Azurin
Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain A； UniProt 22–148 | Mutation：W48F, Y72F, H83Q, Y108F, K122W, T124F, T126H | CU COPPER (II) ION × 1 REQ (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION；pH 4.5；294 K；0.1 M NaOAc, 120 mM/150 mM Li2SO4, and 48.6% PEG 400/27.7% PEG 8000 at pH 4.5 | Resolution 2.01 Å R-free 0.189 |
| 2 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain B； UniProt 22–148 | Mutation：W48F, Y72F, H83Q, Y108F, K122W, T124F, T126H | CU COPPER (II) ION × 1 REQ (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION；pH 4.5；294 K；0.1 M NaOAc, 120 mM/150 mM Li2SO4, and 48.6% PEG 400/27.7% PEG 8000 at pH 4.5 | Resolution 2.01 Å R-free 0.189 |
| 3 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain C； UniProt 22–148 | Mutation：W48F, Y72F, H83Q, Y108F, K122W, T124F, T126H | CU COPPER (II) ION × 1 REQ (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION；pH 4.5；294 K；0.1 M NaOAc, 120 mM/150 mM Li2SO4, and 48.6% PEG 400/27.7% PEG 8000 at pH 4.5 | Resolution 2.01 Å R-free 0.189 |
| 4 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain D； UniProt 22–148 | Mutation：W48F, Y72F, H83Q, Y108F, K122W, T124F, T126H | CU COPPER (II) ION × 1 REQ (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION；pH 4.5；294 K；0.1 M NaOAc, 120 mM/150 mM Li2SO4, and 48.6% PEG 400/27.7% PEG 8000 at pH 4.5 | Resolution 2.01 Å R-free 0.189 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 6MJR | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 1AG0 STRUCTURE OF CYS 112 ASP AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1997-03-26 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
20–148（129 aa）
|
Mutation：C113D | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；pH 6.5
|
Resolution 2.40 Å |
| 1AG0 STRUCTURE OF CYS 112 ASP AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1997-03-26 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
20–148（129 aa）
|
Mutation：C113D | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；pH 6.5
|
Resolution 2.40 Å |
| 1AZN CRYSTAL STRUCTURE OF THE AZURIN MUTANT PHE114ALA FROM PSEUDOMONAS AERUGINOSA AT 2.6 ANGSTROMS RESOLUTION Deposited 1994-05-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.60 Å |
| 1AZN CRYSTAL STRUCTURE OF THE AZURIN MUTANT PHE114ALA FROM PSEUDOMONAS AERUGINOSA AT 2.6 ANGSTROMS RESOLUTION Deposited 1994-05-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain C
21–148（128 aa）
Chain D
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.60 Å |
| 1AZR CRYSTAL STRUCTURE OF PSEUDOMONAS AERUGINOSA ZINC AZURIN MUTANT ASP47ASP AT 2.4 ANGSTROMS RESOLUTION Deposited 1993-03-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
Chain C
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 NO3 NITRATE ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.40 Å |
| 1AZR CRYSTAL STRUCTURE OF PSEUDOMONAS AERUGINOSA ZINC AZURIN MUTANT ASP47ASP AT 2.4 ANGSTROMS RESOLUTION Deposited 1993-03-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain B
21–148（128 aa）
Chain D
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.40 Å |
| 1AZU STRUCTURAL FEATURES OF AZURIN AT 2.7 ANGSTROMS RESOLUTION Deposited 1980-08-04 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.70 Å |
| 1BEX STRUCTURE OF RUTHENIUM-MODIFIED PSEUDOMONAS AERUGINOSA AZURIN Deposited 1998-05-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 4 RBU RUTHEMIUM BIS(2,2'-BIPYRIDINE)-2-IMIDAZOLE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8；30% PEG 4000, 100 MM LINO3,20 MM CUCL2,100 MM TRIS PH 8.0
|
Resolution 2.30 Å R-free 0.289 |
| 1BEX STRUCTURE OF RUTHENIUM-MODIFIED PSEUDOMONAS AERUGINOSA AZURIN Deposited 1998-05-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 4 RBU RUTHEMIUM BIS(2,2'-BIPYRIDINE)-2-IMIDAZOLE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8；30% PEG 4000, 100 MM LINO3,20 MM CUCL2,100 MM TRIS PH 8.0
|
Resolution 2.30 Å R-free 0.289 |
| 1CC3 PURPLE CUA CENTER Deposited 1999-03-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.1；pH 5.1
|
Resolution 1.65 Å R-free 0.263 |
| 1CC3 PURPLE CUA CENTER Deposited 1999-03-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.1；pH 5.1
|
Resolution 1.65 Å R-free 0.263 |
| 1E5Y Azurin from Pseudomonas aeruginosa, reduced form, pH 5.5 Deposited 2000-08-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain B
21–148（128 aa）
Chain D
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；PH 5.5
|
Resolution 2.00 Å |
| 1E5Y Azurin from Pseudomonas aeruginosa, reduced form, pH 5.5 Deposited 2000-08-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
Chain C
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 NO3 NITRATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；PH 5.5
|
Resolution 2.00 Å |
| 1E5Z Azurin from Pseudomonas aeruginosa, reduced form, pH 9.0 Deposited 2000-08-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain B
21–148（128 aa）
Chain D
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 9；PH 9.0
|
Resolution 2.00 Å |
| 1E5Z Azurin from Pseudomonas aeruginosa, reduced form, pH 9.0 Deposited 2000-08-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
Chain C
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 NO3 NITRATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 9；PH 9.0
|
Resolution 2.00 Å |
| 1E65 Azurin from Pseudomonas aeruginosa, apo form Deposited 2000-08-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
Chain C
21–148（128 aa）
Chain D
21–148（128 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；PH 5.5
|
Resolution 1.85 Å |
| 1E67 Zn-Azurin from Pseudomonas aeruginosa Deposited 2000-08-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | ZN ZINC ION × 1 NO3 NITRATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.7；pH 5.70
|
Resolution 2.14 Å |
| 1E67 Zn-Azurin from Pseudomonas aeruginosa Deposited 2000-08-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Not recorded | ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.7；pH 5.70
|
Resolution 2.14 Å |
| 1E67 Zn-Azurin from Pseudomonas aeruginosa Deposited 2000-08-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Not recorded | ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.7；pH 5.70
|
Resolution 2.14 Å |
| 1E67 Zn-Azurin from Pseudomonas aeruginosa Deposited 2000-08-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
|
Not recorded | ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.7；pH 5.70
|
Resolution 2.14 Å |
| 1ETJ AZURIN MUTANT WITH MET 121 REPLACED BY GLU Deposited 1997-01-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：M121E | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；THE BLUISH WELL-FORMED PRISMATIC CRYSTALS OF THE TITLE PROTEIN WERE OBTAINED BY THE VAPOR-DIFFUSION HANGING-DROP TECHNIQUE FROM A SOLUTION CONTAINING 25% PEG4000, 0.24M CALCIUM DICHLORIDE AND 0.26M LITHIUM NITRATE BUFFER AT PH 6.0 AND AT THE TEMPERATURE OF 24 - 25 CENTIGRADE IN AROUND 10 DAYS., vapor diffusion - hanging drop
|
Resolution 2.30 Å |
| 1ETJ AZURIN MUTANT WITH MET 121 REPLACED BY GLU Deposited 1997-01-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：M121E | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；THE BLUISH WELL-FORMED PRISMATIC CRYSTALS OF THE TITLE PROTEIN WERE OBTAINED BY THE VAPOR-DIFFUSION HANGING-DROP TECHNIQUE FROM A SOLUTION CONTAINING 25% PEG4000, 0.24M CALCIUM DICHLORIDE AND 0.26M LITHIUM NITRATE BUFFER AT PH 6.0 AND AT THE TEMPERATURE OF 24 - 25 CENTIGRADE IN AROUND 10 DAYS., vapor diffusion - hanging drop
|
Resolution 2.30 Å |
| 1ETJ AZURIN MUTANT WITH MET 121 REPLACED BY GLU Deposited 1997-01-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Mutation：M121E | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；THE BLUISH WELL-FORMED PRISMATIC CRYSTALS OF THE TITLE PROTEIN WERE OBTAINED BY THE VAPOR-DIFFUSION HANGING-DROP TECHNIQUE FROM A SOLUTION CONTAINING 25% PEG4000, 0.24M CALCIUM DICHLORIDE AND 0.26M LITHIUM NITRATE BUFFER AT PH 6.0 AND AT THE TEMPERATURE OF 24 - 25 CENTIGRADE IN AROUND 10 DAYS., vapor diffusion - hanging drop
|
Resolution 2.30 Å |
| 1ETJ AZURIN MUTANT WITH MET 121 REPLACED BY GLU Deposited 1997-01-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
|
Mutation：M121E | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；THE BLUISH WELL-FORMED PRISMATIC CRYSTALS OF THE TITLE PROTEIN WERE OBTAINED BY THE VAPOR-DIFFUSION HANGING-DROP TECHNIQUE FROM A SOLUTION CONTAINING 25% PEG4000, 0.24M CALCIUM DICHLORIDE AND 0.26M LITHIUM NITRATE BUFFER AT PH 6.0 AND AT THE TEMPERATURE OF 24 - 25 CENTIGRADE IN AROUND 10 DAYS., vapor diffusion - hanging drop
|
Resolution 2.30 Å |
| 1EZL CRYSTAL STRUCTURE OF THE DISULPHIDE BOND-DEFICIENT AZURIN MUTANT C3A/C26A: HOW IMPORTANT IS THE S-S BOND FOR FOLDING AND STABILITY? Deposited 2000-05-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
Chain C
21–148（128 aa）
Chain D
21–148（128 aa）
|
Mutation：C3A,C26A Mutation：C3A,C26A Mutation：C3A,C26A Mutation：C3A,C26A | CU COPPER (II) ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.7；295 K；ammonium sulphate, lithium nitrate, acetate, pH 5.7, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 2.00 Å R-free 0.256 |
| 1GR7 Crystal structure of the double mutant Cys3Ser/Ser100Pro from Pseudomonas Aeruginosa at 1.8 A resolution Deposited 2001-12-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
Chain C
21–148（128 aa）
Chain D
21–148（128 aa）
|
Mutation：YES Non-standard monomer：Yes (specific site not provided by mmCIF) Mutation：YES Non-standard monomer：Yes (specific site not provided by mmCIF) Mutation：YES Non-standard monomer：Yes (specific site not provided by mmCIF) Mutation：YES Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；3.2 M AMMONIUM SULPHATE, 1.0 M LITHIUM NITRATE, 0.2 M ACETATE BUFFER PH 5.5
|
Resolution 1.80 Å R-free 0.208 |
| 1I53 RE(I)-TRICARBONYL DIIMINE (Q107H)) AZURIN Deposited 2001-02-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：Q107H | CU COPPER (II) ION × 1 RTC RHENIUM (I) TRICARBONYL × 1 DPT 4,7-DIMETHYL-[1,10]PHENANTHROLINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；295 K；CuCl2, Imidazole, LiNo3, PEG 8K, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.80 Å R-free 0.259 |
| 1I53 RE(I)-TRICARBONYL DIIMINE (Q107H)) AZURIN Deposited 2001-02-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：Q107H | CU COPPER (II) ION × 1 RTC RHENIUM (I) TRICARBONYL × 1 DPT 4,7-DIMETHYL-[1,10]PHENANTHROLINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；295 K；CuCl2, Imidazole, LiNo3, PEG 8K, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.80 Å R-free 0.259 |
| 1ILS X-RAY CRYSTAL STRUCTURE THE TWO SITE-SPECIFIC MUTANTS ILE7SER AND PHE110SER OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1995-10-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
Chain C
21–148（128 aa）
|
Mutation：I7S Mutation：I7S | CU COPPER (II) ION × 2 NO3 NITRATE ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.20 Å |
| 1ILS X-RAY CRYSTAL STRUCTURE THE TWO SITE-SPECIFIC MUTANTS ILE7SER AND PHE110SER OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1995-10-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain B
21–148（128 aa）
Chain D
21–148（128 aa）
|
Mutation：I7S Mutation：I7S | CU COPPER (II) ION × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.20 Å |
| 1ILU X-RAY CRYSTAL STRUCTURE THE TWO SITE-SPECIFIC MUTANTS ILE7SER AND PHE110SER OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1995-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：F110S | CU COPPER (II) ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1ILU X-RAY CRYSTAL STRUCTURE THE TWO SITE-SPECIFIC MUTANTS ILE7SER AND PHE110SER OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1995-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 10 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain K
21–148（128 aa）
|
Mutation：F110S | CU COPPER (II) ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1ILU X-RAY CRYSTAL STRUCTURE THE TWO SITE-SPECIFIC MUTANTS ILE7SER AND PHE110SER OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1995-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 11 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain L
21–148（128 aa）
|
