GTP-binding nuclear protein Ran
Homo sapiens
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain A； UniProt 1–216 | Not recorded | No other associated polymer | SOLUTION NMR NMR measurement conditions：pH 7.4；298 K；Ionic strength (raw mmCIF value) 102；Pressure ambient NMR sample composition：0.5 mM [U-100% 13C; U-100% 15N] RAN GTPASE, 20 mM HEPES, 2 mM DTT, 0.04 % sodium azide, 100 mM potassium chloride, 2 mM magnesium chloride, 90% H2O/10% D2O | 90% H2O/10% D2O | Resolution not provided |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 2N1B | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 1I2M RAN-RCC1-SO4 COMPLEX Deposited 2001-02-11 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Not recorded | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；20-10% PEG 4000, 200 mM potassium fluoride, 25 mM potassium phosphate, 25 mM ammonium sulfate, 2 mM EDTA, 3mM DTE, pH 6.5, VAPOR DIFFUSION, HANGING DROP
|
Resolution 1.76 Å R-free 0.223 |
| 1I2M RAN-RCC1-SO4 COMPLEX Deposited 2001-02-11 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–216（216 aa）
|
Not recorded | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；20-10% PEG 4000, 200 mM potassium fluoride, 25 mM potassium phosphate, 25 mM ammonium sulfate, 2 mM EDTA, 3mM DTE, pH 6.5, VAPOR DIFFUSION, HANGING DROP
|
Resolution 1.76 Å R-free 0.223 |
| 1I2M RAN-RCC1-SO4 COMPLEX Deposited 2001-02-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
Chain C
1–216（216 aa）
|
Not recorded | SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；20-10% PEG 4000, 200 mM potassium fluoride, 25 mM potassium phosphate, 25 mM ammonium sulfate, 2 mM EDTA, 3mM DTE, pH 6.5, VAPOR DIFFUSION, HANGING DROP
|
Resolution 1.76 Å R-free 0.223 |
| 1IBR COMPLEX OF RAN WITH IMPORTIN BETA Deposited 1999-05-14 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6；pH 6.0
|
Resolution 2.30 Å R-free 0.272 |
| 1IBR COMPLEX OF RAN WITH IMPORTIN BETA Deposited 1999-05-14 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–216（216 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6；pH 6.0
|
Resolution 2.30 Å R-free 0.272 |
| 1K5D Crystal structure of Ran-GPPNHP-RanBP1-RanGAP complex Deposited 2001-10-10 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；PEG4000, POTASSIUM ACETATE, TRIS-HCL, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.70 Å R-free 0.267 |
| 1K5D Crystal structure of Ran-GPPNHP-RanBP1-RanGAP complex Deposited 2001-10-10 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–216（216 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；PEG4000, POTASSIUM ACETATE, TRIS-HCL, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.70 Å R-free 0.267 |
| 1K5D Crystal structure of Ran-GPPNHP-RanBP1-RanGAP complex Deposited 2001-10-10 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–216（216 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；PEG4000, POTASSIUM ACETATE, TRIS-HCL, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.70 Å R-free 0.267 |
| 1K5D Crystal structure of Ran-GPPNHP-RanBP1-RanGAP complex Deposited 2001-10-10 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain J
1–216（216 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；PEG4000, POTASSIUM ACETATE, TRIS-HCL, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.70 Å R-free 0.267 |
| 1K5G Crystal structure of Ran-GDP-AlFx-RanBP1-RanGAP complex Deposited 2001-10-10 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 AF3 ALUMINUM FLUORIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；PEG4000, TRIS-HCL, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 3.10 Å R-free 0.269 |
| 1K5G Crystal structure of Ran-GDP-AlFx-RanBP1-RanGAP complex Deposited 2001-10-10 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–216（216 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 AF3 ALUMINUM FLUORIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；PEG4000, TRIS-HCL, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 3.10 Å R-free 0.269 |
| 1K5G Crystal structure of Ran-GDP-AlFx-RanBP1-RanGAP complex Deposited 2001-10-10 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–216（216 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 AF3 ALUMINUM FLUORIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；PEG4000, TRIS-HCL, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 3.10 Å R-free 0.269 |
| 1K5G Crystal structure of Ran-GDP-AlFx-RanBP1-RanGAP complex Deposited 2001-10-10 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain J
1–216（216 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 AF3 ALUMINUM FLUORIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；PEG4000, TRIS-HCL, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 3.10 Å R-free 0.269 |
| 1QBK STRUCTURE OF THE KARYOPHERIN BETA2-RAN GPPNHP NUCLEAR TRANSPORT COMPLEX Deposited 1999-04-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–216（216 aa）
Fragment：FULL-LENGTH PROTEIN
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | MG MAGNESIUM ION × 1 GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；HEPES, MGCL2, PEG3350, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 20K
|
Resolution 3.00 Å R-free 0.315 |
| 1QBK STRUCTURE OF THE KARYOPHERIN BETA2-RAN GPPNHP NUCLEAR TRANSPORT COMPLEX Deposited 1999-04-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
1–216（216 aa）
Fragment：FULL-LENGTH PROTEIN
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | MG MAGNESIUM ION × 2 GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；HEPES, MGCL2, PEG3350, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 20K
|
Resolution 3.00 Å R-free 0.315 |
| 1RRP STRUCTURE OF THE RAN-GPPNHP-RANBD1 COMPLEX Deposited 1999-01-15 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
8–211（204 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.25；pH 6.25
|
Resolution 2.96 Å R-free 0.304 |
| 1RRP STRUCTURE OF THE RAN-GPPNHP-RANBD1 COMPLEX Deposited 1999-01-15 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
8–211（204 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.25；pH 6.25
|
Resolution 2.96 Å R-free 0.304 |
| 1RRP STRUCTURE OF THE RAN-GPPNHP-RANBD1 COMPLEX Deposited 1999-01-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric |
Chain A
8–211（204 aa）
Chain C
8–211（204 aa）
|
Not recorded | MG MAGNESIUM ION × 4 GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.25；pH 6.25
|
Resolution 2.96 Å R-free 0.304 |
| 1RRP STRUCTURE OF THE RAN-GPPNHP-RANBD1 COMPLEX Deposited 1999-01-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
8–211（204 aa）
Chain C
8–211（204 aa）
|
Not recorded | MG MAGNESIUM ION × 2 GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.25；pH 6.25
|
Resolution 2.96 Å R-free 0.304 |
| 2MMC Nucleotide-free human ran gtpase Deposited 2014-03-13 | Different experimental conditions | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–216（216 aa）
|
Not recorded | No recorded non-water small molecule |
SOLUTION NMR
NMR measurement conditions
pH 7.4；298 K；Ionic strength (raw mmCIF value) 102；Pressure ambient
NMR sample composition
0.5 mM [U-100% 13C; U-100% 15N] RAN GTPASE, 10 % [U-100% 2H] D2O, 20 mM HEPES, 2 mM DTT, 0.04 % sodium azide, 100 mM potassium chloride, 2 mM magnesium chloride, 90% H2O/10% D2O | 90% H2O/10% D2O
|
Resolution not provided |
| 2MMG Structural Characterization of the Mengovirus Leader Protein Bound to Ran GTPase by Nuclear Magnetic Resonance Deposited 2014-03-15 | Different experimental conditions | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–216（216 aa）
|
Not recorded | No recorded non-water small molecule |
SOLUTION NMR
NMR measurement conditions
pH 7.4；298 K；Ionic strength (raw mmCIF value) 102；Pressure ambient
NMR sample composition
0.5 mM [U-100% 13C; U-100% 15N] Ran GTPase, 0.5 mM L Mengo, 20 mM HEPES, 100 mM potassium chloride, 2 mM magnesium chloride, 2 mM DTT, 0.04 % sodium azide, 90% H2O/10% D2O | 90% H2O/10% D2O
|
Resolution not provided |
| 3CH5 The crystal structure of the RanGDP-Nup153ZnF2 complex Deposited 2008-03-07 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric |
Chain A
1–216（216 aa）
|
Not recorded | MG MAGNESIUM ION × 4 SO4 SULFATE ION × 4 GDP GUANOSINE-5'-DIPHOSPHATE × 4 ZN ZINC ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.5；293 K；2 M ammonium sulfate, 0.1 M Bis Tris, pH 5.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.10 Å R-free 0.234 |
| 3CH5 The crystal structure of the RanGDP-Nup153ZnF2 complex Deposited 2008-03-07 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | MG MAGNESIUM ION × 2 SO4 SULFATE ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 ZN ZINC ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.5；293 K；2 M ammonium sulfate, 0.1 M Bis Tris, pH 5.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.10 Å R-free 0.234 |
