structure of Xpo1p-Yrb2p-Gsp1p-GTP complex Deposited 2014-08-26 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain F
1–1084（1084 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.7；0.1M CITRATE, 17% PEG6000, PH 5.7, VAPOR DIFFUSION, HANGING DROP, TEMPERATURE 293K
|
Resolution 2.22 Å R-free 0.214 |
| 3WYG Crystal structure of Xpo1p-PKI-Gsp1p-GTP complex Deposited 2014-08-26 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1084（1084 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.7；0.1M TRIS, 15% PEG20000, PH 7.7, VAPOR DIFFUSION, HANGING DROP, TEMPERATURE 293K
|
Resolution 2.15 Å R-free 0.220 |
| 4GMX Crystal structure of KPT185 in complex with CRM1-Ran-RanBP1 Deposited 2012-08-16 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
Fragment：UNP residues 1-1058
|
Mutation：T539C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 K85 propan-2-yl 3-{3-[3-methoxy-5-(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}propanoate × 1 GOL GLYCEROL × 6 CL CHLORIDE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.10 Å R-free 0.197 |
| 4GPT Crystal structure of KPT251 in complex with CRM1-Ran-RanBP1 Deposited 2012-08-21 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
Fragment：UNP residues 1-1058
|
Mutation：T539C,Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 CL CHLORIDE ION × 5 51K 2-(2-{3-[3,5-bis(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}ethyl)-1,3,4-oxadiazole × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.22 Å R-free 0.210 |
| 4HAT Crystal structure of CRM1 inhibitor Leptomycin B in complex with CRM1-Ran-RanBP1 Deposited 2012-09-27 | Different mutation/modification Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–376（376 aa）
Fragment：SEE REMARK 999
Chain C
414–1058（645 aa）
Fragment：SEE REMARK 999
|
Mutation：T539C,Y1022C Mutation：T539C,Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 3 LMB Leptomycin B, bound form × 1 GOL GLYCEROL × 2 CL CHLORIDE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.78 Å R-free 0.173 |
| 4HAU Crystal structure of CRM1 inhibitor Ratjadone A in complex with CRM1-Ran-RanBP1 Deposited 2012-09-27 | Different mutation/modification Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–376（376 aa）
Fragment：SEE REMARK 999
Chain C
414–1058（645 aa）
Fragment：SEE REMARK 999
|
Mutation：T539C,Y1022C Mutation：T539C,Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 4 RJA Ratjadone A, bound form × 1 GOL GLYCEROL × 3 CL CHLORIDE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.207 |
| 4HAV Crystal structure of CRM1 inhibitor Anguinomycin A in complex with CRM1-Ran-RanBP1 Deposited 2012-09-27 | Different mutation/modification Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–376（376 aa）
Fragment：SEE REMARK 999
Chain C
414–1058（645 aa）
Fragment：SEE REMARK 999
|
Mutation：T539C,Y1022C Mutation：T539C,Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 CL CHLORIDE ION × 4 AA8 Anguinomycin A, bound form × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.220 |
| 4HAW Crystal structure of CRM1 inhibitor Leptomycin B in complex with CRM1(K548A)-Ran-RanBP1 Deposited 2012-09-27 | Different mutation/modification Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–376（376 aa）
Fragment：SEE REMARK 999
Chain C
414–1058（645 aa）
Fragment：SEE REMARK 999
|
Mutation：T539C,K548A,Y1022C Mutation：T539C,K548A,Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 2 GOL GLYCEROL × 3 EDO 1,2-ETHANEDIOL × 2 LMB Leptomycin B, bound form × 1 CL CHLORIDE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.90 Å R-free 0.209 |
| 4HAY Crystal structure of CRM1 inhibitor Leptomycin B in complex with CRM1(K548E,K579Q)-Ran-RanBP1 Deposited 2012-09-27 | Different mutation/modification Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–376（376 aa）
Fragment：SEE REMARK 999
Chain C
414–1058（645 aa）
Fragment：SEE REMARK 999
|
Mutation：T539C,K548E,K579Q,Y1022C Mutation：T539C,K548E,K579Q,Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 5 LMB Leptomycin B, bound form × 1 CL CHLORIDE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.30 Å R-free 0.230 |