Mutation：F110S | CU COPPER (II) ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1ILU X-RAY CRYSTAL STRUCTURE THE TWO SITE-SPECIFIC MUTANTS ILE7SER AND PHE110SER OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1995-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 12 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain M
21–148（128 aa）
|
Mutation：F110S | CU COPPER (II) ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1ILU X-RAY CRYSTAL STRUCTURE THE TWO SITE-SPECIFIC MUTANTS ILE7SER AND PHE110SER OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1995-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：F110S | CU COPPER (II) ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1ILU X-RAY CRYSTAL STRUCTURE THE TWO SITE-SPECIFIC MUTANTS ILE7SER AND PHE110SER OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1995-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Mutation：F110S | CU COPPER (II) ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1ILU X-RAY CRYSTAL STRUCTURE THE TWO SITE-SPECIFIC MUTANTS ILE7SER AND PHE110SER OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1995-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
|
Mutation：F110S | CU COPPER (II) ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1ILU X-RAY CRYSTAL STRUCTURE THE TWO SITE-SPECIFIC MUTANTS ILE7SER AND PHE110SER OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1995-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 5 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain E
21–148（128 aa）
|
Mutation：F110S | CU COPPER (II) ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1ILU X-RAY CRYSTAL STRUCTURE THE TWO SITE-SPECIFIC MUTANTS ILE7SER AND PHE110SER OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1995-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 6 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain F
21–148（128 aa）
|
Mutation：F110S | CU COPPER (II) ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1ILU X-RAY CRYSTAL STRUCTURE THE TWO SITE-SPECIFIC MUTANTS ILE7SER AND PHE110SER OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1995-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 7 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain G
21–148（128 aa）
|
Mutation：F110S | CU COPPER (II) ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1ILU X-RAY CRYSTAL STRUCTURE THE TWO SITE-SPECIFIC MUTANTS ILE7SER AND PHE110SER OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1995-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 8 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain H
21–148（128 aa）
|
Mutation：F110S | CU COPPER (II) ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1ILU X-RAY CRYSTAL STRUCTURE THE TWO SITE-SPECIFIC MUTANTS ILE7SER AND PHE110SER OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1995-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 9 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain I
21–148（128 aa）
|
Mutation：F110S | CU COPPER (II) ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1JVL Azurin dimer, covalently crosslinked through bis-maleimidomethylether Deposited 2001-08-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
Fragment：Azurin
Chain B
21–148（128 aa）
Fragment：Azurin
|
Mutation：N42C Mutation：N42C | CU COPPER (II) ION × 2 NI NICKEL (II) ION × 2 144 TRIS-HYDROXYMETHYL-METHYL-AMMONIUM × 2 OPP 1-[PYRROL-1-YL-2,5-DIONE-METHOXYMETHYL]-PYRROLE-2,5-DIONE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；PEG 2000 MME, nickel chloride, Tris/HCl, pH 8.5, VAPOR DIFFUSION, SITTING DROP at 293K
|
Resolution 2.00 Å R-free 0.227 |
| 1JVO Azurin dimer, crosslinked via disulfide bridge Deposited 2001-08-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
21–148（128 aa）
Fragment：Azurin
Chain B
21–148（128 aa）
Fragment：Azurin
Chain C
21–148（128 aa）
Fragment：Azurin
Chain D
21–148（128 aa）
Fragment：Azurin
|
Mutation：N42C Mutation：N42C Mutation：N42C Mutation：N42C | CU COPPER (II) ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；PEG 8000, Tris/HCl, pH 8.5, VAPOR DIFFUSION, SITTING DROP at 293K, temperature 293.0K
|
Resolution 2.75 Å R-free 0.289 |
| 1JVO Azurin dimer, crosslinked via disulfide bridge Deposited 2001-08-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain E
21–148（128 aa）
Fragment：Azurin
Chain F
21–148（128 aa）
Fragment：Azurin
Chain G
21–148（128 aa）
Fragment：Azurin
Chain H
21–148（128 aa）
Fragment：Azurin
|
Mutation：N42C Mutation：N42C Mutation：N42C Mutation：N42C | CU COPPER (II) ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；PEG 8000, Tris/HCl, pH 8.5, VAPOR DIFFUSION, SITTING DROP at 293K, temperature 293.0K
|
Resolution 2.75 Å R-free 0.289 |
| 1JVO Azurin dimer, crosslinked via disulfide bridge Deposited 2001-08-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain I
21–148（128 aa）
Fragment：Azurin
Chain J
21–148（128 aa）
Fragment：Azurin
Chain K
21–148（128 aa）
Fragment：Azurin
Chain L
21–148（128 aa）
Fragment：Azurin
|
Mutation：N42C Mutation：N42C Mutation：N42C Mutation：N42C | CU COPPER (II) ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；PEG 8000, Tris/HCl, pH 8.5, VAPOR DIFFUSION, SITTING DROP at 293K, temperature 293.0K
|
Resolution 2.75 Å R-free 0.289 |
| 1JZE Pseudomonas aeruginosa Azurin Ru(bpy)2(im)(His83) Deposited 2001-09-16 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 DRU DELTA-BIS(2,2'-BIPYRIDINE)IMIDAZOLE RUTHENIUM (II) × 1 LRU LAMBDA-BIS(2,2'-BIPYRIDINE)IMIDAZOLE RUTHENIUM (II) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；PEG, Imidazole, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.60 Å R-free 0.274 |
| 1JZF Pseudomonas aeruginosa Oxidized Azurin(Cu2+) Ru(tpy)(phen)(His83) Deposited 2001-09-16 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 RTB (2,2':6',2'-TERPYRIDINE)-(1,10-PHENANTHROLINE) RUTHENIUM (II) × 1 IME TETRA(IMIDAZOLE)DIAQUACOPPER (II) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；PEG, Imidazole, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.50 Å R-free 0.220 |
| 1JZG Pseudomonas aeruginosa Reduced Azurin (Cu1+) Ru(tpy)(phen)(His83) Deposited 2001-09-16 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU1 COPPER (I) ION × 1 RTB (2,2':6',2'-TERPYRIDINE)-(1,10-PHENANTHROLINE) RUTHENIUM (II) × 1 IMF TETRA(IMIDAZOLE)DIAQUACOPPER (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；PEG, Imidazole, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.40 Å R-free 0.232 |
| 1JZH Pseudomonas aeruginosa Azurin Ru(tpy)(bpy)(His83) Deposited 2001-09-16 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 RTA (2,2':6',2''-TERPYRIDINE)-(2,2''-BIPYRIDINE) RUTHENIUM (II) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；PEG, Imidazole, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.70 Å R-free 0.277 |
| 1JZI Pseudomonas aeruginosa Azurin Re(phen)(CO)3(His83) Deposited 2001-09-16 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 REP (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 IME TETRA(IMIDAZOLE)DIAQUACOPPER (II) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；PEG, Imidazole, pH 7.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.62 Å R-free 0.247 |
| 1JZI Pseudomonas aeruginosa Azurin Re(phen)(CO)3(His83) Deposited 2001-09-16 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 REP (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；PEG, Imidazole, pH 7.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.62 Å R-free 0.247 |
| 1JZJ Pseudomonas aeruginosa Azurin Os(bpy)2(im)(His83) Deposited 2001-09-16 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 DOS DELTA-BIS(2,2'-BIPYRIDINE)IMIDAZOLE OSMIUM (II) × 1 LOS LAMBDA-BIS(2,2'-BIPYRIDINE)IMIDAZOLE OSMIUM (II) × 1 IME TETRA(IMIDAZOLE)DIAQUACOPPER (II) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；298 K；PEG, Imidazole, pH 6.0, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.260 |
| 1JZJ Pseudomonas aeruginosa Azurin Os(bpy)2(im)(His83) Deposited 2001-09-16 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 DOS DELTA-BIS(2,2'-BIPYRIDINE)IMIDAZOLE OSMIUM (II) × 1 LOS LAMBDA-BIS(2,2'-BIPYRIDINE)IMIDAZOLE OSMIUM (II) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；298 K；PEG, Imidazole, pH 6.0, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.260 |
| 1JZJ Pseudomonas aeruginosa Azurin Os(bpy)2(im)(His83) Deposited 2001-09-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 6 DOS DELTA-BIS(2,2'-BIPYRIDINE)IMIDAZOLE OSMIUM (II) × 4 LOS LAMBDA-BIS(2,2'-BIPYRIDINE)IMIDAZOLE OSMIUM (II) × 4 IME TETRA(IMIDAZOLE)DIAQUACOPPER (II) × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；298 K；PEG, Imidazole, pH 6.0, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.260 |
| 1JZJ Pseudomonas aeruginosa Azurin Os(bpy)2(im)(His83) Deposited 2001-09-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 3 DOS DELTA-BIS(2,2'-BIPYRIDINE)IMIDAZOLE OSMIUM (II) × 2 LOS LAMBDA-BIS(2,2'-BIPYRIDINE)IMIDAZOLE OSMIUM (II) × 2 IME TETRA(IMIDAZOLE)DIAQUACOPPER (II) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；298 K；PEG, Imidazole, pH 6.0, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.260 |
| 1JZJ Pseudomonas aeruginosa Azurin Os(bpy)2(im)(His83) Deposited 2001-09-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 5 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain B
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 4 DOS DELTA-BIS(2,2'-BIPYRIDINE)IMIDAZOLE OSMIUM (II) × 2 LOS LAMBDA-BIS(2,2'-BIPYRIDINE)IMIDAZOLE OSMIUM (II) × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；298 K；PEG, Imidazole, pH 6.0, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.260 |
| 1NZR CRYSTAL STRUCTURE OF THE AZURIN MUTANT NICKEL-TRP48MET FROM PSEUDOMONAS AERUGINOSA AT 2.2 ANGSTROMS RESOLUTION Deposited 1994-12-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
Chain C
21–148（128 aa）
|
Mutation：W48M Mutation：W48M | NI NICKEL (II) ION × 2 NO3 NITRATE ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.20 Å |
| 1NZR CRYSTAL STRUCTURE OF THE AZURIN MUTANT NICKEL-TRP48MET FROM PSEUDOMONAS AERUGINOSA AT 2.2 ANGSTROMS RESOLUTION Deposited 1994-12-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain B
21–148（128 aa）
Chain D
21–148（128 aa）
|
Mutation：W48M Mutation：W48M | NI NICKEL (II) ION × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.20 Å |
| 1R1C PSEUDOMONAS AERUGINOSA W48F/Y72F/H83Q/Y108W-AZURIN RE(PHEN)(CO)3(HIS107) Deposited 2003-09-23 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：W48F/Y72F/H83Q/Q107H/Y108W | CU1 COPPER (I) ION × 1 REP (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；298 K；PEG 4000, lithium nitrate, imidazole, pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.260 |
| 1R1C PSEUDOMONAS AERUGINOSA W48F/Y72F/H83Q/Y108W-AZURIN RE(PHEN)(CO)3(HIS107) Deposited 2003-09-23 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：W48F/Y72F/H83Q/Q107H/Y108W | CU1 COPPER (I) ION × 1 REP (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；298 K；PEG 4000, lithium nitrate, imidazole, pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.260 |
| 1R1C PSEUDOMONAS AERUGINOSA W48F/Y72F/H83Q/Y108W-AZURIN RE(PHEN)(CO)3(HIS107) Deposited 2003-09-23 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Mutation：W48F/Y72F/H83Q/Q107H/Y108W | CU1 COPPER (I) ION × 1 REP (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；298 K；PEG 4000, lithium nitrate, imidazole, pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.260 |
| 1R1C PSEUDOMONAS AERUGINOSA W48F/Y72F/H83Q/Y108W-AZURIN RE(PHEN)(CO)3(HIS107) Deposited 2003-09-23 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
|
Mutation：W48F/Y72F/H83Q/Q107H/Y108W | CU1 COPPER (I) ION × 1 REP (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；298 K；PEG 4000, lithium nitrate, imidazole, pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.260 |
| 1VLX STRUCTURE OF ELECTRON TRANSFER (COBALT-PROTEIN) Deposited 1996-10-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
Chain C
21–148（128 aa）
Chain D
21–148（128 aa）
|
Not recorded | CO COBALT (II) ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.7；THE BLUISH WELL-FORMED PRISMATIC CRYSTALS OF THE TITLE PROTEIN WERE OBTAINED BY THE VAPOR-DIFFUSION HANGING-DROP TECHNIQUE FROM A SOLUTION CONTAINING 3.6M AMMONIUM SULFATE, 0.5M LITHIUM NITRATE AND 0.1M ACETATE BUFFER AT PH 5.7 AND AT THE TEMPERATURE OF 24 - 25 CENTIGRADE IN AROUND 10 DAYS., vapor diffusion - hanging drop