| 3EA5 Kap95p Binding Induces the Switch Loops of RanGDP to adopt the GTP-bound Conformation: Implications for Nuclear Import Complex Assembly Dynamics Deposited 2008-08-24 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Mutation：A181C, L254K | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.1；298 K；17% PEG 4000
0.1 M MES (pH 6.1)
10 mM MgCl2
125 mM NaCl
12% MPD
5 mg/ml GDP, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.50 Å R-free 0.232 |
| 3EA5 Kap95p Binding Induces the Switch Loops of RanGDP to adopt the GTP-bound Conformation: Implications for Nuclear Import Complex Assembly Dynamics Deposited 2008-08-24 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–216（216 aa）
|
Mutation：A181C, L254K | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.1；298 K；17% PEG 4000
0.1 M MES (pH 6.1)
10 mM MgCl2
125 mM NaCl
12% MPD
5 mg/ml GDP, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.50 Å R-free 0.232 |
| 3GJ0 Crystal structure of human RanGDP Deposited 2009-03-07 | Different construct Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
2–216（215 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；0.1M Bis-Tris pH 6.5, 18-20% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.48 Å R-free 0.203 |
| 3GJ0 Crystal structure of human RanGDP Deposited 2009-03-07 | Different construct Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
2–216（215 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；0.1M Bis-Tris pH 6.5, 18-20% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.48 Å R-free 0.203 |
| 3GJ3 Crystal structure of human RanGDP-Nup153ZnF2 complex Deposited 2009-03-07 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
2–216（215 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；0.1M Bis-Tris pH 6.5, 18-20% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.79 Å R-free 0.194 |
| 3GJ4 Crystal structure of human RanGDP-Nup153ZnF3 complex Deposited 2009-03-07 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
2–216（215 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；0.1M Bis-Tris pH 6.5, 18-20% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 2.15 Å R-free 0.257 |
| 3GJ4 Crystal structure of human RanGDP-Nup153ZnF3 complex Deposited 2009-03-07 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
2–216（215 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；0.1M Bis-Tris pH 6.5, 18-20% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 2.15 Å R-free 0.257 |
| 3GJ5 Crystal structure of human RanGDP-Nup153ZnF4 complex Deposited 2009-03-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
2–216（215 aa）
|
Mutation：F35S | MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；0.1 Bis-Tris pH 6.5, 18-20% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.79 Å R-free 0.233 |
| 3GJ5 Crystal structure of human RanGDP-Nup153ZnF4 complex Deposited 2009-03-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
2–216（215 aa）
|
Mutation：F35S | MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；0.1 Bis-Tris pH 6.5, 18-20% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.79 Å R-free 0.233 |
| 3GJ6 Crystal structure of human RanGDP-Nup153ZnF1 complex Deposited 2009-03-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
2–216（215 aa）
|
Mutation：F35S | MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；0.1 M Bis-Tris pH 6.5, 18-20% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 2.70 Å R-free 0.279 |
| 3GJ7 Crystal structure of human RanGDP-Nup153ZnF12 complex Deposited 2009-03-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
2–216（215 aa）
|
Mutation：F35S | MG MAGNESIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；0.1M Bis-Tris pH 6.5, 18-20% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.93 Å R-free 0.229 |
| 3GJ7 Crystal structure of human RanGDP-Nup153ZnF12 complex Deposited 2009-03-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
2–216（215 aa）
|
Mutation：F35S | MG MAGNESIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；0.1M Bis-Tris pH 6.5, 18-20% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.93 Å R-free 0.229 |
| 3GJ8 Crystal structure of human RanGDP-Nup153ZnF34 complex Deposited 2009-03-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
2–216（215 aa）
|
Mutation：F35S | MG MAGNESIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；0.1M Bis-Tris pH 6.5, 18-20% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.82 Å R-free 0.203 |
| 3GJ8 Crystal structure of human RanGDP-Nup153ZnF34 complex Deposited 2009-03-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
2–216（215 aa）
|
Mutation：F35S | MG MAGNESIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；0.1M Bis-Tris pH 6.5, 18-20% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.82 Å R-free 0.203 |
| 3GJX Crystal Structure of the Nuclear Export Complex CRM1-Snurportin1-RanGTP Deposited 2009-03-09 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–216（216 aa）
|
Not recorded | NA SODIUM ION × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；PEG 1000, pH 8, VAPOR DIFFUSION, SITTING DROP, temperature 293K
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；PEG 1000, pH 8, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.50 Å R-free 0.281 |
| 3GJX Crystal Structure of the Nuclear Export Complex CRM1-Snurportin1-RanGTP Deposited 2009-03-09 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain F
1–216（216 aa）
|
Not recorded | NA SODIUM ION × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；PEG 1000, pH 8, VAPOR DIFFUSION, SITTING DROP, temperature 293K
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；PEG 1000, pH 8, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.50 Å R-free 0.281 |
| 3NBY Crystal structure of the PKI NES-CRM1-RanGTP nuclear export complex Deposited 2010-06-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
5–180（176 aa）
|
Mutation：Q69L | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.2；293 K；0.1 M Tris/HCl pH range 8.08-8.30, 10-14% (w/v) PEG 1000, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 3.42 Å R-free 0.315 |
| 3NBY Crystal structure of the PKI NES-CRM1-RanGTP nuclear export complex Deposited 2010-06-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain F
5–180（176 aa）
|
Mutation：Q69L | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.2；293 K；0.1 M Tris/HCl pH range 8.08-8.30, 10-14% (w/v) PEG 1000, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 3.42 Å R-free 0.315 |
| 3NBZ Crystal structure of the HIV-1 Rev NES-CRM1-RanGTP nuclear export complex (crystal I) Deposited 2010-06-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
5–180（176 aa）
|
Mutation：Q69L | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.8；289 K；0.1 M Tris/HCl, 16% (w/v) PEG 1000, pH 7.8, VAPOR DIFFUSION, HANGING DROP, temperature 289K
|
Resolution 2.80 Å R-free 0.285 |
| 3NBZ Crystal structure of the HIV-1 Rev NES-CRM1-RanGTP nuclear export complex (crystal I) Deposited 2010-06-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain F
5–180（176 aa）
|
Mutation：Q69L | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.8；289 K；0.1 M Tris/HCl, 16% (w/v) PEG 1000, pH 7.8, VAPOR DIFFUSION, HANGING DROP, temperature 289K
|
Resolution 2.80 Å R-free 0.285 |
| 3NC0 Crystal structure of the HIV-1 Rev NES-CRM1-RanGTP nuclear export complex (crystal II) Deposited 2010-06-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain C
5–180（176 aa）
Chain F
5–180（176 aa）
|
Mutation：Q69L Mutation：Q69L | GOL GLYCEROL × 8 PEG DI(HYDROXYETHYL)ETHER × 11 IPH PHENOL × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.8；293 K；0.1 M Tris/HCl, 16% (w/v) PEG 1000, 2 mM phenol, pH 7.8, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.90 Å R-free 0.295 |
| 3NC0 Crystal structure of the HIV-1 Rev NES-CRM1-RanGTP nuclear export complex (crystal II) Deposited 2010-06-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain C
5–180（176 aa）
Chain F
5–180（176 aa）
|
Mutation：Q69L Mutation：Q69L | GOL GLYCEROL × 10 PEG DI(HYDROXYETHYL)ETHER × 11 IPH PHENOL × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.8；293 K；0.1 M Tris/HCl, 16% (w/v) PEG 1000, 2 mM phenol, pH 7.8, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.90 Å R-free 0.295 |
| 3NC1 Crystal structure of the CRM1-RanGTP complex Deposited 2010-06-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–180（180 aa）
|
Mutation：Q69L | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；0.1 M Tris/HCl, 12% (w/v) PEG 4000, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 3.35 Å R-free 0.254 |
| 3ZJY Crystal Structure of Importin 13 - RanGTP - eIF1A complex Deposited 2013-01-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–180（180 aa）