| 4HAZ Crystal structure of CRM1 inhibitor Leptomycin B in complex with CRM1(R543S,K548E,K579Q)-Ran-RanBP1 Deposited 2012-09-27 | Different mutation/modification Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–376（376 aa）
Fragment：SEE REMARK 999
Chain C
414–1058（645 aa）
Fragment：SEE REMARK 999
|
Mutation：T539C,R543S,K548E,K579Q,Y1022C Mutation：T539C,R543S,K548E,K579Q,Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 CL CHLORIDE ION × 5 LBF Leptomycin B × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.90 Å R-free 0.209 |
| 4HB0 Crystal structure of CRM1 inhibitor Leptomycin B in complex with CRM1(K541Q,K542Q,R543S,K545Q,K548Q,K579Q)-Ran-RanBP1 Deposited 2012-09-27 | Different mutation/modification Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–376（376 aa）
Fragment：SEE REMARK 999
Chain C
414–1058（645 aa）
Fragment：SEE REMARK 999
|
Mutation：T539C,K541Q,K542Q,R543S,K545Q,K548Q,K579Q,Y1022C Mutation：T539C,K541Q,K542Q,R543S,K545Q,K548Q,K579Q,Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 LBF Leptomycin B × 1 CL CHLORIDE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.20 Å R-free 0.225 |
| 4HB2 Crystal structure of CRM1-Ran-RanBP1 Deposited 2012-09-27 | Different mutation/modification Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–376（376 aa）
Fragment：SEE REMARK 999
Chain C
414–1058（645 aa）
Fragment：SEE REMARK 999
|
Mutation：T539C,Y1022C Mutation：T539C,Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 4 EDO 1,2-ETHANEDIOL × 2 CL CHLORIDE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.80 Å R-free 0.201 |
| 4HB3 Crystal structure of CRM1(T539S)-Ran-RanBP1 with weakly bound unmodeled Leptomycin B Deposited 2012-09-27 | Different mutation/modification Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–376（376 aa）
Fragment：SEE REMARK 999
Chain C
414–1058（645 aa）
Fragment：SEE REMARK 999
|
Mutation：T539S,Y1022C Mutation：T539S,Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.80 Å R-free 0.276 |
| 4HB4 Crystal structure of CRM1 inhibitor Leptomycin B in complex with CRM1(537DLTVK541/GLCEQ)-Ran-RanBP1 Deposited 2012-09-27 | Different mutation/modification Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–376（376 aa）
Fragment：SEE REMARK 999
Chain C
414–1058（645 aa）
Fragment：SEE REMARK 999
|
Mutation：537DLTVK541 to GLCEQ, Y1022C Mutation：537DLTVK541 to GLCEQ, Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 LMB Leptomycin B, bound form × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.05 Å R-free 0.218 |
| 5DH9 Crystal Structure of PKI NES Flip Mutant Peptide in complex with CRM1-Ran-RanBP1 Deposited 2015-08-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
|
Mutation：V441D,D536G,T539C,V540E,K541Q,Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；298 K；17% PEG3350, 100mM Bis-Tris pH6.4, 200mM NH4NO3, 10mM Spermine HCl
|
Resolution 2.55 Å R-free 0.226 |
| 5DHA Crystal Structure of CPEB4 NES Reverse Mutant Peptide in complex with CRM1-Ran-RanBP1 Deposited 2015-08-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
|
Mutation：V441D,D536G,T539C,V540E,K541Q,Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；298 K；17% PEG3350, 100mM Bis-Tris, 10mM Spermine HCl
|
Resolution 2.95 Å R-free 0.240 |
| 5DHF Crystal Structure of hRio2 NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2015-08-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
|
Mutation：V441D,D536G,T539C,V540E,K541Q,Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；298 K；17% PEG3350, 100mM Bis-Tris pH6.4, 200mM NH4NO3, 10mM Spermine HCl
|
Resolution 2.29 Å R-free 0.218 |
| 5DI9 Crystal Structure of hRio2 NES Reverse Mutant Peptide in complex with CRM1-Ran-RanBP1 Deposited 2015-08-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
|
Mutation：V441D,D536G,T539C,V540E,K541Q,Y1022C, delta 377-413 | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 4 ZN ZINC ION × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；298 K；17% PEG3350, 100mM Bis-Tris pH6.4, 200mM NH4NO3, 10mM Spermine HCl
