8ufs

Structure of human endothelial nitric oxide synthase E361Q mutant heme domain obtain after soaking crystal with 4-methyl-7-(4-methyl-2,3,4,5-tetrahydrobenzo[f][1,4]oxazepin-7-yl)quinolin-2-amine dihydrochloride

Method: X-RAY DIFFRACTION Dmax: 143.6 Å Quality: GOOD
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Nitric oxide synthase 3

Homo sapiens

UniProt P29474

State in the Current Structure

Assembly Oligomeric State Construct Mutations and Modifications Ligands, Ions and Associated Components Method and Experimental Conditions Structure Quality
1 Protein homooligomer Homooligomer Protein × 2 PDB declaration: dimeric（2） Consistent with protein copy count Chain A； UniProt 41–480 Chain B； UniProt 41–480 Mutation：E361Q HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 7 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP Resolution 2.05 Å R-free 0.234
2 Protein homooligomer Homooligomer Protein × 2 PDB declaration: dimeric（2） Consistent with protein copy count Chain C； UniProt 41–480 Chain D； UniProt 41–480 Mutation：E361Q HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 3 GOL GLYCEROL × 6 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 CA CALCIUM ION × 1 X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP Resolution 2.05 Å R-free 0.234

Other States of the Same Protein in the Database

Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.

