9jkr

human GM-CSF with Fabs from autoantibodies, F1 and C.

Method: ELECTRON MICROSCOPY
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Granulocyte-macrophage colony-stimulating factor

Homo sapiens

UniProt P04141

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 5 Fab region of F1 antibody heavy chain × 1 Fab region of F1 antibody light chain × 1 Fab region of C antibody heavy chain × 1 Fab region of C antibody light chain × 1 Consistent with protein count

Other States of the Same Protein in the Database

Monomer
2gmf 2gmf

2 assemblies

Homodimer
1csg

1 assemblies

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
4nkq 4rs1 5c7x 5c7x 5d70 5d71 5d72 5d72 6bfq 6bfq 6bfq 6bfq

14 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name CSF2_HUMAN
Isoform —
PDB entities 5
Chains and sequence ranges Author chain I； PDBConstruct 1–127； UniProt 18–144

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id9jkr
Deposition date deposition_date2024-09-17
Structure title titlehuman GM-CSF with Fabs from autoantibodies, F1 and C.
Keywords keywordsAutoimmune pulmonary alveolar proteinosis, autoantibody, IMMUNE SYSTEM; IMMUNE SYSTEM
Experimental Method methodELECTRON MICROSCOPY
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

9jkr__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

9jkr__assembly_1__model_1 | I(q)

10-2 10-1 105 106 107 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

9jkr__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）28.44 Å
Rg (electron density)27.67 Å
Total Rg28.50 Å
Atom count4404
Residues567
Excluded volume78150 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 9jkr__assembly_1__model_1 pentameric （5） Success 4.1.3-1-20251215 (887e7ef) View Download
▶