|
Resolution 2.28 Å R-free 0.211 |
| 5DIF Crystal Structure of CPEB4 NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2015-08-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
|
Mutation：V441D,D536G,T539C,V540E,K541Q,Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 7 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；298 K；17% PEG3350, 100mM Bis-Tris pH6.4, 200mM NH4NO3, 10mM Spermine HCl
|
Resolution 2.09 Å R-free 0.208 |
| 5JLJ Crystal Structure of KPT8602 in complex with CRM1-Ran-RanBP1 Deposited 2016-04-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
|
Mutation：T539C,Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 5 CL CHLORIDE ION × 1 6L8 (2R)-3-{3-[3,5-bis(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}-2-(pyrimidin-5-yl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；298 K；17% PEG3350, 100mM Bis-Tris pH6.6, 200mM Ammounium Nitrate
|
Resolution 2.50 Å R-free 0.232 |
| 5UWH Crystal Structure of Paxillin NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–376（376 aa）
Chain C
414–1058（645 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；16% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 20 mM HCl
|
Resolution 2.26 Å R-free 0.218 |
| 5UWI Crystal Structure of HDAC5 NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–376（376 aa）
Chain C
414–1058（645 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；17% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 10 mM spermine-HCl, 16 mM HCl
|
Resolution 2.14 Å R-free 0.218 |
| 5UWJ Crystal Structure of FMRP NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–376（376 aa）
Chain C
414–1058（645 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；17% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 10 mM spermine-HCl, 4 mM HCl
|
Resolution 2.22 Å R-free 0.213 |
| 5UWO Crystal Structure of Engineered FMRP-1b NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–376（376 aa）
Chain C
414–1058（645 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；16% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 12 mM HCl
|
Resolution 2.35 Å R-free 0.223 |
| 5UWP Crystal Structure of mDia2 NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–376（376 aa）
Chain C
414–1058（645 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；16% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 8 mM HCl
|
Resolution 2.05 Å R-free 0.213 |
| 5UWQ Crystal Structure of CDC7 NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–376（376 aa）
Chain C
414–1058（645 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；16% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 8 mM HCl
|
Resolution 2.28 Å R-free 0.225 |
| 5UWR Crystal Structure of CDC7 NES Peptide (extended) in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–376（376 aa）
Chain C
414–1058（645 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；17% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 10 mM spermine-HCl
|
Resolution 2.24 Å R-free 0.222 |
| 5UWS Crystal Structure of X11L2 NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–376（376 aa）
Chain C
414–1058（645 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；17% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 10 mM spermine-HCl
|
Resolution 2.40 Å R-free 0.222 |
| 5UWT Crystal Structure of Hxk2 Peptide in complex with CRM1 K579A mutant-Ran-RanBP1 Deposited 2017-02-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–376（376 aa）
Chain C
414–1058（645 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；17% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 20 mM HCl
|
Resolution 2.34 Å R-free 0.227 |
| 5UWU Crystal Structure of SMAD4 NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–376（376 aa）
Chain C
414–1058（645 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；16% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 16 mM HCl
|
Resolution 2.24 Å R-free 0.211 |