Other PDB Difference from Current Entry 8UFS Assembly / Oligomeric State Construct Mutations and Modifications Ligands, Ions and Non-polymers Method and Experimental Conditions Structure Quality
1M9J human endothelial nitric oxide synthase with chlorzoxazone bound Deposited 2002-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 66–480（415 aa） Fragment：oxygenase domain
Chain B 66–480（415 aa） Fragment：oxygenase domain
Not recorded ZN ZINC ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 2 CLW CHLORZOXAZONE × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；298 K；NaCl, MPD, PEG, pH 5.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
Resolution 2.43 Å R-free 0.272
1M9K Human Endothelial Nitric Oxide Synthase with 7-Nitroindazole Bound Deposited 2002-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 66–480（415 aa） Fragment：oxygenase domain
Chain B 66–480（415 aa） Fragment：oxygenase domain
Not recorded ZN ZINC ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 2 7NI 7-NITROINDAZOLE × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；298 K；NaCl, MPD, PEG, pH 5.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 2.01 Å R-free 0.224
1M9M human endothelial nitric oxide synthase with 6-nitroindazole bound Deposited 2002-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 66–480（415 aa） Fragment：oxygenase domain
Chain B 66–480（415 aa） Fragment：oxygenase domain
Not recorded ZN ZINC ION × 1 NA SODIUM ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 2 6NI 6-NITROINDAZOLE × 2 IPA ISOPROPYL ALCOHOL × 3 MPD (4S)-2-METHYL-2,4-PENTANEDIOL × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；298 K；NaCl, MPD, PEG, pH 5.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 1.96 Å R-free 0.223
1M9Q human endothelial nitric oxide synthase with 5-nitroindazole bound Deposited 2002-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 66–480（415 aa） Fragment：oxygenase domain
Chain B 66–480（415 aa） Fragment：oxygenase domain
Not recorded ZN ZINC ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 2 5NI 5-NITROINDAZOLE × 2 IPA ISOPROPYL ALCOHOL × 2 MPD (4S)-2-METHYL-2,4-PENTANEDIOL × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；298 K；NaCl, MPD, PEG, pH 5.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 2.01 Å R-free 0.226
1M9R human endothelial nitric oxide synthase with 3-Bromo-7-Nitroindazole bound Deposited 2002-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 66–480（415 aa） Fragment：oxygenase domain
Chain B 66–480（415 aa） Fragment：oxygenase domain
Not recorded ZN ZINC ION × 1 HEM PROTOPORPHYRIN IX CONTAINING FE × 2 INE 3-BROMO-7-NITROINDAZOLE × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；298 K；NaCl, MPD, PEG, pH 5.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 2.56 Å R-free 0.266
1NIW Crystal structure of endothelial nitric oxide synthase peptide bound to calmodulin Deposited 2002-12-26 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 492–511（20 aa） Fragment：Calmodulin binding region
Not recorded CA CALCIUM ION × 4 SO4 SULFATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 5；298 K；Polyethylene glycol, ammonium sulfate, pH 5, VAPOR DIFFUSION, temperature 298K
Resolution 2.05 Å R-free 0.249
1NIW Crystal structure of endothelial nitric oxide synthase peptide bound to calmodulin Deposited 2002-12-26 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 492–511（20 aa） Fragment：Calmodulin binding region
Not recorded CA CALCIUM ION × 4 EDO 1,2-ETHANEDIOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 5；298 K；Polyethylene glycol, ammonium sulfate, pH 5, VAPOR DIFFUSION, temperature 298K
Resolution 2.05 Å R-free 0.249
1NIW Crystal structure of endothelial nitric oxide synthase peptide bound to calmodulin Deposited 2002-12-26 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain F 492–511（20 aa） Fragment：Calmodulin binding region
Not recorded CA CALCIUM ION × 4 EDO 1,2-ETHANEDIOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 5；298 K；Polyethylene glycol, ammonium sulfate, pH 5, VAPOR DIFFUSION, temperature 298K
Resolution 2.05 Å R-free 0.249
1NIW Crystal structure of endothelial nitric oxide synthase peptide bound to calmodulin Deposited 2002-12-26 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 4 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain H 492–511（20 aa） Fragment：Calmodulin binding region
Not recorded CA CALCIUM ION × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 5；298 K；Polyethylene glycol, ammonium sulfate, pH 5, VAPOR DIFFUSION, temperature 298K
Resolution 2.05 Å R-free 0.249
1NIW Crystal structure of endothelial nitric oxide synthase peptide bound to calmodulin Deposited 2002-12-26 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 5 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric
Chain B 492–511（20 aa） Fragment：Calmodulin binding region
Chain D 492–511（20 aa） Fragment：Calmodulin binding region
Chain F 492–511（20 aa） Fragment：Calmodulin binding region
Chain H 492–511（20 aa） Fragment：Calmodulin binding region
Not recorded CA CALCIUM ION × 16 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 5；298 K；Polyethylene glycol, ammonium sulfate, pH 5, VAPOR DIFFUSION, temperature 298K
Resolution 2.05 Å R-free 0.249
1NIW Crystal structure of endothelial nitric oxide synthase peptide bound to calmodulin Deposited 2002-12-26 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 6 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric
Chain B 492–511（20 aa） Fragment：Calmodulin binding region
Chain D 492–511（20 aa） Fragment：Calmodulin binding region
Chain F 492–511（20 aa） Fragment：Calmodulin binding region
Chain H 492–511（20 aa） Fragment：Calmodulin binding region
Not recorded CA CALCIUM ION × 16 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 5；298 K；Polyethylene glycol, ammonium sulfate, pH 5, VAPOR DIFFUSION, temperature 298K
Resolution 2.05 Å R-free 0.249
1NIW Crystal structure of endothelial nitric oxide synthase peptide bound to calmodulin Deposited 2002-12-26 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 7 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain D 492–511（20 aa） Fragment：Calmodulin binding region
Chain H 492–511（20 aa） Fragment：Calmodulin binding region
Not recorded CA CALCIUM ION × 8 EDO 1,2-ETHANEDIOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 5；298 K；Polyethylene glycol, ammonium sulfate, pH 5, VAPOR DIFFUSION, temperature 298K
Resolution 2.05 Å R-free 0.249
1NIW Crystal structure of endothelial nitric oxide synthase peptide bound to calmodulin Deposited 2002-12-26 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 8 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 492–511（20 aa） Fragment：Calmodulin binding region
Chain F 492–511（20 aa） Fragment：Calmodulin binding region
Not recorded CA CALCIUM ION × 8 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 5；298 K；Polyethylene glycol, ammonium sulfate, pH 5, VAPOR DIFFUSION, temperature 298K
Resolution 2.05 Å R-free 0.249
2LL7 Solution NMR structure of CaM bound to the eNOS CaM binding domain peptide Deposited 2011-10-29 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 493–509（17 aa） Fragment：Calmodulin-binding region residues 493-509
Not recorded No recorded non-water small molecule SOLUTION NMR
NMR measurement conditions pH 6；298 K；Pressure ambient
NMR sample composition 1.0 mM [U-99% 13C; U-99% 15N] protein_1, 1.0 mM protein_2, 100 mM potassium chloride, 10 mM calcium chloride, 0.2 mM sodium azide, 90% H2O/10% D2O | 90% H2O/10% D2O
Resolution not provided
2N8J Structure and 15N relaxation data of Calmodulin bound to the endothelial Nitric Oxide Synthase Calmodulin Binding Domain Peptide at Physiological Calcium Concentration Deposited 2015-10-16 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 491–512（22 aa） Fragment：UNP residues 491-512
Not recorded No recorded non-water small molecule SOLUTION NMR
NMR measurement conditions pH 7.2；298 K；Ionic strength (raw mmCIF value) 0.150；Pressure ambient
NMR sample composition 1 mM [U-99% 13C; U-99% 15N] CaM, 1 mM eNOS, 100 mM potassium chloride, 30 mM MOPS, 4 mM EGTA, 6 mM CaEGTA, 90% H2O/10% D2O | 90% H2O/10% D2O
Resolution not provided
3EAH Structure of inhibited human eNOS oxygenase domain Deposited 2008-08-25 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 66–492（427 aa）
Chain B 66–492（427 aa）
Not recorded HEC HEME C × 2 ZN ZINC ION × 1 327 (3S,5E)-3-propyl-3,4-dihydrothieno[2,3-f][1,4]oxazepin-5(2H)-imine × 2 MPD (4S)-2-METHYL-2,4-PENTANEDIOL × 4 CL CHLORIDE ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6；298 K；pH 6.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 2.44 Å R-free 0.258
3NOS HUMAN ENDOTHELIAL NITRIC OXIDE SYNTHASE WITH ARGININE SUBSTRATE Deposited 1999-02-03 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 66–492（427 aa） Fragment：OXYGENASE DOMAIN
Chain B 66–492（427 aa） Fragment：OXYGENASE DOMAIN
Not recorded ZN ZINC ION × 1 HAR N-OMEGA-HYDROXY-L-ARGININE × 2 HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 X-RAY DIFFRACTION
X-ray crystallization conditions pH 6.7；pH 6.70
Resolution 2.40 Å R-free 0.308
4D1O Structure of human endothelial nitric oxide synthase heme domain with L-Arg bound Deposited 2014-05-02 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：RESIDUES 41-480
Chain B 41–480（440 aa） Fragment：RESIDUES 41-480
Not recorded ARG ARGININE × 2 HEM PROTOPORPHYRIN IX CONTAINING FE × 2 ACT ACETATE ION × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 3 ZN ZINC ION × 1 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.5；10-12% PEG3350, 0.1M BIS TRIS, PH7.5, 0.3M MG ACETATE, 0.1M GDCL3, 5 MM TCEP
Resolution 1.82 Å R-free 0.192
4D1P Structure of human endothelial nitric oxide synthase heme domain IN COMPLEX WITH 6-((((3S, 5R)-5-(((6-AMINO-4-METHYLPYRIDIN-2-YL)METHOXY) METHYL)PYRROLIDIN-3-YL)OXY) METHYL)-4-METHYLPYRIDIN-2-AMINE Deposited 2014-05-02 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 Q16 6-((((3S, 5R)-5-(((6-amino-4-methylpyridin-2-yl)methoxy)methyl)pyrrolidin-3-yl)oxy)methyl)-4-methylpyridin-2-amine × 2 ACT ACETATE ION × 4 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 1 ZN ZINC ION × 1 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.5；10-12% PEG3350 0.1M BIS TRIS, PH7.5 0.3M MG ACETATE, 0.1M GDCL3, 5 MM TCEP
Resolution 1.73 Å R-free 0.186
5UO8 Structure of human endothelial nitric oxide synthase heme domain in complex with 3-[(2-aminoquinolin-7-yl)methoxy]-5-((methylamino)methyl)benzonitrile Deposited 2017-01-31 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：UNP residues 41-480
Chain B 41–480（440 aa） Fragment：UNP residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 8EV 3-[(2-aminoquinolin-7-yl)methoxy]-5-[(methylamino)methyl]benzonitrile × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 ZN ZINC ION × 1 GOL GLYCEROL × 1 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；12-15% PEG3350, 0.1 M Bis-Tris, 0.2-0.3 M magnesium acetate, 0.1 M gadolinium chloride, 10% glycerol, 5 mM TCEP
Resolution 2.18 Å R-free 0.272
5UO8 Structure of human endothelial nitric oxide synthase heme domain in complex with 3-[(2-aminoquinolin-7-yl)methoxy]-5-((methylamino)methyl)benzonitrile Deposited 2017-01-31 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：UNP residues 41-480
Chain D 41–480（440 aa） Fragment：UNP residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 8EV 3-[(2-aminoquinolin-7-yl)methoxy]-5-[(methylamino)methyl]benzonitrile × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 ZN ZINC ION × 1 GOL GLYCEROL × 1 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；12-15% PEG3350, 0.1 M Bis-Tris, 0.2-0.3 M magnesium acetate, 0.1 M gadolinium chloride, 10% glycerol, 5 mM TCEP
Resolution 2.18 Å R-free 0.272
5UO9 Structure of human endothelial nitric oxide synthase heme domain in complex with 7-[(3-Ethyl-5-((methylamino)methyl)phenoxy)methyl]quinolin-2-amine Deposited 2017-01-31 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：UNP residues 41-480
Chain B 41–480（440 aa） Fragment：UNP residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 8J4 7-({3-ethyl-5-[(methylamino)methyl]phenoxy}methyl)quinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 8 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 CA CALCIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS,0.2-0.3M MG ACETATE, 0.1M GdCl3,10% glycerol, 5 mM TCEP
Resolution 2.19 Å R-free 0.276
5UO9 Structure of human endothelial nitric oxide synthase heme domain in complex with 7-[(3-Ethyl-5-((methylamino)methyl)phenoxy)methyl]quinolin-2-amine Deposited 2017-01-31 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：UNP residues 41-480
Chain D 41–480（440 aa） Fragment：UNP residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 8J4 7-({3-ethyl-5-[(methylamino)methyl]phenoxy}methyl)quinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 3 GD GADOLINIUM ATOM × 2 MG MAGNESIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS,0.2-0.3M MG ACETATE, 0.1M GdCl3,10% glycerol, 5 mM TCEP
Resolution 2.19 Å R-free 0.276
5UOA Structure of human endothelial nitric oxide synthase heme domain in complex with 3-[(2-Amino-4-methylquinolin-7-yl)methoxy]-5-((methylamino)methyl)benzonitrile Deposited 2017-01-31 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：UNP residues 41-480
Chain B 41–480（440 aa） Fragment：UNP residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 8EY 3-[(2-amino-4-methylquinolin-7-yl)methoxy]-5-[(methylamino)methyl]benzonitrile × 4 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 8 ZN ZINC ION × 3 GOL GLYCEROL × 1 GD GADOLINIUM ATOM × 2 CL CHLORIDE ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS,0.2-0.3M MG ACETATE, 0.1M GdCl3,10% glycerol, 5 MM TCEP
Resolution 2.20 Å R-free 0.281
5UOB Structure of human endothelial nitric oxide synthase heme domain in complex with (R)-3-[(2-amino-4-methylquinolin-7-yl)methoxy]-5-(2-(methylamino)propyl)benzonitrile Deposited 2017-01-31 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：UNP residues 41-480
