8dwo

Cryo-EM Structure of Eastern Equine Encephalitis Virus in complex with SKE26 Fab

Method: ELECTRON MICROSCOPY
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Envelope glycoprotein E1

Eastern equine encephalitis virus

UniProt Q88678

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 12 SKE26 Fab Heavy Chain × 3 SKE26 Fab Light Chain × 3 Consistent with protein count

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers
6xo4 6xo4 6xo4 6xo4 6xo4

5 assemblies

Heteromeric or nucleic-acid complex
6xob 6xob 6xob 6xob 6xob 8dwo 8ua4 8ua9 8ufa 8ufb 8ufc

11 assemblies

View Construct and Data Evidence
UniProt name Q88678_EEEV
Isoform —
PDB entities 1, 2
Chains and sequence ranges Author chain A； PDBConstruct 1–441； UniProt 802–1242 Author chain F； PDBConstruct 1–441； UniProt 802–1242 Author chain J； PDBConstruct 1–441； UniProt 802–1242 Author chain B； PDBConstruct 1–420； UniProt 325–744 Author chain G； PDBConstruct 1–420； UniProt 325–744 Author chain K； PDBConstruct 1–420； UniProt 325–744

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id8dwo
Deposition date deposition_date2022-08-01
Structure title titleCryo-EM Structure of Eastern Equine Encephalitis Virus in complex with SKE26 Fab
Keywords keywordsEastern Equine Encephalitis virus, Virus Like Particle, virus-fab complex; VIRUS LIKE PARTICLE
Experimental Method methodELECTRON MICROSCOPY
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

8dwo__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

8dwo__assembly_1__model_1 | I(q)

10-2 10-1 106 107 108 109 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

8dwo__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）50.50 Å
Rg (electron density)50.47 Å
Total Rg50.71 Å
Atom count22572
Residues2916
Excluded volume399210 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 8dwo__assembly_1__model_1 dodecameric （12） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (4)

▼

6. Fold Classification (SCOP + CATH) 14 domains

CATH v4.4 (14 domains)

Domain ID domain_id8dwoB01
Class class2 — Mainly Beta
Architecture architecture60 — Sandwich
Topology topology40 — Immunoglobulin-like
Homologous superfamily homologous superfamily3200 — Alphavirus E2 glycoprotein, A domain
Domain ID domain_id8dwoB02
Class class2 — Mainly Beta
Architecture architecture60 — Sandwich
Topology topology40 — Immunoglobulin-like
Homologous superfamily homologous superfamily2400 — Alphavirus E2 glycoprotein, domain C
Domain ID domain_id8dwoG01
Class class2 — Mainly Beta
Architecture architecture60 — Sandwich
Topology topology40 — Immunoglobulin-like
Homologous superfamily homologous superfamily3200 — Alphavirus E2 glycoprotein, A domain
Domain ID domain_id8dwoG02
Class class2 — Mainly Beta
Architecture architecture60 — Sandwich
Topology topology40 — Immunoglobulin-like
Homologous superfamily homologous superfamily2400 — Alphavirus E2 glycoprotein, domain C
Domain ID domain_id8dwoH01
Class class2 — Mainly Beta
Architecture architecture60 — Sandwich
Topology topology40 — Immunoglobulin-like
Homologous superfamily homologous superfamily10 — Immunoglobulins
Domain ID domain_id8dwoJ01
Class class2 — Mainly Beta
Architecture architecture60 — Sandwich
Topology topology40 — Immunoglobulin-like
Homologous superfamily homologous superfamily350 —
Domain ID domain_id8dwoK01
Class class2 — Mainly Beta
Architecture architecture60 — Sandwich
Topology topology40 — Immunoglobulin-like
Homologous superfamily homologous superfamily3200 — Alphavirus E2 glycoprotein, A domain
Domain ID domain_id8dwoK02
Class class2 — Mainly Beta
Architecture architecture60 — Sandwich
Topology topology40 — Immunoglobulin-like
Homologous superfamily homologous superfamily4310 — Alphavirus E2 glycoprotein, domain B
Domain ID domain_id8dwoK03
Class class2 — Mainly Beta
Architecture architecture60 — Sandwich
Topology topology40 — Immunoglobulin-like
Homologous superfamily homologous superfamily2400 — Alphavirus E2 glycoprotein, domain C
Domain ID domain_id8dwoL01
Class class2 — Mainly Beta
Architecture architecture60 — Sandwich
Topology topology40 — Immunoglobulin-like
Homologous superfamily homologous superfamily10 — Immunoglobulins
Domain ID domain_id8dwoS01
Class class2 — Mainly Beta
Architecture architecture60 — Sandwich
Topology topology40 — Immunoglobulin-like
Homologous superfamily homologous superfamily10 — Immunoglobulins
Domain ID domain_id8dwoT01
Class class2 — Mainly Beta
Architecture architecture60 — Sandwich
Topology topology40 — Immunoglobulin-like
Homologous superfamily homologous superfamily10 — Immunoglobulins
Domain ID domain_id8dwoU01
Class class2 — Mainly Beta
Architecture architecture60 — Sandwich
Topology topology40 — Immunoglobulin-like
Homologous superfamily homologous superfamily10 — Immunoglobulins
Domain ID domain_id8dwoV01
Class class2 — Mainly Beta
Architecture architecture60 — Sandwich
Topology topology40 — Immunoglobulin-like
Homologous superfamily homologous superfamily10 — Immunoglobulins
▶

7. Citations (1)
