8qyu

Beta-cardiac myosin S1 fragment in the pre-powerstroke state complexed to Omecamtiv mecarbil

Method: X-RAY DIFFRACTION

▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Myosin-7

OrganismNot specified

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein heterocomplex	Heteromer	Protein 2	Myosin light chain 3 × 1 （P85100） ADENOSINE-5'-DIPHOSPHATE × 1 VANADATE ION × 1 MAGNESIUM ION × 1 FORMIC ACID × 1 DIMETHYL SULFOXIDE × 3 methyl 4-(2-fluoro-3-{[(6-methylpyridin-3-yl)carbamoyl]amino}benzyl)piperazine-1-carboxylate × 1 water × 2	Consistent with protein count
2	Protein heterocomplex	Heteromer	Protein 2	Myosin light chain 3 × 1 （P85100） ADENOSINE-5'-DIPHOSPHATE × 1 VANADATE ION × 1 MAGNESIUM ION × 1 FORMIC ACID × 2 DIMETHYL SULFOXIDE × 1 methyl 4-(2-fluoro-3-{[(6-methylpyridin-3-yl)carbamoyl]amino}benzyl)piperazine-1-carboxylate × 1 GLYCEROL × 2 MALONIC ACID × 1 water × 2	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	MYH7_BOVIN
Isoform	—
PDB entities	1
Chains and sequence ranges	Author chain A； PDBConstruct 1–810； UniProt 1–810 Author chain B； PDBConstruct 1–810； UniProt 1–810

Myosin light chain 3

OrganismNot specified

UniProt P85100

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein heterocomplex	Heteromer	Protein 2	Myosin-7 × 1 （Q9BE39） ADENOSINE-5'-DIPHOSPHATE × 1 VANADATE ION × 1 MAGNESIUM ION × 1 FORMIC ACID × 1 DIMETHYL SULFOXIDE × 3 methyl 4-(2-fluoro-3-{[(6-methylpyridin-3-yl)carbamoyl]amino}benzyl)piperazine-1-carboxylate × 1 water × 2	Consistent with protein count
2	Protein heterocomplex	Heteromer	Protein 2	Myosin-7 × 1 （Q9BE39） ADENOSINE-5'-DIPHOSPHATE × 1 VANADATE ION × 1 MAGNESIUM ION × 1 FORMIC ACID × 2 DIMETHYL SULFOXIDE × 1 methyl 4-(2-fluoro-3-{[(6-methylpyridin-3-yl)carbamoyl]amino}benzyl)piperazine-1-carboxylate × 1 GLYCEROL × 2 MALONIC ACID × 1 water × 2	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	MYL3_BOVIN
Isoform	—
PDB entities	2
Chains and sequence ranges	Author chain G； PDBConstruct 1–199； UniProt 1–199 Author chain H； PDBConstruct 1–199； UniProt 1–199

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id	8qyu
Deposition date deposition_date	2023-10-26
Last revision last_revision	2023-12-13
Structure title title	Beta-cardiac myosin S1 fragment in the pre-powerstroke state complexed to Omecamtiv mecarbil
Keywords keywords	cardiac myosin modulators inherited cardiomyopathies Omecamtiv mecarbil, CONTRACTILE PROTEIN; CONTRACTILE PROTEIN
Experimental Method method	X-RAY DIFFRACTION

▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

8qyu__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

8qyu__assembly_1__model_1 | I(q)

100 plotted points; both axes use logarithmic scales.

8qyu__assembly_1__model_1 | P(r) · Pending

P(r) will be calculated and displayed separately for the same assembly/model.

Rg（Guinier）	35.49 Å
Rg (electron density)	35.49 Å
Total Rg	35.91 Å
Atom count	7502
Residues	921
Excluded volume	133990 Å³
Maximum q	0.500 Å⁻¹

Assembly	Model	Structure unit	Oligomeric description	Status	CRYSOL	Actions
1	1	`8qyu__assembly_1__model_1`	dimeric （2）	Success	4.1.3-1-20251215 (887e7ef)	View Download
2	1	`8qyu__assembly_2__model_1`	dimeric （2）	Success	4.1.3-1-20251215 (887e7ef)	View Download

▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (11)

Entity 1 Entity 1 polymer

Description description	Myosin-7
Molecular weight formula_weight	92693.1 kDa
Source method src_method	nat
Copy count entity_count	2

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	A,B
Atom count atom_count	15636