Chain B 41–480（440 aa） Fragment：UNP residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 M4R 3-[(2-amino-4-methylquinolin-7-yl)methoxy]-5-[(2R)-2-(methylamino)propyl]benzonitrile × 4 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 ZN ZINC ION × 3 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS,0.2-0.3M MG ACETATE, 0.1M GdCl3,10% glycerol, 5 MM TCEP
Resolution 2.29 Å R-free 0.279
5UOB Structure of human endothelial nitric oxide synthase heme domain in complex with (R)-3-[(2-amino-4-methylquinolin-7-yl)methoxy]-5-(2-(methylamino)propyl)benzonitrile Deposited 2017-01-31 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：UNP residues 41-480
Chain D 41–480（440 aa） Fragment：UNP residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 M4R 3-[(2-amino-4-methylquinolin-7-yl)methoxy]-5-[(2R)-2-(methylamino)propyl]benzonitrile × 4 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 ZN ZINC ION × 3 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS,0.2-0.3M MG ACETATE, 0.1M GdCl3,10% glycerol, 5 MM TCEP
Resolution 2.29 Å R-free 0.279
5UOC Structure of human endothelial nitric oxide synthase heme domain in complex with (S)-3-[(2-amino-4-methylquinolin-7-yl)methoxy]-5-(2-(methylamino)propyl)benzonitrile Deposited 2017-01-31 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：UNP residues 41-480
Chain B 41–480（440 aa） Fragment：UNP residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 8FD 3-[(2-amino-4-methylquinolin-7-yl)methoxy]-5-[(2S)-2-(methylamino)propyl]benzonitrile × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 ZN ZINC ION × 2 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS,0.2-0.3M MG ACETATE, 0.1M GdCl3,10% glycerol, 5 mM TCEP
Resolution 2.20 Å R-free 0.287
5UOC Structure of human endothelial nitric oxide synthase heme domain in complex with (S)-3-[(2-amino-4-methylquinolin-7-yl)methoxy]-5-(2-(methylamino)propyl)benzonitrile Deposited 2017-01-31 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：UNP residues 41-480
Chain D 41–480（440 aa） Fragment：UNP residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 8FD 3-[(2-amino-4-methylquinolin-7-yl)methoxy]-5-[(2S)-2-(methylamino)propyl]benzonitrile × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 ZN ZINC ION × 2 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS,0.2-0.3M MG ACETATE, 0.1M GdCl3,10% glycerol, 5 mM TCEP
Resolution 2.20 Å R-free 0.287
5VVB Structure of human endothelial nitric oxide synthase heme domain in complex with 4-(2-(((2-Aminoquinolin-7-yl)methyl)amino)ethyl)-2-methylbenzonitrile Deposited 2017-05-19 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：residues 41-480
Chain B 41–480（440 aa） Fragment：residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 9P7 4-(2-{[(2-aminoquinolin-7-yl)methyl]amino}ethyl)-2-methylbenzonitrile × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 ZN ZINC ION × 1 GOL GLYCEROL × 1 GD GADOLINIUM ATOM × 2 CL CHLORIDE ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 MM TCEP
Resolution 2.15 Å R-free 0.268
5VVB Structure of human endothelial nitric oxide synthase heme domain in complex with 4-(2-(((2-Aminoquinolin-7-yl)methyl)amino)ethyl)-2-methylbenzonitrile Deposited 2017-05-19 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：residues 41-480
Chain D 41–480（440 aa） Fragment：residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 9P7 4-(2-{[(2-aminoquinolin-7-yl)methyl]amino}ethyl)-2-methylbenzonitrile × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 ZN ZINC ION × 1 GOL GLYCEROL × 1 GD GADOLINIUM ATOM × 2 CL CHLORIDE ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 MM TCEP
Resolution 2.15 Å R-free 0.268
5VVC Structure of human endothelial nitric oxide synthase heme domain in complex with 4-(2-(((2-Amino-4-methylquinolin-7-yl)methyl)amino)ethyl)-2-methylbenzonitrile Deposited 2017-05-19 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：residues 41-480
Chain B 41–480（440 aa） Fragment：residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 9OJ 4-(2-{[(2-amino-4-methylquinolin-7-yl)methyl]amino}ethyl)-2-methylbenzonitrile × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.40 Å R-free 0.272
5VVC Structure of human endothelial nitric oxide synthase heme domain in complex with 4-(2-(((2-Amino-4-methylquinolin-7-yl)methyl)amino)ethyl)-2-methylbenzonitrile Deposited 2017-05-19 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：residues 41-480
Chain D 41–480（440 aa） Fragment：residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 9OJ 4-(2-{[(2-amino-4-methylquinolin-7-yl)methyl]amino}ethyl)-2-methylbenzonitrile × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.40 Å R-free 0.272
5VVD Structure of human endothelial nitric oxide synthase heme domain in complex with 4-(2-(((2-Amino-4-methylquinolin-7-yl)methyl)amino)ethyl)benzonitrile Deposited 2017-05-19 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：residues 41-480
Chain B 41–480（440 aa） Fragment：residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 9OG 4-(2-{[(2-amino-4-methylquinolin-7-yl)methyl]amino}ethyl)benzonitrile × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 7 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 MM TCEP
Resolution 2.25 Å R-free 0.269
5VVD Structure of human endothelial nitric oxide synthase heme domain in complex with 4-(2-(((2-Amino-4-methylquinolin-7-yl)methyl)amino)ethyl)benzonitrile Deposited 2017-05-19 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：residues 41-480
Chain D 41–480（440 aa） Fragment：residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 9OG 4-(2-{[(2-amino-4-methylquinolin-7-yl)methyl]amino}ethyl)benzonitrile × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 MM TCEP
Resolution 2.25 Å R-free 0.269
5XOF Crystal structure of human paired immunoglobulin-like type 2 receptor alpha with synthesized glycopeptide I Deposited 2017-05-28 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Other combination Heteromer；Protein × 2 PDB declaration: dimeric
Chain O 30–36（7 aa）
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；293 K；0.1M Tris-HCl pH8.5, 25% (w/v) PEG 6000
Resolution 1.96 Å R-free 0.269
5XOF Crystal structure of human paired immunoglobulin-like type 2 receptor alpha with synthesized glycopeptide I Deposited 2017-05-28 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Other combination Heteromer；Protein × 2 PDB declaration: dimeric
Chain P 30–36（7 aa）
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；293 K；0.1M Tris-HCl pH8.5, 25% (w/v) PEG 6000
Resolution 1.96 Å R-free 0.269
5XOF Crystal structure of human paired immunoglobulin-like type 2 receptor alpha with synthesized glycopeptide I Deposited 2017-05-28 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Other combination Heteromer；Protein × 2 PDB declaration: dimeric
Chain Q 30–36（7 aa）
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；293 K；0.1M Tris-HCl pH8.5, 25% (w/v) PEG 6000
Resolution 1.96 Å R-free 0.269
5XOF Crystal structure of human paired immunoglobulin-like type 2 receptor alpha with synthesized glycopeptide I Deposited 2017-05-28 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 4 Other combination Heteromer；Protein × 2 PDB declaration: dimeric
Chain R 30–36（7 aa）
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；293 K；0.1M Tris-HCl pH8.5, 25% (w/v) PEG 6000
Resolution 1.96 Å R-free 0.269
6AV6 Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(3-Fluoro-5-(3-(methylamino)propyl)phenethyl)-4-methylpyridin-2-amine Deposited 2017-09-01 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：UNP residues 41-480
Chain B 41–480（440 aa） Fragment：UNP residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 W68 6-(2-{3-fluoro-5-[3-(methylamino)propyl]phenyl}ethyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 MM TCEP
Resolution 2.08 Å R-free 0.239
6AV6 Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(3-Fluoro-5-(3-(methylamino)propyl)phenethyl)-4-methylpyridin-2-amine Deposited 2017-09-01 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：UNP residues 41-480
Chain D 41–480（440 aa） Fragment：UNP residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 W68 6-(2-{3-fluoro-5-[3-(methylamino)propyl]phenyl}ethyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 3 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 MM TCEP
Resolution 2.08 Å R-free 0.239
6AV7 Structure of human endothelial nitric oxide synthase heme domain in complex with HW69 Deposited 2017-09-01 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：UNP residues 41-480
Chain B 41–480（440 aa） Fragment：UNP residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 W69 6-(2-{3-[3-(dimethylamino)propyl]-5-fluorophenyl}ethyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 MM TCEP
Resolution 1.92 Å R-free 0.254
6AV7 Structure of human endothelial nitric oxide synthase heme domain in complex with HW69 Deposited 2017-09-01 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：UNP residues 41-480
Chain D 41–480（440 aa） Fragment：UNP residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 W69 6-(2-{3-[3-(dimethylamino)propyl]-5-fluorophenyl}ethyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 MM TCEP
Resolution 1.92 Å R-free 0.254
6CIE Structure of human endothelial nitric oxide synthase heme domain in complex with N-(1-(2-(Ethyl(methyl)amino)ethyl)-1,2,3,4-tetrahydroquino-lin-6-yl)thiophene-2-carboximidamide Deposited 2018-02-23 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 7R2 N-(1-{2-[ethyl(methyl)amino]ethyl}-1,2,3,4-tetrahydroquinolin-6-yl)thiophene-2-carboximidamide × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.95 Å R-free 0.262
6CIE Structure of human endothelial nitric oxide synthase heme domain in complex with N-(1-(2-(Ethyl(methyl)amino)ethyl)-1,2,3,4-tetrahydroquino-lin-6-yl)thiophene-2-carboximidamide Deposited 2018-02-23 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 7R2 N-(1-{2-[ethyl(methyl)amino]ethyl}-1,2,3,4-tetrahydroquinolin-6-yl)thiophene-2-carboximidamide × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.95 Å R-free 0.262
6CIF Structure of the human endothelial nitric oxide synthase heme domain in complex with N-(1-(Piperidin-4-yl)indolin-5-yl)thiophene-2-carboximidamide Deposited 2018-02-23 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 F2J N-[1-(piperidin-4-yl)-1H-indol-5-yl]thiophene-2-carboximidamide × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.20 Å R-free 0.246
6CIF Structure of the human endothelial nitric oxide synthase heme domain in complex with N-(1-(Piperidin-4-yl)indolin-5-yl)thiophene-2-carboximidamide Deposited 2018-02-23 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 F2J N-[1-(piperidin-4-yl)-1H-indol-5-yl]thiophene-2-carboximidamide × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；12-15% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.20 Å R-free 0.246
6POU Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(4-(2-Aminoethyl)phenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 M16 7-[4-(2-aminoethyl)phenyl]-4-methylquinolin-2-amine × 4 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 7 ZN ZINC ION × 3 GD GADOLINIUM ATOM × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.19 Å R-free 0.243
6POU Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(4-(2-Aminoethyl)phenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 M16 7-[4-(2-aminoethyl)phenyl]-4-methylquinolin-2-amine × 4 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 ZN ZINC ION × 3 GD GADOLINIUM ATOM × 3 GOL GLYCEROL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.19 Å R-free 0.243
6POU Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(4-(2-Aminoethyl)phenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain E 41–480（440 aa）
Chain F 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 M16 7-[4-(2-aminoethyl)phenyl]-4-methylquinolin-2-amine × 4 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 ZN ZINC ION × 3 GD GADOLINIUM ATOM × 1 GOL GLYCEROL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.19 Å R-free 0.243
6POV Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(3-(2-Aminoethyl)phenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 OUG 7-[3-(aminomethyl)phenyl]-4-methylquinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 7 ZN ZINC ION × 1 ACT ACETATE ION × 2 GOL GLYCEROL × 1 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.05 Å R-free 0.247
6POV Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(3-(2-Aminoethyl)phenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 OUG 7-[3-(aminomethyl)phenyl]-4-methylquinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 7 ZN ZINC ION × 1 ACT ACETATE ION × 2 GOL GLYCEROL × 1 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.05 Å R-free 0.247
6POW Structure of human endotheial nitric oxide synthase heme domain in complex with 7-(5-(Aminomethyl)pyridin-3-yl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 1 OUA 7-[5-(aminomethyl)pyridin-3-yl]-4-methylquinolin-2-amine × 3 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.15 Å R-free 0.277
6POW Structure of human endotheial nitric oxide synthase heme domain in complex with 7-(5-(Aminomethyl)pyridin-3-yl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 1 OUA 7-[5-(aminomethyl)pyridin-3-yl]-4-methylquinolin-2-amine × 3 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.15 Å R-free 0.277
6POX Structure of human endothelialnitric oxide synthase heme domain in complex with 7-(3-(Aminomethyl)-4-ethoxyphenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 OSJ 7-[3-(aminomethyl)-4-ethoxyphenyl]-4-methylquinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 8 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.20 Å R-free 0.241
6POX Structure of human endothelialnitric oxide synthase heme domain in complex with 7-(3-(Aminomethyl)-4-ethoxyphenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 OSJ 7-[3-(aminomethyl)-4-ethoxyphenyl]-4-methylquinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.20 Å R-free 0.241