Fragment：RESIDUES 1-180
|
Mutation：YES | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 3.60 Å R-free 0.288 |
| 3ZJY Crystal Structure of Importin 13 - RanGTP - eIF1A complex Deposited 2013-01-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain D
1–180（180 aa）
Fragment：RESIDUES 1-180
|
Mutation：YES | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 3.60 Å R-free 0.288 |
| 3ZJY Crystal Structure of Importin 13 - RanGTP - eIF1A complex Deposited 2013-01-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain F
1–180（180 aa）
Fragment：RESIDUES 1-180
|
Mutation：YES | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 3.60 Å R-free 0.288 |
| 4C0Q Transportin 3 in complex with Ran(Q69L)GTP Deposited 2013-08-06 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
2–216（215 aa）
|
Mutation：YES | MG MAGNESIUM ION × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；13.5% (W/V) PEG3350, 8.5% (W/V) BENZAMIDINE HYDROCHLORIDE, 0.2M SODIUM ACETATE, PH6.5
|
Resolution 3.42 Å R-free 0.290 |
| 4C0Q Transportin 3 in complex with Ran(Q69L)GTP Deposited 2013-08-06 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain D
2–216（215 aa）
|
Mutation：YES | MG MAGNESIUM ION × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；13.5% (W/V) PEG3350, 8.5% (W/V) BENZAMIDINE HYDROCHLORIDE, 0.2M SODIUM ACETATE, PH6.5
|
Resolution 3.42 Å R-free 0.290 |
| 4GMX Crystal structure of KPT185 in complex with CRM1-Ran-RanBP1 Deposited 2012-08-16 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 K85 propan-2-yl 3-{3-[3-methoxy-5-(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}propanoate × 1 GOL GLYCEROL × 6 CL CHLORIDE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.10 Å R-free 0.197 |
| 4GPT Crystal structure of KPT251 in complex with CRM1-Ran-RanBP1 Deposited 2012-08-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 CL CHLORIDE ION × 5 51K 2-(2-{3-[3,5-bis(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}ethyl)-1,3,4-oxadiazole × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.22 Å R-free 0.210 |
| 4HAT Crystal structure of CRM1 inhibitor Leptomycin B in complex with CRM1-Ran-RanBP1 Deposited 2012-09-27 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 3 LMB Leptomycin B, bound form × 1 GOL GLYCEROL × 2 CL CHLORIDE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.78 Å R-free 0.173 |
| 4HAU Crystal structure of CRM1 inhibitor Ratjadone A in complex with CRM1-Ran-RanBP1 Deposited 2012-09-27 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 4 RJA Ratjadone A, bound form × 1 GOL GLYCEROL × 3 CL CHLORIDE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.207 |
| 4HAV Crystal structure of CRM1 inhibitor Anguinomycin A in complex with CRM1-Ran-RanBP1 Deposited 2012-09-27 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 CL CHLORIDE ION × 4 AA8 Anguinomycin A, bound form × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.220 |
| 4HAW Crystal structure of CRM1 inhibitor Leptomycin B in complex with CRM1(K548A)-Ran-RanBP1 Deposited 2012-09-27 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 2 GOL GLYCEROL × 3 EDO 1,2-ETHANEDIOL × 2 LMB Leptomycin B, bound form × 1 CL CHLORIDE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.90 Å R-free 0.209 |
| 4HAX Crystal structure of CRM1 inhibitor Ratjadone A in complex with CRM1(K579A)-Ran-RanBP1 Deposited 2012-09-27 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | RJA Ratjadone A, bound form × 1 GOL GLYCEROL × 3 EDO 1,2-ETHANEDIOL × 3 CL CHLORIDE ION × 3 GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.28 Å R-free 0.216 |
| 4HAY Crystal structure of CRM1 inhibitor Leptomycin B in complex with CRM1(K548E,K579Q)-Ran-RanBP1 Deposited 2012-09-27 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 5 LMB Leptomycin B, bound form × 1 CL CHLORIDE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.30 Å R-free 0.230 |
| 4HAZ Crystal structure of CRM1 inhibitor Leptomycin B in complex with CRM1(R543S,K548E,K579Q)-Ran-RanBP1 Deposited 2012-09-27 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 CL CHLORIDE ION × 5 LBF Leptomycin B × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.90 Å R-free 0.209 |
| 4HB0 Crystal structure of CRM1 inhibitor Leptomycin B in complex with CRM1(K541Q,K542Q,R543S,K545Q,K548Q,K579Q)-Ran-RanBP1 Deposited 2012-09-27 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 LBF Leptomycin B × 1 CL CHLORIDE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.20 Å R-free 0.225 |
| 4HB2 Crystal structure of CRM1-Ran-RanBP1 Deposited 2012-09-27 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 4 EDO 1,2-ETHANEDIOL × 2 CL CHLORIDE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.80 Å R-free 0.201 |
| 4HB3 Crystal structure of CRM1(T539S)-Ran-RanBP1 with weakly bound unmodeled Leptomycin B Deposited 2012-09-27 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.80 Å R-free 0.276 |
| 4HB4 Crystal structure of CRM1 inhibitor Leptomycin B in complex with CRM1(537DLTVK541/GLCEQ)-Ran-RanBP1 Deposited 2012-09-27 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 LMB Leptomycin B, bound form × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200 mM ammonium nitrate, 100 mM Bis-Tris, pH 6.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.05 Å R-free 0.218 |
| 4OL0 Crystal structure of transportin-SR2, a karyopherin involved in human disease, in complex with Ran Deposited 2014-01-23 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.7；293.15 K；100mM MES, 4.8% MPD, 15.2% PEG6000, pH 6.7, VAPOR DIFFUSION, HANGING DROP, temperature 293.15K
|
Resolution 2.90 Å R-free 0.276 |
| 4WVF Crystal structure of KPT276 in complex with CRM1-Ran-RanBP1 Deposited 2014-11-05 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 GOL GLYCEROL × 4 K76 (2E)-3-{3-[3,5-bis(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}-1-(3,3-difluoroazetidin-1-yl)prop-2-en-1-one × 1 CL CHLORIDE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；0.1M Bis-Tris pH 6.6, 0.2M NH4NO3 and 18% PEG3350
|
Resolution 1.80 Å R-free 0.183 |
| 5CIQ Ran GDP wild type tetragonal crystal form Deposited 2015-07-13 | Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–216（216 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；291 K；30% PEG 1000, 50 mM TRIS pH 8, 20 mM MgCl2
|
Resolution 1.65 Å R-free 0.249 |
| 5CIQ Ran GDP wild type tetragonal crystal form Deposited 2015-07-13 | Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–216（216 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；291 K；30% PEG 1000, 50 mM TRIS pH 8, 20 mM MgCl2
|
Resolution 1.65 Å R-free 0.249 |
| 5CIT Ran GDP wild type monoclinic crystal form Deposited 2015-07-13 | Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–216（216 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.2；291 K；32 % PEG 1000, 50 mM HEPES pH 7.2, 20 mM MgCl2, 1mM BeF
|
Resolution 1.75 Å R-free 0.262 |
| 5CIT Ran GDP wild type monoclinic crystal form Deposited 2015-07-13 | Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–216（216 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.2；291 K；32 % PEG 1000, 50 mM HEPES pH 7.2, 20 mM MgCl2, 1mM BeF
|
Resolution 1.75 Å R-free 0.262 |
| 5CIW Ran GDP Y39A mutant monoclinic crystal form Deposited 2015-07-13 | Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–216（216 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.2；291 K；34 % PEG 1000, 50 mM HEPES pH 7.2, 20 mM MgCl2, 1 mM BeF
|
Resolution 1.75 Å R-free 0.246 |
| 5CIW Ran GDP Y39A mutant monoclinic crystal form Deposited 2015-07-13 | Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–216（216 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.2；291 K；34 % PEG 1000, 50 mM HEPES pH 7.2, 20 mM MgCl2, 1 mM BeF
|
Resolution 1.75 Å R-free 0.246 |
| 5CJ2 Ran GDP Y39A mutant triclinic crystal form Deposited 2015-07-13 | Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–216（216 aa）
|
Mutation：Y39A | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；291 K；35% PEG 1000, 50mM Tris pH 8.5, 20mM MgCl2, 1 mM BeF
|
Resolution 1.75 Å R-free 0.239 |
| 5CJ2 Ran GDP Y39A mutant triclinic crystal form Deposited 2015-07-13 | Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–216（216 aa）
|
Mutation：Y39A | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 3 PO4 PHOSPHATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；291 K；35% PEG 1000, 50mM Tris pH 8.5, 20mM MgCl2, 1 mM BeF
|
Resolution 1.75 Å R-free 0.239 |
| 5CJ2 Ran GDP Y39A mutant triclinic crystal form Deposited 2015-07-13 | Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
1–216（216 aa）
|
