8wzo

Parkin in complex with phospho NEDD8

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

E3 ubiquitin-protein ligase parkin

Homo sapiens

UniProt O60260

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 2 NEDD8 × 1 (Q15843) ZINC ION × 8 1,2-ETHANEDIOL × 3 water × 2 Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name PRKN_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A; PDBConstruct 1–325; UniProt 141–465

NEDD8

Homo sapiens

UniProt Q15843

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 2 E3 ubiquitin-protein ligase parkin × 1 (O60260) ZINC ION × 8 1,2-ETHANEDIOL × 3 water × 2 Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name NEDD8_HUMAN
Isoform —
PDB entities 2
Chains and sequence ranges Author chain B; PDBConstruct 2–77; UniProt 1–76

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id8wzo
Deposition date deposition_date2023-11-02
Structure title titleParkin in complex with phospho NEDD8
Keywords keywordsE3 Ligase, LIGASE; LIGASE
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

8wzo__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

8wzo__assembly_1__model_1 | I(q)

10-2 10-1 105 106 107 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

8wzo__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg(Guinier)25.32 Å
Rg (electron density)24.33 Å
Total Rg25.19 Å
Atom count2949
Residues377
Excluded volume52172 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 8wzo__assembly_1__model_1 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
▶