| 5UWW Crystal Structure of DEAF1 Peptide in complex with CRM1 K579A mutant-Ran-RanBP1 Deposited 2017-02-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–376（376 aa）
Chain C
414–1058（645 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；16% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 16 mM HCl
|
Resolution 2.15 Å R-free 0.226 |
| 5XOJ Crystal structure of Xpo1p-PKI-Nup42p-Gsp1p-GTP complex Deposited 2017-05-29 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain C
1–1084（1084 aa）
|
Mutation：residues 377-413 deleted | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.7；293 K；PEG20000, Tris-HCl
|
Resolution 2.20 Å R-free 0.220 |
| 5YRO RanL182A in complex with RanBP1-CRM1 Deposited 2017-11-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–376（376 aa）
Chain C
414–1058（645 aa）
|
Mutation：D537G, T539C, V540E, K541Q Mutation：D537G, T539C, V540E, K541Q | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 2 EDO 1,2-ETHANEDIOL × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG 3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH 6.6
|
Resolution 2.40 Å R-free 0.245 |
| 5YST RanM189D in complex with RanBP1-CRM1 Deposited 2017-11-15 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–376（376 aa）
Fragment：lacking C-terminal inhibitory tail,lacking C-terminal inhibitory tail
Chain C
414–1052（639 aa）
Fragment：lacking C-terminal inhibitory tail,lacking C-terminal inhibitory tail
|
Mutation：D537G, T539C, V540E, K541Q Mutation：D537G, T539C, V540E, K541Q | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 2 EDO 1,2-ETHANEDIOL × 1 CL CHLORIDE ION × 6 GOL GLYCEROL × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG 3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH 6.6
|
Resolution 2.04 Å R-free 0.238 |
| 5YSU Plumbagin in complex with CRM1-RanM189D-RanBP1 Deposited 2017-11-15 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–376（376 aa）
Chain C
414–1058（645 aa）
|
Mutation：D537G,T539C,V540E,K541Q,Y1022C Mutation：D537G,T539C,V540E,K541Q,Y1022C | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 CL CHLORIDE ION × 2 NO3 NITRATE ION × 4 F2X (2~{R})-2-methyl-5-oxidanyl-2,3-dihydronaphthalene-1,4-dione × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG 3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH 6.6
|
Resolution 2.30 Å R-free 0.257 |
| 5YTB RanY197A in complex with RanBP1-CRM1 Deposited 2017-11-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–376（376 aa）
Chain C
414–1052（639 aa）
|
Mutation：D537G, T539C, V540E, K541Q, Y1022C Mutation：D537G, T539C, V540E, K541Q, Y1022C | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 CL CHLORIDE ION × 7 GOL GLYCEROL × 3 ACT ACETATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG 3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH 6.6
|
Resolution 2.30 Å R-free 0.229 |
| 5ZPU LFS829 in complex with CRM1-Ran-RanBP1 Deposited 2018-04-16 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–376（376 aa）
Chain C
414–1058（645 aa）
|
Mutation：D537G, T539C, V540E, K541Q, Y1022C,D537G, T539C, V540E, K541Q, Y1022C Mutation：D537G, T539C, V540E, K541Q, Y1022C,D537G, T539C, V540E, K541Q, Y1022C | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 D29 (Z)-{[(3E)-4-{(R)-[3,5-bis(trifluoromethyl)phenyl]sulfinyl}but-3-en-1-yl]imino}methanethiol × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH6.6
|
Resolution 2.60 Å R-free 0.259 |
| 6A38 MVM NS2 NES in complex with CRM1-Ran-RanBP1 Deposited 2018-06-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
Fragment：lacking C-terminal inhibitory tail and H9 loop
|
Mutation：D537G, T539C, V540E, K541Q, Y1022C, 377-413 deletion, 441-461 deletion | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 GOL GLYCEROL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH6.6
|
Resolution 2.69 Å R-free 0.256 |
| 6A3A MVM NES mutant Nm2 in complex with CRM1-Ran-RanBP1 Deposited 2018-06-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
Fragment：lacking C-terminal inhibitory tail and H9 loop
|