Mutation：Y39A | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 3 PO4 PHOSPHATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；291 K；35% PEG 1000, 50mM Tris pH 8.5, 20mM MgCl2, 1 mM BeF
|
Resolution 1.75 Å R-free 0.239 |
| 5CJ2 Ran GDP Y39A mutant triclinic crystal form Deposited 2015-07-13 | Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
1–216（216 aa）
|
Mutation：Y39A | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；291 K；35% PEG 1000, 50mM Tris pH 8.5, 20mM MgCl2, 1 mM BeF
|
Resolution 1.75 Å R-free 0.239 |
| 5CJ2 Ran GDP Y39A mutant triclinic crystal form Deposited 2015-07-13 | Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 5 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain E
1–216（216 aa）
|
Mutation：Y39A | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；291 K；35% PEG 1000, 50mM Tris pH 8.5, 20mM MgCl2, 1 mM BeF
|
Resolution 1.75 Å R-free 0.239 |
| 5CJ2 Ran GDP Y39A mutant triclinic crystal form Deposited 2015-07-13 | Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 6 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain F
1–216（216 aa）
|
Mutation：Y39A | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；291 K；35% PEG 1000, 50mM Tris pH 8.5, 20mM MgCl2, 1 mM BeF
|
Resolution 1.75 Å R-free 0.239 |
| 5CJ2 Ran GDP Y39A mutant triclinic crystal form Deposited 2015-07-13 | Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 7 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain G
1–216（216 aa）
|
Mutation：Y39A | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；291 K；35% PEG 1000, 50mM Tris pH 8.5, 20mM MgCl2, 1 mM BeF
|
Resolution 1.75 Å R-free 0.239 |
| 5CJ2 Ran GDP Y39A mutant triclinic crystal form Deposited 2015-07-13 | Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 8 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain H
1–216（216 aa）
|
Mutation：Y39A | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；291 K；35% PEG 1000, 50mM Tris pH 8.5, 20mM MgCl2, 1 mM BeF
|
Resolution 1.75 Å R-free 0.239 |
| 5CLL Truncated Ran wild type in complex with GDP-BeF and RanBD1 Deposited 2015-07-16 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–191（191 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 1 BEF BERYLLIUM TRIFLUORIDE ION × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.25；291 K；18 % PEG 4000, 250 mM ammonium sulfate, 100 mM MES pH 6.25, 1 mM BeF
|
Resolution 2.45 Å R-free 0.272 |
| 5CLL Truncated Ran wild type in complex with GDP-BeF and RanBD1 Deposited 2015-07-16 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–191（191 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 1 BEF BERYLLIUM TRIFLUORIDE ION × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.25；291 K；18 % PEG 4000, 250 mM ammonium sulfate, 100 mM MES pH 6.25, 1 mM BeF
|
Resolution 2.45 Å R-free 0.272 |
| 5CLQ Ran Y39A in complex with GPPNHP and RanBD1 Deposited 2015-07-16 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Mutation：Y39A | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；1.8M ammonium sulfate, 2.5% PEG 1500, 100 mM HEPES pH 7.5
|
Resolution 3.20 Å R-free 0.254 |
| 5CLQ Ran Y39A in complex with GPPNHP and RanBD1 Deposited 2015-07-16 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–216（216 aa）
|
Mutation：Y39A | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；1.8M ammonium sulfate, 2.5% PEG 1500, 100 mM HEPES pH 7.5
|
Resolution 3.20 Å R-free 0.254 |
| 5DH9 Crystal Structure of PKI NES Flip Mutant Peptide in complex with CRM1-Ran-RanBP1 Deposited 2015-08-30 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；298 K；17% PEG3350, 100mM Bis-Tris pH6.4, 200mM NH4NO3, 10mM Spermine HCl
|
Resolution 2.55 Å R-free 0.226 |
| 5DHA Crystal Structure of CPEB4 NES Reverse Mutant Peptide in complex with CRM1-Ran-RanBP1 Deposited 2015-08-30 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；298 K；17% PEG3350, 100mM Bis-Tris, 10mM Spermine HCl
|
Resolution 2.95 Å R-free 0.240 |
| 5DHF Crystal Structure of hRio2 NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2015-08-30 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；298 K；17% PEG3350, 100mM Bis-Tris pH6.4, 200mM NH4NO3, 10mM Spermine HCl
|
Resolution 2.29 Å R-free 0.218 |
| 5DI9 Crystal Structure of hRio2 NES Reverse Mutant Peptide in complex with CRM1-Ran-RanBP1 Deposited 2015-08-31 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 4 ZN ZINC ION × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；298 K；17% PEG3350, 100mM Bis-Tris pH6.4, 200mM NH4NO3, 10mM Spermine HCl
|
Resolution 2.28 Å R-free 0.211 |
| 5DIF Crystal Structure of CPEB4 NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2015-08-31 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 7 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；298 K；17% PEG3350, 100mM Bis-Tris pH6.4, 200mM NH4NO3, 10mM Spermine HCl
|
Resolution 2.09 Å R-free 0.208 |
| 5DIS Crystal structure of a CRM1-RanGTP-SPN1 export complex bound to a 113 amino acid FG-repeat containing fragment of Nup214 Deposited 2015-09-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain B
8–179（172 aa）
Fragment：UNP residues 8-179
|
Mutation：Q69L | PRO PROLINE × 2 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；293 K；5% PEG 8000, 0.2M L-proline, 0.1M Tris pH 7.5, 4 mM D-maltose, 180 mM LiCl
|
Resolution 2.85 Å R-free 0.249 |
| 5DLQ Crystal structure of RanGTP-Exportin 4-eIF5A complex Deposited 2015-09-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
5–180（176 aa）
|
Mutation：Q69L | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.26；293 K；Peg 400, MES
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.26；293 K；Peg 400, MES, DTT
|
Resolution 3.20 Å R-free 0.270 |
| 5DLQ Crystal structure of RanGTP-Exportin 4-eIF5A complex Deposited 2015-09-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
5–180（176 aa）
|
Mutation：Q69L | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.26；293 K；Peg 400, MES
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.26；293 K；Peg 400, MES, DTT
|
Resolution 3.20 Å R-free 0.270 |
| 5FYQ Sirt2 in complex with a 13-mer trifluoroacetylated Ran peptide Deposited 2016-03-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain D
31–43（13 aa）
Fragment：PART OF SWITCH I, RESIDUES 31-43
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；0.1 M HEPES PH 7.5 2.0M NH4SO4
|
Resolution 3.00 Å R-free 0.271 |
| 5FYQ Sirt2 in complex with a 13-mer trifluoroacetylated Ran peptide Deposited 2016-03-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
31–43（13 aa）
Fragment：PART OF SWITCH I, RESIDUES 31-43
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；0.1 M HEPES PH 7.5 2.0M NH4SO4
|
Resolution 3.00 Å R-free 0.271 |
| 5JLJ Crystal Structure of KPT8602 in complex with CRM1-Ran-RanBP1 Deposited 2016-04-27 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 5 CL CHLORIDE ION × 1 6L8 (2R)-3-{3-[3,5-bis(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}-2-(pyrimidin-5-yl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；298 K；17% PEG3350, 100mM Bis-Tris pH6.6, 200mM Ammounium Nitrate
|
Resolution 2.50 Å R-free 0.232 |
| 5UWH Crystal Structure of Paxillin NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；16% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 20 mM HCl
|
Resolution 2.26 Å R-free 0.218 |
| 5UWI Crystal Structure of HDAC5 NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；17% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 10 mM spermine-HCl, 16 mM HCl
|
Resolution 2.14 Å R-free 0.218 |
| 5UWJ Crystal Structure of FMRP NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；17% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 10 mM spermine-HCl, 4 mM HCl
|
Resolution 2.22 Å R-free 0.213 |
| 5UWO Crystal Structure of Engineered FMRP-1b NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；16% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 12 mM HCl
|
Resolution 2.35 Å R-free 0.223 |
| 5UWP Crystal Structure of mDia2 NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；16% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 8 mM HCl
|
Resolution 2.05 Å R-free 0.213 |
| 5UWQ Crystal Structure of CDC7 NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；16% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 8 mM HCl
|
Resolution 2.28 Å R-free 0.225 |
| 5UWR Crystal Structure of CDC7 NES Peptide (extended) in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；17% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 10 mM spermine-HCl
|
Resolution 2.24 Å R-free 0.222 |
| 5UWS Crystal Structure of X11L2 NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；17% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 10 mM spermine-HCl
|
Resolution 2.40 Å R-free 0.222 |