|
Resolution 1.90 Å |
| 1XB3 The D62C/K74C double mutant of Pseudomonas Aeruginosa Azurin Deposited 2004-08-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：D62C/K74C | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.5；293 K；20-23% PEG 3350, 0.25M MgCl2, 0.1M Sodium Acetate, pH 4.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.50 Å R-free 0.214 |
| 1XB3 The D62C/K74C double mutant of Pseudomonas Aeruginosa Azurin Deposited 2004-08-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：D62C/K74C | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.5；293 K；20-23% PEG 3350, 0.25M MgCl2, 0.1M Sodium Acetate, pH 4.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.50 Å R-free 0.214 |
| 1XB6 The K24R mutant of Pseudomonas Aeruginosa Azurin Deposited 2004-08-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：K24R | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.5；293 K；20-23% PEG 3350, 0.25M MgCl2, 0.1M Sodium Acetate, pH 4.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.82 Å R-free 0.187 |
| 1XB6 The K24R mutant of Pseudomonas Aeruginosa Azurin Deposited 2004-08-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：K24R | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.5；293 K；20-23% PEG 3350, 0.25M MgCl2, 0.1M Sodium Acetate, pH 4.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.82 Å R-free 0.187 |
| 1XB8 Zn substituted form of D62C/K74C double mutant of Pseudomonas Aeruginosa Azurin Deposited 2004-08-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：D62C/K74C | ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；0.2 M Ammonium Sulfate, 0.1 M Cacodylate, 30% PEG 8000, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293.0K
|
Resolution 2.00 Å R-free 0.236 |
| 1XB8 Zn substituted form of D62C/K74C double mutant of Pseudomonas Aeruginosa Azurin Deposited 2004-08-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Mutation：D62C/K74C | ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；0.2 M Ammonium Sulfate, 0.1 M Cacodylate, 30% PEG 8000, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293.0K
|
Resolution 2.00 Å R-free 0.236 |
| 2AZU X-RAY CRYSTAL STRUCTURE OF THE TWO SITE-SPECIFIC MUTANTS HIS35*GLN AND HIS35*LEU OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1991-01-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
Chain C
21–148（128 aa）
|
Mutation：H35L Mutation：H35L | CU COPPER (II) ION × 2 NO3 NITRATE ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.90 Å |
| 2AZU X-RAY CRYSTAL STRUCTURE OF THE TWO SITE-SPECIFIC MUTANTS HIS35*GLN AND HIS35*LEU OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1991-01-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain B
21–148（128 aa）
Chain D
21–148（128 aa）
|
Mutation：H35L Mutation：H35L | CU COPPER (II) ION × 2 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.90 Å |
| 2FNW Pseudomonas aeruginosa E2Q/H83Q/M109H-azurin RE(PHEN)(CO)3 Deposited 2006-01-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
17–45（29 aa）
|
Mutation：E2Q/H83Q/M109H | CU COPPER (II) ION × 1 REP (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；20% PEG molecular weight 4000, 100 mM LiNO3 and 100 mM imidazole pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.40 Å R-free 0.227 |
| 2FNW Pseudomonas aeruginosa E2Q/H83Q/M109H-azurin RE(PHEN)(CO)3 Deposited 2006-01-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
17–45（29 aa）
|
Mutation：E2Q/H83Q/M109H | CU COPPER (II) ION × 1 REP (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；20% PEG molecular weight 4000, 100 mM LiNO3 and 100 mM imidazole pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.40 Å R-free 0.227 |
| 2FT6 Structure of Cu(II)azurin with the metal-binding loop sequence "CTFPGHSALM" replaced with "CTPHPM" Deposited 2006-01-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；293 K；0.1MM MES, 20% PEG6000, 0.2M LiCl, pH 6.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.25 Å R-free 0.155 |
| 2FT7 Structure of Cu(I)azurin at pH 6, with the metal-binding loop sequence "CTFPGHSALM" replaced with "CTPHPM" Deposited 2006-01-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；293 K；0.1MM MES, 20% PEG6000, 0.2M LiCl, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.40 Å R-free 0.178 |
| 2FT8 Structure of Cu(I)azurin, pH8, with the metal-binding loop sequence "CTFPGHSALM" replaced with "CTPHPM" Deposited 2006-01-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；293 K；0.1MM MES, 20% PEG6000, 0.2M LiCl, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.55 Å R-free 0.191 |
| 2FTA Structure of Cu(II)azurin with the metal-binding loop sequence "CTFPGHSALM" replaced with "CTPHPFM" Deposited 2006-01-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 2PE NONAETHYLENE GLYCOL × 1 EOH ETHANOL × 3 PEG DI(HYDROXYETHYL)ETHER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；0.1M Potassium Thiocyanate, 30% PEG MME 2000, pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.61 Å R-free 0.269 |
| 2FTA Structure of Cu(II)azurin with the metal-binding loop sequence "CTFPGHSALM" replaced with "CTPHPFM" Deposited 2006-01-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；0.1M Potassium Thiocyanate, 30% PEG MME 2000, pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.61 Å R-free 0.269 |
| 2FTA Structure of Cu(II)azurin with the metal-binding loop sequence "CTFPGHSALM" replaced with "CTPHPFM" Deposited 2006-01-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；0.1M Potassium Thiocyanate, 30% PEG MME 2000, pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.61 Å R-free 0.269 |
| 2FTA Structure of Cu(II)azurin with the metal-binding loop sequence "CTFPGHSALM" replaced with "CTPHPFM" Deposited 2006-01-24 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 2PE NONAETHYLENE GLYCOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；0.1M Potassium Thiocyanate, 30% PEG MME 2000, pH 7, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.61 Å R-free 0.269 |
| 2GHZ Crystal structure of Azurin Phe114Pro mutant Deposited 2006-03-28 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：Phe114Pro | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4；293 K；25% PEG1500, 100mM MMT buffer, pH 4, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.60 Å R-free 0.190 |
| 2GHZ Crystal structure of Azurin Phe114Pro mutant Deposited 2006-03-28 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：Phe114Pro | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4；293 K；25% PEG1500, 100mM MMT buffer, pH 4, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.60 Å R-free 0.190 |
| 2GI0 Crystal structure of Cu(I) Phe114Pro Azurin mutant Deposited 2006-03-28 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：Phe114Pro | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4；293 K；25% PEG1500, 100mM MMT buffer, pH4. To generate Cu(I), Cu(II) containing crystals were reduced by soaking in reservoir solution with 10mM ascorbate, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.70 Å R-free 0.224 |
| 2GI0 Crystal structure of Cu(I) Phe114Pro Azurin mutant Deposited 2006-03-28 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：Phe114Pro | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4；293 K；25% PEG1500, 100mM MMT buffer, pH4. To generate Cu(I), Cu(II) containing crystals were reduced by soaking in reservoir solution with 10mM ascorbate, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.70 Å R-free 0.224 |
| 2HX7 Crystal structure of Cu(II) Azurin with the metal-binding loop sequence "CTFPGHSALM" replaced with "CSPHQGAGM" Deposited 2006-08-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：;Metal binding loop "CTFPGHSALM" mutated to "CSPHQGAGM" ; | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；29-31% PEG 4000, 100mM magnesium chloride, 100mM Sodium acetate, pH 5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.55 Å R-free 0.190 |
| 2HX7 Crystal structure of Cu(II) Azurin with the metal-binding loop sequence "CTFPGHSALM" replaced with "CSPHQGAGM" Deposited 2006-08-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：;Metal binding loop "CTFPGHSALM" mutated to "CSPHQGAGM" ; | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；29-31% PEG 4000, 100mM magnesium chloride, 100mM Sodium acetate, pH 5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.55 Å R-free 0.190 |
| 2HX8 Crystal structure of Cu(I) Azurin with the metal-binding loop sequence "CTFPGHSALM" replaced with "CSPHQGAGM", at pH5 Deposited 2006-08-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：Metal binding loop | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；29-31% PEG 4000, 100mM magnesium chloride, 100mM Sodium acetate, pH 5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.60 Å R-free 0.184 |
| 2HX8 Crystal structure of Cu(I) Azurin with the metal-binding loop sequence "CTFPGHSALM" replaced with "CSPHQGAGM", at pH5 Deposited 2006-08-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：Metal binding loop | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；29-31% PEG 4000, 100mM magnesium chloride, 100mM Sodium acetate, pH 5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.60 Å R-free 0.184 |
| 2HX9 Crystal structure of Cu(I) Azurin with the metal-binding loop sequence "CTFPGHSALM" replaced with "CSPHQGAGM", at pH4 Deposited 2006-08-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：Metal binding loop | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；29-31% PEG 4000, 100mM magnesium chloride, 100mM Sodium acetate. Crystal soaked in pH4 buffer and ascorbate following growth, pH 5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.70 Å R-free 0.218 |
| 2HX9 Crystal structure of Cu(I) Azurin with the metal-binding loop sequence "CTFPGHSALM" replaced with "CSPHQGAGM", at pH4 Deposited 2006-08-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：Metal binding loop | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；29-31% PEG 4000, 100mM magnesium chloride, 100mM Sodium acetate. Crystal soaked in pH4 buffer and ascorbate following growth, pH 5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.70 Å R-free 0.218 |
| 2HXA Crystal structure of Cu(I) Azurin with the metal-binding loop sequence "CTFPGHSALM" replaced with "CSPHQGAGM", at pH3.5 Deposited 2006-08-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：Metal binding loop | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；29-31% PEG 4000, 100mM magnesium chloride, 100mM Sodium acetate. Crystal soaked in ascorbate and pH3.5 buffer following growth, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.21 Å R-free 0.267 |
| 2HXA Crystal structure of Cu(I) Azurin with the metal-binding loop sequence "CTFPGHSALM" replaced with "CSPHQGAGM", at pH3.5 Deposited 2006-08-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：Metal binding loop | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；29-31% PEG 4000, 100mM magnesium chloride, 100mM Sodium acetate. Crystal soaked in ascorbate and pH3.5 buffer following growth, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.21 Å R-free 0.267 |
| 2I7O Structure of Re(4,7-dimethyl-phen)(Thr124His)(Lys122Trp)(His83Gln)AzCu(II), a Rhenium modified Azurin mutant Deposited 2006-08-31 | Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：H83N, K122W, T124H | CU COPPER (II) ION × 1 REQ (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 3.2；298 K；20-24% PEG 4000, 100 mM LiNO3, 100 mM citric acid, pH 3.2, VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
|
Resolution 1.50 Å R-free 0.255 |
| 2I7S Crystal structure of Re(phen)(CO)3 (Thr124His)(His83Gln) Azurin Cu(II) from Pseudomonas aeruginosa Deposited 2006-08-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
Chain C
21–148（128 aa）
|
Mutation：H83Q, T124H Mutation：H83Q, T124H | CU COPPER (II) ION × 2 REP (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；20% PEG4000, 100 mM LiNO3, 100 mM Imidazole pH 7.0. One fourth of the drop volume was saturated with [Co(NH3)5Cl]Cl2 solution, VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
|
Resolution 1.35 Å R-free 0.239 |