MVDAEMAAFGEAAPYLRKSEKERLEAQTRPFDLKKDVFVPDDKEEFVKATILSREGGKVTAETEHGKTVTVKEDQVLQQNPPKFDKIEDMAMLTFLHEPAVLYNLKERYASWMIYTYSGLFCVTINPYKWLPVYNAEVVAAYRGKKRSEAPPHIFSISDNAYQYMLTDRENQSILITGESGAGKTVNTKRVIQYFAVIAAIGDRSKKEQATGKGTLEDQIIQANPALEAFGNAKTVRNDNSSRFGKFIRIHFGATGKLASADIETYLLEKSRVIFQLKAERDYHIFYQILSNKKPELLDMLLITNNPYDYAFISQGETTVASIDDAEELMATDNAFDVLGFTTEEKNSMYKLTGAIMHFGNMKFKLKQREEQAEPDGTEEADKSAYLMGLNSADLLKGLCHPRVKVGNEYVTKGQNVQQVVYAKGALAKAVYERMFNWMVTRINATLETKQPRQYFIGVLDIAGFEIFDFNSFEQLCINFTNEKLQQFFNHHMFVLEQEEYKKEGIEWEFIDFGMDLQACIDLIEKPMGIMSILEEECMFPKATDMTFKAKLFDNHLGKSSNFQKPRNIKGKPEAHFSLIHYAGTVDYNIIGWLQKNKDPLNETVVDLYKKSSLKMLSSLFANYAGFDTPIEKGKGKAKKGSSFQTVSALHRENLNKLMTNLRSTHPHFVRCIIPNETKSPGVIDNPLVMHQLRCNGVLEGIRICRKGFPNRILYGDFRQRYRILNPAAIPEGQFIDSRKGAEKLLGSLDIDHNQYKFGHTKVFFKAGLLGLLEEMRDERLSRIITRIQAQSRGVLSRMEFKKLLERRDS

Entity 2 Entity 2 polymer

Description description	Myosin light chain 3
Molecular weight formula_weight	21968.0 kDa
Source method src_method	nat
Copy count entity_count	2

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	G,H

MAPKKPDPKKDEAKAGAKAAAAPAPAPAPPPAPEPSKEPEFDPSKIKIEFTPEQIEEFKEAFTLFDRTPKCEMKITYGQCGDVLRALGQNPTQAEVLRVLGKPKQEELNSKMMDFDTFLPMLQHISKNKDTGTYEDFVEGLRVFDKEGNGTVMGAELRHVLATLGEKLTEDEVEKLMAGQEDSNGCINYEAFVKHIMAG

Entity 3 Entity 3 non-polymer

Description description	ADENOSINE-5'-DIPHOSPHATE
Molecular weight formula_weight	427.2 kDa
Source method src_method	syn
Copy count entity_count	2

Entity 4 Entity 4 non-polymer

Description description	VANADATE ION
Molecular weight formula_weight	114.9 kDa
Source method src_method	syn
Copy count entity_count	2

Entity 5 Entity 5 non-polymer

Description description	MAGNESIUM ION
Molecular weight formula_weight	24.3 kDa
Source method src_method	syn
Copy count entity_count	2

Entity 6 Entity 6 non-polymer

Description description	FORMIC ACID
Molecular weight formula_weight	46.0 kDa
Source method src_method	syn
Copy count entity_count	3

Entity 7 Entity 7 non-polymer

Description description	DIMETHYL SULFOXIDE
Molecular weight formula_weight	78.1 kDa
Source method src_method	syn
Copy count entity_count	4

Entity 8 Entity 8 non-polymer

Description description	methyl 4-(2-fluoro-3-{[(6-methylpyridin-3-yl)carbamoyl]amino}benzyl)piperazine-1-carboxylate
Molecular weight formula_weight	401.4 kDa
Source method src_method	syn
Copy count entity_count	2

Entity 9 Entity 9 non-polymer

Description description	GLYCEROL
Molecular weight formula_weight	92.1 kDa
Source method src_method	syn
Copy count entity_count	2

Entity 10 Entity 10 non-polymer

Description description	MALONIC ACID
Molecular weight formula_weight	104.1 kDa
Source method src_method	syn
Copy count entity_count	1

Entity 11 Entity 11 water

Description description	water
Molecular weight formula_weight	18.0 kDa
Source method src_method	nat
Copy count entity_count	769

▶

Unit-cell length a length_a	97.996 Å
Unit-cell length b length_b	122.503 Å
Unit-cell length c length_c	187.463 Å
Unit-cell angle α angle_alpha	90.00 °
Unit-cell angle β angle_beta	90.00 °
Unit-cell angle γ angle_gamma	90.00 °
Molecules per unit cell Z z_pdb	8

Space group space_group	P 21 21 21
Space-group number int_tables_number	19
Crystal system crystal_system	—

Resolution resolution	1.960 Å
Low-resolution limit resolution_low	22.630 Å
R factor r_factor	0.1940
R_work r_work	0.1910
R_free r_free	0.2350