6POY Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(3-(Aminomethyl)-4-propoxyphenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 OSG 7-[3-(aminomethyl)-4-propoxyphenyl]-4-methylquinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.30 Å R-free 0.261
6POY Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(3-(Aminomethyl)-4-propoxyphenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 OSG 7-[3-(aminomethyl)-4-propoxyphenyl]-4-methylquinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.30 Å R-free 0.261
6POZ Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(3-(Aminomethyl)-4-isopropoxyphenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 1 OSD 7-{3-(aminomethyl)-4-[(propan-2-yl)oxy]phenyl}-4-methylquinolin-2-amine × 3 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.20 Å R-free 0.251
6POZ Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(3-(Aminomethyl)-4-isopropoxyphenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 1 OSD 7-{3-(aminomethyl)-4-[(propan-2-yl)oxy]phenyl}-4-methylquinolin-2-amine × 3 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 3 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.20 Å R-free 0.251
6PP0 Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(3-(Aminomethyl)-4-(cyclobutylmethoxy)phenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 OUP 7-[3-(aminomethyl)-4-(cyclobutylmethoxy)phenyl]-4-methylquinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.97 Å R-free 0.261
6PP0 Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(3-(Aminomethyl)-4-(cyclobutylmethoxy)phenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 OUP 7-[3-(aminomethyl)-4-(cyclobutylmethoxy)phenyl]-4-methylquinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.97 Å R-free 0.261
6PP1 Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(3-(Aminomethyl)-4-(cyclopropylmethoxy)phenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 OU1 7-[3-(aminomethyl)-4-(cyclopropylmethoxy)phenyl]-4-methylquinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 2 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.76 Å R-free 0.212
6PP1 Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(3-(Aminomethyl)-4-(cyclopropylmethoxy)phenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 OU1 7-[3-(aminomethyl)-4-(cyclopropylmethoxy)phenyl]-4-methylquinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 2 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.76 Å R-free 0.212
6PP2 Structure of human endothelial nitric oxide synthase heme domain in complex with 4-((4-(2-Amino-4-methylquinolin-7-yl)-2-(aminomethyl)phenoxy)methyl)benzonitrile Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 OUM 4-{[2-(aminomethyl)-4-(2-amino-4-methylquinolin-7-yl)phenoxy]methyl}benzonitrile × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；0-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.02 Å R-free 0.246
6PP2 Structure of human endothelial nitric oxide synthase heme domain in complex with 4-((4-(2-Amino-4-methylquinolin-7-yl)-2-(aminomethyl)phenoxy)methyl)benzonitrile Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 OUM 4-{[2-(aminomethyl)-4-(2-amino-4-methylquinolin-7-yl)phenoxy]methyl}benzonitrile × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；0-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.02 Å R-free 0.246
6PP3 Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(3-(Aminomethyl)-4-(pyridin-2-ylmethoxy)phenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 OS7 7-{3-(aminomethyl)-4-[(pyridin-2-yl)methoxy]phenyl}-4-methylquinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 8 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.95 Å R-free 0.260
6PP3 Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(3-(Aminomethyl)-4-(pyridin-2-ylmethoxy)phenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 OS7 7-{3-(aminomethyl)-4-[(pyridin-2-yl)methoxy]phenyl}-4-methylquinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 3 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.95 Å R-free 0.260
6PP4 Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(3-(Aminomethyl)-4-(pyridin-3-ylmethoxy)phenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 OUS 7-{3-(aminomethyl)-4-[(pyridin-3-yl)methoxy]phenyl}-4-methylquinolin-2-amine × 2 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.20 Å R-free 0.238
6PP4 Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(3-(Aminomethyl)-4-(pyridin-3-ylmethoxy)phenyl)-4-methylquinolin-2-amine Deposited 2019-07-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 3 OUS 7-{3-(aminomethyl)-4-[(pyridin-3-yl)methoxy]phenyl}-4-methylquinolin-2-amine × 2 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.20 Å R-free 0.238
7M56 Structure of human endothelial nitric oxide synthase heme domain in complex with 7-((3-(3-aminophenethyl)phenoxy)methyl)quinolin-2-amine Deposited 2021-03-22 Different mutation/modification Different ligand/ion Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 V5G 7-({3-[2-(6-aminopyridin-2-yl)ethyl]phenoxy}methyl)quinolin-2-amine × 3 ACT ACETATE ION × 3 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 2 ZN ZINC ION × 1 GOL GLYCEROL × 2 GD GADOLINIUM ATOM × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.96 Å R-free 0.210
7TSG Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(3-(dimethylamino)propyl)-4-methylpyridin-2-amine Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 KL0 6-[3-(dimethylamino)propyl]-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.85 Å R-free 0.262
7TSG Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(3-(dimethylamino)propyl)-4-methylpyridin-2-amine Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 KL0 6-[3-(dimethylamino)propyl]-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.85 Å R-free 0.262
7TSH Structure of human endothelial nitric oxide synthase heme domain in complex with 4-methyl-6-(3-(methylamino)propyl)pyridin-2-amine Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 KKU 4-methyl-6-[3-(methylamino)propyl]pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.15 Å R-free 0.270
7TSH Structure of human endothelial nitric oxide synthase heme domain in complex with 4-methyl-6-(3-(methylamino)propyl)pyridin-2-amine Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 KKU 4-methyl-6-[3-(methylamino)propyl]pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.15 Å R-free 0.270
7TSI Structure of human endothelial nitric oxide synthase heme domain in complex with 4-methyl-6-(3-((methylamino)methyl)phenyl)pyridin-2-amine Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 KMI 4-methyl-6-{3-[(methylamino)methyl]phenyl}pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.10 Å R-free 0.277
7TSI Structure of human endothelial nitric oxide synthase heme domain in complex with 4-methyl-6-(3-((methylamino)methyl)phenyl)pyridin-2-amine Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 KMI 4-methyl-6-{3-[(methylamino)methyl]phenyl}pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 6 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.10 Å R-free 0.277
7TSK Structure of human endothelial nitric oxide synthase heme domain in complex with 4-methyl-6-(3-(methylamino)prop-1-yn-1-yl)pyridin-2-amine Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 K9C 4-methyl-6-[3-(methylamino)prop-1-yn-1-yl]pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.05 Å R-free 0.264
7TSK Structure of human endothelial nitric oxide synthase heme domain in complex with 4-methyl-6-(3-(methylamino)prop-1-yn-1-yl)pyridin-2-amine Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 K9C 4-methyl-6-[3-(methylamino)prop-1-yn-1-yl]pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.05 Å R-free 0.264
7TSL Structure of human endothelial nitric oxide synthase heme domain in complex with 4-methyl-6-(3-(4-methylpiperazin-1-yl)propyl)pyridin-2-amine Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 KMR 4-methyl-6-[3-(4-methylpiperazin-1-yl)propyl]pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.90 Å R-free 0.254
7TSL Structure of human endothelial nitric oxide synthase heme domain in complex with 4-methyl-6-(3-(4-methylpiperazin-1-yl)propyl)pyridin-2-amine Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 KMR 4-methyl-6-[3-(4-methylpiperazin-1-yl)propyl]pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 2 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.90 Å R-free 0.254
7TSM Structure of human endothelial nitric oxide synthase heme domain in complex with 4-methyl-6-(3-(4-methylpiperazin-1-yl)prop-1-yn-1-yl)pyridin-2-amine bishydrochloride Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 K90 4-methyl-6-[3-(4-methylpiperazin-1-yl)prop-1-yn-1-yl]pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.85 Å R-free 0.237
7TSM Structure of human endothelial nitric oxide synthase heme domain in complex with 4-methyl-6-(3-(4-methylpiperazin-1-yl)prop-1-yn-1-yl)pyridin-2-amine bishydrochloride Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 K90 4-methyl-6-[3-(4-methylpiperazin-1-yl)prop-1-yn-1-yl]pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 2 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.85 Å R-free 0.237
7TSN Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(3-(3,3-difluoroazetidin-1-yl)prop-1-yn-1-yl)-4-methylpyridin-2-amine Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 K7U 6-[3-(3,3-difluoroazetidin-1-yl)prop-1-yn-1-yl]-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.08 Å R-free 0.262
7TSN Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(3-(3,3-difluoroazetidin-1-yl)prop-1-yn-1-yl)-4-methylpyridin-2-amine Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 K7U 6-[3-(3,3-difluoroazetidin-1-yl)prop-1-yn-1-yl]-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.08 Å R-free 0.262
7TSO Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(3-(3,3-difluoroazetidin-1-yl)propyl)-4-methylpyridin-2-amine Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 K8F 6-[3-(3,3-difluoroazetidin-1-yl)propyl]-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.00 Å R-free 0.273
7TSO Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(3-(3,3-difluoroazetidin-1-yl)propyl)-4-methylpyridin-2-amine Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 K8F 6-[3-(3,3-difluoroazetidin-1-yl)propyl]-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.00 Å R-free 0.273
7TSP Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(3-(4,4-difluoropiperidin-1-yl)prop-1-yn-1-yl)-4-methylpyridin-2-amine Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 K8O 6-[3-(4,4-difluoropiperidin-1-yl)prop-1-yn-1-yl]-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.00 Å R-free 0.267
7TSP Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(3-(4,4-difluoropiperidin-1-yl)prop-1-yn-1-yl)-4-methylpyridin-2-amine Deposited 2022-01-31 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 K8O 6-[3-(4,4-difluoropiperidin-1-yl)prop-1-yn-1-yl]-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.00 Å R-free 0.267
7UAO Structure of human endothelial nitric oxide synthase heme domain in complex with (6-(3-(4,4-difluoropiperidin-1-yl)propyl)-4-methylpyridin-2-amine) Deposited 2022-03-13 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 M5L 6-[3-(4,4-difluoropiperidin-1-yl)propyl]-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.90 Å R-free 0.245
7UAO Structure of human endothelial nitric oxide synthase heme domain in complex with (6-(3-(4,4-difluoropiperidin-1-yl)propyl)-4-methylpyridin-2-amine) Deposited 2022-03-13 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 M5L 6-[3-(4,4-difluoropiperidin-1-yl)propyl]-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 4 CL CHLORIDE ION × 3 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.90 Å R-free 0.245
8FGN Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(5-(2-(dimethylamino)ethyl)-2,3-difluorophenethyl)pyridin-2-amine Deposited 2022-12-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 XVO 6-(2-{5-[2-(dimethylamino)ethyl]-2,3-difluorophenyl}ethyl)pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.20 Å R-free 0.236
8FGN Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(5-(2-(dimethylamino)ethyl)-2,3-difluorophenethyl)pyridin-2-amine Deposited 2022-12-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 XVO 6-(2-{5-[2-(dimethylamino)ethyl]-2,3-difluorophenyl}ethyl)pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.20 Å R-free 0.236
8FGO Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(5-(2-(dimethylamino)ethyl)-2,3-difluorophenethyl)-4-methylpyridin-2-amine Deposited 2022-12-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 XVU 6-(2-{5-[2-(dimethylamino)ethyl]-2,3-difluorophenyl}ethyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.80 Å R-free 0.227
8FGO Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(5-(2-(dimethylamino)ethyl)-2,3-difluorophenethyl)-4-methylpyridin-2-amine Deposited 2022-12-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 XVU 6-(2-{5-[2-(dimethylamino)ethyl]-2,3-difluorophenyl}ethyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.80 Å R-free 0.227
8FGP Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(5-(2-(dimethylamino)ethyl)-2,3-difluorophenethyl)-4-methoxypyridin-2-amine Deposited 2022-12-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 XW5 6-(2-{5-[2-(dimethylamino)ethyl]-2,3-difluorophenyl}ethyl)-4-methoxypyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.88 Å R-free 0.229
8FGP Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(5-(2-(dimethylamino)ethyl)-2,3-difluorophenethyl)-4-methoxypyridin-2-amine Deposited 2022-12-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 XW5 6-(2-{5-[2-(dimethylamino)ethyl]-2,3-difluorophenyl}ethyl)-4-methoxypyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.88 Å R-free 0.229