| 2I7S Crystal structure of Re(phen)(CO)3 (Thr124His)(His83Gln) Azurin Cu(II) from Pseudomonas aeruginosa Deposited 2006-08-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain B
21–148（128 aa）
Chain D
21–148（128 aa）
|
Mutation：H83Q, T124H Mutation：H83Q, T124H | CU COPPER (II) ION × 2 REP (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 2 CON COBALT TETRAAMMINE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；20% PEG4000, 100 mM LiNO3, 100 mM Imidazole pH 7.0. One fourth of the drop volume was saturated with [Co(NH3)5Cl]Cl2 solution, VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
|
Resolution 1.35 Å R-free 0.239 |
| 2IDF P. aeruginosa azurin N42C/M64E double mutant, BMME-linked dimer Deposited 2006-09-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
|
Mutation：N42C, M64E Mutation：N42C, M64E | CU COPPER (II) ION × 2 NI NICKEL (II) ION × 2 144 TRIS-HYDROXYMETHYL-METHYL-AMMONIUM × 2 OPP 1-[PYRROL-1-YL-2,5-DIONE-METHOXYMETHYL]-PYRROLE-2,5-DIONE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 9；293 K；25% PEG 2000 MME, 10 mM NiCl2, 100 mM Tris/HCl, pH 9.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.25 Å R-free 0.261 |
| 2IWE Structure of a cavity mutant (H117G) of Pseudomonas aeruginosa azurin Deposited 2006-06-29 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
Chain J
21–148（128 aa）
|
Mutation：YES Mutation：YES | ZN ZINC ION × 2 2IH 1,1'-HEXANE-1,6-DIYLBIS(1H-IMIDAZOLE) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；100 MM TRIS-HCL PH 8.5 AND 20% (W/V) POLYETHYLENE GLYCOL (PEG) 8000
|
Resolution 2.83 Å R-free 0.233 |
| 2IWE Structure of a cavity mutant (H117G) of Pseudomonas aeruginosa azurin Deposited 2006-06-29 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain D
21–148（128 aa）
Chain G
21–148（128 aa）
|
Mutation：YES Mutation：YES | ZN ZINC ION × 2 2IH 1,1'-HEXANE-1,6-DIYLBIS(1H-IMIDAZOLE) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；100 MM TRIS-HCL PH 8.5 AND 20% (W/V) POLYETHYLENE GLYCOL (PEG) 8000
|
Resolution 2.83 Å R-free 0.233 |
| 2OJ1 Disulfide-linked dimer of azurin N42C/M64E double mutant Deposited 2007-01-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：N42C, M64E | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 3.1；293 K；30 % PEG 4000, 0.1M sodium citrate buffer, pH 3.1, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.30 Å R-free 0.281 |
| 2OJ1 Disulfide-linked dimer of azurin N42C/M64E double mutant Deposited 2007-01-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：N42C, M64E | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 3.1；293 K；30 % PEG 4000, 0.1M sodium citrate buffer, pH 3.1, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.30 Å R-free 0.281 |
| 2TSA AZURIN MUTANT M121A Deposited 1996-05-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
Chain C
21–148（128 aa）
Chain D
21–148（128 aa）
|
Mutation：M121A Mutation：M121A Mutation：M121A Mutation：M121A | CU COPPER (II) ION × 4 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.20 Å |
| 2TSB AZURIN MUTANT M121A-AZIDE Deposited 1996-05-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
Chain C
21–148（128 aa）
Chain D
21–148（128 aa）
|
Mutation：M121A Mutation：M121A Mutation：M121A Mutation：M121A | AZI AZIDE ION × 4 CU COPPER (II) ION × 4 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 2XV0 Pseudomonas aeruginosa Azurin with mutated metal-binding loop sequence (CAAHAAM), chemically reduced, pH4.8 Deposited 2010-10-22 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：YES | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.8；293 K；0.1M POTASSIUM THIOCYANATE, 30% PEG2000, PH 7.0, VAPOR DIFFUSION, HANGING DROP, TEMPERATURE 293K
|
Resolution 1.60 Å R-free 0.199 |
| 2XV2 Pseudomonas aeruginosa Azurin with mutated metal-binding loop sequence (CAAHAAM), chemically reduced, pH4.2 Deposited 2010-10-22 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：YES | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.2；293 K；0.1M POTASSIUM THIOCYANATE, 30% PEG2000, PH 7.0, VAPOR DIFFUSION, HANGING DROP, TEMPERATURE 293K
|
Resolution 1.60 Å R-free 0.200 |
| 2XV3 Pseudomonas aeruginosa Azurin with mutated metal-binding loop sequence (CAAAAHAAAAM), chemically reduced, pH5.3 Deposited 2010-10-22 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：YES | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.3；293 K；10MM TRI-SODIUM CITRATE, 33% PEG6000, PH 7.6, VAPOR DIFFUSION, HANGING DROP, TEMPERATURE 293K
|
Resolution 2.30 Å R-free 0.266 |
| 2XV3 Pseudomonas aeruginosa Azurin with mutated metal-binding loop sequence (CAAAAHAAAAM), chemically reduced, pH5.3 Deposited 2010-10-22 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：YES | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.3；293 K；10MM TRI-SODIUM CITRATE, 33% PEG6000, PH 7.6, VAPOR DIFFUSION, HANGING DROP, TEMPERATURE 293K
|
Resolution 2.30 Å R-free 0.266 |
| 3AZU X-RAY CRYSTAL STRUCTURE OF THE TWO SITE-SPECIFIC MUTANTS HIS35GLN AND HIS35LEU OF AZURIN FROM PSEUDOMONAS AERUGINOSA Deposited 1991-01-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
Chain C
21–148（128 aa）
Chain D
21–148（128 aa）
|
Mutation：H35Q Mutation：H35Q Mutation：H35Q Mutation：H35Q | CU COPPER (II) ION × 4 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.10 Å |
| 3FPY Azurin C112D/M121L Deposited 2009-01-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：C112D, M121L | CU COPPER (II) ION × 2 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；298 K；25% PEG 4000, 0.1 M sodium acetate pH 5.6, 0.1 M tris pH 8, 0.1 M lithium nitrate, 0.01 M copper(II) sulfate, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 2.10 Å R-free 0.236 |
| 3FQ1 Azurin C112D/M121I Deposited 2009-01-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：C112D, M121I | CU COPPER (II) ION × 2 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；298 K；25% PEG 4000, 0.1M sodium acetate pH 5.6, 0.1 M tris pH 8, 0.1 M lithium nitrate, 0.01 M copper(II) sulfate, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.256 |
| 3FQ2 Azurin C112D/M121F Deposited 2009-01-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：C112D, M121F | CU COPPER (II) ION × 2 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；298 K；25% PEG 4000, 0.1 M sodium acetate pH 5.6, 0.1 M tris pH 8, 0.1 M lithium nitrate, 0.01 M copper(II) sulfate, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.91 Å R-free 0.245 |
| 3FQY Azurin C112D Deposited 2009-01-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：C112D | CU COPPER (II) ION × 2 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；298 K；25% PEG 4000, 0.1M sodium acetate pH 5.6, 0.1 M tris pH 8, 0.1 M lithium nitrate, 0.01 M copper(II) sulfate, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.244 |
| 3FS9 Pseudomonas aeruginosa Azurin with mutated metal-binding loop sequence (CAAHAAM) Deposited 2009-01-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；0.1M potassium thiocyanate, 30% PEG 2000, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.05 Å R-free 0.145 |
| 3FSA Pseudomonas aeruginosa Azurin with mutated metal-binding loop sequence (CAAHAAM); chemically reduced. Deposited 2009-01-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；0.1M potassium thiocyanate, 30% PEG 2000, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 0.98 Å R-free 0.135 |
| 3FSV Pseudomonas aeruginosa Azurin with mutated metal-binding loop sequence (CAAAHAAAM) Deposited 2009-01-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；150mM potassium bromide, 30% PEG MME 2000, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.30 Å R-free 0.308 |
| 3FSV Pseudomonas aeruginosa Azurin with mutated metal-binding loop sequence (CAAAHAAAM) Deposited 2009-01-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；150mM potassium bromide, 30% PEG MME 2000, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.30 Å R-free 0.308 |
| 3FSW Pseudomonas aeruginosa Azurin with mutated metal-binding loop sequence (CAAAAHAAAM) Deposited 2009-01-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；100mM Hepes pH 8.0, 34% PEG 4000, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.256 |
| 3FSW Pseudomonas aeruginosa Azurin with mutated metal-binding loop sequence (CAAAAHAAAM) Deposited 2009-01-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；100mM Hepes pH 8.0, 34% PEG 4000, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.256 |
| 3FSW Pseudomonas aeruginosa Azurin with mutated metal-binding loop sequence (CAAAAHAAAM) Deposited 2009-01-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；100mM Hepes pH 8.0, 34% PEG 4000, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.256 |
| 3FSW Pseudomonas aeruginosa Azurin with mutated metal-binding loop sequence (CAAAAHAAAM) Deposited 2009-01-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；100mM Hepes pH 8.0, 34% PEG 4000, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.256 |
| 3FSZ Pseudomonas aeruginosa Azurin with mutated metal-binding loop sequence (CAAAAHAAAAM) Deposited 2009-01-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.6；293 K；10mM tri-sodium citrate, 33% PEG 6000, pH 7.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.255 |
| 3FSZ Pseudomonas aeruginosa Azurin with mutated metal-binding loop sequence (CAAAAHAAAAM) Deposited 2009-01-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.6；293 K；10mM tri-sodium citrate, 33% PEG 6000, pH 7.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.255 |
| 3FT0 Pseudomonas aeruginosa Azurin with mutated metal-binding loop sequence (CAAAAHAAAAM), chemically reduced Deposited 2009-01-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.6；293 K；10mM tri-sodium citrate, 33% PEG 6000, pH 7.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.80 Å R-free 0.250 |
| 3FT0 Pseudomonas aeruginosa Azurin with mutated metal-binding loop sequence (CAAAAHAAAAM), chemically reduced Deposited 2009-01-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Not recorded | CU1 COPPER (I) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.6；293 K；10mM tri-sodium citrate, 33% PEG 6000, pH 7.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.80 Å R-free 0.250 |
| 3IBO Pseudomonas aeruginosa E2Q/H83Q/T126H-azurin RE(PHEN)(CO)3 Deposited 2009-07-16 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：E2Q, H83Q, T126H | CU COPPER (II) ION × 1 REP (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；20% PEG4000, 100 MM LINO3, 100 MM IMIDAZOLE, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.45 Å R-free 0.217 |
| 3IBO Pseudomonas aeruginosa E2Q/H83Q/T126H-azurin RE(PHEN)(CO)3 Deposited 2009-07-16 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：E2Q, H83Q, T126H | CU COPPER (II) ION × 1 REP (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；20% PEG4000, 100 MM LINO3, 100 MM IMIDAZOLE, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.45 Å R-free 0.217 |
| 3IBO Pseudomonas aeruginosa E2Q/H83Q/T126H-azurin RE(PHEN)(CO)3 Deposited 2009-07-16 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Mutation：E2Q, H83Q, T126H | CU COPPER (II) ION × 1 REP (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；20% PEG4000, 100 MM LINO3, 100 MM IMIDAZOLE, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.45 Å R-free 0.217 |
| 3IBO Pseudomonas aeruginosa E2Q/H83Q/T126H-azurin RE(PHEN)(CO)3 Deposited 2009-07-16 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
|
Mutation：E2Q, H83Q, T126H | CU COPPER (II) ION × 1 REP (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；20% PEG4000, 100 MM LINO3, 100 MM IMIDAZOLE, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.45 Å R-free 0.217 |
| 3IN0 Crystal structure of the F114P/M121Q variant of Pseudomonas aeruginosa azurin in the Cu(II) state Deposited 2009-08-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：F114P, M121Q | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；PEG 8000, 0.08M NaOAc, 0.2M Lithium nitrate, 0.2M Calcium chloride, pH 6.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.35 Å R-free 0.286 |
| 3IN0 Crystal structure of the F114P/M121Q variant of Pseudomonas aeruginosa azurin in the Cu(II) state Deposited 2009-08-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：F114P, M121Q | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；PEG 8000, 0.08M NaOAc, 0.2M Lithium nitrate, 0.2M Calcium chloride, pH 6.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.35 Å R-free 0.286 |
