8f7k

Thermoplasma acidophilum 20S proteasome - wild type bound to ZYA

Method: ELECTRON MICROSCOPY
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Proteasome subunit alpha

Thermoplasma acidophilum

UniProt P25156

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 28 Proteasome subunit beta × 14 （P28061） N-[(benzyloxy)carbonyl]-L-tyrosyl-D-alanine × 14 Consistent with protein count

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers
2ku1 2ku2

2 assemblies

Heteromeric or nucleic-acid complex
1pma 1ya7 1yar 1yau 3c91 3c92 3ipm 3j9i 3jrm 3jse 3jtl 5vy3

23 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name PSA_THEAC
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 1–230； UniProt 4–233 Author chain B； PDBConstruct 1–230； UniProt 4–233 Author chain C； PDBConstruct 1–230； UniProt 4–233 Author chain D； PDBConstruct 1–230； UniProt 4–233 Author chain E； PDBConstruct 1–230； UniProt 4–233 Author chain F； PDBConstruct 1–230； UniProt 4–233 Author chain G； PDBConstruct 1–230； UniProt 4–233 Author chain O； PDBConstruct 1–230； UniProt 4–233 Author chain P； PDBConstruct 1–230； UniProt 4–233 Author chain Q； PDBConstruct 1–230； UniProt 4–233 Author chain R； PDBConstruct 1–230； UniProt 4–233 Author chain S； PDBConstruct 1–230； UniProt 4–233 Author chain T； PDBConstruct 1–230； UniProt 4–233 Author chain U； PDBConstruct 1–230； UniProt 4–233

Proteasome subunit beta

Thermoplasma acidophilum

UniProt P28061

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 28 Proteasome subunit alpha × 14 （P25156） N-[(benzyloxy)carbonyl]-L-tyrosyl-D-alanine × 14 Consistent with protein count

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
1pma 1ya7 1yar 1yau 3c91 3c92 3ipm 3j9i 3jrm 3jse 3jtl 5vy3

23 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name PSB_THEAC
Isoform —
PDB entities 2
Chains and sequence ranges Author chain H； PDBConstruct 1–203； UniProt 9–211 Author chain I； PDBConstruct 1–203； UniProt 9–211 Author chain J； PDBConstruct 1–203； UniProt 9–211 Author chain K； PDBConstruct 1–203； UniProt 9–211 Author chain L； PDBConstruct 1–203； UniProt 9–211 Author chain M； PDBConstruct 1–203； UniProt 9–211 Author chain N； PDBConstruct 1–203； UniProt 9–211 Author chain V； PDBConstruct 1–203； UniProt 9–211 Author chain W； PDBConstruct 1–203； UniProt 9–211 Author chain X； PDBConstruct 1–203； UniProt 9–211 Author chain Y； PDBConstruct 1–203； UniProt 9–211 Author chain Z； PDBConstruct 1–203； UniProt 9–211 Author chain a； PDBConstruct 1–203； UniProt 9–211 Author chain b； PDBConstruct 1–203； UniProt 9–211

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id8f7k
Deposition date deposition_date2022-11-18
Last revision last_revision2023-08-30
Structure title titleThermoplasma acidophilum 20S proteasome - wild type bound to ZYA
Keywords keywordsProtease, threonine protease, endopeptidase activity, HYDROLASE; HYDROLASE
Experimental Method methodELECTRON MICROSCOPY
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

8f7k__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

8f7k__assembly_1__model_1 | I(q)

10-2 10-1 106 107 108 109 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

8f7k__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）60.19 Å
Rg (electron density)59.84 Å
Total Rg59.90 Å
Atom count95284
Residues6048
Excluded volume847070 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 8f7k__assembly_1__model_1 28-meric （28） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (3)

▼

6. Fold Classification (SCOP + CATH) 28 domains

CATH v4.4 (28 domains)

Domain ID domain_id8f7kA01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kB01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kC01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kD01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kE01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kF01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kG01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kH01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kI01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kJ01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kK01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kL01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kM01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kN01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kO01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kP01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kQ01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kR01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kS01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kT01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kU01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kV01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kW01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kX01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kY01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kZ01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7ka01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
Domain ID domain_id8f7kb01
Class class3 — Alpha Beta
Architecture architecture60 — 4-Layer Sandwich
Topology topology20 — Glutamine Phosphoribosylpyrophosphate, subunit 1, domain 1
Homologous superfamily homologous superfamily10 — Aminohydrolase, N-terminal nucleophile (Ntn) domain
▶

7. Citations (1)