| 5UWT Crystal Structure of Hxk2 Peptide in complex with CRM1 K579A mutant-Ran-RanBP1 Deposited 2017-02-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；17% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 20 mM HCl
|
Resolution 2.34 Å R-free 0.227 |
| 5UWU Crystal Structure of SMAD4 NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2017-02-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；16% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 16 mM HCl
|
Resolution 2.24 Å R-free 0.211 |
| 5UWW Crystal Structure of DEAF1 Peptide in complex with CRM1 K579A mutant-Ran-RanBP1 Deposited 2017-02-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；295 K；16% PEG3350, 100 mM Bis-Tris, pH 6.4, 200 mM ammonium nitrate, 16 mM HCl
|
Resolution 2.15 Å R-free 0.226 |
| 5YRO RanL182A in complex with RanBP1-CRM1 Deposited 2017-11-09 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：L182A | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 2 EDO 1,2-ETHANEDIOL × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG 3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH 6.6
|
Resolution 2.40 Å R-free 0.245 |
| 5YST RanM189D in complex with RanBP1-CRM1 Deposited 2017-11-15 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：M189D | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 2 EDO 1,2-ETHANEDIOL × 1 CL CHLORIDE ION × 6 GOL GLYCEROL × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG 3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH 6.6
|
Resolution 2.04 Å R-free 0.238 |
| 5YSU Plumbagin in complex with CRM1-RanM189D-RanBP1 Deposited 2017-11-15 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：M189D | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 CL CHLORIDE ION × 2 NO3 NITRATE ION × 4 F2X (2~{R})-2-methyl-5-oxidanyl-2,3-dihydronaphthalene-1,4-dione × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG 3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH 6.6
|
Resolution 2.30 Å R-free 0.257 |
| 5YTB RanY197A in complex with RanBP1-CRM1 Deposited 2017-11-17 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：Y197A | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 CL CHLORIDE ION × 7 GOL GLYCEROL × 3 ACT ACETATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG 3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH 6.6
|
Resolution 2.30 Å R-free 0.229 |
| 5ZPU LFS829 in complex with CRM1-Ran-RanBP1 Deposited 2018-04-16 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：L182A | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 D29 (Z)-{[(3E)-4-{(R)-[3,5-bis(trifluoromethyl)phenyl]sulfinyl}but-3-en-1-yl]imino}methanethiol × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH6.6
|
Resolution 2.60 Å R-free 0.259 |
| 6A38 MVM NS2 NES in complex with CRM1-Ran-RanBP1 Deposited 2018-06-15 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Mutation：Y197A | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 GOL GLYCEROL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH6.6
|
Resolution 2.69 Å R-free 0.256 |
| 6A3A MVM NES mutant Nm2 in complex with CRM1-Ran-RanBP1 Deposited 2018-06-15 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Mutation：Y197A | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 GOL GLYCEROL × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH6.6
|
Resolution 2.30 Å R-free 0.246 |
| 6A3B MVM NES mutant Nm13 in complex with CRM1-Ran-RanBP1 Deposited 2018-06-15 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Mutation：Y197A | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 GOL GLYCEROL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH6.6
|
Resolution 2.51 Å R-free 0.254 |
| 6A3C MVM NES mutant Nm12 in complex with CRM1-Ran-RanBP1 Deposited 2018-06-15 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Mutation：Y197A | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 GOL GLYCEROL × 2 CL CHLORIDE ION × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH6.6
|
Resolution 2.35 Å R-free 0.266 |
| 6A3E MVM NES mutant Nm15 in complex with CRM1-Ran-RanBP1 Deposited 2018-06-15 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Mutation：Y197A | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；18% PEG3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH6.6
|
Resolution 2.70 Å R-free 0.241 |
| 6CIT Crystal Structure of MVM NS2 NES Peptide in complex with CRM1-Ran-RanBP1 Deposited 2018-02-25 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 6 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；295 K；17% PEG3350, 100 MM Bis-Tris, pH 6.4, 200 mM ammonium nitrate
|
Resolution 2.03 Å R-free 0.215 |
| 6LQ9 S109 in complex with CRM1-Ran-RanBP1 Deposited 2020-01-13 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 NO3 NITRATE ION × 5 CL CHLORIDE ION × 1 EQF (3~{R},4~{S})-1-[[6-chloranyl-5-(trifluoromethyl)pyridin-2-yl]amino]-3,4-dimethyl-pyrrolidine-2,5-dione × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；293 K；18% PEG3350, 200mM Ammonium Nitrate, 100mM Bis-Tris pH6.6
|
Resolution 2.50 Å R-free 0.228 |
| 6M60 Plumbagin in complex with CRM1#-Ran-RanBP1 Deposited 2020-03-12 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：Q69L, L182A | MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 NO3 NITRATE ION × 9 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 CL CHLORIDE ION × 3 DMS DIMETHYL SULFOXIDE × 3 F2X (2~{R})-2-methyl-5-oxidanyl-2,3-dihydronaphthalene-1,4-dione × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.12 M Monosaccharides (20 mM D-Glucose; 20 mM D-Mannose; 20 mM D-Galactose; 20 mM L-Fucose; 20 mM D-Xylose; 20 mM N-Acetyl-D-Glucosamine), 0.1 M buffer system 1 pH 6.5 (sodium HEPES and MOPS), and 50 % Precipitant Mix 2 (40% v/v Ethylene glycol; 20 % w/v PEG 8000)
|
Resolution 2.17 Å R-free 0.213 |
| 6M6X Oridonin in complex with CRM1#-Ran-RanBP1 Deposited 2020-03-16 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：Q69L, L182A | MG MAGNESIUM ION × 1 EDO 1,2-ETHANEDIOL × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 CL CHLORIDE ION × 4 ODN (1beta,6beta,7beta,8alpha,9beta,10alpha,13alpha,14R,16beta)-1,6,7,14-tetrahydroxy-7,20-epoxykauran-15-one × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.12 M Monosaccharides (20 mM D-Glucose; 20 mM D-Mannose; 20 mM D-Galactose; 20 mM L-Fucose; 20 mM D-Xylose; 20 mM N-Acetyl-D-Glucosamine), 0.1 M buffer system 1 pH 6.5 (sodium HEPES and MOPS), and 50 % Precipitant Mix 2 (40% v/v Ethylene glycol; 20 % w/v PEG 8000)
|
Resolution 2.88 Å R-free 0.233 |
| 6Q82 Crystal structure of the biportin Pdr6 in complex with RanGTP Deposited 2018-12-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
5–180（176 aa）
|
Mutation：Q69L | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.26；291 K；Pentaerythritol propoxylate (17/8 PO/OH), MPD, Sodium acetate, Magnesium chloride
|
Resolution 2.99 Å R-free 0.253 |
| 6Q84 Crystal structure of RanGTP-Pdr6-eIF5A export complex Deposited 2018-12-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
5–180（176 aa）
|
Mutation：Q69L | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.3；291 K；100 mM Sodium acetate pH 5.3 and 30% PEG 300
|
Resolution 3.70 Å R-free 0.247 |
| 6Q84 Crystal structure of RanGTP-Pdr6-eIF5A export complex Deposited 2018-12-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain E
5–180（176 aa）
|
Mutation：Q69L | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.3；291 K；100 mM Sodium acetate pH 5.3 and 30% PEG 300
|
Resolution 3.70 Å R-free 0.247 |
| 6TVO Human CRM1-RanGTP in complex with Leptomycin B Deposited 2020-01-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
1–180（180 aa）
|
Mutation：Q69L | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 LMB Leptomycin B, bound form × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；277.15 K；0.02M sodium L-glutamate, 0.02M DL-alanine, 0.02M glycine, 0.02M DL-lysine HCl, 0.02 M DL-serine, 10%w/v PEG 8000, 20% v/v ethylene glycol, 0.1M bicine /Trizma base pH 8.5
|
Resolution 3.20 Å R-free 0.235 |
| 6X2M Crystal Structure of unliganded CRM1-Ran-RanBP1 Deposited 2020-05-20 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.35 Å R-free 0.261 |
| 6X2O Crystal Structure of unliganded CRM1(E571K)-Ran-RanBP1 Deposited 2020-05-20 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.55 Å R-free 0.254 |
| 6X2P Crystal Structure of the Mek1NES peptide bound to CRM1 Deposited 2020-05-20 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.40 Å R-free 0.252 |
| 6X2R Crystal Structure of the 4E-TNES peptide bound to CRM1 Deposited 2020-05-20 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.30 Å R-free 0.257 |
| 6X2S Crystal Structure of Mek1(NQ)NES peptide bound to CRM Deposited 2020-05-20 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.50 Å R-free 0.246 |