| 3IN0 Crystal structure of the F114P/M121Q variant of Pseudomonas aeruginosa azurin in the Cu(II) state Deposited 2009-08-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Mutation：F114P, M121Q | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；PEG 8000, 0.08M NaOAc, 0.2M Lithium nitrate, 0.2M Calcium chloride, pH 6.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.35 Å R-free 0.286 |
| 3IN0 Crystal structure of the F114P/M121Q variant of Pseudomonas aeruginosa azurin in the Cu(II) state Deposited 2009-08-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
|
Mutation：F114P, M121Q | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；PEG 8000, 0.08M NaOAc, 0.2M Lithium nitrate, 0.2M Calcium chloride, pH 6.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.35 Å R-free 0.286 |
| 3IN2 Crystal structure of the N47S/M121L variant of Pseudomonas aeruginosa azurin in the Cu(II) state Deposited 2009-08-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：N47S, M121L | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；PEG 8000, 0.08M NaOAc, 0.2M Lithium nitrate, 0.2M Calcium chloride, pH 6.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.60 Å R-free 0.266 |
| 3JT2 Cu(II) N47S/M121L variant of Pseudomonas Aeruginosa azurin Deposited 2009-09-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：N47S, M121L | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；80mM sodium acetate, 0.24M calcium chloride, 0.24M lithium nitrate, 25% PEG 8000, pH 6.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.10 Å R-free 0.288 |
| 3JT2 Cu(II) N47S/M121L variant of Pseudomonas Aeruginosa azurin Deposited 2009-09-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：N47S, M121L | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；80mM sodium acetate, 0.24M calcium chloride, 0.24M lithium nitrate, 25% PEG 8000, pH 6.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.10 Å R-free 0.288 |
| 3JTB Cu(II) N47S/F114N variant of Pseudomonas Aeruginosa Azurin Deposited 2009-09-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：N47S, F114N | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；80mM sodium acetate, 0.24M calcium chloride, 0.24M lithium nitrate, 25% PEG 8000, pH 6.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 1.80 Å R-free 0.259 |
| 3JTB Cu(II) N47S/F114N variant of Pseudomonas Aeruginosa Azurin Deposited 2009-09-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：N47S, F114N | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；80mM sodium acetate, 0.24M calcium chloride, 0.24M lithium nitrate, 25% PEG 8000, pH 6.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 1.80 Å R-free 0.259 |
| 3JTB Cu(II) N47S/F114N variant of Pseudomonas Aeruginosa Azurin Deposited 2009-09-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Mutation：N47S, F114N | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；80mM sodium acetate, 0.24M calcium chloride, 0.24M lithium nitrate, 25% PEG 8000, pH 6.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 1.80 Å R-free 0.259 |
| 3JTB Cu(II) N47S/F114N variant of Pseudomonas Aeruginosa Azurin Deposited 2009-09-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
|
Mutation：N47S, F114N | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；80mM sodium acetate, 0.24M calcium chloride, 0.24M lithium nitrate, 25% PEG 8000, pH 6.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 1.80 Å R-free 0.259 |
| 3N2J Azurin H117G, oxidized form Deposited 2010-05-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.7；293 K；31 % PEG 2000 MME
0.1 M Tris/HCl pH 8.7
, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.35 Å R-free 0.202 |
| 3N2J Azurin H117G, oxidized form Deposited 2010-05-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 10 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain J
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.7；293 K；31 % PEG 2000 MME
0.1 M Tris/HCl pH 8.7
, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.35 Å R-free 0.202 |
| 3N2J Azurin H117G, oxidized form Deposited 2010-05-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 11 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain K
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.7；293 K；31 % PEG 2000 MME
0.1 M Tris/HCl pH 8.7
, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.35 Å R-free 0.202 |
| 3N2J Azurin H117G, oxidized form Deposited 2010-05-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 12 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain L
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.7；293 K；31 % PEG 2000 MME
0.1 M Tris/HCl pH 8.7
, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.35 Å R-free 0.202 |
| 3N2J Azurin H117G, oxidized form Deposited 2010-05-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.7；293 K；31 % PEG 2000 MME
0.1 M Tris/HCl pH 8.7
, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.35 Å R-free 0.202 |
| 3N2J Azurin H117G, oxidized form Deposited 2010-05-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.7；293 K；31 % PEG 2000 MME
0.1 M Tris/HCl pH 8.7
, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.35 Å R-free 0.202 |
| 3N2J Azurin H117G, oxidized form Deposited 2010-05-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.7；293 K；31 % PEG 2000 MME
0.1 M Tris/HCl pH 8.7
, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.35 Å R-free 0.202 |
| 3N2J Azurin H117G, oxidized form Deposited 2010-05-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 5 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain E
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.7；293 K；31 % PEG 2000 MME
0.1 M Tris/HCl pH 8.7
, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.35 Å R-free 0.202 |
| 3N2J Azurin H117G, oxidized form Deposited 2010-05-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 6 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain F
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.7；293 K；31 % PEG 2000 MME
0.1 M Tris/HCl pH 8.7
, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.35 Å R-free 0.202 |
| 3N2J Azurin H117G, oxidized form Deposited 2010-05-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 7 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain G
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.7；293 K；31 % PEG 2000 MME
0.1 M Tris/HCl pH 8.7
, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.35 Å R-free 0.202 |
| 3N2J Azurin H117G, oxidized form Deposited 2010-05-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 8 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain H
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.7；293 K；31 % PEG 2000 MME
0.1 M Tris/HCl pH 8.7
, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.35 Å R-free 0.202 |
| 3N2J Azurin H117G, oxidized form Deposited 2010-05-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 9 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain I
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.7；293 K；31 % PEG 2000 MME
0.1 M Tris/HCl pH 8.7
, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.35 Å R-free 0.202 |
| 3NP3 C112D/M121E Pseudomonas Aeruginosa Azurin Deposited 2010-06-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：C112D, M121E | CU COPPER (II) ION × 2 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；298 K；25-30% PEG 4000
100 mM LiNO3
20 mM CuCl2
100 mM Tris pH 7, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 2.10 Å R-free 0.265 |
| 3NP4 C112D/M121E Pseudomonas aeruginosa Azurin Deposited 2010-06-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：C112D, M121E | CU COPPER (II) ION × 2 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；298 K；25-30% PEG 4000
100 mM LiNO3
20 mM CuCl2
100 mM Tris pH 7, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 2.25 Å R-free 0.276 |
| 3OQR C112D/M121E Azurin, pH 10.0 Deposited 2010-09-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：C112D, M121E | CU COPPER (II) ION × 2 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；298 K；25% PEG 4000, 0.1 M sodium acetate pH 5.6, 0.1 M tris pH 8, 0.1 M lithium nitrate, 0.01 M copper(II) chloride, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 2.40 Å R-free 0.331 |
| 3U25 Crystal structure of P. aeruginoas azurin containing a Tyr-His hydrogen bonded pair Deposited 2011-09-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–148（127 aa）
Fragment：unp residues 22-148
|
Mutation：H40I, Y48W, F72Y, F108Y | CU COPPER (II) ION × 1 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；298 K；25-30% of poly(ethylene glycol) (PEG) 4000, 100 mM lithium nitrate, 10 mM copper sulfate and 100 mM Tris HCl, pH 8, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.18 Å R-free 0.217 |
| 3U25 Crystal structure of P. aeruginoas azurin containing a Tyr-His hydrogen bonded pair Deposited 2011-09-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–148（127 aa）
Fragment：unp residues 22-148
|
Mutation：H40I, Y48W, F72Y, F108Y | CU COPPER (II) ION × 1 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；298 K；25-30% of poly(ethylene glycol) (PEG) 4000, 100 mM lithium nitrate, 10 mM copper sulfate and 100 mM Tris HCl, pH 8, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.18 Å R-free 0.217 |
| 3UGE Silver Metallated Pseudomonas aeruginosa Azurin at 1.70 A Deposited 2011-11-02 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
Fragment：UNP residues 21-148
|
Not recorded | AG SILVER ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；298 K；3.2 M ammonium sulfate, 0.5 M lithium nitrate, 50 mM sodium acetate, pH 5.5, soaked with 1 mM silver nitrate, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.70 Å R-free 0.245 |
| 3UGE Silver Metallated Pseudomonas aeruginosa Azurin at 1.70 A Deposited 2011-11-02 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
Fragment：UNP residues 21-148
|
Not recorded | AG SILVER ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；298 K；3.2 M ammonium sulfate, 0.5 M lithium nitrate, 50 mM sodium acetate, pH 5.5, soaked with 1 mM silver nitrate, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.70 Å R-free 0.245 |
| 3UGE Silver Metallated Pseudomonas aeruginosa Azurin at 1.70 A Deposited 2011-11-02 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
Fragment：UNP residues 21-148
|
Not recorded | AG SILVER ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；298 K；3.2 M ammonium sulfate, 0.5 M lithium nitrate, 50 mM sodium acetate, pH 5.5, soaked with 1 mM silver nitrate, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.70 Å R-free 0.245 |
| 3UGE Silver Metallated Pseudomonas aeruginosa Azurin at 1.70 A Deposited 2011-11-02 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
Fragment：UNP residues 21-148
|
Not recorded | AG SILVER ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；298 K；3.2 M ammonium sulfate, 0.5 M lithium nitrate, 50 mM sodium acetate, pH 5.5, soaked with 1 mM silver nitrate, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.70 Å R-free 0.245 |
| 4AZU CRYSTAL STRUCTURE ANALYSIS OF OXIDIZED PSEUDOMONAS AERUGINOSA AZURIN AT PH 5.5 AND PH 9.0. A PH-INDUCED CONFORMATIONAL TRANSITION INVOLVES A PEPTIDE BOND FLIP Deposited 1993-06-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
Chain C
21–148（128 aa）
Chain D
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 4 NO3 NITRATE ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.90 Å |
| 4BWW Crystal structure of spin labelled azurin T21R1. Deposited 2013-07-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
Chain C
21–148（128 aa）
Chain D
21–148（128 aa）
|
Mutation：YES Non-standard monomer：Yes (specific site not provided by mmCIF) Mutation：YES Non-standard monomer：Yes (specific site not provided by mmCIF) Mutation：YES Non-standard monomer：Yes (specific site not provided by mmCIF) Mutation：YES Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 4 GOL GLYCEROL × 8 NO3 NITRATE ION × 5 SO4 SULFATE ION × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
2.14 M AMMONIUM SULFATE, 0.28 M AMMONIUM NITRATE, 0.1 M SODIUM CACODYLATE PH 6.0
|