Mutation：D537G, T539C, V540E, K541Q, Y1022C, 377-413 deletion, 441-461 deletion | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 GOL GLYCEROL × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH6.6
|
Resolution 2.30 Å R-free 0.246 |
| 6A3B MVM NES mutant Nm13 in complex with CRM1-Ran-RanBP1 Deposited 2018-06-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
|
Mutation：D537G, T539C, V540E, K541Q, Y1022C, 377-413 deletion, 441-461 deletion | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 GOL GLYCEROL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH6.6
|
Resolution 2.51 Å R-free 0.254 |
| 6A3C MVM NES mutant Nm12 in complex with CRM1-Ran-RanBP1 Deposited 2018-06-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
Fragment：lacking C-terminal inhibitory tail and H9 loop
|
Mutation：D537G, T539C, V540E, K541Q, Y1022C, 377-413 deletion, 441-461 deletion | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 GOL GLYCEROL × 2 CL CHLORIDE ION × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH6.6
|
Resolution 2.35 Å R-free 0.266 |
| 6A3E MVM NES mutant Nm15 in complex with CRM1-Ran-RanBP1 Deposited 2018-06-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
|
Mutation：D537G, T539C, V540E, K541Q, Y1022C, 377-413 deletion, 441-461 deletion | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；18% PEG3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH6.6
|
Resolution 2.70 Å R-free 0.241 |
| 6CIT Crystal Structure of MVM NS2 NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2018-02-25 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–376（376 aa）
Chain C
414–1058（645 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 6 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；295 K；17% PEG3350, 100 MM Bis-Tris, pH 6.4, 200 mM ammonium nitrate
|
Resolution 2.03 Å R-free 0.215 |
| 6LQ9 S109 in complex with CRM1-Ran-RanBP1 Deposited 2020-01-13 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
Fragment：lacking C-terminal inhibitory tail and H9 loop
|
Mutation：del 377-413, D537G, T539C, V540E, K541Q, Y1022C, | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 NO3 NITRATE ION × 5 CL CHLORIDE ION × 1 EQF (3~{R},4~{S})-1-[[6-chloranyl-5-(trifluoromethyl)pyridin-2-yl]amino]-3,4-dimethyl-pyrrolidine-2,5-dione × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH6.6
|
Resolution 2.50 Å R-free 0.228 |
| 6M60 Plumbagin in complex with CRM1#-Ran-RanBP1 Deposited 2020-03-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
|
Mutation：S27E , Q49E, del377-413, del441-461, D522K, D537G, T539C, V540E, K541Q, S553R, Q561E, A741T, Y1022C | MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 NO3 NITRATE ION × 9 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 CL CHLORIDE ION × 3 DMS DIMETHYL SULFOXIDE × 3 F2X (2~{R})-2-methyl-5-oxidanyl-2,3-dihydronaphthalene-1,4-dione × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.12 M Monosaccharides (20 mM D-Glucose; 20 mM D-Mannose; 20 mM D-Galactose; 20 mM L-Fucose; 20 mM D-Xylose; 20 mM N-Acetyl-D-Glucosamine), 0.1 M buffer system 1 pH 6.5 (sodium HEPES and MOPS), and 50 % Precipitant Mix 2 (40% v/v Ethylene glycol; 20 % w/v PEG 8000)
|
Resolution 2.17 Å R-free 0.213 |
| 6M6X Oridonin in complex with CRM1#-Ran-RanBP1 Deposited 2020-03-16 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
|
Mutation：S27E , Q49E, del377-413, del441-461, D522K, D537G, T539C, V540E, K541Q, S553R, Q561E, A741T, Y1022C | MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 CL CHLORIDE ION × 4 ODN (1beta,6beta,7beta,8alpha,9beta,10alpha,13alpha,14R,16beta)-1,6,7,14-tetrahydroxy-7,20-epoxykauran-15-one × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.12 M Monosaccharides (20 mM D-Glucose; 20 mM D-Mannose; 20 mM D-Galactose; 20 mM L-Fucose; 20 mM D-Xylose; 20 mM N-Acetyl-D-Glucosamine), 0.1 M buffer system 1 pH 6.5 (sodium HEPES and MOPS), and 50 % Precipitant Mix 2 (40% v/v Ethylene glycol; 20 % w/v PEG 8000)
|
Resolution 2.88 Å R-free 0.233 |
| 6X2M Crystal Structure of unliganded CRM1-Ran-RanBP1 Deposited 2020-05-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