| 6X2U Crystal Structure of PKINES peptide bound to CRM1 Deposited 2020-05-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.20 Å R-free 0.240 |
| 6X2V Crystal Structure of PKI(DE)NES peptide bound to CRM1 Deposited 2020-05-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.82 Å R-free 0.262 |
| 6X2W Crystal Structure of PKINES peptide bound to CRM1(E571K) Deposited 2020-05-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 3.00 Å R-free 0.253 |
| 6X2X Crystal Structure of Mek1NES peptide bound to CRM1(E571K) Deposited 2020-05-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.46 Å R-free 0.250 |
| 6X2Y Crystal Structure of mDia2NES peptide bound to CRM1(E571K) Deposited 2020-05-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；273 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.30 Å R-free 0.256 |
| 6XJP Crystal Structure of KPT-185 bound to CRM1 (537-DLTVK-541 to GLCEQ) Deposited 2020-06-24 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 K85 propan-2-yl 3-{3-[3-methoxy-5-(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}propanoate × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；295 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.80 Å R-free 0.260 |
| 6XJR Crystal Structure of KPT-185 bound to CRM1 (E582K, 537-DLTVK-541 to GLCEQ) Deposited 2020-06-24 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 K85 propan-2-yl 3-{3-[3-methoxy-5-(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}propanoate × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；295 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 1.94 Å R-free 0.226 |
| 6XJS Crystal Structure of KPT-330 bound to CRM1 (E582K, 537-DLTVK-541 to GLCEQ) Deposited 2020-06-24 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 2 V6A selinexor, bound form × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；295 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 1.94 Å R-free 0.240 |
| 6XJT Crystal Structure of KPT-8602 bound to CRM1 (537-DLTVK-541 to GLCEQ) Deposited 2020-06-24 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 6L8 (2R)-3-{3-[3,5-bis(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}-2-(pyrimidin-5-yl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；295 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.41 Å R-free 0.246 |
| 6XJU Crystal Structure of KPT-8602 bound to CRM1 (E582K, 537-DLTVK-541 to GLCEQ) Deposited 2020-06-24 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 6L8 (2R)-3-{3-[3,5-bis(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}-2-(pyrimidin-5-yl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；295 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 2.19 Å R-free 0.225 |
| 7B51 Crystal structure of human CRM1 covalently modified by 2-mercaptoethanol at Cys528 Deposited 2020-12-03 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
1–180（180 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 BME BETA-MERCAPTOETHANOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 8.5；277.15 K；0.02M sodium L-glutamate, 0.02M DL-alanine, 0.02M glycine, 0.02M DL-lysine HCl, 0.02 M DL-serine, 10%w/v PEG 8000, 20% v/v ethylene glycol, 0.1M bicine /Trizma base pH 8.5
|
Resolution 2.58 Å R-free 0.250 |
| 7CND NCI-1 in complex with CRM1-Ran-RanBP1 Deposited 2020-07-31 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：Q69L, L182A | MG MAGNESIUM ION × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 DMS DIMETHYL SULFOXIDE × 6 CL CHLORIDE ION × 9 G6U ~{N}-[(~{E})-3-[3,5-bis(trifluoromethyl)phenyl]sulfinylprop-2-enyl]-3-methyl-butan-1-amine × 1 GOL GLYCEROL × 1 MPO 3[N-MORPHOLINO]PROPANE SULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.12 M Monosaccharides (20 mM D-Glucose; 20 mM D-Mannose; 20 mM D-Galactose; 20 mM L-Fucose; 20 mM D-Xylose; 20 mM N-Acetyl-D-Glucosamine), 0.1 M buffer system 1 pH 6.5 (sodium HEPES and MOPS), and 50 % Precipitant Mix 2 (40% v/v Ethylene glycol; 20 % w/v PEG 8000)
|
Resolution 1.80 Å R-free 0.232 |
| 7DBG Yeast CRM1e (apo) in complex with Ran-RanBP1 Deposited 2020-10-20 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：Q69L, L182A | MG MAGNESIUM ION × 1 GOL GLYCEROL × 2 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 CL CHLORIDE ION × 12 DMS DIMETHYL SULFOXIDE × 2 MPO 3[N-MORPHOLINO]PROPANE SULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；296 K；0.12 M Monosaccharides (20 mM D-Glucose; 20 mM D-Mannose; 20 mM D-Galactose; 20 mM L-Fucose; 20 mM D-Xylose; 20 mM N-Acetyl-D-Glucosamine), 0.1 M buffer system 1 pH 6.5 (sodium HEPES and MOPS), and 50 % Precipitant Mix 2 (40% v/v Ethylene glycol; 20 % w/v PEG 8000)
|
Resolution 2.06 Å R-free 0.228 |
| 7L5E Crystal Structure of KPT-330 bound to CRM1 (537-DLTVK-541 to GLCEQ) Deposited 2020-12-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 1 V6A selinexor, bound form × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；17% (weight/vol) PEG3350, 100 mM Bis-Tris (pH 6.4), 200 mM ammonium nitrate, and 10 mM Spermine HCl
|
Resolution 1.94 Å R-free 0.245 |
| 7MNP Crystal Structure of the ZnF2 of Nucleoporin NUP358/RanBP2 in complex with Ran-GDP Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；294 K；17 % (w/v) PEG 3,350; 0.1M Bis-Tris
|
Resolution 2.05 Å R-free 0.231 |
| 7MNP Crystal Structure of the ZnF2 of Nucleoporin NUP358/RanBP2 in complex with Ran-GDP Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；294 K；17 % (w/v) PEG 3,350; 0.1M Bis-Tris
|
Resolution 2.05 Å R-free 0.231 |
| 7MNQ Crystal Structure of the ZnF2 of Nucleoporin NUP358/RanBP2 in complex with Ran-GDP Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；294 K；21% (w/v) PEG 3350; 0.1 M Bis-Tris
|
Resolution 2.05 Å R-free 0.208 |
| 7MNR Crystal Structure of the ZnF3 of Nucleoporin NUP358/RanBP2 in complex with Ran-GDP Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；294 K；19% (w/v) PEG 3350; 0.1 M Bis-Tris
|
Resolution 1.80 Å R-free 0.196 |
| 7MNS Crystal Structure of the ZnF4 of Nucleoporin NUP358/RanBP2 in complex with Ran-GDP Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；294 K；18 % (w/v) PEG 3,350; 0.1M Bis-Tris
|
Resolution 2.10 Å R-free 0.203 |
| 7MNT Crystal Structure of the ZnF5 or ZnF6 of Nucleoporin NUP358/RanBP2 in complex with Ran-GDP Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；294 K；19 % (w/v) PEG 3,350; 0.1M Bis-Tris
|
Resolution 2.45 Å R-free 0.257 |
| 7MNT Crystal Structure of the ZnF5 or ZnF6 of Nucleoporin NUP358/RanBP2 in complex with Ran-GDP Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；294 K；19 % (w/v) PEG 3,350; 0.1M Bis-Tris
|
Resolution 2.45 Å R-free 0.257 |
| 7MNU Crystal Structure of the ZnF7 of Nucleoporin NUP358/RanBP2 in complex with Ran-GDP Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；294 K；19% (w/v) PEG 3350; 0.1 M Bis-Tris
|
Resolution 2.00 Å R-free 0.224 |
| 7MNV Crystal Structure of the ZnF8 of Nucleoporin NUP358/RanBP2 in complex with Ran-GDP Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 GOL GLYCEROL × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.7；294 K；19% (w/v) PEG 3350; 0.1 M Bis-Tris
|
Resolution 1.80 Å R-free 0.185 |
| 7MNW Crystal Structure of Nup358/RanBP2 Ran-binding domain 1 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；277 K；20% w/v PEG3350, 0.2 M potassium sodium tartrate tetrahydrate
|
Resolution 2.40 Å R-free 0.242 |
| 7MNW Crystal Structure of Nup358/RanBP2 Ran-binding domain 1 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；277 K；20% w/v PEG3350, 0.2 M potassium sodium tartrate tetrahydrate
|
Resolution 2.40 Å R-free 0.242 |
| 7MNW Crystal Structure of Nup358/RanBP2 Ran-binding domain 1 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain E
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；277 K；20% w/v PEG3350, 0.2 M potassium sodium tartrate tetrahydrate
|
Resolution 2.40 Å R-free 0.242 |
| 7MNW Crystal Structure of Nup358/RanBP2 Ran-binding domain 1 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain G
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；277 K；20% w/v PEG3350, 0.2 M potassium sodium tartrate tetrahydrate
|
Resolution 2.40 Å R-free 0.242 |
| 7MNX Crystal Structure of Nup358/RanBP2 Ran-binding domain 2 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；294 K；15% w/v PEG3350, 0.125 M magnesium formate
|
Resolution 2.40 Å R-free 0.230 |
| 7MNX Crystal Structure of Nup358/RanBP2 Ran-binding domain 2 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；294 K；15% w/v PEG3350, 0.125 M magnesium formate
|
Resolution 2.40 Å R-free 0.230 |
| 7MNX Crystal Structure of Nup358/RanBP2 Ran-binding domain 2 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain E
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；294 K；15% w/v PEG3350, 0.125 M magnesium formate