Resolution 1.48 Å R-free 0.210 |
| 4HHG Crystal structure of the Pseudomonas aeruginosa azurin, RuH107NO YOH109 Deposited 2012-10-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：W68F,Y92F,H103Q,Y128F,M129NIY,Q127H Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 DRU DELTA-BIS(2,2'-BIPYRIDINE)IMIDAZOLE RUTHENIUM (II) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.2；293.15 K；26-34% PEG 4000, 100mM Lithium Nitrate, 6.25mM Copper Sulfate and 100 mM Imidazole, pH 7.2, VAPOR DIFFUSION, SITTING DROP, temperature 293.15K
|
Resolution 1.60 Å R-free 0.261 |
| 4HHG Crystal structure of the Pseudomonas aeruginosa azurin, RuH107NO YOH109 Deposited 2012-10-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
|
Mutation：W68F,Y92F,H103Q,Y128F,M129NIY,Q127H Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 2 DRU DELTA-BIS(2,2'-BIPYRIDINE)IMIDAZOLE RUTHENIUM (II) × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.2；293.15 K；26-34% PEG 4000, 100mM Lithium Nitrate, 6.25mM Copper Sulfate and 100 mM Imidazole, pH 7.2, VAPOR DIFFUSION, SITTING DROP, temperature 293.15K
|
Resolution 1.60 Å R-free 0.261 |
| 4HHW Crystal structure of the Pseudomonas aeruginosa azurin, H124NO YOH122 Deposited 2012-10-10 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：W68F,Y92F,H103Q,Y128F,K142NIY,T144H Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.2；293.15 K；26-34% PEG 4000, 100 mM Lithium Nitrate, 6.25 mM Copper Sulfate and 100 mM Imidazole, pH 7.2, VAPOR DIFFUSION, SITTING DROP, temperature 293.15K
|
Resolution 2.00 Å R-free 0.281 |
| 4HHW Crystal structure of the Pseudomonas aeruginosa azurin, H124NO YOH122 Deposited 2012-10-10 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：W68F,Y92F,H103Q,Y128F,K142NIY,T144H Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.2；293.15 K；26-34% PEG 4000, 100 mM Lithium Nitrate, 6.25 mM Copper Sulfate and 100 mM Imidazole, pH 7.2, VAPOR DIFFUSION, SITTING DROP, temperature 293.15K
|
Resolution 2.00 Å R-free 0.281 |
| 4HHW Crystal structure of the Pseudomonas aeruginosa azurin, H124NO YOH122 Deposited 2012-10-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
|
Mutation：W68F,Y92F,H103Q,Y128F,K142NIY,T144H Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.2；293.15 K；26-34% PEG 4000, 100 mM Lithium Nitrate, 6.25 mM Copper Sulfate and 100 mM Imidazole, pH 7.2, VAPOR DIFFUSION, SITTING DROP, temperature 293.15K
|
Resolution 2.00 Å R-free 0.281 |
| 4HHW Crystal structure of the Pseudomonas aeruginosa azurin, H124NO YOH122 Deposited 2012-10-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain B
21–148（128 aa）
|
Mutation：W68F,Y92F,H103Q,Y128F,K142NIY,T144H Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.2；293.15 K；26-34% PEG 4000, 100 mM Lithium Nitrate, 6.25 mM Copper Sulfate and 100 mM Imidazole, pH 7.2, VAPOR DIFFUSION, SITTING DROP, temperature 293.15K
|
Resolution 2.00 Å R-free 0.281 |
| 4HIP Crystal structure of the Pseudomonas aeruginosa azurin, H126NO YOH109 Deposited 2012-10-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：W68F,Y92F,H103Q,Y128F,K142NIY,T146H Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.2；293.15 K；26-34% PEG 4000, 100 mM Lithium Nitrate, 6.25 mM Copper Sulfate and 100 mM Imidazole, pH 7.2, VAPOR DIFFUSION, SITTING DROP, temperature 293.15K
|
Resolution 1.90 Å R-free 0.317 |
| 4HIP Crystal structure of the Pseudomonas aeruginosa azurin, H126NO YOH109 Deposited 2012-10-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：W68F,Y92F,H103Q,Y128F,K142NIY,T146H Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.2；293.15 K；26-34% PEG 4000, 100 mM Lithium Nitrate, 6.25 mM Copper Sulfate and 100 mM Imidazole, pH 7.2, VAPOR DIFFUSION, SITTING DROP, temperature 293.15K
|
Resolution 1.90 Å R-free 0.317 |
| 4HIP Crystal structure of the Pseudomonas aeruginosa azurin, H126NO YOH109 Deposited 2012-10-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
|
Mutation：W68F,Y92F,H103Q,Y128F,K142NIY,T146H Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.2；293.15 K；26-34% PEG 4000, 100 mM Lithium Nitrate, 6.25 mM Copper Sulfate and 100 mM Imidazole, pH 7.2, VAPOR DIFFUSION, SITTING DROP, temperature 293.15K
|
Resolution 1.90 Å R-free 0.317 |
| 4HIP Crystal structure of the Pseudomonas aeruginosa azurin, H126NO YOH109 Deposited 2012-10-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain B
21–148（128 aa）
|
Mutation：W68F,Y92F,H103Q,Y128F,K142NIY,T146H Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.2；293.15 K；26-34% PEG 4000, 100 mM Lithium Nitrate, 6.25 mM Copper Sulfate and 100 mM Imidazole, pH 7.2, VAPOR DIFFUSION, SITTING DROP, temperature 293.15K
|
Resolution 1.90 Å R-free 0.317 |
| 4HZ1 Crystal Structure of Pseudomonas aeruginosa azurin with iron(II) at the copper-binding site. Deposited 2012-11-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | ACT ACETATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；300 K；3.0 - 3.5 M ammonium sulfate, 0.5 M lithium nitrate, 0.1 M sodium acetate pH 5.2-5.4, VAPOR DIFFUSION, HANGING DROP, temperature 300K
|
Resolution 2.20 Å R-free 0.277 |
| 4HZ1 Crystal Structure of Pseudomonas aeruginosa azurin with iron(II) at the copper-binding site. Deposited 2012-11-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Not recorded | ACT ACETATE ION × 1 FE2 FE (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；300 K；3.0 - 3.5 M ammonium sulfate, 0.5 M lithium nitrate, 0.1 M sodium acetate pH 5.2-5.4, VAPOR DIFFUSION, HANGING DROP, temperature 300K
|
Resolution 2.20 Å R-free 0.277 |
| 4HZ1 Crystal Structure of Pseudomonas aeruginosa azurin with iron(II) at the copper-binding site. Deposited 2012-11-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Not recorded | ACT ACETATE ION × 1 FE2 FE (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；300 K；3.0 - 3.5 M ammonium sulfate, 0.5 M lithium nitrate, 0.1 M sodium acetate pH 5.2-5.4, VAPOR DIFFUSION, HANGING DROP, temperature 300K
|
Resolution 2.20 Å R-free 0.277 |
| 4HZ1 Crystal Structure of Pseudomonas aeruginosa azurin with iron(II) at the copper-binding site. Deposited 2012-11-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；300 K；3.0 - 3.5 M ammonium sulfate, 0.5 M lithium nitrate, 0.1 M sodium acetate pH 5.2-5.4, VAPOR DIFFUSION, HANGING DROP, temperature 300K
|
Resolution 2.20 Å R-free 0.277 |
| 4JKN Mercury Metallated Pseudomonas aeruginosa Azurin at 1.54 A Deposited 2013-03-10 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
Fragment：UNP residues 21-148
|
Not recorded | HG MERCURY (II) ION × 2 NO3 NITRATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；298 K；3.2 M ammonium sulfate, 0.5 M lithium nitrate, 50 mM sodium acetate, pH 5.5, soaked with 3 fold excess Mercury Chloride , VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.54 Å R-free 0.239 |
| 4JKN Mercury Metallated Pseudomonas aeruginosa Azurin at 1.54 A Deposited 2013-03-10 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
Fragment：UNP residues 21-148
|
Not recorded | HG MERCURY (II) ION × 1 NO3 NITRATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；298 K；3.2 M ammonium sulfate, 0.5 M lithium nitrate, 50 mM sodium acetate, pH 5.5, soaked with 3 fold excess Mercury Chloride , VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.54 Å R-free 0.239 |
| 4JKN Mercury Metallated Pseudomonas aeruginosa Azurin at 1.54 A Deposited 2013-03-10 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
Fragment：UNP residues 21-148
|
Not recorded | HG MERCURY (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；298 K；3.2 M ammonium sulfate, 0.5 M lithium nitrate, 50 mM sodium acetate, pH 5.5, soaked with 3 fold excess Mercury Chloride , VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.54 Å R-free 0.239 |
| 4JKN Mercury Metallated Pseudomonas aeruginosa Azurin at 1.54 A Deposited 2013-03-10 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
Fragment：UNP residues 21-148
|
Not recorded | HG MERCURY (II) ION × 1 NO3 NITRATE ION × 4 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；298 K；3.2 M ammonium sulfate, 0.5 M lithium nitrate, 50 mM sodium acetate, pH 5.5, soaked with 3 fold excess Mercury Chloride , VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.54 Å R-free 0.239 |
| 4K9J Structure of Re(CO)3(4,7-dimethyl-phen)(Thr126His)(Lys122Trp)(His83Glu)(Trp48Phe)(Tyr72Phe)(Tyr108Phe)AzCu(II), a Rhenium modified Azurin mutant Deposited 2013-04-20 | Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：t126H, k122w, h83e,w48f, y72f | CU COPPER (II) ION × 1 REQ (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.4；298 K；protein buffer:40 mM imidazole, 2 mM NaCl. Reservoir: 100 mM imidazole, 100 mM LiNO3, 6.25 mM CuCl2, 27% PEG 4000, pH 7.4, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 1.70 Å R-free 0.236 |
| 4KO5 Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V31I/W48L/V95I/Y108F) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V31I/W48L/V95I/Y108F | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.79 Å R-free 0.240 |
| 4KO5 Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V31I/W48L/V95I/Y108F) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V31I/W48L/V95I/Y108F | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.79 Å R-free 0.240 |
| 4KO6 Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V31I/V95K/Y108F) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V31I/V95K/Y108F | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.74 Å R-free 0.273 |
| 4KO6 Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V31I/V95K/Y108F) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V31I/V95K/Y108F | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.74 Å R-free 0.273 |
| 4KO6 Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V31I/V95K/Y108F) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V31I/V95K/Y108F | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.74 Å R-free 0.273 |
| 4KO6 Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V31I/V95K/Y108F) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V31I/V95K/Y108F | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.74 Å R-free 0.273 |
| 4KO7 Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V31I/W48F/V95I) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V31I/W48F/V95I | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.07 Å R-free 0.266 |
| 4KO7 Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V31I/W48F/V95I) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V31I/W48F/V95I | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.07 Å R-free 0.266 |
| 4KO7 Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V31I/W48F/V95I) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V31I/W48F/V95I | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.07 Å R-free 0.266 |
| 4KO7 Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V31I/W48F/V95I) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V31I/W48F/V95I | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.07 Å R-free 0.266 |
| 4KO9 Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V95I/Y108F) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V95I/Y108F | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.05 Å R-free 0.226 |
| 4KO9 Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V95I/Y108F) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V95I/Y108F | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.05 Å R-free 0.226 |
| 4KO9 Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V95I/Y108F) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V95I/Y108F | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.05 Å R-free 0.226 |
| 4KO9 Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V95I/Y108F) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V95I/Y108F | CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.05 Å R-free 0.226 |
| 4KOB Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V31I/V95I) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V31I/V95I | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.87 Å R-free 0.226 |
| 4KOB Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V31I/V95I) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V31I/V95I | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.87 Å R-free 0.226 |