|
Mutation：377-413 deleted | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.35 Å R-free 0.261 |
| 6X2O Crystal Structure of unliganded CRM1(E571K)-Ran-RanBP1 Deposited 2020-05-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
|
Mutation：E582K | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.55 Å R-free 0.254 |
| 6X2P Crystal Structure of the Mek1NES peptide bound to CRM1 Deposited 2020-05-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.40 Å R-free 0.252 |
| 6X2R Crystal Structure of the 4E-TNES peptide bound to CRM1 Deposited 2020-05-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.30 Å R-free 0.257 |
| 6X2S Crystal Structure of Mek1(NQ)NES peptide bound to CRM Deposited 2020-05-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.50 Å R-free 0.246 |
| 6X2U Crystal Structure of PKINES peptide bound to CRM1 Deposited 2020-05-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.20 Å R-free 0.240 |
| 6X2V Crystal Structure of PKI(DE)NES peptide bound to CRM1 Deposited 2020-05-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.82 Å R-free 0.262 |
| 6X2W Crystal Structure of PKINES peptide bound to CRM1(E571K) Deposited 2020-05-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
|
Mutation：E582K | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 3.00 Å R-free 0.253 |
| 6X2X Crystal Structure of Mek1NES peptide bound to CRM1(E571K) Deposited 2020-05-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
|
Mutation：E582K | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.46 Å R-free 0.250 |
| 6X2Y Crystal Structure of mDia2NES peptide bound to CRM1(E571K) Deposited 2020-05-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
|
Mutation：E582K | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.30 Å R-free 0.256 |
| 6XJP Crystal Structure of KPT-185 bound to CRM1 (537-DLTVK-541 to GLCEQ) Deposited 2020-06-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
|
Mutation：537-DLTVK-541 to GLCEQ | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 K85 propan-2-yl 3-{3-[3-methoxy-5-(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}propanoate × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；295 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.80 Å R-free 0.260 |
| 6XJR Crystal Structure of KPT-185 bound to CRM1 (E582K, 537-DLTVK-541 to GLCEQ) Deposited 2020-06-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
|
Mutation：E582K, 537-DLTVK-541 to GLCEQ | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 K85 propan-2-yl 3-{3-[3-methoxy-5-(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}propanoate × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；295 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 1.94 Å R-free 0.226 |
| 6XJS Crystal Structure of KPT-330 bound to CRM1 (E582K, 537-DLTVK-541 to GLCEQ) Deposited 2020-06-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
|
Mutation：E582K, 537-DLTVK-541 to GLCEQ | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 2 V6A selinexor, bound form × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；295 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 1.94 Å R-free 0.240 |
| 6XJT Crystal Structure of KPT-8602 bound to CRM1 (537-DLTVK-541 to GLCEQ) Deposited 2020-06-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
|
Mutation：537-DLTVK-541 to GLCEQ | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 6L8 (2R)-3-{3-[3,5-bis(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}-2-(pyrimidin-5-yl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；295 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.41 Å R-free 0.246 |
| 6XJU Crystal Structure of KPT-8602 bound to CRM1 (E582K, 537-DLTVK-541 to GLCEQ) Deposited 2020-06-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
|
Mutation：E582K, 537-DLTVK-541 to GLCEQ | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 6L8 (2R)-3-{3-[3,5-bis(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}-2-(pyrimidin-5-yl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；295 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.19 Å R-free 0.225 |