|
Resolution 2.40 Å R-free 0.230 |
| 7MNX Crystal Structure of Nup358/RanBP2 Ran-binding domain 2 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain G
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；294 K；15% w/v PEG3350, 0.125 M magnesium formate
|
Resolution 2.40 Å R-free 0.230 |
| 7MNX Crystal Structure of Nup358/RanBP2 Ran-binding domain 2 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 5 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain I
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；294 K；15% w/v PEG3350, 0.125 M magnesium formate
|
Resolution 2.40 Å R-free 0.230 |
| 7MNX Crystal Structure of Nup358/RanBP2 Ran-binding domain 2 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 6 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain K
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；294 K；15% w/v PEG3350, 0.125 M magnesium formate
|
Resolution 2.40 Å R-free 0.230 |
| 7MNY Crystal Structure of Nup358/RanBP2 Ran-binding domain 3 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；294 K；20% w/v PEG3350, 0.2 M sodium formate
|
Resolution 2.70 Å R-free 0.262 |
| 7MNY Crystal Structure of Nup358/RanBP2 Ran-binding domain 3 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；294 K；20% w/v PEG3350, 0.2 M sodium formate
|
Resolution 2.70 Å R-free 0.262 |
| 7MNY Crystal Structure of Nup358/RanBP2 Ran-binding domain 3 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain E
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；294 K；20% w/v PEG3350, 0.2 M sodium formate
|
Resolution 2.70 Å R-free 0.262 |
| 7MNY Crystal Structure of Nup358/RanBP2 Ran-binding domain 3 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain G
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；294 K；20% w/v PEG3350, 0.2 M sodium formate
|
Resolution 2.70 Å R-free 0.262 |
| 7MNY Crystal Structure of Nup358/RanBP2 Ran-binding domain 3 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 5 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain I
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；294 K；20% w/v PEG3350, 0.2 M sodium formate
|
Resolution 2.70 Å R-free 0.262 |
| 7MNY Crystal Structure of Nup358/RanBP2 Ran-binding domain 3 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 6 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain K
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；294 K；20% w/v PEG3350, 0.2 M sodium formate
|
Resolution 2.70 Å R-free 0.262 |
| 7MNZ Crystal Structure of Nup358/RanBP2 Ran-binding domain 4 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–215（215 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；294 K；20% w/v PEG3350, 0.1 M ammonium sulfate, 0.1 M HEPES
|
Resolution 2.35 Å R-free 0.225 |
| 7MNZ Crystal Structure of Nup358/RanBP2 Ran-binding domain 4 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–215（215 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；294 K；20% w/v PEG3350, 0.1 M ammonium sulfate, 0.1 M HEPES
|
Resolution 2.35 Å R-free 0.225 |
| 7MNZ Crystal Structure of Nup358/RanBP2 Ran-binding domain 4 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain E
1–215（215 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；294 K；20% w/v PEG3350, 0.1 M ammonium sulfate, 0.1 M HEPES
|
Resolution 2.35 Å R-free 0.225 |
| 7MNZ Crystal Structure of Nup358/RanBP2 Ran-binding domain 4 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain G
1–215（215 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；294 K；20% w/v PEG3350, 0.1 M ammonium sulfate, 0.1 M HEPES
|
Resolution 2.35 Å R-free 0.225 |
| 7MNZ Crystal Structure of Nup358/RanBP2 Ran-binding domain 4 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 5 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain I
1–215（215 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；294 K；20% w/v PEG3350, 0.1 M ammonium sulfate, 0.1 M HEPES
|
Resolution 2.35 Å R-free 0.225 |
| 7MNZ Crystal Structure of Nup358/RanBP2 Ran-binding domain 4 in complex with Ran-GPPNHP Deposited 2021-05-01 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 6 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain K
1–215（215 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；294 K；20% w/v PEG3350, 0.1 M ammonium sulfate, 0.1 M HEPES
|
Resolution 2.35 Å R-free 0.225 |
| 7MO0 Crystal Structure of Nucleoporin NUP50 Ran-Binding Domain in Complex with Ran-GPPNHP Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；294 K；25% w/v PEG3350, 0.2 M ammonium sulfate, 0.1 M HEPES
|
Resolution 2.45 Å R-free 0.239 |
| 7MO0 Crystal Structure of Nucleoporin NUP50 Ran-Binding Domain in Complex with Ran-GPPNHP Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–216（216 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；294 K；25% w/v PEG3350, 0.2 M ammonium sulfate, 0.1 M HEPES
|
Resolution 2.45 Å R-free 0.239 |
| 7MO1 Crystal Structure of the ZnF1 of Nucleoporin NUP153 in complex with Ran-GDP Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；294 K；22% w/v PEG3350, 0.1 M Bis-Tris
|
Resolution 1.60 Å R-free 0.175 |
| 7MO2 Crystal Structure of the ZnF2 of Nucleoporin NUP153 in complex with Ran-GDP Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.3；294 K；19% w/v PEG3350, 0.1 M Bis-Tris
|
Resolution 1.65 Å R-free 0.241 |
| 7MO2 Crystal Structure of the ZnF2 of Nucleoporin NUP153 in complex with Ran-GDP Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.3；294 K；19% w/v PEG3350, 0.1 M Bis-Tris
|
Resolution 1.65 Å R-free 0.241 |
| 7MO3 Crystal Structure of the ZnF3 of Nucleoporin NUP153 in complex with Ran-GDP, resolution 2.05 Angstrom Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；294 K；20% w/v PEG3350, 0.1 M Bis-Tris
|
Resolution 2.05 Å R-free 0.228 |
| 7MO3 Crystal Structure of the ZnF3 of Nucleoporin NUP153 in complex with Ran-GDP, resolution 2.05 Angstrom Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；294 K；20% w/v PEG3350, 0.1 M Bis-Tris
|
Resolution 2.05 Å R-free 0.228 |
| 7MO4 Crystal Structure of the ZnF3 of Nucleoporin NUP153 in complex with Ran-GDP, resolution 2.4 Angstrom Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.9；294 K；20% w/v PEG3350, 0.1 M Bis-Tris
|
Resolution 2.40 Å R-free 0.237 |
| 7MO4 Crystal Structure of the ZnF3 of Nucleoporin NUP153 in complex with Ran-GDP, resolution 2.4 Angstrom Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.9；294 K；20% w/v PEG3350, 0.1 M Bis-Tris
|
Resolution 2.40 Å R-free 0.237 |
| 7MO5 Crystal Structure of the ZnF4 of Nucleoporin NUP153 in complex with Ran-GDP Deposited 2021-05-01 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–216（216 aa）
|
Mutation：F35S | GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.2；294 K；22% w/v PEG3350, 0.1 M Bis-Tris
|
Resolution 1.55 Å R-free 0.190 |
| 7YPZ Zafirlukast in complex with CRM1-Ran-RanBP1 Deposited 2022-08-05 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：Q69L, L182A | MG MAGNESIUM ION × 1 DMS DIMETHYL SULFOXIDE × 6 EDO 1,2-ETHANEDIOL × 8 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 CL CHLORIDE ION × 4 NA SODIUM ION × 1 GOL GLYCEROL × 2 MPO 3[N-MORPHOLINO]PROPANE SULFONIC ACID × 1 ZLK zafirlukast × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.12 M Monosaccharides (20 mM D-Glucose; 20 mM D-Mannose; 20 mM D-Galactose; 20 mM L-Fucose; 20 mM D-Xylose; 20 mM N-Acetyl-D-Glucosamine), 0.1 M buffer system 1 pH 6.5 (sodium HEPES and MOPS), and 50 % Precipitant Mix 2 (40% v/v Ethylene glycol; 20 % w/v PEG 8000)
|
Resolution 2.15 Å R-free 0.216 |
| 8HQ3 KL1 in complex with CRM1-Ran-RanBP1 Deposited 2022-12-13 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：Q69L, L182A | MG MAGNESIUM ION × 1 NO3 NITRATE ION × 17 GOL GLYCEROL × 6 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 CL CHLORIDE ION × 1 DMS DIMETHYL SULFOXIDE × 7 MI8 methyl (3~{S},5~{R},6~{E},8~{Z},10~{R},12~{E},14~{E},16~{R})-3,16-bis(azanyl)-8,10,12-trimethyl-16-[(2~{S},4~{R},5~{S},6~{S})-5-methyl-4-oxidanyl-6-[(~{E})-prop-1-enyl]oxan-2-yl]-5-oxidanyl-hexadeca-6,8,12,14-tetraenoate × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.12 M Monosaccharides (20 mM D-Glucose; 20 mM D-Mannose; 20 mM D-Galactose; 20 mM L-Fucose; 20 mM D-Xylose; 20 mM N-Acetyl-D-Glucosamine), 0.1 M buffer system 1 pH 6.5 (sodium HEPES and MOPS), and 50 % Precipitant Mix 2 (40% v/v Ethylene glycol; 20 % w/v PEG 8000)
|
Resolution 2.10 Å R-free 0.210 |
| 8HQ4 B27 in complex with CRM1-Ran-RanBP1 Deposited 2022-12-13 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：Q69L, L182A | MG MAGNESIUM ION × 1 GOL GLYCEROL × 5 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 DMS DIMETHYL SULFOXIDE × 3 CL CHLORIDE ION × 2 M9R 3-[(4-fluorophenyl)carbonylamino]-4-[4-[3-(trifluoromethyl)phenyl]piperazin-1-yl]benzoic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.12 M Monosaccharides (20 mM D-Glucose; 20 mM D-Mannose; 20 mM D-Galactose; 20 mM L-Fucose; 20 mM D-Xylose; 20 mM N-Acetyl-D-Glucosamine), 0.1 M buffer system 1 pH 6.5 (sodium HEPES and MOPS), and 50 % Precipitant Mix 2 (40% v/v Ethylene glycol; 20 % w/v PEG 8000)