8FGQ Structure of human endothelial nitric oxide synthase heme domain in complex with 4-(5-(2-(dimethylamino)ethyl)-2,3-difluorophenethyl)-6-methylpyrimidin-2-amine Deposited 2022-12-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 V80 4-(2-{5-[2-(dimethylamino)ethyl]-2,3-difluorophenyl}ethyl)-6-methylpyrimidin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 ZN ZINC ION × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.20 Å R-free 0.246
8FGQ Structure of human endothelial nitric oxide synthase heme domain in complex with 4-(5-(2-(dimethylamino)ethyl)-2,3-difluorophenethyl)-6-methylpyrimidin-2-amine Deposited 2022-12-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 V80 4-(2-{5-[2-(dimethylamino)ethyl]-2,3-difluorophenyl}ethyl)-6-methylpyrimidin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 ZN ZINC ION × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 GOL GLYCEROL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.20 Å R-free 0.246
8FGR Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(5-(2-aminoethyl)-2,3-difluorophenethyl)-4-methylpyridin-2-amine Deposited 2022-12-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 XVZ 6-{2-[5-(2-aminoethyl)-2,3-difluorophenyl]ethyl}-4-methylpyridin-2-amine × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.98 Å R-free 0.263
8FGR Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(5-(2-aminoethyl)-2,3-difluorophenethyl)-4-methylpyridin-2-amine Deposited 2022-12-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 XVZ 6-{2-[5-(2-aminoethyl)-2,3-difluorophenyl]ethyl}-4-methylpyridin-2-amine × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.98 Å R-free 0.263
8FGS Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(5-(2-(diethylamino)ethyl)-2,3-difluorophenethyl)-4-methylpyridin-2-amine Deposited 2022-12-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 XVF 6-(2-{5-[2-(diethylamino)ethyl]-2,3-difluorophenyl}ethyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 6 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.84 Å R-free 0.218
8FGS Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(5-(2-(diethylamino)ethyl)-2,3-difluorophenethyl)-4-methylpyridin-2-amine Deposited 2022-12-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 XVF 6-(2-{5-[2-(diethylamino)ethyl]-2,3-difluorophenyl}ethyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.84 Å R-free 0.218
8FGT Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(2,3-difluoro-5-(2-(4-methylpiperazin-1-yl)ethyl)phenethyl)-4-methylpyridin-2-amine Deposited 2022-12-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 XVK 6-(2-{2,3-difluoro-5-[2-(4-methylpiperazin-1-yl)ethyl]phenyl}ethyl)-4-methylpyridin-2-amine × 2 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.90 Å R-free 0.241
8FGT Structure of human endothelial nitric oxide synthase heme domain in complex with 6-(2,3-difluoro-5-(2-(4-methylpiperazin-1-yl)ethyl)phenethyl)-4-methylpyridin-2-amine Deposited 2022-12-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 XVK 6-(2-{2,3-difluoro-5-[2-(4-methylpiperazin-1-yl)ethyl]phenyl}ethyl)-4-methylpyridin-2-amine × 2 GOL GLYCEROL × 6 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 1.90 Å R-free 0.241
8FGU Structure of human endothelial nitric oxide synthase heme domain in complex with 4-(difluoromethyl)-6-(5-(2-(dimethylamino)ethyl)-2,3-difluorophenethyl)pyridin-2-amine Deposited 2022-12-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 XVA 4-(difluoromethyl)-6-(2-{5-[2-(dimethylamino)ethyl]-2,3-difluorophenyl}ethyl)pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 2 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.00 Å R-free 0.252
8FGU Structure of human endothelial nitric oxide synthase heme domain in complex with 4-(difluoromethyl)-6-(5-(2-(dimethylamino)ethyl)-2,3-difluorophenethyl)pyridin-2-amine Deposited 2022-12-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 XVA 4-(difluoromethyl)-6-(2-{5-[2-(dimethylamino)ethyl]-2,3-difluorophenyl}ethyl)pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 2 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GdCl3 10% glycerol, 5 mM TCEP
Resolution 2.00 Å R-free 0.252
8UFR Structure of human endothelial nitric oxide synthase heme domain in complex with 4-methyl-7-(4-methyl-2,3,4,5-tetrahydrobenzo[f][1,4]oxazepin-7-yl)quinolin-2-amine dihydrochloride Deposited 2023-10-04 Different mutation/modification Different ligand/ion Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 WK2 (7M)-4-methyl-7-(4-methyl-2,3,4,5-tetrahydro-1,4-benzoxazepin-7-yl)quinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.87 Å R-free 0.251
8UFR Structure of human endothelial nitric oxide synthase heme domain in complex with 4-methyl-7-(4-methyl-2,3,4,5-tetrahydrobenzo[f][1,4]oxazepin-7-yl)quinolin-2-amine dihydrochloride Deposited 2023-10-04 Different mutation/modification Different ligand/ion Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 WK2 (7M)-4-methyl-7-(4-methyl-2,3,4,5-tetrahydro-1,4-benzoxazepin-7-yl)quinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 ZN ZINC ION × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.87 Å R-free 0.251
8UFT Structure of human endothelial nitric oxide synthase P370N mutant heme domain in complex with 4-methyl-7-(4-methyl-2,3,4,5-tetrahydrobenzo[f][1,4]oxazepin-7-yl)quinolin-2-amine Deposited 2023-10-04 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Mutation：P370N Mutation：P370N HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 WK2 (7M)-4-methyl-7-(4-methyl-2,3,4,5-tetrahydro-1,4-benzoxazepin-7-yl)quinolin-2-amine × 2 ACT ACETATE ION × 3 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 3 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 ZN ZINC ION × 1 CA CALCIUM ION × 3 GD GADOLINIUM ATOM × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；8-10% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.78 Å R-free 0.210
8UFT Structure of human endothelial nitric oxide synthase P370N mutant heme domain in complex with 4-methyl-7-(4-methyl-2,3,4,5-tetrahydrobenzo[f][1,4]oxazepin-7-yl)quinolin-2-amine Deposited 2023-10-04 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Mutation：P370N Mutation：P370N HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 WK2 (7M)-4-methyl-7-(4-methyl-2,3,4,5-tetrahydro-1,4-benzoxazepin-7-yl)quinolin-2-amine × 2 ACT ACETATE ION × 3 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 ZN ZINC ION × 1 GD GADOLINIUM ATOM × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；8-10% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.78 Å R-free 0.210
8UFU Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(9-amino-6,7,8,9-tetrahydro-5H-benzo[7]annulen-2-yl)-4-methylquinolin-2-amine Deposited 2023-10-04 Different mutation/modification Different ligand/ion Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 WRI (7M)-7-[(9S)-9-amino-6,7,8,9-tetrahydro-5H-benzo[7]annulen-2-yl]-4-methylquinolin-2-amine × 4 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 ZN ZINC ION × 3 CA CALCIUM ION × 1 GD GADOLINIUM ATOM × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.05 Å R-free 0.256
8UFU Structure of human endothelial nitric oxide synthase heme domain in complex with 7-(9-amino-6,7,8,9-tetrahydro-5H-benzo[7]annulen-2-yl)-4-methylquinolin-2-amine Deposited 2023-10-04 Different mutation/modification Different ligand/ion Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 WRI (7M)-7-[(9S)-9-amino-6,7,8,9-tetrahydro-5H-benzo[7]annulen-2-yl]-4-methylquinolin-2-amine × 4 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 2 CL CHLORIDE ION × 2 ZN ZINC ION × 3 CA CALCIUM ION × 1 GD GADOLINIUM ATOM × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.05 Å R-free 0.256
9C1Z Structure of human endothelial nitric oxide synthase heme domain in complex with 7-((3-(((4-(6-aminopyridin-2-yl)butyl)amino)methyl)phenoxy)methyl)quinolin-2-amine Deposited 2024-05-30 Different mutation/modification Different ligand/ion Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 V5D 7-{[3-({[4-(6-aminopyridin-2-yl)butyl]amino}methyl)phenoxy]methyl}quinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.00 Å R-free 0.245
9C1Z Structure of human endothelial nitric oxide synthase heme domain in complex with 7-((3-(((4-(6-aminopyridin-2-yl)butyl)amino)methyl)phenoxy)methyl)quinolin-2-amine Deposited 2024-05-30 Different mutation/modification Different ligand/ion Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 V5D 7-{[3-({[4-(6-aminopyridin-2-yl)butyl]amino}methyl)phenoxy]methyl}quinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 2 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE, 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.00 Å R-free 0.245
9CW2 Structure of human endothelial nitric oxide synthase heme domain bound with 4-methyl-6-(3-((methylamino)methyl)phenyl)pyridin-2-amine dihydrochloride Deposited 2024-07-29 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 KMI 4-methyl-6-{3-[(methylamino)methyl]phenyl}pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 2.10 Å R-free 0.277
9CW2 Structure of human endothelial nitric oxide synthase heme domain bound with 4-methyl-6-(3-((methylamino)methyl)phenyl)pyridin-2-amine dihydrochloride Deposited 2024-07-29 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 KMI 4-methyl-6-{3-[(methylamino)methyl]phenyl}pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 6 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 2.10 Å R-free 0.277
9CW4 Structure of human endothelial nitric oxide synthase heme domain bound with 6-(3-fluoro-5-((methylamino)methyl)phenyl)-4-methylpyridin-2-amine dihydrochloride Deposited 2024-07-29 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0H (6M)-6-{3-fluoro-5-[(methylamino)methyl]phenyl}-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 2.00 Å R-free 0.284
9CW4 Structure of human endothelial nitric oxide synthase heme domain bound with 6-(3-fluoro-5-((methylamino)methyl)phenyl)-4-methylpyridin-2-amine dihydrochloride Deposited 2024-07-29 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0H (6M)-6-{3-fluoro-5-[(methylamino)methyl]phenyl}-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 2.00 Å R-free 0.284
9CW5 Structure of human endothelial nitric oxide synthase heme domain bound with 4-methyl-6-(3-((methylamino)methyl)-5-(trifluoromethyl)phenyl)pyridin-2-amine dihydrochloride Deposited 2024-07-29 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0F (6P)-4-methyl-6-{3-[(methylamino)methyl]-5-(trifluoromethyl)phenyl}pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 1.88 Å R-free 0.228
9CW5 Structure of human endothelial nitric oxide synthase heme domain bound with 4-methyl-6-(3-((methylamino)methyl)-5-(trifluoromethyl)phenyl)pyridin-2-amine dihydrochloride Deposited 2024-07-29 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0F (6P)-4-methyl-6-{3-[(methylamino)methyl]-5-(trifluoromethyl)phenyl}pyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 1.88 Å R-free 0.228
9CW6 Structure of human endothelial nitric oxide synthase heme domain bound with 6-(3-chloro-5-((dimethylamino)methyl)phenyl)-4-methylpyridin-2-amine dihydrochloride Deposited 2024-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：heme domain
Chain B 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0N (6P)-6-{3-chloro-5-[(dimethylamino)methyl]phenyl}-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 2.15 Å R-free 0.266
9CW6 Structure of human endothelial nitric oxide synthase heme domain bound with 6-(3-chloro-5-((dimethylamino)methyl)phenyl)-4-methylpyridin-2-amine dihydrochloride Deposited 2024-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：heme domain
Chain D 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0N (6P)-6-{3-chloro-5-[(dimethylamino)methyl]phenyl}-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 2.15 Å R-free 0.266
9CW7 Structure of human endothelial nitric oxide synthase heme domain bound with 4-methyl-5'-((methylamino)methyl)-[2,3'-bipyridin]-6-amine dihydrochloride Deposited 2024-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：heme domain
Chain B 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0E (2M)-4-methyl-5'-[(methylamino)methyl][2,3'-bipyridin]-6-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 3 ZN ZINC ION × 1 ACT ACETATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 1.83 Å R-free 0.228
9CW7 Structure of human endothelial nitric oxide synthase heme domain bound with 4-methyl-5'-((methylamino)methyl)-[2,3'-bipyridin]-6-amine dihydrochloride Deposited 2024-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：heme domain
Chain D 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0E (2M)-4-methyl-5'-[(methylamino)methyl][2,3'-bipyridin]-6-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 3 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 1 ZN ZINC ION × 1 ACT ACETATE ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 1.83 Å R-free 0.228
9CW8 Structure of human endothelial nitric oxide synthase heme domain bound with 3-(6-amino-4-methylpyridin-2-yl)-5-((methylamino)methyl)benzonitrile dihydrochloride Deposited 2024-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：heme domain
Chain B 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A3F (3P)-3-(6-amino-4-methylpyridin-2-yl)-5-[(methylamino)methyl]benzonitrile × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 1.92 Å R-free 0.232
9CW8 Structure of human endothelial nitric oxide synthase heme domain bound with 3-(6-amino-4-methylpyridin-2-yl)-5-((methylamino)methyl)benzonitrile dihydrochloride Deposited 2024-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：heme domain
Chain D 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A3F (3P)-3-(6-amino-4-methylpyridin-2-yl)-5-[(methylamino)methyl]benzonitrile × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 1.92 Å R-free 0.232