| 7L5E Crystal Structure of KPT-330 bound to CRM1 (537-DLTVK-541 to GLCEQ) Deposited 2020-12-21 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 1 V6A selinexor, bound form × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 1.94 Å R-free 0.245 |
| 8QYZ Crystal structure of hiNES2 in complex with Xpo1 and RanGTP Deposited 2023-10-26 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1084（1084 aa）
|
Mutation：del(377-413) | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ACT ACETATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；Tris, PEG 20K, magnesium acetate
|
Resolution 3.00 Å R-free 0.247 |
| 8QYZ Crystal structure of hiNES2 in complex with Xpo1 and RanGTP Deposited 2023-10-26 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–1084（1084 aa）
|
Mutation：del(377-413) | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ACT ACETATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；Tris, PEG 20K, magnesium acetate
|
Resolution 3.00 Å R-free 0.247 |
| 8QYZ Crystal structure of hiNES2 in complex with Xpo1 and RanGTP Deposited 2023-10-26 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain F
1–1084（1084 aa）
|
Mutation：del(377-413) | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ACT ACETATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；Tris, PEG 20K, magnesium acetate
|
Resolution 3.00 Å R-free 0.247 |
| 8QYZ Crystal structure of hiNES2 in complex with Xpo1 and RanGTP Deposited 2023-10-26 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
1–1084（1084 aa）
|
Mutation：del(377-413) | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ACT ACETATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；Tris, PEG 20K, magnesium acetate
|
Resolution 3.00 Å R-free 0.247 |
| 9OGN Crystal Structure of KPT396 in complex with CRM1-Ran-RanBP1 Deposited 2025-05-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
|
Mutation：T539C, Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 CL CHLORIDE ION × 3 A1CBD 3-(3-{3-[(but-2-yn-1-yl)oxy]-5-(trifluoromethyl)phenyl}-1H-1,2,4-triazol-1-yl)-N-(piperidin-1-yl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；17% PEG3350, 100 mM Bis-Tris (pH 6.6) and 200 mM ammonium nitrate
|
Resolution 2.41 Å R-free 0.224 |
| 9OGO Crystal Structure of KPT185 in complex with CRM1(EH mutant)-Ran-RanBP1 Deposited 2025-05-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
|
Mutation：V529E, T539C, F572H, Y1022C | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 K85 propan-2-yl 3-{3-[3-methoxy-5-(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}propanoate × 1 CL CHLORIDE ION × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；298 K；17% PEG3350, 100 mM Bis-Tris (pH 6.6) and 200 mM ammonium nitrate
|
Resolution 2.37 Å R-free 0.236 |
| 9VM1 MVM NS2 mutant Nm42 in complex with CRM1-Ran-RanBP1 Deposited 2025-06-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–1058（1058 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 1 NA SODIUM ION × 1 NO3 NITRATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；300 K；0.12 M Monosaccharides (20 mM D-Glucose; 20 mM D-Mannose; 20 mM D-Galactose; 20 mM L-Fucose; 20 mM D-Xylose; 20 mM N-Acetyl-D-Glucosamine), 0.1 M buffer system 1 pH 6.5 (sodium HEPES and MOPS), and 50 % Precipitant Mix 2 (40% v/v Ethylene glycol; 20 % w/v PEG 8000)
|
Resolution 2.45 Å R-free 0.235 |
| 9X7O Lansoprazole derivative in complex with CRM1-Ran-RanBP1 Deposited 2025-10-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–1058（1058 aa）
|
Mutation：S27E/Q49E/A51V/D537G/T539C/V540E/K541Q/S553R/Q561E/A741T/Y1022C | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å R-free 0.218 |
69 other PDB entries and 73 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | XPO1_YEAST |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain C； PDBConstruct 3–378； UniProt 1–376 Author chain C； PDBConstruct 379–1023； UniProt 414–1058 |
