8pef

Crystal structure of SLF1 Ankyrin repeat domain in complex with H4 tail (K20me0)

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

SMC5-SMC6 complex localization factor protein 1

Homo sapiens

UniProt Q9BQI6

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 2 Histone H4 × 1 (P62805) water × 2 Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name SLF1_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A; PDBConstruct 4–136; UniProt 802–934

Histone H4

OrganismNot specified

UniProt P62805

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 2 SMC5-SMC6 complex localization factor protein 1 × 1 (Q9BQI6) water × 2 Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name H4_HUMAN
Isoform —
PDB entities 2
Chains and sequence ranges Author chain B; PDBConstruct 1–17; UniProt 10–26

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id8pef
Deposition date deposition_date2023-06-13
Structure title titleCrystal structure of SLF1 Ankyrin repeat domain in complex with H4 tail (K20me0)
Keywords keywordsDNA repair, SMC5/6, nucleosome, Histone 4, SLF1, Ankyrin repeat, RAD18, K20me0, Interstrand crosslinks, NUCLEAR PROTEIN; NUCLEAR PROTEIN
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

8pef__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

8pef__assembly_1__model_1 | I(q)

10-2 10-1 105 106 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

8pef__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg(Guinier)15.79 Å
Rg (electron density)14.89 Å
Total Rg16.03 Å
Atom count1113
Residues146
Excluded volume19902 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 8pef__assembly_1__model_1 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (3)

▶

7. Citations (1)