9CW9 Structure of human endothelial nitric oxide synthase heme domain bound with 6-(2,3-difluoro-5-((methylamino)methyl)phenyl)-4-methylpyridin-2-amine dihydrochloride Deposited 2024-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：heme domain
Chain B 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0B (6M)-6-{2,3-difluoro-5-[(methylamino)methyl]phenyl}-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 2.12 Å R-free 0.256
9CW9 Structure of human endothelial nitric oxide synthase heme domain bound with 6-(2,3-difluoro-5-((methylamino)methyl)phenyl)-4-methylpyridin-2-amine dihydrochloride Deposited 2024-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：heme domain
Chain D 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0B (6M)-6-{2,3-difluoro-5-[(methylamino)methyl]phenyl}-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 2.12 Å R-free 0.256
9CWD Structure of human endothelial nitric oxide synthase heme domain bound with 6-(5-((dimethylamino)methyl)-2,3-difluorophenyl)-4-methylpyridin-2-amine dihydrochloride Deposited 2024-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：heme domain
Chain B 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0K (6M)-6-{5-[(dimethylamino)methyl]-2,3-difluorophenyl}-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 1.92 Å R-free 0.252
9CWD Structure of human endothelial nitric oxide synthase heme domain bound with 6-(5-((dimethylamino)methyl)-2,3-difluorophenyl)-4-methylpyridin-2-amine dihydrochloride Deposited 2024-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：heme domain
Chain D 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0K (6M)-6-{5-[(dimethylamino)methyl]-2,3-difluorophenyl}-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 1.92 Å R-free 0.252
9CWI Structure of human endothelial nitric oxide synthase heme domain bound with 6-(5-((3,3-difluoroazetidin-1-yl)methyl)-2,3-difluorophenyl)-4-methylpyridin-2-amine dihydrochloride Deposited 2024-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：heme domain
Chain B 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0D (6M)-6-{5-[(3,3-difluoroazetidin-1-yl)methyl]-2,3-difluorophenyl}-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 1.73 Å R-free 0.222
9CWI Structure of human endothelial nitric oxide synthase heme domain bound with 6-(5-((3,3-difluoroazetidin-1-yl)methyl)-2,3-difluorophenyl)-4-methylpyridin-2-amine dihydrochloride Deposited 2024-07-29 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：heme domain
Chain D 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0D (6M)-6-{5-[(3,3-difluoroazetidin-1-yl)methyl]-2,3-difluorophenyl}-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 1.73 Å R-free 0.222
9CWJ Structure of human endothelial nitric oxide synthase heme domain bound with 6-(5-((4,4-difluoropiperidin-1-yl)methyl)-2,3-difluorophenyl)-4-methylpyridin-2-amine dihydrochloride Deposited 2024-07-29 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0A (6M)-6-{5-[(4,4-difluoropiperidin-1-yl)methyl]-2,3-difluorophenyl}-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 6 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 1.90 Å R-free 0.237
9CWJ Structure of human endothelial nitric oxide synthase heme domain bound with 6-(5-((4,4-difluoropiperidin-1-yl)methyl)-2,3-difluorophenyl)-4-methylpyridin-2-amine dihydrochloride Deposited 2024-07-29 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0A (6M)-6-{5-[(4,4-difluoropiperidin-1-yl)methyl]-2,3-difluorophenyl}-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 1.90 Å R-free 0.237
9CWK Structure of human endothelial nitric oxide synthase heme domain bound with 6-(2,3-difluoro-5-(2-(methylamino)ethyl)phenyl)-4-methylpyridin-2-amine dihydrochloride Deposited 2024-07-29 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0C (6M)-6-{2,3-difluoro-5-[2-(methylamino)ethyl]phenyl}-4-methylpyridin-2-amine × 2 ACT ACETATE ION × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 1.90 Å R-free 0.217
9CWK Structure of human endothelial nitric oxide synthase heme domain bound with 6-(2,3-difluoro-5-(2-(methylamino)ethyl)phenyl)-4-methylpyridin-2-amine dihydrochloride Deposited 2024-07-29 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1A0C (6M)-6-{2,3-difluoro-5-[2-(methylamino)ethyl]phenyl}-4-methylpyridin-2-amine × 2 ACT ACETATE ION × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 2 CL CHLORIDE ION × 2 GD3 GADOLINIUM ION × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；278 K；10-12% PEG3350, 0.1M Bis-Tris, 0.2-0.3M Magnesium Acetate, 0.1M GdCl3, 10% Glycerol, 5 mM TCEP
Resolution 1.90 Å R-free 0.217
9MWN Structure of human endothelial nitric oxide synthase heme domain bound with N-(4-(2-((3-(thiophene-2-carboximidamido)benzyl)amino)ethyl)phenyl)thiophene-2-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–481（441 aa） Fragment：heme domain
Chain B 41–481（441 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 H44 N-(4-{2-[(3-{[(E)-imino(thiophen-2-yl)methyl]amino}benzyl)amino]ethyl}phenyl)thiophene-2-carboximidamide × 2 ACT ACETATE ION × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 1 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.00 Å R-free 0.234
9MWN Structure of human endothelial nitric oxide synthase heme domain bound with N-(4-(2-((3-(thiophene-2-carboximidamido)benzyl)amino)ethyl)phenyl)thiophene-2-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–481（441 aa） Fragment：heme domain
Chain D 41–481（441 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 H44 N-(4-{2-[(3-{[(E)-imino(thiophen-2-yl)methyl]amino}benzyl)amino]ethyl}phenyl)thiophene-2-carboximidamide × 2 ACT ACETATE ION × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 2 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.00 Å R-free 0.234
9MWO Structure of human endothelial nitric oxide synthase heme domain bound with N-(4-(2-((3-(thiophene-2-carboximidamido)benzyl)amino)ethyl)phenyl)thiophene-2-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：heme domain
Chain B 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BTY N-[3-({[2-(4-{[(E)-(furan-2-yl)(imino)methyl]amino}phenyl)ethyl]amino}methyl)phenyl]furan-2-carboximidamide × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.76 Å R-free 0.233
9MWO Structure of human endothelial nitric oxide synthase heme domain bound with N-(4-(2-((3-(thiophene-2-carboximidamido)benzyl)amino)ethyl)phenyl)thiophene-2-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：heme domain
Chain D 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BTY N-[3-({[2-(4-{[(E)-(furan-2-yl)(imino)methyl]amino}phenyl)ethyl]amino}methyl)phenyl]furan-2-carboximidamide × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.76 Å R-free 0.233
9MWP Structure of human endothelial nitric oxide synthase heme domain bound with N-(4-(2-((3-(furan-3-carboximidamido)benzyl)amino)ethyl)phenyl)furan-3-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–481（441 aa） Fragment：heme domain
Chain B 41–481（441 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BT1 N-[3-({[2-(4-{[(E)-(furan-3-yl)(imino)methyl]amino}phenyl)ethyl]amino}methyl)phenyl]furan-3-carboximidamide × 2 ACT ACETATE ION × 4 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 5 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.86 Å R-free 0.214
9MWQ Structure of human endothelial nitric oxide synthase heme domain bound with N-(4-(2-((3-(isoxazole-3-carboximidamido)benzyl)amino)ethyl)phenyl)isoxazole-3-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：heme domain
Chain B 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BT0 N-[3-({[2-(4-{[(E)-imino(1,2-oxazol-3-yl)methyl]amino}phenyl)ethyl]amino}methyl)phenyl]-1,2-oxazole-3-carboximidamide × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 CA CALCIUM ION × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.94 Å R-free 0.211
9MWQ Structure of human endothelial nitric oxide synthase heme domain bound with N-(4-(2-((3-(isoxazole-3-carboximidamido)benzyl)amino)ethyl)phenyl)isoxazole-3-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：heme domain
Chain D 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BT0 N-[3-({[2-(4-{[(E)-imino(1,2-oxazol-3-yl)methyl]amino}phenyl)ethyl]amino}methyl)phenyl]-1,2-oxazole-3-carboximidamide × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.94 Å R-free 0.211
9MWR Structure of human endothelial nitric oxide synthase heme domain bound with N-(4-(2-((3-(thiazole-2-carboximidamido)benzyl)amino)ethyl)phenyl)thiazole-2-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：heme domain
Chain B 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BTV N-[3-({[2-(4-{[(Z)-imino(1,3-thiazol-2-yl)methyl]amino}phenyl)ethyl]amino}methyl)phenyl]-1,3-thiazole-2-carboximidamide × 2 ACT ACETATE ION × 1 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 CA CALCIUM ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.97 Å R-free 0.211
9MWR Structure of human endothelial nitric oxide synthase heme domain bound with N-(4-(2-((3-(thiazole-2-carboximidamido)benzyl)amino)ethyl)phenyl)thiazole-2-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：heme domain
Chain D 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BTV N-[3-({[2-(4-{[(Z)-imino(1,3-thiazol-2-yl)methyl]amino}phenyl)ethyl]amino}methyl)phenyl]-1,3-thiazole-2-carboximidamide × 2 ACT ACETATE ION × 1 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.97 Å R-free 0.211
9MWS Structure of human endothelial nitric oxide synthase heme domain bound with N-(3-(2-((3-(thiazole-5-carboximidamido)benzyl)amino)ethyl)phenyl)thiazole-5-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：heme domain
Chain B 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BTX N-[3-({[2-(3-{[(Z)-imino(1,3-thiazol-5-yl)methyl]amino}phenyl)ethyl]amino}methyl)phenyl]-1,3-thiazole-5-carboximidamide × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 3 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 ZN ZINC ION × 1 CA CALCIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.90 Å R-free 0.203
9MWS Structure of human endothelial nitric oxide synthase heme domain bound with N-(3-(2-((3-(thiazole-5-carboximidamido)benzyl)amino)ethyl)phenyl)thiazole-5-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：heme domain
Chain D 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BTX N-[3-({[2-(3-{[(Z)-imino(1,3-thiazol-5-yl)methyl]amino}phenyl)ethyl]amino}methyl)phenyl]-1,3-thiazole-5-carboximidamide × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 CA CALCIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.90 Å R-free 0.203
9MWT Structure of human endothelial nitric oxide synthase heme domain bound with N-(3-(2-((3-(furan-2-carboximidamido)benzyl)amino)ethyl)phenyl)furan-2-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：heme domain
Chain B 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BT6 N-[3-({[2-(3-{[(Z)-(furan-2-yl)(imino)methyl]amino}phenyl)ethyl]amino}methyl)phenyl]furan-2-carboximidamide × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 ACT ACETATE ION × 2 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 ZN ZINC ION × 1 GOL GLYCEROL × 1 CA CALCIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.90 Å R-free 0.233
9MWT Structure of human endothelial nitric oxide synthase heme domain bound with N-(3-(2-((3-(furan-2-carboximidamido)benzyl)amino)ethyl)phenyl)furan-2-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：heme domain
Chain D 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BT6 N-[3-({[2-(3-{[(Z)-(furan-2-yl)(imino)methyl]amino}phenyl)ethyl]amino}methyl)phenyl]furan-2-carboximidamide × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 ACT ACETATE ION × 2 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 GOL GLYCEROL × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.90 Å R-free 0.233
9MWU Structure of human endothelial nitric oxide synthase heme domain bound with N-(3-(((2-(3-(aminomethyl)-[1,1'-biphenyl]-4-yl)ethyl)amino)methyl)phenyl)furan-2-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–481（441 aa） Fragment：heme domain
Chain B 41–481（441 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BT2 N-{3-[({2-[3-(aminomethyl)[1,1'-biphenyl]-4-yl]ethyl}amino)methyl]phenyl}furan-2-carboximidamide × 2 ACT ACETATE ION × 3 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.74 Å R-free 0.182
9MWV Structure of human endothelial nitric oxide synthase heme domain bound with N-(3-(((2-(3-(aminomethyl)-[1,1'-biphenyl]-4-yl)ethyl)amino)methyl)phenyl)thiophene-2-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：heme domain
Chain B 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BT9 N-{3-[({2-[3-(aminomethyl)[1,1'-biphenyl]-4-yl]ethyl}amino)methyl]phenyl}thiophene-2-carboximidamide × 2 ACT ACETATE ION × 3 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 CA CALCIUM ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.90 Å R-free 0.218
9MWV Structure of human endothelial nitric oxide synthase heme domain bound with N-(3-(((2-(3-(aminomethyl)-[1,1'-biphenyl]-4-yl)ethyl)amino)methyl)phenyl)thiophene-2-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：heme domain
Chain D 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BT9 N-{3-[({2-[3-(aminomethyl)[1,1'-biphenyl]-4-yl]ethyl}amino)methyl]phenyl}thiophene-2-carboximidamide × 2 ACT ACETATE ION × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 3 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 CA CALCIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.90 Å R-free 0.218
9MWW Structure of human endothelial nitric oxide synthase heme domain bound with N-(3-(((2-(3-(aminomethyl)-[1,1'-biphenyl]-4-yl)ethyl)amino)methyl)phenyl)thiazole-5-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：heme domain
Chain B 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BTW N-{3-[({2-[3-(aminomethyl)[1,1'-biphenyl]-4-yl]ethyl}amino)methyl]phenyl}-1,3-thiazole-5-carboximidamide × 2 ACT ACETATE ION × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 ZN ZINC ION × 1 CA CALCIUM ION × 2 GD GADOLINIUM ATOM × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.80 Å R-free 0.231