|
Resolution 2.12 Å R-free 0.210 |
| 8HQ5 G6 in complex with CRM1-Ran-RanBP1 Deposited 2022-12-13 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：Q69L, L182A | MG MAGNESIUM ION × 1 GOL GLYCEROL × 2 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 CL CHLORIDE ION × 11 DMS DIMETHYL SULFOXIDE × 2 MPO 3[N-MORPHOLINO]PROPANE SULFONIC ACID × 1 MBI 3-[(4-bromophenyl)carbonylamino]-4-[4-(5-chloranyl-2-methyl-phenyl)piperazin-1-yl]benzoic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.12 M Monosaccharides (20 mM D-Glucose; 20 mM D-Mannose; 20 mM D-Galactose; 20 mM L-Fucose; 20 mM D-Xylose; 20 mM N-Acetyl-D-Glucosamine), 0.1 M buffer system 1 pH 6.5 (sodium HEPES and MOPS), and 50 % Precipitant Mix 2 (40% v/v Ethylene glycol; 20 % w/v PEG 8000)
|
Resolution 2.25 Å R-free 0.209 |
| 8HQ6 KL2 in complex with CRM1-Ran-RanBP1 Deposited 2022-12-13 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：Q69L, L182A | MG MAGNESIUM ION × 1 NO3 NITRATE ION × 14 GOL GLYCEROL × 5 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 GLU GLUTAMIC ACID × 1 CL CHLORIDE ION × 2 DMS DIMETHYL SULFOXIDE × 4 MFF methyl (3~{S},5~{R},6~{E},8~{Z},10~{R},12~{E},14~{E},16~{S})-3,16-bis(azanyl)-8,10,12-trimethyl-16-[(2~{S},4~{R},5~{S},6~{S})-5-methyl-4-oxidanyl-6-[(~{E})-prop-1-enyl]oxan-2-yl]-5-oxidanyl-hexadeca-6,8,12,14-tetraenoate × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.12 M Monosaccharides (20 mM D-Glucose; 20 mM D-Mannose; 20 mM D-Galactose; 20 mM L-Fucose; 20 mM D-Xylose; 20 mM N-Acetyl-D-Glucosamine), 0.1 M buffer system 1 pH 6.5 (sodium HEPES and MOPS), and 50 % Precipitant Mix 2 (40% v/v Ethylene glycol; 20 % w/v PEG 8000)
|
Resolution 2.03 Å R-free 0.224 |
| 8HUF B28 in complex with CRM1-Ran-RanBP1 Deposited 2022-12-23 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：Q69L, L182A | MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 BR BROMIDE ION × 1 CL CHLORIDE ION × 1 NA SODIUM ION × 1 N5X 3-[(4-chlorophenyl)carbonylamino]-4-[4-(2,5-dimethylphenyl)piperazin-1-yl]benzoic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.12 M Monosaccharides (20 mM D-Glucose; 20 mM D-Mannose; 20 mM D-Galactose; 20 mM L-Fucose; 20 mM D-Xylose; 20 mM N-Acetyl-D-Glucosamine), 0.1 M buffer system 1 pH 6.5 (sodium HEPES and MOPS), and 50 % Precipitant Mix 2 (40% v/v Ethylene glycol; 20 % w/v PEG 8000)
|
Resolution 2.29 Å R-free 0.222 |
| 8HUG F1 in complex with CRM1-Ran-RanBP1 Deposited 2022-12-23 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：Q69L, L182A | MG MAGNESIUM ION × 1 GOL GLYCEROL × 4 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 CL CHLORIDE ION × 3 DMS DIMETHYL SULFOXIDE × 3 N59 4-[4-(3-chlorophenyl)piperazin-1-yl]-3-[(3-fluorophenyl)sulfonylamino]benzoic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.12 M Monosaccharides (20 mM D-Glucose; 20 mM D-Mannose; 20 mM D-Galactose; 20 mM L-Fucose; 20 mM D-Xylose; 20 mM N-Acetyl-D-Glucosamine), 0.1 M buffer system 1 pH 6.5 (sodium HEPES and MOPS), and 50 % Precipitant Mix 2 (40% v/v Ethylene glycol; 20 % w/v PEG 8000)
|
Resolution 2.15 Å R-free 0.224 |
| 8ITV KL2.1 in complex with CRM1-Ran-RanBP1 Deposited 2023-03-23 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：Q69L, L182A | MG MAGNESIUM ION × 1 NO3 NITRATE ION × 14 DMS DIMETHYL SULFOXIDE × 9 GOL GLYCEROL × 5 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 CL CHLORIDE ION × 1 ACT ACETATE ION × 1 Q73 (3~{S},5~{R},6~{E},8~{Z},10~{R},12~{E},14~{E},16~{S})-3,16-bis(azanyl)-8,10,12-trimethyl-16-[(2~{S},4~{R},5~{S},6~{S})-5-methyl-4-oxidanyl-6-[(~{E})-prop-1-enyl]oxan-2-yl]-5-oxidanyl-hexadeca-6,8,12,14-tetraenoic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.12 M Monosaccharides (20 mM D-Glucose; 20 mM D-Mannose; 20 mM D-Galactose; 20 mM L-Fucose; 20 mM D-Xylose; 20 mM N-Acetyl-D-Glucosamine), 0.1 M buffer system 1 pH 6.5 (sodium HEPES and MOPS), and 50 % Precipitant Mix 2 (40% v/v Ethylene glycol; 20 % w/v PEG 8000)
|
Resolution 2.30 Å R-free 0.224 |
| 8URJ Cryo-EM structure of the HIV-1 nuclear export complex Deposited 2023-10-26 | Different construct Different mutation/modification Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–RNA Heteromer；Protein × 6 PDB declaration: heptameric |
Chain D
3–179（177 aa）
Chain H
3–179（177 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE；Washed grid 2x outside of vitrobot; with the second drop of buffer I loaded the tweezers; moved the grid into the chamber and then I blotted.
|
Resolution 4.25 Å |
| 8UX1 Cryo-EM structure of Ran bound to RCC1 and the nucleosome core particle Deposited 2023-11-08 | Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 10 PDB declaration: dodecameric |
Chain K
1–216（216 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.50 Å |
| 9B62 Human RANBP2/RAN(GTP)/RANGAP1-SUMO1/UBC9/CRM1/RAN(GTP) - composite map and model Deposited 2024-03-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric |
Chain B
1–216（216 aa）
Chain F
1–216（216 aa）
|
Mutation：Q69L Mutation：Q69L | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 8；20 mM Tris-Cl pH 8.0, 50 mM NaCl, 0.1 mM TCEP supplemented with 0.02% (v/v) IGEPAL CA-630
cryo-EM vitrification conditions
Cryogen ETHANE；30 s wait time, blot for 2.5 s before plunging
|
Resolution 2.90 Å |
| 9BAW Cryo-EM structure of human importin beta-Ran-GTP heterodimer Deposited 2024-04-04 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
9–178（170 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.30 Å |
| 9HFL Cryo-EM structure of the human snRNA export complex comprising CBC-PHAX-CRM1-RanGTP and capped-RNA Deposited 2024-11-18 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–RNA Heteromer；Protein × 6 PDB declaration: heptameric |
Chain B
1–216（216 aa）
|
Mutation：Q69L | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GTA P1-7-METHYLGUANOSINE-P3-ADENOSINE-5',5'-TRIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.62 Å |
| 9N85 Cryo-EM structure of human importin beta:Ran-GTP:RanBP1 trimeric complex Deposited 2025-02-07 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
6–213（208 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.60 Å |
| 9OGN Crystal Structure of KPT396 in complex with CRM1-Ran-RanBP1 Deposited 2025-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 3 CL CHLORIDE ION × 3 A1CBD 3-(3-{3-[(but-2-yn-1-yl)oxy]-5-(trifluoromethyl)phenyl}-1H-1,2,4-triazol-1-yl)-N-(piperidin-1-yl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；17% PEG3350, 100 mM Bis-Tris (pH 6.6) and 200 mM ammonium nitrate
|
Resolution 2.41 Å R-free 0.224 |
| 9OGO Crystal Structure of KPT185 in complex with CRM1(EH mutant)-Ran-RanBP1 Deposited 2025-05-01 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Not recorded | GNP PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER × 1 MG MAGNESIUM ION × 1 K85 propan-2-yl 3-{3-[3-methoxy-5-(trifluoromethyl)phenyl]-1H-1,2,4-triazol-1-yl}propanoate × 1 CL CHLORIDE ION × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.6；298 K；17% PEG3350, 100 mM Bis-Tris (pH 6.6) and 200 mM ammonium nitrate
|
Resolution 2.37 Å R-free 0.236 |
| 9VM1 MVM NS2 mutant Nm42 in complex with CRM1-Ran-RanBP1 Deposited 2025-06-27 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–216（216 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GOL GLYCEROL × 1 NA SODIUM ION × 1 NO3 NITRATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；300 K；0.12 M Monosaccharides (20 mM D-Glucose; 20 mM D-Mannose; 20 mM D-Galactose; 20 mM L-Fucose; 20 mM D-Xylose; 20 mM N-Acetyl-D-Glucosamine), 0.1 M buffer system 1 pH 6.5 (sodium HEPES and MOPS), and 50 % Precipitant Mix 2 (40% v/v Ethylene glycol; 20 % w/v PEG 8000)
|
Resolution 2.45 Å R-free 0.235 |
| 9X7O Lansoprazole derivative in complex with CRM1-Ran-RanBP1 Deposited 2025-10-17 | Different mutation/modification Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–216（216 aa）
|
Mutation：Q69L/L182A | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å R-free 0.218 |
| 9YB5 Cryo-EM structure of human importin Beta:Ran-GDP:RanBP1 complex Deposited 2025-09-16 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
8–213（206 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.20 Å |
137 other PDB entries and 203 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | RAN_HUMAN |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 42–257； UniProt 1–216 |