| 4KOB Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V31I/V95I) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V31I/V95I | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.87 Å R-free 0.226 |
| 4KOB Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V31I/V95I) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V31I/V95I | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.87 Å R-free 0.226 |
| 4KOC Investigating the functional significance of the interlocked pair structural determinants in Pseudomonas aeruginosa azurin (V31I/V95I/Y108F) Deposited 2013-05-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：V31I/V95I/Y108F | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；100 mM Tris-HCl, 100 mM lithium nitrate, 10 mM copper sulfate, 30% PEG4000, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 1.46 Å R-free 0.238 |
| 4MFH Crystal Structure of M121G Azurin Deposited 2013-08-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：M121G | CU COPPER (II) ION × 2 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；2 UL droplet containing 1 UL apo-M121G azurin (1.3 mM) in 100 mM NaOAc pH 5.6 buffer and 1 UL PEG buffer (25% PEG 4000 containing 100 mM LiNO3, 10 mM CuSO4 and 100 mM Tris pH 8.0) above 250 UL well buffer (25% PEG 4000 containing 100 mM LiNO3 10 mM CuSO4 and 100 mM Tris pH 8.0), VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 1.54 Å R-free 0.194 |
| 4MFH Crystal Structure of M121G Azurin Deposited 2013-08-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：M121G | CU COPPER (II) ION × 2 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；2 UL droplet containing 1 UL apo-M121G azurin (1.3 mM) in 100 mM NaOAc pH 5.6 buffer and 1 UL PEG buffer (25% PEG 4000 containing 100 mM LiNO3, 10 mM CuSO4 and 100 mM Tris pH 8.0) above 250 UL well buffer (25% PEG 4000 containing 100 mM LiNO3 10 mM CuSO4 and 100 mM Tris pH 8.0), VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 1.54 Å R-free 0.194 |
| 4MFH Crystal Structure of M121G Azurin Deposited 2013-08-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Mutation：M121G | CU COPPER (II) ION × 2 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；2 UL droplet containing 1 UL apo-M121G azurin (1.3 mM) in 100 mM NaOAc pH 5.6 buffer and 1 UL PEG buffer (25% PEG 4000 containing 100 mM LiNO3, 10 mM CuSO4 and 100 mM Tris pH 8.0) above 250 UL well buffer (25% PEG 4000 containing 100 mM LiNO3 10 mM CuSO4 and 100 mM Tris pH 8.0), VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 1.54 Å R-free 0.194 |
| 4QKT Azurin mutant M121EM44K with copper Deposited 2014-06-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：M121E, M44K | CU COPPER (II) ION × 3 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；278 K；pH8.0 100mM LiNO3 100 mM Tris 25%PEG4000 1:1 mixing-medium, VAPOR DIFFUSION, HANGING DROP, temperature 278K
|
Resolution 1.64 Å R-free 0.216 |
| 4QKT Azurin mutant M121EM44K with copper Deposited 2014-06-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：M121E, M44K | CU COPPER (II) ION × 3 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 ACT ACETATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；278 K；pH8.0 100mM LiNO3 100 mM Tris 25%PEG4000 1:1 mixing-medium, VAPOR DIFFUSION, HANGING DROP, temperature 278K
|
Resolution 1.64 Å R-free 0.216 |
| 4QLW Azurin mutant M121E with iron Deposited 2014-06-13 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：M121E | SO4 SULFATE ION × 2 NO3 NITRATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.3；278 K；(NH4)2SO4 (3.25 M), LiNO3 (0.1 M), NaOAc (0.1 M), pH 5.3, VAPOR DIFFUSION, HANGING DROP, temperature 278K
|
Resolution 2.00 Å R-free 0.262 |
| 4QLW Azurin mutant M121E with iron Deposited 2014-06-13 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：M121E | NO3 NITRATE ION × 2 FE FE (III) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.3；278 K；(NH4)2SO4 (3.25 M), LiNO3 (0.1 M), NaOAc (0.1 M), pH 5.3, VAPOR DIFFUSION, HANGING DROP, temperature 278K
|
Resolution 2.00 Å R-free 0.262 |
| 4QLW Azurin mutant M121E with iron Deposited 2014-06-13 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Mutation：M121E | SO4 SULFATE ION × 1 NO3 NITRATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.3；278 K；(NH4)2SO4 (3.25 M), LiNO3 (0.1 M), NaOAc (0.1 M), pH 5.3, VAPOR DIFFUSION, HANGING DROP, temperature 278K
|
Resolution 2.00 Å R-free 0.262 |
| 4QLW Azurin mutant M121E with iron Deposited 2014-06-13 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
|
Mutation：M121E | NO3 NITRATE ION × 2 FE FE (III) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.3；278 K；(NH4)2SO4 (3.25 M), LiNO3 (0.1 M), NaOAc (0.1 M), pH 5.3, VAPOR DIFFUSION, HANGING DROP, temperature 278K
|
Resolution 2.00 Å R-free 0.262 |
| 4QLW Azurin mutant M121E with iron Deposited 2014-06-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 5 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
Chain C
21–148（128 aa）
Chain D
21–148（128 aa）
|
Mutation：M121E Mutation：M121E Mutation：M121E Mutation：M121E | SO4 SULFATE ION × 3 NO3 NITRATE ION × 10 FE FE (III) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.3；278 K；(NH4)2SO4 (3.25 M), LiNO3 (0.1 M), NaOAc (0.1 M), pH 5.3, VAPOR DIFFUSION, HANGING DROP, temperature 278K
|
Resolution 2.00 Å R-free 0.262 |
| 4WKX Reversible S-Nitrosylation in an Engineered Mutant of Pseudomonas aeruginosa Azurin with Red Copper Site Deposited 2014-10-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Mutation：H66E, M141H | CU COPPER (II) ION × 2 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；277 K；25% PEG 4000, 100 mM LiNO3, 10 mM CuSO4 and 100 mM Tris
|
Resolution 1.94 Å R-free 0.235 |
| 4WKX Reversible S-Nitrosylation in an Engineered Mutant of Pseudomonas aeruginosa Azurin with Red Copper Site Deposited 2014-10-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Mutation：H66E, M141H | CU COPPER (II) ION × 2 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；277 K；25% PEG 4000, 100 mM LiNO3, 10 mM CuSO4 and 100 mM Tris
|
Resolution 1.94 Å R-free 0.235 |
| 4WKX Reversible S-Nitrosylation in an Engineered Mutant of Pseudomonas aeruginosa Azurin with Red Copper Site Deposited 2014-10-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
|
Mutation：H66E, M141H Mutation：H66E, M141H | CU COPPER (II) ION × 4 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；277 K；25% PEG 4000, 100 mM LiNO3, 10 mM CuSO4 and 100 mM Tris
|
Resolution 1.94 Å R-free 0.235 |
| 5AZU CRYSTAL STRUCTURE ANALYSIS OF OXIDIZED PSEUDOMONAS AERUGINOSA AZURIN AT PH 5.5 AND PH 9.0. A PH-INDUCED CONFORMATIONAL TRANSITION INVOLVES A PEPTIDE BOND FLIP Deposited 1993-06-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
Chain C
21–148（128 aa）
Chain D
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 4 NO3 NITRATE ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.90 Å |
| 5I26 Azurin T30R1, crystal form I Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；Sodium malonate
|
Resolution 1.89 Å R-free 0.240 |
| 5I26 Azurin T30R1, crystal form I Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；Sodium malonate
|
Resolution 1.89 Å R-free 0.240 |
| 5I26 Azurin T30R1, crystal form I Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；Sodium malonate
|
Resolution 1.89 Å R-free 0.240 |
| 5I26 Azurin T30R1, crystal form I Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；Sodium malonate
|
Resolution 1.89 Å R-free 0.240 |
| 5I28 Azurin T30R1, crystal form II Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；sodium malonate
|
Resolution 1.95 Å R-free 0.271 |
| 5I28 Azurin T30R1, crystal form II Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 10 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain J
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；sodium malonate
|
Resolution 1.95 Å R-free 0.271 |
| 5I28 Azurin T30R1, crystal form II Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 11 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain K
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；sodium malonate
|
Resolution 1.95 Å R-free 0.271 |
| 5I28 Azurin T30R1, crystal form II Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 12 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain L
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；sodium malonate
|
Resolution 1.95 Å R-free 0.271 |
| 5I28 Azurin T30R1, crystal form II Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 13 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain M
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；sodium malonate
|
Resolution 1.95 Å R-free 0.271 |
| 5I28 Azurin T30R1, crystal form II Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 14 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain N
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；sodium malonate
|
Resolution 1.95 Å R-free 0.271 |
| 5I28 Azurin T30R1, crystal form II Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 15 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain O
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；sodium malonate
|
Resolution 1.95 Å R-free 0.271 |
| 5I28 Azurin T30R1, crystal form II Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 16 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain P
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；sodium malonate
|
Resolution 1.95 Å R-free 0.271 |
| 5I28 Azurin T30R1, crystal form II Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；sodium malonate
|
Resolution 1.95 Å R-free 0.271 |
| 5I28 Azurin T30R1, crystal form II Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；sodium malonate
|
Resolution 1.95 Å R-free 0.271 |
| 5I28 Azurin T30R1, crystal form II Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；sodium malonate
|
Resolution 1.95 Å R-free 0.271 |
| 5I28 Azurin T30R1, crystal form II Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 5 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain E
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；sodium malonate
|
Resolution 1.95 Å R-free 0.271 |
| 5I28 Azurin T30R1, crystal form II Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 6 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain F
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；sodium malonate
|
Resolution 1.95 Å R-free 0.271 |
| 5I28 Azurin T30R1, crystal form II Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 7 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain G
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；sodium malonate
|
Resolution 1.95 Å R-free 0.271 |
| 5I28 Azurin T30R1, crystal form II Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 8 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain H
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；sodium malonate
|
Resolution 1.95 Å R-free 0.271 |
| 5I28 Azurin T30R1, crystal form II Deposited 2016-02-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 9 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain I
21–148（128 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；sodium malonate
|
Resolution 1.95 Å R-free 0.271 |
| 5SYD Circularly permutated azurin (cpAz) based on P. aeruginosa azurin sequence Deposited 2016-08-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
63–148（86 aa）
Fragment：unp residues 63-148; 1-38
|
Not recorded | CU COPPER (II) ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；277 K；2 uL of 5 mM protein was mixed with equal amount of well buffer (0.1 M Tris, 0.1 M LiNO 3, 0.01 M CUSO 4 with 35% polyethylene glycol 10000), and crystalized using the hanging drop method, with 300 uL well buffer in the crystallization tray.
|
Resolution 2.40 Å R-free 0.251 |
| 5SYD Circularly permutated azurin (cpAz) based on P. aeruginosa azurin sequence Deposited 2016-08-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
63–148（86 aa）
Fragment：unp residues 63-148; 1-38
|
Not recorded | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；277 K；2 uL of 5 mM protein was mixed with equal amount of well buffer (0.1 M Tris, 0.1 M LiNO 3, 0.01 M CUSO 4 with 35% polyethylene glycol 10000), and crystalized using the hanging drop method, with 300 uL well buffer in the crystallization tray.