9MWW Structure of human endothelial nitric oxide synthase heme domain bound with N-(3-(((2-(3-(aminomethyl)-[1,1'-biphenyl]-4-yl)ethyl)amino)methyl)phenyl)thiazole-5-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：heme domain
Chain D 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BTW N-{3-[({2-[3-(aminomethyl)[1,1'-biphenyl]-4-yl]ethyl}amino)methyl]phenyl}-1,3-thiazole-5-carboximidamide × 2 ACT ACETATE ION × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 6 CL CHLORIDE ION × 2 ZN ZINC ION × 1 GD GADOLINIUM ATOM × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.80 Å R-free 0.231
9MWX Structure of human endothelial nitric oxide synthase heme domain bound withN-(4-(2-((3-(thiazole-5-carboximidamido)benzyl)amino)ethyl)phenyl)thiazole-5-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：heme domain
Chain B 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BT5 N-[3-({[2-(4-{[(Z)-imino(1,3-thiazol-5-yl)methyl]amino}phenyl)ethyl]amino}methyl)phenyl]-1,3-thiazole-5-carboximidamide × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 CA CALCIUM ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.84 Å R-free 0.234
9MWX Structure of human endothelial nitric oxide synthase heme domain bound withN-(4-(2-((3-(thiazole-5-carboximidamido)benzyl)amino)ethyl)phenyl)thiazole-5-carboximidamide Deposited 2025-01-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：heme domain
Chain D 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BT5 N-[3-({[2-(4-{[(Z)-imino(1,3-thiazol-5-yl)methyl]amino}phenyl)ethyl]amino}methyl)phenyl]-1,3-thiazole-5-carboximidamide × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 3 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 CA CALCIUM ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.84 Å R-free 0.234
9MZ1 Structure of human endothelial nitric oxide synthase heme domain bound with 7-(3-aminomethyl)phenyl-6-fluoro-4-methylquinoin-2-amine Deposited 2025-01-22 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：heme domain
Chain B 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BUD (7P)-7-[3-(aminomethyl)phenyl]-6-fluoro-4-methylquinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 3 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.05 Å R-free 0.224
9MZ1 Structure of human endothelial nitric oxide synthase heme domain bound with 7-(3-aminomethyl)phenyl-6-fluoro-4-methylquinoin-2-amine Deposited 2025-01-22 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：heme domain
Chain D 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BUD (7P)-7-[3-(aminomethyl)phenyl]-6-fluoro-4-methylquinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 6 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 1 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.05 Å R-free 0.224
9MZ2 Structure of human endothelial nitric oxide synthase heme domain bound with 2-(2-amino-6-fluoro-4-methylquinolin-7-yl)-5-(aminomethyl)phenol Deposited 2025-01-22 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：UNP residues 41-480
Chain B 41–480（440 aa） Fragment：UNP residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BUF (2M)-2-(2-amino-6-fluoro-4-methylquinolin-7-yl)-5-(aminomethyl)phenol × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 CA CALCIUM ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.99 Å R-free 0.227
9MZ2 Structure of human endothelial nitric oxide synthase heme domain bound with 2-(2-amino-6-fluoro-4-methylquinolin-7-yl)-5-(aminomethyl)phenol Deposited 2025-01-22 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：UNP residues 41-480
Chain D 41–480（440 aa） Fragment：UNP residues 41-480
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BUF (2M)-2-(2-amino-6-fluoro-4-methylquinolin-7-yl)-5-(aminomethyl)phenol × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.99 Å R-free 0.227
9MZ3 Structure of human endothelial nitric oxide synthase heme domain bound 2-(2-amino-6-fluoro-4-methylquinolin-7-yl)-5-(2-aminoethyl)phenol Deposited 2025-01-22 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa） Fragment：heme domain
Chain B 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BUH (2M)-5-(2-aminoethyl)-2-(2-amino-6-fluoro-4-methylquinolin-7-yl)phenol × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 ACT ACETATE ION × 4 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 CA CALCIUM ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.95 Å R-free 0.250
9MZ3 Structure of human endothelial nitric oxide synthase heme domain bound 2-(2-amino-6-fluoro-4-methylquinolin-7-yl)-5-(2-aminoethyl)phenol Deposited 2025-01-22 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa） Fragment：heme domain
Chain D 41–480（440 aa） Fragment：heme domain
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BUH (2M)-5-(2-aminoethyl)-2-(2-amino-6-fluoro-4-methylquinolin-7-yl)phenol × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 ACT ACETATE ION × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.95 Å R-free 0.250
9MZ4 Structure of human endothelial nitric oxide synthase heme domain bound 7-(3-(aminomethyl)-4-(cyclopropylmethoxy)phenyl)-6-fluoro-4-methylquinolin-2-amine Deposited 2025-01-22 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BU3 (7P)-7-[3-(aminomethyl)-4-(cyclopropylmethoxy)phenyl]-6-fluoro-4-methylquinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 CA CALCIUM ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.94 Å R-free 0.254
9MZ4 Structure of human endothelial nitric oxide synthase heme domain bound 7-(3-(aminomethyl)-4-(cyclopropylmethoxy)phenyl)-6-fluoro-4-methylquinolin-2-amine Deposited 2025-01-22 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1BU3 (7P)-7-[3-(aminomethyl)-4-(cyclopropylmethoxy)phenyl]-6-fluoro-4-methylquinolin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 5 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.94 Å R-free 0.254
9Q4X Structure of human endothelial nitric oxide synthase heme domain bound with 6-((5-(2-(dimethylamino)ethyl)-2,3-difluorophenoxy)methyl)-4-methylpyridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1CN2 6-({5-[2-(dimethylamino)ethyl]-2,3-difluorophenoxy}methyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 CA CALCIUM ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.15 Å R-free 0.261
9Q4X Structure of human endothelial nitric oxide synthase heme domain bound with 6-((5-(2-(dimethylamino)ethyl)-2,3-difluorophenoxy)methyl)-4-methylpyridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1CN2 6-({5-[2-(dimethylamino)ethyl]-2,3-difluorophenoxy}methyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.15 Å R-free 0.261
9Q4Y Structure of human endothelial nitric oxide synthase heme domain bound with 6-((2,3-difluoro-5-(2-(methylamino)ethyl)phenoxy)methyl)-4-methylpyridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1CN3 6-({2,3-difluoro-5-[2-(methylamino)ethyl]phenoxy}methyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 ZN ZINC ION × 1 CA CALCIUM ION × 2 GD GADOLINIUM ATOM × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.10 Å R-free 0.293
9Q4Y Structure of human endothelial nitric oxide synthase heme domain bound with 6-((2,3-difluoro-5-(2-(methylamino)ethyl)phenoxy)methyl)-4-methylpyridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1CN3 6-({2,3-difluoro-5-[2-(methylamino)ethyl]phenoxy}methyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 ZN ZINC ION × 1 CA CALCIUM ION × 1 GD GADOLINIUM ATOM × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.10 Å R-free 0.293
9Q4Z Structure of human endothelial nitric oxide synthase heme domain bound with 6-((5-(2-(ethyl(methyl)amino)ethyl)-2,3-difluorophenxy)methyl)-4-methylphridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1CN4 6-[(5-{2-[ethyl(methyl)amino]ethyl}-2,3-difluorophenoxy)methyl]-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 CA CALCIUM ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.90 Å R-free 0.266
9Q4Z Structure of human endothelial nitric oxide synthase heme domain bound with 6-((5-(2-(ethyl(methyl)amino)ethyl)-2,3-difluorophenxy)methyl)-4-methylphridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1CN4 6-[(5-{2-[ethyl(methyl)amino]ethyl}-2,3-difluorophenoxy)methyl]-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.90 Å R-free 0.266
9Q51 Structure of human endothelial nitric oxide synthase heme domain bound with 6-((5-(2-(diethylamino)ethyl)-2,3-difluorophenxy)methyl)-4-methylpyridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1COA 6-({5-[2-(diethylamino)ethyl]-2,3-difluorophenoxy}methyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 CA CALCIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.80 Å R-free 0.228
9Q51 Structure of human endothelial nitric oxide synthase heme domain bound with 6-((5-(2-(diethylamino)ethyl)-2,3-difluorophenxy)methyl)-4-methylpyridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1COA 6-({5-[2-(diethylamino)ethyl]-2,3-difluorophenoxy}methyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.80 Å R-free 0.228
9Q52 Structure of human endothelial nitric oxide synthase heme domain bound with 6-((5-(2-(azetidin-1-yl)ethyl)-2,3-difluorophenxy)methyl)-4-methylpyridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1CN5 6-({5-[2-(azetidin-1-yl)ethyl]-2,3-difluorophenoxy}methyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.25 Å R-free 0.275
9Q52 Structure of human endothelial nitric oxide synthase heme domain bound with 6-((5-(2-(azetidin-1-yl)ethyl)-2,3-difluorophenxy)methyl)-4-methylpyridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1CN5 6-({5-[2-(azetidin-1-yl)ethyl]-2,3-difluorophenoxy}methyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 5 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.25 Å R-free 0.275
9Q53 Structure of human endothelial nitric oxide synthase heme domain bound with 6-((2,3-difluoro-5-(2-(piperidin-1-yl)ethyl)phenoxy)methyl)-4-methylpyridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1CN6 6-({2,3-difluoro-5-[2-(piperidin-1-yl)ethyl]phenoxy}methyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 CA CALCIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.88 Å R-free 0.253
9Q53 Structure of human endothelial nitric oxide synthase heme domain bound with 6-((2,3-difluoro-5-(2-(piperidin-1-yl)ethyl)phenoxy)methyl)-4-methylpyridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1CN6 6-({2,3-difluoro-5-[2-(piperidin-1-yl)ethyl]phenoxy}methyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 4 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 CA CALCIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 1.88 Å R-free 0.253
9Q54 Structure of human endothelial nitric oxide synthase heme domain bound with 6-((2,3-difluoro-5-(2-(3-fluoroazetidin-1-yl)ethyl)phenoxy)methyl)-4-methylpyridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1CN7 6-({2,3-difluoro-5-[2-(3-fluoroazetidin-1-yl)ethyl]phenoxy}methyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 2 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 CA CALCIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.13 Å R-free 0.281
9Q54 Structure of human endothelial nitric oxide synthase heme domain bound with 6-((2,3-difluoro-5-(2-(3-fluoroazetidin-1-yl)ethyl)phenoxy)methyl)-4-methylpyridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1CN7 6-({2,3-difluoro-5-[2-(3-fluoroazetidin-1-yl)ethyl]phenoxy}methyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.13 Å R-free 0.281
9Q55 Structure of human endothelial nitric oxide synthase heme domain bound with 6-((2,3-difluoro-5-(2-(4-fluoropiperidin-1-yl)ethyl)phenoxy)methyl)-4-methylpyridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1CN8 6-({2,3-difluoro-5-[2-(4-fluoropiperidin-1-yl)ethyl]phenoxy}methyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 3 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 ZN ZINC ION × 1 CA CALCIUM ION × 2 GD GADOLINIUM ATOM × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.10 Å R-free 0.229
9Q55 Structure of human endothelial nitric oxide synthase heme domain bound with 6-((2,3-difluoro-5-(2-(4-fluoropiperidin-1-yl)ethyl)phenoxy)methyl)-4-methylpyridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1CN8 6-({2,3-difluoro-5-[2-(4-fluoropiperidin-1-yl)ethyl]phenoxy}methyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 3 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 ZN ZINC ION × 1 GD GADOLINIUM ATOM × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.10 Å R-free 0.229
9Q58 Structure of human endothelial nitric oxide synthase heme domain bound with 6-((5-(2-(4,4-difluoropiperidin-1-yl)ethyl-2,3-difluorophenoxy)methyl)-4-methylpyridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 41–480（440 aa）
Chain B 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1CN9 6-({5-[2-(4,4-difluoropiperidin-1-yl)ethyl]-2,3-difluorophenoxy}methyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 2 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 CA CALCIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.03 Å R-free 0.259
9Q58 Structure of human endothelial nitric oxide synthase heme domain bound with 6-((5-(2-(4,4-difluoropiperidin-1-yl)ethyl-2,3-difluorophenoxy)methyl)-4-methylpyridin-2-amine Deposited 2025-08-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain C 41–480（440 aa）
Chain D 41–480（440 aa）
Not recorded HEM PROTOPORPHYRIN IX CONTAINING FE × 2 H4B 5,6,7,8-TETRAHYDROBIOPTERIN × 2 A1CN9 6-({5-[2-(4,4-difluoropiperidin-1-yl)ethyl]-2,3-difluorophenoxy}methyl)-4-methylpyridin-2-amine × 2 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 4 GOL GLYCEROL × 3 CL CHLORIDE ION × 2 GD GADOLINIUM ATOM × 2 ZN ZINC ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；10-12% PEG3350, 0.1M BIS-TRIS 0.2-0.3M MG ACETATE 0.1M GDCL3 10% GLYCEROL, 5 MM TCEP
Resolution 2.03 Å R-free 0.259

