8izm

Structure of the Mumps Virus L Protein (state2) Bound by Phosphoprotein Tetramer

Method: ELECTRON MICROSCOPY
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Phosphoprotein

Mumps virus strain Jeryl Lynn

UniProt Q9J4L6

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 5 RNA-directed RNA polymerase L × 1 （Q9J4L0） ZINC ION × 2 Consistent with protein count

Other States of the Same Protein in the Database

Monomer
3bbz 3bbz

2 assemblies

Homodimer
3bbz

1 assemblies

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
8izl 8izm

2 assemblies

View Construct and Data Evidence
UniProt name Q9J4L6_MUMPJ
Isoform —
PDB entities 1
Chains and sequence ranges Author chain B； PDBConstruct 1–391； UniProt 1–391 Author chain C； PDBConstruct 1–391； UniProt 1–391 Author chain D； PDBConstruct 1–391； UniProt 1–391 Author chain E； PDBConstruct 1–391； UniProt 1–391

RNA-directed RNA polymerase L

Mumps virus strain Jeryl Lynn

UniProt Q9J4L0

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 5 Phosphoprotein × 4 （Q9J4L6） ZINC ION × 2 Consistent with protein count

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
8izl 8izm

2 assemblies

View Construct and Data Evidence
UniProt name Q9J4L0_MUMPJ
Isoform —
PDB entities 2
Chains and sequence ranges Author chain A； PDBConstruct 1–2261； UniProt 1–2261

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id8izm
Deposition date deposition_date2023-04-07
Last revision last_revision2024-04-17
Structure title titleStructure of the Mumps Virus L Protein (state2) Bound by Phosphoprotein Tetramer
Keywords keywordsMumps virus polymerase complex, RNA-dependent RNA synthesis, Large protein, phosphoprotein., VIRAL PROTEIN; VIRAL PROTEIN
Experimental Method methodELECTRON MICROSCOPY
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

8izm__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

8izm__assembly_1__model_1 | I(q)

10-2 10-1 106 107 108 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

8izm__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）41.75 Å
Rg (electron density)41.70 Å
Total Rg42.17 Å
Atom count12742
Residues1608
Excluded volume229070 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 8izm__assembly_1__model_1 pentameric （5） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (3)

▶

7. Citations (1)