|
Resolution 2.40 Å R-free 0.251 |
| 5YT7 crystal structure of circularly permutated Azurin 3 Deposited 2017-11-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–134（114 aa）
|
Not recorded | CU COPPER (II) ION × 1 CA CALCIUM ION × 1 NO3 NITRATE ION × 1 CL CHLORIDE ION × 1 NA SODIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；0.08 M NaOAc, 0.24 M LiNO3, 0.24 M CaCl2, 20% polyethylene glycol 8000
|
Resolution 1.66 Å R-free 0.217 |
| 5YT7 crystal structure of circularly permutated Azurin 3 Deposited 2017-11-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–134（114 aa）
|
Not recorded | CU COPPER (II) ION × 1 CA CALCIUM ION × 2 NO3 NITRATE ION × 2 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；0.08 M NaOAc, 0.24 M LiNO3, 0.24 M CaCl2, 20% polyethylene glycol 8000
|
Resolution 1.66 Å R-free 0.217 |
| 5YT7 crystal structure of circularly permutated Azurin 3 Deposited 2017-11-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–134（114 aa）
|
Not recorded | CU COPPER (II) ION × 1 NO3 NITRATE ION × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；0.08 M NaOAc, 0.24 M LiNO3, 0.24 M CaCl2, 20% polyethylene glycol 8000
|
Resolution 1.66 Å R-free 0.217 |
| 5YT7 crystal structure of circularly permutated Azurin 3 Deposited 2017-11-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–134（114 aa）
|
Not recorded | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；0.08 M NaOAc, 0.24 M LiNO3, 0.24 M CaCl2, 20% polyethylene glycol 8000
|
Resolution 1.66 Å R-free 0.217 |
| 6GYI Azurin fom Pseudomonas aeruginosa treated with hydrosulfide Deposited 2018-06-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；30% PEG 4000, 100 mM NaHEPES pH 6,5, 200 mM CaCl2, 10 mM Na2S. Cryoprotectant: 10% PEG 4000, 20% PEG 400, 100 mM NaHEPES pH 6,5, 200 mM CaCl2
|
Resolution 1.60 Å R-free 0.243 |
| 6GYI Azurin fom Pseudomonas aeruginosa treated with hydrosulfide Deposited 2018-06-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；30% PEG 4000, 100 mM NaHEPES pH 6,5, 200 mM CaCl2, 10 mM Na2S. Cryoprotectant: 10% PEG 4000, 20% PEG 400, 100 mM NaHEPES pH 6,5, 200 mM CaCl2
|
Resolution 1.60 Å R-free 0.243 |
| 6GYI Azurin fom Pseudomonas aeruginosa treated with hydrosulfide Deposited 2018-06-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；30% PEG 4000, 100 mM NaHEPES pH 6,5, 200 mM CaCl2, 10 mM Na2S. Cryoprotectant: 10% PEG 4000, 20% PEG 400, 100 mM NaHEPES pH 6,5, 200 mM CaCl2
|
Resolution 1.60 Å R-free 0.243 |
| 6GYI Azurin fom Pseudomonas aeruginosa treated with hydrosulfide Deposited 2018-06-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；30% PEG 4000, 100 mM NaHEPES pH 6,5, 200 mM CaCl2, 10 mM Na2S. Cryoprotectant: 10% PEG 4000, 20% PEG 400, 100 mM NaHEPES pH 6,5, 200 mM CaCl2
|
Resolution 1.60 Å R-free 0.243 |
| 6IAV CO-AZURIN FROM PSEUDOMONAS AERUGINOSA TREATED WITH HYDROSULFIDE Deposited 2018-11-27 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–148（127 aa）
|
Not recorded | CO COBALT (II) ION × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；30% PEG 4000, 100 MM TRIS PH 7.5, 200 MM CACL2, 10 MM NA2S. CRYOPROTECTANT: 10% PEG 4000, 20% PEG 400, 100 MM TRIS PH 7.5, 200 MM CACL2, PH 7.5
|
Resolution 2.00 Å R-free 0.310 |
| 6IAV CO-AZURIN FROM PSEUDOMONAS AERUGINOSA TREATED WITH HYDROSULFIDE Deposited 2018-11-27 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–148（127 aa）
|
Not recorded | CO COBALT (II) ION × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；30% PEG 4000, 100 MM TRIS PH 7.5, 200 MM CACL2, 10 MM NA2S. CRYOPROTECTANT: 10% PEG 4000, 20% PEG 400, 100 MM TRIS PH 7.5, 200 MM CACL2, PH 7.5
|
Resolution 2.00 Å R-free 0.310 |
| 6IAV CO-AZURIN FROM PSEUDOMONAS AERUGINOSA TREATED WITH HYDROSULFIDE Deposited 2018-11-27 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
22–148（127 aa）
|
Not recorded | CO COBALT (II) ION × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；30% PEG 4000, 100 MM TRIS PH 7.5, 200 MM CACL2, 10 MM NA2S. CRYOPROTECTANT: 10% PEG 4000, 20% PEG 400, 100 MM TRIS PH 7.5, 200 MM CACL2, PH 7.5
|
Resolution 2.00 Å R-free 0.310 |
| 6IAV CO-AZURIN FROM PSEUDOMONAS AERUGINOSA TREATED WITH HYDROSULFIDE Deposited 2018-11-27 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
22–148（127 aa）
|
Not recorded | CO COBALT (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；30% PEG 4000, 100 MM TRIS PH 7.5, 200 MM CACL2, 10 MM NA2S. CRYOPROTECTANT: 10% PEG 4000, 20% PEG 400, 100 MM TRIS PH 7.5, 200 MM CACL2, PH 7.5
|
Resolution 2.00 Å R-free 0.310 |
| 6MJS Azurin 122W/124W/126Re Deposited 2018-09-21 | Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–148（127 aa）
|
Mutation：W48F, Y72F, H83Q, Y108F, K122W, T124W, T126H | CU COPPER (II) ION × 1 REQ (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.2；294 K；100 mM imidiazole, 100 mM LiNO3, 6.25 mM CuCl2, 28% PEG 4000
|
Resolution 1.85 Å R-free 0.198 |
| 6MJS Azurin 122W/124W/126Re Deposited 2018-09-21 | Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–148（127 aa）
|
Mutation：W48F, Y72F, H83Q, Y108F, K122W, T124W, T126H | CU COPPER (II) ION × 1 REQ (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.2；294 K；100 mM imidiazole, 100 mM LiNO3, 6.25 mM CuCl2, 28% PEG 4000
|
Resolution 1.85 Å R-free 0.198 |
| 6MJS Azurin 122W/124W/126Re Deposited 2018-09-21 | Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
22–148（127 aa）
|
Mutation：W48F, Y72F, H83Q, Y108F, K122W, T124W, T126H | CU COPPER (II) ION × 1 REQ (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.2；294 K；100 mM imidiazole, 100 mM LiNO3, 6.25 mM CuCl2, 28% PEG 4000
|
Resolution 1.85 Å R-free 0.198 |
| 6MJS Azurin 122W/124W/126Re Deposited 2018-09-21 | Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
22–148（127 aa）
|
Mutation：W48F, Y72F, H83Q, Y108F, K122W, T124W, T126H | CU COPPER (II) ION × 1 REQ (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.2；294 K；100 mM imidiazole, 100 mM LiNO3, 6.25 mM CuCl2, 28% PEG 4000
|
Resolution 1.85 Å R-free 0.198 |
| 6MJT Azurin 122F/124W/126Re Deposited 2018-09-21 | Different mutation/modification Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–148（127 aa）
|
Mutation：W48F, Y72F, H83Q, Y108F, K122F, T124W, T126H | CU COPPER (II) ION × 1 REQ (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 4.5；294 K；0.1 M NaOAc, 120 mM/150 mM Li2SO4, and 48.6% PEG 400/27.7% PEG 8000 at pH 4.5
|
Resolution 1.89 Å R-free 0.245 |
| 6MJT Azurin 122F/124W/126Re Deposited 2018-09-21 | Different mutation/modification Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–148（127 aa）
|
Mutation：W48F, Y72F, H83Q, Y108F, K122F, T124W, T126H | CU COPPER (II) ION × 1 REQ (1,10 PHENANTHROLINE)-(TRI-CARBON MONOXIDE) RHENIUM (I) × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 4.5；294 K；0.1 M NaOAc, 120 mM/150 mM Li2SO4, and 48.6% PEG 400/27.7% PEG 8000 at pH 4.5
|
Resolution 1.89 Å R-free 0.245 |
| 7TC6 All Phe-Azurin variant - F15W Deposited 2021-12-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
22–148（127 aa）
Chain B
22–148（127 aa）
|
Mutation：F15W, W48F, Y72F, H83Q, Y108F, T124H Mutation：F15W, W48F, Y72F, H83Q, Y108F, T124H | CU COPPER (II) ION × 3 NO3 NITRATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；20 mg/mL protein in 0.1 M NaOAc (pH 5.0), 26.5-29% PEG 4000, 100 mM lithium nitrate, 10 mM copper sulfate, and 100 mM tris (pH 8.0)
|
Resolution 1.85 Å R-free 0.243 |
| 7TNC M13F/G116F Pseudomonas aeruginosa azurin Deposited 2022-01-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
21–148（128 aa）
|
Mutation：M13F, G116F | TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 CU COPPER (II) ION × 8 CL CHLORIDE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；277 K；The 1.4 mM apo-protein was prepared in 100 mM pH=5.6 NaOAc buffer. For each well, add 300 uL reservoir buffer containing 100 mM pH=8.0 Tris-HCl, 10 mM CuSO4 and 20% PEG-4000. 3 uL of protein stock was mixed with 1 uL reservoir buffer on the glass slides and sealed on the wells. Diamond-shaped blue crystals grew within 4 days.
|
Resolution 1.47 Å R-free 0.237 |
| 7U2F G116F Pseudomonas aeruginosa azurin Deposited 2022-02-23 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–148（128 aa）
Fragment：UNP residues 21-148
|
Mutation：G116F | CU COPPER (II) ION × 2 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；3 uL 1.4 mM in 100 mM sodium acetate, pH 5.6 + 1 uL reservoir buffer (20% PEG4000, 100 mM Tris-HCl, pH 8.0, 10 mM copper(II) sulfate, 100 mM lithium nitrate) against 250 uL reservoir buffer
|
Resolution 2.20 Å R-free 0.256 |
| 7YGI Crystal structure of p53 DBD domain in complex with azurin Deposited 2022-07-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain C
23–145（123 aa）
Chain D
23–145（123 aa）
|
Not recorded | NA SODIUM ION × 2 ZN ZINC ION × 2 K POTASSIUM ION × 2 PO4 PHOSPHATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；298 K；0.05M Na2HPO4+19.5% PEG3350
|
Resolution 2.10 Å R-free 0.270 |
| 8F5K Azurin from Pseudomonas aeruginosa, Y72F/Y108F/F110A mutant Deposited 2022-11-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–148（148 aa）
|
Mutation：Y72F,Y108F,F110A | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；22-25 % (w/v) PEG 3350, 0.1 M Hepes, pH 7.0, 0.2 M sodium formate
|
Resolution 1.25 Å R-free 0.179 |
| 8F5K Azurin from Pseudomonas aeruginosa, Y72F/Y108F/F110A mutant Deposited 2022-11-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–148（148 aa）
|
Mutation：Y72F,Y108F,F110A | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；22-25 % (w/v) PEG 3350, 0.1 M Hepes, pH 7.0, 0.2 M sodium formate
|
Resolution 1.25 Å R-free 0.179 |
| 8F5K Azurin from Pseudomonas aeruginosa, Y72F/Y108F/F110A mutant Deposited 2022-11-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
1–148（148 aa）
|
Mutation：Y72F,Y108F,F110A | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；22-25 % (w/v) PEG 3350, 0.1 M Hepes, pH 7.0, 0.2 M sodium formate
|
Resolution 1.25 Å R-free 0.179 |
| 8F5K Azurin from Pseudomonas aeruginosa, Y72F/Y108F/F110A mutant Deposited 2022-11-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
1–148（148 aa）
|
Mutation：Y72F,Y108F,F110A | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；22-25 % (w/v) PEG 3350, 0.1 M Hepes, pH 7.0, 0.2 M sodium formate
|
Resolution 1.25 Å R-free 0.179 |
| 8F5L Azurin from Pseudomonas aeruginosa, Y72F/Y108F/F110L mutant Deposited 2022-11-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–148（148 aa）
|
Mutation：Y72F,Y108F,F110L | TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 CU COPPER (II) ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；22-25 % (w/v) PEG 3350, 0.1 M Hepes, pH 7.0, 0.2 M sodium formate
|
Resolution 1.15 Å R-free 0.174 |
| 8F5L Azurin from Pseudomonas aeruginosa, Y72F/Y108F/F110L mutant Deposited 2022-11-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
1–148（148 aa）
|
Mutation：Y72F,Y108F,F110L | CU COPPER (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；22-25 % (w/v) PEG 3350, 0.1 M Hepes, pH 7.0, 0.2 M sodium formate
|
Resolution 1.15 Å R-free 0.174 |
| 9L6D the crystal structure of Azurin-LBT Deposited 2024-12-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 3 PDB declaration: trimeric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
Chain C
21–148（128 aa）
|
Not recorded | CU COPPER (II) ION × 3 TB TERBIUM(III) ION × 7 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；277 K；0.1M NaOAc pH5.6, 10% 2-propanol with 16% PEG6000
|
Resolution 2.38 Å R-free 0.245 |
| 9OH6 H117A/M121H Azurin with Cu(II), pH 7.7 Deposited 2025-05-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain B
21–148（128 aa）
Chain E
21–148（128 aa）
Chain H
21–148（128 aa）
Chain K
21–148（128 aa）
|
Mutation：H117A, M121H Mutation：H117A, M121H Mutation：H117A, M121H Mutation：H117A, M121H | TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 CU COPPER (II) ION × 8 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.7；277 K；Well buffer: 27% PEG 4000, 100 mM LiNO3, 50 mM Tris at pH 7.7
Protein stock: 1.5 mM in 25 mM Tris pH 7.8, 1.8 mM CuSO4
Crystallization drop: 1 uL protein stock + 3 uL well buffer
|
Resolution 2.04 Å R-free 0.233 |
| 9OH7 M13F/H117A/M121H Azurin with Cu(II), pH 7.4 Deposited 2025-05-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
21–148（128 aa）
Chain B
21–148（128 aa）
Chain E
21–148（128 aa）
Chain G
21–148（128 aa）
|
Mutation：M13F, H117A, M121H Mutation：M13F, H117A, M121H Mutation：M13F, H117A, M121H Mutation：M13F, H117A, M121H | TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 CU COPPER (II) ION × 8 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；277.15 K；Well buffer: 30% PEG 4000, 100 mM LiNO3, 50 mM Tris at pH 7.4
Protein stock: 1.5 mM in 25 mM Tris pH 7.8, 1.8 mM CuSO4
Crystallization drop: 1.5 uL protein stock + 1.5 uL well buffer
|
Resolution 2.00 Å R-free 0.265 |
110 other PDB entries and 267 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | AZUR_PSEAE |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 2–128； UniProt 22–148 Author chain B； PDBConstruct 2–128； UniProt 22–148 Author chain C； PDBConstruct 2–128； UniProt 22–148 Author chain D； PDBConstruct 2–128； UniProt 22–148 |