94 other PDB entries and 182 assemblies. Open the comparison page and filter oligomeric states

View Construct and Data Evidence
UniProt name NOS3_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 1–440； UniProt 41–480 Author chain B； PDBConstruct 1–440； UniProt 41–480 Author chain C； PDBConstruct 1–440； UniProt 41–480 Author chain D； PDBConstruct 1–440； UniProt 41–480

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

SAXS scattering curve SAXS Profile

SAXS profile for 8ufs

P(r) Distance Distribution P(r) Distribution

P(r) distribution for 8ufs
Download Download
▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id8ufs
Deposition date deposition_date2023-10-04
Structure title titleStructure of human endothelial nitric oxide synthase E361Q mutant heme domain obtain after soaking crystal with 4-methyl-7-(4-methyl-2,3,4,5-tetrahydrobenzo[f][1,4]oxazepin-7-yl)quinolin-2-amine dihydrochloride
Keywords keywordsnitric oxide synthase inhibitor, heme enzyme, OXIDOREDUCTASE; OXIDOREDUCTASE
Experimental Method methodX-RAY DIFFRACTION
▼

3. SAXS Parameters (CRYSOL theoretical calculation) 3. SAXS Parameters (CRYSOL)

Radius of gyration Rg (Guinier) rg_guinier43.47 Å
Radius of gyration Rg (electron density) rg_electron43.07 Å
Forward intensity I(0) i0535152000.00
Molecular weight molecular_weight189070.0 kDa
Excluded volume excluded_volume235440 ų
Envelope volume envelope_volume305780 ų
Hydration-shell volume shell_volume59042 ų
Envelope diameter envelope_diameter149.5 Å
Shell Rg shell_rg47.64 Å
Envelope Rg envelope_rg42.90 Å
Shape Rg shape_rg43.12 Å
Total Rg total_rg43.13 Å
Total atoms total_atoms13275
Residues n_residues1606
Spherical-harmonic order n_harmonics20
q range q_range— – 0.5000 Å−1
Data points n_points101
Shell type shell_typedirectional
Solvent electron density solvent_density0.3340 e/ų
Shell contrast contrast_shell0.0300 e/ų
CRYSOL version crysol_version4.1.3
▼

4. P(r) Distance Distribution (GNOM inversion) 4. P(r) Analysis (GNOM)

Maximum dimension Dmax dmax143.6 Å
Rg (real space) rg_real43.52 Å
Rg uncertainty (real space) rg_real_error1.14 Å
I(0) (real space) i0_real5.3520e+08
I(0) uncertainty (real space) i0_real_error8.9880e+06
Rg (reciprocal space) rg_reciprocal43.47 Å
I(0) (reciprocal space) i0_reciprocal535100000.0000
Solution quality estimate total_estimate0.8823
Solution quality rating solution_quality GOOD a GOOD solution
P(r) peaks n_peaks1
Primary peak position r_peak_primary39.9 Å
Skewness Skewness skewness0.285
Kurtosis Kurtosis kurtosis-0.602
Angular range angular_range— – 0.1800 Å−1
Current regularization parameter α current_alpha0.0000
Highest regularization parameter α highest_alpha133400000.0000
Real-space data points n_real_points37
GNOM version gnom_version4.1.3
Quality Criteria quality_criteria AN1: 0.000; Oscil: 0.900; Stabil: 1.000; Sysdev: 1.000; Positv: 1.000; Valcen: 0.964; Smooth: 0.802
▶

5. Crystallography and Experiment 5. Crystallography & Experiment

▶

6. Entities and Polymers Entities & Polymers (10)

▶

8. Citations (1)

▶

9. Files and Curves (10)
